TECRA 740CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 740.doc Rev. 18 02/07/00 nmm. Page 1 of 3
740CDT: PA1229U-T2C 740CDT: PA1233U-T2C
2.1 Billion Bytes = 2.02GB 3.08 Billion Bytes = 2.87 GB
PROCESSOR
Intel Pentium166Mhz (2.45v/3.3v) w/ MMX Yes Yes
External data bus width 64 bit 64 bit
External data/address bus speed 66 MHz 66 MHz
Integrated Coprocessor Yes Yes
Processor Cache 32KB: (16KB code; 16KB data) 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE Yes Yes
Data Bus Width 64 bit 64 bit
Data Bus Speed 66 MHz 66 MHz
DATA RAM: Yes Yes
1 Mbit Pipelined Burst Synchronous SRAM (32K x 32bit, 3.3V) x 2 (32K x 32bit, 3.3V) x 2
Access Time 8 ns 8 ns
TAG-RAM: Yes Yes
256Kbit Asynchronous SRAM (32K x 8bit, 3.3V) x 1 (32K x 8bit, 3.3V) x 1
Access Time 14ns 14ns
SYSTEM ARCHITECTURE
PCI BUS (v.2.1): (32-bit, 33 MHz) Connecting Devices: PC Card Slots, Expansion Bus, Graphics Controller
ISA BUS: 16-bit, 8 MHz Connecting Devices: BIOS, CD-ROM, FDD, FIR, HDD, KBC, Sound chip
MEMORY: 16Mbit EDO DRAM, 3.3V
Standard 16 MB 16 MB
Maximum 144 MB 144 MB
Speed 60ns 60ns
Hyper Page mode memory access Yes Yes
Data width 64 bit 64 bit
BIOS (256KB FLASH EPROM, 120ns, 5V) Yes Yes
PnP 1.0a SUPPORT Yes Yes
DISPLAY
Type 13.3”Diagonal TFT Active Matrix 13.3”Diagonal TFT Active Matrix
Dot Pitch .26mm x .26mm .26mm x .26mm
Contrast Ratio 100:1 (min) 100:1 (min)
VIDEO (All models)
Memory: 4Mbit EDO DRAM, 5V 2 MB
Speed 50ns w/ Hyper-page mode support
Controller Chip C&T HIQV32 (CT65554) w/64-bit Data Bus Width
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes: Supports 64-bit BitBLT, DirectDraw, Direct3D, H/W Cursor
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling Support Yes
Zoomed Video Port Support Yes (vertical & horizontal)
Interpolation Yes (vertical & horizontal)
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Resolution 1024 x 768 x 64K/64K colors
Smaller Image 640 x 480 x 64K/64K colors
Smaller Image 800 x 600 x 64K/64K colors
Virtual Display Mode 1280 x 1024 x 256/256K colors
External Resolution Colors/Palette
640 x 480 16.7M colors/16.7M colors
800 x 600 16.7M colors/16.7M colors
1024 x 768 64K colors/64K
1280 x 1024 256 colors/256K
Refresh Rate Vert.: 60Hz; Hor.: 48.5kHz (taken.@ 1024x768/64K colors Non-Interlaced)

