TOSHIBA PORTEGE 660CDT Specifications
PART# PA1126U-T9A
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS P660cdt.doc Rev. 8 02/07/00 nmm. Page 1 of 3
PROCESSOR Intel Pentium150Mhz (2.9v/3.3v) w/VRT
External data bus width 64 bit
External data/address bus speed 60 MHz
Integrated Coprocessor Yes
Processor Cache 16KB: (8KB code; 8KB data)
LEVEL 2 (L2) CACHE Yes: 256KB (Data); 32KB (Address)
Data Memory Type 1 Mbit Pipelined Burst Synchronous SRAM (32K x 32bit x 2, 3.3V)
Data Bus Width 64 Bit
Access Time 8 ns
TAG RAM: Yes: 256Kbit Asynchronous SRAM (32Kx8bit, 3.3V) x 1
Access Time 14ns
Cacheable main memory area Up to 64 MB (not using TAG-RAM) w/30 ns Access speed
Local Bus Clock Speed 60 Mhz
SYSTEM ARCHITECTURE
PCI Bus: (32-bit, 30 MHz) Connecting Devices: PC Card Slots, Expansion Bus, Graphics Controller
ISA Bus: (16-bit, 8mhz) Connecting Devices:BIOS, FDD, HDD, RTC
MEMORY: 16Mbit EDO DRAM, 3.3V
Standard 16 MB
Maximum 80 MB
Speed 60ns
Hyper Page mode memory access Yes
Data width 64 bit
Local Bus Clock Speed 60 MHz
BIOS (256KB FLASH EPROM, 120ns, 5V) Yes
PnP 1.0a SUPPORT Yes
DISPLAY
Type TFT Active Matrix Color
Size 11.3" (9”W x 6.75”H)
Dot Pitch 0.287mm x 0.287mm
Contrast Ratio 100:1 (min)
VIDEO
Memory: 4Mbit EDO DRAM, 5V 2 MB
Speed 60ns
Hyper Page mode support Yes
Controller Chip Chips & Technology (F65554) w/64-bit Data Bus Width
PCI Bus Architecture w/burst mode Yes: 32-bit, 30 MHz
Graphics Accelerator: Yes: Supports BitBLT, LINEdraw, H/W Cursor
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling Support Yes
Zoomed Video Port Support Yes
DirectVideo support Yes
Internal Resolution 800 x 600 x 16.7M/16.7M colors
Smaller Image 640 x 480 x 16.7M/16.7M colors
Virtual Display Mode 1024 x 768 x 64K/64K colors
Virtual Display Mode 1280 x 1024 x 256/256K colors
External Resolution Colors/Palette
640 x 480 16.7M colors/16.7M colors
800 x 600 16.7M colors/16.7M colors
1024 x 768 64K colors/64K
1280 x 1024 256 colors/256K
Refresh Rate (@ 1024 x 768 Non-Interlaced ) Vert.: 85Hz; Hor.: 68.8kHz @ 256 colors

TOSHIBA PORTEGE 660CDT Specifications
PART# PA1126U-T9A
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS P660cdt.doc Rev. 8 02/07/00 nmm. Page 2 of 3
STORAGE
Removeable HDD (2.6” Enhanced IDE) 1.4 billion bytes=1.35GB (13msec)
SELECT BAY DEVICES
Second Battery Optional: Part# PA2494UR (Includes adapter & 2nd battery)
Battery Type Li-Ion ( 10.8V, 3400mAh )
Modular FDD (3.5” 1.44MB) Included/Swappable with CD-ROM
FDD Dimensions 4.57”L x 3.8”W x .59”H
FDD Weight Weight: .29 lbs
Simultaneous FDD & CD-ROM Support3Yes: w/FDD adapter (included)
FDD Adapter Dimensions 7.0”L x 5.5”W
FDD Adapter Weight .25 lbs
Modular CD-ROM: Toshiba XM-1502B
5.25” 10x Average speed Installed/Swappable with FDD
Interface .ATAPI (Enhanced IDE)
Random Access Time 180ms
Sustained Transfer Rate 1500 KB/sec
Supported Disc formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
KEYBOARD
84 keys Yes (18mm key pitch; full-size key caps; 3mm Travel)
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted "T") Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slot2Yes: CardBus & ZV Card Ready
32-bit, 3.3V PC CardBus Support Yes
16-bit, 5.0V PC Card Support Yes
