System Characteristics1
Part Number and UPC
• Part Number: PQF46U-00K005
• UPC: 032017980662
Operating System
• Genuine Windows Vista®Ultimate (32-bit version)
Processor and Chipset2
Intel®Centrino®Duo processor technology featuring:
• Intel®Core™ 2 Duo Processor T72503
-2.0GHz, 2MB L2, 800MHz FSB
• Mobile Intel®PM965 Express Chipset
• Integrated Wi-Fi®compliant wireless LAN
-Intel®Wireless WiFi Link 4965AGN (802.11a/g/n)4
Memory5
• Configured with 2048MB PC2-5300 DDR2 SDRAM (both
memory slots may be occupied). Maximum capacity
4096MB
Hard Disk Drive6
• 300GB (4200 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive7
• HD DVD-ROM/DVD SuperMulti (+/- double layer) drive (in
one optical drive), supporting 12 formats
-Maximum speed and compatibility: HD DVD-ROM (1x),
CDROM (24x), CD-R (24x), CD-RW (10x), DVD-ROM (8x),
DVD-R (4x), DVD+R (4x),DVD-RW (4x), DVD+R (Double
Layer (2.4x)), DVD-R (Double Layer (2x)), DVD+RW (4x),
DVD-RAM (3x)
Display8
• 15.4” diagonal widescreen TruBrite®TFT LCD display
at 1280x800 native resolution (WXGA)
-Native support for 720p content
Graphics9
• PCI-Express™ x16 graphics subsystem, featuring:
-NVIDIA®GeForce™ 8600M GT, 256MB GDDR2 discrete
graphics memory, plus up to 255MB dynamically
allocated shared graphics memory using NVIDIA®
TurboCache™ technology.
• Total Available Graphics memory 511MB
Sound
• 2 built-in harman/kardon®speakers with 1 Bass
Reflex sub-woofer
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 86 key US keyboard
• TouchPad™ pointing device
• Qosmio AV Controller
• TouchPad™ Enable/Disable
• Control Buttons:
-Internet button to launch default browser
-CD/DVD control buttons (Play/Pause, Stop, Prev Track,
Next Track)
Communications
• Webcam and microphone built into LCD bezel
• Modem10
• 10/100 Ethernet
• Integrated Wi-Fi®compliant wireless:
-Intel®Wireless WiFi Link 4965AGN (802.11a/g/n)4
Expandability
• 2 main memory slots. Both slots may be occupied.
• ExpressCard™ slot (ExpressCard/34 and Express
Card/54)
• 5-in-1 Bridge Media Adapter
-Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Ports
• Video
-RGB (monitor) output port
-S-Video output port
-HDMI output port
• Audio
-S/P DIF output port (shared with headphone port)
-Microphone input port
-Headphone output port
• Data
-i.LINK™ IEEE-1394
-USB v2.0 – 4 ports
-RJ-45 LAN port
-RJ-11 modem port
• Security
-Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear):
14.9” x 11.0” x 1.50” /1.77” without feet
• Weight: Starting at 6.6 lbs depending upon
configuration11
• LCD Cover Color: Cosmic Black
Power Supply
• 120W (19V 6.3A) Auto sensing ,
100-240V/50-60Hz AC Adapter.
-Dimensions (WxDxH): 6.10” x 2.63” x 1.43”
-Weight: starting at 1.25 lbs
Battery12
• 4000mAh Lithium Ion battery pack
Software13
• Toshiba Software and Utilities
-TOSHIBA Value Added Package
-Electronic User’s Guide
-Bluetooth Stack for Windows by Toshiba
-TOSHIBA ConfigFree®
-TOSHIBA Disc Creator
-TOSHIBA HD DVD Player
-TOSHIBA Extended Tiles for Windows Mobility Center
-TOSHIBA Speech System
• Third-party Software
-TOSHIBA Game Console
-Microsoft Works Version 8.5
-Sun®Java™ 2 Runtime Environment
-Adobe®Acrobat®Reader 8.0
-InterVideo® WinDVD®8
-Google™ Desktop
-Google™ Toolbar
-Google Picasa™
-Yahoo! Music™ Jukebox
-Ulead®DVD MovieFactory®5 for TOSHIBA
• Trial Software
-Microsoft Office Trial Home and Student 2007 Edition
(60-day trial)
-McAfee®Internet Security Suite (30-day trial)
• Special Offers
-Microsoft Office Live
-Shutterfly digital photo service
-Napster®music subscription service
-eMusic MP3 music subscription service
-VONGOSM internet video download service
-ebay®
-CNN Pipeline
Limited Warranty14
• 1 Year Standard Limited Warranty
Memory Upgrade
• PA3512U-1M1G Toshiba 1GB DDR2-667 Memory
Module
• PA3513U-1M2G Toshiba 2GB DDR2-667 Memory
Module
Power
• PA3290U-3ACA Toshiba 120W Global AC Adapter
• PA3609U-1BRS Toshiba Primary Li Ion Battery Pack
(6 Cell)
Expansion
• PA3541U-2PRP dynadock USB Docking Station with
video port (VGA)
• PA3542U-2PRP dynadock USB Docking Station with
video port (DVI)
• PA3579U-1ETC Toshiba Universal Notebook/Projec
tor Stand
Security
• PA3567U-1ETC Toshiba Keyboard Protector
• PA410U Targus DEFCON CL Cable Lock
Storage
• PA3109U-3FDD Toshiba USB Floppy Disk Drive Kit
• PA3556U-1M1G Toshiba 1GB USB Hi-Speed Flash
Drive, Ready Boost
• PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash
Drive, Ready Boost
• PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash
Drive
Wireless & Bluetooth
• PA3624U-1BTM Toshiba USB Adapter with Bluetooth
2.0+EDR capability
• PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel
Mouse (Black/Silver)
• PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel
Mouse (Black/Red)
Qosmio®F45-AV425
Accessories
-
©2007 Toshiba America Information Systems, Inc. Satellite and TruBrite
are registered trademarks of Toshiba America Information Systems, Inc.
