Qosmio F40-ST4101 BTO Rev. 1.05 2007-12-21 SK T20070420 CB1.20 Page 1 of 5

Qosmio F40-ST4101 Series Detailed Product Specification1

Model Name Description Part Number UPC

F40-ST4101 Genuine Windows Vista™ Home Premium, Intel® Core™ 2 Duo processor T7250,

1024MB DDR2 SDRAM, 120GB HDD (5400RPM, S-ATA), 15.4” Widescreen WXGA

Display, DVD-SuperMulti, NVIDIA® GeForce™ 8400M GS with 128MB, 5-in-1 Card

reader, Integrated 1.3M Webcam, Fingerprint reader, 10/100Mbps LAN, Intel® Wireless

WiFi Link 4965AGN (802.11a/g/n), 1-Year Standard Limited Warranty

PQF46U-00J006 032017933861

Operating System C1 2

oGenuine Windows Vista™ Home Premium (32-bit version)

oGenuine Windows Vista™ Ultimate(32-bit version)

Processor and Chipset3

Intel® Centrino® Duo processor technology featuring:

oProcessor Options:

•Intel® Core™ 2 Duo Processor T71004

1.8GHz, 2MB L2, 800MHz FSB with 64-bit C1

•Intel® Core™ 2 Duo Processor T72505

2.0GHz, 2MB L2, 800MHz FSB with 64-bit C1

•Intel® Core™ 2 Duo Processor T73006

2.00GHz, 4MB L2, 800MHz FSB with 64-bit C1

•Intel® Core™ 2 Duo Processor T75007

2.20GHz, 4MB L2, 800MHz FSB with 64-bit C1

•Intel® Core™ 2 Duo Processor T77008

2.40GHz, 4MB L2, 800MHz FSB with 64-bit C1

oChipset

•Mobile Intel® PM965 Express Chipset

oIntegrated Wi-Fi® compliant wireless LAN

•Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)9

Memory10

oConfigured with 1024MB PC2-5300 DDR2 SDRAM (both memory

slots may be occupied). Maximum capacity 4096MB

oOptional Intel® Turbo Memory

•1024MB

Hard Disk Drive11

oChoice of Primary Hard Disk Drive: 120GB (5400 RPM),160GB

(5400 RPM); Serial ATA hard disk drive; 9.5mm height; or

200GB (4200RPM), 250GB (4200RPM); Serial ATA hard disk

drive; 12.5mm height; user removable

oChoice of Secondary Hard Disk Drive (see availability at time of

ordering): 120GB (5400 RPM),160GB (5400 RPM); Serial ATA

hard disk drive; 9.5mm height; or 200GB (4200RPM), Serial

ATA hard disk drive; 12.5mm height; user removable

Fixed Optical Disk Drive12

oDVD SuperMulti (+/-R double layer) with Labelflash™ drive

supporting 11 formats

•Maximum speed and compatibility: CD-ROM (24x), CD-R

(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single Layer,

(8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x), DVD+R

(Single Layer, (2x)), DVD+R (Double Layer, (2.4x)),

DVD+RW (4x), DVD-RAM (3x)

•Supports Labelflash™ media to burn high quality labels

directly on the disk.

oHD DVD-ROM/DVD13 SuperMulti (+/- double layer) drive (in one

optical drive), supporting 13 formats

•Maximum speed and compatibility: HD DVD-ROM (1x), ,CD-

ROM (24x), CD-R (24x), HS CD-RW (10x), DVD-ROM (8x),

DVD-R (4x), DVD+R (4x),DVD-RW (4x), DVD+R (Double

Layer (2.4x)), DVD-R (Double Layer (2x)), DVD+RW (4x),

DVD-RAM (3x)

Display14

o15.4" diagonal widescreen TruBrite®TFT active-matrix LCD

display at 1280x800 native resolution (WXGA)

•Maximum Brightness – up to 200 Cd/m2

•Contrast Ratio: 300:1

•Horizontal Viewing Angle: 120 Degree

•Vertical Viewing Angle: 100 Degree

Graphics15

oPCI-Express™ x16 graphics subsystem, featuring:

