20W330DB
23W330DB
OWNER’S MANUAL
䍏噅刭㈰☲㍗㌳〦ㅄ䈦䕎䜭塘㜳しⴱ㝍䈲㈭⡁啔中十䴩⴨啋䑖䈭吩ⴱ〰㐸㘱㈦ㄳⴵ〱じ塘
ㄶ⁍慲琠㈰〷⁃畭愠ㄷ㨵㔺ㄱ

English-1-
Contents
SETTING UP
Safety Precautions –Somedo's and don'ts for youtobe aware of 2
Installation and important information 3
Theremotecontrol–anat-a-glanceguide 4
Connectingexternal equipment –aguide toconnectingequipment tothe backofthe television 5
SideConnectionsandcontrols –switchingonthetelevision, standby,using thesidecontrols,
headphonesocket, connectingequipment tothe sideof the television 7
Tuningthetelevision –digital tuning, programmesorting 8
Tuningthetelevision – digital tuning, autotuning, manual tuning 9
Tuningthetelevision –analoguetuning, programmesorting 10
Tuningthetelevision – manual tuning 11
Tuningthetelevision –APS,choosing alanguage 12
CONTROLSAND FEATURES
Analoguegeneralcontrols–selectingprogramme positions, time display 13
Stereoandbilingual transmissions –stereo/monoor duallanguage broadcasts 13
Childlock –disablingthebuttonson the television 13
Picture format 14
Analoguepicture controls –picturemode(contrast, brightness, sharpness, colour, hue) 15
colourtemperature,noisereduction, film mode
Analoguepicture controls –3D comb, blue background, PIP,PAP 16
Timers 17
Digitalprogrammeguideandon-screeninformation 18
Digitalparental controls –settingthepin, mode 19
Digitalsettings–favouriteprogrammes, locked programmes,encryptedprogrammes 20
Digitalsettings-countryandlanguage, audiolanguages 21
Digitalsettingscontinued–subtitles,audiooutput reset tv, common interface, local timesettings 22
Digitalsettingscontinued–version, autoupgradeandsearchfornewsoftware 23
Analoguesoundcontrols –volume, soundmute,equalizer, balance, headphone 24
Analoguesoundcontrols –headphone, AVL, effect, dynamicbass 25
Input selectionandAV connections–inputandoutput sockets for connectedequipment 26
PCMode 27
PCInput TypicalDisplayModes 28
TEXT SERVICES
Digitaltext services 29
Analoguetext 29
PROBLEMSOLVING
Questions andAnswers –answerstosome ofthemore commonqueries 30
Notes–for your ownrecords 32
INFORMATION
SpecificationsandAccessories –technicalinformationabout thetelevision,
suppliedaccessories
20W330DG 34
23W330DG 35
DECLARATIONS
20W330DG 36
23W330DG 37
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:451

English-2-
SafetyPrecautions
Thisequipment has been designed and manufactured tomeet internationalsafetystandards but, likeanyelectrical
equipment,caremustbetakentoobtainthebestresultsandforsafetyto beassured.Pleasereadthepointsbelowfor
yourown safety.Theyareof a generalnature, intendedtohelp withallelectronicconsumerproductsandsome points may
notapplyto thegoodsyouhavejust purchased.
Air Circulation
Leave morethan 10cmclearancearoundthetelevisionto
allowadequate ventilation.Thiswill prevent overheating
andpossible damageto thetelevision.Dustyplacesshould
alsobeavoided.
Heat Damage
Damagemayoccur ifthetelevisionisleftindirectsunlight
or nearaheater.Avoid places subject to extremelyhigh
temperaturesorhumidity,orlocationswhere thetempera-
tureislikelytofallbelow5°C(41°F).
Mains Supply
Thesetshouldbeoperatedonlyfrom a220-240VAC50Hz
outlet. DOensurethatthe televisionisnotstandingonthe
mainslead.DO NOT cutoffthe mainsplugfromthis
equipment, thisincorporatesaspecial Radio Interference
Filter,theremovalofwhich willimpair its performance.IF
IN DOUBT PLEASE CONSULTA COMPETENTELECTRI-
CIAN.
Do
DO readtheoperating instructions beforeyouattemptto
usetheequipment.
DO ensurethatallelectricalconnections(includingthemains
plug, extensionleadsandinterconnectionsbetweenpieces
ofequipment)areproperly madeandinaccordancewiththe
manufacturers’instructions. Switch offand withdrawthe
mainsplugbeforemakingorchangingconnections.
DO consultyourdealerifyouareeverindoubtaboutthe
installation,operation or safetyofyour equipment.
DO becarefulwithglasspanelsordoorsonequipment.
Donot
DON’T remove anyfixedcover as this mayexpose dan-
gerous voltages.
DON’T obstructtheventilationopenings oftheequipment
withitemssuchasnewspapers,tablecloths,curtains,etc.
Overheatingwill causedamage andshortenthelifeofthe
equipment.
DON’T allow electricalequipmenttobeexposedtodripping
orsplashingorobjectsfilledwithliquids,such asvases,to
beplacedontheequipment.
DON’T placehotobjectsornakedflamesources,suchas
lighted candles or nightlightson,or close to equipment.
Hightemperaturescanmeltplasticandleadtofires.
DON’T usemakeshiftstandsand NEVER fixlegs with
wood screws. Toensure complete safety,alwaysfitthe
manufacturers’ approved stand,bracket or legs with the
fixings provided according to theinstructions.
DON’T leaveequipmentswitchedonwhen itisunattended,
unless itisspecificallystatedthatitisdesigned forunat-
tended operation or has astandbymode. Switch offby
withdrawingtheplug,makesureyour familyknow how todo
this.Specialarrangementsmayneedtobemadeforpeople
withdisabilities.
DON’T continuetooperatetheequipmentifyouareinany
doubtaboutitworkingnormally,oritis damaged in anyway
-switchoff, withdraw the mainsplug and consult your
dealer.
WARNING-excessivesoundpressurefromearphonesor
headphonescancausehearingloss.
ABOVE ALL -NEVER let anyone, especiallychildren,
pushorhitthescreen,pushanythinginto holes,slots
or any other openings in the case.
NEVER guess ortake chances with electrical equip-
mentofany kind-itisbetter tobe safethansorry.
THEMAINSSOCKET OUTLETISUSED ASADISCON-
NECTING DEVICEAND THEREFORE SHOULDBE
READILYOPERABLE.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:452

