SERVICE MANUAL
NETWORK EXPANSION KIT
GA-1330
Model: GA-1330
Publish Date: July 2008
File No. SME08000500
R080621G0800-TTEC
Ver00_2008-07
Trademarks
•Microsoft
®, Windows®, Windows®98, Windows®Me, Windows®2000, Windows®XP, Windows®
Vista, and Internet Explorer®are registered trademarks or trademarks of Microsoft Corporation in
the U.S.A. and other countries.
• Adobe®, the Adobe®logo, Acrobat®, the Adobe®PDF logo, and ReaderTM are registered trade-
marks or trademarks of Adobe Systems Incorporated in the United States and other countries.
• IBM, PC/AT, and PowerPC are trademarks of International Business Machines Corporation.
• All other trademarks and copyrights are the property of their respective owners.
© 2008 TOSHIBA TEC CORPORATION All rights reserved
Under the copyright laws, this manual cannot be reproduced in any form without prior written permission
of TOSHIBA TEC CORPORATION. No patent liability is assumed, however, with respect to the use of the
information contained herein.
General Precautions for Installation/Servicing/Maintenance
for the GA-1330
The installation and service should be done by a qualified service
technician.
1. When installing the GA-1330 to the Equipment, be sure to follow the instructions described in the
"Unpacking/Set-Up Procedure for the GA-1330" booklet which comes with each unit of the GA-
1330.
2. The GA-1330 should be installed by an authorized/qualified person.
3. Before starting installation, servicing or maintenance work, be sure to turn OFF and unplug the
equipment first.
4. When servicing or maintaining the GA-1330, be careful about the rotating or operation sections such
as gears, pulleys, sprockets, cams, belts, etc.
5. When parts are disassembled, reassembly is basically the reverse of disassembly unless otherwise
noted in this manual or other related materials. Be careful not to reassemble small parts such as
screws, washers, pins, E-rings, toothed washers to the wrong places.
6. Basically, the machine should not be operated with any parts removed or disassembled.
7. Delicate parts for preventing safety hazard problems (such as switches, sensors, etc. if any) should
be handled/installed/adjusted correctly.
8. Use suitable measuring instruments and tools.
9. During servicing or maintenance work, be sure to check the serial No. plate and other cautionary
labels (if any) to see if they are clean and firmly fixed. If not, take appropriate actions.
10.The PC board must be stored in an anti-electrostatic bag and handled carefully using a wristband,
because the ICs on it may be damaged due to static electricity. Before using the wrist band, pull out
the power cord plug of the equipment and make sure that there is no uninsulated charged objects in
the vicinity.
11.For the recovery and disposal of used GA-1330, consumable parts and packing materials, follow the
relevant local regulations or rules.
12.After completing installation, servicing and maintenance of the GA-1330, return the GA-1330 to its
original state, and check operation.
GA-1330 CONFIGURATION 1 - 1
[1] CONFIGURATION
[2] SPECIFICATIONS
1. Basic specifications
*1: Mac OS 10.5 is supported by running change.
GA-1330
e-STUDIO203S/203SD
Items Spec
Extensible model e-STUDIO203S/S203D
Standard memory 64MB
Expansion memory DIMM 1slot
144pin 128/256MB SO-DIMM
Platform of Client PC IBM PC/AT compatible, Macintosh
Expansion memory
for fonts PS font memory
Bar-code font memory
Flash ROM kit
Useable OS Windows 98/Me/2000 professional/
Windows XP Home Edition/Professional
Edition/Vista
Mac OS 9-9.2, 10.1.5, 10.2.8, 10.3.9,
10.4-10.4.10 *1(For PS)
Required hardware
(PC) (System)
The conditions of each OS which can be
used are required.
(HDD) Exceeding 100M is recommended.
(Monitor) 800 x 600 dots
(Interface)
10BASE-T/100BASE-TX Ethernet
Required software Internet Explorer 5.5 or later
Netscape Navigator 6 or later
Network Protocol TCP/IP, IPX/SPX, NetBEUI, Ether Talk
Emulation
(The functions which
can be used differ by
The MFP connected)
PCL/PS (PS: Cancels by the soft key)
Network Print PCL/PS
Network Scan
(The functions which
can be used differ by
The MFP connected)
Scan to E-mail, Scan to FTP,
Scan to Desktop
(Requires Desktop Document Mnager
v3.2)
E-mail alert status Yes (Cancels by the soft key)
Power supply Supplies via copier
(AC power supply built-in) AC120mA
Items Spec
Power consumption 5.5W
Outside dimension
(W x D x H) 248mm x 127mm x 59mm
Accessories USB cord x 1
(for connection to Copier)
Software CD-ROM x 4
Screw for installation x 1
Clamp x 1
(for harness fixation)
Installation manual
Installation guide
∗An installation manual exists in driver
CD-ROM by the pdf file format.
Bundle software Disk 1: Driver CD-ROM
• PCL driver (Win)
•PSdriver(Win)
• Status Monitor V4.2
• Integrated installer
• PCL font
• PS font
Disk 2: Network setting CD-ROM
• Printer Administration Utility V4.1 (Win)
• Mac PPD driver (Mac)
• Online Manual (for printer) (Win/Mac)
• Online Manual (for image send) (Win/
Mac)
• Setup Guide (Win/Mac)
Disk 3: Application CD-ROM
• Desktop Document Manager
• Online Manual (for desktop document
manager)
• TWAIN driver
Disk 4: Driver CD-ROM
Internet Explorer 6.0
GA-1330 SPECIFICATIONS 1 - 2
2. Function description
A. Print emulation
A difference exists in the function which can be used by execution of the basic performance and composition of the MFP to connect (print size/
configuration).
(1) comparison table of main print function classified by driver
(2) Comparison table of printing function for each driver
Function PCL5e
Custom Driver PCL6 (XL)/SPDL2
Custom Driver PS
Custom Driver Macintosh
PPD file Windows
PPD file
General Document Style 1-Sided, 2-Sided (Book), 2-Sided (Tablet), Pamphlet Style
(Tiled Pamphlet), Pamphlet Style (2-up Pamphlet) 1-Sided, 2-Sided (Book), 2-Sided (Tablet)
Booklet Yes No
Binding Edge No
N-up 2/4/6/8/16 Win 9x: 2/4
Win2K/XP/Vista:
2/4/6/8/16
N-up Order Z Z, Reverse Z, N, Reverse N Z
Custom Paper Size 1size 3 sizes
Different 1st (Cover) Yes No
Graphic Resolution Setting 600/300 dpi 600dpi
Half tone Setting No Yes No
Graphics Mode Raster/HP-GL2 Raster/Vector No
Negative Image No Yes
Mirror Image No Yes No Yes
Fit to Page Yes No
Font Resident Font 80 fonts 136 fonts,
5 Kanji fonts
(Japan only)
35 fonts,
5 Kanji fonts
(Japan only)
136 fonts,
5 Kanji fonts
(Japan only)
Download font Yes No Yes
Others Configuration
Setting Yes (Automatic) No
Job Compression No Yes No
Bitmap
Compression No Yes No
The model to connect e-STUDIO203S/203SD
Function PCL5e PCL6 PS Mac PPD Win PPD
General Copies 1-999
Orientation Portrait/Landscape
Collate Collate/Group
Document Style 1-Sided, 2-Sided (Book), 2-Sided (Tablet), Pamphlet Style
(Tiled Pamphlet), Pamphlet Style (2-up Pamphlet) 1-Sided, 2-Sided (Book), 2-Sided (Tablet)
Booklet Invoice on Letter, A5 on A4, Letter on Letter, A4 on A4 No
Binding Edge No
Margin Shift No
N-up 2/4/6/8/16 Win9x: 2/4
Win2k/XP/Vista:
2/4/6/8/16
N-up order Z Z, Reverse Z, N, Reverse N Z
N-up Border
On/Off
Yes
(Single hairline/
Single thin line/
Double hairline/
Double thin line)
On/Off
GA-1330 SPECIFICATIONS 1 - 3
*1: Mac OS 10.1 is not supported.