•NVIDIA® GeForce™ 8400M Gs with 128MB DDR2 discrete

graphics memory; plus up to 255MB dynamically allocated

shared graphics memory using NVIDIA® TurboCache™

technology.16 or

•NVIDIA® GeForce™ 8600M GT with 256MB DDR2 discrete

graphics memory; plus up to 255MB dynamically allocated

shared graphics memory using NVIDIA® TurboCache™

technology.17

Sound

oBuilt-in harman/kardon® stereo speakers with subwoofer

oSound Volume Control Dial

oBuilt-in microphone

Input Devices

o86 key US keyboard

oTouchPad™ pointing device

oTouchPad™ Enable/Disable

oControl Buttons:

•Internet button to launch default browser

•CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next

Track)

Communications

oWebcam and microphone built into LCD bezel

oModem18

o10/100 Ethernet

oIntegrated Wi-Fi® compliant wireless:19

•Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)

oBluetooth® version 2.0 plus Enhanced Data Rate (EDR)

Expandability

o2 main memory slots. Both slots may be occupied.

oExpressCard™ slot (ExpressCard/34 and ExpressCard/54)

o5-in-1 Bridge Media Adapter

•Secure Digital, Memory Stick™, Memory Stick PRO™, Multi

Media Card, xD Picture Card [shared slots]

Ports

oVideo

•RGB (monitor) output port

•HDMI output port

oAudio

•S/P DIF output port (shared with headphone port)

•Microphone input port

•Headphone output port

oData

•i.LINK™ IEEE-1394

•USB v2.0 – 4 ports

oSecurity

•Fingerprint reader

Physical Description

oDimensions (WxDxH Front/H Rear): 14.9” x 11.0” x 1.50” /1.77”

without feet

oWeight: Starting at 7.5 lbs depending upon configuration20

oLCD Cover Color: Cosmic Black

Power

o120W (19V x 6.3A) 100-240V AC Adapter

oDimensions (WxDxH): 6.10” x 1.44” x 2.64”

oWeight: starting at 1.26 lbs

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Qosmio F40-ST4101 BTO Rev. 1.05 2007-12-21 SK T20070420 CB1.20 Page 2 of 5

Battery21

o(4000mAh) Lithium Ion battery pack

oDimensions (WxDxH): 4.72” x 3.31” x 1.06”

oWeight: starting at 0.73 lb

Software C1 22

oToshiba Software and Utilities

•TOSHIBA Value Added Package

•Electronic User’s Guide

•Bluetooth Stack for Windows by Toshiba

•TOSHIBA Management Console

•TOSHIBA Assist

•TOSHIBA Security Assist

•TOSHIBA Disc Creator

•TOSHIBA Recovery Disc Creator

•TOSHIBA HD DVD Player (only on units with HD DVD)

•TOSHIBA Speech System

oThird-party Software

•TOSHIBA Game Console

•Microsoft Office Basic Edition 2007 (If purchased at time of

system configuration)

•Microsoft Office Small Business Edition 2007 (If purchased at

time of system configuration)

•Sun® Java™ 2 Runtime Environment

•Adobe® Acrobat® Reader 8.0

•InterVideo®WinDVD® 8

•Google™ Desktop

•Google™ Toolbar

•Google Picasa™

•Yahoo! Music™ Jukebox

•Protector Suite™ QL by UPEK®32

•Ulead® DVD MovieFactory® 5 for TOSHIBA

•

oTrial Software

•Microsoft Office Ready with 60 day Office Professional 2007

Edition Trial

•McAfee® Internet Security Suite (30-day trial)

oSpecial Offers

•Microsoft Office Live

•Napster® music subscription service

•VONGOSM internet video download service

•Skype™ internet communications

Environmental Specifications

Operating Non-operating

Temperature23 5° to 35° C

(41° to 95° F) -20° to 65° C

(-4° to 149° F)

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Relative Humidity

(non-condensing) 20% to 80% 10% to 95%

Altitude

(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters

Shock 10G 60G

Vibration 0.5G 1.0G

•This product is RoHS24 compatible

1 YEAR STANDARD LIMITED WARRANTY25

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

On-Site Repair, and ServiceExpress to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com.

