Satellite®2410/2415 Series
Resource Guide
NOTE: Keep this guide in a convenient place to access important
information about your computer.
If you need assistance:
InTouchCenter
Calling within the United States [phone]
Calling from outside the United States [phone]
Please fill in for your reference and future use:
Model name _______________________________________
Part number _______________________________________
Serial number ______________________________________

2
RG 5.375 x 8.375 ver 2.3.4

3
Contents
RG 5.375 x 8.375 ver 2.3.4
Contents
Setting up your computer and getting started............................ 6
Inserting PC Cards................................................................... 12
Removing PC Cards................................................................. 13
Learning the basics.................................................................. 14
Playing a CD or DVD ................................................................ 15
Moving the computer............................................................... 17
Mobile computing.................................................................... 18
If something goes wrong ......................................................... 22
If you need further assistance.................................................. 25
Power cable connectors........................................................... 26
Features and specifications...................................................... 26
Regulatory information ............................................................ 31
Index ........................................................................................43

4Contents
RG 5.375 x 8.375 ver 2.3.4

5
RG 5.375 x 8.375 ver 2.3.4
Welcome to the world of powerful and portable multimedia computers!
With your new Toshiba notebook computer, your access to information can
accompany you wherever you go.
You will find that the Microsoft®Windows®XP operating system is
already installed on your computer. It offers exciting features and easy
Internet access.
This guide
This guide offers important information about your computer, including
solutions to the most common problems, and features and specifications.
For more detailed information, descriptions of other features and more
extensive troubleshooting guidelines, see the electronic user’s guide
preinstalled on your system. It is also available on the Web at
pcsupport.toshiba.com.
Safety icons
This guide contains safety instructions that must be observed in order to
avoid potential hazards that could result in personal injuries, damage to
your equipment, or loss of data. These safety cautions have been classified
according to the seriousness of the risk, and the icons highlight these
instructions as follows:
DANGER: This icon indicates the existence of a hazard that could result in death or
serious bodily injury if the safety instruction is not observed.
WARNING: This icon indicates the existence of a hazard that could result in bodily
injury if the safety instruction is not observed.
CAUTION: This icon indicates the existence of a hazard that could result in damage to
equipment or property if the safety instruction is not observed.
NOTE: This icon indicates information that relates to the safe operation of the
equipment or related items.
Other icons used
Additional icons highlight other helpful or educational information:
TECHNICAL NOTE: This icon highlights technical information about the computer.
HINT: This icon denotes helpful hints and tips.

6Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
DEFINITION: This icon indicates the definition of a term used in the text.
Other documentation
Your computer comes with all or some of the following documentation in
addition to this resource guide:
❖Electronic user’s guide installed on your system.
❖Guides for other software that may come preinstalled.
❖Microsoft®Windows®XP operating system documentation.
❖For accessory information, visit Toshiba’s Web site at toshiba.com.
❖The Recovery CDs containing the programs that are preinstalled at the
factory and any bundled software. Keep these CDs in a safe and
convenient place.
Setting up your computer and getting started
Strain and stress injuries are becoming more common as people spend
more time using their computers. With a little care and proper use of the
equipment, you can work comfortably throughout the day.
WARNING: Using the computer keyboard incorrectly can result in discomfort and
possible injury. If your hands, wrists, and/or arms bother you while typing, stop using
the computer and rest. If the discomfort persists, consult a physician.
For more information, consult books on ergonomics, repetitive-strain
injury, and repetitive-stress syndrome.
Placement of the computer
Proper placement of the computer and external devices is important to
avoid stress-related injuries. Consider the following when placing your
computer.
❖Place the computer on a flat surface at a comfortable height and
distance. You should be able to type without twisting your torso or
neck, and look at the screen without slouching.
❖If you are using an external monitor, the top of the display should be
no higher than eye level.
❖If you use a paper holder, set it at about the same height and distance
as the screen.
Seating and posture
When using your computer, maintain good posture with your body relaxed
and your weight distributed evenly. Proper seating is a primary factor in
reducing work strain.

