SATELLITE 2545 Series Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S2545.doc Rev. 6 02/07/00 st. Page 1 of 3
MODEL 2545CDS/4.3 billion bytes 2545XCDT/4.3 billion bytes
PART NUMBER PAS254U-S6CW8 PAS254U-T6CW8
PROCESSOR
333MHz AMD K6-2 processor Yes: with 3D technology
Integrated Coprocessor Yes
Processor Cache 64KB: (32KB code; 32KB data)
LEVEL 2 (L2) CACHE Yes: 512KB
Access speed 8ns
Cacheable Main Memory Area Up to 128MB
Data/Address Bus Width 64-bit/32-bit
Local Clock Bus Speed 66 MHz
SYSTEM ARCHITECTURE Connecting Devices
PCI BUS (v.2.1): (32-bit, 33 MHz) PC Card Slots, Graphics Controller, HDD, CD-ROM, FDD
ISA BUS: 16-bit, 8.25 MHz BIOS, Sound chip, KBC
BIOS 4Mbit Flash EPROM (5V), 512KB
Supported standards APM (v.1.2); ACPI; PnP (v.1.0a); VESA (v.2.0); DPMS; DCC2B; DMI (v.2.0);
PCI BIOS; CD-ROM & ATA-HDD bootable
SYSTEM MANAGEMENT DMI 2.0 BIOS w/asset tag capability; Wired for Management (v.1.1a); ACPI
Toshiba Configuration Builder – customize software image tool;
Year 2000 Compliant (NSTL Hardware Tested)
MEMORY: 64Mbit EDO DRAM, 3.3V 2545CDS 2545XCDT
Standard 32 MB 64 MB
Maximum 160 MB 192 MB
Speed 60ns 60ns
Hyper Page mode memory access Yes Yes
Data /Address Bus width 64-bit/32-bit 64-bit/32-bit
Local Bus Clock Speed 66 MHz 66 MHz
VIDEO
Memory: 16Mbit SGRAM, 3.3V 2 MB
Speed 83 MHz
Controller Chip S3 VirgeMX 3D graphics controller
Data Bus Width 64-bit
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
2D graphics support BitBLT, DirectDraw, H/W Cursor
3D graphics support Direct3D
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Zoom Yes
Scaling/Interpolation Yes
DirectMPEG support Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Support Resolution 2545CDS 2545XCDT
640 x 480 16.7M colors (Smaller Image) 16.7M colors (Smaller Image)
800 x 600 16.7M colors (Full Screen) 16.7M colors (Smaller Image)
1024 x 768 64K colors (Virtual Display Mode) 64K colors (Full Screen)
1280 x 1024 256 colors (Virtual Display Mode) 256 colors (Virtual Display Mode)
External Support Resolution Colors Support Vertical Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors 85Hz @ 64K color
800 x 600 16.7M colors 85Hz @ 64K color
1024 x 768 64K colors 60 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 64K color

SATELLITE 2545 Series Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S2545.doc Rev. 6 02/07/00 st. Page 2 of 3
MODEL 2545CDS/4.3 billion bytes 2545XCDT/4.3 billion bytes
PART NUMBER PAS254U-S6CW8 PAS254U-T6CW8
DISPLAY 2545CDS 2545XCDT
Type Color Bright Dual Scan (800 x 600) TFT Active Matrix (1024 x 768)
Size 13.0” Diagonal 14.1” Diagonal
Dot Pitch .33mm x .33mm .279mm x .279mm
Contrast Ratio 50:1 100:1
Brightness Control Yes: using SETUP or Power Save Utility Yes: using SETUP or Power Save Utility
Contrast Control Yes No
ALL-IN-ONE DESIGN
HDDRemovable HDD (2.5” Enhanced IDE) 4.3 billion bytes (13msec read/14msec write) – Service Removable
Height 9.5mm
Buffer 512KB
Burst Data Transfer Rate Ultra DMA33 Mode2 (33.3MB/sec) or PIO Mode 4 (16.7MB/sec)
Local Bus support Yes
FDD (3.5” 1.44MB; 12.7mm high) Yes
Simultaneous FDD & CD-ROM Support Yes: two independent internal units
CD-ROM: (5.25” ; 12.7mm high) 24X Maximum Speed
Weight .62 lbs.
Interface .ATAPI (Enhanced IDE) with 128KB buffer
Random Access Time 130 ms
Average Sustained Transfer Rate 3,600 KB/sec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec) or Multi Word DMA Mode2 (16.6MB/sec)
Supported Disc formats CD-DA, CD-ROM, CD-R, CD-ROM XA, Photo CD (Multisession), Video CD,
CD Extra (CD Plus), CD-G, CD-RW (read only)
KEYBOARD
84 keys, 3mm Travel Yes
Key support Windows 95/98, Application
Internet Browser function F6 key
CD-ROM functions Skip to Previous track (F7); Play & Stop (F8); Skip to next track (F9)
Dedicated function keys 12 dedicated function keys
Keyboard height 9.5mm
Key Pitch 19.05mm
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART equivalent) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
Microphone (3.5mm mini jack, monaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
RJ-11 Modem port Yes
Noteworthy security lock port Yes

