SATELLITE 1555CDS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1999 TAIS S1555.doc Rev. 16 03/21/00 nmm. Page 1 of 3
MODEL 1555CDS/4.3 billion bytes
PART NUMBER PS155U-S6CW8
PROCESSOR
380MHz AMD K6-2 processor (1.9V) Yes: with 3D Now Technology
Integrated Coprocessor Yes
Processor Cache (on-die) 64KB: (32KB code; 32KB data)
LEVEL 2 (L2) CACHE Yes: 512KB
Type of cache memory Pipelined Burst Synchronous SRAM
Cacheable Main Memory Area Up to 256MB
Data Bus Width 64-bit
Local Clock Bus Speed 95MHz
SYSTEM ARCHITECTURE Connecting Devices
PCI BUS (v.2.2): (32-bit, 33MHz) PC Card Slots, Graphics controller, Sound, USB, Modem, HDD, CD-ROM, FDD
ISA BUS: 16-bit, 8MHz BIOS, KBC
BIOS 4Mbit Flash EPROM, 512KB
Supported standards APM (v.1.2), ACPI (v.1.0b), PnP (v.1.0a), VESA (v.2.0), DPMS, DCC2B,
SM BIOS (V.2.3), PCI BIOS. FDD/HDD/CD-ROM bootable.
SYSTEM MANAGEMENT SM 2.3 BIOS support with asset tag capability, Wired for Management V1.1a,
ACPI power management,
Toshiba Configuration Builder – customize software image tool,
Year 2000 Compliant (NSTL Hardware Tested)
MEMORY: 64Mbit SDRAM, 3.3V
Standard 32 MB
Maximum 160 MB
Speed PC100
Data Bus width 64-bit
VIDEO
Memory: 16Mbit SGRAM, 3.3V 2 MB
Speed 83 MHz
Controller Chip S3 ViRGE MX (86C260)
Data Bus Width 64-bit
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
2D graphics support BitBLT, DirectDraw, H/W Cursor
3D graphics support Direct3D
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Zoom Yes
Scaling/Interpolation Yes
DirectMPEG support Yes
DirectVideo support Yes
Internal Support Resolution
640 x 480 16.7M colors (Smaller Image)
800 x 600 16.7M colors (Full Screen)
1024 x 768 64K colors (Virtual Display Mode)
1280 x 1024 256 colors (Virtual Display Mode)
External Support Resolution Colors Support
640 x 480 16.7M colors 85Hz @ 16M color
800 x 600 16.7M colors 85Hz @ 16M color
1024 x 768 64K colors 85Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 256 color

SATELLITE 1555CDS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1999 TAIS S1555.doc Rev. 16 03/21/00 nmm. Page 2 of 3
MODEL 1555CDS/4.3 billion bytes
PART NUMBER PS155U-S6CW8
DISPLAY
Type Color Bright Dual Scan (800 x 600)
Size 12.1” Diagonal
Dot Pitch 0.3075 x 0.3075mm
Contrast Ratio 50:1
Brightness Control Yes: using SETUP or Power Save Utility
Contrast Control Yes (by dial)
ALL-IN-ONE DESIGN
HDDRemovable HDD (2.5” Enhanced IDE) 4.3 billion bytes (13msec) – Service Removable
Certification SMART
Height 8.45mm
Buffer 512KB
Burst Data Transfer Rate Ultra DMA33 Mode2 (33.3MB/sec), Multiword DMA mode 2 (16.6MB/sec),
PIO Mode 4 (16.7MB/sec)
FDD (3.5” 1.44MB; 12.7mm high) Yes
Simultaneous FDD & CD-ROM Support Yes: two independent internal units
CD-ROM: (5.25” ; 12.7mm high) 24X Maximum Speed
Weight .62 lbs.
Interface .ATAPI (Enhanced IDE) with 128KB buffer
Random Access Time 130ms
Data Transfer Rate (max) 3,600KB/sec
Burst Data Transfer Rate Ultra DMA mode2 (33.3MB/sec) or PIO Mode 4 (16.7MB/sec)
Supported Disc formats CD-ROM, CD-R, Photo CD (Multisession), CD Extra (CD Plus), CD-G,
CD-RW (read only)
KEYBOARD
84 keys, 3mm Travel Yes
Key support Windows 95/98, Application
Application Key support Yes
Easy Access Internet Key Fn + F6 key
CD-ROM functions Skip to Previous track (Fn+F7); Play & Stop (Fn+F8); Skip to next track (Fn+F9)
Dedicated function keys 12 dedicated function keys
Keyboard height 8mm
Key Pitch 19.05mm
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART equivalent) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
RJ-11 Modem port Yes
Microphone (3.5mm mini jack, monaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Noteworthy security lock port Yes

