Toshiba A75 S209 - Satellite - Mobile Pentium 4 3.06... User manual

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 1 of 8
Satellite A75 Series
Model Name Description Part Number UPC Code
Satellite A75-
S209 Intel® Pentium® 4 Processor 532, 15.4” TruBrite™ WXGA, 512MB, 60GB (4200 RPM), DVD/CD-RW, 802.11g, TV-Out, CD play/Instant play button, Parallel port, Microsoft®
Windows® XP Home,1-year Limited Warranty
PSA70U-09700E 32017270091
Satellite A75-
S2091 Intel® Pentium® 4 Processor 532, 15.4” TruBrite™ WXGA, 512MB, 60GB (4200 RPM), DVD/CD-RW, 802.11g, TV-Out, CD play/Instant play button, Parallel port, Microsoft®
Windows® XP Pro, 1-year Limited Warranty
PSA70U-09700M 32017270107
Satellite A75-
S229 Intel® Pentium® 4 Processor 538, 15.4” TruBrite™ WXGA, 512MB, 80GB (4200 RPM), DVD- SuperMulti, 802.11g, TV-Out, IEEE®1394, 5-in-1 Multimedia port, Parallel port, Infrared port,
CD play/Instant play button, Microsoft® Windows® XP Home, 1-year Limited Warranty
PSA70U-00E00G 32017270053
Satellite A75-
S2291 Intel® Pentium® 4 Processor 538, 15.4” TruBrite™ WXGA, 512MB, 80GB (4200 RPM), DVD- SuperMulti, 802.11g, TV-Out, IEEE®1394, 5-in-1 Multimedia port, Parallel port, Infrared port,
CD play/Instant play button, Microsoft® Windows® XP Pro, 1-year Limited Warranty
PSA70U-00E00P 32017270060
System Characteristics1
Operating System
•Microsoft® Windows® XP Home
•Microsoft® Windows® XP Professional
Processor2and Chipset
•Choice of processors:
oMobile Intel® Pentium® 4 Processor 532 supporting HT
Technology [3.06GHz, 1MB L2 cache, 533MHz Front Side
Bus (“FSB”)],
oMobile Intel® Pentium® 4 Processor 538 supporting HT
Technology [3.20GHz, 1MB L2 cache, 533MHz Front Side
Bus (“FSB”)],
•ATI MOBILITY™ RADEON™ 9000 IGP
Memory
•512MB (Min)/1536MB (Max) (512MB on-board model). PC2700
DDR333 SDRAM 2.5V SODIMM Memory modules; configurable
from 512MB to 1536MB
Mass Storage3
Choice of Hard Disk Drives:
•80GB (4200RPM) or 60GB (4200 RPM), Enhanced IDE (ATA-6)
hard disk drive; 9.5mm height; user removable
Choice of Optical Disk Drives:
•Fixed Bay DVD-ROM/CD-RW, 5.25” EIDE, 12.7mm height.
Compatibility: CD-ROM (read), CD-R (read), CD-RW (read/write),
DVD-ROM (read), DVD-R (read), DVD-RW (read), DVD-RAM
(read).
•Fixed Bay DVD Super Multi Drive, 5.25” EIDE, 12.7mm height.
Capability: CD-ROM (read), CD-R (read/write), CD-RW
(read/write), DVD-ROM (read), DVD-R (read/write), DVD-RW
(read/write), DVD+R (read/write), DVD+RW (read/write), DVD-
RAM (read/write)
Optional Floppy Disk Drive
•External USB Floppy Drive, 3.5”, 1.44MB
Display4
•15.4” diagonal WXGA TFT active-matrix TruBrite™ LCD; internal
display supports up to 16M colors at 1280 x 800 (WXGA), High-
Brightness CSV
•Maximum brightness 232 Cd/m2
•Brightness Control
Graphics
•ATI MOBILITY™ RADEON™ 9000 IGP (integrated video); 64MB
of shared memory, user adjustable to 128MB
Input Devices
•Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows®& Application keys
support; HotKey function
•Mouse: Touch Pad
Expandability
•2 Expansion memory slots
•1 PC Card slots support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Communications5
•Integrated V.92 modem
•Integrated 10/100Base-TX
•Integrated Wi-Fi® compliant 802.11g Atheros wireless LAN
Ports
Standard
•RGB (monitor) port
•TV-Out port (S-video)
•3 Universal Serial Bus (USB) port (v2.0)
•External Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
Configured (Only available on certain models)
•Parallel port
•CD play/Instant play button
•IEEE 1394
•Infrared port
•5-in-1 Multimedia port (SD, Memory Stick, MMC, xD-picture Card,
Memory Stick Pro)
Physical Description
•Dimensions (WxDxH Front/H Rear): 14.4” x 10.8” x 1.54”/1.81”
•Weight6: Starting at 7.97lbs depending upon configuration
•LED Indicators: DC-In, Power, Primary Battery, Hard Drive, CD-
DVD ROM Access, Wireless indicator, Caps Lock, Arrow Lock,
Numeric Lock, Main Battery Charging Status, Sleep Suspend
Mode, SD Card, Multiple Digital Media Card
Sound
•Realtek ALC259 Software Sound
•16-bit stereo; Built-in stereo speakers, Built-in microphone
•3D Sound Support, Direct 3D Sound; DirectSound, Direct Music,
MIDI (playback) Support
•Sound Volume Control Dial
Power Supply
•120W (19V 6.3A) Auto-sensing external AC Adapter, 100-240V /
50-60Hz input.
Battery7
•12-cell (6450mAh), rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Battery Life (Normal Mode): Up to 2 hours (12-cell battery)
(measured by Winstone™)
Security
•Slot for cable lock; HDD, memory (by screw only); User Power-on
password, Supervisor Password (Set-up Security), Screen Blank
(by HotKey), Screen Saver (by software).
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS v2. 1,
PC BIOS v2.2 support
Software
Toshiba Software and Utilities
•Toshiba Notebook Maximizer
•Toshiba Speech System
•Toshiba ConfigFree™
•Toshiba Custom Utilities
•Toshiba Touch and Launch
•TOSHIBA MyConnect™ - 45 day free trial offer
MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your Access
Plan before the end of the trial period to avoid being charged the $39.95 monthly
Access Service fee for the six month plan commitment period. Monthly automatic

