Toshiba Aquilion TSX-101A/I Series Technical manual

No. 2A201-519EN*A
©TOSHIBA MEDICAL SYSTEMS CORPORATION 2005-2006
ALL RIGHTS RESERVED
SITE PLANNING MANUAL
FOR
TOSHIBA SCANNER
MODEL TSX-101A
(2A201-519EN*A)

No. 2A201-519EN*A
Trademarks
Aquilion is a trademark of Toshiba Medical Systems Corporation.
This manual may include trademarks and registered trademarks of other companies.
Note that the ™mark and the ®mark are not used in this manual.
IMPORTANT!
1. No part of this manual may be copied or reprinted, in whole or in part,
without written permission.
2. The contents of this manual are subject to change without prior notice
and without our legal obligation.
3. The contents of this manual are correct to the best of our knowledge.
Please inform us of any ambiguous or erroneous descriptions, missing
information, etc.

No. 2A201-519EN*A
3
REVISION RECORD
REV. DATE REASON PAGE SER. DOC.
(MM/YY) /AUTHOR CHANGED No. PRODUCT.
INI. 07/'05 Mr. Shinno ------- KD-WPX
*A 03/'06 Addition of grounding for 72-kW
system transformer Mr. Mizuno
P. 37

No. 2A201-519EN*A
4
Safety Precautions
1. Meaning of Signal Words
In this manual, the signal words DANGER, WARNING, and CAUTION are used to indicate
safety and other important instructions. The signal words and their meanings are defined as follows.
Please understand their meanings clearly before reading this manual.
Signal word Meaning
DANGER Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury.
CAUTION Indicates a potentially hazardous situation which, if not avoided, may result in
property damage.
In addition to the above, the signal word NOTE is used to indicate other important information.
NOTE Indicates reference information that enables more efficient use of the equipment.

No. 2A201-519EN*A
5
2. Safety Precautions
Please observe the following precautions to ensure the safety of the service engineer as well as
operators when servicing this equipment. For detailed information about each precaution, refer to the
main body of this manual.
CAUTION: 1. If the system transformer is installed beside the console, adequate distance
must be kept between them. Otherwise, the displayed images may be
adversely affected.
2. In general, the scanning room must be provided with an independent air
conditioning system.
Even if the room is maintained within the permissible temperature range,
gradual temperature shifts (for example, a slow increase in room
temperature from morning to evening) may adversely affect system
performance.
3. The air conditioning system in the scanning room must be installed so that
the CT system is not exposed to direct airflow. Failure to do so may cause
the temperature inside the CT system to fluctuate, possibly affecting the
displayed images adversely.
CAUTION: 1. An independent power supply must be provided for this system at the cubicle output
stage. Otherwise, this system may adversely affect other facilities or equipment.
2. Use only noise filters manufactured by Toshiba. The noise filter of this system is
designed taking into account extreme phenomena such as lightning. If a noise filter
made by a manufacturer other than Toshiba is used, the system may not be protected
adequately.
3. Although two different hardeners are available for the epoxy resin (winter-use hardener
and summer-use hardener), the winter-use hardener must be used.
The summer-use hardener is not suitable for work in hospitals or clinics because it
requires a long hardening time and, in some cases, the application of heat may be
necessary to achieve hardening.
4. Observe the following precautions when applying epoxy resin during floor-leveling work.
•Good ventilation must be provided since the epoxy resin is a volatile chemical.
•This job must be performed with a plastic floor-covering sheet laid on the floor.
•Gloves, eye protection, etc. must be worn when handling the resin.
•Before mixing the liquid agents, they must be accurately weighed using an oil
replenishment container.
•The oil replenishment container that has been used for weighing must not be used to
apply the resin.

