SATELLITE PRO 490XCDT SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS 490x.doc Rev. 14 02/07/00 st. Page 1 of 4
490XCDT: 4.0 billion bytes: PA1270U-T2C
490XCDT-NT: 4.0 billion bytes: PA1270U-T2N
PROCESSOR (All Models) Intel Mobile PentiumII266MHz (1.7v/1.8v/3.3v)
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE Yes: 512KB Integrated into CPU
Type of cache memory 1 Mbit Pipelined Burst Synchronous SRAM (3.3v)
Access Time 8 ns
Data Bus Width 64 bit
Data Bus Speed 66 MHz
SYSTEM ARCHITECTURE (All Models) Chipset Connecting Devices
PCI BUS (v.2.1): (32-bit, 33 MHz) Intel 440BX PC Card Slots, Expansion Bus, Modem DSP, FDD, HDD, CD-ROM
PCI66: (32-bit, 66 MHz)Intel 440BX Graphic Controller
ISA BUS: (16-bit, 8.3 Mhz) N/A BIOS, Sound chip, Keyboard controller
MEMORY: 64Mbit EDO DRAM, 3.3V (All Models)
Standard 32 MB
Maximum 160 MB
Speed 60ns
Hyper Page mode memory access Yes
Data/Address Bus width 64-bit/32-bit
Local Bus Clock Speed 66 MHz
BIOS (All Models) (512KB: 4Mbit FLASH EPROM)
Supported standards APM (v.1.2); VESA (v2.0); DPMS, DCC2, DMI, PCI , PnP 1.0a, ACPI (v.1.0)
DISPLAY (All Models)
Type TFT Active Matrix Color
Size 13.3” Diagonal (1,024 x 768 resolution)
Dot Pitch .3075mm x .3075mm
Contrast Ratio 100:1 (min)
VIDEO (All Models)
Memory: 8Mbit SGRAM, 3.3V 2 MB
Speed 83 MHz
Controller Chip S3 Virge MX 3D (= 86C260)
Data Bus Width 64-bit
PCI66 Bus Architecture w/burst mode Yes
Bus Clock Speed 66 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
DirectDraw, Direct3D, H/W Cursor Yes
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation Yes
Zoomed Video Port Support Yes
DirectMPEG Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Support Resolution Colors Support
Full Screen 1024 x 768 64K colors
Smaller Image 640 x 480 16.7M colors
Smaller Image 800 x 600 16.7M colors
Virtual Display Mode 1280 x 1024 256 colors
External Support Resolution Colors Support Vertical Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors colors 85Hz @ 64K color
800 x 600 16.7M colors colors 85Hz @ 64K color
1024 x 768 64K colors 60 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 64K color

SATELLITE PRO 490XCDT SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS 490x.doc Rev. 14 02/07/00 st. Page 2 of 4
490XCDT: 4.0 billion bytes: PA1270U-T2C
490XCDT-NT: 4.0 billion bytes: PA1270U-T2N
STORAGE (All Models)
Removable HDD (2.5” Enhanced IDE) 4.0 billion bytes (12msec read/14msec write)
Burst Data Transfer Rate Ultra DMA33 (33MB/sec) or PIO Mode 4 (14.0MB/sec)
SELECT BAY DEVICES (All Models)
Second Battery Optional: Part# PA2451UR (Includes battery adapter)
Battery Type Li-Ion (10.8V, 3400mAH)
Modular FDD (3.5” 1.44MB) Included/Swappable with CD-ROM
FDD Dimensions 4.57”L x 3.8”W x .59”H
FDD Weight Weight: .29 lbs
Simultaneous FDD & CD-ROM Support Yes: External FDD adapter included
FDD Adapter Dimensions 7.0”L x 5.5”W
FDD Adapter Weight .25 lbs
Modular HDD (2.5” Enhanced IDE) Optional/Swappable with FDD
Capacity 4.0 billion bytes (13msec)
Burst Data Transfer Rate Ultra DMA33 (33MB/sec) or PIO Mode 4 (14.0MB/sec)
Modular CD-ROM (12.7mm Slimline)
5.25” 20X Max. speed Installed/ For use in SelectBay only
Weight .70 lbs
Interface .ATAPI (Enhanced IDE)
Random Access Time 135 ms @ 20X Max speed
Average Sustained Transfer Rate 3420KB/sec @ 20X Max speed; 2394KB/sec @ 14X Average speed
Supported Disc formats Red Book, Yellow Book, CD-ROM XA, CD-I Bridge (Photo-CD)
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Extra), CD-RW
KEYBOARD (All Models)
84/86 keys, 3mm Travel Yes with Windows 95 key support
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device (All Models) AccuPoint
EXPANSION SLOTS (All Models)
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS (All Models)
One RJ-11 port for internal modem (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (ESP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
One External Floppy Drive port Yes
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
Microphone (3.5mm mini jack, stereo) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Noteworthy security lock port Yes

