Toshiba PSAF0U-06H009 User manual

Satellite®A205-S4797
Laptop Shows Eye For Good Looks and Affordability.
The eye catching Satellite A205 15.4” diagonal WXGA display laptop goes beneath the surface with
inexpensive entertainment and powerful performance. Intel®mobile technology, large capacity hard
drives and memory packs this, starting at 6.0 pounds12, laptop. Use the DVD SuperMulti drive and six
CD/DVD control buttons. Connect your way with the Webcam and 802.11abg4wireless Wi-Fi®. The
Express Card slot and four USB ports adds desktop-like expansion.
Toshiba recommends
Windows Vista™ Home Premium.

System Characteristics1
Part Number and UPC
• Part Number: PSAF0U-06H009
• UPC: 032017915428
Operating System
• Genuine Windows Vista™ Home Premium (32-bit version)
Processor and Chipset2
Intel®Centrino®Duo processor technology featuring:
• Intel®Core™ 2 Duo Processor T5300
-1.73GHz, 2MB L2, 533MHz FSB with 64-bit3
• Mobile Intel®945GM Express Chipset
• Intel®PRO/Wireless 3945ABG (802.11a/b/g)4
Memory5
• Configured with 2048MB SDRAM (both memory slots may be
occupied). Maximum capacity 4096MB
Hard Disk Drive6
• 160GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive7
• DVD SuperMulti (+/-R double layer) drive supporting 11
formats
-Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x),
DVDRAM (5x)
-Supports Labelflash™ media to burn high quality labels
directly on the disk.
Display8
• 15.4” diagonal widescreen TruBrite® TFT LCD display at
1280x800 native resolution (WXGA)
-Native support for 720p content
Graphics9
• Intel®Graphics Media Accelerator 950 with 8MB-256MB
dynamically allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
Input Devices
• 86 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
-Internet button to launch default browser
-CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next
Track)
Communications
• Webcam and microphone built into LCD bezel
• Modem10
• 10/100 Base-TX Ethernet
• Intel®PRO/Wireless 3945ABG (802.11a/b/g)4
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and
Express Card/54)
• 5-in-1 Bridge Media Adapter
-Secure Digital, Memory Stick™, Memory Stick PRO™,
MultiMedia Card, xD Picture Card [shared slots]
Ports
• Video
-RGB (monitor) output port
-S-Video output port
• Audio
-Microphone input port
-Headphone output port
• Data
-i.LINK™ IEEE-1394
-USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.3” x 10.5” x
1.32” /1.55” without feet
• Weight: Starting at 6.00lbs depending upon configuration11
• LCD Cover Color: Onyx Blue Metallic
Power Supply
• 65W (19V x 3.42A) 100-240V AC Adapter
-Dimensions (WxDxH): 4.25” x 1.34” x 1.85”
-Weight: starting at 0.67 lb
Battery12
• 4000mAh Lithium Ion battery pack
-Dimensions (WxDxH): 8.11” x 2.09” x 0.83”
-Weight: starting at 0.71 lb
Software13
• Toshiba Software and Utilities
-TOSHIBA Value Added Package
-Electronic User’s Guide
-Bluetooth Stack for Windows by Toshiba
-TOSHIBA ConfigFree®
-TOSHIBA Assist
-TOSHIBA Security Assist
-TOSHIBA Disc Creator
-TOSHIBA Extended Tiles for Windows Mobility Center
• Third-party Software
-TOSHIBA Game Console
-Microsoft Works Version 8.5
-Sun®Java™ 2 Runtime Environment
-Adobe®Acrobat®Reader
-Google™ Desktop
-Google™ Toolbar
-Google Picasa™
-Yahoo! Music™ Jukebox
-Ulead®DVD MovieFactory®5 for TOSHIBA
• Trial Software
-Microsoft Office Trial Home and Student 2007 Edition
(60-day trial)
-McAfee®Internet Security Suite (30-day trial)
• Special Offers
-EarthLink®Internet Service
-PeoplePC®Internet Service
-Toshiba Compare and Search for Broadband
-Microsoft Office Live
-Shutterfly digital photo service
-Napster®music subscription service
-eMusic MP3 music subscription service
-VONGOSM internet video download service
-ebay®
-CNN Pipeline
-Skype internet communications
Limited Warranty14
• 1 Year Standard Limited Warranty
Memory Upgrade
• PA3511U-1M51 Toshiba 512MB DDR2-667 Memory
Module
• PA3512U-1M1G Toshiba 1GB DDR2-667 Memory
Module
• PA3513U-1M2G Toshiba 2GB DDR2-667 Memory
Module
Power
• PA3534U-1BRS Toshiba Primary Li Ion Battery Pack
(6 Cell)
• PA3535U-1BRS Toshiba Primary Extended Capacity
Li Ion Battery Pack (9 Cell)
• PA3290U-3ACA Toshiba 120W Global AC Adapter
Expansion
• PA3541U-2PRP Toshiba dynadock™ USB Docking
Station with VGA port
• PA3542U-2PRP Toshiba dynadock USB Docking
Station with DVI port
Security & Protection
• PA3567U-1ETC Toshiba Keyboard Protector
• PA410U Targus DEFCON CL Cable Lock
Storage
• PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit
• PA1411U-1M1G Toshiba 1GB USB Hi-Speed Flash
Drive
• PA1412U-1M2G Toshiba 2GB USB Hi-Speed Flash
Drive
Wireless & Bluetooth
• PA1380U-1NMS Toshiba Wireless Travel Mouse with
Bluetooth Technology
©2007 Toshiba America Information Systems, Inc. Satellite and TruBrite are
registered trademarks of Toshiba America Information Systems, Inc. and/or
Toshiba Corporation. Intel, Centrino and Core are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and
other countries. Windows Vista is a trademark of Microsoft Corporation in the
United States and/or other countries. All other trademarks are the property
of their respective owners. While Toshiba has made every effort at the time of
publication to ensure the accuracy of the information provided herein, product
specifications, configurations, prices, system/component/ options availability
are all subject to change without notice. Reseller/Retailer pricing may vary. All
rights reserved.
