Toshiba Portege R400-S4932 User manual

Toshiba recommends
Windows Vista™ Ultimate.
Portégé®R400-S4932 Tablet PC
The Signature Notebook for Windows Vista™.
The product of a joint collaboration between two industry giants,
Toshiba and Microsoft®, the R400’s distinguished chassis
houses inspired technological breakthroughs with the sole
purpose of delivering the finest mobile computing experience.
The Portégé R400 is the World’s First PC that automatically
synchronizes your e-mail and calendar events with Active
Notifications. The Toshiba Edge Display, serving as a Personal
Information Assistant, presents the synchronized information,
while the 12.1” LED backlit wide-aspect display ensures a rich
and brilliant visual computing experience. The Portégé R400 is
the ultimate expression of Toshiba innovation, where
presentation is every bit as distinctive as the technology within.

System Characteristics1
Operating System2
• Genuine Windows Vista™ Ultimate
Processor and Chipset3
Intel®Centrino®Duo Mobile Technology featuring:
• Intel®Core™ Duo Processor U2500
-1.20GHz, 2MB L2, 533MHz FSB
• Mobile Intel®945GM Express Chipset
• Intel®PRO/Wireless 3945ABG (802.11a/b/g)
Memory4
• Configured with 2048MB PC4200 DDR2 SDRAM (both memory
slots are occupied)
• 2048MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC4200 DDR2 memory modules. Dual-channel support
requires two memory modules of same capacity and clockspeed.
Hard Disk Drive5
• 80GB (4200 RPM) Enhanced IDE (ATA-6) hdd; 8mm height
External USB Optical Disk Drive6
• DVD SuperMulti (+R double layer) drive supporting 10 formats
-Read: CD-ROM/-R/-RW (12x), DVD-ROM (4x), DVD-RAM (2x)
-Write: CD-R (4x), CD-RW (4x), DVD-R (4x), DVD-RW (2x),
DVD+R/+R DL (2.4X), DVD+RW (2.4x), DVDRAM (2x)
Display7
• 12.1” diagonal widescreen LED backlight High Brightness display
at 1280x800 native resolution (WXGA) with Wide Viewing Angle.
Graphics8
• Intel®Graphics Media Accelerator 950 with 8MB-256MB dynami-
cally allocated shared graphics memory
Sound
• Built-in monaural speaker
• Sound Volume Control
• Built-in microphone
Input Devices
• 85 key US keyboard
• Hot Key Functions (Fn)
• Windows Key Function
• Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons: Email button, Security button, Rotation button,
Cross-Functional button (TOSHIBA Mobility Center)
Communications
• Intel®PRO/1000 Network Connection - 10/100/1000 Base-TX
Ethernet
• Intel®PRO/Wireless Network Connection 3945ABG (802.11a/b/g)9
• Bluetooth®version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
• Integrated Verizon Wireless EVDO10
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
Ports
• Video
-RGB (monitor) output port
• Audio
-Microphone input port
-Headphone output port
• Data
-USB v2.0 – 2 ports
-RJ-45 LAN port
Physical Description
• Dimensions (WxDxH Front/H Rear): 12.0” (304.0mm) x 9.43”
(239.5mm) x 1.18” (29.9mm)[F]/1.26” (31.9mm)[R] without feet
• Weight: Starting at 3.79 lbs (1.72 kg) depending upon
configuration11
• Chassis Description
-Case material: Magnesium + Polycarbonate ABS
-LCD Cover Color: Cloud
• Physical Security
-Slot for cable lock;
-Items protected by a screw: Memory, Main HDD
-Fingerprint reader
• Software Security
-Passwords: User power-on password, supervisor password
-Hotkey locks: Screen Blank
Power Supply
• 60W (15V x 4A) Auto sensing external AC Adapter, 100-240V / 50-
60Hz frequency (Universal) input.