English-3-
Locatethetelevisionaway fromdirectsunlightandstronglights;soft,
indirectlightingisrecommendedforcomfortableviewing. Usecurtains
orblindstopreventdirectsunlightfalling onthescreen.
Place onasturdy platform, the mounting surfaceshouldbe flat and
steady. It must thenbesecuredtothewallwithasturdytieusing
the clip on the back of the television, thiswillprevent itfrom
falling over.
Makesurethe television islocated in aposition where it cannot be
pushedorhitbyobjectsandthatsmallitems cannot beinsertedinto
slotsoropeningsinthecase.
Please take note
EXCLUSIONCLAUSE
Toshibashallundernocircumstancesbeliableforlossand/ordamagetotheproductcausedby:
i)fire;
ii)earthquake;
iii)accidentaldamage;
iv)intentionalmisuseof theproduct;
v)useofthe productinimproperconditions;
vi)lossand/ordamagecaused totheproduct whilstinthepossessionof athirdparty;
vii)any damage orlosscausedasaresultoftheowner’sfailureand/orneglecttofollowtheinstructionsset
outintheowner’smanual;
viii) anylossor damage caused directlyas aresult of misuseor malfunction ofthe productwhen used
simultaneouslywithassociatedequipment;
Furthermore,under no circumstancesshall Toshiba be liablefor anyconsequentiallossand/or damage
including but not limitedto thefollowing, loss of profit,interruption of business, the lossof recorded data
whethercaused duringnormaloperation ormisuseof theproduct.
Note: AToshibawallbracketorstand,whereavailable,mustbeused. If anonToshibawallbracketorstand
isusedthe products'BEAB approvalwillbecomevoidandtheequipmentisthenusedat theconsumersown
risk.
If stationary imagesgeneratedby text services,channelidentificationlogos,computerdisplays,videogames,onscreen
menus,etc.areleftonthe televisionscreenforanylengthoftime theycouldbecomeconspicuous,itisalwaysadvisable
toreduceboththe brightnessandcontrastsettings.
Installationand importantinformation
Where to install
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:453

English-4-
The remotecontrol
Simple at-a-glance reference ofyourremotecontrol.
Inserting batteries and effective range of the remote
Removethe back cover torevealthebatterycompartmentand makesurethe
batteriesareinsertedtherightwayround.Suitablebatterytypesforthisremoteare
AAA,IECR031.5V.
Donotcombine a used, oldbatterywith a newoneor mixbatterytypes.Remove dead
batteries immediatelytopreventacidfrom leaking intothe batterycompartment.
Disposeoftheminadesignated disposalarea.
Warning:Batteriesmustnotbeexposedtoexcessiveheatsuchassunshine,fireor
thelike.
The performance ofthe remotecontrolwilldeterioratebeyond adistanceof five
metresor outside an angle of 30 degrees from the centre of the television. Ifthe
operatingrangebecomesreducedthebatteriesmay needreplacing.
Whenusing a Toshiba VCR or DVD :
pressto PAUSE/STEP
pressto PLAY
pressto REWIND
pressto FAST FORWARD
pressto EJECT
pressto STOP
pressto SKIP-REWIND
pressto SKIP-FORWARD
MENU
GUIDE
EXIT
TEXT
Standby mode
To mute thesound
To return to the previous programme
.in TV mode
On-screen menus
To selectTV programme number
To select between analogue and digital TV,
or an external source
Picture format
To exit Menus
To alter the volume
To call uptext services in mode and
interactive services in mode.
analogue
digital
When using menus the direction buttons
move the cursor on the screen up,
selection
To change programme positions and
teletext pages
Select tocontrol your
Toshiba TV, DVD or VCR
To view ATV, DTV,PC and otherAV inputs
picture-in-picture (pip) orpicture-and-picture
(pap)modes.
To display the on-screendigital Programme Guide
To display on-screen information
Selectable picture mode
down, left or right. toconfirm your
OK
Whenin TVmode:
CT-8003
Still picture
Stereo /bilingual transmissions
SUBTITLE
SUBTITLE
Digital Subtitles
When using the ProgrammeGuide
BACK
Time displayin analogue mode
-2hours
+2hours
-24 hours
+24 hours
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:454