SATELLITE PRO 490XCDT SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS 490x.doc Rev. 14 02/07/00 st. Page 3 of 4
490XCDT: 4.0 billion bytes: PA1270U-T2C
490XCDT-NT: 4.0 billion bytes: PA1270U-T2N
INTERNAL MODEM (As Listed) K56Flex /14.4 Kbps Data/Fax/Voice modem
DAA support US/Canada and Euro/Australia
Data support (All models) Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.32, V.32bis, V.34, V.80
Error correction MNP 1-4
Data compression MNP 5, CCITT V.42 bis
Fax support (All models) Fax class 1
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Telephony Functions (Windows 95 only)
Standard software Ring Zero RingCentral telephony software
Supported Functions Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Incoming Call Discrimination, Caller ID; Video conferencing
NoteDock III

Port Replicator (Optional) Part# PA2717U
(2) Type III PCI/CardBus ready PC Card slots Yes: each slot supports one card
Supported Interfaces Serial, USB, parallel, PS/2 keyboard, PS/2 mouse, DC in, SVGA port,
lock slot , joystick/MIDI, audio line-in, line-out, headphone, microphone
POWER (All models)
Autosensing External AC Adapter Part # PA2450U
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3A (max)
Power Output (Watts) 45W
Battery Type: Li-Ion (15V, 4000mAH) Yes (one standard): Part# PA2487UR
Battery Life: (One battery/Two batteries) Full power: 2+ hrs./4 hrs. Low power: 2.5/5 hrs.
Recharge Time (Computer Off/On) 2-3 hrs.(Off) /4-10 hrs.(On) --- (per one battery pack)
MaxTimePower Management Yes
SOUND SYSTEM (All models)
Chipsets: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum Sampling Rate 48kHz
FM Synthesis support Yes
Full duplex function Yes
Sound formats supported: SoundBlaster Prov.3.01, .WAV, MIDI, Windows Sound System 2.0
3D Sound Support Yes
DirectSound/Direct3Dsound support Yes: with Windows 95 Game SDK driver from Microsoft
Built-in microphone (monoaural) Yes
Speaker system Two top-mounted stereo speakers (28mm, 8 Ω)
DIMENSIONS (All models) Dimensions Weight
Notebook (Weights include Battery: .88 lbs.) 11.95”W x 9.4”D x 2”H 7.2 lbs. w/FDD; 7.2 lbs. w/CD-ROM
AC Adapter 4.92”L x 2.48”W x 1.0”H .66 lbs.
Primary Battery (Standard) 6.87”L x 2.76”W x .73”H .88 lbs.
Select Bay Battery (Optional) 4.55”L x 4.06W x .66”H .78 lbs.
BUNDLED SOFTWARE (Windows 95 models)
Windows®95; Fn-esse, Microsoft Internet Explorer; Ring Central (modem software), Puma Intellisync97 (infrared software),
Yamaha Audio Rack; Intel Indeo Video; Direct X5 driver, Mediamatics Arcade Pak; America Online, CompuServe, AT&T WorldNet,
Online documentation, SystemSoft Cardworks 32-bit (on CD only)
CD’s Included: Windows95 Companion CD; Enhanced/Recovery CD
BUNDLED SOFTWARE (Windows NT models)
Windows NT 4.0; Service Pack 3.0; Yamaha OPL3-SA3 Audio Rack; Puma Intellisync 97; Microsoft Internet Explorer (3.02);
SystemSoft CardWorks 32-bit; Toshiba NT 4.0 Utilities; 490CDT User’s Guide and Discovery Center
CD’s Included: Windows NT 4.0 CD; Windows NT Service Pack 3.0

SATELLITE PRO 490XCDT SERIES Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1998 TAIS 490x.doc Rev. 14 02/07/00 st. Page 4 of 4
490CDT: 4.0 billion bytes: PA1269U-T2C
490CDT-NT: 4.0 billion bytes: PA1269U-T2N
SECURITY (All models) Hardware Lock slot, screen blank, keyboard lock
Password Power-on, Supervisor, & HDD password (both drives)
WARRANTY (All models) 3 YR Parts / 1 YR. Labor
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) -- --
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration: 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
