Toshiba 50H13 User manual

FILE NO. 023-200310
SERVICE MANUAL
– SUMMARY –
N2PSP Chassis
COLOR TELEVISION
50H13
(TAC0360)
50H13 is the same as 50H82 except for the parts tabled on back of this sheet.
Use this service manual together with the service manual of 50H82, 65H82 (File No. 020-
200207).

REPLACEMENT PARTS LIST DIFFERENCES
Location
No. Part No. Description
Location
No. Part No. Description
A001 23411921 Cabinet, Wood Cabinet
Shipment
A102 23527240 Grille, Speaker Grille Assembly
A202 23450 84 Panel, Control Panel Assembly
A213 23428213 Door, Door Proper
A701 230 7277 Carton
C201 24203100 EL, 10?F, ±20%, 1 V
C202 24100104 Chip, 0.1?F, +80%, -20%, 25V
C203 24100104 Chip, 0.1?F, +80%, -20%, 25V
C204 24100104 Chip, 0.1?F, +80%, -20%, 25V
C205 24100104 Chip, 0.1?F, +80%, -20%, 25V
C20 24100104 Chip, 0.1?F, +80%, -20%, 25V
C207 24203100 EL, 10?F, ±20%, 1 V
C208 24100104 Chip, 0.1?F, +80%, -20%, 25V
C209 24100104 Chip, 0.1?F, +80%, -20%, 25V
C210 24100104 Chip, 0.1?F, +80%, -20%, 25V
C212 24203100 EL, 10?F, ±20%, 1 V
C213 24100104 Chip, 0.1?F, +80%, -20%, 25V
C214 24100104 Chip, 0.1?F, +80%, -20%, 25V
C215 24100104 Chip, 0.1?F, +80%, -20%, 25V
C21 24203100 EL, 10?F, ±20%, 1 V
C217 24100104 Chip, 0.1?F, +80%, -20%, 25V
C218 24100104 Chip, 0.1?F, +80%, -20%, 25V
C219 24109103 Chip, 0.01?F, ±10%
C220 2420 479 EL, 4.7?F, ±20%, 50V
C221 24203100 EL, 10?F, ±20%, 1 V
C222 24100104 Chip, 0.1?F, +80%, -20%, 25V
C223 24100104 Chip, 0.1?F, +80%, -20%, 25V
C224 24100104 Chip, 0.1?F, +80%, -20%, 25V
C225 24203100 EL, 10?F, ±20%, 1 V
C22 24100104 Chip, 0.1?F, +80%, -20%, 25V
C227 24100104 Chip, 0.1?F, +80%, -20%, 25V
C228 24100104 Chip, 0.1?F, +80%, -20%, 25V
C229 24100104 Chip, 0.1?F, +80%, -20%, 25V
C230 24100104 Chip, 0.1?F, +80%, -20%, 25V
C231 24100104 Chip, 0.1?F, +80%, -20%, 25V
C232 24203100 EL, 10?F, ±20%, 1 V
C233 24109103 Chip, 0.01?F, ±10%
C23 24100104 Chip, 0.1?F, +80%, -20%, 25V
C237 24100104 Chip, 0.1?F, +80%, -20%, 25V
C238 24203100 EL, 10?F, ±20%, 1 V
C239 24100104 Chip, 0.1?F, +80%, -20%, 25V
C240 24100104 Chip, 0.1?F, +80%, -20%, 25V
C241 24100104 Chip, 0.1?F, +80%, -20%, 25V
C242 24100104 Chip, 0.1?F, +80%, -20%, 25V
C243 24203100 EL, 10?F, ±20%, 1 V
C244 24100104 Chip, 0.1?F, +80%, -20%, 25V
C245 241055 0 Chip, 5 pF
C24 24105150 Chip, 15pF
C247 24105270 Chip, 27pF
C248 24105101 Chip, 100pF
C249 24105820 Chip, 820pF
C250 241055 0 Chip, 5 pF
C251 24105150 Chip, 15pF
C252 24105270 Chip, 27pF
