Toshiba Personal Computer
Satellite A60/ Pro A60
Maintenance Manual
TOSHIBA CORPORATION
S/ No.
Satellite A60/ Pro A60 Maintenance Manual

ii Satellite A60/ Pro A60 Maintenance Manual
Copyright
© 2004 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual
cannot be reproduced in any form without the prior written permission of Toshiba. No patent
liability is assumed with respect to the use of the information contained herein.
Toshiba Satellite A60/ Pro A60 Maintenance Manual
First edition Apr 2004
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The
included set of instructions and descriptions are accurate for the Satellite A60/ Pro A60 at the
time of this manual's production. However, succeeding computers and manuals are subject
to change without notice. Therefore, Toshiba assumes no liability for damages incurred
directly or indirectly from errors, omissions, or discrepancies between any succeeding
product and this manual.
Trademarks
Intel and Pentium are registered trademarks of Intel Corporation.
IBM, IBM PC/XT, PC/AT, PS/2 and OS/2 are registered trademarks of IBM Corporation.
MS-DOS and Windows XP home edition are registered trademarks of Microsoft Corporation.
Sound Blaster and Pro are trademarks of Creative Technology Ltd.
UNIX is a registered trademark of X/Open Company Ltd.
NetWare are registered trademarks of Novell, Inc.
All other properties are trademarks or registered trademarks of their respective holders.

Satellite A60/ Pro A60 Maintenance Manual iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer Satellite A60/ Pro A60, referred to as Satellite A60/ Pro A60 in
this manual.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
 Be sure to fasten screws securely with the right screwdriver. If a screw is not fully
fastened, it could come loose, creating a danger of a short circuit, which could cause
overheating, smoke or fire.
 If you replace the battery pack, RTC battery or backup battery, be sure to use only the
same model battery or an equivalent battery recommended by Toshiba. Installation of
the wrong battery can cause the battery to explode.

iv Satellite A60/ Pro A60 Maintenance Manual
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the Satellite A60/ Pro A60 system unit
and each FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve
FRU problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
 Handling the LCD module
 Board layout
 Keyboard scan/character codes
 Key layout
 Wiring diagrams
 BIOS Rewrite Procedures

Satellite A60/ Pro A60 Maintenance Manual v
Conventions
This manual uses the following formats to describe, identify, and highlight terms and
operating procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on
the keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If
three keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the XXXXX that appears on its display is presented in the type face
below:
Format complete
System transferred

vi Satellite A60/ Pro A60 Maintenance Manual
Table of Contents
Chapter 1 Hardware Overview
1.1 Features ..................................................................................................................1-1
1.2 System Unit Components.......................................................................................1-8
1.3 2.5-inch HDD.......................................................................................................1-14
1.4 DVD-ROM Drive.................................................................................................1-15
1.5 CD-RW/DVD-ROM Drive ..................................................................................1-16
1.6 DVD Multi ........................................................................................................... 1-17
1.7 Power Supply .......................................................................................................1-18
1.8 Batteries................................................................................................................1-19
1.1.1 Main Battery.......................................................................................1-19
1.1.2 Battery Charging Control...................................................................1-19
1.1.3 RTC Battery .......................................................................................1-20
Chapter 2 Troubleshooting
2.1 Outline....................................................................................................................2-1
2.2 Basic Flowchart......................................................................................................2-2
2.3 Power Supply .........................................................................................................2-6
Procedure 1 Power Icon Check............................................................................2-6
Procedure 2 Connection Check............................................................................ 2-8
Procedure 3 Replacement Check.........................................................................2-8
2.4 System Board .........................................................................................................2-9
Procedure 1 Replacement Check.......................................................................2-10
2.5 2.5-inch HDD.......................................................................................................2-11
Procedure 1 Message Check..............................................................................2-11
Procedure 2 Partition Check..............................................................................2-11
Procedure 3 Format Check.................................................................................2-12
Procedure 4 Test Program Check ...................................................................... 2-13