and/or Toshiba Corporation. Intel, Centrino and Core are trademarks
or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries. Windows Vista is a trademark of
Microsoft Corporation in the United States and/or other countries. All other
trademarks are the property of their respective owners. While Toshiba has
made every effort at the time of publication to ensure the accuracy of the
information provided herein, product specifications, configurations, prices,
system/component/ options availability are all subject to change without
notice. Reseller/Retailer pricing may vary. All rights reserved.
1The product specifications and configuration information are designed
for a product Series. Your particular model may not have all the features
and specifications listed or illustrated. For more detailed information
about the features and specifications on your particular model, please visit
Toshiba’s Web site at pcsupport.toshiba.com. Toshiba America Information
Systems, Inc. reserves the right to modify or withdraw this offer at
anytime without notice.2CPU performance may vary. See Processor Legal
Footnote at www.info.toshiba.com. 3Intel® Dual Core Technology is a
new technology designed to deliver improved performance to the notebook
PC. Performance or compatibility may vary. For more information on
Intel’s Core 2 Duo processors, visit: http://www.Intel.com/core2duo/.4May
require purchase of additional software, external hardware, or services.
Transmission speeds may vary. See Wireless Legal Footnote at www.info.
toshiba.com.The Intel® Wireless Wi-Fi® Link 4965AGN (802.11a/g/n)
adapter is based on a draft “n” release version of the IEEE 802.11n
specification, also known as “Draft N”, which may not be compatible
with, or support all features (e.g., security) of, certain Wi-Fi® equipment.
Based on the theoretical bandwidth maximum enabled by 2x3 Draft-N
implementations with 2 spatial streams. Actual wireless throughput and/
or range will vary depending on your specific operating system, hardware
and software configurations. Compatible wireless access point required.
http://www.intel.com/network/connectivity/resources/doc_library/
tech_brief/316286.pdf.5 Memory size may vary. See Memory Legal Footnote
at www.info.toshiba.com.6 Hard drive capacity may vary. 1 Gigabyte (GB)
means 109 = 1,000,000,000 bytes using powers of 10. See Hard Disk
Drive Capacity Legal Footnote at www.info.toshiba.com.7 Copy protection
technology may prevent or limit recording or viewing of certain optical
media (e.g., CD or DVD).8Small bright dots may appear on your screen
display when you turn on your PC. Your display contains an extremely
large number of thin-film transistors (TFT) and is manufactured using
high-precision technology. Any small bright dots that may appear on your
display are an intrinsic characteristic of the TFT manufacturing technology.
Over a period of time, and depending on the usage of the computer,
the brightness of the screen will deteriorate. This is also an intrinsic
characteristic of the screen technology. When the computer is operated
on battery power, the screen with dim and you may not be able to increase
the brightness of the screen while on battery power.9GPU performance
may vary. See Graphics Legal Footnote at www.info.toshiba.com. 10 Due
to FCC limitations, speeds of 53 kbps are the maximum permissible
transmission rates during download. Actual data transmission speeds will
vary depending on line conditions.11 Weight may vary. See Weight Legal
Footnote at www.info.toshiba.com.12 Battery life may vary. See Battery
Life Legal Footnote at www.info.toshiba.com.13 Some software may differ
from its retail version (if available), and may not include user manuals or
all program functionality. Internet access is required to enable certain
functionality of certain Microsoft products which may be included with your
computer. The Microsoft Office 2007 60-Day Trial software (if applicable)
is intended for evaluation purposes only. You must activate the software
before you can use it. Product activation procedures will be detailed during
initial launch of the software; activation requires Internet access. This
software has an expiration date of 60 days from date of first use, at which
time the software will operate under reduced-functionality mode, limiting
end-user options and operations. The Microsoft Office 2007 60-Day Trial
software is distributed without charge to the End User Customer but if the
End User wants to continue to use such product after the trial period, then
the End User Customer will have to pay a fee for the perpetual version of
such Office Product. For systems with Microsoft Money Essentials 2007
installed, note that some online services for Microsoft® Money 2007 and
Microsoft® Money 2007 Essentials will expire on the earlier of two years
after your activation of the software or September 1, 2009. Also, you may
need to get some online services separately from your financial institution,
which may charge a fee. See the online services policy at http://money.
msn.com/Money/2007/OSP.asp. 14 The terms and conditions of Toshiba’s
standard limited warranty are available at www.info.toshiba.com.
