Toshiba F45-AV412 - Qosmio - Core 2 Duo 1.8 GHz User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV412 Rev. 1.20 2007-07-10 DM T20070420 CB1.10 Page 2 of 6
Qosmio F45-AV412 Detailed Product Specification1
Model Name:F45-AV412 Part Number: PQF43U-008004 UPC: 032017912496
Operating System C1 2
•Genuine Windows Vista™ Ultimate (32-bit version)
Processor and Chipset3
Intel® Centrino® Duo processor technology featuring:
•Intel® Core™ 2 Duo Processor T71004
o1.80GHz, 2MB L2, 800MHz FSB with 64-bit C1
•Mobile Intel® GM965 Express Chipset
•Integrated Wi-Fi® compliant wireless LAN
oIntel® Wireless WiFi Link 4965AGN (802.11a/g/n)5
Memory6
•Configured with 2048MB PC2-5300 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 4096MB
•Intel® Turbo Memory
o1024MB
Hard Disk Drive7
•250GB (4200 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive8
oHD DVD-ROM/DVD9SuperMulti (+/- double layer) drive (in one
optical drive), supporting 12 formats
oMaximum speed and compatibility: HD DVD-ROM (1x), CD-ROM
(24x), CD-R (24x), CD-RW (10x), DVD-ROM (8x), DVD-R (4x),
DVD+R (4x),DVD-RW (4x), DVD+R (Double Layer (2.4x)), DVD-R
(Double Layer (2x)), DVD+RW (4x), DVD-RAM (3x)
Display10
•15.4" diagonal widescreen TruBrite®TFT active-matrix LCD display at
1280x800 native resolution (WXGA)
oMaximum Brightness – up to 200 Cd/m2
oContrast Ratio: 300:1
oHorizontal Viewing Angle: 120 Degree
oVertical Viewing Angle: 100 Degree
Graphics11
•Mobile Intel® Graphics Media Accelerator X3100 with 8MB-256MB
dynamically allocated shared graphics memory
Sound
•Two built-in harman/kardon® stereo speakers with subwoofer
•Sound Volume Control Dial
•Built-in microphone
Input Devices
•86 key US keyboard
•TouchPad™ pointing device
•TouchPad™ Enable/Disable
•Control Buttons:
oInternet button to launch default browser
oCD/DVD control buttons (Play/Pause, Stop, Prev Track, Next Track)
Communications
•Webcam and microphone built into LCD bezel
•Modem12
•10/100 Ethernet
•Integrated Wi-Fi® compliant wireless:13
oIntel® Wireless WiFi Link 4965AGN (802.11a/g/n)5
Expandability
•2 main memory slots. Both slots may be occupied.
•ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
•5-in-1 Bridge Media Adapter
oSecure Digital, Memory Stick™, Memory Stick PRO™, Multi Media
Card, xD Picture Card [shared slots]
Ports
•Video
oRGB (monitor) output port
oS-Video output port
•Audio
oS/P DIF output port (shared with headphone port)
oMicrophone input port
oHeadphone output port
•Data
oi.LINK(tm) IEEE-1394
oUSB v2.0 – 4 ports
•Security
oFingerprint reader
Physical Description
•Dimensions (WxDxH Front/H Rear): 14.9” x 11.0” x 1.50” /1.77” without
feet
•Weight: Starting at 6.6 lbs depending upon configuration14
•LCD Cover Color: Cosmic Black
Power
•90W (19V x 4.74A) 100-240V AC Adapter
•Dimensions (WxDxH): 5.24” x 1.21” x 2.28”
•Weight: starting at 0.89 lb
Battery15
•4000mAh Lithium Ion battery pack
•Dimensions (WxDxH): 4.72” x 3.31” x 1.06”
•Weight: starting at 0.73 lb
Software C1 16
•Toshiba Software and Utilities
oTOSHIBA Value Added Package
oElectronic User’s Guide
oBluetooth Stack for Windows by Toshiba
oTOSHIBA ConfigFree®
oTOSHIBA Assist
oTOSHIBA Security Assist
oTOSHIBA Disc Creator
oTOSHIBA Extended Tiles for Windows Mobility Center
oTOSHIBA HD DVD Player
oTOSHIBA Speech System
oTOSHIBA Remote Control Manager
•Third-party Software
oTOSHIBA Game Console
oMicrosoft Works Version 8.5
oSun® Java™ 2 Runtime Environment
oAdobe® Acrobat® Reader 8.0
oInterVideo®WinDVD® 8
oGoogle™ Desktop
oGoogle™ Toolbar
oGoogle Picasa™
oYahoo! Music™ Jukebox
oInfineon TPM Software Professional Package 3.0
oUlead® DVD MovieFactory® 5 for TOSHIBA
