TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 1 of 9

Tecra M2V Series

Model Name Description Part Number UPC

Tecra M2V-S310: Pentium M 1.50GHz, 14.1”XGA, 256MB, 40GB (4200rpm), Intel Extreme Graphics 2,

DVD-CDRW, Intel 802.11g, WinXP Pro, 1Yr Limited Warranty PTM2VU-0007T8 032017249271

Tecra M2V-S330: Pentium M 1.50GHz, 14.1”XGA, 256MB, 40GB (4200rpm), Intel Extreme Graphics 2,

DVD-CDRW, Intel 802.11g, WinXP Pro, 3Yr Limited Warranty PTM2VU-000HK8 032017236905

*Traditional/SMB SKUs w/Office 2003 – 14th Digit “S

System Characteristics1

Operating System

•Microsoft® Windows® XP Professional

•Microsoft Windows 2000 (Components only)

Intel® Centrino™ Mobile Technology featuring:

•Choice of Processors2:

oIntel Pentium® M processor 1.40 [1MB Level 2 (“L2”) cache,

400MHz Front Side Bus (“FSB”)],

oIntel Pentium M processor 1.50 [1MB L2 cache, 400MHz FSB],

oIntel Pentium M processor 1.60 [1MB L2 cache, 400MHz FSB],

oIntel Pentium M processor 1.70 [1MB L2 cache, 400MHz FSB],

oIntel Pentium M processor 735 [1.70GHz, 2MB L2 cache,

400MHz FSB],

oIntel Pentium M processor 745 [1.80GHz, 2MB L2 cache,

400MHz FSB],

oIntel Pentium M processor 755 [2.00GHz, 2MB L2 cache,

400MHz FSB],

•Intel 855GME system chipset

•Choice of Integrated Wi-Fi™ compliant wireless LAN – Intel

PRO/Wireless 802.11g or Intel PRO/Wireless 802.11b

Memory

•256MB-2048MB SODIMM memory

•256MB, 512MB, 1024MB PC2700 DDR333 SDRAM, 2.5V

Mass Storage3

Choice of Primary Hard Disk Drives:

•80GB (5400 RPM), 60GB (7200 RPM), 60GB (5400 RPM), 60GB

(4200 RPM), 40GB (5400 RPM), or 40GB (4200 RPM), Enhanced

IDE (ATA-5) hard disk drive; 9.5mm height; user removable

Optional: Secondary Hard Drive (see Accessories):

•Choice of Hard Drives for use in the Slim SelectBay: 80GB (5400

RPM) or 60GB (5400 RPM)

•Toshiba Slim SelectBay HDD Adaptor with Black Bezel required

(part number: PA3134U-1ETC)

Choice of Optical Disk Drives

•Slim SelectBay DVD-ROM, 5.25” EIDE, 12.7mm height.

Compatibility: CD-ROM, CD-R, CD-RW, DVD-ROM, DVD-R,

DVD-RAM (all read only).

•Slim SelectBay DVD-ROM/CD-RW, 5.25” EIDE, 12.7mm height.

Compatibility: CD-ROM, CD-R (read/write), CD-RW (read/rewrite),

DVD-ROM, DVD-R (read only), DVD-RW (read only), DVD-RAM

(read only).

•Slim SelectBay DVD Multi Drive, 5.25” EIDE, 12.7mm height.

Compatibility: CD-ROM, CD-R (read/write), CD-RW (read/write),

DVD-ROM, DVD-R (read/write), DVD-RW (read/write), DVD-RAM

(read/write).

•Slim SelectBay DVD Super Multi Drive, 5.25” EIDE, 12.7mm

height. Compatibility: CD-ROM, CD-R(read/write), CD-

RW(read/write), DVD-ROM, DVD-R(read/write), DVD-

RW(read/write), DVD+R(read/write), DVD+RW(read/write), DVD-

RAM(read/write)

Optional Floppy Disk Drive

•USB Floppy Drive, 3.5”, 1.44MB

Display4

•14.1” TFT active-matrix LCD; internal display supports up to 16M

colors at 1024 x 768 (XGA)

•Brightness Control

Graphics

•Intel Extreme Graphics 2 (integrated video) 64MB of shared

dynamic memory.