7
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Precautions
Your notebook computer is designed to provide optimum safety and ease of
use, and to withstand the rigors of travel. You should observe certain
precautions to further reduce the risk of personal injury or damage to the
computer.
CAUTION: Never apply heavy pressure to the computer or subject it to sharp impacts.
Excessive pressure or impact can damage computer components or otherwise cause
your computer to malfunction.
CAUTION: Some PC Cards become hot with prolonged use. If two cards are installed,
both can become hot even if only one is being used. Overheating of a PC Card can
result in errors or instability in its operation.
Be careful when you remove a PC Card that has been used for lengthy periods of time.
Important information on your computer’s built-in LCD sensor
Your computer has a built-in LCD (liquid crystal display) sensor located
near the left-hand corner of the palm rest. When the computer is on, the
LCD sensor detects when the display panel is closed.
Please do not place a magnetic object in the area of the left-hand corner of
the palm rest. A magnetic object placed there causes the LCD sensor to
erroneously activate.
For more information, see “Important information on your computer’s
built-in LCD sensor” in your electronic user’s guide.
Connecting to a power source
Your computer requires power to operate. Use the power cable and AC
adapter to connect the computer to a live electrical outlet, or to charge the
computer’s battery.
Built-in
LCD sensor

8Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Power Cable and AC Adapter
CAUTION: Use only the AC adapter supplied with your computer or an equivalent
adapter that is compatible. Use of any incompatible adapter could damage your
computer. Toshiba assumes no liability for any damage caused by use of an
incompatible adapter.
When you connect the AC adapter to the computer, always follow the steps in the exact
order as described in the User's Manual. Connecting the power cable to a live electrical
outlet should be the last step otherwise the adapter DC output plug could hold an
electrical charge and cause an electrical shock or minor bodily injury when touched. As
a general safety precaution, avoid touching any metal parts.
DANGER: Hold the power cable by its plug when you connect/disconnect it. Do NOT
pull the cable itself. Doing so may damage the power cable and result in a short circuit
or electric shock.
To connect AC power to the computer:
1Connect the power cable to the AC adapter.
2Plug the AC adapter into the DC-IN on the back of the computer.
3Connect the power cable to a live electrical outlet.
If the electrical outlet is live, the system indicator panel’s AC power light
( ) glows green.
DANGER: Damaged power cables can cause fire or electric shock. Never modify,
forcibly bend, place heavy objects on top of, or apply heat to the power cable.
If the power cable becomes damaged or the plug overheats, discontinue use. There is a
risk of electric shock.
Never remove the power plug from the outlet with wet hands. Doing so may cause an
electric shock.
Connecting a printer
You can connect a USB-compatible printer to your computer through one
of the USB ports. You can also connect a parallel printer through the
parallel port.
To confirm a printer’s compatibility, check its documentation.
AC adapter
Power cable

9
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Connecting a USB printer
To achieve the connection, you need a suitable USB cable, which may
come with your printer. Otherwise, you can purchase one from a computer
or electronics store.
NOTE: Follow the manufacturer’s instructions for connecting a USB printer to your
computer.
Connecting a parallel printer
To achieve the connection, you need a suitable cable, which may come
with your parallel printer. Otherwise, you can purchase one from a
computer or electronics store.
If you connect a parallel printer, do so before you turn on the computer.
NOTE: Follow the manufacturer’s instructions for connecting a parallel printer to your
computer.
Installing additional memory (optional)
CAUTION: Before you install or remove a memory module, turn off the computer using
the Start menu. If you install or remove a memory module while the computer is in
Standby or Hibernation mode, data will be lost.
Your computer comes with enough memory to run most of today’s popular
applications. You may want to increase the computer’s memory if you use
complex software or process large amounts of data.
There are two memory slots. Your system may have both slots occupied.
CAUTION: If you use the computer for a long time, the memory modules will become
hot. If this happens, let the modules cool to room temperature before you replace them.
CAUTION: Do not try to install a memory module under the following conditions. You
can damage the computer and the module.
1. The computer is turned on.
2. The computer was shut down using Standby mode.
3. Power to the DVD-ROM or multi-function drive has been turned on.
CAUTION: Do not install or remove a memory module while the DVD-ROM or multi-
function drive power is on.

10 Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
1If the computer is on, turn it off.
See “Turn Off or Shut down command” in your electronic user’s
guide.
2Unplug and remove any cables connected to the computer.
3Close the display panel and turn the computer upside down.
Underside of the computer
NOTE: Use a point size 0 Phillips screwdriver.
4Locate the expansion memory slot cover and remove the screw that
secures the cover.
Removing the expansion memory slot cover screw
5Using your finger or a narrow object, lift off the cover.
6Put the screw and the cover in a safe place so that you can retrieve
them later.
CAUTION: Static electricity can damage the memory module. Before you handle the
module, touch a grounded metal surface to discharge any static electricity you may
have built up.
To avoid damaging the memory module, be careful not to touch its gold connector bar
(on the side you insert into the computer).
7Remove the new memory module from its antistatic packaging.
8Holding the memory module by its edges so that the gold connector
bar faces the slot, fit the module into the slot at a slight angle.
Expansion memory slot cover

