Satellite L515 Detailed Product Specification
1
Model Name
:
L515
-
S4960
Part Number:
PSLQ0
-
00C006
PC:
883974308491
Operating System
C1 2
• Genuine Windows
®
7 Home Premium 32-bit
Processor
3
and Graphics
4
• Intel
®
Pentium
®
processor T4300
o 2.10GHz, 1MB L2 Cache, 800MHz F B
• Mobile Intel
®
GL40 Express Chipset
• Intel
®
Graphics Media Accelerator 4500M with dynamically allocated
shared graphics memory
Memory
5
• Configured with 3GB DDR2 (max 4GB)
Storage Drive
6
• 320GB (5400 RPM) erial ATA hard disk drive
Fixed Optical Disk Drive
7
• DVD uperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R ( ingle Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R ( ingle
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
Display
8
• 14.0” diagonal widescreen TruBrite
®
TFT LCD display at 1366x768
native resolution (HD)
o Native support for 720p content
o LED backlight
Sound
• Built-in stereo speakers
• ound volume control dial
Input Devices
• 86 key U keyboard (black)
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
Communications
• Modem
9
• 10/100 Ethernet
• Realtek
®
802.11b/g wireless LAN
10
Expandability
• 2 main memory slots. Both slots may be occupied.
• Memory Card Reader
o ecure Digital, ecure Digital High Capacity, Mini D Card,
Micro D Card, Memory tick™, Memory tick PRO™, Multi
Media Card [shared slot]
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o 3 U B v2.0 ports
o 2 x U B v2.0 ports
o 1 x e ATA/U B port
o RJ-45 LAN port
o RJ-11 modem port
• ecurity
o lot for ecurity Lock
Physical Description
• Fusion™ Finish with Breeze Pattern in Graphite Gray
• Dimensions (W x D x H ): 13.4” x 9.13” x 1.32”/1.50”
• Weight: tarting at 5.07 lbs., depending upon configuration
11
Battery
12
• 3700 mAh (6 cell) Lithium Ion battery pack
• Battery Life (measured by MobileMark™ 2007)
13
o Included 6 cell battery: 3 hours, 10 minutes
Power Supply
• 65W (19V x 3.42A) Auto-sensing ,100-240V/50-60Hz AC Adapter
• Dimensions (W x D x H): 4.3” x 1.8” x 1.2”
• Weight: starting at .49 lbs.
Software
C1
14
• Toshiba oftware and Utilities
o Electronic User’s Guide
o Bluetooth tack for Windows by Toshiba
o TO HIBA Recovery Media Creator
o TO HIBA ConfigFree
®
o TO HIBA Disc Creator
o TO HIBA DVD Player
o TO HIBA PC Health Monitor
o Hard Disc Drive (HDD) Recovery
• Third-party oftware
o Microsoft
®
Windows Media Player
o Microsoft
®
Works 9
o Internet Explorer 8
o Adobe
®
Acrobat
®
Reader
o Google™ Toolbar
o un
®
Java™ 2 Runtime Environment
o WildTangent
®
Orb™ Game Console
• Trial oftware
o Norton Internet ecurity™ 2009, 30-day trial
o Microsoft
®
Office Home and tudent 2007 Edition, 60-day trial
• pecial Offers
o Toshiba Online Backup
o NetZero
®
Internet ervice
o kype
®
o Intuit
®
Quickbooks
®
Financial Center
Environmental Specifications
• This product is RoH
15
compatible
• Energy tar 5.0 Qualified
• EPEAT™ Gold Compliant
Operating Non-operating
Temperature
16
5° to 35° C -20° to 60° C
Relative Humidity
(non-condensing)
20% to 80% 10% to 90%
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Altitude
(relative to sea level)
0 to 3,000 meters 0 to 10,000 meters
hock 10G 60G
Vibration 0.5G 1.0G
1 YEAR STANDARD LIMITED WARRANTY
17
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
Service pgrades and Extensions
Toshiba offers many different enhanced services such as ystemGuard
®
,
On- ite Repair, and erviceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L515- 4960 Page 2 of 4
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory pgrade
Part Number Description
PA3669U-1M2G Toshiba 2GB DDR2-800 Memory Module
Power
Part Number Description
PA3290U-3ACA Toshiba 120W Global AC Adapter
PA3635U-1BRM Toshiba Primary Li Ion Battery Pack (6 cell)
PA3728U-1BR Toshiba Primary High Capacity Li Ion Battery Pack
(12 cell)
Expansion
Part Number Description
PA3575U-1PRP Toshiba dynadock U Universal Docking tation
PA3579U-1ETC Toshiba Universal Notebook/Projector tand
Storage
Part Number Description
PA3556U-1M2G Toshiba 2GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M4G Toshiba 4GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M8G Toshiba 8GB U B Hi- peed Flash Drive, ReadyBoost
HDDR320E04XW Toshiba External U B Hard Drive, 320GB (White)
HDDR500E04XL Toshiba External U B Hard Drive, 500GB (Blue)
HDDR640E04XR Toshiba External U B Hard Drive, 640GB (Red)
Protection
Part Number Description
PA3567U-1ETC Toshiba Keyboard Protector
Bluetooth
Part Number Description
PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/ ilver)
PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/Red)
Carrying Case
Part Number Description
PA1457U-1CL4 Toshiba 14” Envoy Leather Carrying Case (Fits up to
14.1”)
PA1445U-1C 4 Toshiba 14" Envoy Ballistic Polyester Carrying Case
(Fits up to 14.1")
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
ystems, Inc. (“TAI ”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAI dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information ystems, Incorporated (“TAI ”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAI website for resellers: http://sell.toshiba.com
TAI PC upport website: http://pcsupport.toshiba.com
atellite, ConfigFree and ystemGuard are registered trademarks of Toshiba America Information ystems, Inc. and/or Toshiba Corporation. All other
products and names mentioned are the property of their respective owners.
C1
64-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating ystem
- 64-bit CPU, Chipset and BIO (Basic Input/Output ystem)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. ee "Detailed pecs" for more information.
1
Product Series Legal Footnote . The product specifications and configuration information are designed for a product eries. Your particular model may not
have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote . Toshiba America Information ystems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2
Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L515- 4960 Page 3 of 4
3
Processor (Central Processing nit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed pecs.” Contact Toshiba Technical
ervice and upport for more information.
4
Graphics (Graphics Processing nit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, ystem Video Memory and hared ystem Memory. hared ystem Memory will vary
depending on system memory size and other factors.
5
Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6
Storage Drive (Internal HDD Capacity). One Gigabyte (GB) means 109 = 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000 bytes using powers of
10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB = 240 =
1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed operating
systems, such as Microsoft Operating ystem and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7
Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8
Display. mall bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9
Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
10
Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access
points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic
environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the
theoretical maximum speed. To use the Atheros uperAG™ or uperG™ wireless function, if available, your client and access point must support the corresponding feature.
Performance of these functions may vary depending on the format of data transmitted.
11
Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12
Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as
well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations
tested by Toshiba at the time of publication. ee “Detailed pecs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while
computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
13
Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
14
Software. Also see 64-Bit Computing Legal Footnote, if applicable.
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Microsoft® Office 2007 60-Day Trial Version: This trial software will work for 60 days after you first use it. You will not be able to use the software if you do not activate it as
described the first time you use the software. You can activate the software by Internet. Internet service charges may apply. If you want to keep the software after the 60-day trial
period, you must convert to the perpetual version. You can convert online by following the conversion instructions presented during setup and paying the required fees.

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite L515- 4960 Page 4 of 4
15
RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous ubstances in electrical and electronic equipment
(RoH ), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoH requirements
and verifies its suppliers' commitment to meeting RoH requirements by conducting component sampling inspections during the product design approval process.
16
Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
17
Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
