Toshiba Satellite P200 Series User manual

Toshiba Personal Computer
Satellite P200/ P205
Maintenance Manual
TOSHIBA CORPORATION
[CONFIDENTIAL]

ii [CONFIDENTIAL] Satellite P200 / P205 Series Maintenance Manual
Copyright
© 2007 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual
cannot be reproduced in any form without the prior written permission of Toshiba. No patent
liability is assumed with respect to the use of the information contained herein.
Toshiba Personal Computer Satellite P200/ P205 Maintenance Manual
First edition Mar. 2007
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The
included set of instructions and descriptions are accurate at the time of this manual's production.
However, succeeding computers and manuals are subject to change without notice. Therefore,
Toshiba assumes no liability for damages incurred directly or indirectly from errors, omissions,
or discrepancies between any succeeding product and this manual.
Trademarks
IBM is a registered trademark, and OS/2 and PS/2 are trademarks of IBM Corporation.
Microsoft, MS-DOS, Windows, DirectSound and DirectMusic are registered trademarks of
Microsoft Corporation.
Intel and Pentium are registered trademarks, and SpeedStep is a trademark of Intel Corporation.
Sound Blaster is a registered trademark of Creative Technology Ltd.
Centronics is a registered trademark of Centronics Data Computer Corporation.
Photo CD is a trademark of Eastman Kodak.
All other properties are trademarks or registered trademarks of their respective holders.

Satellite P200 / P205 Series Maintenance Manual [CONFIDENTIAL] iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer Satellite P200/205, referred to as the P200 Series in this manual.
The procedures described in this manual are intended to help service technicians isolate faulty
Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your attention.
Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety precautions
are adhered to strictly.
Be sure to fasten screws securely with the right screwdriver. If a screw is not fully
fastened, it could come loose, creating a danger of a short circuit, which could cause
overheating, smoke or fire.
If you replace the battery pack or RTC battery, be sure to use only the same model battery
or an equivalent battery recommended by Toshiba. Installation of the wrong battery can
cause the battery to explode.

iv [CONFIDENTIAL] Satellite P200 / P205 Series Maintenance Manual
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the P200 Series system unit and each FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU
problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
Handling the LCD module
Board layout
Pin assignments
Keyboard scan/character codes
Key layout
Screw torque list
Reliability
Conventions
This manual uses the following formats to describe, identify, and highlight terms and operating
procedures.
Acronyms
On the first appearance and whenever necessary for clarification, acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on the
keyboard is printed in boldface type.

Satellite P200 / P205 Series Maintenance Manual [CONFIDENTIAL] v
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If three
keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the computer that appears on its display is presented in the typeface below:
Format complete
System transferred

vi [CONFIDENTIAL] Satellite P200 / P205 Series Maintenance Manual
Table of Contents
Chapter 1 Hardware Overview
1.1 Features .........................................................................................................................1-1.
1.2 System Unit...................................................................................................................1-5
1.3 2.5-inch Hard Disk Drive..............................................................................................1-6
1.4 Optical Disc Devices.....................................................................................................1-8
1.4.1 DVD-ROM & CD-RW....................................................................................1-8
1.4.2 DVD Super Multi Double Layer.....................................................................1-9
1.5 Power Supply ................................................................................................................1-10
1.6 Batteries.........................................................................................................................1-12
1.6.1 Main Battery...................................................................................................1-13
1.6.2 RTC battery.....................................................................................................1-14
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting Introduction.........................................................................................2-3
2.2 Troubleshooting Flowchart .............................................................................................2-4
2.3 Power Supply Troubleshooting.......................................................................................2-9
2.4 Display Troubleshooting................................................................................................2-14
2.5 Keyboard Troubleshooting.............................................................................................2-17
2.6 External USB Devices Troubleshooting ........................................................................2-19
2.7 TV-Out Failure Troubleshooting ...................................................................................2-21
2.8 TouchPad Troubleshooting ............................................................................................2-23
2.9 Speaker Troubleshooting................................................................................................2-25