English-5-
Connectingexternal equipment
Beforeconnectinganyexternalequipment,disconnectfromthemainpower.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:455

English-6-
Aerialcables:
Connecttheaerialtothesocketontherear ofthetelevi-
sion. If you use adecoder and/or amedia recorder it is
essential that the aerial cableis connected through the
decoder and/or throughthe media recorderto the televi-
sion.
SCARTleads:
Connectthemediarecorder IN/OUT sockettothetelevi-
sion. Connectthe decoder TV socket tothe television.
Connect the media recorder SAT socket tothe decoder
MEDIA RECORDER socket.
BeforerunningAPS(AUTOPROGRAMMINGSYSTEM)put
yourdecoder andmediarecorderto Standby.
Awidevarietyofexternalequipmentcanbeconnectedto
the backof the television, therefore the relevant owners
manualsfor all additionalequipment must bereferredto.
NOTE: BecuseFAVCVBS andSVHSYarecon-
nected parallelly,the picture may blend if
thetwo peripheralsareused atthesame
time.Likewise, becauseSVHS Cand
SCARTIIRare connected parallelly,the
picture mayblendifthetwoperipherals are
used atthesame time. Thusthese twoare
not tobeusedatthesame time.
If connectingS-VIDEOequipment, setthe INPUT for
AV-4 S. See page27.
Ifthe television automaticallyswitchesover tomonitor
externalequipment,returntonormaltelevisionby pressing
thedesiredprogrammepositionbutton.Torecallexternal
equipment,press toselectbetween ATV/DTV,AV-1,
AV-2,AV-2S,AV-4,AV-4S, YPbPr,HDMI or PC RGB.
Connecting externalequipment continued,
Connecting thePCvia PCinput
• Power off both computer and TV before making anycon-
nections.
•ConnectthePCcableto thePCinputofyourTV andtothe
15-pin connector on the rear ofyour computer.
•Tighten the screws on the plugs untilthe connectorsare
fastened securely.
•Ifyou are using Windowsoperating system running on a
PCwithaMicrosoftPlug&Playcompatiblevideocard,your
system willselecttheappropriatetiming for your
monitor.No additional device driver is required.
• For PC sound, use stereo jack socket located at the right
side of the tuner.
High Definition
Your TV is capable of displaying High Definition pictures
from devicessuchasaHighDefinitionSatellite Receiver
orDVDPlayer.Thesedevicesmustbeconnectedviathe
HDMIsocketor YPbPr (Component)sockets.Thesesock-
etscanaccepteither720por 1080isignals.
PLEASE NOTE:Althoughthistelevisionisable toconnect
to HDMIequipment,itispossible that some equipment
maynotoperate correctly.HDMIcablesshouldbe less
than5m.
NOTE:It is recommended thatapproved HDMI
cables upto5mlong is used. If the unit has
DVI output, aspecialconversion cablefrom
DVI toHDMI willberequired.
HDMI,theHDMIlogo,andHighDefinitionMultiMediaInter-
facearetrade marks, orregistered trademarks of HDMI
licensing,LLC.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:456

English-7-
Connections and controls
Awidevarietyofexternalequipmentcanbeconnectedviathesocketslocatedonthesideofthetelevision. Whilstallthe
necessaryadjustmentsandcontrolsforthetelevision aremadeusingtheremote control,the buttonsonthetopofthe
televisionmay beusedforsomefunctions.
Switching on
Ifthe power-on lightisunlit,connect the plug of the
mainssocket-outletandtheredLED will light. Press the
STAND-BYbuttonofthetelevisiontoswitchthetelevi-
sionon.ThentheLEDwillturnGREEN.
Toputthe television intoStandby,press on the
remotecontrolorontheTV;thegreenactiveStandby
LED willappear(see“SoftwareUpgrade”section)next
tothe greenON LED for afew moments. The red
Standby LED will thenlight. To viewthetelevisionpress
again orany of thenumberbuttons.The picturemay
takeafewsecondstoappear.
Using the remote control
Pressthe MENU buttonontheremote controlto seethe
menus.
In TV modethe menuappears asagroupoficonseach
for amenu option. Pressthe Leftor Right button to
selectatopic.
TousetheoptionspresstheUpandDown buttonson
theremotecontroltomoveupanddownthroughthem
and OK,Leftor Right buttonstoselectthe required
choice. Followtheonscreen instructions.Thefunctions
ofeachmenu are described in detailthroughout the
manual.
Using the controls and connections
Usingthecontrolbuttons onthetop oftheTV:
• Toalter the volumepress+ —.
•Toaltertheprogrammepositionpress onthetop
of the TV.
• Press MENU and + —and to control the
menu options.
•Press MENU to finish.
WhenconnectingmonosoundequipmenttoAV-4 (FRONT-
AV),connecttheaudiooutputof theequipmenttotheLor
Rsocketonthetelevision, then press toselect
DualIforleftmonoorDualIIforrightmono.
ToselecttheInput,press until AV-4 ishighlightedin
SOURCE menuasdescribedon page26. Thetelevision
will automaticallysensethe type of signal.
Pleasealwaysrefer totheowner’s manualoftheequipment
tobeconnectedforfulldetails.
DIGITAL COAXIAL: ThedigitalTV(DTV)audiooutputis
alwayspresentevenwhenotherinput modesareselected.
LED
Red=Standby,
Green=On
LED
Green=Timer/
Active Standby
AV-4
HEADPHONE
AUDIOLINEOUT
DIGITAL
(COAXIAL)
S-VIDEO
OK
MENU
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:457

