Satellite®A20/A25 Series
Resource Guide
Keep this guide in a convenient place to access important
information about your computer.
If you need assistance, contact the following:
InTouchCenter
Calling within the United States [phone]
Calling from outside the United States [phone]
Please fill in for your reference and future use:
Model name _______________________________________
Model number _______________________________________
Serial number ______________________________________

2Contents
RG 5.375 x 8.375 ver 2.3.4
Contents
Setting up your computer and getting started............................ 4
Your computer’s TFT display.................................................... 13
Inserting a PC Card.................................................................. 13
Removing a PC Card................................................................ 14
Using SD cards ........................................................................ 14
Learning the basics.................................................................. 15
Playing a CD or DVD ................................................................ 16
Moving the computer............................................................... 19
Mobile computing.................................................................... 19
Important information on your Satellite®computer’s
cooling fan ............................................................................... 24
If something goes wrong ......................................................... 24
If you need further assistance.................................................. 27
Power cable connectors........................................................... 28
Features and specifications...................................................... 28
Regulatory information ............................................................ 34
Index ........................................................................................54

3
RG 5.375 x 8.375 ver 2.3.4
Welcome to the world of powerful and portable multimedia computers!
With your new Toshiba notebook computer, your access to information can
accompany you wherever you go.
You will find that the Microsoft®Windows®XP operating system is
already installed on your computer. It offers exciting features and easy
Internet access.
This guide
This guide offers important information about your computer, including
solutions to the most common problems, and features and specifications.
For more detailed information, descriptions of other features and more
extensive troubleshooting guidelines, see the electronic user’s guide
preinstalled on your system. It is also available on the Web at
pcsupport.toshiba.com.
Safety icons
This guide contains safety instructions that must be observed in order to
avoid potential hazards that could result in personal injuries, damage to
your equipment, or loss of data. These safety cautions have been classified
according to the seriousness of the risk, and the icons highlight these
instructions as follows:
Danger indicates a hazardous situation, which will result in death, serious
personal injury, or substantial property damage if the safety instruction is
ignored.
Warning indicates a hazardous situation, which can result in death, serious
personal injury, or substantial property damage if the safety instruction is
ignored.
Caution indicates a hazardous situation, which will or can cause minor
personal injury or property damage if the safety instruction is ignored.
Provides you with important but not hazard-related information.
Other icons used
Additional icons highlight other helpful or educational information:
TECHNICAL NOTE: This icon highlights technical information about the
computer.
DANGE
R

4Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
HINT: This icon denotes helpful hints and tips.
DEFINITION: This icon indicates the definition of a term used in the text.
Other documentation
Your computer comes with all or some of the following documentation in
addition to this resource guide:
❖Electronic user’s guide installed on your system.
❖Guides for other software that may come preinstalled.
❖Microsoft®Windows®XP operating system documentation.
❖For accessory information, visit Toshiba’s Web site at toshiba.com.
❖The Recovery Media containing the programs that are preinstalled at
the factory and any bundled software. Keep this media in a safe and
convenient place.
Setting up your computer and getting started
Strain and stress injuries are becoming more common as people spend
more time using their computers. With a little care and proper use of the
equipment, you can work comfortably throughout the day.
Using the computer keyboard incorrectly can result in discomfort and
possible injury. If your hands, wrists, and/or arms bother you while typing,
stop using the computer and rest. If the discomfort persists, consult a
physician.
For more information, consult books on ergonomics, repetitive-strain
injury, and repetitive-stress syndrome.
Placement of the computer
Proper placement of the computer and external devices is important to
avoid stress-related injuries. Consider the following when placing your
computer.
❖Place the computer on a flat surface at a comfortable height and
distance. You should be able to type without twisting your torso or
neck, and look at the screen without slouching.
❖If you are using an external monitor, the top of the display should be
no higher than eye level.
❖If you use a paper holder, set it at about the same height and distance
as the screen.