Recommended Services

Extended Service Plan

Provides an extended service plan for up to 4 total years from the original

notebook purchase date.

Part Number Description

WSN-PEQQ2V 2nd Year Extended Service Plan

WSN-PEQQ3V 2nd/3rd Year Extended Service Plan

WSN-PEQQ4V 2nd/3rd/4th Year Extended Service Plan

SystemGuard Accidental Damage Service w/ ServiceExpress26

Provides advanced protection from damage caused from handling. Select

your express repair service with either Depot Express or Carry-In Express

and go to the front of the line. Extended Service Plan included except with 1

Year plan. SystemGuard coverage must be purchased within the first 30

days of notebook purchase.

Part Number Description

WSN-PSGP1V 1st Year

WSN-PEGP2V 1st/2nd Year + Extended Service Plan

WSN-PEGP3V 1st/2nd/3rd Year + Extended Service Plan

SystemGuard Accidental Damage Service + On-Site Repair26

Combines SystemGuard and Business On-Site Repair coverage. Extended

Service Plan included except with 1 Year plan. SystemGuard coverage

must be purchased within the first 30 days of notebook purchase.

Part Number Description

WSN-PSGN1V 1st Year

WSN-PEGN2V 1st/2nd Year + Extended Service Plan

WSN-PEGN3V 1st/2nd/3rd Year + Extended Service Plan

ServiceExpress

Select your express repair service with either Depot Express or Carry-In

Express. Depot Express: Your notebook will be repaired and returned via

overnight shipment (excluding weekends and holidays). Carry-In Express:

Take your notebook into a Premier ASP and go to the front of the line for

expedited repair service. Extended Service Plan included except with 1

Year plan.

Part Number Description

WSN-PSQP1V 1st Year

WSN-PEQP2V 1st/2nd Year + Extended Service Plan

WSN-PEQP3V 1st/2nd/3rd Year + Extended Service Plan

On-Site Repair Service

On-site service will be provided at the customer’s home or business location

(excluding weekends and holidays) to perform the necessary hardware

repairs. Extended Service Plan included except with 1 Year plan.

Part Number Description

WSN-PSQN1V 1st Year

WSN-PEQN2V 1st/2nd Year + Extended Service Plan

WSN-PEQN3V 1st/2nd/3rd Year + Extended Service Plan

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3512U-1M1G Toshiba 1GB DDR2-667 Memory Module

PA3513U-1M2G Toshiba 2GB DDR2-667 Memory Module

Power

Part Number Description

PA3290U-3ACA Toshiba 120W Global AC Adapter

PA3609U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)

Expansion

Part Number Description

PA3541U-2PRP dynadock USB Docking Station with video port (VGA)

PA3542U-2PRP dynadock USB Docking Station with video port(DVI)

Security & Protection

Part Number Description

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Qosmio F40-ST4101 BTO Rev. 1.05 2007-12-21 SK T20070420 CB1.20 Page 3 of 5

PA3567U-1ETC Toshiba Keyboard Protector - 14"-15", 17" NBs (A4 size)

PA410U Targus DEFCON CL Cable Lock

Storage

Part Number Description

PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit

PA1411U-1M1G Toshiba 1GB USB Hi-Speed Flash Drive

PA1412U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive

Article I. Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Article II. Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba

America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo

are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are

registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered

trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the

Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned

by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA

Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled

on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features

and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at

pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.

2Operating System.

Also see 64-Bit Computing Legal Footnote, if applicable.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Processor (Central Processing Unit).

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are

approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Qosmio F40-ST4101 BTO Rev. 1.05 2007-12-21 SK T20070420 CB1.20 Page 4 of 5

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your

computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical

Service and Support for more information.

4Core™ 2 Duo Processor

Intel® Dual Core Technology is a new technology designed to deliver improved performance to the notebook PC. Performance or compatibility may vary. For more information on

Intel's Core 2 Duo processors, visit: http://www.intel.com/core2duo/
