Portege M805D-SP2906 Page 1 of 4

Portege M805D Detailed Product Specification1

Model Name: M805D-SP2906R

M805D-SP2906A

M805D-SP2906C

Part Number: PPM82U-001RL1

PPM82U-001AR1

PPM82U-001CB1

UPC: 883974197064

883974197040

883974197057

Operating System C1 2

•Genuine Windows Vista®Home Premium (SP1, 32-bit version) Spanish

Processor and Chipset3

•AMD Turion™ X2 Dual-Core Mobile Processor RM-72

o2.1 GHz, 1MB L2 Cache, HyperTransport™ 3: up to 3.6(GT/sec)

•AMD M780V chipset

Memory4

•Configured with 3GB PC6400 DDR2 SDRAM (both memory slots may

be occupied). Maximum capacity 4GB

Storage Drive5

•250GB (5400 RPM) Serial ATA hard disk drive

Fixed Optical Disk Drive6

•DVD SuperMulti (+/-R double layer) with Labelflash™ drive supporting

11 formats

oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),

CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),

DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single

Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-

RAM (5x)

oSupports Labelflash™ media to burn high quality labels directly

on the disk.

Display7

•13.3” diagonal widescreen TruBrite®TFT LCD display at 1280 x 800

native resolution(WXGA)

Graphics8

•ATI RadeonTM 3100 Graphics with 256MB-895MB dynamically allocated

shared graphics memory

Sound

•Built-in stereo speakers

•Sound volume control dial

•Built-in microphone

Input Devices

•85 key Spanish keyboard

•TouchPad™ pointing device

•TouchPad™ Enable/Disable

•Control Buttons:

oInternet button to launch default browser

oCD/DVD control buttons (Play/Pause, Stop, Prev Track, Next

Track)

Communications

•Webcam and microphone built into LCD bezel

•Modem9

•10/100 Ethernet

•Integrated Wi-Fi®compliant wireless:10

oAtheros®802.11a/g/n wireless-LAN10/100

•Bluetooth®version 2.1 plus Enhanced Data Rate (EDR)

Expandability

•2 main memory slots. Both slots may be occupied.

•ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)

•5-in-1 Bridge Media Adapter

oSecure Digital, Memory Stick™, Memory Stick PRO™, Multi

Media Card, xD Picture Card [shared slots]

Ports

•Video

oRGB (monitor) output port

•Audio

oS/P DIF output port (shared with headphone port)

oMicrophone input port

oHeadphone output port

•Data

oi.LINK™ IEEE-1394

oUSB v2.0 – 3 ports with USB Sleep and Charge11

o2 USB v2.0 ports

o1 eSATA/USB combo port

oRJ-45 LAN port

oRJ-11 modem port

•Security

oFingerprint reader

Physical Description

•Pink

•Dimensions (WxDxH Front/H Rear): 315mm x 230mm x

27.5mm/35.5mm with feet

•Weight: Starting at 2.2 kg 12

Power

•75W (19V x 3.95A) 100-240V AC Adapter.

oDimensions (WxDxH): 128mm x 51mm x 30.5mm

oWeight: starting at 350g

Battery13

•4800mAh (6-cell) Lithium Ion battery pack

Software C1 14

•Toshiba Software and Utilities

oTOSHIBA Value Added Package

oElectronic User’s Guide

oBluetooth Stack for Windows by Toshiba

oTOSHIBA ConfigFree®

oTOSHIBA Assist

oTOSHIBA DVD Player

oTOSHIBA Disc Creator

oTOSHIBA Extended Tiles for Windows Mobility Center

oTOSHIBA Face Recognition

•Third-party Software

oMicrosoft®Works 9

oSun®Java™ 2 Runtime Environment

oAdobe®Acrobat®Reader

oGoogle™ Desktop

oGoogle™ Toolbar

oGoogle™ Picasa™

oUlead®DVD MovieFactory®5 for TOSHIBA

oPowerCinema for TOSHIBA

•Trial Software

oMicrosoft Office Trial Home and Student 2007 Edition (60-day trial)

oNorton Internet Suite (NIS) 2009

Environmental Specifications

Operating Non-operating

Temperature

5° to 35° C

(41° to 95° F) -20° to 60° C

(-4° to 140° F)