SATELLITE 1555CDS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1999 TAIS S1555.doc Rev. 16 03/21/00 nmm. Page 3 of 3
MODEL 1555CDS/4.3 billion bytes
PART NUMBER PS155U-S6CW8
INTERNAL MODEM Integrated V.90/K56flex modem
DAA support US/Canada
Data support
Protocols supported ITU-T V.21/V.22/V.22bis/V.23/V.32/V.32bis/V.34/BELL 103/212A, V.90
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Modem Functions
Standard software RingZeroRingCentralmodem software
Supported Functions Ring Wake-up Resume
POWER
Autosensing External AC Adapter: PA2450U 4.9”L x 2.46”W x .97”H --- Weight: .66lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3.0A
Power Output (Watts) 45W
Battery Type: Li-Ion Graphite (2600mAH) Yes (one standard): Part# PA2487UR
Battery Life: (Full Power) 2.0 hrs
Recharge Time (Computer Off/On) 3/4-10 hrs. depending on the computer function performed
Power Saving Features APM v.1.2 BIOS, CPU Sleep mode, HDD Auto Off, Display Auto Off
CPU speed change, Hibernation, Stand By
SOUND SYSTEM Toshiba Sound System
Chipset ESS ES1978S (PCI audio accelerator) & ESS 1918S
Features Multi-stream DirectSound and DirectSound3D acceleration
Hardware acceleration for DirectMusic and DirectInput
16-bit stereo audio playback/record Yes
Maximum sampling rate 48 kHz
FM Synthesis support 64-channel wavetable music synthesis
Full duplex function Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI
3D Sound Support Yes: w/ HRTF 3D positional audio
Direct3DSound, DirectSound support Yes
DirectMusic, DirectInput support Yes
Speaker system Two top-mounted stereo speakers (28mm, 8 Ω) with volume control
DIMENSIONS
Notebook 12.2”W x 10.2”D x 1.7”H
AC Adapter 4.92”W x 2.48”H x .98”D
Battery (Standard) 6.87”L x 2.76”W x 0.73”H
WEIGHT
Notebook 6.8 lbs.
AC Adapter .66 lbs.
Battery (Standard) .66 lbs.
SECURITY Hardware Cable Lock slot; memory, main HDD & modem (by screw only)
Password Power-on
Miscellaneous Screen blank, screen saver, Keyboard lock

SATELLITE 1555CDS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1999 TAIS S1555.doc Rev. 16 03/21/00 nmm. Page 4 of 3
MODEL 1555CDS/4.3 billion bytes
PART NUMBER PS155U-S6CW8
BUNDLED SOFTWARE (Windows 98 models)
Windows98 Second Edition, Lotus Smartsuite Millenium, Symantec NortonAntivirus5.0, Ring ZeroRing Central,
Intuit Quicken Basic 99, AT&T WorldNet Free Trial, Customizable Toshiba/My Yahoo start page, System Soft Card &
Socket Services, Toshiba Custom Utilities (HWSetup, Quick Hibernation, Power Saver, Toshiba Hibernation utility,Hotkey utility),
User’s Guide, Toshiba Accessories (Desktop Shortcut to purchase Accessories Online)
CD’s Included: Bootable Windows 98 Configuration Builder CD (CBCD Pro compatible), Lotus Smartsuite CD,
Toshiba Companion diskette
Toshiba Take 2 Software: Select a Total of 2 Additional Software Titles. Pay only $7.95 shipping
Mobile Productivity
LaplinkPro Print Artist6.0
Route Planner Snapshot
Street Wizard 6.0 Education
The New Way Things Work Encyclopedia of Science 2.0
Eyewitness Children’s Encyclopedia 1999 Grolier Multimedia Encyclopedia®
Entertainment
Smart Games2 All-American Sports: Golf
YahtzeeHoyle Classic Card Game
Boggle
WARRANTY 1 YR Parts / 1 YR. Labor / 1 YR. Battery
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity: Operating 20%to 80%non-condensing 10%to 95%non-condensing
Altitude: Operating -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: Operating 10G (11ms) 60G (66ms)
Vibration: Operating 0.5G 1G
