Tecra M4-S635 Detailed Product Specification1

Model Name Description Part Number UPC

Tecra M4-S635 Microsoft® Windows® XP Tablet Edition 2005, Intel Pentium® M Processor 750,

512MB DDR2, 80GB 5400rpm SATA, DVD SuperMulti (+R double layer) drive, 14.1”

diagonal TFT SXGA+, NVIDIA GeForce™ Go 6200 TE with 64MB DDR, Integrated

Intel Pro/Wireless Network Connection 2200BG (802.11b/g), 3-year standard limited

warranty; 1-year standard limited warranty on battery and AC adapter.

PTM40U-01F021 32017415904

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Tecra M4-S635 BTS Rev. 1.00 2005-09-07 KK T20050810 CB1.00 Page 1 of 5

Operating System2

•Microsoft® Windows® XP Tablet Edition 2005

Processor and Chipset3

Intel® Centrino™ Mobile Technology featuring:

•Intel Pentium® M Processor 750

o1.86GHz, 2MB L2, 533MHz FSB

•Chipset

oMobile Intel 915PM Express Chipset

•Integrated Wi-Fi™ compliant wireless LAN

oIntel PRO/Wireless 2200BG (802.11b/g),

Memory4

•Configured with 512MB PC4200 DDR2 533MHz SDRAM (using

one memory module, one memory expansion slot open)

•512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,

or 1024MB PC4200 DDR2 533MHz SDRAM, dual-channel

support requires two memory modules of same capacity and

clockspeed

Hard Disk Drive5

•80GB (5400 RPM) Serial-ATA (SATA) hard disk drive; 9.5mm

height

Slim SelectBay Optical Disk Drive

•DVD SuperMulti (+R double layer) drive supporting 10 formats

maximum speed and compatibility:

oCD-ROM (24x:read), CD-R (24x:write), CD-RW

(10x:write), DVD-ROM (8x:read), DVD-R (8x:write),

DVD-RW (4x:write), DVD+R (Single Layer, 4x: write),

DVD+R (Double Layer, 2.4x:write), DVD+RW (4x:write),

DVD-RAM (3x:write)

Display6

•14.1” diagonal TFT active-matrix LCD display at 1400x1050 native

resolution (SXGA+)

Graphics7

•NVIDIA GeForce™ Go 6200 TE with 64MB DDR discrete graphics

memory

Sound

•Analog Devices AD1981B 16-bit stereo software sound

oSupports Direct 3D Sound, DirectSound, Direct Music,

MIDI (playback)

•Built-in microphone

•Sound Volume Control Dial

•Built-in stereo speakers

Input Devices

•Keyboard

o85 key US keyboard

oHot Key Functions (Fn)

oWindows Key Function

oApplication Key Function

•Toshiba Accupoint™ and TouchPad™ dual pointing device

•TouchPad™ Enable/Disable (FN+F9 or by help of software)

•Control Buttons:

oWindows security button

oESC/Display Rotation button

oCross Functional button

Communications

•Toshiba V.92 software modem8

•Marvell 10/100/1000 Base-TX Ethernet

•Integrated Intel Pro/Wireless Network Connection 2200BG

(802.11b/g)9

Expandability

•2 main memory slots. Both slots may be occupied.

•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,

CardBus

•Secure Digital slot (supports SDIO)

Ports

•RGB (monitor) port

•TV-out (S-Video)

•i.LINK™IEEE-1394

•3 Universal Serial Bus (USB) ports (v2.0)

•External Microphone jack

•Headphone jack

•RJ-45 LAN port

•RJ-11 modem port

•240-pin docking connector

Physical Description for this Product Series

•Dimensions (WxDxH Front/H Rear): 12.91” (328.0mm) x 11.41”

(289.7mm) x 1.45” (36.9mm)[F]/1.51” (38.4mm)[R] without feet

•Weight: Starting at 6.17 lbs (2.80 kg) depending upon

configuration10

•Indicators: DC-In, Power/Sleep, Hard Drive, CD-DVD ROM Access,

Caps Lock, Numeric Lock, Scroll Lock, Battery Charging Status,

Wireless

•Chassis Description

oCase material: Magnesium Alloy/Polycarbonate ABS

oLCD Cover Color: Aluminum Silver

•Physical Security

oSlot for cable lock;

oItems protected by a screw: HDD, Memory, Selectable

Bay

•Software Security

oPasswords: User power-on password, supervisor

password

oHotkey locks: Screen Blank

Power Supply

•75W (15V x 5A) Auto sensing external AC Adapter, 100-240V / 50-

60Hz frequency (Universal) input.