•External Color Support:

640 x 480 16bit/32bit colors

800 x 600 16bit/32bit colors

1024 x 768 16bit/32bit colors

1280 x 800 16bit/32bit colors

1280 x 1024 16bit/32bit colors

1600 x 1200 16bit/32bit colors

1920 x 1440 16bit/32bit colors

2048 x 1536 16bit/32bit colors

Input Devices

•Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key

stroke, 6mm height; Dedicated Windows®& Application keys

support; HotKey function

•Mouse: Toshiba Touch Pad

•Toshiba Console Button

•Presentation Button

Expandability

•2 Expansion memory slots (including Main Memory)

•2 PC Card slots support 2 Type II or 1 Type III PC Cards,

PCMCIA R2.01, PC Card16, CardBus

•SD slot

Communications5

•Integrated V.92 modem

•Integrated 10/100Base-TX

•Integrated Fast Infrared (4Mbps)

•Integrated Wi-Fi compliant wireless LAN – Intel Pro/Wireless

802.11g, Intel Pro/Wireless 802.11b or Atheros 802.11a/g

Ports

•Parallel port

•Serial Port (Supported on Advanced Port Rep III only)

•RGB (monitor) port

•2 Universal Serial Bus (USB) port (v2.0)

•Fast Infrared (4Mbps) port

•SD slot

•240 pin docking connector

•External Microphone jack

•Headphone jack

•RJ-45 LAN port

•RJ-11 modem port

Physical Description

•Dimensions (WxDxH Front/Rear): 12.3” x 10.1” x 1.2/1.4”

•Weight6: starting at 4.76lbs (with 6 cell)

•LED Indicators: DC-In, Power, Primary Battery, Hard Drive, Slim

SelectBay, Wireless indicator, SD indicator, Caps Lock, Arrow

Lock, Numeric Lock, Main Battery Charging Status, Sleep

Suspend Mode, SD Card Usage,

•PCABS/Magnesium Alloy Case

Sound

•Analog Devices 1981B software sound

•16-bit stereo; Built-in stereo speakers, Built-in microphone

•Direct 3D Sound; DirectSound and DirectMusic; Full Duplex and

MIDI support

•Sound Volume Control Dial

Power Supply

•75W (15V 5A) Auto sensing external AC Adapter; 100-240V 50-

60Hz input.

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 2 of 9

Battery7

•6-cell (4400mAh) or 12-cell (8800mAh), rechargeable, removable

Lithium Ion (Li-Ion) battery pack

•Optional: Slim SelectBay Battery, Lithium Ion (10.8V 3600mAh)

[see Accessories]

•Battery Life (Normal Mode)

oUp to 3Hrs/36 Min. (6-cell battery alone) (measured by

MobileMark™)

oUp to 7 Hrs/26 Min (6-cell + 2nd 3600 mAh battery) (measured

by MobileMark)

oUp to 7 Hrs/34 Min (12-cell battery alone) (measured by

MobileMark)

oUp to 11Hrs/17 Min (12-cell battery + 2nd 3600 mAh battery)

(measured by MobileMark)

Security

•Slot for cable lock; PC Card (by screw and cable lock), HDD, Slim

SelectBay and memory (by screw only); User Power-on password,

HDD Password, Supervisor Password, Keyboard Lock (by

HotKey), Screen Blank (by Hotkey), Screen Saver (by software).

