TECRA M9 BTS Rev. 1.07 2007-09-17 CM T20070514 CB0.1.60GC Page 1 of 5

TECRA M9-S5514 Detailed Product Specification1

Model Name Description Part Number UPC

M9-S5514 Genuine Windows Vista™ Business (32-bit version), Intel® Core™ 2 Duo Processor

T7500, 1024MB DDR2, 120GB 5400rpm SATA, DVD-SuperMulti, 14.1” widescreen

WXGA+, NVIDIA Quadro NVS 130M with 383MB Total Available VRAM, Intel® Wireless

WiFi Link 4965AGN, Bluetooth v2.0 + EDR, 3 year limited warranty

PTM91U-02P010 032017888500

Operating System C1 2

•Genuine Windows Vista™ Business (32-bit version)

Intel® Centrino® Pro processor technology featuring:

oIntel® Core™ 2 Duo Processor T75003

2.2GHz, 4MB L2, 800MHz FSB with 64-bit C1

oMobile Intel® PM965 Express Chipset

oIntel® Pro 82566MM 10/100/1000 Ethernet

oIntel® Wireless WiFi Link 4965AGN (802.11a/g/n)

Memory4

•Configured with 1024MB PC2-5300 DDR2 SDRAM (both memory slots

are occupied)

•1024MB (Min)/4096MB (Max), with 512MB, 1024MB or 2048MB PC2-

4200 or PC2-5300 DDR2 memory modules

Hard Disk Drive5

•120GB (5400 RPM) Serial ATA hard disk drive; 9.5mm height

Ultra SlimBay Optical Disk Drive6

•DVD SuperMulti (+/-R double layer) drive supporting 11 formats

oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),

CD-RW (10x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),

DVD-R (Double Layer, (2x)), DVD-RW (4x), DVD+R (Single

Layer, (2x)), DVD+R (Double Layer, (2.4x)), DVD+RW (4x),

DVD-RAM (3x)

Display7

•14.1” diagonal widescreen TFT LCD display at 1440x900 native

resolution (WXGA+)

Graphics8

•NVIDIA Quadro NVS 130M with 383MB of available total graphics

memory (128MB of dedicated graphics memory and up to 255MB of

TurboCache™ Technology)

Sound

•Built-in stereo speakers

•Sound Volume Control Dial

•Built-in microphone

Input Devices

•86 key US keyboard

•Toshiba Accupoint® and TouchPad™ dual pointing device

•TouchPad™ Enable/Disable

Communications

•Modem9

•Intel® Pro 82566MM 10/100/1000 Ethernet

•Integrated Wi-Fi® compliant wireless:10

oIntel® Wireless WiFi Link 4965AGN (802.11a/g/n)

•Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)

Expandability

•2 main memory slots. Both slots may be occupied.

•One PCMCIA – Type II/Type I Card Slot

•Secure Digital slot (supports SDIO)

Ports

•Video

oRGB (monitor) output port

•Audio

oMicrophone input port

oHeadphone output port

•Data

oi.LINK(tm) IEEE-1394

oUSB v2.0 – 3 ports

oSerial port

oDocking connector

•Security

oFingerprint reader

•Additional Ports available via the Toshiba Express Port Replicator

•Video

oDVI-D output port

•Data

oUSB v2.0 – 4 ports

o10/100/1000 Ethernet port

Physical Description

•Dimensions (WxDxH Front/H Rear): 13.2” x 11.1” x 1.24” /1.43” without

feet

•Weight: Starting at 5.2 lbs depending upon configuration11

•LCD Cover Color: Titanium Silver

Power

•75W (15V x 5A) 100-240V AC Adapter.

•Dimensions (WxDxH): 5.00” x 2.01” x 1.20”

•Weight: starting at 0.78 lbs

Battery12

•Lithium Ion battery pack (5100mAh)

•Dimensions (WxDxH): 8.15” x 0.79” x 1.77”

•Weight: starting at 0.74 lbs

•Battery Life (measured by MobileMark™)13

oIncluded 6-cell battery: 3 hours, 23 minutes

oOptional 9-cell battery: 4 hours, 42 minutes

oOptional 12-cell battery: 5 hours, 42 minutes

Toshiba EasyGuard®14

•Protect & Fix

oShock Absorbing Design15

HDD Shock Absorber

LCD Panel Shock Absorber

LCD Inverter Shock Absorber

Chassis Shock Protector

oHard Disk Drive Protection

3D Accelerometer

HDD Dome Shock Protector

HDD Shock Absorber

oSpill-Resistant Keyboard16

oMagnesium Alloy Casework

oTOSHIBA PC Diagnostic Tool

oKey Component Access

•Secure

oMultiple-Level Password Utilities

oFingerprint Reader (includes software for password and identity

management)

oUPEK Protector Suite™ QL

oInfineon TPM Software Professional Package

oTrusted Platform Module (TPM v1.2)

oTOSHIBA Secure Digital Token Utility

oAdvanced Instant Security

oReinforced Security Cable Lock Slot

oExecute Disable Bit

oOptional Services and Accessories (additional purchase required)