Paper Paper Size A3/B4/A4/B5/A5/B6/A6/11x17/8.5x14/8.5x13/8.5x11/5.5x8.5/Folio/Executive/COM-10/Monarch/DL/C5/8K/
16K
Fit to Page size A4/B5/A5/B6/A6/8.5x14/8.5x13/8.5x11/5.5x8.5/Folio/Executive/COM-10/Monarch/DL/C5/8K/16K
Paper Type No
Custom Paper Size 1 size 1 size *13 sizes
Source Selection Auto/Bypass (Auto)
Tray 1/2
Different 1st (cover) On/Off No
Transparency
Inserts No
Carbon Copy No
Paper
Output Output Tray
Selection No
Staple No
Graphic Resolution Setting 600/300 dpi 600 dpi
Half tone Setting
No
ScreenFrequency8
to 360.0 in 0.1 steps
Screen angle 0.0 to
360.0 in 0.1 steps
No
Graphics Mode Raster
HP-GL2 Raster
Vector No
Smoothing No
Toner save No
Half tone Enhance No
Brightness No
Negative Image No On/Off
Mirror Image No Horizontal/Vertical No Horizontal/Vertical
Zoom No 25-400%
Fit to Page On/Off No
Font Resident Font 80 fonts 136 fonts 35 fonts 136 fonts
Download Font Bitmap, TrueType, Graphics No Type1
True Type
Others Configuration
Setting Yes (Automatic) No
ROPM On/Off
Overlay On/Off No
Print Auditor No
Job Retention No
Watermark On/Off On/Off (With functional restriction)
Page Protection No
Job Compression No None, Fastest, Fast,
Medium, Best No
Job Compression No None, Very High,
High, Medium, Draft No
The model to connect e-STUDIO203S/203SD
Function PCL5e PCL6 PS Mac PPD Win PPD
GA-1330 SPECIFICATIONS 1 - 4
(3) PDF/TIFF direct printing function
PDF and TIFF files can be specified from a web page and directly
printed out.
(4) Limitations (printing function)
If a print request for GDI/SPLC data is made, an error message is
printed out.
(5) Printer condition setup
The following setup can be made from the web page.
Default Setting Items
(6) Network status page
The network status pages shows a list of settings about the network.
Data are printed out in the A4 or letter size in US English regardless
of the destination and OS language selected.
The status page can be printed out by pressing the status switch on
the network expansion kit.
Note:
1. The name of the printer is printed under the item "printer name."
2. When WINS is disabled, "WINS server 1-5" is not displayed. It is
displayed when a value is set or information is acquired from the
DHCP server.
Any server which responds normally to the registration of WINS
is marked with an asterisk "∗".
"WINS server" shows up to 5 values: 2 settings, 2 DHCP values,
and broadcast. However, the broadcast operates only when no
normal response is returned from any server.
3. The "WINS Scope ID" is displayed only when a value is set or
when information is acquired from the DHCP server and more
than one piece of information is valid as a WINS server.
B. Network scanning function
It is possible to use the MFP scanning function as a network scanner
with a network scanner expansion kit. Setups can be made using a
Web browser. Supported functions vary with the type of the MFP
connected.
(1) Basic scanning function
(2) Scanner settings
Function Item Default
Copies 1-999 1
Orientation Portrait / Landscape Portrait
Default Paper
Size (Overseas)
• Invoice •Letter •Foolscap
•Legal
(Domestic)
•A5 •B5 • A4
(China - size of AB system)
•A5 •B5 •A4 •16K
Letter or A4
Default Paper
Source drop down box select values:
•AUTO •Tray1 • Tray2
•BYPASS
AUTO
2-Sided Print drop down box slect values:
•1-SIDED •2-SIDED (BOOK)
•2-SIDED (TABLET)
1-SIDED
ROPM Enable / Disable Disable
Function Item Remarks
Network
scanner Scan to E-mail Yes
Scan to Desktop Yes
Scan to FTP server Yes
Destination Specify e-mail address with LDAP Yes
AdHoc
(Enter e-mail address from MFP.) Yes
File format JPEG
PDF
(non-compression, G3, G4)
TIFF
(non-compression, G4, G4)
Yes TIFF/PDF
multiple
page
support
Setting Item Default Remarks
File
format JPEG color/
JPEG gray scale/
PDF color/
PDF gray scale/
PDF monochrome,
binary
non-compression/
PDF monochrome,
binary G3
compression/
PDF monochrome,
binary G4
compression/
TIFF color/
TIFF gray scale/
TIFF monochrome,
binary
non-compression/
TIFF monochrome,
binary G3
compression/
TIFF monochrome,
binary G4
compression
TIFF
monochrome,
binary G4
compression
Color
mode Monochrome,
2 gradations/
Gray scale/Full color
Monochrome,
2 gradations Available only
at the
“monochrome”.
Resolution 75/100/150/200/
300/400/600 75 Selectable
resolutions vary
with different
memory
capacities.
Light
source Red/Green/Blue Green Light source
can be selected
only when the
color mode is in
"Monochrome".
Void On/Off On When On is
selected, the
edges of
images are cut.
GA-1330 SPECIFICATIONS 1 - 5
(3) Send file (message and filename)
• Information contained in filename
Example:
e-STUDIO203SD_20000620_155114_0057_06a3f3393948.pdf
• Mail subject
Can be freely set.
Default:
Scanned image. device name: e-STUDIOXXX (MFP product
name)
Example: Scanned image. device name: e-STUDIO203SD
•Mailmessage
The following messages are added to the image send mail.
Example:
Device name : e-STUDIO203SD
Model name : e-STUDIO203SD
Location : D2) Planning dept.
File type : PDF MMR (G4)
Resolution : 200 dpi x 200 dpi
(4) Recipient registration
• Up to 200 destinations can be registered on the network expan-
sion kit to which the scan can be sent from the network scanner.
• The mail address registered for each destination can be selected
from the mail address which is searched using LDAP.
• The information for each recipient includes the recipient name, IP
address or mail address, scanning size, format type, and scan
parameter.
• Either of LDAP-selected or directly-entered mail address scan set-
ting is available. If the destination is a mail address entered
through the main system or selected by LDAP, this scan setting is
used.
• The destination name is displayed on the LCD.
(5) Scanning size
• Scanning size is the size set up in main unit (Copier).
(Apply to the main scan, a subscan, RADF, and OC)
(6) Scanner limitations
• The scanning function is allocated to the network expansion kit.
The b Button Manager settings are disabled.
• When the network expansion kit is connected, the scanner func-
tion through TWAIN (pull scan) and push scan which used button
manager on pc are not available.
C. Functions by interface
When the network expansion kit is connected, the following func-
tions are available by system interface.
(*1): PS requires soft keys of the GA-1180.
D. Network setup
Network setups should be performed by the system administrator.
Use a setup tool such as TCP/IP, Netware, Ether Talk or Web inter-
face.
E. Software setup
The network expansion kit can be installed by setting up NIC, install-
ing a printer driver with the total installer, and installing Desktop Doc-
ument Manager.
(1) Installing driver
The network expansion kit printer is connected only through the net-
work. The port setup required for installing a printer driver is the net-
work only. The following items should be set up.