5
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Seating and posture
When using your computer, maintain good posture with your body relaxed
and your weight distributed evenly. Proper seating is a primary factor in
reducing work strain.
Precautions
Your notebook computer is designed to provide optimum safety and ease of
use, and to withstand the rigors of travel. You should observe certain
precautions to further reduce the risk of personal injury or damage to the
computer.
Never apply heavy pressure to the computer or subject it to sharp impacts.
Excessive pressure or impact can damage computer components or
otherwise cause your computer to malfunction.
Some PC Cards become hot with prolonged use. Overheating of a PC Card
can result in errors or instability in its operation.
Be careful when you remove a PC Card that has been used for lengthy
periods of time.
Connecting to a power source
Your computer requires power to operate. Use the power cable and AC
adapter to connect the computer to a live electrical outlet, or to charge the
computer’s battery.
Power Cable and AC adapter
Use only the AC adapter supplied with your computer or an equivalent
adapter that is compatible. Use of any incompatible adapter could damage
your computer. Toshiba assumes no liability for any damage caused by use
of an incompatible adapter.
When you connect the AC adapter to the computer, always follow the steps in
the exact order as described in the User's Manual. Connecting the power
cable to a live electrical outlet should be the last step otherwise the adapter
DC output plug could hold an electrical charge and cause an electrical shock
or minor bodily injury when touched. As a general safety precaution, avoid
touching any metal parts.
AC adapter
Power cable

6Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Hold the power cable by its plug when you connect/disconnect it. Do NOT
pull the cable itself. Doing so may damage the power cable and result in a
short circuit or electric shock.
The power cord on this product contains lead, a chemical known to
the State of California to cause birth defects or other reproductive
harm. Wash hands after handling.
To connect AC power to the computer:
1Connect the power cable to the AC adapter.
2Plug the AC adapter into the DC-IN on the back of the computer.
3Connect the power cable to a live electrical outlet.
If the electrical outlet is live, the system indicator panel’s AC power light
( ) glows green.
Damaged power cables can cause fire or electric shock. Never modify,
forcibly bend, place heavy objects on top of, or apply heat to the power
cable.
If the power cable becomes damaged or the plug overheats, discontinue use.
There is a risk of electric shock.
Never remove the power plug from the outlet with wet hands. Doing so may
cause an electric shock.
Connecting a printer
You can connect a USB-compatible printer to your computer through a
USB port. You can also connect a parallel printer through the parallel port.
To confirm a printer’s compatibility, check its documentation.
Connecting a USB printer
To achieve the connection, you need a suitable USB cable, which may
come with your printer. Otherwise, you can purchase one from a computer
or electronics store.
Follow the manufacturer’s instructions for connecting a USB printer to your
computer.
Connecting a parallel printer
To achieve the connection, you need a suitable cable, which may come with
your parallel printer. Otherwise, you can purchase one from a computer or
electronics store.
If you connect a parallel printer, do so before you turn on the computer.
DANGE
R
DANGE
R

7
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Follow the manufacturer’s instructions for connecting a parallel printer to
your computer.
Installing additional memory (optional)
Before you install or remove a memory module, turn off the computer using
the Start menu. If you install or remove a memory module while the
computer is in Standby or Hibernation mode, data will be lost.
A memory module must be installed in slot A. Do not try to operate the
computer with a memory module in slot B only.
Your computer is equipped with two memory slots which can provide for
various memory configurations. When additional memory is added, or
original memory replaced, it is recommended that you use only compatible
memory. In the event original memory is replaced with invalid memory, the
system will beep and will not start up beyond the BIOS memory check. A
message will display. If this occurs, contact Toshiba’s support center. See
“Toshiba voice contact” on page 27.
HINT: To purchase additional memory modules, visit the Toshiba Web site at
toshiba.com.
Your computer comes with enough memory to run most of today’s popular
applications. You may want to increase the computer’s memory if you use
complex software or process large amounts of data.
There are two memory slots. Your system may have both slots occupied.
If you use the computer for a long time, the memory modules will become
hot. If this happens, let the modules cool to room temperature before you
replace them.
Do not try to install a memory module under the following conditions. You
can damage the computer and the module.
1. The computer is turned on.
2. The computer was shut down using Standby mode.
3. Power to the DVD-ROM or multi-function drive has been turned on.
Do not install or remove a memory module while the DVD-ROM or multi-
function drive power is on.

8Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
You will need a standard Phillips No.1 screwdriver and a small flat head
screwdriver to install a memory module.
To avoid damaging the computer’s screws, use a standard Phillips
screwdriver that is in good condition.
1If the computer is on, turn it off.
See “Turn Off or Shut down command” in your electronic user’s
guide.
2Unplug and remove any cables connected to the computer.
3Open the display panel and remove the panel above the keyboard that
contains the power button.
When removing the computer’s power button panel to install additional
memory, be careful not to damage the display or circuit board.
Using a flat-head screwdriver to pry off the panel
You can pry the panel out of its position by using a flat-head
screwdriver. Starting at the left or right side, carefully wedge the flat-
head screwdriver between the panel and the surrounding housing.
Grasp the end of the panel and lift up until the panel comes free.
4Remove the three screws that hold the keyboard in place, and remove
the keyboard retaining brace.
Removing the left keyboard screw

9
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
The two-inch-long, propeller-shaped brace sits in the center of the
area exposed when the panel is removed.
Observe how the propeller-shaped keyboard retaining brace is positioned
before you remove it.
Store the brace with the screws for safekeeping.
Removing the right keyboard screw
5Lift the keyboard and gently place it face down on the palm rest of the
computer.
Lifting the keyboard
Removing the keyboard exposes the two memory slots, which are
covered by a plastic sheet.
Locating the covered memory module slots
Covered memory slots

10 Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
6Lift (but do not detach) the plastic sheet to expose the memory slots.
Lifting the plastic covering the memory slots
7Remove the new memory module from its antistatic packaging.
Static electricity can damage the memory module. Before you handle the
module, touch a grounded metal surface to discharge any static electricity
you may have built up.
To avoid damaging the memory module, be careful not to touch its pin
connector (on the side you insert into the computer).
Avoid touching the connectors on the memory module or on the computer.
Grease or dust on the connectors may cause memory access problems.
8Insert the memory module in a slot and gently press it down into
place.
Inserting the memory module
The clips on either side of the module will click to secure the module.
9Cover the slots with the plastic sheet.
10 Replace the keyboard.
To secure the keyboard, fit the tabs at the bottom of the keyboard into
the corresponding slots at the top of the computer’s palm rest.
11 Fasten the keyboard with the keyboard retaining brace and screws.

11
Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
12 Replace the panel above the keyboard by doing the following:
❖Fit the tabs at the bottom of the panel into corresponding slots at
the top of the keyboard.
❖Fit the tabs at the top of the panel into corresponding slots at the
base of the display and gently push down.
When the panel is properly positioned, it will snap down into place.
13 Reconnect any cables you removed.
14 Turn on the computer.
To verify that the computer correctly recognizes the memory, see
“Checking total memory” on page 12.
15 If the computer does not recognize the memory, shut down the
computer, remove the memory slot cover, and make sure the memory
module is seated properly, as described in step 8.
Removing a memory module
If you use the computer for a long time, the memory modules will become
hot. If this happens, let the modules cool to room temperature before you
replace them.
Do not try to remove a memory module with the computer turned on. You
can damage the computer and the device.
Do not remove the memory module while the computer is in Standby mode.
The computer could hang up the next time you turn it on and data in memory
will be lost. In either of the above cases, the Standby configuration will not
be saved.
The following message appears when you turn on the power:
Warning: Resume Failure
Press Any Key To Continue
If the computer hangs up when you turn it on, perform the following: Press
the power button and hold it down for five seconds, then turn the power on
again.
1Follow steps 1 through 6 in “Installing additional memory (optional)”
on page 7.
2Pull the clips away from the memory module.
The memory module pops partially out of the slot.