1The product specifications and configuration information are designed for
a product Series. Your particular model may not have all the features and
specifications listed or illustrated. For more detailed information about the
features and specifications on your particular model, please visit Toshiba’s
Web site at pcsupport.toshiba.com. Toshiba America Information Systems,
Inc. reserves the right to modify or withdraw this offer at anytime without
notice.2CPU performance may vary. See Processor Legal Footnote at
www.info.toshiba.com. Intel® Dual Core Technology is a new technology
designed to deliver improved performance to the notebook PC. Performance
or compatibility may vary. For more information on Intel’s Core 2 Duo
processors, visit: http://www.Intel.com/core2duo/.364-bit processors are
designed to take advantage of 32 and 64 bit computing. 64-bit computing
requires that the following hardware and software requirements are met:
64-bit Operating System, 64-bit CPU, Chipset and BIOS (Basic Input/Output
System), 64-bit Device drivers, 64-bit applications. Certain device drivers
and/or applications may not be compatible with a 64-bit CPU and therefore
may not function properly. A 32-bit version of the operating system is
preinstalled on your computer unless explicitly stated that the operating
system is 64-bit. See “Detailed Specs” for more information.4May require
purchase of additional software, external hardware, or services. Transmission
speeds may vary. See Wireless Legal Footnote at www.info.toshiba.com.5
Memory size may vary. See Memory Legal Footnote at www.info.toshiba.com.6
Hard drive capacity may vary. 1 Gigabyte (GB) means 109 = 1,000,000,000
bytes using powers of 10. See Hard Disk Drive Capacity Legal Footnote at
www.info.toshiba.com.7 Copy protection technology may prevent or limit
recording or viewing of certain optical media (e.g., CD or DVD).
8Small bright dots may appear on your screen display when you turn on your
PC. Your display contains an extremely large number of thin-film transistors
(TFT) and is manufactured using high-precision technology. Any small bright
dots that may appear on your display are an intrinsic characteristic of the
TFT manufacturing technology. Over a period of time, and depending on the
usage of the computer, the brightness of the screen will deteriorate. This is
also an intrinsic characteristic of the screen technology. When the computer
is operated on battery power, the screen with dim and you may not be able
to increase the brightness of the screen while on battery power.9 GPU
performance may vary. See Graphics Legal Footnote at www.info.toshiba.com.
10 Due to FCC limitations, speeds of 53 kbps are the maximum permissible
transmission rates during download. Actual data transmission speeds will
vary depending on line conditions.11 Weight may vary. See Weight Legal
Footnote at www.info.toshiba.com.12 Battery life may vary. See Battery Life
Legal Footnote at www.info.toshiba.com.13 Some software may differ from its
retail version (if available), and may not include user manuals or all program
functionality. Internet access is required to enable certain functionality of
certain Microsoft products which may be included with your computer. The
Microsoft Office 2007 60-Day Trial software (if applicable) is intended for
evaluation purposes only. You must activate the software before you can use
it. Product activation procedures will be detailed during initial launch of the
software; activation requires Internet access. This software has an expiration
date of 60 days from date of first use, at which time the software will operate
under reduced-functionality mode, limiting end-user options and operations.
The Microsoft Office 2007 60-Day Trial software is distributed without charge
to the End User Customer but if the End User wants to continue to use such
product after the trial period, then the End User Customer will have to pay
a fee for the perpetual version of such Office Product. For systems with
Microsoft Money Essentials 2007 installed, note that some online services for
Microsoft® Money 2007 and Microsoft® Money 2007 Essentials will expire on
the earlier of two years after your activation of the software or September 1,
2009. Also, you may need to get some online services separately from your
financial institution, which may charge a fee. See the online services policy at
http://money.msn.com/Money/2007/OSP.asp. 14 The terms and conditions of
Toshiba’s standard limited warranty are available at www.info.toshiba.com.
Satellite®A205-S4797
Accessories
