Satellite A665-3DV12X Page 1 of 4

Satellite A665 Detailed Product Specification1

Model Name: A665-3DV12X Part Number: PSAW9U-01903T UPC: 883974782987

Operating System C1 2

Genuine Windows®7 Home Premium 64-bit

Processor3and Graphics4

Intel®Core™ i7-2630QM Processor

o2. 0 GHz (2.90 GHz with Turbo Boost Technology), 6MB Cache

Mobile Intel®HM65 Express Chipset

NVIDIA®GeForce®GT 540M with 1GB GDDR3 discrete graphics

memory

oTotal Available Graphics memory 4095MB

Memory5

Configured with 8GB DDR3 (max 8GB)

2 memory slots. Both slots occupied.

Storage Drive6

750GB (5400 RPM); Serial ATA hard disk drive

TOSHIBA Hard Drive Impact Sensor (3D sensor)

Fixed Optical Disk Drive7

Blu-ray Disc®Rewriteable (BD-RE) and DVD SuperMulti drive with

Labelflash®supporting 16 formats

oMaximum speed and compatibility: CD-ROM (24x), CD-R (24x),

CD-RW (24x), DVD-ROM (8x), DVD-R (8x), DVD-R DL (4x),

DVD-RW (6x), DVD+R (8x), DVD+R DL (4x), DVD+RW (8x),

DVD-RAM (5x), BD-ROM (6x),BD-R (6x),BD-R DL (4x),BD-RE

(4x), BD-RE DL (4x)

oSupports Labelflash®media to burn high quality labels directly on

the disc.

Display8

15.6” diagonal widescreen TruBrite® LCD display at 1366 x 768 native

resolution (HD)

o3D ready

o120 Hz

oNative support for 720p content

o16:9 aspect ratio

oLED backlit

oNVIDIA® 3D VISION™9kit which include

oNVIDIA® 3D VISION™ active shutter glasses

oIntegrated 3D Vision IR emitter

oUSB 2.0 type A to 5-pin mini-B cable

Sound

Built-in harman/kardon®stereo speakers

DOLBY®Advanced Audio™

Input Devices

Premium Raised Tile LED Backlit Keyboard with 10-Keypad (black)

TouchPad™ pointing device with multi-touch control

TouchPad™ Enable/Disable

Media Control Buttons:

oTOSHIBA eco utility™ (Energy-saving mode)

oMute

oMedia

oCD/DVD control buttons

oVolume up, volume down

Communications

Webcam and microphone

10/100/1000 Ethernet

Wi-Fi®Wireless networking (802.11b/g/n)10

Bluetooth®version 3.0 plus Enhanced Data Rate (EDR)

Expandability

Memory Card Reader

oSecure Digital, Secure Digital High Capacity, Memory Stick™,

Memory Stick PRO™, xD Picture Card, Mini SD Card, Multi

Media Card [shared slot may require adapter for use]

Ports

Video

oRGB

oHDMI-CEC (REGZA LINK™)

Audio

oMicrophone input port with Toshiba Sleep and Music11

oHeadphone output port

Data

o4 USB ports( (1 USB v3.0 port + 3 USB v2.0 ports (2

eSATA/USB combo with USB Sleep and Charge12))

oRJ-45 LAN port

Security

oSlot for security lock

Physical Description

Fusion®X2 Finish in Charcoal

Dimensions (W x D x H Front/H Rear): 14.98” x 10.0” x 1.18”/1.48”

without feet

Weight: Starting at 6.5 lbs. depending upon configuration13

Power

120W (19V 6.32A) 100-240V/50-60Hz AC Adapter.

oDimensions (W x H x D): 6.1” x 2.63” x 1.43”

oWeight: starting at 1.2 lbs.

Battery14

12 cell/98Wh Lithium Ion battery pack,

Battery Life Rating (measured by MobileMark™ Productivity 2007)15

Included 12 cell battery: 5 hours, 15 minutes

Software C1 16

Toshiba Software and Utilities

Bluetooth Stack for Windows by Toshiba

Bluetooth Monitor

HDMI Control Manager

TOSHIBA App PlaceSM

TOSHIBA Assist

TOSHIBA BookPlace™

TOSHIBA Bulletin Board

TOSHIBA Disc Creator

TOSHIBA DVD Player with Resolution+ Upconvert Technology17

TOSHIBA eco Utility™

TOSHIBA Face Recognition

TOSHIBA HDD/SSD Alert

TOSHIBA HW Setup Utility

TOSHIBA Laptop Checkup

TOSHIBA Media Controller18

TOSHIBA Password Utility

TOSHIBA PC Health Monitor

TOSHIBA Recovery Disc Creator

TOSHIBA ReelTime

TOSHIBA Service Station

TOSHIBA Sleep Utility

TOSHIBA Supervisor Password Utility

TOSHIBA Value Added Package

TOSHIBA Video Player

TOSHIBA Web Camera Application

Third-party Software

Adobe®Acrobat®Reader

Google®Toolbar

Google®Chrome

Internet Explorer 8

Intervideo WinDVD BD with 3D Blu-Ray Support

Microsoft®Office Starter 201020

Microsoft®Windows Media Player 12

Microsoft®Silverlight™

Microsoft®Live Essentials

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A665-3DV12X Page 2 of 4

Photo Gallery

Messenger

Mail

Writer

Movie Maker

Ulead/Corel DVD MovieFactory®for TOSHIBA

WildTangent®Games Console

Special Offers and Trial Software

NetZero®Internet Service

Norton Internet Security™ 2011 (30-day trial subscription)