• TCP/IP peer-to-peer port
1) Search for the network expansion kit on the network and select
the network expansion kit you want or enter the IP address of
the applicable network expansion kit to create a TCP/IP port.
2) Install the driver to the created port.
• Windows printer shared port
When the setup of the above client PC is completed and the
printer is set to "Windows shared printer," other client PCs can
select this printer shared port and then proceed to installation of
the driver.
F. Hardware setup
1) Connection to the system unit
Connect to the USB2.0 port
2) Power supply
Supplied by the main unit.
Sender name : Use MFP product name.
Date & Time : Date and time at which file is sent
Session page
counter : Image send counter
Unique identifier: Automatically created based on the information
of the date and time and image send counter.
Device name : Freely set
Model : MFP product name
Location : Freely set
File type : File type of send image
Resolution : Resolution of send image
SystemI/F
(main unit) GA-1330 I/F Function
SPLC GDI PCL5e/6 PS
(*1) Net
Scan
USB2.0 RJ45 (LAN) No No Yes Yes Yes
USB2.0 ➝YesNoNoNoNo
GA-1330 UNPACKING AND INSTALLATION 3 - 1
[3] UNPACKING AND INSTALLATION
1. Unpacking
2. Packaged goods
3. Installation procedure
This installation manual is provided for e-STUDIO203S/203SD
series.
For Installation to other models, see the operation manual of the
main unit or the service manual.
Turn off the main switch of the copier and remove the power
plug of the copier from the outlet.
(1) Cut the rear cabinet.
1) Remove the RADF from the main unit and gently place it on the
document glass as shown in the illustration.
2) Cut out two cut-out portions from the rear cabinet using a cutter
or the like.
3) Use a Phillips screwdriver or the like to open a hole.
4) Remove the screw and then remove the rear cabinet cover.
5) Cut out a part of the rear cabinet cover with nippers or the like as
shown in the illustration. (Be careful about the orientation of the
nippers so that the cross section is flat.)
(2) Attach the network expansion kit.
1) Engage the two pawls on the rear of the network expansion kit
with the cut-out portions of the main unit and secure the kit with
the supplied screw (3 x 14).
2) Connect the connector of the network expansion kit to the con-
nector of the main unit.
3) Secure the rear cabinet cover to the main unit with the screw.
4) Attach the RADF to the main unit.
GA-1330 UNPACKING AND INSTALLATION 3 - 2
(3) Connect the USB cable and the network cable.
1) Attach the supplied cable clamp to the position shown in the
illustration.
2) Connect the USB cable to the network expansion kit and the
main unit.
At this time, reduce slack of the cable with the cable clamp as
shown in the illustration.
3) Connect the network cable.
Insert the power plug of the copier to the outlet, turn the main
switch of the copier to the “ON” position, and perform network
setting and installation of the software.
GA-1330 SETUP IN A WINDOWS ENVIRONMENT 4 - 1
[4] SETUP IN A WINDOWS ENVIRONMENT
1. Setting the IP address of the machine
A. IP address setting
When connecting a network box, use this setting in the user program
to set the IP address of the network box.
1) With the network box connected, enter the user program from
the printer mode, and select [IP ADDRESS SETTING].
2) When [IP ADDRESS SETTING] is selected, the display indi-
cates [IP ADDRESS], [SUBNET MASK], and [DEFAULT GATE-
WAY] setting menu sequentially.
• One block is composed of 3 digits, and every menu displays 4
blocks. Use 10-key to input into each block.
• On [DEFAULT] menu, the top digit of each block is "0."
• The cursor at the right end of the selected block flashes.
• The entered value is displayed on the flashing cursor. When three
valid numbers are entered, the cursor moves to the next block on
the right. (If the number to be entered is 10, enter 10 and press
[←/→] key, or enter 010, and the cursor moves to the next block.
("0" on the top digit, in this case, is not displayed.)
• The cursor is moved by entering three digits of numbers or press-
ing [←/→] key.
• To shift between [IP ADDRESS], [SUBNET MASK], and
[DEFAULT GATEWAY], press [←/→] key.
Though, therefore, three digits are entered on the last block of [IP
ADDRESS], the display is not shifted to the first block of [SUBNET
MASK].
• When the clear key is pressed, if the value of the selected block is
changed from that on selection of setting, it is reset to the value on
selection of setting.
• When the clear key is pressed with the value unchanged or reset
to the value on selection of setting, the display is shifted to the
menu of item 1. (In this case, all the changes in values made
before pressing the clear key are cleared.)
2. Checking the IP address
To check the IP address of the machine, press the status button on
the network expansion kit to print out a network status page.
GA-1330 UPDATING NETWORK BOX FIRMWARE 5 - 1
[5] UPDATING NETWORK BOX FIRMWARE
Update the Network Box firmware in the following procedure using a
Web browser.
1. Display the web page for updating Network Box firmware
Start the browser on your PC and specify the following URL.
A web page, as shown in Fig. 1, appears on screen.
http://<IP Address of Network Box>/firmware_upload.html
[Fig.1: Web page for updating Network Box firmware]
2. Switch to firmware upload mode
Click the button on the screen, the message shown in Fig. 2
appears.
[Fig.2: Switch to firmware upload mode]
The page changes to the Network Box firmware upload mode.
The browser is automatically reloaded and then the screen looks
like this.
∗When the screen shown in fig.3 is not displayed, refresh a
browser manually.
[Fig. 3: Upload mode]
3. Specifying the file
Click the Reference button. Selects the firmware of the Network
Box version you want to update, from the file selection menu
indicated in Fig.4.
[Fig. 4: Specifying the file]
GA-1330 UPDATING NETWORK BOX FIRMWARE 5 - 2
4. Updating the firmware
After you select the file, click the Submit button. The firmware is
transmitted to Network Box, and it is updated. The message indi-
cated in Fig.5 blinks repeatedly until the updating process is
completed. Do not turn off the power supply.
[Fig.5: Updating in progress]
5. Restarting your PC
When updating is completed, the message shown in Fig.6
appears on screen. Turn off the power and then turn it on again
to restart Network Box.
[Fig.6: Updating completed]
Note: Both the Boot and Main files can be updated in the same pro-
cedure as mentioned above. However, when you want to
update both at the same time, you need to update them sepa-
rately by repeating the same procedure twice.
Caution: If a DHCP is used, the browser may not be able to reload
automatically in some cases when transferring to the
upload mode because different IP addresses are read.
Therefore, we recommend that you use a fixed IP address
when updating firmware.
If the upload mode is operating with different IP addresses,
check the IP address obtained by the Ethernet address of
Network Box from the DHCP server and display the updat-
ing mode URL again using the browser.
When a proxy server is used, the screen may not be
updated by reloading. In that case, you need to update
manually.
GA-1330 TROUBLE CODE 6 - 1
[6] TROUBLE CODE
1. Trouble code (CE code)
If "CE" blinks in the display, press the [START] key. An error code will
appear. Solve the problem as explained below.
Error Code Solution
CE-00 Error which cannot be specified occurred.
Turn off the power and turn it back on. Consult with
your network administrator to make sure that no
problems exist on the network or in the server.
CE-01 Network Server card error.
Turn off the power and turn it back on. Consult with
your network administrator to make sure that no
problems exist on the network or in the server.
CE-02 Server access denied. The scanned image was not
sent because a connection to the server could not be
established. Make sure that the SMTP server
settings or FTP server settings in the Web page are
correct.
CE-03 The scanned image was not sent because the server
was busy or there was too much traffic. Wait briefly
and then try again.
CE-04 It has not logged in to the FTP server and the mail
server. Please reconfirm the login name and a
password.
CE-05 The scanned image was not sent because the
directory of the destination FTP server was not
correct. Make sure that the correct FTP server
information is configured in the Web page.