No. 2A201-519EN*A
6
CONTENTS
Page
Safety Precautions --------------------------------------------------------------------------------------------------------------- 4
1. SCOPE----------------------------------------------------------------------------------------------------------------------- 8
2. APPLICATION-------------------------------------------------------------------------------------------------------------- 8
3. SYSTEM COMPOSITION ----------------------------------------------------------------------------------------------- 8
4. MAIN SPECIFICATIONS FOR SITE PLANNING------------------------------------------------------------------ 9
5. SPACE REQUIREMENTS ---------------------------------------------------------------------------------------------13
5.1 Scanning Room --------------------------------------------------------------------------------------------------13
5.2 Scan Control Room ---------------------------------------------------------------------------------------------15
5.3 Layout --------------------------------------------------------------------------------------------------------------16
5.4 Maintenance Space ---------------------------------------------------------------------------------------------18
5.5 System Operating Environment and EMC-----------------------------------------------------------------19
6. CLASSIFICATION OF INSTALLATION-RELATED WORK ----------------------------------------------------20
6.1 Scope of Work to Be Executed by the Customer --------------------------------------------------------20
6.2 Scope of Work to Be Executed by Toshiba ---------------------------------------------------------------20
7. BUILDING CONSTRUCTION WORK -------------------------------------------------------------------------------21
7.1 Entrance Used to Bring-in the Unit --------------------------------------------------------------------------21
7.2 X-ray Shielding in the Scanning Room ---------------------------------------------------------------------22
7.3 Support -------------------------------------------------------------------------------------------------------------22
7.4 Floor Structure of the Scanning Room ---------------------------------------------------------------------22
7.4.1 Floor-leveling work using epoxy resin----------------------------------------------------------22
7.4.1.1 Tools and materials required -----------------------------------------------------23
7.4.1.2 Application area ---------------------------------------------------------------------24
7.4.1.3 Work procedures --------------------------------------------------------------------26
7.5 Wiring Pits and Wall Ducts ------------------------------------------------------------------------------------30
7.5.1 Pit and duct sizes -----------------------------------------------------------------------------------30
7.5.2 Partitions in the pit and duct ----------------------------------------------------------------------30
7.5.3 Precautions -------------------------------------------------------------------------------------------31
7.5.4 Pit layout example ----------------------------------------------------------------------------------32

No. 2A201-519EN*A
7
CONTENTS - continued
Page
8. ELECTRICAL WORK----------------------------------------------------------------------------------------------------33
8.1 Electrical Equipment --------------------------------------------------------------------------------------------33
8.1.1 Electrical specification------------------------------------------------------------------------------33
8.1.2 Power transformer and power distribution ----------------------------------------------------34
8.1.2.1 Power transformer and power distribution cabling --------------------------34
8.1.2.2 Grounding for power transformer and hospital power supply ------------37
8.1.3 Ground fault interrupter ----------------------------------------------------------------------------38
8.1.3.1 Leakage current ---------------------------------------------------------------------38
8.1.3.2 Countermeasures -------------------------------------------------------------------39
8.1.4 Voltage regulation-----------------------------------------------------------------------------------40
8.1.5 Countermeasures against high-frequency electromagnetic radiation ------------------40
8.2 Power Distribution Board --------------------------------------------------------------------------------------41
8.3 Grounding ---------------------------------------------------------------------------------------------------------41
8.4 Electrical Equipment --------------------------------------------------------------------------------------------42
8.5 Illumination --------------------------------------------------------------------------------------------------------42
8.6 Cable Connections Between the Units ---------------------------------------------------------------------42
8.7 Installing a Public Telephone Line Jack for InnerVision ------------------------------------------------49
9. AIR CONDITIONING/WATER SUPPLY AND DRAINAGE WORKS-----------------------------------------50
9.1 Air Conditioning --------------------------------------------------------------------------------------------------50
9.2 Water Supply and Drainage-----------------------------------------------------------------------------------51
10. OUTLINE DRAWINGS --------------------------------------------------------------------------------------------------51
A. APPENDIX -----------------------------------------------------------------------------------------------------------------62
A.1 HANDLING EMC-------------------------------------------------------------------------------------------------62
A.1.1 Effects of EMI noise and countermeasures---------------------------------------------------62
A.1.2 Influence of static electricity and required countermeasures -----------------------------65

No. 2A201-519EN*A
8
1. SCOPE
This document applies to the Toshiba scanner Aquilion model TSX-101A.
Model Type Standard patient couch*1
TSX-101A/I series 32-slice system CBTB-019A or CBTB-019B
TSX-101A/H series 64-slice system CBTB-019A or CBTB-019B
*1: The patient couch used in combination depends on the system model.
2. APPLICATION
This document describes site planning requirements to ensure optimal performance. It also
describes necessary site facilities and outlines the range of responsibilities during installation work.
3. SYSTEM COMPOSITION
(1) Standard composition
Gantry (X-ray high-voltage generator mounted type) 1 set
Patient couch 1 set
Console (CPU chassis (CPU BOX, REC BOX), monitors×2, keyboards×2, mice×2) 1 set
Accessories 1 set
Operation manual 1 set
(2) Miscellaneous
Desks, such as for the console and patient observation system, and chairs are not included in
the system configuration.
The desks and chairs selected should meet the requirements below.
(a) Desk
Height : 800 mm (When the CPU BOX is installed under the desk, a height of more
than 700 mm is required under the desk.)
Width : 1600 mm
Depth : 800 mm
(b) Chair
Seat height : The range from 500 to 550 mm should be covered.
High stability (5 legs)
With footrest or foot bar

