Toshiba Satellite Pro L670D User manual

Toshiba Personal Computer
Satellite & Satellite Pro
Maintenance Manual
TOSHIBA CORPORATION
[CONFIDENTIAL]

ii [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
Copyright
© 2009 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual
cannot be reproduced in any form without the prior written permission of Toshiba. No patent
liability is assumed with respect to the use of the information contained herein.
Toshiba Personal Computer Satellite & SatellitePro Maintenance Manual
First edition April. 2010
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The
included set of instructions and descriptions are accurate for the Satellite Series at the time of this
manual's production. However, succeeding computers and manuals are subject to change without
notice. Therefore, Toshiba assumes no liability for damages incurred directly or indirectly from
errors, omissions, or discrepancies between any succeeding product and this manual.
Trademarks
IBM is a registered trademark, and OS/2 and PS/2 are trademarks of IBM Corporation.
Microsoft, MS-DOS, Windows, DirectSound and DirectMusic are registered trademarks of
Microsoft Corporation.
Intel and Pentium are registered trademarks, and SpeedStep is a trademark of Intel Corporation.
Sound Blaster is a registered trademark of Creative Technology Ltd.
Centronics is a registered trademark of Centronics Data Computer Corporation.
Photo CD is a trademark of Eastman Kodak.
All other properties are trademarks or registered trademarks of their respective holders.

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the Toshiba
Personal Computer Satellite, referred to as the Satellite Series in this manual.
The procedures described in this manual are intended to help service technicians isolate faulty
Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your attention.
Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service technicians
and authorized dealers or service providers to ensure the following safety precautions are adhered
to strictly.
Be sure to fasten screws securely with the right screwdriver. If a screw is not fully fastened, it
could come loose, creating a danger of a short circuit, which could cause overheating,
smoke or fire.
If you replace the battery pack or RTC battery, be sure to use only the same model battery or
an equivalent battery recommended by Toshiba. Installation of the wrong battery can
cause the battery to explode.

iv [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the Satellite Series system unit and each
FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU
problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
Handling the LCD module
Board layout
Pin assignments
Keyboard scan/character codes
Key layout
Screw torque list
Reliability
Conventions
This manual uses the following formats to describe, identify, and highlight terms and operating
procedures.
Acronyms
On the first appearance and whenever necessary for clarification, acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on the
keyboard is printed in boldface type.
Key operation

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] v
Some operations require you to simultaneously use two or more keys. We identify such operations
by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause (Break) means
you must hold down Ctrl and at the same time press Pause (Break). If three keys are used, hold
down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the computer that appears on its display is presented in the typeface below:
Format complete
System transferred

vi [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
Table of Contents
Chapter 1 Hardware Overview
1.1 Features.............................................................................................................................1-1
1.2 2.5-inch HDD .................................................................................................................1-10
1.3 DVD Super Multi (+-R Double Layer) ..........................................................................1-11
1.4 BD-Writer and BD-Combo drives……………………………………………………..1-12
1.5 Power Supply..................................................................................................................1-13
1.6 Batteries..........................................................................................................................1-15
1.6.1 Main Battery.....................................................................................................1-15
1.6.2 Battery Charging Control.................................................................................1-15
1.6.3 RTC Battery......................................................................................................1-16
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting Introduction..............................................................................................3
2.2 Troubleshooting Flowchart..................................................................................................4
2.3 Power Supply Troubleshooting...........................................................................................9
2.4 Display Troubleshooting ...................................................................................................14
2.5 Keyboard Troubleshooting................................................................................................17
2.6 External USB Devices Troubleshooting............................................................................19
2.7 TouchPad Troubleshooting................................................................................................21
2.8 Speaker Troubleshooting...................................................................................................23
2.9 Optical Drive Troubleshooting..........................................................................................25
2.10 Modem Troubleshooting ..................................................................................................28
2.11 Wireless LAN Troubleshooting.........................................................................................30
2.12 Camera Troubleshooting ...................................................................................................32
2.13 Bluetooth Troubleshooting…………………...…………………………….……….. 34
2.14 Bridge Media slot Troubleshooting……………………………………………..…... 36

