TOSHIBA
Tecra M3 Series
Model Name Description Part Number UPC
Tecra M3-S331 Intel Pentium® M Processor 740 [1.73GHz, 2MB L2 cache, 533MHz FSB], 14.1”
diagonal TFT active-matrix XGA LCD display at 1024x768 native resolution, 512MB
(512MBx1) Memory, 60GB (4200 RPM) HDD, CD-RW/DVD-ROM, Intel PRO/Wireless
2200BG (802.11b/g), nVIDIA GeForce Go 6200 TE 64M (64MB), 6-cell battery, Microsoft
Windows XP Professional, 3-year limited warranty
PTM30U-02X00L 032017324817
System Characteristics1
Operating System
•Microsoft® Windows® XP Professional
Intel® Centrino™ Mobile Technology featuring:
Intel Processor2:
•Intel Pentium M Processor 740 [1.73GHz, 2MB L2 cache,
533MHz FSB]
Chipset
•Mobile Intel 915PM Express Chipset
Integrated Wi-Fi™ compliant wireless LAN:
•Intel PRO/Wireless 2200BG (802.11b/g)
Memory
•512MB (Min)/2048MB (Max), 2 memory slots using 256MB,
512MB, or 1024MB DDR2 533MHz PC2-4200 SDRAM 2.5V
SODIMM memory modules; both slots may be occupied.
Mass Storage
Hard Drive3
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M3-S331 BTS Rev. 1.04 2005-04-05 PT CB 1.20 Page 1 of 4
•60GB (4200 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drives
•Select Bay CD-RW/DVD drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-RW (read),
DVD+R (read), DVD-RAM (read)
Display4
•14.1” diagonal TFT active-matrix LCD XGA display at 1024x768
native resolution; Maximum Brightness 145 Cd/m2
•Brightness Control [keyboard: Fn+F6 (decrease brightness) or
Fn+F7 (increase brightness)]
Graphics5
•nVIDIA® GeForce™ Go 6200 TE 64M with dedicated 64MB
DDR SDRAM
Input Devices
•Keyboard
o85 key US keyboard, 2.7mm key stroke, 6mm keyboard
height, 19.05mm key pitch
oHot Key Functions (FN); please see electronic User’s Guide
for more information
•Pointing Device: Toshiba dual point device
Expandability
•2 main memory slots. Both slots may be occupied.
•1 PC Card slot; supports 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
•1 slot for ExpressCard/34 or ExpressCard/54 (extended) module
support
•Secure Digital® slot
•240-pin Advanced Port Replicator III docking connector
Communications
•Integrated V.92 modem6
•Marvell® PC Express Network Connection – 10Base-
T/100Base-TX/1000Base-TX Ethernet
•Optional Bluetooth Version 1.2 available (see Accessories)
•Wireless-LAN:7Integrated Intel Pro/Wireless Network
Connection 2200BG (802.11b/g)
Ports
•Parallel port
•RGB (monitor) port
•Fast Infrared (4Mbps) port
•2 Universal Serial Bus (USB) ports (v2.0)
•TV-out (S-Video)
•RJ-11 modem port
•RJ-45 LAN port
•i.LINK™ IEEE-1394
•240-pin docking connector for Advanced Replicator III
•Microphone jack
•Headphone jack
Physical Description
•Dimensions (WxDxH Front/H Rear): 12.36'' (314.0mm) x 10.20''
(259.0mm) x 1.24'' (31.5mm)[F]/1.37'' (34.9mm)[R] without feet
•Weight8: 4.98 lb. (2260 g) (min) ~ 6.11 lb. (2770 g) (max)
depending upon configuration
•Indicators: Power, DC-IN, Primary HDD/ODD Access, Caps
Lock (keyboard), Arrow Mode (keyboard), Numeric Mode
(keyboard)
•Case material: PC+ABS Plastic; Magnesium alloy LCD Cover
painted Premium Silver; Premium Black for LCD Mask, Cover,
and Base.