BIOS

•ACPI v1.0B, VESA, DPMS, DDC, SM BIOS v2.3, PC BIOS v2.1

support

Additional Software

Third-party Software

•Adobe® Acrobat® Reader

•Microsoft Office 2003 Small-business (60 Day Trial on select

models)

•Microsoft Office One Note

•Norton AntiVirus (on select models)

•Microsoft Works (on select models)

•AT&T Software (3 Month Trail Version on select models)

Toshiba Software

•Toshiba ConfigFree™

•Toshiba Custom Utilities

•Electronic User’s Guide

Environmental Specifications

Operating Non-Operating

Temperature 5°to 35°C

(41°to 95°F) -20°to 65°C

(-4°to 149°F)

Thermal Gradient 15°C per hour

maximum 20°C per hour

maximum

Relative Humidity 20% to 80% 10% to 95%

Altitude (relative to sea

level) -60 to 3000 meters -60 to 10,000

meters

Shock 7G 60G

Vibration 0.2G 1.0G

Limited Warranty

•Tecra M2V-S330 and select models: 3 year parts and labor; 1

year battery

•Tecra M2V-S310 and select models: 1 year parts, labor, and

battery.

SelectServ® Limited Warranty Upgrades and Extensions

Models with 3 Year Standard Limited Warranty

SWP-PQGQ3V 3 Year SystemGuard

SWP-PQQX3V 3 Year Depot Express

SWP-PQQN3V 3 Year Bus. On-Site Repair, Next Bus. Day

Response

SWP-PQGX3V 3 Year SystemGuard & Depot Express

SWP-PQGN3V 3 Year SystemGuard, Bus. On-Site Repair, Next

Bus. Day Response

Models with 1 Year Standard Limited Warranty

SWP-PEQQ3V Limited Warranty Extension to 3 Years

SWP-PEQX3V 3 Year Depot Express + Limited Warranty Extension

SWP-PEGQ3V 3 Year SystemGuard + Limited Warranty Extension

SWP-PEQN3V 3 Year Business On-Site Repair, Next Business Day

Response + Limited Warranty Extension

SWP-PEGX3V 3 Year SystemGuard & Depot Express + Limited

Warranty Extension

SWP-PEGN3V 3 Year SystemGuard, Business On-Site Repair &

Next Business Day Response + Limited Warranty

Extension

Accessories

For additional and most update accessories, please visit

www.accessories.toshiba.com.

Power

PA3283U-2ACA Toshiba 75W Global AC adapter

PA3356U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)

PA3357U-1BRL Toshiba Primary Li Ion High Capacity Battery Pack

(12 Cell)

PA3129U-2BRS Toshiba Slim SelectBay 2nd 3600mAh Battery Pack

PA3091U-1CHG Toshiba Battery Charger w/Integrated AC Adapter

Memory Upgrades & SD Memory Options

KTT3311/512 Kingston PC2100/PC2700, 512MB DDR

KTT3311/1G Kingston PC2100/PC2700, 1GB DDR

SD-M2564B3 Toshiba 256MB SD (Secure Digital)

SD-M5124B3 Toshiba 512MB SD (Secure Digital)

Primary HDD Upgrade or Replacement

PA3204U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 5400 rpm

PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm

Storage & Backup

HDD1232CZP41002 Toshiba 5GB Type II PC Card HDD w/Back-up

software

UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup System

UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup System

Bluetooth

PA3235U-5BTM Bluetooth Module Kit (Dealer Install Only)

PA3271U-1BTM Toshiba Bluetooth SD Card

Cases & Security

PA1334U-1NCS Toshiba Ambassador Nylon Case (15.4")

PA1335U-1NCS Toshiba Ambassador Leather Case (15.4")

PA1362U-1NCS Toshiba BackPack (15.4")

NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock

Input & Miscellaneous

PA1336U-1NKB Toshiba USB Keyboard

PA1337U-1NMS Toshiba USB Optical Scroller Mouse

PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller Mouse

PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC adapter)

PA1370U-1ETC Toshiba Keyboard Skin Protector (Tecra/Satellite)

Expansion

PA3109U-1FDD Toshiba USB Floppy Disk Kit

PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC

Adapter

Slim SelectBay Options

Slim SelectBay Secondary HDD Kits

To use the secondary HDD Kits for extra storage capacity in the Toshiba

Slim SelectBay, you must also purchase the Toshiba Slim SelectBay

HDD Adaptor (part number: PA3134U-1ETC).