English-8-
Digital Tuning
Before switching on the television putyour decoder and media recorder to Standby if theyare connected and ensure the
aerial is connected to your television. Toset up the television use the buttons onthe remote control as detailed on page 4.
Connect themains plug andswitchtheTV intostandby
usingtherearPowerbutton.Pressanynumberedor
standby buttonontheremotecontrol,the LocalOp-
tions screenwillappear.Thisscreenwillappearthe
firsttime thatthetelevisionisswitched on andeach
timethetelevisionisreset.
LOCALOPTIONS
Selectyour Country byusing or buttons.Use
tomovedownthroughthelist.
Setyour Language and AudioLanguage outofthe
optionsavailable.
Youcanalsoset Subtitles OFF,aswellasspecifying
thesubtitlelanguage.
Whencompleted,press OK tostarttuning.
After auto-tuning hascompleted,you mayfind the
timeisnotcorrect.Inthiscase, you can adjust the
timeby using and buttonstohighlight Local
TimeSetting, and andbuttonstosetthecorrect
time.
TheAutotuningscreenwillappearandthetelevisionwill
starttosearchforavailablestations.
Theprogressbarwillmovealongtheline.
DTV AUTOTUNING
Youmustallow thetelevisiontocompletethesearch.
When thesearchiscompletetheAuto tuningscreenwill
displaythetotalnumberofservicesfound.
9
DTV AUTO TUNING
22
Use or to move through the list toselect a
programme thenpress OK toview.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:458

English-9-
Programme sorting
Thestationorder may bechanged,forinstanceifthe
pictureisunclear orthesignalisweak. Press MENU,
the SETUP MENU will appearonthescreen.
Use tomovedown throughthelistandhighlight
Programmes. Press OK.
SETUPMENU
TV Setup ENTER
LocalOptionsENTER
AutotuningENTER
Manual tuningENTER
Programmes ENTER
Watch TV
Back
Withthelistof stationsnowshowing use or to
highlightthestationyouwantto moveandpress .
Theselectedstationwillbemovedtotherightofthe
screen.
Use or to movethrough the list to your
preferred position.As youdosotheotherstations will
movetomakeroom.
Press tostoreyourmove.
Repeatas necessary,thenpress EXIT.
Digital programme sorting continued,
programmesorting ,auto tuning, manual tuning
Autotuning
Autotuning willcompletelyre-tunethetelevision.Allcur-
rentprogrammesortingandsettings,i.e.favouritesandlocked
programmes,willbelost.
Selectthe SETUPMENU anduse tohighlightthe
Autotuning. Press OK.
€
Ascreenwill appear warningthatprevious digital
programmesand settingswillbedeleted.
Press OK tocontinue withthe Autotuning.
WARNING
!Allprevioussettingswill bedeleted.
Continue?
YES
Select Cancel
The televisionwillstarttosearch forall available
stations.Youmustallowthetelevisiontocompletethe
search.When the searchiscompletethe Auto tuning
screenwilldisplaythetotal numberofservicesfound.
Manualtuning
Thefeature isavailableforservice engineers orcanbe
used for directchannel entryifthe multiplex channelis
known.
Select Manual Tuning from the SETUP MENU and
press OK.
Enterthemultiplex number usingthenumberbuttons.
Thetelevisionwillautomaticallysearchforthatmulti-
plex.
Whenthemultiplexisfoundanychannelsnotcurrently
ontheprogrammelistwillbeaddedandtheprogramme
informationat thetopofthescreenwillbeupdated.
Repeatasnecessary.Press EXIT tofinish. Note:
Press toselectbetweenATV/DTV.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:459