No. 2A201-519EN*A
9
4. MAIN SPECIFICATIONS FOR SITE PLANNING
(1) Classification of the equipment
Class of protection against electric shock Class I
Type of protection against electric shock Type B
Level of protection against the ingress of
water
Normal equipment (IPX0)
Type of safety when used in an environment
where flammable gas mixtures with air or
flammable anesthetic mixtures with oxygen
or nitrous oxide are present
Equipment that should not be used in an
environment where flammable gas mixtures
with air or flammable anesthetic mixtures
with oxygen or nitrous oxide are present
Classification based on the operating mode Continuous operation with intermittent load
(2) X-ray specifications
Pattern and type of X-rays : Fan beam, continuous X-rays
X-ray tube voltage : 80, 100, 120, 135 kV (±3%)
X-ray tube current : 10 mA to 50 mA (±3 mA)
50 mA to 500 mA (±5%)
50 mA to 600 mA (±5%)*1
Scan time : (0.32), 0.5, 0.75, 1.0, 1.5, 2.0, 3.0 s
(0.32 s is for half scan)
*1: When high-power X-ray generator kit (option) is incorporated
(3) X-ray tube leakage dose
X-ray tube leakage dose : 1.0 mGy or less per hour
(or 2.58 ×10-5 C/kg·H [100 mR] or less)
X-ray beam shielding lead equivalent : 2.4 mmPb or more
X-ray tube inherent filtration : 1.0 mm Al equivalent or more
Inherent filtration other than the X-ray tube : Minimum 1.5 mm Al equivalent
(4) Power supply requirements (for standard system)
See subsection 8.1 "Electrical Equipment".
(5) Grounding
Grounding must be provided in accordance with all applicable legal requirements for medically
used electrical equipment.
(6) Wiring work
Wiring work for the power supply must be provided as detailed in subsections 8.1 and 8.2.

No. 2A201-519EN*A
10
(7) Site environment
(a) Ambient temperature, humidity, and calorific value
Table 4-1 Heat generation by units and environmental conditions
Maximum heat
generation*1
Normal heat
generation*2 Environmental conditions
Names of rooms
and units
[kW] [kJ/h]*3 [kW] [kJ/h] Temperature*4 (°C) Relative humidity (%)
1. Scanning room
•Gantry
•Patient couch
(10.5) (37,800)
10.0 36,000
0.5 1,800
(4.3) (15,480)
4.0 14,400
0.3 1,080
18°C to 28°C where
median value is 20°C
to 26°C. Fluctuation
around the median
not to exceed ±2°C.
40% to 80%
(No condensation)
2. Scan control room
•Console
(8.0) (28,827)
8.0 28,827
(8.0) (21,600)
8.0 21,600
16°C to 28°C 40% to 80%
(No condensation)
*1 Maximum heat generation is the heat that is generated when continuous scanning is
performed at the maximum output rating of the unit.
*2 Normal heat generation is the heat that is generated when scanning is not
performed.
*3 1 kW = 860 kcal/h, 1 cal = 4.19 J
*4 A temperature from 0°C to 40°C is permissible if the units are not operated.
(b) Vibration
0.98 m/s2(0.1 G) or less
(c) Floor construction
Reinforced concrete structure
(d) Explosion-proof structure
This system is not explosion-proof. Therefore, do not use flammable or explosive gases
near the system.
(e) Other
Check for evidence of excessive dust or dirt.

No. 2A201-519EN*A
11
(8) External dimensions and mass
External dimensions Mass
Unit name
Width (mm) Depth (mm) Height (mm) (kg)
Gantry (with cover) 2,330 960 1,950 1,750
Gantry (without cover but with
median-line metal plate)
2,290 875 1,935 1,650
Patient couch (CBTB-019A) 630 2,690 450 480
Patient couch (CBTB-019B) 630 2,390 450 450
Console (CKCN-012B/2A)*1 2,470 815 1,470 435
Computer system (CPU BOX) 450 815 700 140
(REC BOX) 870 650 1,470 260
Speaker 140 135 200 2
System transformer 800 770 980 550
*1: The dimensions of the console are those when a recommended table is used.
(9) Maximum cable length
See subsection 8.6 "Cable Connections Between the Units".
(10) Installation altitude
The installation altitude should be no more than 1000 m above sea level. Prior consultation is
required for installations higher than 1000 m.
(11) Transport and storage conditions
Observe the following conditions during transport and storage after shipment.
Ambient temperature : -10°C to 50°C
Relative humidity : 40% to 80% (No condensation)
Atmospheric pressure : 700 hPa to 1060 hPa
Vibration : 9.8 m/s2(1G) or less (during storage)
: 19.6 m/s2(2G) or less (during transport)