-Dimensions (WxDxH): 4.51” (114.5mm) x 1.14” (29.0mm) x 1.95”
(49.5mm)
-Weight: starting at 0.58 lbs (262 g)
Battery12
• 6-cell (4000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
-Dimensions (WxDxH): 8.74” (221.9mm) x 3.29” (83.67mm) x 0.47”
(11.9mm)
-Weight: starting at 0.65 lbs (295 g)
• Secondary 6-cell (4000mAh) rechargeable, removable Lithium Ion
(Li-Ion) battery pack
-Dimensions (WxDxH): 12.0” (304.0mm) x 4.65” (118.0mm) x 1.01”
(25.6mm)
-Weight: starting at 0.96 lbs (435 g)
• Recharge Time
-Main Battery Off/On – approx. 3.5 hrs/approx. 3.5 to 4.0 hrs
Toshiba EasyGuard™13
• Protect & Fix
-Shock Absorbing Design14: HDD Shock Absorber
-Hard Disk Drive Protection: 3D Accelerometer; HDD Shock
Absorber
-Magnesium Alloy Casework
-TOSHIBA PC Diagnostic Tool
-Key Component Access
• Secure
-Multiple-Level Password Utilities
-Fingerprint Reader (includes software for password and
identity management)
-UPEK Protector Suite™ QL
-Infineon TPM Software Professional Package 2.0
-Trusted Platform Module (TPM v1.2)
-Advanced Instant Security
-Reinforced Security Cable Lock Slot
-Execute Disable Bit
• Connect
-Diversity Antenna
-TOSHIBA ConfigFree®
-Voice-over-IP Ready Design
-TOSHIBA Bluetooth®Stack
• Optimize
-Email Button
-TOSHIBA Zooming Utility
-LCD Rotation Utility
-One-touch Resolution Change
-TOSHIBA Power Saver Utility
-Wireless On/Off Switch
-TOSHIBA Mouse Utility
-FN Shortcut Keys
Software15
• Toshiba Software and Utilities
-TOSHIBA Value Added Package
-Electronic User’s Guide
-Bluetooth Stack for Windows by Toshiba
-Toshiba 3G RF Power Control Utility
-Toshiba Tablet PC Extension
-TOSHIBA ConfigFree®
-TOSHIBA Management Console
-TOSHIBA Tablet Access Code Logon Utility
-TOSHIBA Assist
-TOSHIBA Security Assist
-TOSHIBA Disc Creator
-TOSHIBA Fingerprint Utility
-TOSHIBA Extended Tiles for Windows Mobility Center
-TOSHIBA Recovery Disc Creator
-TOSHIBA Speech System
• Third-party Software
-Microsoft®Office OneNote®2007
-Sun®Java™ 2 Runtime Environment
-Adobe®Acrobat®Reader
-InterVideo®WinDVD®8 SD
-Microsoft®Windows Media Player 11
-Google™ Toolbar
-Infineon Trusted Platform Module Utility
-Ulead®DVD MovieFactory®for TOSHIBA
• Trial Software
-McAfee®Internet Security Suite (30-day trial)
• Special Offers
-Microsoft Office Live
Limited Warranty16
• 3 Year Standard Limited Warranty
Expansion
• PA3541U-2PRP Toshiba dynadock USB Docking Station
with VGA port
• PA3542U-2PRP Toshiba dynadock USB Docking Station
with DVI port
• PA3438U-2CD2 Toshiba UltraSlim USB 2.0 CDRW/DVD
Combo Drive (Silver)
• PA3454U-1DV2 Toshiba UltraSlim USB 2.0 DVD SuperMulti
Drive (Silver)
Security & Protection
• PA1409U-1NCS Toshiba Neoprene Shuttle
• PA410U Targus DEFCON CL Cable Lock
Storage
• PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit
• PA1411U-1M1G Toshiba 1GB USB Hi-Speed Flash Drive
Wireless & Bluetooth
• PA1380U-1NMS Toshiba Wireless Travel Mouse with
Bluetooth Technology
Input Devices
• PA3545U-1ETC Toshiba Tablet PC Pen
• PA1404U-1ETC Toshiba Tablet Pen Tether
Input Devices
• PA1417U-1NCS Toshiba Portégé R400 Leather Carrying
Case
© Copyright 2007. Portege, ConfigFree and TruBrite are registered trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. Intel, Centrino and Core are
trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United
States and other countries. Windows and Vista are registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries. All other trademarks are
the property of their respective owners. All Rights Reserved.