English-10-
Analogue Tuning and programme sorting
Before switching on the television putyour decoder and media recorder to Standby if theyare connected and ensure the
aerial is connected to your television. Toset up the television use the buttons on the remote controlas detailedon page 4.
WhenATV (AnalogueTV)isselectedforthefirsttime;
theA.P.S. screenwillappear.
Country
Language
Germany
Ok
Cancel
PLEASECHECKANTENNA CABLE
AUTOPROGRAMMINGSYSTEM
TXTLanguage
UsetheUporDown buttontohighlightthe Language
and Country items.PresstheLeftorRightbuttonto
adjustthehighlighteditem.Thenpress theREDorOK
buttontostarttuning.
•Thetelevisionwillstarttosearchfor availablestations.
UK
P03-C04
63.75MHz
6%
63.75MHz
Cancel
APS is running...
Youmustallow thetelevisiontocompletethesearch.
Whenthesearchiscompletethetelevisionwillautomati-
callyselect programme position1.Thismaynot beaclear
pictureorthesignalmaybeweak,sothestationordercan
bechanged using program table whichwillappearonthe
screen.
P02C 04
P03C 05
P04BBC1
P05CH4
P06BBC2
P07C 04
P08C 07
P09C 12
P10C 15
P11S 18
P12S 29
P13S 31
P14S 33
P15S 34
P16S 35
P17S 36
P18S 37
P19S 40
P20C 21
Name
Delete Insert
APS
P01BBC1
Program Table
With the list of stations nowshowing use the Up or
Down button tohighlightthestationyouwanttomove
andpressthe GREEN button.
UsetheUpor Down button tomovethroughthelistto
thepreferredposition,asyoudosotheotherstations
will moveto make room, thenpress the GREEN button
again.Theselectedstationwillbe movedtothenew
position.
Repeatasnecessary,thenpress EXIT.
If the television cannotbeconnectedtoamediare-
corder/decoderwithaSCART leadorifastationon
another system isrequired,a programme positioncan
bemanuallytunedin.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4510

English-11-
Manual tuning
Thetelevisioncanbetuned-inmanuallyusing INSTALL. Forexample:ifthetelevisioncannotbeconnectedtoamedia
recorder/decoderwithaSCARTleadortotune-inastationonanother System.
Manual tuning
Toallocate aprogrammeposition on the television for a
decoderandmediarecorder:turnthedecoder on,inserta
pre-recordedfilmintothemediarecorderandpressPLAY,
thenmanuallytune.
Press MENU andusingtheLeft orRightbutton select
INSTALLmenu.
UsingtheDownbuttonselect Program andkey inthe
programme positiontobetunedwiththenumberbut-
tons, we suggest Programme0 foramediarecorder.
INSTALL
ProgramTable
Program
Band
Channel
ColourSystem
1
UsetheDown button toselect Search thenpressthe
Leftor Rightbutton tosearch. Thetelevision willbegin
searchingforchannels.
Eachsignalwillshowonthetelevision,ifitisnotyour
media recorderpress the Leftor Rightbuttontorestart
thesearch.
When your mediarecorder signalis found, save the
selectionbypressingthe Down buttonuntil Store Pro-
gram ishighlighted,thenpressthe Left/Right or OK
button to save.
Repeatforeach programmeposition tobetunedthen
press EXIT tofinish.
Note: Press toselectbetween ATV orDTV.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4511

English-12-
AnalogueAPS, choosingalanguage
APS (AUTOMATICPROGRAMMING
SYSTEM)
When the APS (AUTOMATICPROGRAMMING SYSTEM)
feature isselectedallchannels andsettings will belost,the
televisionwillreturnto factorysettingsandthenre-tune.
Press MENU andusingtheLeftorRightbuttonselect
INSTALL menu.ByusingUporDown buttons,select
PROGRAM TABLE andpressRightbutton.
P02C 04
P03C 05
P04BBC 1
P05CH 4
P06BBC 2
P07C 04
P08C 07
P09C 12
P10C 15
P11 S 18
P12 S 29
P13 S 31
P14 S 33
P15 S 34
P16 S 35
P17 S 36
P18 S 37
P19 S 40
P20 C 21
Name
Delete Insert
APS
P01BBC 1
ProgramTable
The PROGRAM screenwillappearonthescreen.Press
the BLUE buttontostart APS.
INSTALL
Program Table
Program
Band
Channel
ColourSystem
Country
WARNING!
All Prestored Programs
will be deleted
UK
Ok
Cancel
Auto Program
Country
WARNING!
All Prestored Programs
will be deleted
UK
Ok
Cancel
Auto Program
Press theLeft orRightbuttontosetthecountry..
Pressthe BLUE buttontocancel APS orthe RED or
OK button tostart.
UK
P 03 - C 04
63.75 MHz
6%
63.75 MHz
Cancel
APS is running...
Youmustallow thetelevisiontocompletethesearch.
Whenthesearchiscompletethetelevisionwillautomati-
callyselect programme position1.Thismaynot beaclear
picture orthesignalmaybe weak,so the stationordercan
bechangedusing program table whichwill appearonthe
screen.
PressEXITtofinish.
Choosing alanguage
The Language featureallows themenustobeshownina
varietyoflanguages.
Press MENU andusingtheLeftorRightbutton select
Featuremenu.
Press the Downbutton to highlight Language, then
use the Left or Rightbutton toselectthe required
language.
FEATURE
Sleep Timer
Child Lock
Language
Ext-2 Out
PC Audio In
English
Selecting programme positions
Toselecta programmepositionusethenumberedbuttons
on the remote control.Programme positions can also be
selectedusing and .Press todisplaytheon-
screen information i.e. programme position,stereo/mono
signal andpicture format.Torevert to theprevious
programme positionpress .
TheUp andDown buttons can be usedto navigate through
thesourcesin SOURCE menu,too.
SOURCE
ATV
AV-1
AV-2
AV-2 S
DTV
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4512

