Toshiba Satellite C655D-S5200 LCD
Replacement
Here is a Toshiba C655D-S5200 that had a broken case. I did remove the LCD and feel this may
be helpful for anybody trying to replace the LCD. Straight forward and not to complicated.
Written By: oldturkey03
Toshiba Satellite C655D-S5200 LCD Replacement
© iFixit — CC BY-NC-SA www.iFixit.com Page 1 of 7

INTRODUCTION
Typical Toshiba and no service manuals available. The LCD on this laptop was removed for other
purposes. This is a straight forward task and only requires minimal tools.
TOOLS:
Phillips #00 Screwdriver (1)
iFixit Opening Tools (1)
Toshiba Satellite C655D-S5200 LCD Replacement
© iFixit — CC BY-NC-SA www.iFixit.com Page 2 of 7

Step 1 — LCD
Here is the Toshiba Satellite C655D-S5200
Open the laptop with the LCD facing forward. There are four rubber caps, one in each corner
Removing the plugs reveal the Phillips screws
Step 2
Remove all four screws, tow on top left and right corner
One on the bottom left corner
and the bottom right corner.
Here are the four M3x5mm screws
Toshiba Satellite C655D-S5200 LCD Replacement
© iFixit — CC BY-NC-SA www.iFixit.com Page 3 of 7

Step 3
Use a plastic opening tool, or similar to pop the bezel of the LCD assembly
Continue to slide the tool all the way across the top
Once the bezel has been released from the tabs, it can be further released be applying some gently
manual pulling

Step 4
Continue to pull gently on the sides
and finally on the bottom.
With all the tabs released the bezel can now be removed.
Toshiba Satellite C655D-S5200 LCD Replacement
© iFixit — CC BY-NC-SA www.iFixit.com Page 4 of 7

Step 5
Here is the LCD assembly without the bezel
Remove the Phillips screw that connects the LCD frame to the back cover. This is the left one
Remove the right one as well
Step 6
The LCD can now be moved forward and away from the rear cover
There are three screws on either side that hold the panel to the frame. Remove those
Here are the three M2x4 screws
Toshiba Satellite C655D-S5200 LCD Replacement
© iFixit — CC BY-NC-SA www.iFixit.com Page 5 of 7

To reassemble your device, follow these instructions in reverse order.
Step 7
Remove the three Phillips screws on the right side as well.
with the screws removed the panel can now be moved out of the LCD frame. The LCD is still
connected by the display cable.

The display cable is secured to the connector with some clear adhesive. Remove this frist
Step 8
Remove the display cable carefully.
With the display cable disconnected, the LCD can now be removed and replaced.