CompuTrace®

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

TECRA M9 BTS Rev. 1.07 2007-09-17 CM T20070514 CB0.1.60GC Page 2 of 5

•Connect

oDiversity Antenna

oTOSHIBA ConfigFree®

oVoice-over-IP Ready Design

oTOSHIBA Bluetooth® Stack

•Optimize

oTOSHIBA Zooming Utility

oLCD Rotation Utility

oOne-touch Resolution Change

oTOSHIBA Power Saver Utility

oTOSHIBA Optical Disc Drive Power On/Off Utility

oWireless On/Off Switch

oTOSHIBA Mouse Utility

oFN Shortcut Keys

oWindows® Mobility Center Button

BIOS

•ACPI, PNP, VESA, DPMS, DDC, SM BIOS v2.4, PCI BIOS v2.1

support

Software C1 17

•Toshiba Software and Utilities

oTOSHIBA Value Added Package

oElectronic User’s Guide

oBluetooth Stack for Windows by Toshiba

oTOSHIBA ConfigFree®

oTOSHIBA Management Console

oTOSHIBA Assist

oTOSHIBA Security Assist

oTOSHIBA Disc Creator

oTOSHIBA Extended Tiles for Windows Mobility Center

oTOSHIBA Recovery Disc Creator

oTOSHIBA Speech System

•Third-party Software

oSun® Java™ 2 Runtime Environment

oAdobe® Acrobat® Reader 8.0

oMicrosoft® Windows Media Player 11

oGoogle™ Desktop

oGoogle™ Toolbar

oInfineon TPM Software Professional Package

oProtector Suite™ QL by UPEK®32

oUlead® DVD MovieFactory® 5 for TOSHIBA

oCNN

•Trial Software

oMicrosoft Office Ready with 60 day Office Professional 2007

Edition Trial

oMcAfee® Internet Security Suite (30-day trial)

•Special Offers

oMicrosoft Office Live

Environmental Specifications

Operating Non-operating

Temperature

5° to 35° C

(41° to 95° F) -20° to 65° C

(-4° to 149° F)

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Relative Humidity

(non-condensing) 20% to 80% 10% to 90%

Altitude

(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters

Shock 10G 60G

Vibration 0.5G, 0.25 w/ ODD 1.0G

•This product is RoHS19 compatible

TECRA / PORTEGE / LIBRETTO – 3 YEAR STANDARD

LIMITED WARRANTYError! Bookmark not defined.

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

On-Site Repair, and ServiceExpress to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com.

Recommended Services

Extended Service Plan

Provides an extended service plan for up to 4 total years from the original

notebook purchase date.

Part Number Description

WSN-PTQQ4V 4th Year Extended Service Plan

SystemGuard Accidental Damage Service w/ ServiceExpressError! Bookmark

not defined.

Provides advanced protection from damage caused from handling. Select

your express repair service with either Depot Express or Carry-In Express

and go to the front of the line. Extended Service Plan included with 4 Year

plan. SystemGuard coverage must be purchased within the first 30 days of

notebook purchase.

Part Number Description

WSN-PQGP3V 1st/2nd/3rd Year

WSN-PTGP4V 1st/2nd/3rd/4th Year + Extended Service Plan

SystemGuard Accidental Damage Service + On-Site RepairError! Bookmark not

defined.

Combines SystemGuard and On-Site Repair coverage. Extended Service

Plan included with 4 Year plan. SystemGuard coverage must be purchased

within the first 30 days of notebook purchase.

Part Number Description

WSN-PQGN3V 1st/2nd/3rd Year

WSN-PTGN4V 1st/2nd/3rd/4th Year + Extended Service Plan

ServiceExpress

Select your express repair service with either Depot Express or Carry-In

Express. Depot Express: Your notebook will be repaired and returned via

overnight shipment (excluding weekends and holidays). Carry-In Express:

Take your notebook into a Premier ASP and go to the front of the line for

expedited repair service. Extended Service Plan included with 4 Year plan.

Part Number Description

WSN-PQQP3V 1st/2nd/3rd Year

WSN-PTQP4V 1st/2nd/3rd/4th Year + Extended Service Plan

On-Site Repair Service

On-site service will be provided at the customer’s home or business location

(excluding weekends and holidays) to perform the necessary hardware

repairs. Extended Service Plan included with 4 Year plan.