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port Yes: IrDA2.0: 4Mbps
One (PS/2) 101 Keyboard/Mouse port Yes: Supports use of Y-cable
One External Floppy Drive port Yes
Microphone (3.5mm mini jack, monoaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
One RJ11 Port for internal modem Yes
Noteworthy security lock port Yes
POWER
Autosensing External AC Adapter: PA2438U 4.92’’L x 2.48’’W x .98’’--- .75lbs
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.0A
Power Output (Watts) 30W
Battery Type: Li-Ion ( 10.8V, 3400mAh ) Yes: Part# PA2492UR (one standard)
Battery Life: (Full Power/Low Power) 2-4 hrs
Recharge Time (Computer Off/On) 4.5 hrs.(Off) / 6-9 hrs.(On)
MaxTimePower Management Yes
2. Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.

TOSHIBA PORTEGE 660CDT Specifications
PART# PA1126U-T9A
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS P660cdt.doc Rev. 8 02/07/00 nmm. Page 3 of 3
INTERNAL MODEM 28.8 /14.4 Kbps Data/Fax modem w/International DAA support
Data support
Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34
Error correction MNP 1-4
Data compression MNP 5, CCITV V.42bis
Fax support
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Fax class 1
Supported Functions Speaker Phone, Telephony Answering Machine,
Ring Wake-up Resume, Incoming Call Discrimination, Caller ID
SOUND SYSTEM
Chipsets: Yamaha OPL3-SA2
16 bit stereo audio playback/record Yes
Maximum Sampling Rate 48 kHz
Built-in Speaker Yes (monaural)
Built in Microphone Yes (monaural)
Full duplex supported Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI, Zoomed video port audio (stereo),
CardBus audio (monaural), CD-ROM audio
Desk Station V Plus ( Optional )3Part# PA2710U
(2) Full Length 32-bit PCI/16-bit ISA slots Yes
(1) Half Length 32-bit PCI slot Yes
(2) Type III PC Card slots Yes
Built-in SCSI II Yes
5.25’’ half height drive bay Yes
Select Bay for Modular FDD, HDD, CD-ROM 4Yes
Designed for Windows 95 and PNP Yes
Hot Docking Support Yes
NoteDock II Enhanced Port Replicator (Optional) Part# PA2713U
Two Type III CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, parallel, PS/2 mouse, DC in,SVGA monitor, lock slot,
joystick/MIDI, audio line-in, line-out, headphone, microphone
DIMENSIONS 10.35"W x 1.9"H x 8.27"D
WEIGHT (includes . 88 lb. battery & FDD) 5.6 LBS.
BUNDLED SOFTWARE:
User selectable Windows 95 or Windows for Workgroups 3.11 and MS-DOS 6.22w/Special Enhancements;
Intel Indeo Video; Synchro multimedia connect Communications utilities; Mediamatics MPEG Arcade Player, MagiCDisk;
America Online, CompuServe, Netscape Navigator, Fn-esse, Hypertext online documentation
SECURITY Lock slot, power-on & HDD password, screen blank, keyboard lock
WARRANTY 3 YR Parts & Labor
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°(65°C)
Thermal Gradient: 20º C per hour (max.) -- --
Relative Humidity: 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G 60G
Vibration: 0.5G 1G
3. Requires use of Docking adapter supplied with computer. 4. The slimline CD-ROM, standard with 660CDT, is not compatible with
the Deskstation V Plus. CD-ROM use in the Desk Station requires the purchase of 10x Avg. Speed CD-ROM (PA2659U).