12 Setting up your computer and getting started
RG 5.375 x 8.375 ver 2.3.4
Pulling the clips away from the memory module
3Carefully remove the module from the slot.
Static electricity can damage the memory module. Before you handle the
module, touch a grounded metal surface to discharge any static electricity
you may have built up.
To avoid damaging the memory module, be careful not to touch its pin
connector (on the side you insert into the computer).
Avoid touching the connectors on the memory module or on the computer.
Grease or dust on the connectors may cause memory access problems.
Removing the memory module
4Complete the procedure by following steps 9 through 14 in “Installing
additional memory (optional)” on page 7.
Checking total memory
When you add or remove memory, you can check that the computer has
recognized the change. To do this:
1Click Start, Control Panel.
2Click Performance and Maintenance.

13
Your computer’s TFT display
RG 5.375 x 8.375 ver 2.3.4
3Click System.
4The General tab view automatically appears and shows the
recognized memory.
5If the computer does not recognize the memory, turn off the computer,
remove the memory slot cover, and make sure the memory module is
seated properly, as described in “Installing additional memory
(optional)” on page 7.
Your computer’s TFT display
Small bright dots may appear on your TFT display when you turn on your
computer. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology.
Any small bright dots that may appear on your display are an intrinsic
characteristic of the TFT manufacturing technology.
Inserting a PC Card
Use caution when lifting or turning your computer. Failure to do so may
result in damage to components, such as cables, attached to your computer,
or to the computer itself.
Before you insert a PC Card, refer to the documentation that comes with
the card to see if you need to do anything before you insert it.
1If your PC Card does not support hot swapping, save your data and
turn off the computer before inserting the PC Card. For more
information, see “Hot swapping a PC Card” on page 14.
2Hold the PC Card with the arrow or main label side up and the
connector side toward the PC Card slot.
3Align the card connectors with the PC Card slot and carefully slide the
card into the slot until it locks into place.
Inserting a PC Card
To avoid damaging the PC Card or the computer, do not force the card into
the PC Card slot.

14 Removing a PC Card
RG 5.375 x 8.375 ver 2.3.4
Removing a PC Card
1Click the Safely Remove Hardware icon on the System tray.
2Click Safely remove xxxx, where xxxx is the identifier for your PC
Card.
The operating system advises you that you may safely remove the
Card.
3Press the PC Card eject button next to the PC Card slot to extend the
button.
Ejecting the PC Card
4Press the extended eject button so the PC Card pops out slightly.
5Remove the PC Card and store it properly.
Hot swapping a PC Card
One of the great things about PC Cards is that you can replace one PC Card
with another while the computer is on. This is called “hot swapping.”
Hot swapping precautions
Although you can insert a PC Card at any time, to avoid data loss never
remove a card while it is in use. For example:
❖Never remove an ATA card while the system is accessing it.
❖Never remove a network card while you are connected to a network.
❖Never remove a SCSI card while any of the SCSI devices connected to
it are operating.
Before removing a PC Card, shut it down properly. See “Removing a PC
Card” on page 14.
Using SD cards
Your computer supports the use of SD (Secure Digital) memory/input/
output cards. The cards can be used with a variety of digital products:
digital music players, cellular phones, PDAs, digital cameras, digital video
camcorders, etc.