Satellite P200 / P205 Series Maintenance Manual [CONFIDENTIAL] vii
2.10 Optical drive troubleshooting.................................................................................... 2-27
2.11 Modem Troubleshooting.............................................................................................2-30
2.12 Express card Troubleshooting ....................................................................................2-32
2.13 IEEE 1394 Troubleshooting .......................................................................................2-34
2.14 Wireless LAN Troubleshooting..................................................................................2-36
2.15 Finger printer troubleshooting....................................................................................2-38
2.16 Bluetooth Troubleshooting…………………...…………………………….……….. 2-40
2.17 4 in 1 card Troubleshooting……………………………………………………..……2-42
2.18 1st HDD Troubleshooting…………..……………………………………………….. 2-44
2.19 2nd HDD Troubleshooting………………………………………………….……….. 2-46
2.20 Camera Troubleshooting…………………………………………………………….. 2-48
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test........................................................................................................3-3
3.2 Executing the Diagnostic Test........................................................................................3-4
3.3 Display Configuration ....................................................................................................3-8
3.4 Speaker Audio Test.........................................................................................................3-9
3.5 Fan ON/OFF Test ..........................................................................................................3-10
3.6 Main Battery Charge Test..............................................................................................3-11
3.7 FDD Test........................................................................................................................3-12
3.8 ODD Test.......................................................................................................................3-13
3.9 Keyboard Test................................................................................................................3-14
3.10 Mouse (Pad) Test...........................................................................................................3-15
3.11 LCD Pixels Mode Test ..................................................................................................3-17
3.12 Magnetic switch Test.....................................................................................................3-18
3.13 LAN Test .......................................................................................................................3-19
3.14 RTC Test........................................................................................................................3-23
3.15 Read 1394 GUID ...........................................................................................................3-24
3.16 Speaker EQ Check…………...………….…….….…………..……………....……......3-25
3.17 Button Test …………..……………………….………….….…………….….……….3-26
3.18 Fingerprint DOS Test ……………………....…………….….……………..….………3-27
3.19 Clear Fingerprint Registered…………………………….………………...…………...3-29

viii [CONFIDENTIAL] Satellite P200/ P205 Series Maintenance Manual
3.20 1st HDD Test...................................................................................................................3-30
3.21 2nd HDD Test………………………….………………………..…………….…….…..3-33
3.22 Front Edge Logo check ……………….………………………..…………….………..3-36
Chapter 4 Replacement Procedures
4.1 General ...........................................................................................................................4-1
4.2 Battery............................................................................................................................4-7
4.3 PC Card ..........................................................................................................................4-9
4.4 Memory Card ................................................................................................................4-11
4.5 HDD ...........................................................................................................................4-13
4.6 Expansion Memory .......................................................................................................4-18
4.7 Modem...........................................................................................................................4-21
4.8 Optical Drive Module....................................................................................................4-23
4.9 Optical Drive.................................................................................................................4-25
4.10 Keyboard.......................................................................................................................4-27
4.11 Display Assembly..........................................................................................................4-30
4.12 Function Button Board..................................................................................................4-34
4.13 Wireless LAN Unit........................................................................................................4-36
4.14 Bluetooth.......................................................................................................................4-38
4.15 Top Cover......................................................................................................................4-39
4.16 Touch Pad......................................................................................................................4-42
4.17 Fingerprint Module .......................................................................................................4-44
4.18 Speakers.........................................................................................................................4-46
4.19 Subwoofer Unit and USB Board...................................................................................4-48
4.20 System Fan....................................................................................................................4-51
4.21 VGA PCB......................................................................................................................4-53
4.22 System Board ................................................................................................................4-55
4.23 VGA Board....................................................................................................................4-57
4.24 Fan and CPU .................................................................................................................4-59
4.25 Display Mask.................................................................................................................4-63

Satellite P200 / P205 Series Maintenance Manual [CONFIDENTIAL] ix
4.26 FL Inverter Board .........................................................................................................4-65
4.27 LCD Module.................................................................................................................4-67
4.28 Camera and Microphone...............................................................................................4-70

x [CONFIDENTIAL] Satellite P200 / P205 Series Maintenance Manual
Appendices
Appendix A Handling the LCD Module..................................................................................A-1
Appendix B Board Layout.......................................................................................................B-1
Appendix C Pin Assignments..................................................................................................C-1
Appendix D Keyboard Scan/Character Codes.........................................................................D-1
Appendix E Key Layout.......................................................................................................... E-1
Appendix F Series Screw Torque List .................................................................................... F-1
Appendix G Reliability............................................................................................................G-1