Part Number Description

WSN-PQQN3V 1st/2nd/3rd Year

WSN-PTQN4V 1st/2nd/3rd/4th Year + Extended Service Plan

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3511U-1M51 Toshiba 512MB PC2-5300 DDR2-667MHz Memory

Module

PA3512U-1M1G Toshiba 1GB PC2-5300 DDR2-667MHz Memory

Module

PA3513U-1M2G Toshiba 2GB PC2-5300 DDR2-667MHz Memory

Module

Power

Part Number Description

PA3283U-5ACA Toshiba 75W Global AC Adapter, CA EE

PA3588U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)

PA3509U-1BRM Toshiba Primary Extended Capacity Li Ion Battery Pack

(9 Cell)

PA3357U-3BRL Toshiba Primary High Capacity Li Ion Battery Pack

(12 Cell)

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

TECRA M9 BTS Rev. 1.07 2007-09-17 CM T20070514 CB0.1.60GC Page 3 of 5

PA3091U-2CHG Toshiba Battery Charger w/Integrated AC Adapter

Expansion

Part Number Description

PA3508U-1PRP Toshiba Express Port Replicator w/90W AC Adapter

PA3541U-2PRP Toshiba dynadock USB Docking Station with VGA port

PA3542U-2PRP Toshiba dynadock USB Docking Station with DVI Port

PA3473U-1DV6 Toshiba Ultra Slim Bay DVD SuperMulti Double Layer

Drive Kit (Black)

Security & Protection

Part Number Description

PA3567U-1ETC Toshiba Keyboard Protector

PA410U Targus DEFCON CL Notebook Cable Lock

Storage

Part Number Description

PA3408U-2ETC Toshiba Ultra Slim Bay HDD Adapter (Black Bezel)

PA3430U-2HA0 Toshiba 100GB HDD Kit with Bracket

(5400 rpm S-ATA)

PA3109U-3FDD Toshiba USB Floppy Disk Drive, RoHS

PA1411U-1M1G Toshiba 1GB USB Hi-Speed Flash Drive

PA1412U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive

Wireless/Bluetooth

Part Number Description

PA3455U-1BTM Toshiba USB Adapter with Bluetooth EDR+2.0

capability

PA3573U-1ETA Toshiba Bluetooth Laser Mouse (Black/Silver)

PA3573U-1ETB Toshiba Bluetooth Laser Mouse (Black/Red)

Article I. Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Article II. Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba

America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo

are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are

registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered

trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the

Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned

by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA

Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

TECRA M9 BTS Rev. 1.07 2007-09-17 CM T20070514 CB0.1.60GC Page 4 of 5

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled

on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features

and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at

pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.

2Operating System.

Also see 64-Bit Computing Legal Footnote, if applicable.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Core™ 2 Duo Processor

Intel® Dual Core Technology is a new technology designed to deliver improved performance to the notebook PC. Performance or compatibility may vary. For more information on

Intel's Core 2 Duo processors, visit: http://www.intel.com/core2duo/

See 64-Bit Computing Legal Footnote, if applicable.

4Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system

memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less

and will vary by model and system configuration.

5Hard Disk Drive (HDD) Capacity.

1 Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1

GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating

systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.

6Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical

drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical

media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or

optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.

Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.

7Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a

period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.

8Graphics (Graphics Processing Unit).

GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized

when operating in AC power mode and may decrease considerably when operating in battery power mode.

9Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary

depending on line conditions.

10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access

points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic

environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the

theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless function, if available, your client and access point must support the corresponding feature.

Performance of these functions may vary depending on the format of data transmitted.

11 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

12 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as

well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations

tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while

computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.

Battery life will be less than when using similar applications in the Windows Operating System

13 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

TECRA M9 BTS Rev. 1.07 2007-09-17 CM T20070514 CB0.1.60GC Page 5 of 5

14 EasyGuard. Toshiba EasyGuard™ technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the

model selected. See www.easyguard.toshiba.com for detailed information.

15 Shock Protection. Toshiba’s shock absorption technology provides higher impact protection for your system as compared to Toshiba systems without similar shock protection

features based on Toshiba’s drop tests. Toshiba’s standard limited warranty terms and limitations apply. Visit www. warranty.toshiba.com for details.

16 Spill-Resistant Keyboard. Under Toshiba testing conditions, the spill-resistant keyboard delayed the time for a water spill to reach the PC's main board to allow more time to

properly close down the machine. Toshiba’s standard limited warranty terms and limitations apply. Visit www.warranty.toshiba.com for details.

17 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft® software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy

protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION

PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software

products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Internet access is required to enable certain functionality of certain Microsoft products which may be included with this computer.

The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation

procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which

time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without

charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the

perpetual version of such Office Product.

For systems with Microsoft Money Essentials 2007 installed, note that some online services for Microsoft® Money 2007 and Microsoft® Money 2007 Essentials will expire on the

earlier of two years after your activation of the software or September 1, 2009. Also, you may need to get some online services separately from your financial institution, which may

charge a fee. See the online services policy at http://money.msn.com/Money/2007/OSP.asp.

18 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when

operating within the recommended temperature range.

19 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements

and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