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Relative Humidity

(non-condensing) 20% to 80% 10% to 95%

Altitude

(relative to sea level) -30 to 10,000 feet -30 to 40,000 feet

Shock 10G 60G

Vibration 0.5G 1.0G

•This product is RoHS16 compatible

TECRA / PORTEGE / SATELLITE / LIBRETTO – LATIN

AMERICA - 1 YEAR STANDARD LIMITED WARRANTY17

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Portege M805D-SP2906 Page 2 of 4

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®

and Extended Service Plan to provide additional support to your notebook

PC. For a full description and complete list of programs, please visit

www.pcsupport.toshiba.com.

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3669U-1M2G Toshiba 2GB DDR2-800 Memory Module

Power

Part Number Description

PA3290U-3ACA Toshiba 120W Global AC Adapter

PA3635U-1BRM Toshiba Primary Li Ion Battery Pack (6 cell)

PA3636U-1BRL Toshiba Primary High Capacity Li Ion Battery Pack (9

cell)

Storage

Part Number Description

PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M8G Toshiba 8GB USB Hi-Speed Flash Drive, Ready boost

HDDR250E03X Toshiba External USB Hard Drive, 250GB

HDDR320E03X Toshiba External USB Hard Drive, 320GB

HDDR400E03X Toshiba External USB Hard Drive, 400GB

Expansion

Part Number Description

PA3579U-1ETC Toshiba Universal Notebook/Projector Stand

PA3555U-1ETC Toshiba USB Data Transfer Cable

Security & Protection

Part Number Description

PA3610U-1ETC Toshiba Keyboard Protector

Bluetooth/Wireless

Part Number Description

PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel Mouse

(Black/Silver)

PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel Mouse

(Black/Red)

Carrying Case

Part Number Description

PA1389U-1NCS Toshiba 5-Pocket Ballistic Nylon Case (Fits up to 15.4")

PA1420U-1NCS Toshiba Elite Nylon Carrying Case (Fits up to 15.4")

PA1452U-1NCS Toshiba Mobile Back pack, Brick Red (Fits up to 15.4")

Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Qosmio, Satellite, Portégé, Tecra, SelectBay, ConfigFree, SystemGuard, EasyGuard are registered trademarks of Toshiba America Information Systems, Inc.

and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled

on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may

not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,

please visit Toshiba's Web site at pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice

2Operating System.

Also see 64-Bit Computing Legal Footnote, if applicable.

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Portege M805D-SP2906 Page 3 of 4

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Processor (Central Processing Unit).

Also see 64-Bit Computing Legal Footnote, if applicable.

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are

approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your

computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical

Service and Support for more information.

4Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system

memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less

and will vary by model and system configuration.

5Storage Drive (Capacity)

Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity

using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer

includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity

may vary.

6Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical

drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical

media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or

optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.

Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.

7Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a

period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.

8Graphics (Graphics Processing Unit).

GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized

when operating in AC power mode and may decrease considerably when operating in battery power mode.

Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary

depending on system memory size and other factors.

9Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary

depending on line conditions.

10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access

points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic

environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the

theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless function, if available, your client and access point must support the corresponding feature.

Performance of these functions may vary depending on the format of data transmitted.

11 USB Sleep & Charge. The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn

the power of the computer ON to charge the device.

12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

13 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as

well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations

tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Portege M805D-SP2906 Page 4 of 4

computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.

14 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft® software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy

protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION

PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software

products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Internet access is required to enable certain functionality of certain Microsoft products(including Microsoft Office Small Business Accounting 2006) which may be included with this computer.

The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation

procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which

time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without

charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the

perpetual version of such Office Product.

15 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when

operating within the recommended temperature range.

16 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements

and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