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 2 of 8
renewal feature after end of commitment period. Available to new members in the U.S.,
age 18 or older, and a major credit card for billing is required. Offer is for unlimited dial-
up, wired broadband, or Wi-Fi remote access connection time in the 50 United States
and the District of Columbia within the MyConnect service area for 30 day continuous
service periods. Use of optional 800 telephone number dial-up usage will incur
additional fees even during the trial period. Other terms and conditions apply. Offer
expires December 31, 2004. Information, prices, and availability subject to change
without notice.
Third-party Software
•Microsoft® Works
•Microsoft® Office OneNote™ 2003
•Software Decoder: InterVideo® (Win-DVD™ 5) -w/SRS
TruSurround XT® Technology (SRS TruSurround XT® Technology
features: TruSurround, SRS Dialog Clarity Enhancement, &
TruBass)
•Sonic® Solutions Drive Letter Access (DLA)
•Sonic® Solutions RecordNow!™ Basic
•ArcSoft ShowBiz® DVD Version 1.3
•Intuit® Quicken® New User Edition 2004
•Norton AntiVirus™ 2004 – w/3-Month Subscription
•AOL® (3 –Month offer)
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL
BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services
carry surcharges and communication surcharges may apply, including AK, even during
promotional period. Members may incur telephone charges on their phone bill,
depending on their location and calling plan, even during promotional period. Available
to new AOL members in the United States, age 18 or older; a major credit card or
checking account is required.
•Adobe® Acrobat Reader
•AT&T® Worldnet® Service – 1 Month FREE
Telephone access and other charges and other terms and conditions may apply. Offer
available to new customers only.
•QuickTime™ Player
•RealOne™ Player 8 Basic
•Microsoft® Internet Explorer
•Napster™ online digital music service (30-day trial)
Environmental Specifications
Operating Non-Operating
Temperature 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour
maximum 20°C per hour maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to sea
level) -60 to 3000 meters -60 to 10,000 meters
Shock 7G 60G
Vibration 0.2G 1.0G
Limited Warranty
•1 year parts, labor, and battery
Extended Warranty
•Toshiba offers many different warranty extensions and
enhanced service plans such as SystemGuard®, At-Home
Repair, and Service Express to provide additional support to
your notebook PC. For a full description and complete list of
programs, please visit www.accessories.toshiba.com
Models with 1 Year Standard Limited Warranty
•2nd/3rd Year Warranty Extension SWP-PEQQ3V
•3 Year SystemGuard + Warranty Extension SWP-PEGQ3V
•3 Year ServiceExpress + Warranty Extension SWP-PEQP3V
•3 Year At-Home Repair + Warranty Extension SWP-PEQH3V
•3 Year SystemGuard + Service Express SWP-PEGP3V
•3 Year SystemGuard + At-Home Repair SWP-PEGH3V
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com.
Memory
KTT3311/512 Kingston PC2100/PC2700, 512MB DDR
KTT3311/1G Kingston PC2100/PC2700, 1GB DDR
SD Memory Cards (Only on selected models with 5-in-1 slot)
SD-M2564B3 Toshiba 256MB SD (Secure Digital)
SD-M5124B3 Toshiba 512MB SD (Secure Digital)
Power
PA3290U-2ACA Toshiba 120W Global AC Adapter
PA3383U-1BRS Toshiba Primary Li Ion Battery (12 cell)
Cases-Security
PA1360U-1NCS Toshiba Nylon Case (15.4")
PA1361U-1NCS Toshiba Executive Leather Case (15.4")
PA1362U-1NCS Toshiba BackPack (15.4")
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Input Devices
PA1336U-1NKB Toshiba USB Keyboard
PA1337U-1NMS Toshiba USB Optical Scroller Mouse
PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller
Mouse
PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC
adapter)
Storage & Back-up
HDD1232CZP41002 Toshiba 5GB Type II PC Card HDD w/Back-up software
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup
Syst
UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup
Syst
Other
PA1370U-1ETC Toshiba Keyboard Protector
(Tecra/Satellite/Qosmio)
See Toshiba Service Plan Agreement for program terms and conditions at www.pcsupport.toshiba.com