PA3204U-1H60 Toshiba 60GB HDD Kit, (with Bracket) 5400 rpm

PA3230U-1H80 Toshiba 80GB HDD Kit, (with Bracket) 5400 rpm

PA3134U-1ETC Toshiba Slim SelectBay HDD Adaptor (Black Bezel)

(use only in the Toshiba Tablet Multi Dock)

Optical Drives

PA3231U-1DV1 Toshiba Slim SelectBay DVD Multi Drive Kit (Black)

PA3359U-1DV2 Toshiba Slim SelectBay DVD Super Multi Drive Kit

(Black)

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 3 of 9

Return Policy

TAIS does not accept the return of component parts, or bundled software, which have been removed from the PC system. Pro-rata refunds on individual PC

components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the TAIS dealer

where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information Systems, Inc. and/or

Toshiba Corporation.

Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or registered trademarks of Intel Corporation or its

subsidiaries in the United States and other countries.

Microsoft and Windows are registered trademarks and OneNote is a trademark of Microsoft Corporation in the United States and/or other countries.

BAPCo and MobileMark are registered trademarks of Business Applications Performance Corporation.

Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by

Toshiba is under license.

nVidia and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States and/or other countries.

All other trademarks are the property of their respective owners.

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 4 of 9

BAPCo® MobileMark™ 2002

These models achieved the battery life times shown using Business Applications Performance Corporation (“BAPCo”) MobileMark 2002. BAPCo does not

make any representations or warranties as to the results of the tests. All products used in the tests were shipping versions available to the general public.

The battery life results were achieved running the BAPCo MobileMark 2002 on the following system parameters. System parameters were set according to

BAPCo’s recommendations.

Max1 Intel Pentium M Processor1.7G, 14.1"XGA, 1024MB+1024MB, 60GB(7200rpm), DVD-Super Multi, 802.11a/b/g(Atheros), Microsoft Windows

XP Professional

Standard1 Intel Pentium M Processor1.5G, 14.1"XGA, 256MB+0MB, 40GB(4200rpm), CD-RW/DVD , 802.11b/g(Intel), Microsoft Windows XP

Professional

Min1 Intel Pentium M Processor1.4G, 14.1"XGA, 256MB+0MB, 30GB(4200rpm), DVD , 802.11b(Intel), Microsoft Windows XP Professional

Max2 Intel Pentium M Processor 755 (2.0GHz, 2MB L2 Cache, 400MHz FSB), 14.1"XGA, 1024MB+1024MB, 60GB(7200rpm), DVD-Super Multi,

802.11a/b/g(Atheros), Microsoft Windows XP Professional

Standard2 Intel Pentium M Processor 735 (1.7G Hz, 2MB L2 Cache, 400MHz FSB), 14.1"XGA, 256MB+0MB, 40GB(4200rpm), CD-RW/DVD ,

802.11b/g(Intel), Microsoft Windows XP Professional

Catalog Spec Battery Life : 3h53m

(

measured b

MobileMark

)

Battery Life : 4h20m

(

measured b

MobileMark

)

Battery Life : 4h11m

(

measured b

MobileMark

)

Battery Life : 3h36m

(

measured b

MobileMark

)

Battery Life : 4h01m

(

measured b

MobileMark

)

BenchMark Score 188 152 150 226 174

Number of Conditioning Phase 11111

Life Test Run 33333

CPU Name Intel® Pentium® M Intel® Pentium® M Intel® Pentium® M Intel Pentium M Processor

755 Intel Pentium M Processor

735

Processor info speed 1.7GHz 1.5GHz 1.4GHz 2.0GHz 1.7GHz

number of processors 11111

amount of RAM 1024MB+1024MB 256MB 256MB 1024MB+1024MB 256MB

Amount of secondary RAM cache 1MB

(

L2 RAM CACHE

)