No. 2A201-519EN*A
12
(12) Installation conditions
Installed location : Group 1 according to IEC60364-7-710
NOTE: 1. Group 1 requirement is described in IEC60364-7-710.
2. The title of IEC60364-7-710 is "Electrical installations of buildings - Part 7-710:
Requirements for special installations or locations - Medical Locations".
3. The definition of Group 1 is "Medical location where applied parts are intended to
be used as follows:
externally;
invasively to any part of the body, except where Group 2 applies".
The definition of Group 2 is "Medical location where applied parts are intended to
be used in applications such as intracardiac procedures, operating theatres and
vital treatment where discontinuity (failure) of the supply can cause danger to
life".

No. 2A201-519EN*A
13
5. SPACE REQUIREMENTS
The floor space for unit installation should be 25 m2or more, divided into two rooms. Subsection
5.3 provides an example of the layout for the minimum space and subsection 5.4 provides a
reference figure for the maintenance space.
For patient couch CBTB-019A : Required space 27 m2or more
For patient couch CBTB-019B : Required space 25 m2or more
Patient couch model Scanner room Operation room Minimum required
space
CBTB-019A 5.60 m ×3.80 m 1.50 m ×3.80 m 27 m2
CBTB-019B 5.00 m ×3.80 m 25 m2
5.1 Scanning Room
The gantry and patient couch are installed in the scanning room.
(1) Installation of the gantry
The following space is required for installation and maintenance of the gantry and
inward/outward movements of the couch top:
2330
960
B
C
A
(Rear)
(Front)
(Top view)
3830 or more
(Gantry)
A: 800 mm or more
B: 700 mm or more
C: 1470 mm or more
(For patient couch CBTB-019A)
1170 mm or more
(For patient couch CBTB-019B)
(2) X-ray shielding
Since the gantry releases X-rays, X-ray shielding should be provided around the scanner
room and the entrance.
(Refer to subsection 7.2 "X-ray Shielding in the Scanning Room".)
(3) Ceiling height
The ceiling should be 2500 mm or higher at a floor level considering that equipment such as
contrast medium injection tools are installed on the ceiling.

No. 2A201-519EN*A
14
(4) Miscellaneous
The following should be provided where required:
•Washstand : For water phantom or contrast medium injector
•Storage rack : For first-aid kit or accessories
•Gases required for medical treatment : Oxygen and nitrogen dioxide
•Vacuum
•Ceiling traveling irrigator : For instillator
(5) Air conditioning
Since the gantry includes components such as detectors or electronic circuits which permit
high-precision measurement, air conditioning is required to maintain high precision. For
details, refer to subsection 9.1 "Air Conditioning".
(6) Illumination
Illumination should be adjustable, because it is easier to specify the desired scan slice
position using the positioning projectors when illumination is decreased.
(7) Wiring pits and ducts
The wiring pits and ducts should be installed in accordance with subsection 7.5 "Wiring Pits
and Wall Ducts".

No. 2A201-519EN*A
15
5.2 Scan Control Room
The console (CPU BOX, monitors×2, keyboards×2, mice×2) is installed in the scan control room.
CAUTION: If the system transformer is installed beside the console, adequate
distance must be kept between them. Otherwise, the displayed images
may be adversely affected.
(1) Window
The window for monitoring the scanning room should be in front of or on the side of the
console. The lowest window frame should be 90 cm from the floor for easy patient
monitoring. A curtain should be provided for the window facing the outside.
(2) Entry
Doors should be provided at both the corridor and scanning room.
Take extreme care for X-ray leakage from the scanning room door.
(3) Illumination
For easy image reading, install freely adjustable or two-step-adjustable illumination.
(4) Receptacles
At least two standard outlets should be provided near the console for installation of the 3D
workstation and InnerVision PC.
A public telephone line jack for InnerVision should also be provided.
In addition to the above, the wiring and power distribution ducting or pit should be installed in
accordance with subsection 7.5 "Wiring Pits and Wall Ducts".