1The product specifications and configuration information are designed for a product Series.
Your particular model may not have all the features and specifications listed or illustrated.
For more detailed information about the features and specifications on your particular model,
please visit Toshiba’s Web site at pcsupport.toshiba.com. Toshiba America Information
Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Certain Microsoft software product(s) included with this computer may use technological
measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during
initial launch of the product, or upon certain reinstallations of the software product(s) or
reconfigurations of the computer, and may be completed by Internet or telephone (toll charges
may apply). Some software may differ from its retail version (if available), and may not include
user manuals or all program functionality. 3CPU performance may vary. See Processor Legal
Footnote at www.info.toshiba.com. 4Memory size may vary. See Memory Legal Footnote
at www.info.toshiba.com. 5Hard drive capacity may vary. 1 Gigabyte (GB) means 109 =
1,000,000,000 bytes using powers of 10. See Hard Disk Drive Capacity Legal Footnote at www.
info.toshiba.com. 6Copy protection technology may prevent or limit recording or viewing
of certain optical media (e.g., CD or DVD). 7Small bright dots may appear on your screen
display when you turn on your PC. Your display contains an extremely large number of thin-fi
lm transistors (TFT) and is manufactured using high-precision technology. Any small bright
dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing
technology. Over a period of time, and depending on the usage of the computer, the brightness
of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able
to increase the brightness of the screen while on battery power. 8GPU performance may vary.
See Graphics Legal Footnote at www.info.toshiba.com. 9May require purchase of additional
software, external hardware, or services. Transmission speeds may vary. See Wireless
Legal Footnote at www.info.toshiba.com. 10 3G wireless use requires separately purchased
subscription service from Verizon Wireless. Access limited to coverage area. See www.
verizonwireless.com. 11 Weight may vary. See Weight Legal Footnote at www.info.toshiba.
com. 12 Battery life may vary. See Battery Life Legal Footnote at www.info.toshiba.com. 13
Toshiba EasyGuard™ technology comprises a number of features some of which may or may
not be available on a particular Toshiba notebook depending on the model selected. See www.
easyguard.toshiba.com for detailed information. 14 Toshiba’s shock absorption technology
provides higher impact protection for your system as compared to Toshiba systems without
similar shock protection features based on Toshiba’s drop tests. Toshiba’s standard limited
warranty terms and limitations apply. Visit www. warranty.toshiba.com for details.15 Some
software may differ from its retail version (if available), and may not include user manuals or
all program functionality. Internet access is required to enable certain functionality of certain
Microsoft products which may be included with your computer. The Microsoft Office 2007 60-
Day Trial software (if applicable) is intended for evaluation purposes only. You must activate
the software before you can use it. Product activation procedures will be detailed during initial
launch of the software; activation requires Internet access. This software has an expiration
date of 60 days from date of first use, at which time the software will operate under reduced-
functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day
Trial software is distributed without charge to the End User Customer but if the End User
wants to continue to use such product after the trial period, then the End User Customer will
have to pay a fee for the perpetual version of such Office Product. For systems with Microsoft
Money Essentials 2007 installed, note that some online services for Microsoft®Money 2007 and
Microsoft®Money 2007 Essentials will expire on the earlier of two years after your activation of
the software or September 1, 2009. Also, you may need to get some online services separately
from your financial institution, which may charge a fee. See the online services policy at http://
money.msn.com/Money/2007/OSP.asp. 16 The terms and conditions of Toshiba’s standard
limited warranty are available at www.warranty.toshiba.com.
Portégé®R400-S4932 Tablet PC
Accessories