CE-09 The size of the scanned image file exceeds the
upper limit set in "Maximum Size of File" in the Web
page. Reduce the number of original pages scanned
into the file, or change the upper limit set in
"Maximum Size of File".
CE-10 A transmission method assigned to a [SCAN MENU]
key cannot be used. Check the transmission
methods assigned to the [SCAN MENU] keys in
"Enable Scanner Delivery to:" in the Web page
whether or not the method can be used.
CE-11 The memory filled with scanner data.
It was not able to process by the size of a scanner
data being too large.
Please drop resolution of data by setup of scaner
and retry scan.
CE-12 The quantity of the result for which LDAP searched
exceeded the maximum quantity which can be
searched.
There are too many addresses which were in
agreement with reference conditions.
Please increase the number of reference characters
and perform re-reference.
GA-1330 ELECTRICAL SECTION 7 - 1
[7] ELECTRICAL SECTION
TMPR4927TB
PCIC
EBIF
SDRAMC
EBUSC
100MHz/64bit
System BUS
256Kbit
Serial EEPROM
Tx49Core
G-Bus
Bridge
IM-Bus
ADDR[19:0]
DATA[63:0]
MEMA[14:5]
CPUCLK = 200MHz
OSC
25MHz
MEMD[15:0]
MEMD[31:16]
4Pin Connector
(RS-232C Connector)
PCI
Connector
Ethernet
Connector
USB
Connector
UART Ch1
DP83816
(MAC/PHY)
USB2.0
ISP1561
33MHz/32bit
PCI BUS
RTC
12MHz
32.768KHz
PIO
LCX14
On Board 64MB
SDRAM0 (H)
256Mbit
SDRAM0 (L)
256MB(Max)
256Mbit SPD
SDRAM1 SO_DIMM
MEMD[63:0]
AHCT125
LCH
LD[31:0]
LCX245
Flash
SO-DIMM
slot0 12MB or 16MB
3.3V
LA[20:0]
LD[31:0]
LCX244
BUSSPRT
MEMD[31:0]
Flash
SO-DIMM (Mask ROM)
slot2 32MB
ACE
LCX373
LD[31:0]
Flash
SO-DIMM
slot1 8MB
IRCUART
LVC125
1. BLOCK DIAGRAM
5
5
4
4
3
3
21
21
D D
C C
B B
A A
1/16
GA-1330 ELECTRICAL SECTION 7 - 2
R37 10K
TP742
TP712
R36 10K
TP395
TP713 TP714
R35 10K
R304 10K
TP743
TP710
TP656
TP736
TP744
R249 1K
TP381
TPAD33
1
R248 1K
TP745
R247 1K
TP746
TP747
R296 1K
TP639
TP748
R297 1K
IC1A
TMPR4927/4937
TDI/DINT
C11
TCK
B11
TMS
C12
TRST
E16
RESET
K1
TPCO/TDO B13
DCLK B12
PCST0 A17
PCST1 C16
PCST2 B16
PCST3 A16
PCST4 C15
PCST5 B15
PCST6 E14
PCST7 C14
PCST8 B14
TPC1 E13
TPC2 D13
TPC3 C13
TEST0
K2
TEST1
L5
TEST2
L4
TEST3
L3
TEST4
L2
HALTDOZE K3
BYPASSPLL
D5
CGRESET
P23
MASTERCLK
R26
SDIN1
E6
TCLK
E1 WDRST M2
TIMER0 E2
TIMER1 E3
NMI
F4
CTS0
H3
CTS1
J4
INT0
F3
INT1
F2
INT2
F1
INT3
G3
INT4
G2
INT5
G1
RTS0 H2
RTS1 J3
RXD0
G4
RXD1
J5 TXD0 H1
TXD1 J2
SCLK
J1
PIO0 A2
PIO1 A1
BITCLK/PIO2 B2
SDIN0/PIO3 B1
SDOUT/PIO4 C2
PIO5 C1
PIO6 D3
PIO7 D1
CB0/PIO8 AD3
CB1/PIO9 AF3
CB2/PIO10 AC20
CB3/PIO11 AB21
CB4/PIO12 AE3
CB5/PIO13 AE4
CB6/PIO14 AE20
CB7/PIO15 AD21
TX4927/TX4837 1/5
R298 10K
C1
0.1uF
TP737
R288 33
TP749
R15 10K
TP750
TPAD35
1
TP751
R16
33
TP394
TP658
R20 8.2K
R250 1K
NOASM
TPAD27 1
R27 10K
TP650
TPAD28
1
TP752
R290 33
TP753
R291 33
R19 8.2K
TP711
TP754
R292 33
TPAD10
1
TPAD6
1
R293 33
CN11
RF-H102TD-1130
NOASM
1
1
3
3
5
5
7
7
9
9
2
2
4
4
6
6
8
8
10
10
TP651
R303 10K
TP396
X1
SCO-10 25MHz
CONT
1
GND
4OUT 5
VDD 8
TP659
R2871K
R14 1K
TPAD9 1
R17 10K
TP738
R302 10K
R301 10K
TPAD8
1
R300 10K
C2
0.1uF
TP427
R294 1K
R295 1K
NO ASM
TP652
R218
10
R289 33
R18 8.2K
TP741
TP660
R34 10K
TPAD7 1
R22 1K
R299 10K
TP655
R24 1K
R33 10K
JP1
T2B-SQ
NOASM
12
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
NMI13,16
RTCDATA 8,16
DIMM_SCK 5,16
CGRESET13,16
EEP_SCK 8,16
WDRST 13,16
RTCR/W 8,16
DIMM_SDA 5,16
RTCCS 8,16
PIO_SW 13,16
VCCWCTL 7,16
RXD16,16
PONRST7,9,10,11,13,15
TXD1 6,16
HDD_POWER 9
RTCCLK 8,16
PCIINTA9,10,11
DBG_LED1 13,16
DBG_LED3 13,16
PCIINTB9
DBG_LED0 13,16
EEP_SDA 8,16
DBG_LED2 13,16
INT213,16
CLK10,16
HALTDOZE
PIO15
<JTAG CONNECTOR>
NO ASM
NO ASM
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
MAIN PWB (TMPR4927TB_1) 2/16
2. CIRCUIT DIAGRAM
GA-1330 ELECTRICAL SECTION 7 - 3
MAIN PWB (TMPR4927TB_2)
R45 10
BR19
33
1
2
3
45
6
7
8
BR4
33
1
2
3
45
6
7
8