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 3 of 8
Business Winstone® 2002 BatteryMark™ Version 1.0
These models achieved the battery life times shown using Ziff Davis Media Inc.’s Business Winstone® 2002 BatteryMark™ Version 1.0. These tests were
performed without independent verification by the VeriTest testing division of Lionbridge Technologies, Inc. (“VeriTest”). Neither Ziff Davis Media Inc. nor
VeriTest makes any representations or warranties as to the results of the tests. Winstone® is a registered trademark and BatteryMark™ is a trademark of Ziff
Davis Publishing Holdings Inc. in the U.S. and other countries. Copyright 2002 Ziff Davis Media Inc. All Rights Reserved. All products used in the tests were
shipping versions available to the general public. The battery life results were achieved running the Business Winstone® 2002 BatteryMark™ Version 1.0 on
the following system parameters. System parameters were set according to Ziff Davis Media Inc.’s recommendations.
Catalog Spec (1st) 2H 2H
(1st+2nd)
Number of Conditioning Phase 1 1
Battery Life
Life Test Run 3 3
CPU Name Mobile Intel® Pentium® 4 processor 518 with HT Technology Mobile Intel® Pentium® 4 processor 538 with HT Technology
speed 2.8GHz 3.2GHz
Processor info
number of processors 1 1
amount of RAM 512MB 512MB
A
Amount of secondary RAM cache 1MB 1MB
Li-Ion Li-Ion
type(1st)
model number(1st) PA3383U-1BRS/BAS PA3383U-1BRS/BAS
- -
type(2nd)
- -
model number(2nd) - -
B Battery
number of batteries 1 1
Graphics ATI RC300ML (internal GFX) ATI RC300ML (internal GFX)
UMA UMA
amount and type of RAM
graphics driver name and version V8.01 V8.01
C
graphics resolution and color depth, refresh rate 1280x800, 32bit, 60Hz 1280x800, 32bit, 60Hz
hard disk capacity 60G (4200rpm) 80G (4200rpm)
hard disk file system & transfer mode Enhanced IDE(ATA-6) Enhanced IDE(ATA-6)
hard disk controller model ATI IXP150 ATI IXP150
D
size of hardware cache if any - -
operating system version, service pack Windows XP Professional Savice Pack 1 Windows XP Professional Savice Pack 1
E
other special conditions N/A N/A
BIOS version 1.00 1.00
F
Power management setting see another sheet see another sheet