•Trial Software
oMicrosoft Office Trial Home and Student 2007 Edition (60-day trial)
oMcAfee® Internet Security Suite (30-day trial)
•Special Offers
oMicrosoft Office Live
oShutterfly digital photo service
oNapster® music subscription service
oeMusic MP3 music subscription service
oVONGOSM internet video download service
oebay®
oCNN Pipeline
oSkype™ internet communications
Environmental Specifications
Operating Non-operating
Temperature
17
5° to 35° C
(41° to 95° F) -20° to 65° C (-4° to 149° F)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)

This product specification is variable and subject to change prior to product launch.
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV412 Rev. 1.20 2007-07-10 DM T20070420 CB1.10 Page 3 of 6
Relative Humidity
(non-condensing) 20% to 80% 10% to 95%
Altitude
(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters
Shock 10G 60G
Vibration 0.5G 1.0G
•This product is RoHS18 compatible
QOSMIO – 1 YEAR STANDARD LIMITED WARRANTY19
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date.
Part Number Description
WSN-PEQQ2V 2nd Year Extended Service Plan
WSN-PEQQ3V 2nd/3rd Year Extended Service Plan
WSN-PEQQ4V 2nd/3rd/4th Year Extended Service Plan
SystemGuard Accidental Damage Service w/ ServiceExpress20
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Extended Service Plan included except with 1
Year plan. SystemGuard coverage must be purchased within the first 30
days of notebook purchase.
Part Number Description
WSN-PSGP1V 1st Year
WSN-PEGP2V 1st/2nd Year + Extended Service Plan
WSN-PEGP3V 1st/2nd/3rd Year + Extended Service Plan
SystemGuard Accidental Damage Service + On-Site Repair21
Combines SystemGuard and Business On-Site Repair coverage. Extended
Service Plan included except with 1 Year plan. SystemGuard coverage
must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PSGN1V 1st Year
WSN-PEGN2V 1st/2nd Year + Extended Service Plan
WSN-PEGN3V 1st/2nd/3rd Year + Extended Service Plan
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included except with 1
Year plan.
Part Number Description
WSN-PSQP1V 1st Year
WSN-PEQP2V 1st/2nd Year + Extended Service Plan
WSN-PEQP3V 1st/2nd/3rd Year + Extended Service Plan
On-Site Repair Service
On-site service will be provided at the customer’s home or business location
(excluding weekends and holidays) to perform the necessary hardware
repairs. Extended Service Plan included except with 1 Year plan.
Part Number Description
WSN-PSQN1V 1st Year
WSN-PEQN2V 1st/2nd Year + Extended Service Plan
WSN-PEQN3V 1st/2nd/3rd Year + Extended Service Plan
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade
Part Number Description
PA3512U-1M1G Toshiba 1GB DDR2-667 Memory Module
PA3513U-1M2G Toshiba 2GB DDR2-667 Memory Module
Power
Part Number Description
PA3290U-3ACA Toshiba 120W Global AC Adapter
PA3589U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)
Expansion
Part Number Description
PA3541U-2PRP dynadock USB Docking Station with video port (VGA)
PA3542U-2PRP dynadock USB Docking Station with video port (DVI)
Security & Protection
Part Number Description
PA3567U-1ETC Toshiba Keyboard Protector - 14"-15, 17” NBs (A4 size)
PA410U Targus DEFCON CL Cable Lock
Storage
Part Number Description
PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit
PA1411U-1M1G Toshiba 1GB USB Hi-Speed Flash Drive
PA1412U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive
Article I. Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Article II. Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com

This product specification is variable and subject to change prior to product launch.