Sound
•Analog Devices AD1981B Software Sound
•16-bit stereo; Built-in stereo speakers, Built-in microphone
•Direct3D Sound; DirectSound, Direct Music, MIDI (playback)
Support
•Sound Volume Control Dial
Power Supply
•75W (15V x 5A) Auto sensing external AC Adapter, 100-
240V/50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 5.00'' (127.0mm) x 1.20'' (30.5mm) x
2.01'' (51.0mm)
•Weight: starting at 0.78 lb. (355 g)
Battery9
•6-cell (4700mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
oBattery Life: Up to 3 hours 25 minutes (measured by
MobileMark™) (6-cell battery) 10
oWeight: approximately 0.75 lb. (338 g)
oDimensions (WxDxH): 8.15'' (207.0mm) x 1.77'' (45.0mm) x
0.79'' (20.0mm)
oMain Battery Recharge Time: up to 3 hours (system off) or up
to 13 hours (system on)
Optional Slim Select Bay Second Battery (see Accessories):
•6-cell (3600mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
oWeight: approximately 0.62 lb. (280 g)
oDimensions (WxDxH): 4.21'' (107.0mm) x 4.72'' (120.0mm) x
0.51'' (13.0mm)
oBattery Life: Up to 6 hours 5 minutes (measured by
MobileMark) (6-cell primary battery plus 6-cell optional
secondary battery)
oBattery Recharge Time: 6-cell Main Battery plus 6-cell
Second Battery: up to 6 hours (system off) or up to 22
hours 30 minutes (system on); or,
Security
•Slot for cable lock;
•Items protected by a screw: Memory, Main Battery (by sliding
lock); Main HDD (by screws only), SelectBay Device (by screw
only)
•Passwords: User Power-on password, Supervisor Password,

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M3-S331 BTS Rev. 1.04 2005-04-05 PT CB 1.20 Page 2 of 4
HDD Password
•Other locks: Keyboard Lock (by Hotkey), Screen Blank (by
Hotkey), Screen Saver (by Software).
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS
v2.34, PC BIOS v2.2 support
Software11
Toshiba Software and Utilities
•Toshiba ConfigFree™
•Toshiba Custom Utilities
•Electronic User’s Guide
Third-party Software
•Microsoft Office® OneNote™ 2003
•Microsoft Works™ Version 8.0
•Sun® Java™ 2 Runtime Environment
•Adobe® Acrobat® Reader version 5.0
•Software Decoder: InterVideo® (WinDVD™ 5)
•InterVideo WinDVD Creator 2 Platinum
•Sonic™ PrimeTime
•Sonic Solutions RecordNow!™ Basic for Toshiba
•Sonic Solutions Drive Letter Access (DLA)
•Microsoft Windows Media Player version 10
•Napster® Digital Music Service – 30 days trial
•Computer Associates Easy FireWall – 30 days trial
•Norton® AntiVirus™ 2004 – w/3-Month Subscription
•AOL® version 9.0 – 3-Month offer
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL
BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services
carry surcharges and communication surcharges may apply, including AK, even
during promotional period. Members may incur telephone charges on their phone bill,
depending on their location and calling plan, even during promotional period.
Available to new AOL members in the United States, age 18 or older; a major credit
card or checking account is required.
•AT&T® Worldnet® Service – 1 Month offer
Telephone access and other charges and other terms and conditions may apply.
Offer available to new customers only,
•Intuit® Quicken® New User Edition 2004
•QuickTime™ Player
•RealOne™ Player 8 Basic
Environmental Specifications
Operating Non-Operating
Temperature 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour maximum 20°C per hour
maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to
sea level) -60 to 3000 meters -60 to 10,000 meters
Shock 7G;
1.5G when CDRW-DVD
ROM device installed
60G
Vibration 0.2G;
0.25G when CDRW-DVD
ROM device installed
1.0G
Limited Warranty
•3-year standard, limited warranty
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description and
complete list of programs, please visit
http://www.accessories.toshiba.com
Recommended Services for Products with a
3-year Standard, Limited Warranty
Warranty Extension
Extends the standard warranty for up to 4 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at www.pcsupport.toshiba.com.
Part Number Description
SWC-PTQQ4V 4th Year Warranty Extension
SystemGuard Accidental Damage Coverage1
Provides coverage of accidental damage caused by drops, spills and
even screen breakage. Warranty Extension included except with 1 Year
plan.
Part Number Description
SWC-PSGQ1V 1st/2nd/3rd Year
SWC-PTGQDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGQ4V 4th Year Only + Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Notebook repaired the same day it is received,
and returned via overnight delivery. Shipping and box provided. Carry-In
Express: Notebook repaired by the next business day at any Premier
Authorized Service Provider. Warranty Extension included except with 1
Year plan.
Part Number Description
SWP-PQQP3V 1st/2nd/3rd Year
SWC-PTQPDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTQP4V 4th Year Only + Warranty Extension
Business On-Site Repair
A technician arrives with parts at the customer’s business location the
next business day and performs the necessary hardware repairs.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWP-PQQN3V 1st/2nd/3rd Year
SWC-PTQNDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTQN4V 4th Year Only + Warranty Extension
SystemGuard1 + ServiceExpress
Combines SystemGuard and ServiceExpress coverage. Warranty
Extension included except with 1 Year plan.