TECRA 740CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 740.doc Rev. 18 02/07/00 nmm. Page 2 of 3
740CDT: PA1229U-T2C (con.) 740CDT: PA1233U-T2C
2.1 Billion Bytes = 2.02 GB 3.08 Billion Bytes = 2.87 GB
STORAGE
Removeable HDD (2.5” Enhanced IDE) 2.1 Billion Bytes=2.02GB (13msec) 3.08 Billion Bytes = 2.87 GB (13msec)
SELECT BAY DEVICES (All models)
Modular FDD (3.5” 1.44MB) Included/Swappable with CD-ROM
FDD Dimensions 4.57”L x 3.8”W x .59”H
FDD Weight Weight: .29 lbs
Simultaneous FDD & CD-ROM Support Yes: External FDD adapter included
FDD Adapter Dimensions 7.0”L x 5.5”W
FDD Adapter Weight .25 lbs
Modular HDD (2.5” Enhanced IDE) Optional/For use in SelectBay only
Capacity 2.1 billion bytes=2.02GB (13msec)
Modular CD-ROM: Toshiba XM-1502B
5.25” 10x-Average speed Installed/ For use in SelectBay only
Weight .6 lbs
Interface .ATAPI (Enhanced IDE)
Random Access Time 180 ms
Average Sustained Transfer Rate 1,500 KB/sec
Supported Disc formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
KEYBOARD
82 keys, 3mm Travel Yes Yes
12 dedicated function keys Yes Yes
Cursor control (8 Keys, Inverted "T") Yes Yes
Numeric keypad (Integrated Overlay) Yes Yes
Integrated Pointing Device AccuPointAccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slot2Yes: CardBus & ZV Card Ready Yes: CardBus & ZV Card Ready
32-bit, 3.3V PC CardBus Support Yes Yes
16-bit, 5.0V PC Card Support Yes Yes
Internal Memory Slot (One only) Yes Yes
EXPANSION PORTS
One RJ-11 port for internal modem (supplied) Yes Yes
One 9-Pin Serial (16550 UART compliant) Yes Yes
One 25-Pin Parallel (8 bit ECP) Yes Yes
One 15-Pin RGB (SVGA video) Yes Yes
Serial Fast Infrared port (back only) Yes: IrDA 1.1:4 Mbps compatible Yes: IrDA 1.1:4 Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: w/”Y”Connector support Yes: w/”Y”Connector support
One External Floppy Drive port Yes Yes
Microphone (3.5mm mini jack, monoaural) Yes Yes
Headphone (3.5mm mini jack, stereo) Yes: (16 Ωmin) Yes: (16 Ωmin)
Line-in (3.5mm mini jack, stereo, 2V rms) Yes Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes Yes
Noteworthy security lock port Yes Yes
SOUND SYSTEM (All models)
Chipsets: Crystal Semiconductor CS4232, Yamaha OPL3 (YMF262),
Synthesis policy FM synthesis
16 bit stereo audio playback/record Yes: w/48kHz maximum sampling rate
Full duplex function Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI, Zoomed video port audio (stereo),
CardBus audio (monaural), CD-ROM audio
DirectSound support Yes: with Windows 95 Game SDK driver from Microsoft
Speaker system: Two top-mounted stereo speakers (28mm, 8 Ω)
2. Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.

TECRA 740CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 740.doc Rev. 18 02/07/00 nmm. Page 3 of 3
740CDT: PA1229U-T2C (con.) 740CDT: PA1233U-T2C
2.1 Billion Bytes = 2.02 GB 3.08 Billion Bytes = 2.87 GB
INTERNAL MODEM (All models) 28.8 /14.4 Kbps Voice/Data/Fax modem w/V.80 support for Video Conferencing
DAA support US/Canada and Euro/Australia
Noteworthy Business Video phone (std) Color video camera, CardBus Capture Card, & video phone w/ProShare Technolgy
Data support
Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.22bis, V.23, VV.32, V.32bis, V.32 terbo, V.34
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Supported Functions Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Incoming Call Discrimination, Caller ID
NoteDock II

Port Replicator (Optional) Part# PA2713U
Two Type III CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA monitor,
Lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone
Desk Station V Plus (Optional) Part# PA2710U
(2) Full length 32-bit PCI/16-bit ISA slots Yes
(1) Half Length 32-bit PCI slot Yes
(2) Type III PC Card slots Yes
Built-in SCSI II Yes
5.25” half height drive bay Yes
Select Bay for Modular FDD or CD-ROM Yes
Designed for Windows 95 and PNP Yes
Hot Docking Support Yes
POWER (All models)
Autosensing External AC Adapter 5.51”L x 2.95”W x .98” --- .75 lbs. (Part#:NW2484U)
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.7A (max)
Power Output (Watts) 40W
Battery Type: Li-Ion (10.8V, 5600mAH) Yes: Part# PA2485UXR (Note: Different form factor from 730 series models)
Battery Life: (Full Power/Low Power) 2.5 hrs.
Recharge Time (Computer Off/On) 4 hrs.(Off) /5.5-12.5 hrs.(On)
MaxTimePower Management Yes
DIMENSIONS 11.95”W x 9.41"D x 2.4”H 11.95”W x 9.41"D x 2.4”H
WEIGHT (includes 1.32 lbs. battery) 8.45 LBS. 8.45 LBS.
BUNDLED SOFTWARE (All models): User selectable Windows 95 or Windows for Workgroups 3.11 and MS-DOS 6.22;
Intel Indeo Video; Runtime Video f/Windows; Synchro Multimedia ConnectTelephony Software ; Sony Music Screeners;
Mediamatics Arcade Pack; America Online; Toshiba utilities: Maxtime, magiCDisc, Fn-esse, online documentation
Netscape Navigator; Compuserve; Puma TranXit, SystemSoft CardSoft card & socket serivices
SECURITY Lock slot, Password:power-on, supervisor, HDD, Docking station eject
WARRANTY 3 YR Parts & Labor (battery 1 year)
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient (20º C per hour max.) N/A N/A
Relative Humidity: 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration: 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