No. 2A201-519EN*A
16
5.3 Layout
An example of the layout for the minimum space is given below.
(1) Gantry
(2) Patient couch
(CBTB-019A)
(3) Console
(in scanning room)
•REC BOX
(4) Console
(in control room)
•CPU BOX
•Liquid-crystal monitors
•Keyboards
•Mice
(5) Patient observation
system
(This is not included in
the system
configuration. In this
example layout, the
patient observation
monitor is provided by
the hospital.)
(6) PC for InnerVision
(1)
650
(3)
(6)
(4)
(2)
(Scanning room)(Control room)
(5)
Unit: mm
Figure 5.3-1 Room layout example (for patient couch CBTB-019A)

No. 2A201-519EN*A
17
(1) Gantry
(2) Patient couch
(CBTB-019B)
(3) Console
(in scanning room)
•REC BOX
(4) Console
(in control room)
•CPU BOX
•Liquid-crystal monitors
•Keyboards
•Mice
(5) Patient observation
system
(This is not included in
the system
configuration. In this
example layout, the
patient observation
monitor is provided by
the hospital.)
(6) PC for InnerVision
650
(5)
(1)
(2)
(4)
(6)
(3)
470
630
(Scanning room)(Control room)
Unit: mm
Figure 5.3-2 Room layout example (for patient couch CBTB-019B)

No. 2A201-519EN*A
18
5.4 Maintenance Space
(a) Gantry
(b) Patient couch
(c) Console (in scanning room)
(d) Console (in control room)
(a)
(8)
(2)
(1)
(3) (4)
(5)
(6)
(b)
(d)
(7)
(c)
(Scanning room)(Control room)
(1) Since the scanner front cover opens outward, provide a clearance of 1400 mm for
opening/closing the cover.
(2) Provide a clearance of at least 650 mm behind the scanner for servicing the LCSR, data
transfer section.
(3) Provide a clearance of at least 800 mm for service.
(4) Provide a clearance of at least 700 mm for servicing the servo amplifier etc.
(5) Provide a clearance of at least 400 mm from the rear edge of the patient couch for
servicing the patient couch.
(6) Provide a clearance of at least 500 mm with the CPU BOX pulled out toward the front
for servicing the console.
(7) Provide a clearance of at least 500 mm with the REC BOX for servicing the REC BOX.
(8) It is desirable to reserve a clearance of more than 400 mm for the use of the headrest.
Figure 5.4-1 Clearance required for maintenance

No. 2A201-519EN*A
19
5.5 System Operating Environment and EMC
Recently, the EMC (electromagnetic compatibility) problem in hospitals has drawn attention. To
prevent the problem from occurring and to ensure that the system operates in a stable manner,
this system conforms to IEC60601-1-2, the international standards regarding EMC.
The standards specify the requirements taking into account the following points:
<1> Adverse effect on other systems due to noise generated by this system
<2> Adverse effect on this system due to noise generated by other systems
<3> Adverse effect on this system due to static electricity
In actual hospitals, not all systems meet the standards.
Systems such as laser surgical unit, microwave accelerator, microwave thermal therapy system,
etc. emit high-level electromagnetic waves due to their characteristics. This system may adversely
affect ultrasound systems which use faint signals.
With regard to static electricity, the level may easily exceed the level specified in the standards
depending on the operating environment.
Therefore, take extreme care when determining the installation location.
For example, the system should be installed at a location as far from equipment emitting strong
electromagnetic waves as possible.
There are methods for reducing mutual influence to preventive the EMC problem. Refer to
subsection A.1 "HANDLING EMC" of the appendix.

No. 2A201-519EN*A
20
6. CLASSIFICATION OF INSTALLATION-RELATED WORK
* The field engineers should check and clarify the scope of the work and the allocation of
responsibilities.
6.1 Scope of Work to Be Executed by the Customer
The work listed below should be executed by the customer as a general rule.
See sections 7 to 9 for details concerning the execution of the work.
(1) Construction work
(Refer to section 7.)
A. New construction, extension, and reconstruction works of the
building
B. X-ray shielding in the scanning room
Wall shielding
Door and frame shielding
Window and frame shielding
C. Reinforcement for floor load
D. Wiring pit and ducting
E. Interior finish work of the building
(2) Electrical work
(Refer to section 8.)
A. Power supply system
B. Power distribution board
C. Grounding
D. "X-ray on" indication lamp during X-ray exposure, piping, and
wiring
E. Interior illumination and dimmers
F. Installation of a public telephone line jack for InnerVision
(3) Air conditioning
and plumbing system
(Refer to section 9.)
A. Air conditioning work (heater, cooler, and ventilation)
B. Water supply and drainage work (e.g., for a washstand)
6.2 Scope of Work to Be Executed by Toshiba
(1) Bringing-in, installation, and adjustment of the entire system
(2) Intersystem wiring and cable connections to the customer's facilities
(3) Installation of the InnerVision service processor and connection to the public telephone line