SATELLITE 2545 Series Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S2545.doc Rev. 6 02/07/00 st. Page 3 of 3
MODEL 2545CDS/4.3 billion bytes 2545XCDT/4.3 billion bytes
PART NUMBER PAS254U-S6CW8 PAS254U-T6CW8
INTERNAL MODEM 56K Integrated ITU with V.90 support
DAA support US/Canada and Euro/Australia
Data support
Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34, V.90
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Telephony Functions
Standard software Ring Zero RingCentral telephony software
Supported Functions Ring Wake-up Resume
POWER
Autosensing External AC Adapter: PA2450U 4.9”L x 2.46”W x .97”H --- Weight: .66lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3.0A
Power Output (Watts) 45W
Battery Type: Li-Ion (10.8V, 4000mAH) Yes (one standard): Part# PA2487URG
Battery Life: (Full Power) 2.75+ hrs.
Recharge Time (Computer Off/On) 3 hrs./4-10 hrs. depending on the computer function performed
Power Saving Features APM v.1.2 BIOS, CPU Sleep mode, HDD Auto Off, Auto Resume, Display Auto Off
CPU speed change, Hibernation
SOUND SYSTEM Yamaha Sound System
Chipset: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum sampling ratge 48 kHz
FM Synthesis support Yes with Soft Wave Table included
Full duplex function Yes
Sound formats supported: SoundBlaster ProV3.01, Windows Sound System V2.0, MIDI
3D Sound Support Yes
Direct3DSound, DirectSound support Yes: with Windows 95 Game SDK driver from Microsoft
Speaker system Two top-mounted stereo speakers (28mm, 8 Ω) with volume control
DIMENSIONS 2545CDS 2545XCDT
Notebook 12.2”W x 10.2”D x 1.7”H 12.2”W x 10.2”D x 1.6”H
AC Adapter 4.9”L x 2.46”W x .97”H 4.9”L x 2.46”W x .97”H
Battery (Standard) 6.87”L x 2.76”W x .73”H 6.87”L x 2.76”W x .73”H
WEIGHT 2545CDS 2545XCDT
Notebook 6.8 lbs. 7.0 lbs.
AC Adapter .66lbs .66lbs
Battery (Standard) .88 lbs. .88 lbs.

SATELLITE 2545 Series Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S2545.doc Rev. 6 02/07/00 st. Page 4 of 3
MODEL 2545CDS/4.3 billion bytes 2545XCDT/4.3 billion bytes
PART NUMBER PAS254U-S6CW8 PAS254U-T6CW8
BUNDLED SOFTWARE
Windows98; Symantec NortonAntivirus Scanner; Toshiba/AT&T/Yahoo Internet Offer; Ring ZeroRing Central; AOL update;
Intel Indeo Video; Yamaha Audio Station; Disney Daily Blast; Microsoft Money 99; Microsoft Outlook; Quicken 99 Basic;
Toshiba Custom Utilities (HWSetup, Quick Hibernation, Power Saver, Hotkey utility, Toshiba Hibernation utility); User’s Guide
CD’s Included: Bootable Windows 98 Configuration Builder CD; Toshiba Companion diskette; Microsoft Encarta 99 MPEG version;
Microsoft Money; Microsoft Outlook 98; Microsoft Bookshelf 99
Customer Choice Software: Select of a Total of 5 Additional Software Titles
Office Productivity
Lotus

SmartSuite Millenium Edition (counts as 5 selections): Lotus 123, Approach, Freelance Graphics, Wordpro, and Organizer
Dragon Point & Speak

(requires the purchase of a $6.00 microphone)
Mobile Productivity
Laplink7.5 Print Artist4.5
Rand McNally TripMaker1999 Snapshot
USA 99: Streets & Destinations Education
The Way Things Work 2.0 Encyclopedia of Science 2.0
Eyewitness Children’s Encyclopedia Higher Score Guaranteed ACT/SAT/PSAT
Math BlasterAlgebra Jump Start Family Activity CD
Entertainment
You Don’t Know JackMovies Asteroids
Sierra SportsSki Racing ‘99 Battlezone
OddWorld: Abe’s OddyseeJack Nicklaus 5.0
Total Annihilation
SECURITY Hardware Cable Lock slot; PC Card lock slot; main HDD & modem (by screw only)
Password Power-on, Supervisor, & HDD password
Miscellaneous Screen blank, Keyboard lock
WARRANTY 1 YR Parts / 1 YR. Labor / 1 YR. Battery
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity: Operating 20%to 80%non-condensing 10%to 95%non-condensing
Altitude: Operating -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: Operating 10G (11ms) 60G (66ms)
Vibration: Operating 0.5G 1G