BR20
33
1
2
3
45
6
7
8
BR11
33
1
2
3
45
6
7
8
R56 4.7K
IC3A
TC74LCX14FT
12
BR18
33
1
2
3
45
6
7
8
BR5
33
1
2
3
45
6
7
8
TPAD32
1
BR15
33
1
2
3
45
6
7
8
R48 82
TPAD31
1
BR21
33
1
2
3
45
6
7
8
TPAD30
1TPAD29
1
BR23
33
1
2
3
45
6
7
8
R49 33
BR27
4.7K
NOASM
1
2
3
45
6
7
8
R50 33
R39 4.7K
NO ASM
BR12
33
1
2
3
45
6
7
8
R277 4.7K NOASM
R46 33
BR14
33
1
2
3
45
6
7
8
R42 4.7K
BR9
33
1
2
3
45
6
7
8
BR8
33
1
2
3
45
6
7
8
R43 4.7KNO ASM
C245
22pF
BR7
33
1
2
3
45
6
7
8
TP662
R44 4.7K
NO ASM
BR26
33
1
2
3
45
6
7
8
C246
22pF
BR16
33
1
2
3
45
6
7
8
R61 33
R40 4.7K
BR25
33
1
2
3
45
6
7
8
R53 33
R47 33
TPAD18
1
R60 33
R57 4.7K
TPAD17
1
R63 33
R38 4.7K
BR6
33
1
2
3
45
6
7
8
R265 4.7K NOASM
R69 33
R62 33
R66 33
TPAD16
1
BR13
33
1
2
3
45
6
7
8
R208 33
R51 47
ICT32
R64 33
R209 33
TPAD15
1
R54 33
R276 4.7K NOASM
R65 33
R55 33
R52 47
IC1B
TMPR4927/4937
SDCLKIN
AF15
DMAREQ0
E11
DMAREQ1
B9
DMAREQ2/ACRESET
B8
DMAREQ3
C8
DATA0
N3
DATA1
N1
DATA2
P1
DATA3
R2
DATA4
T5
DATA5
T2
DATA6
U2
DATA7
V5
DATA8
W1
DATA9
Y4
DATA10
Y1
DATA11
AA2
DATA12
AB4
DATA13
AB2
DATA14
AC1
DATA15
AE1
DATA16
AF21
DATA17
AD22
DATA18
AF22
DATA19
AF24
DATA20
AE25
DATA21
AD26
DATA22
AC26
DATA23
AA22
DATA24
AA25
DATA25
Y23
DATA26
Y25
DATA27
W25
DATA28
V23
DATA29
V26
DATA30
T22
DATA31
T25
DATA32
N2
DATA33
P3
DATA34
R3
DATA35
R1
DATA36
T3
DATA37
U3
DATA38
U1
DATA39
W2
DATA40
Y5
DATA41
Y2
DATA42
AA5
DATA43
AA1
DATA44
AB3
DATA45
AB1
DATA46
AD2
DATA47
AF2
DATA48
AC22
DATA49
AE22
DATA50
AD24
DATA51
AF25
DATA52
AD25
DATA53
AC25
DATA54
AB25
DATA55
AA24
DATA56
AA26
DATA57
Y24
DATA58
Y26
DATA59
W26
DATA60
V25
DATA61
U25
DATA62
T23
DATA63
N25
SDCLK0 AF14
SDCLK1 AF19
SDCLK2 AF13
SDCLK3 AF17
RAS AE7
CAS AF4
DQM0 AB6
DQM1 AE6
DQM2 AC18
DQM3 AE19
DQM4 AD6
DQM5 AF6
DQM6 AD18
DQM7 AB20
SDCS0 AC7
SDCS1 AD7
SDCS2 AE17
SDCS3 AB18
WE AE5
CKE AD17
ADDR0 AF7
ADDR1 AE8
ADDR2 AF8
ADDR3 AB9
ADDR4 AE9
ADDR5 AD10
ADDR6 AE10
ADDR7 AB11
ADDR8 AC11
ADDR9 AE11
ADDR10 AD12
ADDR11 AF12
ADDR12 AD13
ADDR13 AE13
ADDR14 AD14
ADDR15 AD15
ADDR16 AE15
ADDR17 AB16
ADDR18 AD16
ADDR19 AE16
ACK/REDY C4
SYSCLK L1
SWE A3
OE M1
CE0 D7
CE1 C7
CE2 C6
CE3 B6
CE4 A6
CE5 A5
CE6 B4
CE7 A4
ACE C5
BUSSPRT B3
BWE0 BE0/A9
BWE1 BE1/A10
BWE2 BE2/B10
BWE3 BE3/C10
DMAACK0 D11
DMAACK1 A8
SYNC/DMAACK2 A7
DMAACK3 B7
DMADONE
E9
TX4927/TX4937 2/5
BR22
33
1
2
3
45
6
7
8
R268 4.7K NOASM
C3
68pF
R275 4.7K NOASM
R58 4.7K
R267 4.7K NOASM
R264 4.7K NOASM
R68 33
NOASM
BR28
33
1
2
3
45
6
7
8
TP1
1
TPAD11
1
TPAD14
1
R59 33
R67 33
BR17
33
1
2
3
45
6
7
8
BR10
33
1
2
3
45
6
7
8
R266 4.7K NOASM
TP366
R41 4.7K
LACE
CE5
BWE_BEA3
CE1
ACK_READY
SDCS2
CE2
CE4
BWE_BEA2
SDCS0
SDCS1
CE6
DMAACK3
RAS
CE3
BWE_BEA1
BUSSPRT
DMAACK0
DMAACK1
WE
CE7
DMAACK2
CAS
CE0
BWE_BEA0
SDCLK1A
SDCLK0A
SDCLK2A
SDCLK0A
SDCLK2A
SDCS1
SDCS2
SDCS0
CKE
DQM3
DQM1
DATA54
DATA51
DATA38
DATA30
DATA30
DATA20
DATA19
DATA18
DATA13
DATA10
DATA2
DATA51
DATA28
DATA7
DATA63
DATA53
DATA49
DATA43
DATA29
DATA21
DATA16
DATA43
DATA42
DATA32
DATA15
DATA5
DATA7
DATA16
DATA47
DATA34
DATA25
DATA4
DATA1
DATA44
DATA57
DATA49
DATA56
DATA41
DATA46
DATA35
DATA33
DATA23
DATA11
DATA9
DATA5
DATA1
DATA33
DATA9
DATA55
DATA12
DATA8
DATA6
DATA32
DATA24
DATA61
DATA25
DATA60
DATA40
DATA0
DATA36
DATA15
DATA23
DATA8
DATA45
DATA52
DATA29
DATA4
DATA17
DATA31
DATA59
DATA22
DATA22
DATA7
DATA21
DATA48
DATA24
DATA46
DATA37
DATA62
DATA18
DATA13
DATA2
DATA17
DATA19
DATA10
DATA27
DATA47
DATA50
DATA34
DATA26
DATA41
DATA31
DATA12
DATA3
DATA3
DATA42
DATA44
DATA58
DATA36
DATA28
DATA39
DATA45
DATA[63:0]
DATA38
DATA1
DATA11
DATA39
DATA14
DATA6
DATA40
DATA37
DATA0
DATA20
DATA27
DATA26
DATA35
DATA14
DATA48
DATA50
DATA53
DATA55
DATA52
DATA54
DATA57
DATA59
DATA56
DATA58
DATA61
DATA63
DATA60
DATA62
MEMD0
MEMD2
MEMD1
MEMD3
MEMD4
MEMD6
MEMD5
MEMD7
MEMD8
MEMD9
MEMD10
MEMD11
MEMD15
MEMD13
MEMD14
MEMD12
MEMD16
MEMD18
MEMD17
MEMD19
MEMD23
MEMD21
MEMD20
