SATELLITE 4060CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4060.DOC Rev. 6 02/07/00 st. Page 1 of 3
PART NUMBER DESCRIPTION
PAS406U-T2CW8 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows 98 w/ dual linked Win95/98
Configuration Builder CD
PAS406U-T2N4 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows NT 4.0
PROCESSOR (All models) Intel Mobile Pentium II 333Mhz (1.6v)
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE (All models) Yes: 256KB Integrated into CPU
Data/Address Bus Width 64bit/32bit
Front Side Bus Clock Speed 66 MHz
SYSTEM ARCHITECTURE (All models) Chipset Connecting Devices
PCI BUS (v.2.1): (32-bit, 33 MHz) Intel 440DX Graphics Controller, Sound chip, modem
ISA BUS: 16-bit, 8.33 MHz N/A BIOS, KBC
MEMORY: 64Mbit SDRAM, 3.3V (All models)
Standard 64 MB
Maximum 192 MB
Speed 60ns
Hyper Page mode memory access Yes
Data/Address Bus Width 64bit/32bit
Local Bus Clock Speed 66 MHz
BIOS (All models) 512KB: 4Mbit FLASH EPROM, 5V
Supported standards APM (v.1.2); ACPI; PnP 1.0a; VESA (v.2.0); DPMS, DCC2B, SM BIOS (v.2.1);
PCI BIOS
DISPLAY (All models)
Type TFT Active Matrix Color (1024 x 768)
Size 13.3” Diagonal
Dot Pitch .3075mm x .3075mm
Contrast Ratio 100:1 (Min)
VIDEO (All models)
Memory 2.5 MB integrated into chipset
Speed 50ns
Hyper Page mode support Yes
Controller Chip Trident Cyber 9525
Data Bus Width 64-bit
PCI Bus Architecture Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
2D graphics support BitBLT, DirectDraw, H/W Cursor, Pattern area fills, polygon fill
3D Supported Features
Modeling Fogging, Lighting
Shading Flat shading, Gouraud shading
Rendering Bilinear texture mapping , Anti-aliasing, MIP mapping, Z-buffering
Alpha-blending Yes
Direct3D support Yes
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation Yes
Color Palette 16.7M colors
Internal Support Resolution Colors Support
Full Screen 1024 x 768 64K colors
Smaller Image 640 x 480 16.7M colors
Smaller Image 800 x 600 16.7M colors
Virtual Display Mode 1280 x 1024 256 colors
External Support Resolution Colors Support Vertical Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors 85Hz @ 64K color
800 x 600 16.7M colors 85Hz @ 64K color
1024 x 768 64K colors 85 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 256 color

SATELLITE 4060CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4060.DOC Rev. 6 02/07/00 st. Page 2 of 3
PART NUMBER DESCRIPTION
PAS406U-T2CW8 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows 98 w/ dual linked Win95/98
Configuration Builder CD
PAS406U-T2N4 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows NT 4.0
ALL-IN-ONE DESIGN (All models)
STORAGE
Removable HDD (2.5” Enhanced IDE) 4.3 billion bytes (13msec) with 512KB Buffer --- 2 screw service-removable
Height 9.5mm
Burst Data Transfer Rate Ultra DMA Mode 2 (33.3MB/s); PIO Mode 4 (16.7MB/s)
FDD (3.5” 1.44MB; 12.7mm high) Yes
Simultaneous FDD & CD-ROM Support Yes: two independent units
CD-ROM: (5.25”; 12.7mm high, .62 lbs.) 24X Maximum Speed
Interface .ATAPI (Enhanced IDE) with 128KB buffer
Random Access Time 130 ms
Average Sustained Transfer Rate 3,600 KB/sec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec); Multi Word DMA Mode2 (16.6MB/sec)
Supported Disc formats CD-DA, CD-ROM, CD-R, CD-ROM XA, CD-I FMV, Photo CD (Multi-session)
Video CD, CD Extra (CD Plus), CD-G, CD-RW (read only)
INTERNAL MODEM (As Listed) Internal 56K V.90 modem
DAA support US/Canada
Data support (All models) Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34, V.90
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support (All models) Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
SOUND SYSTEM