15
Learning the basics
RG 5.375 x 8.375 ver 2.3.4
Inserting an SD card
MMC cards (multimedia cards) do not work in this slot.
1Turn the card so that the metal contacts are face down.
2Push the card into the slot until it locks in place.
Inserting an SD card
Removing an SD card
1Click the Safely Remove Hardware icon on the System tray.
2Click Safely remove xxxx, where xxxx is the identifier for your SD
card.
3Press the card inward to release it.
The card pops out slightly.
4Lift the side of the computer where the card is located, grasp the card,
and pull it straight out.
Learning the basics
Computing tips
❖Save your work frequently.
Your work stays in the computer’s temporary memory until you save it
to the disk. You will lose all unsaved work, if, for example, a system
error occurs and you must restart your computer, or your battery runs
out of charge while you are working. Your computer can be
configured to warn you when the battery is running low.
HINT: Some programs have an automatic save feature that you can turn on.
This feature saves your file to the hard disk at preset intervals. See your
software documentation for details.
❖Back up your files to diskettes (or other removable storage media) on
a regular basis. Label the backup copies clearly and store them in a
safe place.

16 Playing a CD or DVD
RG 5.375 x 8.375 ver 2.3.4
❖Scan all new files for viruses.
❖Never turn off the computer if a drive indicator light indicates a drive
is active.
The Windows® XP operating system records information, such as your
desktop setup, during its shutdown procedure. If you do not let the operating
system shut down normally, details such as new icon positions may be lost.
Using the TouchPadTM
The TouchPad, the touch-sensitive cutout in front of the keyboard, enables
you to move the cursor by brushing your finger on the surface in the
direction you want the cursor to move. To move the cursor to the top of the
screen, move your finger on the TouchPad away from you. To move the
cursor to the bottom, do the opposite.
For more information on the TouchPad, see the electronic user’s guide.
Primary and secondary control buttons
When you want to click or choose an item, use the TouchPad to move the
pointer/cursor to the item. Once the pointer/cursor is positioned, you can
click it into place by either double-tapping the TouchPad or clicking the
control buttons.
The control buttons are adjacent to the TouchPad and are used like the
buttons on a mouse. The primary control button is the left one and
corresponds to the left mouse button. To double-click, press the primary
button twice in rapid succession.
The function of the secondary button depends on the program you are
using. It usually corresponds to the right mouse button. Check your
program’s documentation to find whether it uses the secondary mouse
button.
Playing a CD or DVD
Optical storage has become the preferred medium for software, music, and
video. Digital versatile discs (DVDs) provide a significant increase in data
storage and support features that are not available on any other video
platform. These features include wide-screen movies, multiple language
tracks, digital surround sound, multiple camera angles, and interactive
menus.
For these reasons, your computer may come with a DVD-ROM or
multi-function drive.
HINT: Your DVD-ROM or multi-function drive is designed to play region 1
(North America) DVD-ROMs.

17
Playing a CD or DVD
RG 5.375 x 8.375 ver 2.3.4
For optimum DVD performance, it is recommended that you play DVDs
while running the computer on AC power.
Drive components and control buttons
The DVD-ROM or multi-function drive is located on the side of the
computer. The CD/DVD control buttons are located at the front edge of the
computer and can be accessed when the display panel is closed or open.
Components
Sample DVD-ROM or multi-function drive shown
Use the eject button to release the disc tray. This button requires power to
operate.
Never press the eject button or turn off the computer while the disk/disc
activity light is flashing. Doing so could damage the disc or the drive.
The manual eject button allows you to manually open the disc tray when
power to the computer and the drive is off.
Never use a pencil to press the manual eject button. Pencil lead can break off
inside the computer and damage it. Instead, use a slim object such as a
straightened paper clip.
Inserting a disc
Before playing an audio CD or a DVD, turn down the volume. Playing the
disc at maximum volume could damage your ears. To turn down the volume,
use the volume control dial or access the Volume Control program (click
Start, All Programs, Accessories, Entertainment, Volu me
Control).
1If the computer is turned on, press the eject button on the DVD-ROM
or multi-function drive.
The disc tray partially opens.
To avoid damaging a disc or losing data, check that the Disk/disc activity
light is off before opening the disc tray.
Manual eject button
Eject button