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] vii
2.15 HDD Troubleshooting………………………………………………………………..38
2.16 CRT failure Troubleshooting ……………………………………………………….. 40
2.17 HDMI Troubleshooting …………………………………………………………….. 42
2.18 MIC Troubleshooting ………………………………………………………………. 44
2.19 E-SATA Troubleshooting ………………………………………….……………….. 46
2.20 LAN Troubleshooting………………………………………………………………...48
Figures
Figure 2-1 Troubleshooting Flowchar(1/2)
………………………………………………Error! Bookmark not defined.
Figure 2-1 Troubleshooting Flowchart (2/2)
……………………………………………...Error! Bookmark not defined.
Figure 2-2 Power Supply Troubleshooting Process……………………………………….9
Figure 2-3 Display Troubleshooting Process ....................Error! Bookmark not defined.
Figure 2-4 Keyboard Troubleshooting Process.................................................................17
Figure 2-5 External USB Device Troubleshooting Process..............................................19
Figure 2-6 TouchPad Troubleshooting Process.................................................................21
Figure 2-7 Speaker Troubleshooting Process....................................................................23
Figure 2-8 Optical Drive Troubleshooting Process...........................................................25
Figure 2-9 Modem Troubleshooting Process………………………...…………………..28
Figure 2-10 Wireless LAN Troubleshooting Process………………………………...…...30
Figure 2-11 Camera Troubleshooting Process…………………………………………….32
Figure 2-12 Bluetooth Troubleshooting Process…..…………..………………….……….34
Figure 2-13 3 in 1 Card TroubleshootingProcess…………………………..…….………..36
Figure 2-14 HDD Troubleshooting Process…………………………….………………....38
Figure 2-15 CRT Failure Troubleshooting Process ………………………..……………...40
Figure 2-16 HDMI Troubleshooting Process …………………………………………......42
Figure 2-17 MIC Troubleshooting Process ………………………….……………….…...44
Figure 2-18 E-SATA Troubleshooting Process ……………………...….………………...46
Figure 2-19 LAN Troubleshooting Process …………………...…….………………….....48

viii [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test...........................................................Error! Bookmark not defined.
3.2 Executing the Diagnostic Test...........................................Error! Bookmark not defined.
3.3 Display Configuration .......................................................Error! Bookmark not defined.
3.4 Audio Sound Test ................................................................................................................8
3.5 Fan ON/OFF Test ..............................................................................................................11
3.6 Main Battery Charge Test..................................................................................................13
3.7 FDD Test........................................................................................................................…15
3.8 Memory Check ..................................................................................................................16
3.9 Keyboard Test....................................................................................................................19
3.10 Mouse (Pad) Test...............................................................................................................21
3.11 LCD Pixels Mode Test ......................................................................................................22
3.12 Magnetic Switch Test ........................................................................................................23
3.13 LAN Test ...........................................................................................................................25
3.14 RTC Test............................................................................................................................27
3.15 1st HDDTest ……………………………....……….…….……………....….……….......28
3.16 Read DMI Test………………...….………………….………………...…..……….….....31
3.17 Write DMI Test …………….…………………………..………....…....….………........32
3.18 EEPROM Setting ………………………..………………………………………….…...34
3.19 TOSHIBA Logo Setting…………………..…………………………………………...…..37
3.20 DYNABOOK Logo Setting..............................................................................................39
Chapter 4 Replacement Procedures
4.1 General...............................................................................Error! Bookmark not defined.
Safety Precautions..............................................................Error! Bookmark not defined.
Before You Begin ..............................................................Error! Bookmark not defined.
Disassembly Procedures.....................................................Error! Bookmark not defined.