11
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
9Gently press down on the memory module connector until the clips
snap into place.
Do not force the module into position. The memory module should be
level when secured in place.
Inserting the memory module
CAUTION: Avoid touching the connectors on the memory module or on the computer.
Grease or dust on the connectors may cause memory access problems.
10 Replace the memory slot cover.
11 Replace the screw and tighten them.
12 Turn the computer over and reconnect any cables you removed.
You can now continue setting up the computer. When the operating system
has loaded, you can verify that the computer has recognized the additional
memory.
If you are adding extra memory after setting up the computer, verify that
the computer has recognized it correctly as described in “Checking total
memory.”
Removing a memory module
CAUTION: If you use the computer for a long time, the memory modules will become
hot. If this happens, let the modules cool to room temperature before you replace them.
1Follow steps 1 through 6 in “Installing additional memory (optional)”
on page 9.
CAUTIONS: Do not try to remove a memory module with the computer turned on. You
can damage the computer and the device.
Do not remove the memory module while the computer is in Standby mode.
The computer could hang up the next time you turn it on and data in memory will be
lost. In either of the above cases, the Standby configuration will not be saved.
The following message appears when you turn on the power:
Warning: Resume Failure
Press Any Key To Continue
If the computer hangs up when you turn it on, perform the following: Press the power
button and hold it down for five seconds, then turn the power on again.

12 Inserting PC Cards
RG 5.375 x 8.375 ver 2.3.4
2Push the latches to the outside to release the module. A spring will
force one end of the module up.
Removing the memory module
3Gently pull the memory module out of the slot.
CAUTION: Avoid touching the connectors on the memory module or on the computer.
Grease or dust on the connectors may cause memory access problems.
4Complete the procedure by following steps 10 through 12 in
“Installing additional memory (optional)” on page 9.
Checking total memory
When you add or remove memory, you can check that the computer has
recognized the change. To do this:
1Click Start, Control Panel.
2Click Performance and Maintenance.
3Click System.
4The General tab view automatically appears and shows the
recognized memory.
5If the computer does not recognize the memory, turn off the computer,
remove the memory slot cover, and make sure the memory module is
seated properly, as described in steps 8 and 9 of “Installing additional
memory (optional)” on page 9.
Inserting PC Cards
Inserting a PC Card
1If your PC Card does not support hot swapping, save your data and
turn off the computer before inserting the PC Card. For more
information, see “Hot swapping” on page 13.
2Hold the PC Card with the arrow or main label side up and the
connector side toward the PC Card slot.

13
Removing PC Cards
RG 5.375 x 8.375 ver 2.3.4
3Align the card connectors with an available PC Card slot and carefully
slide the card into the slot until it locks into place.
NOTE: If you have a Type III card, insert the connector into the lower slot. If you have a
Type II card, you can insert it into either the upper or the lower slot.
CAUTION: To avoid damaging the PC Card or the computer, don’t force the card into
the PC Card slot.
Removing PC Cards
1Click the Safely Remove Hardware icon on the System tray.
2Click Safely remove xxxx, where xxxx is the identifier for your PC
Card.
The operating system advises you that you may safely remove the
card.
3Press the PC Card eject button next to the PC Card slot in use.
Ejecting a PC Card
4Remove the PC Card and store it properly.
Hot swapping
One of the great things about PC Cards is that you can replace one PC Card
with another while the computer is on. This is called “hot swapping.”
Hot swapping precautions
Although you can insert a PC Card at any time, to avoid data loss never
remove a card while it is in use. For example:
❖Never remove an ATA card while the system is accessing it.
❖Never remove a network card while you are connected to a network.
❖Never remove a SCSI card while any of the SCSI devices connected
to it are operating.
Before removing a PC Card, shut it down by clicking the Safely Remove
Hardware icon on the System tray. Once the PC Card has stopped, you can
safely remove it.