Satellite A60/ Pro A60 Maintenance Manual vii
Procedure 5 Connector Check and Replacement Check....................................2-14
2.6 Keyboard..............................................................................................................2-15
Procedure 1 Test Program Check ......................................................................2-15
Procedure 2 Connector Check and Replacement Check....................................2-15
2.7 Display..................................................................................................................2-16
Procedure 1 External Monitor Check ................................................................2-16
Procedure 2 Test Program Check ......................................................................2-16
Procedure 3 Connector Check and Replacement Check....................................2-16
2.8 ODD (Optical Disk Drive)...................................................................................2-18
Procedure 1 External Cleaning Check...............................................................2-18
Procedure 2 Test Program Check ......................................................................2-18
Procedure 3 Connector Check and Replacement Check....................................2-18
2.9 LAN .....................................................................................................................2-20
Procedure 1 Test Program Check ......................................................................2-20
Procedure 2 Connector Check and Replacement Check....................................2-20
2.10 SD Card/Memory Stick (Optional)......................................................................2-21
Procedure 1 Test Program Check ......................................................................2-21
Procedure 2 Connector Check ...........................................................................2-21
2.11 Parallel Port (Optional) ........................................................................................2-22
Procedure 1 Test Program Check ......................................................................2-22
Procedure 2 Connector Check ...........................................................................2-22
2.12 Audio Test............................................................................................................2-23
Procedure 1 Test Program Check ......................................................................2-23
Procedure 2 Connector Check and Replacement Check....................................2-23
2.13 IEEE 1394 Test (Optional)...................................................................................2-24
Procedure 1 Test Program Check ......................................................................2-24
Procedure 2 Connector Check ...........................................................................2-24
2.14 Cooling Module....................................................................................................2-25
Procedure 1 Test Program Check ......................................................................2-25
Procedure 2 Connector Check and Replacement Check....................................2-25

viii Satellite A60/ Pro A60 Maintenance Manual
Chapter 3 Diagnostic Programs
3.1 General...................................................................................................................3-1
3.2 Quick Start..............................................................................................................3-3
3.3 Option.....................................................................................................................3-9
3.4 Subtests.................................................................................................................3-18
3.5 System Test ..........................................................................................................3-22
3.6 Memory Test ........................................................................................................3-29
3.7 Storage..................................................................................................................3-34
3.8 Video....................................................................................................................3-39
3.9 Audio....................................................................................................................3-58
3.10 Mode Error Codes and description.......................................................................3-59
Chapter 4 Replacement Procedures
4.1 General...................................................................................................................4-1
4.2 Cooling Module....................................................................................................4-18
4.3 CPU......................................................................................................................4-21
4.4 HDD .....................................................................................................................4-24
4.5 Selectable Bay Module.........................................................................................4-27
4.6 Touch Pad.............................................................................................................4-31
4.7 RTC Battery .........................................................................................................4-35
4.9 Keyboard..............................................................................................................4-39
4.10 Speaker.................................................................................................................4-42
4.12 Top Cover with the Display Assembly................................................................4-46
4.13 I/O Board..............................................................................................................4-50
4.14 System Board .......................................................................................................4-51
4.15 Display Mask........................................................................................................4-53
4.16 Inverter Board ......................................................................................................4-55
4.17 LCD Module ........................................................................................................ 4-57

Satellite A60/ Pro A60 Maintenance Manual ix
Appendices
Appendix A Handling the LCD Module ........................................................................... A-1
Appendix B Board Layout ................................................................................................ B-1
Appendix C Keyboard Scan/Character Codes .................................................................. D-1
Appendix D Key Layout.....................................................................................................E-1
Appendix E Wiring Diagrams............................................................................................F-1
Appendix F BIOS Rewrite Procedures............................................................................. G-1
Appendix G EC/KBC Rewrite Procedures........................................................................ H-1