English-13-
Analogue generalcontrols, timedisplay,stereo/
bilingualtransmissions, childlock
The Time Display
Thetime displayfacilityallows thecurrent(textservice)time
tobeseenonthetelevisionscreen.
Press whilstwatchinganormaltelevisionbroad-
casttoseeatime display from thebroadcaster.
Stereo and Bilingualtransmissions
Ifstereoorduallanguagebroadcastsaretransmittedthe
wordStereoor Dualwillappearonthescreeneachtime
programmepositionsare changed,disappearing aftera few
seconds.Ifthe broadcastis notinstereothewordMono
willappear.
Stereo... Press to select Stereo or
Mono.Bilingual... Bilingualtransmissionsarerare.Ifthey
aretransmittedtheword Dual willdisplay.Choosethere-
quired programme numberandif theword Dual appears
press toselect Dual1 or Dual2.
In digitalmode,alist oflanguages andaudioformatsmay
be shownbriefly(mono, stereo, multi-channel). Use the
buttontoselectbetweenthem.
Childlock
CHILDLOCK disablesthebuttonsonthetop ofthetelevi-
sion.Allbuttonsontheremotecontrolcanstillbeused.
SETUPMENU
TVSetupOK
Local Options OK
AutotuningOK
Manual tuningOK
ProgrammesOK
Back Watch TV
AnalogueTV menuswillappearonthescreen.Press
Left orRightbuttonselectthe FEATURE menu.Press
theDown buttontochoose ChildLock andpressthe
LeftorRightbuttontoturnitonoroff.
FEATURE
Sleep Timer
Child Lock
Language
AV-2 Out
PC Audio In
Off
When ChildLock isselected,areminderwillappear
whenanyofthetoppanelbuttonsarepressed.Once
thetelevisionhasbeenswitched offit can ONLYbe
broughtoutofstandbyusingtheremote control.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4513

English-14-
Picture format
Depending on the type ofbroadcast being transmitted,programmes can be viewed in anumber offormats.Press
the button repeatedlytoselectbetween Auto,Wide,4:3,Super Live,14:9Zoom,Cinema or Subtitle.
When Auto is selected the formatbeing displayed isdetermined bythe picture being broadcast.
WIDE
Use this settingwhen watching a 16:9
broadcast .
4:3
Use thissetting to viewa true4:3
broadcast .
CINEMA
When watching ‘letterboxformat’
films/video tapes, this setting will
eliminate or reduce the black bars at
thetopand bottom of the screenby
zooming in and selectingtheimage
without distortion.
Subtitle
SUBTITLE
Whensubtitlesareincludedon a
letterbox format broadcast, this
setting will raise the pictureto ensure
that all thetext is displayed.
SUPER LIVE
Use this setting when watchinga
widescreen DVD, widescreen video
tape or a 16:9 broadcast(when
available). Duetothe range of
widescreen formats(16:9, 14:9, 20:9
etc.) black bars may be visible on the
top and bottomofthe screen.
14:9ZOOM
Use this settingwhen watching a 14:9
broadcast .
Usingthe specialfunctionstochange thesize ofthedisplayed image(i.e.changing theheight/width ratio)for thepurposes
ofpublicdisplayor commercialgainmayinfringeoncopyrightlaws.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4514

English-15-
Analogue Picturecontrols —picturemode,hue,
colour temperature, noise reduction, filmmode
Picture mode
Thistelevisionoffers thechoice ofpersonalisingthepicture
style.Press toviewthedifferentstylesavailable:
CINEMA, DYNAMIC and NATURAL.
Selectthe PICTURE optionfromthemainmenu.
Mode
Contrast
Brightness
Sharpness
Colour
PresstheDown buttonto highlightMode andthen Right
button toselectapicturestyle.
UsingtheUpandDownbuttonsselectContrast, Bright-
ness, Sharpness and Colour,then Leftand Right
buttons toadjusttosuitpersonaltaste.
PresstheDownbuttonandselect Reset toresetthe
adjustmentsto factorydefaultsettings.
Hue
Thisitem isdisplayedinPICTURE menuwhentheTV re-
ceives anNTSC signal.
In the PICTURE menu press theDown button until Hue
ishighlighted.
PresstheLeftandRightbuttonstoadjust Hue tosuit
your preference.
Hue
Colour Temp.
Noise Reduction
Sharpness
Colour
0
Colour Temperature
Colour Temperature increasesthe‘warmth’ or ‘coolness’
ofapicturebyincreasingtheredorbluetint.
In the PICTURE menu pressthe Downbutton until
ColourTemp ishighlighted.
Press the Leftand Right buttonsto select between
NORMAL,WARM and COOL tosuityourpreference.
Noise Reduction
NoiseReduction ‘softens’ thescreenrepresentationofa
weaksignaltoreducethenoiseeffect.
In the PICTURE menu pressthe Downbutton until
NoiseReduction ishighlighted.
Press the Leftand Right buttonsto select between
Low,Medium,High and Off. The differences may
notalwaysbenoticeable.
FilmMode
Films are recorded atadifferentnumberofframes per sec-
ondtonormaltelevisionprogrammes.Turnthisfeatureon
whenyouarewatchingfilms toseethefastmotionscenes
clearly.
In the PICTURE menupresstheDown buttonuntil Film
Mode ishighlighted.
PresstheLeftorRightbuttontoselect On or Off.
ThisfunctionisvisibleinATV modesonly.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4515