MEMD22
MEMD27
MEMD25
MEMD26
MEMD24
MEMD28
MEMD30
MEMD29
MEMD31
MEMD32
MEMD34
MEMD33
MEMD35
MEMD36
MEMD38
MEMD37
MEMD39
MEMD40
MEMD42
MEMD41
MEMD43
MEMD44
MEMD46
MEMD45
MEMD47
MEMD50
MEMD48
MEMD51
MEMD49
MEMD54
MEMD52
MEMD55
MEMD53
MEMD58
MEMD56
MEMD59
MEMD57
MEMD62
MEMD60
MEMD63
MEMD61
MEMA4
MEMA11
MEMA2
MEMA9
MEMA7
MEMA8
MEMA3
MEMA5
MEMA6
MEMA10
MEMA1
MEMA0
MEMA15
MEMA13
MEMA14
MEMA12
MEMA19
MEMA16
MEMA17
MEMA18
ADDR5
ADDR9
ADDR[19:0]
ADDR11
ADDR1
ADDR7
ADDR11
ADDR13
ADDR14
ADDR4
ADDR6
ADDR15
ADDR4
ADDR7
ADDR1
ADDR0
ADDR2
ADDR13
ADDR2
ADDR6
ADDR16
ADDR1
ADDR11
ADDR10
ADDR8
ADDR14
ADDR2
ADDR3
ADDR5
ADDR18
ADDR7
ADDR18
ADDR0
ADDR0
ADDR16
ADDR12
ADDR17
ADDR4
ADDR8
ADDR6
ADDR3
ADDR10
ADDR5
ADDR19
ADDR3
ADDR9
ADDR8
ADDR10
ADDR9
ADDR13
ADDR15
ADDR12
ADDR14
ADDR18
ADDR17
ADDR16
ADDR19
DQM7 SDDQM7
SDDQM6
SDDQM3
SDDQM2
DQM5 SDDQM5
SDDQM4
SDDQM0
SDDQM1
DQM0
DQM0
DQM1
DQM2
DQM2
DQM3
DQM4
DQM4
DQM5
DQM6
DQM6
DQM7
DMAREQ0
DMAREQ0
DMAREQ3
DMAREQ2
DMAREQ1
DMAREQ2
DMAREQ3
DMAREQ1
DQM7
DQM2
DQM6
DQM1
DQM5
DQM3
DQM4
DQM0
SDCLK1A
SDCLK3A
SDCLK3A
CE1
CE5
CE3
CE0
CE2
CE4
CE6
ACE
SYSCLKA
OE
SWE
VCCIO
ROMWE 6,15
ROMOE 6,15
ROMCS0 7,15
ROMCS1 7,15
ROMCS2 7,15
ALE 6,15
SDCLK2 5,16
SDWE 5,15
SDCLK0 5,16
SDRCS2 5,15
SDRCS1 5,15
SYSCLK 15
MEMDIR 6,15
SDCKE 5,15
SDRAS 5,15
SDCAS 5,15
SDCLK1 5,16
ROMCS3 7,15
ROMCS5 7
ROMCS6 7
ROMCS4 7,15
SDRCS0 5,15
ADDR[19:0] 16
DMAREQ[3:0] 16
SDCLK0A 16
SDCLK1A 16
SDCLK2A 16
SDCLK3A 16
SDCS2 16
SDCS1 16
SDCS0 16
WE 16
BUSSPRT 16
CAS 16
CKE 16
ACE 16
RAS 16
MEMA[19:0] 5,6,16
DATA[63:0] 16
MEMD[63:0]5,6,16
SDDQM[7:0] 5,15
DQM[7:0] 16
CE[6:0] 16
LACE 16
SWE 16
SYSCLKA 16
OE 16
ADDR*/DATA*
DATA[7]
ADDR[14:13]
R*-*
R38
R39-40
FUNCTION
ASM : Internal Timer Interrupt Disable
NOASM : Internal Timer Interrupt Enable
Default
ASM
NOASM/ASM
Setting Table
ASM/ASM : SYSCLK = G-BUSCLK/4
ASM/NOASM : SYSCLK = G-BUSCLK/3
NOASM/ASM : SYSCLK = G-BUSCLK/2
NOASM/NOASM : SYSCLK = G-BUSCLK
ADDR[2:0] R42-44
NOASM/NOASM/NOASM : MASTERCLK : CPUCLK = 1 : 2
NOASM/NOASM/ASM : MASTERCLK : CPUCLK = 1 : 2.5
NOASM/ASM/NOASM : MASTERCLK : CPUCLK = 1 : 3
NOASM/ASM/ASM : MASTERCLK : CPUCLK = 1 : 4
ASM/NOASM/NOASM : MASTERCLK : CPUCLK = 1 : 8
ASM/NOASM/ASM : MASTERCLK : CPUCLK = 1 : 10
ASM/ASM/NOASM : MASTERCLK : CPUCLK = 1 : 12
ASM/ASM/ASM : MASTERCLK : CPUCLK = 1 : 16
ASM/NOASM/NOASM
5
5
4
4
3
3
21
21
D D
C C
B B
A A
3/16
GA-1330 ELECTRICAL SECTION 7 - 4
TP418
R242 33
R245 33
R243 33
TP632
C6 1000pF
C45
0.1uF
R244 33
L1 BLM41P600S
12
C46
0.1uF
BR37
33
1
2
3
45
6
7
8
TP633
C11
6pF
NO ASM
IC1C
TMPR4927/4937
LOCK
C23
EEPROM_DI
A11
PCICLKIN
P26
PCIAD0 B17
PCIAD1 C17
PCIAD2 A18
PCIAD3 B18
PCIAD4 D18
PCIAD5 A19
PCIAD6 B19
PCIAD7 C19
PCIAD8 B20
PCIAD9 C20
PCIAD10 E20
PCIAD11 A21
PCIAD12 B21
PCIAD13 C21
PCIAD14 E21
PCIAD15 A22
PCIAD16 C26
PCIAD17 C25
PCIAD18 D26
PCIAD19 E26
PCIAD20 E25
PCIAD21 E24
PCIAD22 E23
PCIAD23 F26
PCIAD24 G26
PCIAD25 G25
PCIAD26 G24
PCIAD27 G23
PCIAD28 G22
PCIAD29 H24
PCIAD30 J24
PCIAD31 J22
C_BE0
A20
C_BE1
B22
C_BE2
A26
C_BE3
F23
PAR
C22
FRAME
B25
IRDY
A25
TRDY
D24
STOP
B24
ID_SEL
F24
DEVSEL
C24
REQ0
K25
REQ1/INTOUT
L22
REQ2
L24
REQ3
M24
GNT0
J25
GNT1
K24
GNT2
L25
GNT3
M25
PERR
B23
SERR
D22
M66EN
D20
PME N22
EEPROM_DO A12
EEPROM_CS A15
EEPROM_SK A14
PCICLK0 H26
PCICLK1 J26
PCICLK2 K26
PCICLK3 L26
PCICLK4 M26
PCICLK5 N26
TX4927/TX4937 3/5
BR30
33
1
2
3
45
6
7
8
R87 10K
R70 10
TP634
R90 56
TPAD21
1
TP412
TPAD20 1
C12
0.1uF
C27
0.1uF
BR39
33
1
2
3
45
6
7
8
C4 10uF
TP397
ICT31
TP361
C29
0.1uF
TPAD19 1
TP661
L3 BLM41P600S
12
R79 8.2K
C30
0.1uF
TP364
R230 33
C31
0.1uF
R72 10
C25
0.1uF
R78 8.2K
R71 10
R91 56
R231 33
BR41
33
1
2
3
45
6
7
8
C26
0.1uF
C14
0.1uF
C24
0.1uF
C7 1000pF
R94 56
R81 8.2K
TP413 TP631
R232 33
TP406
C28
0.1uF
C9 10uF
R95 56
TP371
R233 33
C32
0.1uF
TP414
TP409
R83 8.2K
C15
0.1uF
C35
0.1uF
C13
0.1uF
R96 120
TP363
BR42
33
1