Part Number Description
SWP-PQGP3V 1st/2nd/3rd Year
SWC-PTGPDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGP4V 4th Year Only + Warranty Extension
SystemGuard1 + Business On-Site Repair
Combines SystemGuard and Business On-Site Repair coverage.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWP-PQGN3V 1st/2nd/3rd Year
SWC-PTGNDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGN4V 4th Year Only + Warranty Extension
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory
Part Number Description
KTT533D2/512 Kingston 512MB DDR2
KTT533D2/1G Kingston 1GB DDR2
Power
Part Number Description
PA3283U-2ACA Toshiba 75W Global AC Adapter
PA3356U-2BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3357U-1BRL Toshiba Primary High Capacity Li Ion Battery Pack
(12 Cell)
PA3129U-2BRS Toshiba Slim SelectBay 2nd 3600mAh Battery Pack
PA3091U-1CHG Toshiba Battery Charger w/Integrated AC Adapter
Cases-Security
Part Number Description
PA1360U-1NCS Toshiba Executive Nylon Case (15.4")
PA1361U-1NCS Toshiba Executive Leather Case (15.4")
PA1362U-1NCS Toshiba BackPack (15.4")
PA1376U-1NCS Toshiba/Brenthaven SlimLine Case 14.1"
PA1377U-1NCS Toshiba/Brenthaven Deluxe Shoulder Case 15.4"
PA1378U-1NCS Toshiba/Brenthaven Wheeled Case 17"
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Expansion
Part Number Description
PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC
Adapter

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M3-S331 BTS Rev. 1.04 2005-04-05 PT CB 1.20 Page 3 of 4
Input Devices
Part Number Description
PA1336U-1NKB Toshiba USB Keyboard
PA1337U-1NMS Toshiba USB Optical Scroller Mouse
PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller Mouse
PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC adapter)
PA1370U-1ETC Toshiba Keyboard Protector (Tecra/Satellite/Qosmio)
Storage and Backup
Part Number Description
PA3404U-1H40 Toshiba USB Mobile Hard Drive 40GB (1.8")
UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup System
UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup System
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
Slim Select Bay
Part Number Description
PA3231U-1DV1 Toshiba Slim SelectBay DVD Multi Drive Kit (Black)
PA3359U-1DV2 Toshiba Slim SelectBay DVD SuperMulti Drive Kit
(Black)
PA3204U-1H60 Toshiba 60GB 5400 rpm HDD Kit, (with Bracket)
PA3230U-1H80 Toshiba 80GB 5400 rpm HDD Kit, (with Bracket)
PA3134U-1ETC Toshiba Slim SelectBay HDD Adapter (Black Bezel)
PA3306U-1H60 Toshiba 60GB 7200 rpm HDD Kit, (with Bracket)
Multimedia
Part Number Description
PA3390U-1MPM Toshiba MultiMedia Center/Audio USB Hub
Wireless LAN
Part Number Description
PA3363U-2MPC Wireless LAN Card Kit, Mini-PCI (802.11g) (Intel)
[dealer install only]
PA3376U-1MPC Wireless LAN Card Kit, Mini-PCI (802.11ag) (Intel)
[dealer install only]
PA3318U-2MPC Wireless LAN Card Kit, Mini-PCI (802.11ag)
(Atheros) [dealer install only]
Bluetooth
Part Number Description
PA3425U-1BTM Bluetooth Module Kit (V1.2) [dealer install only]
PA3405U-1BTM Toshiba Bluetooth USB adapter
PA1381U-1ETC Toshiba Bluetooth Headphones
PA1380U-1NMS Toshiba Bluetooth Travel Mouse
PA3370U-1BTM Toshiba Bluetooth SD Card V1.2
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://pcsupport.toshiba.com. The product
specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or
illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
http://pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your select model may not have all the
features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.
2CPU performance in your computer product may vary from specifications under the following conditions:
1. Use of certain external peripheral products
2. Use of battery power instead of AC power
3. Use of certain multimedia, computer generated graphics or video applications
4. Use of standard telephone lines or low speed network connections
5. Use of complex modeling software, such as high end computer aided design applications
6. Use of several applications or functionalities simultaneously
7. Use of computer in areas with low air pressure (high altitude greater than 1,000 meters or greater than 3,280 feet above sea level)
8. Use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at
www.pcsupport.toshiba.com for details.)
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions
under “Environmental Conditions” in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.
3One (1) Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage
capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available
storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-
installed software applications, or media content. Actual formatted capacity may vary.

TOSHIBA
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra M3-S331 BTS Rev. 1.04 2005-04-05 PT CB 1.20 Page 4 of 4
4Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT)
and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT
manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an
intrinsic characteristic of LCD technology.
5Graphics processor unit ("GPU") performance may vary depending on product model, design configuration, applications, power management settings and
features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power
mode. The graphics processor is optimized for this specific computer model and GPU performance will be slower than the standard nVIDIA® GeForce™ Go
6200/6600. GPU performance is only optimized at ambient temperatures between 5C and 30C.
6Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
7Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone
charges or air time to achieve the functionality as advertised. The transmission speed over the wireless LAN and the distance over which wireless LAN can
reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and
software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
8Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
9Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at
maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that
shipped with your computer or visit the Toshiba web site at http://www.accessories.toshiba.com.
10 MobileMark™ is a registered trademark of Business Applications Performance Corporation.
11 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