14 Learning the basics
RG 5.375 x 8.375 ver 2.3.4
Learning the basics
Computing tips
❖Save your work frequently.
Your work stays in the computer’s temporary memory until you save
it to the disk. You will lose all unsaved work, if, for example, a system
error occurs and you must restart your computer, or your battery runs
out of charge while you are working. Your computer can be
configured to warn you when the battery is running low.
HINT: Some programs have an automatic save feature that you can turn on. This feature
saves your file to the hard disk at preset intervals. See your software documentation for
details.
❖Back up your files to diskettes (or other removable storage media) on
a regular basis. Label the backup copies clearly and store them in a
safe place.
❖Scan all new files for viruses.
❖Never turn off the computer if a drive indicator light indicates a drive
is active.
NOTE: The Windows® XP operating system records information, such as your desktop
setup, during its shutdown procedure. If you don’t let the operating system shut down
normally, details such as new icon positions may be lost.
Using the TouchPad
The TouchPadTM, the touch-sensitive cutout in front of the keyboard,
enables you to move the cursor by brushing your finger on the surface in
the direction you’d like the cursor to move. To move the cursor to the top
of the screen, move your finger on the TouchPad away from you. To move
the cursor to the bottom, do the opposite.
For more information on the TouchPad, see the electronic user’s guide.
Primary and secondary control buttons
When you want to click or choose an item, use the TouchPad to move the
pointer/cursor to the item. Once the pointer/cursor is positioned, you can
click it into place by either double-tapping the TouchPad or clicking the
control buttons.
The control buttons are adjacent to the TouchPad and are used like the
buttons on a mouse. The primary control button is the left one and
corresponds to the left mouse button. To double-click, press the primary
button twice in rapid succession.
The function of the secondary button depends on the program you are
using. It usually corresponds to the right mouse button. Check your

15
Playing a CD or DVD
RG 5.375 x 8.375 ver 2.3.4
program’s documentation to find whether it uses the secondary mouse
button.
Playing a CD or DVD
Your computer has a DVD-ROM or multi-function drive that can read both
DVD-ROM and CD-ROM discs.
Digital versatile discs (DVDs) provide a significant increase in data storage
and support features that are not available on any other video platform.
These features include wide-screen movies, multiple language tracks,
digital surround sound, multiple camera angles, and interactive menus. The
computer can play high-resolution video at up to 30 frames per second.
HINT: Your DVD-ROM or multi-function drive is designed to play region 1 (North
America) DVD-ROMs.
NOTE: For optimum DVD performance, it is recommended that you play DVDs while
running the computer on AC power.
You use CD-ROMs to load and run software, and to access reference
material such as catalogs, as well as listen to music.
A special feature allows you to play audio CDs even when the computer is
turned off. For more information, see “CD/DVD control buttons” in the
electronic user’s guide.
Drive components and control buttons
The DVD-ROM or multi-function drive is on the side of the computer. The
CD/DVD control buttons are located at the front edge of the computer and
can be accessed when the display panel is closed or open.
Components
Sample DVD-ROM or multi-function drive shown
Use the eject button to release the disc tray. This button requires power.
CAUTION: Never press the eject button or turn off the computer while the Disk/disc
activity light is flashing. Doing so could damage the disc or the drive.
The manual eject button allows you to manually open the disc tray when
power to the computer and the drive is off.
Eject button
Manual eject button

16 Playing a CD or DVD
RG 5.375 x 8.375 ver 2.3.4
CAUTION: Never use a pencil to press the manual eject button. Pencil lead can break
off inside the computer and damage it. Instead, use a slim object such as a
straightened paper clip.
Inserting a disc
WARNING: Before playing an audio CD or a DVD, turn down the volume. Playing the
disc at maximum volume could damage your ears. To turn down the volume, use the
volume control dial or access the Volume Control program (click Start, All
Programs, Accessories, Entertainment, Volume Control).
1If the computer is turned on, press the eject button on the DVD-ROM
or multi-function drive.
Pressing the eject button
The disc tray partially opens.
CAUTION: To avoid damaging a disc or losing data, check that the Disk/disc activity
light is off before opening the disc tray.
2Grasp the disc tray and pull it fully open.
3Hold the disc by its edges and check that it is clean and free of dust.
CAUTION: Handle discs carefully. Avoid touching the surface of the disc. Grasp it by its
center hole and edge. If you handle the disc incorrectly, you could lose data.
4Carefully place the disc in the empty tray with its label facing up.
Inserting a disc
CAUTION: Be careful not to touch the drive’s lens (located underneath the drive’s
spindle) or the area around it. Doing so could cause the drive to malfunction.
5Gently press the center of the disc onto the spindle until it locks.

17
Moving the computer
RG 5.375 x 8.375 ver 2.3.4
CAUTION: Make sure the disc is properly positioned on the spindle. If you position the
disc incorrectly, it can jam the disc tray.
6Close the disc tray by pressing gently on the center of the tray until it
clicks, indicating that it is locked.
Removing a disc with the computer on
CAUTION: Never press the eject button while the computer is accessing the drive. Wait
for the Disk/disc activity light on the system indicator panel to turn off before opening
the disc tray.
1Locate and press the eject button.
The disc tray partially opens.
2Grasp the sides of the disc tray and pull it fully open.
3Remove the disc from the disc tray and place it in its protective cover.
CAUTION: If the disc is spinning when you open the disc tray, wait for the disc to stop
before removing it.
4Close the disc tray by pressing gently on the center of the tray until it
clicks indicating that it is locked.
Removing a disc with the computer off
1Insert a slender object, such as a straightened paper clip, into the
manual eject button access hole.
CAUTION: Never use a pencil to press the manual eject button. Pencil lead can break
off inside the computer and damage it.
2Pull the tray fully open, remove the disc and place it in its protective
cover.
3Push the tray in to close the drive.
Moving the computer
Before moving your computer, even across the room, make sure all disk
activity has ended (the drive-in-use lights stop flashing) and all external
peripheral cables are disconnected.
CAUTION: Never pick up the computer by its display panel or by the back (where the
ports are located).

