TOSHIBA PORTEGE 3025CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1999 TAIS P3025.doc Rev. 3 04/04/00 nmm. Page 1 of 3
FEATURED SKU’s DESCRIPTION
PAP302U-T6W8 P300, 10.4”, 32MB, 6.4bb HDD, Modem, Windows 98
PROCESSOR Intel Pentium300Mhz (2.0V/2.5V) w/MMX Technology
Integrated Coprocessor Yes
Processor Cache 32KB: (16KB code; 16KB data)
External data bus width 64 bit
External data/address bus speed 66 MHz
LEVEL 2 (L2) CACHE Yes: 512KB
Data Memory Type 2 Mbit Pipelined Burst Synchronous SRAM
Data Bus Width 64 Bit
Access Time 8 ns
Local Bus Clock Speed 66 MHz
SYSTEM ARCHITECTURE Connecting Devices:
PCI (V.2.1) Bus: (32-bit, 33 MHz) PC Card Slots; Infrared port; USB, KBC, Sound chip, HDD
MEMORY: 64Mbit EDO DRAM, 3.3V
Standard 32 MB
Maximum 96 MB
Speed 60ns
Hyper Page mode memory access Yes
Data/address bus width 64 bit/32 bit
Local Bus Clock Speed 66 MHz
BIOS (4Mbit FLASH EPROM) Yes: 512KB
Supported standards APM (V.1.2); ACPI (V.1.0); PnP 1.0a ;VESA (V.2.0); DPMS, DCC,
DMI (V.2.0)
DISPLAY
Type 10.4” Diagonal TFT Active Matrix Color, 800 x 600
Dot Pitch 0.264mm x .264mm
Contrast Ratio 150:1 (Min)
VIDEO
Memory: EDO-DRAM 2MB (integrated into Controller chip)
Speed 50ns
Hyper Page mode support Yes
Controller Chip NeoMagic (2160) w/128-bit Data Bus Width
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes: supports BiTBLT, H/W Cursor, Scaling
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
INTERNAL SUPPORT
Full Screen (Using Stretch Utility) 640 x 480 x 16.7M colors
Full Screen 800 x 600 x 16.7M colors
Virtual Display mode 1024 x 768 x 64K colors
EXTERNAL SUPPORT Colors Vert. Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors 85 Hz
800 x 600 16.7M colors 85 Hz
1024 x 768 64K colors 75 Hz (interace)

TOSHIBA PORTEGE 3025CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1999 TAIS P3025.doc Rev. 3 04/04/00 nmm. Page 2 of 3
FEATURED SKU’s DESCRIPTION
PAP302U-T6W8 P300, 10.4”, 32MB, 6.4bb HDD, Modem, Windows 98
STORAGE
HDD (2.5” Enhanced IDE) 6.4 billion bytes (13msec)
Height 8.45mm
Buffer 512KB
Burst Data Transfer Rate Ultra DMA, PIO Mode 4
FDD (3.5” 1.44MB) -- External Bundled
CD-ROM (Optional)
5.25” 20X Max. speed External using PC Card
KEYBOARD
84 keys with Windows 95/98 support Yes (full-size key caps; 2mm Travel)
Key Pitch 18mm
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted "T") Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two PC Card Slots Yes: 1-right side & 1-left side
32-bit, 3.3V PC CardBus Support Yes
16-bit, 5.0V PC Card Support Yes
Internal Memory Slot (One only) Yes
EXPANSION PORTS LOCATION
One Power-in Jack Yes: Rear of unit
One 132-pin expansion bus Yes: Left side
One Universal Serial Bus (USB) port Yes: Right side (Supports 127devices. Throughput Rate: 12Mbits/sec.)
One Fast Infrared port (IrDA2.0: 4Mbps) Yes: Right side
One External Floppy Drive port Yes: Right side
Microphone (3.5mm mini jack, monoaural) Yes: Right side
One Headphone (3.5mm mini jack, stereo) Yes: Right side
One Noteworthy security lock port Yes: Right side
I/O BAR (Port Expander) (1) Standard: Connects to 132-pin expansion bus -- rear of unit
One 15-Pin RGB (SVGA video) Yes
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One (PS/2) 101 Keyboard/Mouse port Yes: Supports use of Y-cable
Portege "Mini" I/O BAR Adapter Connects to 132-pin expansion bus -- rear of unit
One (PS/2) 101 Keyboard/Mouse port Yes: Supports use of Y-cable
One 15-Pin RGB (SVGA video) Yes
POWER
Autosensing External AC Adapter: PA2501U 3.94’’L x 1.97’’W x .98’’D--- .46 lbs
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.0A
Power Output (Watts) 30W
Battery Type: Li-Ion High Capacity Battery (Bundled) Lightweight Battery (Optional)
Part Number PA2458UR PA2457UR
Capacity 10.8V, 2600mAh 10.8V, 1300mAh
Battery Life (Full/Low) 2.6 hrs./3.8 hrs 1.3 hrs./1.9 hrs
Recharge Time (Computer Off/On) 6 hrs./12 hrs. 3 hrs./6 hrs.
Dimensions 8.16”(L)x1.6”(H)x.79”(W) 8.16”(L)x.86”(H)x.79”(W)
Power Saving Features APM v.1.2 BIOS, Processing speed change, Auto Resume,
Hibernation, LCD Brightness switch (software)

