Toshiba L645D-S4030 User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L645D- 4030 Page 1 of 4
Satellite L645D Detailed Product Specification
1
Model Name:
L64
5
D
-
S4030
Part Number:
PSK0
U
-
00 004
UPC:
883974499458
Operating System
C1 2
• Genuine Windows
®
7 Home Premium 64-bit
Processor
3
and Graphics
4
VISION PremiumTechnology from AMD Featuring
• AMD Turion™ II Dual Core Processor P520
o 2.3 GHz, 2MB L2 Cache
• AMD M880G Chipset with ATI Mobility Radeon™ HD 4250 Graphics
with 256MB-1917MB dynamically allocated shared graphics memory
Memory
5
• Configured with 4GB DDR3 (max 8GB)
Storage Drive
6
• 320GB (5400 RPM); erial ATA hard disk drive
Fixed Optical Disk Drive
7
• DVD uperMulti drive with Labelflash
®
supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (6x),
DVD-RW (6x), DVD+R (8x), DVD+R DL (6x), DVD+RW (8x),
DVD-RAM (5x)
o Uses Labelflash
®
media to burn high quality labels directly to disc
Display
8
• 14.0” diagonal widescreen HD TruBrite
®
TFT LED display at 1366x768
native resolution
o Native support for 720p content
o 16:9 aspect ratio
Sound
• Built-in stereo speakers
• DOLBY
®
Advanced Audio™
Input Devices
• Premium U keyboard (black)
• TouchPad™ pointing device with multi-touch control
• TouchPad™ Enable/Disable
Communications
• Webcam and microphone
• 10/100 Ethernet
• 802.11b/g/n wireless LAN
9
Expandability
• 2 main memory slots accessible from the bottom. Both slots occupied.
• Memory Card Reader
o ecure Digital, ecure Digital High Capacity, mini ecure Digital,
Memory tick™ , Memory tick PRO™ , Multi Media Card,
(shared slot-may require adapter for use)
Ports
• Video
o RGB
• Audio
o Microphone input port
o Headphone output port
• Data
o U B v2.0 – 3 ports
o 2 x U B v2.0
o 1 x e ATA/U B combo port
o RJ-45 LAN port
Physical Description
• Fusion™ Finish in Helios Grey
• Dimensions (W x D x H Front/H Rear): 13.3” x 9.13” x 1.34”/1.50”
without feet
• Weight: tarting at 4.98 lbs, depending upon configuration
10
Power
• 65W (19V 3.42A) 100-240V/50-60Hz AC Adapter.
o Dimensions (W x H x D): 4.21” x 1.85” x 1.20”
Battery
11
• 6 cell/48Wh Lithium Ion battery pack,
• Battery Life Rating (measured by MobileMark™ Productivity 2007)
o Included 6 cell battery: 4 hours, 10 minutes
Software
C1
12
• Toshiba oftware and Utilities
o TO HIBA Recovery Disc Creator
o TO HIBA ervice tation
o TO HIBA Face Recognition
o TO HIBA HW etup Utility
o TO HIBA Value Added Package
o TO HIBA Web Camera Application
o TO HIBA Disc Creator
o TO HIBA PC Health Monitor
o TO HIBA Eco Utility
o TO HIBA upervisor Password Utility
o TO HIBA Media Controller Plug-in
o TO HIBA Assist
o TO HIBA Media Controller
13
o TO HIBA Bulletin Board
o TO HIBA ReelTime
• Third-party oftware
o Microsoft
®
Works 9
o Microsoft
®
Windows Media Player 12
o Microsoft
®
ilverlight™
o Microsoft
®
Windows
®
Live™ Essentials including Photo Gallery,
Messenger, Mail, Writer and Movie Maker
o Microsoft
®
Internet Explorer 8
o Corel
®
Label@Once
o Adobe
®
Acrobat
®
Reader
o Google
®
Toolbar
o un
®
Java™ 2 Runtime Environment
o WildTangent
®
Orb™ Game Console
• pecial Offers and Trial oftware
o Microsoft
®
Office Home and tudent 2007 Edition 60-day trial
o Norton Internet ecurity™ 2010 (30-day trial subscription)
Environmental Specifications
• This product is RoH
14
compatible
• Energy tar Qualified
• EPEAT™ Gold Compliant
Operating Non-operating
Temperature
15
5° to 35° C -20° to 60° C
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Relative Humidity
(non-condensing)
20% to 90% 10% to 95%
Altitude
(relative to sea level)
0 to 10,000 meters 0 to 40,000 meters
hock 10G 60G
Vibration 0.5G 1.0G
1 YEAR STANDARD LIMITED WARRANTY
16
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as ystemGuard
®
,
On- ite Repair, and erviceExpress to provide additional support to your

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L645D- 4030 Page 2 of 4
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Accessories -
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade
Part Number Description
PA3676U-1M2G Toshiba 2GB DDR3-1066 memory module
PA3677U-1M4G Toshiba 4GB DDR3-1066 memory module
Power
Part Number Description
PA3717U-1ACA Toshiba 120W Global AC Adapter
PA3818U-1BR Toshiba Primary Li Ion Battery Pack(6 cell)
PA3819U-1BR Toshiba Primary High Capacity Li Ion Battery Pack (12
cell)
Expansion
Part Number Description
PA3778U-1PRP dynadock V U B Docking tation with DVI/VGA port
PA3575U-1PRP dynadock U U B Docking tation with DVI/VGA port
Carrying Case
Part Number Description
PA1445U-1C 4 Toshiba 14” Envoy eries Ballistic Polyester Carrying
Case
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
ystems, Inc. (“TAI ”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAI dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information ystems, Incorporated (“TAI ”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAI website for resellers: http://sell.toshiba.com
TAI PC upport website: http://pcsupport.toshiba.com
Qosmio, atellite, Portégé, Tecra, electBay, ConfigFree, ystemGuard, EasyGuard are registered trademarks of Toshiba America Information ystems, Inc.
and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating ystem
- 64-bit CPU, Chipset and BIO (Basic Input/Output ystem)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. ee "Detailed pecs" for more information.
1
Product Series Legal Footnote. The product specifications and configuration information are designed for a product eries. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information ystems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2 Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3 Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L645D- 4030 Page 3 of 4
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed pecs.” Contact Toshiba Technical
ervice and upport for more information.
4 Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memor is the total of, as applicable, Dedicated Video Memory, ystem Video Memory and hared ystem Memory. hared ystem Memory will vary
depending on system memory size and other factors.
5 Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6 Storage Drive
Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer
includes one or more pre-installed operating systems, such as Microsoft Operating ystem and/or pre-installed software applications, or media content. Actual formatted capacity
may vary.
7 Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8 Display. mall bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9
Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment
.
10 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
11 Batter Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. ee “Detailed pecifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com
Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any individual user. Actual battery life may vary considerably from
specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by
the design of individual components. The battery life rating is only achieved on the select models and configurations tested by Toshiba under the specific test settings at the time of
publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.
After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
12 Software. ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software products (including Microsoft Office mall Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office mall Business Accounting 2006) which may be included with this computer.
The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation
procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which
time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without
charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L645D- 4030 Page 4 of 4
perpetual version of such Office Product.
13
Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.
14 RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous ubstances in electrical and electronic equipment
(RoH ), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoH requirements
and verifies its suppliers' commitment to meeting RoH requirements by conducting component sampling inspections during the product design approval process.
15 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
16 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