1MB

(

L2 RAM CACHE

)

1MB

(

L2 RAM CACHE

)

2MB

(

L2 RAM CACHE

)

2MB

(

L2 RAM CACHE

)

type(1st) Li-Ion (Graphite)

10.8V X 4400mAh Li-Ion (Graphite)

10.8V X 4400mAh

model number(1st) PA3356U-SBRS PA3356U-SBRS PA3356U-SBRS PA3356U-SBRS PA3356U-SBRS

Intel® 82855GME Intel® 82855GME Intel® 82855GME Intel® 82855GME Intel® 82855GME

64MB DDR, Shared with

main memor

64MB DDR, Shared with

main memor

64MB DDR, Shared with

main memor

64MB DDR, Shared with

main memor

64MB DDR, Shared with

main memor

Intel® 82852/82855

GM/GME Graphics

Controller

Version 6.14.10.3722

Intel® 82852/82855

GM/GME Graphics

Controller

Version 6.14.10.3722

Intel® 82852/82855

GM/GME Graphics

Controller

Version 6.14.10.3722

Intel® 82852/82855

GM/GME Graphics

Controller

Version 6.14.10.3722

Intel® 82852/82855

GM/GME Graphics

Controller

Version 6.14.10.3722

1024x768/16bit/60Hz 1024x768/16bit/60Hz 1024x768/16bit/60Hz 1024x768/16bit/60Hz 1024x768/16bit/60Hz

60GB(7200rpm) 40GB(4200rpm) 30GB(4200rpm) 60GB(7200rpm) 40GB(4200rpm)

Enhanced IDE (ATA-6) Enhanced IDE (ATA-6) Enhanced IDE (ATA-5) Enhanced IDE (ATA-6) Enhanced IDE (ATA-6)

Intel® 82801DBM Ultra ATA

Storage Controller - 24CA Intel® 82801DBM Ultra ATA

Storage Controller - 24CA

N/A N/A N/A N/A N/A

Windows XP Pro Windows XP Pro Windows XP Pro Windows XP Pro Windows XP Pro

N/A N/A N/A N/A N/A

TOSHIBA BIOS v 1.0 TOSHIBA BIOS v 1.0 TOSHIBA BIOS v 1.0 TOSHIBA BIOS v 1.23 TOSHIBA BIOS v 1.23

See Toshiba Power Saver

Settin

sSee Toshiba Power Saver

Settin

sSee Toshiba Power Saver

Settin

sSee Toshiba Power Saver

Settin

sSee Toshiba Power Saver

Settin

6cell(4400mAh) Battery Life 3h53

4h20

4h11

3h36

4h01

BenchMark Score 188 152 150 226 174

6cell

(

4400mAh

)

+ 2nd

(

3600mAh

)

Battery Life 7h26

8h04

7h56

BenchMark Score 188 153 149

12cell(8800mAh) Battery Life 7h34

8h26

8h08

BenchMark Score 184 153 149

12cell

(

8800mAh

)

+ 2nd

(

3600mAh

)

Battery Life 11h17

12h19

11h59

BenchMark Score 186 155 149

Battery Life

Battery

MobileMark

hard disk capacity

hard disk file system & transfer mode

hard disk controller model

size of hardware cache if any

operating system version, service pack

other special conditions

BIOS version

Power management setting

Graphics

amount and type of RAM

graphics driver name and version

graphics resolution and color depth, refresh rate

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 5 of 9

Toshiba PowerSaver Settings

Full Power High Power Normal Long Life MobileMark2002

Level 8(fixed by default -

indipendent on the rest of

a charged battery)

Level 4(fixed by default -

indipendent on the rest of

a charged battery)

Change dependent on

the rest of a charged

atter

Level 1(fixed by default -

indipendent on the rest of

a charged battery)

Level 4(fixed by default -

indipendent on the rest of

a charged battery)