[CONFIDENTIAL]
Chapter 1
Hardware Overview
1

1 Hardware Overview
1-ii [CONFIDENTIAL] Satellite P200/P205 Series Maintenance Manual

1 Hardware Overview
Satellite P200/P205 Series Maintenance Manual [CONFIDENTIAL] 1-iii
Chapter 1 Contents
1.1 Features......................................................................................................................1-1
1.2 System Unit................................................................................................................1-5
1.3 2.5-inch Hard Disk Drive...........................................................................................1-6
1.4 Optical Disc Devices..................................................................................................1-8
1.4.1 DVD-ROM & CD-RW ............................................................................... 1-8
1.4.2 DVD Super Multi Double Layer.................................................................1-9
1.5 Power Supply...........................................................................................................1-10
1.6 Batteries ...................................................................................................................1-12
1.6.1 Main Battery..............................................................................................1-13
1.6.2 RTC battery...............................................................................................1-14

1 Hardware Overview
1-iv [CONFIDENTIAL] Satellite P200/P205 Series Maintenance Manual
Figures
Figure 1-1 2.5-inch HDD................................................................................................ 1-6
Tables
Table 1-1 2.5-inch HDD specifications......................................................................... 1-6
Table 1-2 DVD-ROM & CD-RW drive specifications................................................. 1-8
Table 1-3 DVD Super Multi Double Layer drive specifications................................... 1-9
Table 1-5 Battery specifications.................................................................................. 1-12

1.1 Features 1 Hardware Overview
Satellite P200/P205 Series Maintenance Manual [CONFIDENTIAL] 1-1
1.1 Features
The Satellite P200/ P205 Series Personal Computer uses extensive Large Scale Integration
(LSI), and Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to
provide compact size, minimum weight and high reliability. This computer incorporates the
following features and benefits:
CPU
•Intel® CoreTM 2 Duo Processor
•Intel® CoreTM Duo Processor
•Intel® Celeron® M Processor
Chipset
•Mobile Intel® 945GM Express Chipset
•Mobile Intel® 945PM Express Chipset
•Mobile Intel® 943GML Express Chipset
Memory
•Two DDRII SO-DIMM, up to 4GB with Intel 945PM/GM Chipset or up to 2GB
with Intel 943GML Chipset
BIOS
•1024MB Flash ROM for system BIOS
•Suspend to RAM/Disk
•Password protection
–Power on password
–Supervisor password
–HDD password for WW
–No HDD password for JP
•Various hot key for system control
•Refreshable
•Complete ACPI 3.0 function
•SMBIOS V2.4
•Supports JSB memory Boot, USB Super Fetch, SD Super Fetch
Power
•Universal AC adapter, 90~264VAC, 47~63Hz.
Offers constant voltage 19V output source with 65W, 75W or 90W max
output power capacity
•6-cell Lithium Ion smart battery pack with 10.8V*4000mAh
•9-cell Lithium Ion smart battery pack with 10.8V*6000mAh
•Approximately 12 hours or longer charging time to 100% battery capacity with
system switched on

1 Hardware Overview 1.1 Features
1-2 [CONFIDENTIAL] Satellite P200/P205 Series Maintenance Manual
•Approximately 4 hours charge time to 100% battery capacity with system
switched off or suspend
•Approximately 1.5 days discharging time in Standby Mode for the 9-cell battery
and 1 day for the 6-cell battery
•Discharge time in shutdown mode is approximately 1 month
HDD
•9.5mm/12.5mm, 2.5” HDD support
•Serial ATA interface
•Single or Dual HDD support
•Up to 250GB per drive
VGA
•Intel® 945GM for Integrated Graphics
•Intel® 943GML for Integrated Graphics
•nVIDIA GeForce® Go 7600
Fixed Optical drives
•12.7mm height, DVD-ROM & CD-RW combo device
•12.7mm height, DVD Super Multi device
•12.7mm height, DVD Super-multi device with Label Flash
Optional devices
•Build-in antenna for wireless LAN module
•Build-in antenna for Bluetooth module
•MDC module
Keyboard
•The computer's keyboard has 104 US keys. There are five types of keys:
typewriter keys, keypad overlay, function keys, soft keys, and cursor control
keys.
Touch Pad with Two Buttons
•Left button
•Right button
I/O Ports
•Four USB (V2.0) ports
•One 6-in-1 push-push type flash card connector and dard reader
•One DDC2b compliant 15-pin VGA port , 15pins (RGB)
•Express card
•One RJ-11 jack for 56kbps V.92 modem
•One RJ-45 jack with LED indicator
•One Microphone jack