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV412 Rev. 1.20 2007-07-10 DM T20070420 CB1.10 Page 4 of 6
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo
are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are
registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered
trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the
Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

This product specification is variable and subject to change prior to product launch.
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV412 Rev. 1.20 2007-07-10 DM T20070420 CB1.10 Page 5 of 6
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled
on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features
and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.
4Core™ 2 Duo Processor
Intel® Dual Core Technology is a new technology designed to deliver improved performance to the notebook PC. Performance or compatibility may vary. For more information on
Intel's Core 2 Duo processors, visit: http://www.intel.com/core2duo/
See 64-Bit Computing Legal Footnote, if applicable.
5Wireless-N. The Intel® Wireless Wi-Fi® Link 4965AGN (802.11a/g/n) adapter is based on a draft release version of the IEEE 802.11n specification, also known as “Draft-N”,
which may not be compatible with, or support all features (e.g., security) of, certain Wi-Fi® equipment.
6Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less
and will vary by model and system configuration.
7Hard Disk Drive (HDD) Capacity.
1 Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1
GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating
systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
8Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
9HD DVD Technology - General.
Because HD DVD is a new format that makes use of new technologies, certain disc, digital connection and other compatibility and/or performance issues are possible. Advanced
interactive and navigation features of the HD DVD Video format including, but not limited to, Picture in Picture (PIP) and network streaming features are not supported by this

This product specification is variable and subject to change prior to product launch.
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio F45-AV412 Rev. 1.20 2007-07-10 DM T20070420 CB1.10 Page 6 of 6
product. HD DVD Application Logo (HD DVD-ROM) represents the optical drive’s conformity with the DVD Forum’s verification criteria for HD DVD physical format, and does not
represent compliance with the HD DVD Video specification defined by the DVD Forum.
Advanced Access Content System (AACS) keys are integrated into your computer for copy protection purposes. Occasional renewal of the AACS key is required, and easily done
by connecting to the Internet. AACS key renewal will be provided at no charge to purchasers. If the AACS key is not renewed, the HD DVD player software will stop playing
AACS-protected HD DVD content. However, it will continue to play other forms of content, such as DVD discs or non-protected HD DVD content. For more information on AACS
key, visit www.aacsla.com/home.
HD DVD Playback Capabilities.
Depending on HD DVD content, you may experience “frame dropping” or lower performance. HD DVD viewing on external display requires an HDCP capable HDMI™ input.
External power required for viewing of HD DVD content. Since CPU power is dedicated to support HD DVD playback function, you must close all other applications during HD DVD
playback. Audio content sampled using Linear PCM and having a quality higher than 48kHz/16bit will be down sampled to 48kHz/16bit.
10 Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
11 Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized
when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary
depending on system memory size and other factors.
12 Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
13 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access
points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic
environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the
theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless function, if available, your client and access point must support the corresponding feature.
Performance of these functions may vary depending on the format of data transmitted.
14 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
15 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as
well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations
tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while
computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
Battery life will be less than when using similar applications in the Windows Operating System
16 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office Small Business Accounting 2006) which may be included with this computer.
The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation
procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which
time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without
charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the
perpetual version of such Office Product.
For systems with Microsoft Money Essentials 2007 installed, note that some online services for Microsoft® Money 2007 and Microsoft® Money 2007 Essentials will expire on the
earlier of two years after your activation of the software or September 1, 2009. Also, you may need to get some online services separately from your financial institution, which may
charge a fee. See the online services policy at http://money.msn.com/Money/2007/OSP.asp.
17 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
18 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
19 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
20 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
21 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