100%-75% - - Level 4 - -

74%-50% - - Level 4 - -

49%-25% - - Level 2 - -

24%-0% - - Level 2 - -

Fixed Fixed Automatic Fixed Automatic

Level 8 Level 8 Level 3 - 8 Level 3 Level 3 - 8

Maximum Performance Maximum Performance Maximum Performance Battery Optimized Maximum Performance

10 minutes 5 minutes 3 minutes 1 minutes Disable

10 minutes 5 minutes 3 minutes 1 minutes 3 minutes

15 minutes 10 minutes 5 minutes 5 minutes Disable

Disable Disable Disable Disable Disable

Shut down Shut down Shut down Shut down Shut down

No Action No Action No Action No Action No Action

Disable Disable Disable Disable Disable

Enable Enable Enable Enable Dissable

Alarm level 10% 10% 10% 10% -

Notification method Messeage Messeage Messeage Messeage -

Action after alarm No Action No Action No Action No Action -

Run program Disable Disable Disable Disable -

Off Off Off Off

Enable Enable Enable Enable Disable

Alarmlevel2%2%2%2%-

Notification method Messeage Messeage Messeage Messeage -

Action after alarm No Action No Action No Action No Action -

Run program Disable Disable Disable Disable -

Normal Power Savings Normal Power Savings Normal Power Savings Normal Power Savings Normal Power Savings

Disable Disable Disable Disable Disable

5 (Seconds) 5 (Seconds) 5 (Seconds) 5 (Seconds) 5 (Seconds)

Wireless Network Off Off Off Off Off

CPU control method

Low Battery Alarm Action

Critical Battrey Alarm Action

Power Mode

System standby

System hibernation

When I press the power button

When I close the lid

Instant Power Save

Timer Settings

Wireless Communication Switch

Basic Setup

Setup Action

SoundMAX Control

Panel Power Management

Setup Alarm

Manual Setup

Power Down settings

Power Usage settings

Prompt for password when resumi

Processor speed

Cooling Method

Monitor Power OFF

HDD Power OFF

Screen brigthness

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 6 of 9

Drawings

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 7 of 9

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 8 of 9

1Subject to Change; Product Series Disclaimer.

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices,

system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the

various computer software or hardware options, visit Toshiba’s Web site at pcsupport.toshiba.com. The product specifications and configuration information are designed

for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and

specifications on your particular model, please visit Toshiba's Web site at pcsupport.toshiba.com.

2Central Processing Unit (“CPU”) Performance Disclaimer.

CPU performance in your computer product may vary from specifications under the following conditions:

•use of certain external peripheral products

•use of battery power instead of AC power

•use of certain multimedia games or videos with special effects

•use of standard telephone lines or low speed network connections

•use of complex modeling software, such as high end computer aided design applications

•use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

TOSHIBA

information, which is subject to change without notice.

Tecra M2V Revision 1.12 BSF-CB V1.21 Page 9 of 9

•use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references

are approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website

at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the

product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage

medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in

your product Resource Guide. Contact Toshiba Technical Service and Support for more information.

3Hard Drive Capacity Disclaimer.

1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of

2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage capacity will also be less if the

product includes pre-installed operating system and/or application software. Actual formatted capacity may vary.

4TFT Disclaimer.

Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology.

5FCC Modem Speed Disclaimer.

Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary depending on line

conditions.

Wireless or Connectivity Claims.

Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone charges and air

time, etc. to achieve the functionality as advertised.

6Weight Disclaimer

Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

7BAPCo® MobileMark Battery Life Data Disclaimer

Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies depending on

usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need

to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web

site at accessoryfinder.toshiba.com.

These models achieved the battery life times shown using Business Applications Performance Corporation (“BAPCo®”) MobileMark™ 2002. BAPCo does not make any

representations or warranties as to the results of the tests. MobileMark™ and BAPCo® are registered trademarks of Business Applications Performance Corporation in the