2
3
45
6
7
8
R73 10
R234 33
TP411
C8 0.1uF
R84 8.2K
L4 BLM41P600S
12
R237 33
BR32
33
1
2
3
45
6
7
8
TP417
TP370
C36
0.1uF
L2 BLM41P600S
12
R235 33
TP416
R85 8.2K
TP3
1
R236 33
C33
0.1uF
R88 0
C34
0.1uF
TP407
C16
0.1uF
R82 8.2K
R74 10
C214
10uF
C19
0.1uF
R86 33
C215
10uF
C17
0.1uF
C18
0.1uF
TP408
IC1D
TMPR4927/4937
PLL1VDD_A
R24 PLL1VSS_A R25
PLL2VDD_A
P24 PLL2VSS_A P25
VDDIO
A24
VDDIO
B5
VDDIO
C3
VDDIO
C9
VDDIO
C18
VDDIO
D12
VDDIO
D14
VDDIO
D16
VDDIO
D19
VDDIO
D21
VDDIO
D25
VDDIO
E4
VDDIO
E7
VDDIO
F22
VDDIO
F25
VDDIO
H4
VDDIO
H25
VDDIO
M3
VDDIO
M23
VDDIO
N5
VDDIO
N23
VDDIO
P5
VDDIO
R4
VDDIO
T4
VDDIO
T24
VDDIO
U24
VDDIO
V3
VDDIO
V4
VDDIO
V22
VDDIO
W23
VDDIO
Y22
VDDIO
AA3
VDDIO
AB7
VDDIO
AB23
VDDIO
AC5
VDDIO
AC8
VDDIO
AC9
VDDIO
AC13
VDDIO
AC14
VDDIO
AC15
VDDIO
AD1
VDDIO
AE2
VDDIO
AC16
VDDIO
AE21
VDDIO
AE24
VDDIO
AE26
VDDIO
AF9
VDDIO
AF11
VDDIO
AF20
VDDIO
AF23
VDDIN
D4
VDDIN
D8
VDDIN
D10
VDDIN
D15
VDDIN
D17
VDDIN
D23
VDDIN
F5
VDDIN
G5
VDDIN
H23
VDDIN
K4
VDDIN
K23
VDDIN
M4
VDDIN
P22
VDDIN
R23
VDDIN
U4
VDDIN
U23
VDDIN
W4
VDDIN
AC4
VDDIN
AC10
VDDIN
AC12
VDDIN
AC17
VDDIN
AC19
VDDIN
AC23
VSS A13
VSS A23
VSS B26
VSS D2
VSS D6
VSS D9
VSS E5
VSS E8
VSS E10
VSS E12
VSS E15
VSS E17
VSS E18
VSS E19
VSS E22
VSS H5
VSS H22
VSS J23
VSS K5
VSS K22
VSS L23
VSS M5
VSS M22
VSS N4
VSS N24
VSS P2
VSS P4
VSS R5
VSS R22
VSS T1
VSS T26
VSS U5
VSS U22
VSS U26
VSS V1
VSS V2
VSS V24
VSS W3
VSS W5
VSS W22
VSS W24
VSS Y3
VSS AA4
VSS AA23
VSS AB5
VSS AB8
VSS AB10
VSS AB12
VSS AB13
VSS AB14
VSS AB15
VSS AB17
VSS AB19
VSS AB22
VSS AB24
VSS AB26
VSS AC2
VSS AC3
VSS AC6
VSS AC21
VSS AC24
VSS AD4
VSS AD5
VSS AD8
VSS AD9
VSS AD11
VSS AD19
VSS AD20
VSS AD23
VSS AE12
VSS AE14
VSS AE18
VSS AE23
VSS AF1
VSS AF5
VSS AF10
VSS AF16
VSS AF18
VSS AF26
TX4927/TX4937 4/5
C38
0.1uF
BR29
10K
1
2
3
45
6
7
8
R80 8.2K
BR31
33
1
2
3
45
6
7
8
C20
0.1uF
C21
0.1uF
R75 10
C43
0.1uF
C39
0.1uF
R238 33
TP369 IC1E
TMPR4927/4937
VSS
K10
VSS
K11
VSS
K12
VSS
K13
VSS
K14
VSS
K15
VSS
K16
VSS
K17
VSS
L10
VSS
L11
VSS
L12
VSS
L13
VSS
L14
VSS
L15
VSS
L16
VSS
L17
VSS
M10
VSS
M11
VSS
M12
VSS
M13
VSS
M14
VSS
M15
VSS
M16
VSS
M17
VSS
N10
VSS
N11
VSS
N12
VSS
N13
VSS
N14
VSS
N15
VSS
N16
VSS
N17
VSS P10
VSS P11
VSS P12
VSS P13
VSS P14
VSS P15
VSS P16
VSS P17
VSS R10
VSS R11
VSS R12
VSS R13
VSS R14
VSS R15
VSS R16
VSS R17
VSS T10
VSS T11
VSS T12
VSS T13
VSS T14
VSS T15
VSS T16
VSS T17
VSS U10
VSS U11
VSS U12
VSS U13
VSS U14
VSS U15
VSS U16
VSS U17
TX4927/TX4937 5/5
C23
0.1uF
R241 33
C22
0.1uF
R239 33
R76 10
C41
0.1uF
R240 33
BR33
33
1
2
3
45
6
7
8
C42
0.1uF
C37
0.1uF
TP415
C40
0.1uF
TP365
R89 0
TP393
C44
0.1uF
C47
0.1uF
TP410
C5 0.1uF
TP390 BR35
33
1
2
3
45
6
7
8
C48
0.1uF
TP362
R77 10
PCIAD0
PCIAD2
PCIAD1
PCIAD3
PCIAD7
PCIAD5
PCIAD4
PCIAD6
PCIAD11
PCIAD10
PCIAD9
PCIAD8
PCIAD15
PCIAD13
PCIAD14
PCIAD12
PCIAD19
PCIAD16
PCIAD18
PCIAD17
PCIAD23
PCIAD22
PCIAD20
PCIAD21
PCIAD26
PCIAD24
PCIAD27
PCIAD25
PCIAD30
PCIAD31
PCIAD29
PCIAD28
PCIADA4
PCIADA30
PCIADA20
PCIADA5
PCIADA7
PCIADA16
PCIADA19
PCIADA31
PCIADA3
PCIADA12
PCIADA0
PCIADA11
PCIADA21
PCIADA25
PCIADA27
PCIADA18
PCIADA26
PCIADA6
PCIADA29
PCIADA10
PCIADA13
PCIADA9
PCIADA28
PCIADA15
PCIADA2
PCIADA17
PCIADA1
PCIADA24
PCIADA14
PCIADA22
PCIADA8
PCIADA23
PCIADA3
PCIADA1
PCIADA2
PCIADA0
PCIADA6
PCIADA4
PCIADA5
PCIADA7
PCIADA8
PCIADA9
PCIADA10
PCIADA11
PCIADA12
PCIADA14
PCIADA13
PCIADA15
PCIADA17
PCIADA18
PCIADA16
PCIADA19
PCIADA21
PCIADA20
PCIADA22
PCIADA23
PCIADA25
PCIADA27
PCIADA24
PCIADA26
PCIADA28
PCIADA29
PCIADA31
PCIADA30
PCIBE0
PCIBE1
PCIBE2
PCIBE3 PCIBEA3
PCIBEA1
PCIBEA1
PCIBEA2
PCIBEA0
PCIBEA3
PCIBEA0
PCIBEA2
VCCIO
VCCINT
PVDD1
PVDD2
VCCIO
VCCINT VCCINT
VCCIO
VCCIO
VCCIO
PCIBE[3:0]9,10,11
PTRDY9,10,11
PCIREQ110,15
PCIREQ29,15
PDEVSEL9,10,11
PPERR9,10,11
PCIGNT110,15
PME 10,11,16
PIRDY9,10,11
PCIGNT011 , 15
PFRAME9,10,11
PSTOP9,10,11
PSERR9,10,11 PCIGNT29,15