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] ix
Assembly Procedures.........................................................Error! Bookmark not defined.
Tools and Equipment .........................................................Error! Bookmark not defined.
Screw Tightening Torque...................................................Error! Bookmark not defined.
Colors of Screw Shanks .....................................................Error! Bookmark not defined.
Symbols of Screws on the Laptop Body............................Error! Bookmark not defined.
Symbol examples ...............................................................Error! Bookmark not defined.
4.2 Battery................................................................................Error! Bookmark not defined.
Removing the Battery Pack................................................Error! Bookmark not defined.
Installing the Battery Pack.................................................Error! Bookmark not defined.
4.3 HDD...................................................................................Error! Bookmark not defined.
Removing the HDD............................................................Error! Bookmark not defined.
Installing the HDD.............................................................Error! Bookmark not defined.
4.4 Memory..............................................................................Error! Bookmark not defined.
Removing the Optional Memory........................................Error! Bookmark not defined.
Installing the Optional Memory.........................................Error! Bookmark not defined.
4.5 ODD...................................................................................Error! Bookmark not defined.
Removing the ODD............................................................Error! Bookmark not defined.
Installing the ODD.............................................................Error! Bookmark not defined.
Disassembling the ODD.....................................................Error! Bookmark not defined.
Assembling the ODD Drive...............................................Error! Bookmark not defined.
4.6 Keyboard Cover and Keyboard .........................................Error! Bookmark not defined.
Removing the Keyboard Cover and Keyboard..................Error! Bookmark not defined.
Installing the Keyboard Cover and Keyboard....................Error! Bookmark not defined.
4.7 Logic Upper Assembly......................................................Error! Bookmark not defined.
Removing the Logic Upper Assembly...............................Error! Bookmark not defined.
Installing the Logic Upper Assembly ................................Error! Bookmark not defined.
4.8 Touchpad FFC ...................................................................Error! Bookmark not defined.
Removing the Touchpad FFC............................................Error! Bookmark not defined.
Installing the Touchpad FFC..............................................Error! Bookmark not defined.
4.9 WLAN Card.......................................................................Error! Bookmark not defined.
Removing the WLAN Card................................................Error! Bookmark not defined.
Installing the WLAN card..................................................Error! Bookmark not defined.

x [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
4.10 Modem Card......................................................................Error! Bookmark not defined.
Removing the Modem Card...............................................Error! Bookmark not defined.
Installing the Modem Card.................................................Error! Bookmark not defined.
4.11 USB Board.........................................................................Error! Bookmark not defined.
Removing the Right USB Board on the Right Side...........Error! Bookmark not defined.
Installing the Right USB Board .........................................Error! Bookmark not defined.
4.12 ODD Board........................................................................Error! Bookmark not defined.
Removing the ODD Board.................................................Error! Bookmark not defined.
Installing the ODD switch board .......................................Error! Bookmark not defined.
4.13 Touchpad Button Board.....................................................Error! Bookmark not defined.
Removing the Touchpad Button Board..............................Error! Bookmark not defined.
Installing the touchpad button switch board......................Error! Bookmark not defined.
4.14 Power Board ......................................................................Error! Bookmark not defined.
Removing the Power Board...............................................Error! Bookmark not defined.
Installing the Power Board.................................................Error! Bookmark not defined.
4.15 Bluetooth Card...................................................................Error! Bookmark not defined.
Removing the Bluetooth card.............................................Error! Bookmark not defined.
Installing the Bluetooth card..............................................Error! Bookmark not defined.
4.16 Display Assembly..............................................................Error! Bookmark not defined.
Removing the Display Assembly.......................................Error! Bookmark not defined.
Installing the Display Assembly........................................Error! Bookmark not defined.
4.17 Thermal Fan.......................................................................Error! Bookmark not defined.
Removing the Thermal Fan................................................Error! Bookmark not defined.
Installing the Thermal Fan.................................................Error! Bookmark not defined.
4.18 Motherboard.......................................................................Error! Bookmark not defined.
Removing the Motherboard ...............................................Error! Bookmark not defined.
Installing the Motherboard.................................................Error! Bookmark not defined.
4.19 Speakers.............................................................................Error! Bookmark not defined.
Removing the Speakers......................................................Error! Bookmark not defined.
Installing the Speakers .......................................................Error! Bookmark not defined.
4.20 RJ11 Cable.........................................................................Error! Bookmark not defined.
Removing the RJ11 Cable..................................................Error! Bookmark not defined.