English-16-
Analogue Picturecontrols continued — 3D comb,blue
background, PIP,PAP
3DComb
3DComb isusedtoimprovecolourtransitionsandcolour
quality of pictures.
In the PICTURE menupresstheDown buttonuntil 3D
Comb ishighlighted.
PresstheLeftorRightbuttontoturnit On or Off.This
functionisvisibleinATV modesonly.
Blue Background
When BlueBackground is selectedthe screen will turn
blueandthesoundwillbemutedwhennosignalisreceived.
Afive minute countdown will be visible on screen.If no
signalisreceivedduringthefiveminuteperiodthetelevision
willswitchtostandbywhenthe countdownfinishes.
Selectthe FEATURE optionfromthemainmenu.
ThisfunctionisvisibleinATV modesonly.
FEATURE
Blue Background
Child Lock
Language
AV-2 Out
PCAudio In
On
UsingtheDownbuttonselect BlueBackground, then
press theLeftorRightbutton toselect.
Press EXIT tofinish.
Picture-in-Picture (PIP),
Picture-and-Picture (PAP)
NOTE: Thisfeatureonlyallows PC mode plus an-
other signal/input.
Pressthe buttonto switchtoPIPmode.
AtPIPMode, asmallpicture(PIPpicture)isdisplayedon
themainpicture.Thereare 3sizesand6 positionsavailable
forthePIPwindow. Youcanuse buttontochangethe
PIPposition. AspectRatioof thePIPwindow isfixedand
4:3.
WhenPIPModeisentered,thedefaultactivewindow isPIP
windowandtheactivewindow isindicatedbya red frame
aroundit.The activewindowcanbechangedby pressing
the or button.ThestatusinfoOSD belongstoactive
window.TheplaceofthestatusOSDsaresame forboth
windows.
Pressthe buttontwicetoswitchtoPAPmode.
AtPAP Mode,twopictureswithequalsizesaredisplayedon
thescreen.AspectRatiosofthewindowsarefixed.
WhenyouswitchtoPAP Mode,Mainwindow inPIP Modeis
displayedon therightsideof the screen.Theactivewindow
canbechangedbypressingthe or button
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4516

English-17-
Timers
Remember: Whenviewingin digital mode if analogue isrequiredpress , Source menu appearsonthe screenand
select ATV/DTV.Toreturnto digital viewing,select ATV/DTV in Sourcemenu.
Programme timers -digital
Thisfeaturesetsthetelevisiontimerstorecordprogrammes.
The “Repeat” feature can be settorecord “daily” and
“weekly”to ensurea seriesofprogrammesarerecorded.
Press MENU and or toselectthe TIMERMENU.
TIMER MENU
Programme timersENTER
Back
Wa
tch TV
Press toselect Programme Timers, then press
OK toselect.YourTV mustbeonorinstandby mode
whenaprogrammetimertoduetostart.
Back
13.45 Sat, 21Aug
.
Press to selectthe first programme tobe recorded,
thenpress OK. The SETTIMER menuwillnowappear.
Press or togothroughthelist addingthedetails
oftheprogramme tobe recordedbyusingthe number
buttonsand or tomakeselections.
SET
TIMER
ProgrammeBBCFOUR10
DateSat, 21Aug. 21/08
Start Time 13.45
End Time 14.45
Repeat ONCE
Subtitles NONE
Auto-start VCR
YES
Whenallthedetailshavebeenenteredpress OK to
save thetimer.
Please Note: When a timedprogrammeisaboutthe
startrecording,aninformationscreenwillappear,the
televisionwillthenchange automaticallyto therequired
channel.Cancellingthiswillalsocanceltherecording.
Sleep timer -analogue
Thetelevision canbesettoturnitself OFF aftera certain
time.
Press MENU and or toselect Feature.Then
press or or OK toenterthemenu.
Tosetthenumberof minutesin whichthetelevisionwill
turnoffpress or . Thiswill increase ordecrease in
stepsof 10minutes.
FEATURE
Child Lock
Language
AV-2 Out
PC Audio In
10 min.
Sleep Timer
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4517