18 Playing a CD or DVD
RG 5.375 x 8.375 ver 2.3.4
2Grasp the disc tray and pull it fully open.
3Hold the disc by its edges and check that it is clean and free of dust.
Handle discs carefully. Avoid touching the surface of the disc. Grasp it by its
center hole and edge. If you handle the disc incorrectly, you could lose data.
4Carefully place the disc in the empty tray with its label facing up.
Inserting a disc
Be careful not to touch the drive’s lens (located underneath the drive’s
spindle) or the area around it. Doing so could cause the drive to malfunction.
5Gently press the center of the disc onto the spindle until it locks.
Make sure the disc is properly positioned on the spindle. If you position the
disc incorrectly, it can jam the disc tray.
6Close the disc tray by pressing gently on the center of the tray until it
clicks, indicating that it is locked.
Removing a disc with the computer on
Never press the eject button while the computer is accessing the drive. Wait
for the disk/disc activity light on the system indicator panel to turn off before
opening the disc tray.
1Locate and press the eject button.
The disc tray partially opens.
2Grasp the sides of the disc tray and pull it fully open.
3Remove the disc from the disc tray and place it in its protective cover.
If the disc is spinning when you open the disc tray, wait for the disc to stop
before removing it.
4Close the disc tray by pressing gently on the center of the tray until it
clicks indicating that it is locked.

19
Moving the computer
RG 5.375 x 8.375 ver 2.3.4
Removing a disc with the computer off
1Insert a slender object, such as a straightened paper clip, into the
manual eject button access hole.
Never use a pencil to press the manual eject button. Pencil lead can break off
inside the computer and damage it.
2Pull the tray fully open, remove the disc and place it in its protective
cover.
3Close the disc tray by pressing gently on the center of the tray until it
clicks indicating it is locked.
Moving the computer
Before moving your computer, even across the room, make sure all disk
activity has ended (the drive-in-use lights stop flashing) and all external
peripheral cables are disconnected.
Never pick up the computer by its display panel or by the back (where the
ports are located).
Mobile computing
Running the computer on battery power
The computer contains a removable lithium ion (Li-ion) high-capacity
battery that provides power when you are away from an AC outlet. You can
recharge it many times.
To ensure that the battery maintains its maximum capacity, operate the
computer on battery power at least once a month until the battery is fully
discharged. Please see “Maximizing battery life” on page 23 for
procedures. If the computer is continuously operated on AC power, either
through an AC adapter or a docking station for an extended period (more
than a month), the battery may fail to retain a charge. It may not function
efficiently over the expected life of the battery and the battery light may not
indicate a low-battery condition.
Monitoring battery power
The battery light indicates the main battery’s current charge. It:
❖Glows green when the battery is fully charged
❖Glows amber while the battery is being charged

20 Mobile computing
RG 5.375 x 8.375 ver 2.3.4
❖Does not glow if the external power source is disconnected or if the
battery is completely discharged
TECHNICAL NOTE: The computer drains the battery faster at low
temperatures. Check your remaining charge frequently if you are working in
temperatures below 50 degrees Fahrenheit.
The computer calculates the remaining battery charge based on your current
rate of power use and other factors such as the age of the battery.
Setting battery alarms
Your computer can be configured to warn you when the battery is running
low. For more information, see “Setting battery alarms” in the electronic
user’s guide.
Changing the main battery
When your battery power is running low, you have two options: connect the
computer to an AC power source or install a charged battery.
If your battery discharges fully, your information will be lost. Be sure to save
your work often.
When handling a battery, be careful not to drop it or short-circuit its
terminals. Also, do not drop, hit or otherwise impact the battery. Do not
scratch or break the casing and do not twist or bend the battery.
Do not remove the battery while the computer is in Standby mode. Data in
memory will be lost.
Removing the battery from the computer
1Save your work.
2Turn off the computer via the Start menu.
See “Using Turn Off or Shut down” in your electronic user’s guide.
3Remove all cables connected to the computer.
4Close the display panel and turn the computer upside down.
5Move the battery lock lever toward the front of the computer in order
to move the battery release latch.