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] xi
Installing the RJ11 Cable...................................................Error! Bookmark not defined.
4.21 CPU and Thermal Module.................................................Error! Bookmark not defined.
Removing the CPU and Thermal Module..........................Error! Bookmark not defined.
Installing the CPU and Thermal Module...........................Error! Bookmark not defined.
4.22 LCD Bezel .........................................................................Error! Bookmark not defined.
Removing the LCD Bezel..................................................Error! Bookmark not defined.
Install the LCD bezel assembly according to the following procedures.Error! Bookmark
not defined.
4.23 LCD Module......................................................................Error! Bookmark not defined.
Removing the LCD Module...............................................Error! Bookmark not defined.
Installing the LCD Panel....................................................Error! Bookmark not defined.
4.24 Camera Module..................................................................Error! Bookmark not defined.
Removing the Camera Module ..........................................Error! Bookmark not defined.
Installing the Camera Module............................................Error! Bookmark not defined.
4.25 Antennas for WLAN..........................................................Error! Bookmark not defined.
Removing the Antennas for WLAN...................................Error! Bookmark not defined.
Installing the Antennas for WLAN....................................Error! Bookmark not defined.
Figures
Figure 4.1 Removing the Battery Pack....................................Error! Bookmark not defined.
Figure 4.2 Removing the logic lower door..............................Error! Bookmark not defined.
Figure 4.3 Removing the HDD from the HDD bay.................Error! Bookmark not defined.
Figure 4.4 Removing the HDD aluminum...............................Error! Bookmark not defined.
Figure 4.5 Installing the HDD aluminum................................Error! Bookmark not defined.
Figure 4.6 Installing the logic lower door................................Error! Bookmark not defined.
Figure 4.7 Removing the RAM from the connectors ..............Error! Bookmark not defined.
Figure 4.8 Removing the ODD................................................Error! Bookmark not defined.
Figure 4.9 Removing the ODD bracket from the ODD...........Error! Bookmark not defined.
Figure 4.10 Removing the keyboard cover..............................Error! Bookmark not defined.

xii [CONFIDENTIAL] Satellite L670D/L675D/ Pro L670D Series Maintenance Manual
Figure 4.11 Removing screws securing the keyboard.............Error! Bookmark not defined.
Figure 4.12 Removing the keyboard........................................Error! Bookmark not defined.
Figure 4.13 Removing twenty-one screws from the bottom of the laptopError! Bookmark not
defined.
Figure 4.14 Removing five screws and disconnecting one FFC from the motherboard. Error!
Bookmark not defined.
Figure 4.15 Removing the logic upper assembly from the laptopError! Bookmark not defined.
Figure 4.16 Removing the touchpad FFC................................Error! Bookmark not defined.
Figure 4.17 Removing the WLAN Card..................................Error! Bookmark not defined.
Figure 4.18 Removing two screws securing the modem card.Error! Bookmark not defined.
Figure 4.19 Disconnecting the cable from the modem card....Error! Bookmark not defined.
Figure 4.20 Disconnecting the FFC from the motherboard.....Error! Bookmark not defined.
Figure 4.21 Disconnecting the ODD board FFC.....................Error! Bookmark not defined.
Figure 4.22 Removing the touchpad button board ..................Error! Bookmark not defined.
Figure 4.23 Disconnecting the FFC from the motherboard.....Error! Bookmark not defined.
Figure 4.24 Removing the power board ..................................Error! Bookmark not defined.
Figure 4.25 Removing the Bluetooth card...............................Error! Bookmark not defined.
Figure 4.26 Disconnecting the Bluetooth cable.......................Error! Bookmark not defined.
Figure 4.27 Removing the display assembly...........................Error! Bookmark not defined.
Figure 4.28 Removing the thermal fan from the logic lower assembly Error! Bookmark not
defined.
Figure 4.29 Removing the motherboard from the logic lower assemblyError! Bookmark not
defined.
Figure 4.30 Removing the speakers.........................................Error! Bookmark not defined.
Figure 4.31 Pulling out the cable from the routing channel....Error! Bookmark not defined.
Figure 4.32 Removing the RJ11 connector .............................Error! Bookmark not defined.
Figure 4.33 Removing the Thermal Module spring screws.....Error! Bookmark not defined.
Figure 4.34 Removing the Thermal Module spring screws.....Error! Bookmark not defined.
Figure 4.35 Removing the CPU...............................................Error! Bookmark not defined.
Figure 4.36 Reapply the Shinetsu 7726 grease on the thermal module and remove any release
papers...............................................................Error! Bookmark not defined.
Figure 4.37 Removing the LCD Bezel ....................................Error! Bookmark not defined.
Figure 4.38 Prying up the LCD Bezel .....................................Error! Bookmark not defined.