PPAR9,10,11
PCIREQ011, 1 5
PLOCK9
PCICLK2 9
PCICLK0 11,16
PCICLK1 10,16
PCIBEA[3:0] 16
PCIAD[31:0] 9,10,11
PCIADA[31:0] 16
PVSS1PVSS2
MAIN PWB (TMPR4927TB_3)
5
5
4
4
3
3
21
21
D D
C C
B B
A A
4/16
GA-1330 ELECTRICAL SECTION 7 - 5
TP553
C60
0.1uF
C61
0.1uF
C49
0.1uF
C51
0.1uF
C56
0.1uF
C57
0.1uF
IC5
NT5SV16M16BS-75B
A0
23
A1
24
A2
25
A3
26
A4
29
A5
30
A6
31
A7
32
A8
33
A9
34
A10/AP
22
A11
35
QD0 2
QD1 4
QD2 5
QD3 7
QD4 8
QD5 10
QD6 11
QD7 13
QD8 42
QD9 44
QD10 45
QD11 47
QD12 48
QD13 50
QD14 51
QD15 53
VCCQ 3
VCCQ 9
VCCQ 43
VCCQ 49
VSSQ 6
VSSQ 12
VSSQ 46
VSSQ 52
CAS# 17
RAS# 18
CS# 19
WE# 16
CLK
38
CKE
37
UDQM
39
LDQM
15
BS0
20
BS1
21
VCC
1
VCC
14
VCC
27
VSS
28
VSS
41
VSS
54
A12
36
NC
40
C50
0.1uF
IC6
NT5SV16M16BS-75B
A0
23
A1
24
A2
25
A3
26
A4
29
A5
30
A6
31
A7
32
A8
33
A9
34
A10/AP
22
A11
35
QD0 2
QD1 4
QD2 5
QD3 7
QD4 8
QD5 10
QD6 11
QD7 13
QD8 42
QD9 44
QD10 45
QD11 47
QD12 48
QD13 50
QD14 51
QD15 53
VCCQ 3
VCCQ 9
VCCQ 43
VCCQ 49
VSSQ 6
VSSQ 12
VSSQ 46
VSSQ 52
CAS# 17
RAS# 18
CS# 19
WE# 16
CLK
38
CKE
37
UDQM
39
LDQM
15
BS0
20
BS1
21
VCC
1
VCC
14
VCC
27
VSS
28
VSS
41
VSS
54
A12
36
NC
40
C52
0.1uF
C62
0.1uF
C58
0.1uF
C59
0.1uF
C53
0.1uF
C54
0.1uF
C55
0.1uF
CN2
DM-3B1-N1210
VSS 1
VSS 2
DQ0 3
DQ1 5
DQ2 7
DQ3 9
DQ4 13
DQ5 15
DQ6 17
DQ7 19
VSS 21
VSS 22
DQM0
23
DQM4
24
DQM1
25
DQM5
26
A0
29
A3
30
A1
31
A4
32
A2
33
A5
34
VSS 35
VSS 36
DQ8 37
DQ9 39
DQ10 41
DQ11 43
DQ12 47
DQ44 48
DQ13 49
DQ45 50
DQ14 51
DQ46 52
DQ15 53
DQ47 54
VSS 55
VSS 56
CLK0
61
CKE0
62
RAS
65
CAS
66
WE
67
CKE1
68
CS0
69
CS1
71
CLK1
74
VSS 75
VSS 76
DQ48 84
DQ49 86
DQ50 88
DQ51 90
VSS 91
VSS 92
DQ52 94
DQ53 96
DQ54 98
DQ55 100
BA0
106
VSS 107
VSS 108
BA1
110
DQM2
115
DQM6
116
DQM3
117
DQM7
118
VSS 119
VSS 120
VSS 139
VSS 140
SDA
141
SCL
142
DQ32 4
DQ33 6
DQ34 8
DQ35 10
DQ36 14
DQ37 16
DQ38 18
DQ39 20
DQ40 38
DQ41 40
DQ42 42
DQ43 44
DQ16 83
DQ17 85
DQ18 87
DQ19 89
DQ20 93
DQ21 95
DQ22 97
DQ23 99
DQ24 121
DQ25 123
DQ26 125
DQ27 127
DQ28 131
DQ29 133
DQ30 135
DQ31 137
DQ56 122
DQ57 124
DQ58 126
DQ59 128
DQ60 132
DQ61 134
DQ62 136
DQ63 138
A6
103
A7
104
A8
105
A9
109
A10/AP
111
A11
112
A12
70
A13
72
DU
73
NC
57
NC
58
NC
59
NC
60
NC
77
NC
78
NC
79
NC
80
VDD
11
VDD
12
VDD
27
VDD
28
VDD
45
VDD
46
VDD
63
VDD
64
VDD
81
VDD
82
VDD
101
VDD
102
VDD
113
VDD
114
VDD
129
VDD
130
VDD
143
VDD
144
C208
10uF
C209
10uF
C210
10uF
TP552
MEMD27
MEMD15
MEMD14
MEMD18
MEMD6
MEMD25
MEMD31
MEMD16
MEMD29
MEMD20
MEMD5
MEMD17
MEMD15
MEMD27
MEMD31
MEMD30
MEMD1
MEMD24
MEMD11
MEMD28
MEMD19
MEMD2
MEMD6
MEMD11
MEMD12
MEMD28
MEMD29
MEMD5
MEMD10
MEMD10
MEMD3
MEMD4
MEMD17
MEMD21
MEMD26
MEMD26
MEMD22
MEMD20
MEMD25
MEMD23
MEMD19
MEMD0
MEMD2
MEMD21
MEMD24
MEMD1
MEMD8
MEMD23
MEMD3
MEMD12
MEMD18
MEMD14
MEMD4
MEMD13
MEMD16
MEMD9
MEMD7
MEMD9
MEMD30
MEMD7
MEMD0
MEMD8
MEMD13
MEMD22
MEMD33
MEMD63
MEMD46
MEMD60
MEMD38
MEMD62
MEMD44
MEMD37
MEMD35
MEMD58
MEMD59
MEMD48
MEMD54
MEMD45
MEMD55
MEMD34
MEMD53
MEMD49
MEMD40
MEMD42
MEMD51
MEMD56
MEMD57
MEMD32
MEMD39
MEMD50
MEMD41
MEMD36
MEMD43
MEMD61
MEMD52
MEMD47
SDDQM0
SDDQM2
SDDQM3
SDDQM1
MEMA19
SDDQM7
MEMA11
MEMA12
MEMA5
SDDQM3
MEMA17
MEMA9
MEMA15
MEMA10
MEMA17
MEMA6
SDDQM0
MEMA7
MEMA19
MEMA12
MEMA6
MEMA7
SDDQM2
MEMA9
MEMA16
MEMA14
MEMA13
MEMA5
MEMA8
MEMA9
MEMA11
SDDQM1
MEMA19
MEMA13
MEMA14
MEMA12
MEMA10
MEMA13
MEMA5
MEMA16
MEMA18
SDDQM6
MEMA8
MEMA15
MEMA6
MEMA17
MEMA11
SDDQM5
SDDQM4
MEMA7
MEMA15
MEMA16
MEMA14
MEMA18
MEMA18
MEMA8 MEMA10
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
VCCIO
MEMA[19:0]3,6,16
SDDQM[7:0]3,15
SDWE3,15
SDRCS23,15
SDCAS3,15
SDRAS3,15
SDCLK23,16
SDCKE3,15
MEMD[63:0] 3,6,16
SDCLK13,16
SDRCS03,15
DIMM_SCK2,16
DIMM_SDA2,16
SDCLK03,16
SDRCS13,15
<On Board : 256Mbit x 2> <SDRAM_SODIMM Slot[0]>
MAIN PWB (SDRAM)
5
5
4
4
3
3
21
21
D D
C C
B B
A A
5/16
Other manuals for GA-1330
1
Table of contents
Other Toshiba Scanner manuals