•Dimensions (WxDxH): 5.00” (127.0mm) x 2.01” (51.0mm) x 1.20”

(30.5mm)

•Weight: starting at 0.78 lbs (355 g)

Battery11

•6-cell (4700mAh) rechargeable, removable Lithium Ion (Li-Ion)

battery pack

•Dimensions (WxDxH): 4.92” (125.1mm) x 2.68” (68.1mm) x 0.80”

(20.4mm)

•Weight: starting at 0.74 lbs (338 g)

•Battery Life (measured by MobileMark™)12

oIncluded 6-cell battery: 2 hours, 54 minutes

•Recharge Time

oMain Battery Off/On – approximately 3.0

hrs/approximately 5.5 to 13.0 hrs

Toshiba EasyGuard™

•Protect & Fix

oShock Absorbing Design13

HDD Shock Absorber

LCD Panel Shock Absorber

LCD Inverter Shock Absorber

Chassis Shock Protector

oHard Disk Drive Protection

3D Accelerometer

HDD Shock Absorber

oMagnesium Alloy Casework

oTOSHIBA PC Diagnostic Tool

oTOSHIBA Software RAID

oKey Component Access

•Secure

oMultiple-Level Password Utilities

oTrusted Platform Module (TPM v1.1)

oTOSHIBA Secure Digital Token Utility

oAdvanced Instant Security

oExecute Disable Bit

•Connect

oDiversity Antenna

oTOSHIBA ConfigFree®

oVoice-over-IP Ready Design

oTOSHIBA Bluetooth® Stack

•Optimize

oPresentation Button

oTOSHIBA Zooming Utility

oLCD Rotation Utility

oOne-touch Resolution Change

oTOSHIBA Power Saver Utility

oTOSHIBA Optical Disc Drive Power On/Off Utility

oWireless On/Off Switch

oTOSHIBA Fn-esse® Shortcut Utility

oTOSHIBA Mouse Utility

oFN Shortcut Keys

BIOS

•TSETUP, ACPI, PNP, VESA, DPMS, DDC, SM BIOS v2.3, PCI

BIOS v2.1 support

Software14

•Toshiba Software and Utilities

oTOSHIBA ConfigFree®

oTOSHIBA Custom Utilities

oElectronic User’s Guide

•Third-party Software

oMicrosoft Office® OneNote® 2003

oMicrosoft Works® Version 8.0

oMcAfee® VirusScan™

oSun® Java™ 2 Runtime Environment

oAdobe® Acrobat® Reader version 5.0

oInterVideo® WinDVD® 5

oInterVideo® WinDVD Creator 2 Platinum

oSonic Solutions® RecordNow!™ Basic for Toshiba

oSonic Solutions® Drive Letter Access™ (DLA)

oMicrosoft® Windows Media Player version 10

oZinio Reader

oFranklin Covey Table Planner (30 Day Trial)

oAlias® SketchBook™ Pro (30 Day Trial)

oAOL® Internet Service (90-day trial)15

oAT&T® Worldnet® Service (30-day trial)16

Environmental Specifications

Operating Non-operating

Temperature17 5° to 35° C

(41° to 95° F) -20° to 65° C

(-4° to 149° F)

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Relative Humidity

(non-condensing) 20% to 80% 10% to 90%

Altitude

(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters

Shock 10G 60G

Vibration 0.5G 1.0G

Tecra/Portégé – 3-year standard limited warranty18

•Standard 3-year limited warranty (battery and AC Adapter come

standard with 1-year limited warranty)

Standard Limited Warranty Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

At-Home Repair, and Service Express to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com

Recommended Services

Extended Service Plans

Provides an extended service plan for up to 4 total years from the original

notebook purchase date. See Toshiba Service Plan Agreement for

program terms and conditions at www.pcsupport.toshiba.com.

Part Number Description

WSN-PTQQ4V 4th Year Extended Service Plan

SystemGuard19 Advanced Protection Coverage w/ ServiceExpress

Provides advanced protection from damage caused from handling. Select

your express repair service with either Depot Express or Carry-In Express

and go to the front of the line. Extended Service Plan included except with

1 Year plan.

Part Number Description

WSN-PQGQ3V 1st/2nd/3rd Year

WSN-PTGQ4V 1st/2nd/3rd/4th Year + Extended Service Plan

SystemGuard Advanced Protection Coverage + Business On-Site

Repair

Combines SystemGuard and Business On-Site Repair coverage.

Extended Service Plan included except with 1 Year plan. 1SystemGuard

coverage must be purchased within the first 30 days of purchase. See

Toshiba Service Plan Agreement for program terms and conditions at

www.pcsupport.toshiba.com.

Part Number Description

WSN-PQGN3V 1st/2nd/3rd Year

WSN-PTGN4V 1st/2nd/3rd/4th Year + Extended Service Plan

ServiceExpress

Select your express repair service with either Depot Express or Carry-In

Express. Depot Express: Toshiba will repair your notebook and return the

notebook to you via overnight shipment (excluding weekends and holidays).

Carry-In Express: Take your notebook into a Premier ASP and go to the

front of the line for expedited repair service. Extended Service Plan

included except with 1 Year plan. See Toshiba Service Plan Agreement

for program terms and conditions at www.pcsupport.toshiba.com.