Satellite L670D/L675D/ProL670D Series Maintenance Manual [CONFIDENTIAL] xiii
Figure 4.39 Removing the LCD Bezel ....................................Error! Bookmark not defined.
Figure 4.40 Removing the LCD Module from the LCD cover assemblyError! Bookmark not
defined.
Figure 4.41 Disconnect the camera module cable...................Error! Bookmark not defined.
Figure 4.42 Removing the LCD hinges...................................Error! Bookmark not defined.
Figure 4.43 Removing the LVDS cable from the LCD panel .Error! Bookmark not defined.
Figure 4.44 Installing the LCD hinges.....................................Error! Bookmark not defined.
Figure 4.45 Removing the Camera Module.............................Error! Bookmark not defined.
Figure 4.46 Removing the antennas from the LCD cover assembly..... Error! Bookmark not
defined.
Appendices
Appendix A Handling the LCD Module ....................................................................................A-1
Appendix B Board Layout .........................................................................................................B-1
Appendix C Pin Assignments.....................................................................................................C-1
Appendix D Keyboard Scan/Character Codes ...........................................................................D-1
Appendix E Key Layout.............................................................................................................E-1
Appendix F Series Screw Torque List....................................................................................... F-1
Appendix G Reliability...............................................................................................................G-1

1 Hardware Overview
[CONFIDENTIAL]Satellite L670D/L675D/Pro L670D Maintenance Manual
Chapter 1
Hardware Overview

1 Hardware Overview
Satellite L670D/L675D/Pro L670D Maintenance Manual [CONFIDENTIAL]
Chapter 1 Contents
1.1 Features ..................................................................................................................1-1
1.2 2.5-inch HDD.......................................................................................................1-10
1.3 DVD Super Multi (+-R Double Layer)................................................................1-11
1.4 BD-Writer and BD-Combo drives .......................................................................1-12
1.5 Power Supply .......................................................................................................1-13
1.6 Batteries................................................................................................................1-15
1.6.1 Main Battery.........................................................................................1-15
1.6.2 Battery Charging Control .....................................................................1-15
1.6.3 RTC Battery.......................................................................................... 1-16

1 Hardware Overview
[CONFIDENTIAL]Satellite L670D/L675D/Pro L670D Maintenance Manual
Figures
Figure 1-1A ID Parts Description Placement Part A..........................................................1-5
Figure 1-2 SATA HDD .................................................................................................1-10
Figure 1-3 DVD Super Multi Drive ..............................................................................1-11
Figure 1-4 BD-Writer or BD-Combo drive (depending on the model).........................1-12
Tables
Table 1-1 HDD Specifications.....................................................................................1-10
Table 1-2 DVD Super Multi Drive Specifications.......................................................1-11
Table 1-3 Blu-ray Disc Drive specifications................................................................1-12
Table 1-4 Quick/Normal Charging Time.....................................................................1-15