TOSHIBA PORTEGE 3025CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1999 TAIS P3025.doc Rev. 3 04/04/00 nmm. Page 3 of 3
FEATURED SKU’s DESCRIPTION
PAP302U-T6W8 P300, 10.4”, 32MB, 6.4bb HDD, Modem, Windows 98
PC Card MODEM (Bundled) -- (All Models) 3Com-Noteworhty 56K PC Card Modem (XJ1560)
Data support
Protocols supported Bell-103 & 212A, V.21, V.23, V.22, V.22bis, V.32, V.32bis,
V.34, V.34+, V.90
Error correction V.42
Data compression V.42 bis
Fax support Group 3, EIA Class 1, EIA Class 2.0
Protocols supported V.17, V.21 Channel 2, V.27 ter, V.29
Features X-Jack Connector, Flash DSP/Flash ROM, Digital Line Guard,
Hot Swapping, Intelligent Auto Install
SOUND SYSTEM Yamaha Sound System
Chipsets: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum Sampling Rate 44.1 kHz
FM Synthesis support Yes
Full duplex support Yes
Built-in Speaker Yes (monaural, located on left side under palm rest)
Built in Microphone Yes (monaural, located on right side)
3D Sound support Yes: when connected to stereo speakers
Sound formats supported: SoundBlaster ProV3.01, MIDI, Windows Sound System V2.0
DIMENSIONS 10.12"W x .78"H x 8.5"D
WEIGHT 2.9 lbs. (with Enhanced battery)
BUNDLED SOFTWARE (Windows 98 models)
Windows 98; Ring Zero Ring Central; Toshiba Controls (Power Saver, Hibernation, Quick Hibernation, Hotkey, HW Setup);
Direct X 6.0; America On Line Update; AT&T Internet Offer; Yahoo; Quicken Basic 99; Intel Indeo Video;
Microsoft NetMeeting; Symantec Norton Antivirus Scanner; User’s Guide
CD’s Included: Windows 98 Configuration Builder CD with Boot Disk
CUSTOMER CHOICE SOFTWARE: BROCHURE ENCLOSED IN BOX
Choice of a Total of 5 Additional Software Titles
Lotus



SmartSuite Millenium Edition (counts as 5 selections)
Mobile Productivity K-6 Education
Laplink Math Blaster 6-9
Rand McNally Trip Planner The Way Things Work
USA 98: Streets & Destinations Ultimate Creativity & Writing Center
Print Artist 4.0 Eyewitness Children’s Encyclopedia
Freddi Fish 2: The Case of the Haunted Schoolhouse
7-12 Education Entertainment
Algebra Blaster Don’t Know Jack 3
Encyclopedia of Science Sierra Front Page Sports Skiing
Student Writing Center Abe’s Oddysee
Higher Score Guaranteed ACT/SAT/PSAT Total Annihilation
SECURITY Miscellaneous Screen blank (by Hotkey), keyboard (by Hotkey)
Lock mechanisms Noteworthy cable lock
Password security Power-on, supervisor, HDD
WARRANTY 1 YR Parts & Labor (1 YR Battery)
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration: 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