18 Mobile computing
RG 5.375 x 8.375 ver 2.3.4
Mobile computing
Running the computer on battery power
The computer contains a removable lithium ion (Li-ion) high-capacity
battery that provides power when you are away from an AC outlet. You can
recharge it many times.
To ensure that the battery maintains its maximum capacity, operate the
computer on battery power at least once a month until the battery is fully
discharged. Please see “Maximizing battery life” on page 21 for
procedures. If the computer is continuously operated on AC power, either
through an AC adapter or a docking station for an extended period, more
than a month, the battery may fail to retain a charge. It may not function
efficiently over the expected life of the battery and the battery light may not
indicate a low-battery condition.
Monitoring battery power
The battery light indicates the main battery’s current charge. It:
❖Glows green when the battery is fully charged
❖Glows amber while the battery is being charged
❖Does not glow if the external power source is disconnected or if the
battery is completely discharged
TECHNICAL NOTE: The computer drains the battery faster at low temperatures. Check
your remaining charge frequently if you are working in temperatures below 50 degrees
Fahrenheit.
The computer calculates the remaining battery charge based on your current rate of
power use and other factors such as the age of the battery.
Setting battery alarms
Your computer can be configured to warn you when the battery is running
low. For more information, see “Setting battery alarms” in the electronic
user’s guide.
Changing the main battery
When your battery power is running low, you have two options: connect
the computer to an AC power source or install a charged battery.
NOTE: If your battery discharges fully, your information will be lost. Be sure to save
your work often.

19
Mobile computing
RG 5.375 x 8.375 ver 2.3.4
CAUTION: When handling a battery, be careful not to drop it or short-circuit its
terminals. Also, do not drop, hit or otherwise impact the battery. Do not scratch or
break the casing and do not twist or bend the battery.
Do not remove the battery while the computer is in Standby mode. Data in memory will
be lost.
Removing the battery from the computer
1Save your work.
2Turn off the computer or place it in Hibernation mode according to the
instructions in “Using Hibernation” in the electronic user’s guide.
3Remove all cables connected to the computer.
4Close the display panel and turn the computer upside down.
Sliding the battery release latch
5Slide the battery release latch toward the front of the computer. Slide
the battery cover toward the edge of the computer until it won’t go any
further.
6Lift the cover straight up from the slot.
WARNING: If the battery is leaking or its case is cracked, put on protective gloves to
handle it, and discard it immediately following the advice in “Disposing of used
batteries safely” in the electronic user’s guide.
CAUTION: For environmental reasons, do not throw away a spent battery. Please return
spent batteries to your Toshiba dealer.
Removing the battery from the battery cover
1Position the battery cover with the battery facing up.
2Press the battery cover latches outward.

20 Mobile computing
RG 5.375 x 8.375 ver 2.3.4
Removing the battery from the battery cover
3Lift the battery from the battery cover.
Inserting a charged battery
1Turn off the computer.
See “Turn Off or Shut down command” in your electronic user’s
guide.
2Remove the battery.
See “Removing the battery from the computer” on page 19.
3Release the battery from the battery cover.
See “Removing the battery from the battery cover” on page 19.
4Wipe the battery terminals of the charged battery with a clean cloth to
ensure a good connection.
5Hold the battery so that the label is face down.
6Fit the battery in the battery cover, ensuring the battery connectors are
exposed. Make sure the battery is secured by the battery cover latches.
7Find the four side tabs on the battery cover and line them up with the
corresponding recessed areas along the sides of the empty battery slot.
When the tabs line up with the recessed areas, the battery cover will
slip comfortably into the battery slot.
8Once the battery cover has been inserted, slide the battery cover until
the side of the battery release latch matches the side of the computer.
9Slide the battery release latch toward the back of the computer. You
may need to press the cover in from the edge slightly to return the
latch to the closed position.
Inserting the battery cover
Tab
Battery cover latch
Battery cover latch
Tab
Battery release latch