1.1 Features 1 Hardware Overview
Satellite L670D/L675D/Pro L670D Maintenance Manual [CONFIDENTIAL]
1.1 Features
The Toshiba Satellite L670D/Pro L670D is a full-size PC notebook equipped with a Dual Core
Processor, providing high-speed processing capabilities and advanced features. The computer
employs a lithium ion battery that allows it to be battery-operated for long periods of time. The
display uses 17.3-inch WXGA LCD panel. Many features can be Built To Order (BTO) to
customize the system for each user.
The computer has the following features:
Processor (BTO)
The computer is equipped with one of the following AMD processors:
AMD Danube Processor
Memory (BTO)
The computer has two SODIMM slots which come standard with 1GB/2GB/4GB, accepting
BTO for your memory requirements. It can incorporate up to 8 GB of main memory and
supports DDR3 at 1066MHz/800MHz.
Battery Pack
The computer is powered by one rechargeable and removable lithium ion battery pack. The
capacity can be 3-cell, 6-cell and 12-cell, depending on the model of the computer.
RTC Battery
The internal RTC battery backs up the Real Time Clock and calendar.
Hard Disk Drive (HDD) (BTO)
The computer accommodates a 9.5 mm HDD with the following storage capacities:
250/320/400/500/640 GB, S-ATA (5,400rpm)
500 GB, S-ATA (7,200rpm)

1 Hardware Overview 1.1 Features
[CONFIDENTIAL]Satellite L670D/L675D/Pro L670D Maintenance Manual
ODD (BTO)
12.7mm height DVD Super Multi drive supporting ±R Double Layer
12.7mm height DVD Super Multi drive supporting ±R Double Layer w/ Labelflash
12.7mm height BD-Combo drive
12.7mm height BD Writer drive
Display
The LCD display comes with the following:
17.3" W (16:9) HD+ (1600x900) LED CSV and Non-CSV Type.
Graphics (BTO)
AMD M880G Chipset for integrated graphics display
ATI Mobility RadeonTM HD5470/HD5650 (DDR3, 1GB)for external graphics support
(depending on model)
Keyboard
The computer is equipped with a Toshiba standard 360mm keyboard, which has A4 +
10key Genchaku Keyboard without stick-point. It is a Win7-compliant keyboard with
optional Windows keys and application keys.
Pointing Device
The integrated Wide Touch Pad and two control buttons in the palm rest allow control of
the on-screen pointer and support functions such as the scrolling of windows.
External Monitor Port
The analog VGA port provides support for VESA DDC2B compatible functions. A WDDM
driver is ready for Win7.
Universal Serial Bus (USB) Ports
The computer has two USB 2.0 ports along with one USB/eSATA combo port (see below).
It is supported to daisy-chain a maximum of 127 USB devices. The serial data transfer rate
is 480 Mbps or 12 Mbps and 1.5 Mbps. These ports support PnP installation and hot
plugging.

1.1 Features 1 Hardware Overview
Satellite L670D/L675D/Pro L670D Maintenance Manual [CONFIDENTIAL]
eSATA
The external SATA or eSATA port executes high-speed data transfer to external devices
and supports shielded cable lengths of up to 2 meters outside the PC. The port also provides
dual USB compatibility.
Bridge Media Slot
This slot allows you to insert SD/SDHC/SDXC memory card, miniSD/microSD Card,
Memory Stick (PRO), and MultiMediaCard. It supports high-speed SD, SDHC and SDXC.
This model does not support CF, SmartMedia cards, xD or Memory Stick Duo cards.
Sound system
The integrated sound system is composed of two Realtek Azalia internal speakers, an
internal microphone (BTO with internal camera), and standard Microphone-IN and
Headphone-OUT ports. Dolby® Advanced Audio function is also integrated in the system.
Internal Camera (BTO)
It supports 0.3M and 1.3M pixels with Auto Macro and comes with a blue LED indicator.
An internal microphone is BTO with the internal camera and includes echo cancellation.
The camera is not a rotation type.
Headphones/Line-out Jack
This jack connects digital speakers or stereo headphones (16 ohm minimum). When
connected to digital speakers or headphones, the internal speaker is automatically disabled.
Microphone/ Line-in Jack
A 3.5mm mini microphone jack enables connection of a three-conductor microphone for
monaural input and also enables the connection of a stereo device for audio input.
HDMI Out Port (BTO)
The HDMI out port can connect with a Type A connector HDMI cable. The HDMI out port
can send SD and HD video/audio signals.