1.1 Features 1 Hardware Overview
Satellite P200/P205 Series Maintenance Manual [CONFIDENTIAL] 1-3
•One Headphone jack
•One IEEE 1394a port
•One S-Video port
•One DC-In jack
•Wireless Communication Switch and WLAN indicator
•Fingerprint authentication
•Built-in camera with microphone
•Digital/Rotary volume control
•Kensington lock
Express Card Slot
•TI 8402 card bus controller for the model with Bridge media slot
•With Shutter door
•No ZV-Port support
Wireless LAN module
•Dual-band built-in antenna for wireless LAN communication
•802.11g, a/g, and a/g/n for Intel 945GM/945PM/943GML Chipset
Excellent Power Management Function
•Standby mode, Suspend to RAM or Suspend to disk mode, using time out or hot
key
•HDD local standby mode by time out
•LCD local standby mode by time out
•Low battery alarm by beep
•Auto-backlight off when LCD cover closed
•Full ACPI 3.0B supported
•LCD auto-dim mode by time out
Switches
•Power button
•Two programmable launch buttons
•Four control buttons for CD playing
•Wireless communication switch
Security
•Fingerprint authentication
AC Adapter
•Universal AC adapter module
•Liteon, API & Delta 65W, 75W, 90W adapters
•Output voltage: 19Vdc
•Input Voltage/Frequency range: 90-264Vac, 47-63Hz

1 Hardware Overview 1.1 Features
1-4 [CONFIDENTIAL] Satellite P200/P205 Series Maintenance Manual
Display
•17” (16:10) TFT screen with a resolution of 1440 horizontal x 900 vertical
pixels, CSV VA, high brightness approximately 200nits, WXGA+
Multiple digital media card slot
•Supports xD, SD, miniSD, MS, MS Pro, and MMC
Universal Serial Bus (USB)
The computer has three Universal Serial Bus (USB) ports that comply with the USB
2.0 standard, which enable data transfer speeds more than 40 times faster than USB
1.1 (which this computer also supports.) The USB drives may be used to transfer data
at Low, Full, and high speeds.
Bluetooth module
Some computers in this series are equipped with Bluetooth functionality (Version 2.0
+ EDR) with antenna. Bluetooth is a short-range wireless technology used to create
PANs (Personal Area Networks) among your devices, and with other nearby devices
like mobile computers, mobile phones, and digital cameras.
OS
•Windows Vista Home Basic/ Home Premium (32/64 bit support)
•Windows Vista Business (32/64 support)
•Vista Premium Logo

1.2 System Unit 1 Hardware Overview
Satellite P200/P205 Series Maintenance Manual [CONFIDENTIAL] 1-5
1.2 System Unit
The system unit is composed of the following major components:
Processor (depending on the model you purchased)
•Intel® CoreTM 2 Duo Processor T7600/T7400/T7200/T5600/T5500
•Intel® CoreTM Duo Processor T2050/T2060/T2250
•Intel® Celeron® M Processor 530/520
System logic
•Mobile Intel® 945GM with ICH7M Chipset
•Mobile Intel® 945PM with ICH7M Chipset
•Mobile Intel® 943GML with ICH7M Chipset
Memory
•Two DDR-II 533/667MHz SO-DIMM
•Supports Dual channel
•Up to 2GB with 512MB/1GB module for Intel 945PM/945GM/943GML
Chipset
•Up to 4GB with 2GB module for Intel 945PM/945GM/943GML Chipset
Video RAM (Depending on the model you purchased)
•nVIDIA GeForce® Go 7600, up to 256MB VRAM (GDDR2)
Audio subsystem
•Realtek High Definition Audio Codec ALC861
−Microphone-in and headphone-out
−Volume control: Digital control, rotary type, without mute function
−Supports Microsoft Outlook Express audio

1 Hardware Overview 1.3 2.5-inch Hard Disk Drive
1.3 2.5-inch Hard Disk Drive
The internal HDD is a random access non-volatile storage device. It has a non-removable
2.5-inch magnetic disk and mini-Winchester type magnetic heads. The computer supports
hard drives up to 250 GB.
The HDD is shown in Figure 1-1. Specifications are listed in Table 1-1.
Figure 1-1 2.5-inch HDD
Items 40GB 60GB 80GB 100GB
Formatted
capacity (GB) 37.26 55.89 74.52 93.15
Logical Blocks
(LBA) 78,140,160 117,210,240 156,301,488 195,371,568
Rotational
speed (rpm) 5400 5400 5400 5400
Toshiba HDD
Buffer (MB) 8 8 8 8
Hitachi HDD
Buffer (MB) 8 8 8 8
Fujitsu HDD
Buffer (MB) 8 8 8 8
Bytes per sector 512 512 512 512
Table 1-1 2.5-inch HDD specifications
1-6 [CONFIDENTIAL] Satellite P200/P205 Series Maintenance Manual