Chipsets ESS ES1978S (PCI audio accelerator); ESS ES1920S
Features Hardware acceleration for DirectMusic, ActiveMovie, and Direct Input API
16-bit stereo audio support Yes
Maximum sampling rate 48 kHz
FM Synthesis support Yes: 64-channel wavetable music synthesis
Full duplex function Yes
Sound formats supported: SoundBlaster ProV3.01, Windows Sound System V2.0; MIDI
3D Sound Support Yes: HRTF 3D positional audio, DVD AC-3 speaker virtualization
Direct3Dsound, DirectSound support Yes: with Windows 98 Game SDK driver from Microsoft
Speaker system Stereo Bass-Reflex speaker system
Form factor Two top-mounted stereo speakers (28mm, 8 Ω) with volume control
KEYBOARD
84/86 keys, 3mm Travel Yes
12 dedicated function keys Yes
Windows 95/98 key support Yes
Application Key support Yes
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes

SATELLITE 4060CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4060.DOC Rev. 6 02/07/00 st. Page 3 of 3
PART NUMBER DESCRIPTION
PAS406U-T2CW8 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows 98 w/ dual linked Win95/98
Configuration Builder CD
PAS406U-T2N4 PII333, 13.3”, 64MB, 4.3bb HDD, Modem, Windows NT 4.0
EXPANSION PORTS
One 9-Pin Serial (16550 UART equivalent) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
One Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
One Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
One Microphone (3.5mm mini jack, stereo) Yes
One Headphone (3.5mm mini jack, stereo) Yes
One Line-in (3.5mm mini jack, stereo, 2V rms) Yes
One Noteworthy security lock port Yes
Enhanced Port Replicator III (Optional) Part# PA2717U (Requires Adapter PA2730U)
Dimensions/Weight 13.2”W x 10.6”D x 2.9”H (Weight: 3.3 lbs.)
Two Type III CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA monitor, FDD port,
lock slot , joystick/MIDI, line-in, line-out, headphone, microphone, lock slot
POWER
Autosensing External AC Adapter: PA2450U 4.9”L x 2.46”W x .97”H --- Weight: .66lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3.0A
Power Output (Watts) 45W
Battery Type: Li-Ion (10.8V, 4000mAH) Yes (one standard): Part# PA2487URG
Battery Life: (Full Power) 3.0 hrs.
Recharge Time (Computer Off/On) 2.5+/4-10 hrs. depending on the computer function performed
Power Saving Features APM v.1.2 BIOS, CPU Sleep mode, HDD Auto Off, Auto Resume, Display Auto Off
CPU speed change, Hibernation
DIMENSIONS Dimensions Weight
Notebook 12.1”W x 10.2”D x 1.6”H 7.0 lbs.
AC Adapter 4.9”L x 2.46”W x .97”H .66lbs.
Battery (Standard) 6.87”L x 2.76”W x 0.73”H .88 lbs.
BUNDLED SOFTWARE (Windows 98 models)
Windows®98; Ring Zero Ring Central; Symantec Norton Antivirus Scanner; Free Internet Trial Offer; America Online
IntelliSync97; Microsoft Internet Explorer 4.0; Prodigy Internet; Intel Indeo Video; User’s Guide
Toshiba Utilities (HWSetup, Quick Hibernation, Toshiba Hibernation, Power Saver, FN-esse)
CD’s Included: Bootable Linked Win98 Configuration Builder CD; Bootable Linked Win95 Configuration Builder CD;
Toshiba Companion Diskette
BUNDLED SOFTWARE (Windows NT models)
Windows NT 4.0; Service Pack 3.0; Toshiba Power Management System (APM); CardWizard Windows NT 4.0; User’s Guide
Microsoft Internet Explorer
Additional Software on Configuration Builder CD: Microsoft Internet Explorer v4.01; SystemSoft CardWorks 32-bit;
SMS Connection
CD’s Included: Windows NT Configuration Builder CD; Toshiba Companion Diskette
SECURITY Hardware Cable Lock slot; By screw only: PC Card lock slot, HDD, internal modem
Password Power-on, Supervisor, & HDD password
Miscellaneous screen blank, keyboard lock
WARRANTY 1 YR Parts / 1 YR. Labor / 1 YR. Battery
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