Part Number Description

WSN-PQQP3V 1st/2nd/3rd Year

WSN-PTQP4V 1st/2nd/3rd/4th Year + Extended Service Plan

Business On-Site Repair

Toshiba will provide on-site service at customer’s business location

(excluding weekends and holidays) to perform the necessary hardware

repairs. Extended Service Plan included except with 1 Year plan. See

Toshiba Service Plan Agreement for program terms and conditions at

www.pcsupport.toshiba.com.

Part Number Description

WSN-PQQN3V 1st/2nd/3rd Year

WSN-PTQN4V 1st/2nd/3rd/4th Year + Extended Service Plan

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Tecra M4-S635 BTS Rev. 1.00 2005-09-20 KK T20050810 CB1.00 Page 2 of 5

PA410U Targus DEFCON CL Cable Lock

Memory PA1401U-1NCS Toshiba Fieldmate Enhanced Portability Case -

M4/R10

Part Number Description PA1388U-1NCS Toshiba 3-in-1 Portfolio Leather 14"

KTT533D2/256 Kingston DDR2 533, 256MB

KTT533D2/512 Kingston DDR2 533, 512MB Storage

KTT533D2/1G Kingston DDR2 533, 1GB Part Number Description

Power PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit (RoHS Compliant)

PA3306U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 7200 rpm

Part Number Description PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm

PA3283U-2ACA Toshiba 75W Global AC Adapter PA3406U-1HA0 Toshiba 100GB HDD Kit, (with Bracket) 5400 rpm

PA3191U-4BRS Toshiba Primary Li Ion Battery Pack (4700mAh, 6

Cell) PA3134U-1ETC Toshiba Slim SelectBay HDD Adapter (Black Bezel)

PA3129U-2BRS Toshiba Slim SelectBay 2nd 3600mAh Battery Pack Wireless/Bluetooth

PA3091U-1CHG Toshiba Battery Charger w/Integrated AC Adapter Part Number Description

Expansion PA3477U-1BTM Toshiba Internal Module with Bluetooth v2.0+EDR

Capability

Part Number Description PA3363U-2MPC Wireless LAN Card Kit, Mini-PCI (802.11g) (Intel)

PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC

Adapter PA3376U-2MPC Wireless LAN Card Kit, Mini-PCI (802.11ag) (Intel)

PA3315U-2PRP Toshiba Tablet Multi Dock II Input Devices

PA3359U-1DV2 Toshiba Slim SelectBay DVD SuperMulti Drive Kit

(Black) Part Number Description

PA3316U-2ETC Toshiba Tablet PC Pen II

Security & Protection PA3317U-1ETC Toshiba Tablet PC Reserve Pen

PA1357U-3ETC Toshiba Tablet Pen Tether DLX

Part Number Description

PA1370U-1ETC Toshiba Keyboard Protector (Tecra/Satellite/Qosmio)

Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba

America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo

are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are

registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered

trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the

Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned

by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA

Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may

not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,

please visit Toshiba's Web site at pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.

2Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH

EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.

Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software

product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

3Processor (Central Processing Unit).

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Tecra M4-S635 BTS Rev. 1.00 2005-09-20 KK T20050810 CB1.00 Page 3 of 5

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Tecra M4-S635 BTS Rev. 1.00 2005-09-20 KK T20050810 CB1.00 Page 4 of 5

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature

references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at

www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or

damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it

on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental

Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information.

4Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount

of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on

the graphics system, applications utilized, system memory size and other factors.

5Hard Disk Drive (HDD) Capacity.

1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity

using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage

capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed

software applications, or media content. Actual formatted capacity may vary.

6Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film

transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic

of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This

is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery

power.

7Graphics (Graphics Processing Unit).

GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU

performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

NVIDIA GeForce™ Go 6200TE/6600TE GPU. The graphics processor is optimized for your specific computer model and GPU performance will be slower

than the standard GeForce™ Go 6200TE/6600TE or applicable successor model. GPU performance is only optimized at ambient temperatures between 5°C

and 30°C.

8Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission

speeds will vary depending on line conditions.

9Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public

wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary

depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware

configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless

function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format

of data transmitted.

10 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

11 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings

and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are

achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.

Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its

ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories

information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.

12 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.

13 Shock Protection. Toshiba’s shock absorption technology provides higher impact protection for your system as compared to Toshiba systems without

similar shock protection features based on Toshiba’s drop tests. Toshiba’s standard limited warranty terms and limitations apply. Visit www.

warranty.toshiba.com for details.

14 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT

BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures

and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations

of the computer, and may be completed by Internet or telephone (toll charges may apply).

15 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,

SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges

may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Tecra M4-S635 BTS Rev. 1.00 2005-09-20 KK T20050810 CB1.00 Page 5 of 5

plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is

required.

16 AT&T® Worldnet® Service. Telephone access and other charges and other terms and conditions may apply. Offer available to new customers only.

17 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from

specifications even when operating within the recommended temperature range.

18 Warranty. Toshiba’s standard limited warranty, extended warranty and service upgrade terms and conditions are available at www.warranty.toshiba.com.