x Satellite A60/ Pro A60 Maintenance Manual

Chapter 1
Hardware Overview

1 Hardware Overview
1-ii Satellite A60/ Pro A60 Maintenance Manual

1 Hardware Overview
Chapter 1 Contents
1.1 Features............................................................................................................................1-1
1.2 System Unit Components ................................................................................................1-8
1.3 2.5-inch HDD.................................................................................................................1-14
1.4 DVD-ROM Drive ..........................................................................................................1-15
1.5 CD-RW/DVD-ROM Drive............................................................................................1-16
1.6 DVD Multi.....................................................................................................................1-17
1.7 Power Supply.................................................................................................................1-18
1.8 Batteries .........................................................................................................................1-19
1.1.1 Main Battery.......................................................................................1-19
1.1.2 Battery Charging Control...................................................................1-19
1.1.3 RTC Battery .......................................................................................1-20
Satellite A60/ Pro A60 Maintenance Manual 1-iii

1 Hardware Overview
Figures
Figure 1- 1 Parts description placement ...............................................................................1-5
Figure 1- 2 The computer Block diagram.............................................................................1-6
Figure 1- 3 System Board configuration..............................................................................1-7
Figure 1- 4 System unit block diagram.................................................................................1-8
Figure 1- 5 2.5-inch HDD...................................................................................................1-14
Figure 1- 6 DVD-ROM drive .............................................................................................1-15
Tables
Table 1- 1 2.5-inch HDD specifications.............................................................................1-14
Table 1- 2 DVD-ROM drive specifications........................................................................1-15
Table 1- 3 CD-RW/DVD-ROM drive specifications ..........................................................1-16
Table 1- 4 DVD-Multi drive specifications.........................................................................1-17
Table 1- 5 Battery specifications.......................................................................................1-19
Table 1- 6 Quick/normal charging time.............................................................................1-20
1-iv Satellite A60/ Pro A60 Maintenance Manual

1.1 Features 1 Hardware Overview
1
1.1 Features
The Toshiba Satellite A60/ Pro A60 is a full size notebook PC based on the Intel Portability P4
processor, providing high-speed processing capabilities and advanced features. The computer
employs a Lithium Ion battery that allows it to be battery-operated for a longer period of time.
The display uses 14.1-inch XGA and 15-inch SXGA+ LCD panel, capable of displaying up to
16M colors at a resolution of 1024 by 768 pixels (XGA) and 1400 by 1050 pixels(SXGA+), The
(PGA socket supports BTO/CTO for the CPU so that the system can be designed to suit your
needs.
The computer has the following features.

Processor
The CPU is the Intel P4(Northwood),P4(Prescott) and Celeron(Northwood),
Celeron(Prescott).
P4(Northwood) 2.66/2.8/3.06/3.2 GHz
P4(Prescott) 518(2.8G)/532(3.06G)/538(3.2G)/552(3.46G)/558(3.60G) GHz
Celeron(Northwood) 2.5/2.6/2.7/2.8 GHz
Celeron(Prescott) 325(2.53G)/330(2.66G)/335(2.8G)/340(2.93G)/345(3.066G)
350(3.2G) GHz

Host bridge system controller
System controller: ATi RS250 M

Memory
The computer have on Board 256MB/512MB memory and one SO DIMMs slot comes
standard with DDR 2100 module. It supports PC2100 and uses SO DIMMs (DDR
SDRAM) driven at 2.5 V, accepting BTO/CTO for your memory requirements. It can
incorporate up to 1.5 GB of main memory
using the following sizes of memory modules:
• 256 MB (16M×16×8P)
• 512 MB (32M×16×8P)
• 512 MB (32M×16×8P)
• 1024 MB (64Mx16x8P)
• 1024 MB (64Mx16x8P)
Satellite A60/ Pro A60 Maintenance Manual 1-1

1 Hardware Overview 1.1 Features

Hard Disk Drive (HDD)
The compu ter accommodates one 2.5-inch HDD with any of the following storage
capacities:
• 30 GB (9.5 mm thick) ATA100 (4,200rpm)
• 40 GB (9.5 mm thick) ATA100 (4,200rpm)
• 60 GB (9.5 mm thick) ATA100 (4,200rpm)
• 80 GB (9.5 mm thick) ATA100 (4,200rpm)
• 40 GB (9.5 mm thick) ATA100 (5,400rpm)
• 60 GB (9.5 mm thick) ATA100 (5,400rpm)
• 80 GB (9.5 mm thick) ATA100 (5,400rpm)

ODD bay
The ODD Bay can accommodate a DVD-R/RW drive, DVD+R/RW,DVD super Multi
drives.