English-18-
DigitalProgramme Guideandon-screen information
When viewing in digitalmode the on-screen informationandguidegiveaccesstoprogrammedetails for all available
channels.Recordingcanalsobesetfrom both theinformationscreen andguide.
Information
Select information bypressing , the information
screen willappear givingdetailsofthe channeland
programme currentlybeingviewed.
BBC ONE
BBC TWO
CBBC Channel
BBC THREE
BBC FOUR
Showingalso
Newsround starting in9 minutesonCBBC Channel
ShowingalsoLanguage
PageDownPageUp
13.45Sat, 21 Aug.
13:35Boxing Olumpic...
014minutesleft
...Grantstand
StakeintheFleyweightand Middleweightdivisions.
Quarterfinal placesare at
14:00 OlympicGrand...
Toseedetailsof any oftheotherchannelscurrently
available,press or toscrollup/down thelist.
Asthechannel isselecteddetailsoftheprogramme
currentlybeingbroadcast willappear.
Torecordthe followingprogramme,with theinforma-
tionguideshowing, press OK.
SET TIMER
Start
Time01:25
End Time 02:55
Repeat ONCE
Subtitles NONE
Audio Language ENGLISH
1 BBCONE 14:00-15:15Sat, 21 Aug.
Press or togothroughthelistaddingdetailsof
theprogramme to berecordedbyusingthenumber
buttonsand or tomake selections.Press OK to
save.
Guide
Select the on-screen guide bypressing GUIDE,the
guidescreenwillappearhighlightingdetailsofthechannel
andprogramme currentlybeingviewed.
Thismaytakeafewmomentstoappear.
BBC ONE
BBC TWO
ITV 1
CHANNEL 4
Five
ITV 2
BBC THREE
Teletext
BBC FOUR
Skytravel
UKTV History
E4
PageUpPageDown
RecordMoreInfo
Timers
Changeprogs
WatchTV
BigBrother Live
Horizon
Time Flyers
Time Flyers
CanaryIslaFloydon
Spanish PackageDeals
ThisisBBC FOUR
ThisisBBC THREE
Judge Judy
SallyJessy Raphael
Brainteaser FrasierTheBigCircus
ThisMorningTrisha
Barg
TheDailyP
CityHospital OlympicGrandstand
Monday
10:0010:30 11:0011:30
10.03Mon, 30Sep.
ALL PROGS
Teletubbies Wildlifeon
TheWrightStuff
Press or for information ofother programmes
scheduledforthechannelselected.
Fordetailsofotherchannelscurrentlyavailable,press
or toscrollupanddown thechannellist.As
thechannelis selecteddetailsoftheprogramme cur-
rentlybeingbroadcastwillappear,thenpress or .
Pressthe buttonformoreinformationaboutthe
currentlyhighlighted programme.
5
Press EXITbutton toreturntooriginalprogramme.
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4518

English-19-
Digital parental controls -setting the pin,mode
There are a number ofparentalcontrolswhichcanblockspecificchannelsbeing viewed, and whichcanonlybe accessed
withasecurityPIN codewhenindigitalmode.
Onceyou’veenteredthePINcode, you do not needtoenteritagainuntilnexttime you power-on TV.TorestorePIN code
entry again(e.g.forparentalcontrolsonlockedprogrammes)pressSTANDBYtwice.
Setting the PIN
Press MENU and to select FEATURE MENU.
FEA
TUREMENU
P
arental Control
F
avourite andLock
ed Programmes
Favourites
ALLPROGS
CommonInterfaceSlot
SoftwareUpgrade OK
Back
Watch TV
OK
OK
Use toselect ParentalControl thenpress OK.
Press tohighlight ChangePin thenpress OK.
P
ARENT
AL CONTROL
Mode OFF
Change Pin OK
BackWatchTV
Usingthenumberbuttonsenterafourdigitnumber,
whenthese havebeenenteredthescreenwill ask you
toconfirm thembyenteringthemagain.
DEFINEPINNUMBER
New PIN
ConfirmPIN
–
–
Exit
–
–
Press MENU togobacktotheParentalControlscreen.
ThePINnumberisnow set.
Mode
Thisfeature locksvariousmenustopreventthe television
beingretunedorthesettingsbeingoverridden.
Inthe PARENTALCONTROL menupress toselect
Mode.
P
ARENT
ALCONTROL
ModeOFF
ChangePinOK
BackWatchTV
Use or tochoosebetween ON, OFF, LOCK
MENU and LOCKINSTALL.
Whenmenusthathave beenlockedarenowselected,
theywillonlybecomeavailablewhenthePINisen-
tered.
ON: Parental control settingsare enabled (PINcode is
requiredfor programme locksandcencorship).
LOCKINSTALL: As ONmodeabove,exceptthatinstalla-
tionfeaturessuchasauto-tuningandprogrammesorting
arealsolocked(PINcodeisrequired).
LOCKMENU: AsONmode,exceptall menu functionsare
locked(PIN codeisrequired).
OFF: All locksettings are disabled (no PIN code isre-
quired).
20_23790W_TOSHIBA_MB22_CT8003_(PAN_EU-DVB-T) (20W330DG-23W330DG).p6502.04.2007, 09:4519