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 4 of 8
Business Winstone 2002 BatteryMark Version 1.0
Model#1-2
Power Save Mode Cooling Method MaximumPerformance
Intel SpeedStep(R) Technology -
Processor speed 100%-75% Low
74%-50% Low
49%-25% Low
24%-0% Low
Monitor brightness 100%-75% Mid2
(* See Notes) 74%-50% Mid2
49%-25% Mid2
24%-0% Mid2
Turn off monitor 100%-75% NEVER
74%-50% NEVER
49%-25% NEVER
24%-0% NEVER
Turn off hard disks 100%-75% 3min
74%-50% 3min
49%-25% 3min
24%-0% 3min
System standby 100%-75% NEVER
74%-50% NEVER
49%-25% NEVER
24%-0% NEVER
System Hibernate 100%-75% NEVER
74%-50% NEVER
49%-25% NEVER
24%-0% NEVER
System Power Mode When I press the power button Power off
When I close the lid Hibernate
Prompt for password when computer goes off Standby or Hibernation Off
Alarm Activate low battery alarm when power level reaches Off
Low Battrey Alarm Action Sound alarm Off
Display message Off
When the alarm goes off,the computer will: Off
When the alarm occurs, run this program: Off
Activate critical battery alarm when power level reaches Off
Critical Battrey Alarm Action Sound alarm Off
Display message Off
When the alarm goes off,the computer will: Off
When the alarm occurs, run this program: Off
Hibernate Enable Hibernate Support On
SoundMAX Audio Power
Management Power Mode -
Timer Setting Instant Power Save -
Power Save Delay -
Internal Speakers Power Down -
Return Policy
TAIS does not accept the return of component parts, or bundled software, which have been removed from the PC system. Pro-rata refunds on individual PC
components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the TAIS dealer
where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation.
Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or registered trademarks of Intel Corporation or
its subsidiaries in the United States and other countries.
Microsoft and Windows are registered trademarks and OneNote is a trademark of Microsoft Corporation in the United States and/or other countries.
BAPCO, SYSmark, and MobileMark are U.S. Registered Trademarks of Business Applications Performance Corporation.
Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such
marks by Toshiba is under license.
NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States and/or other countries.
All other trademarks are the property of their respective owners.
1Subject to Change; Product Series Disclaimer.
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices,
system/component/options availability are all subject to change without notice. For the most up-to-date product information about your computer, or to stay current with the
various computer software or hardware options, visit Toshiba’s Web site at pcsupport.toshiba.com. The product specifications and configuration information are designed
for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and
specifications on your particular model, please visit Toshiba's Web site at pcsupport.toshiba.com.
2Central Processing Unit (“CPU”) Performance Disclaimer.
CPU performance in your computer product may vary from specifications under the following conditions:
•use of certain external peripheral products
•use of battery power instead of AC power
•use of certain multimedia games or videos with special effects
•use of standard telephone lines or low speed network connections
•use of complex modeling software, such as high end computer aided design applications
•use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
•use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references
are approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website
at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the
product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage
medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in
your product Resource Guide. Contact Toshiba Technical Service and Support for more information.

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 5 of 8
3Hard Drive Capacity Disclaimer.
1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of
2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage capacity will also be less if the
product includes pre-installed operating system and/or application software. Actual formatted capacity may vary.
4TFT Disclaimer.
Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology.
Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an intrinsic characteristic of LCD technology.
Screen will dim when the computer is operated on battery power and you may not be able to increase the brightness of the screen.
5FCC Modem Speed Disclaimer.
Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary depending on line
conditions.
Wireless or Connectivity Claims.
Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone charges and air
time, etc. to achieve the functionality as advertised.
6Weight Disclaimer
Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
7General Battery Life Disclaimer or Business Winstone® 2002 BatteryMark™ Version 1.0 Battery Life Data Disclaimer
Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies depending on
usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need
to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web
site at accessoryfinder.toshiba.com.

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 6 of 8
Drawings

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 7 of 8

TOSHIBA
© Copyright 2004 Toshiba America Information Systems Inc. ("TAIS"). All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite A75-Series Revision 1.1 09-28-2004 CBB CB v_1.10 Page 8 of 8