Display
The LCD displays available come in the following three sizes:
14.1” XGA-TFT/15” SXGA+ -TFT color display, resolution 1024×768,
16M/1400×1050,26M colors

Keyboard
The keyboard has 27 kinds countries key.

Batteries
The computer has a removable 8 Cell or 12 Cell Lithium Ion battery pack and an internal
RTC battery (rechargeable).

Universal Serial Bus (USB) ports
The computer has two USB 1.1/2.0 ports, third one is BTO to daisy-chain a maximum of
127 USB devices. The serial data transfer rate is 480 Mbps or 12 Mbps and 1.5 Mbps
These ports support PnP installation and hot plugging.

External monitor port
A 15-pin external monitor port is provided, through which the computer automatically
recognizes an external VESA DDC 2B compatible monitor.

PC Card slot
1-2 Satellite A60/ Pro A60 Maintenance Manual

1.1 Features 1 Hardware Overview
A PC Card slot is provided to hold PC Card Standard Type II (5.0 mm) card, capable of
using a variety of PC Cards including 16-bit Multiple Function PC Cards and CardBus
cards.
PC card HDD boot does Not be supported.

SD/MS Card
This slot is BTO/CTO for your memory card requirements to provide memory card read
on your computer

Toshiba Pointing Device
Toshiba Pointing Device has one kind of input devices TouchPad.
Satellite A60/ Pro A60 Maintenance Manual 1-3

1 Hardware Overview 1.1 Features

Sound system
The ALC250 integrated audio controller supports multimedia. The sound system
contains the following:
• Stereo speakers
• Headphone jack
• External microphone jack

LAN
The internal LAN board supports 10BASE-T and 100BASE-TX, enabling connection to
a LAN at up to 100 Mbps. It also supports Wake-up On LAN From S3 PXE boot support.
The LAN board has the RJ45 jack to directly accommodate a LAN cable.

Wireless LAN
The internal Mini PCI Card slot supports IEEE802.11a/g(13ch)/ IEEE802.11g(13ch)
card. The Antenna is integrated in the system unit.

Internal Modem
The computer contains a MDC, enabling data and fax communication. It supports ITU-
TV.90/92(America, Canada) The transfer rates are 56 Kbps for data reception, 33.6 Kbps
for data transmission, and 14,400 bps for fax transmission. Note, however, that the actual
speed depends on the line quality. The RJ11 modem jack is used to accommodate a
telephone line.

IEEE 1394(optional)
The IEEE 1394 is optional integrated device. to supported IEEE 1394 ports ,The serial
data transfer rate is 400 Mbps, These port support hot plugging.

Parallel Port(optional)
The Parallel Port is optional integrated device. to supported connect a printer or
another parallel device. The port is IEEE-1284 compliant and supports Extended
Capabilities Port (ECP).

Fast Serial InfraRed (FIR) communications port(optional)
The FIR Port is optional integrated device. It provided an IrDA 1.1 compatible FIR port ,
enabling wireless communication at a high speed of 1.15 or 4 Mbps.
1-4 Satellite A60/ Pro A60 Maintenance Manual

1.1 Features 1 Hardware Overview

Figures 1-1 and 1-2 show the computer and its system unit configuration, respectively.
Figure 1- 1 Parts description placement
Satellite A60/ Pro A60 Maintenance Manual 1-5

1 Hardware Overview 1.1 Features
1-6
Figure 1- 2 The computer Block diagram
1-6 Satellite A60/ Pro A60 Maintenance Manual