Skype®

Toshiba Online Backup (30-day trial subscription)

Environmental Specifications

This product is RoHS21 compatible

Energy Star Qualified

EPEAT™ Gold Compliant

Operating Non-operating

Temperature

5° to 35° C -20° to 60° C

Thermal Gradient 15° C per hour (max) 20° C per hour

Relative Humidity

(non-condensing) 20% to 80% 10% to 90%

Altitude

(relative to sea level) 0 to 3,000 meters 0 to 10,000 meters

Shock 10G 60G

Vibration 0.5G 1.0G

1 YEAR STANDARD LIMITED WARRANTY23

Includes International Limited Warranty for obtaining service when

traveling outside the United States.

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

On-Site Repair, and ServiceExpress to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com.

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3677U-1M4G Toshiba 4GB DDR3-1066 memory module

Power

Part Number Description

PA3717U-1ACA Toshiba 120W Global AC Adapter

PA3818U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)

PA3819U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack (12

cell)

Expansion

Part Number Description

PA3778U-1PRP dynadock V USB Docking Station with DVI/VGA port

PA3575U-1PRP dynadock U USB Docking Station with DVI/VGA port

PA3686U-1SET dynadock Wireless U Docking Station with Wireless

USB Adapter

Storage

Part Number Description

PA3879U-1M4S Toshiba 4GB USB Micro Flash Drive

PA3879U-1M8S Toshiba 8GB USB Micro Flash Drive

PA3879U-1MAS Toshiba 16GB USB Micro Flash Drive

E05A050CAU2XK Toshiba 500GB USB 2.0 Port Hard Drive, Raven Black

E05A075PBU2XK Toshiba 750GB USB 2.0 Portable Hard Drive, Raven

Black

E05A100PBU3XW Toshiba 1TB USB 3.0 Portable Hard Drive, Black with

White accents

Bluetooth

Part Number Description

PA3847U-1ETB Toshiba Bluetooth Laser Mouse

Carrying Case

Part Number Description

PA1446U-1CS6 Toshiba 16" Envoy Ballistic Polyester Carrying Case

(Fits up to 16")

PA1452U-1BS6 Toshiba 16” Extreme Backpack, Blue (Fits up to 16”)

PA1504U-1CMS Toshiba 16” Extreme Messenger (Fits up to 16”)

Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Satellite and SystemGuard are registered trademarks of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. All other products and

names mentioned are the property of their respective owners.

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A665-3DV12X Page 3 of 4

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may

not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,

please visit Toshiba's Web site at pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice

2Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.

Certain Microsoft®software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are

approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your

computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical

Service and Support for more information.

4Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features

utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary

depending on system memory size and other factors.

5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system

memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a

64-bit operating system can address 4 GB or more of system memory.

6Storage Drive Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports

storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if

the computer includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual

formatted capacity may vary.

7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical

drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical

media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or

optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.

Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.

8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a

period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.

9NVIDIA® 3D Vision™. Some individuals may experience health-related complications when exposed to certain 3D images. Parents should monitor and/or supervise their

children’s use of 3D Vision™. If you or your child should experience any problem, immediately stop using 3D Vision™ and consult a physician. Carefully read safety instructions

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A665-3DV12X Page 4 of 4

included with the NVIDIA® 3D Vision™ kit and take the "User Vision Test" in the setup wizard before you or your child use 3D Vision™. If you see excessive flicker in your

peripheral vision, change the refresh rate of your display.

10 Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,

certain Wi-Fi® equipment.

11 Sleep & Music: In this mode, the headphone jack and mute functions are disabled. The volume and sound quality will diminish as the speakers not tuned in Windows®

mode. Use the volume control on your audio device to adjust sound. Audio line-in cable is not included

12 USB Sleep & Charge.The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn

the power of the computer ON to charge the device.

13 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

14 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark

Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. See “Detailed Specifications” for test used.

Details of MobileMark 2007 testing are available at www.bapco.com.Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any

individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features

utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and

configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the

specific test settings. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

15 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.

16 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft®software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy

protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION

PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software

products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).

Internet access is required to enable certain functionality of certain Microsoft products (including Microsoft Office Small Business Accounting 2006) which may be included with this

computer.

Includes Microsoft®Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite.

17 Resolution+™ Technology (Upconvert/Upconversion Technology). Viewing enhancements may vary depending upon content quality and display device

capability/functionality/settings. Depending on the quality of the content, some video noise may be visible.

18 Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.

19 Toshiba Video Player 3D Technology . Supported media types are Standard Definition DVD disks and selected video games listed at http://www.nvidia.com/object/3d-vision-

3d-games.html when used with compatible 3D glasses. 3D effect and image quality may vary depending upon content quality and display device capability/functionality/settings.

This technology does not currently support Blu-ray Disc™ (BD) format media.

20 Microsoft Office Starter 2010.Office Starter consists of reduced-functionality versions of Word and Excel with advertising. PowerPoint, Outlook, OneNote, Access and

Publisher are not included.

21 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements

and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

22 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when

operating within the recommended temperature range.