C253 24105101 Chip, 100pF
C254 24105820 Chip, 820pF
C255 241055 0 Chip, 5 pF
C25 24105150 Chip, 15pF
C257 24105270 Chip, 27pF
– 2 –
C258 24105101 Chip, 100pF
C259 24105820 Chip, 820pF
C2 0 24203100 EL, 10?F, ±20%, 1 V
C2 1 24203100 EL, 10?F, ±20%, 1 V
C2 2 24100104 Chip, 0.1?F, +80%, -20%, 25V
C2 3 24100104 Chip, 0.1?F, +80%, -20%, 25V
C2 4 24105100 Chip, 10pF, ±0.5pF
C2 5 24105100 Chip, 10pF, ±0.5pF
C2 24105100 Chip, 10pF, ±0.5pF
C2 7 24100104 Chip, 0.1?F, +80%, -20%, 25V
C2 8 24105101 Chip, 100pF
C2 9 24105101 Chip, 100pF
C272 24100104 Chip, 0.1?F, +80%, -20%, 25V
C273 24100104 Chip, 0.1?F, +80%, -20%, 25V
C801 24203101 EL, 100?F, ±20%, 1 V
C802 24203100 EL, 10?F, ±20%, 1 V
C803 24100104 Chip, 0.1?F, +80%, -20%, 25V
C804 24 17033 EL, 4.7?F, ±20%, 25V
C805 24203100 EL, 10?F, ±20%, 1 V
C80 24100104 Chip, 0.1?F, +80%, -20%, 25V
C820 247 3101 EL, 100?F, ±20%, 1 V
C821 24092730 Chip, 0.1?F, ±10%, 1 V
C822 247 3101 EL, 100?F, ±20%, 1 V
C823 24109103 Chip, 0.01?F, ±10%
C824 24092730 Chip, 0.1?F, ±10%, 1 V
C825 24109103 Chip, 0.01?F, ±10%
C82 247 3101 EL, 100?F, ±20%, 1 V
C827 24092730 Chip, 0.1?F, ±10%, 1 V
CC01 24203100 EL, 10?F, ±20%, 1 V
CC02 24100104 Chip, 0.1?F, +80%, -20%, 25V
CC03 24203100 EL, 10?F, ±20%, 1 V
CC04 24100104 Chip, 0.1?F, +80%, -20%, 25V
CS03 24109221 Chip, 220pF, ±10%
CS07 24109221 Chip, 220pF, ±10%
CS09 24105331 Chip, 330pF
CS12 24109221 Chip, 220pF, ±10%
CS14 24109221 Chip, 220pF, ±10%
CS15 24105331 Chip, 330pF
CS21 24105101 Chip, 100pF
CS22 24105101 Chip, 100pF
CS24 24105331 Chip, 330pF
CS28 24105331 Chip, 330pF
CS29 24105331 Chip, 330pF
CS34 24105331 Chip, 330pF
CS55 24105331 Chip, 330pF
CS5 24105331 Chip, 330pF
CS57 24105331 Chip, 330pF
CS58 24105331 Chip, 330pF
CS91 2420 229 EL, 2.2?F, ±20%, 50V
CS92 2420 229 EL, 2.2?F, ±20%, 50V
CS93 2420 229 EL, 2.2?F, ±20%, 50V
CS94 2420 229 EL, 2.2?F, ±20%, 50V
CS95 247 3101 EL, 100?F, ±20%, 1 V
CS9 24109103 Chip, 0.01?F, ±10%
CV02 24109103 Chip, 0.01?F, ±10%
CV08 24 471 EL, 470?F, ±20%, 1 V
CV09 24 471 EL, 470?F, ±20%, 1 V
CV23 24109103 Chip, 0.01?F, ±10%
CV24 24109102 Chip, 1000pF, ±10%
CV30 24109103 Chip, 0.01?F, ±10%

Location
No. Part No. Description Location No. Part No. Description
–3 –
CV39 24109102 Chip, 1000pF, ±10%
CV4 24109103 Chip, 0.01?F, ±10%
CV 2 24109103 Chip, 0.01?F, ±10%
CV 241055 1 Chip, 5 0pF
CV82 24203470 EL, 47?F, ±20%, 1 V
CV83 24203470 EL, 47?F, ±20%, 1 V
CV84 24203470 EL, 47?F, ±20%, 1 V
CV85 24203470 EL, 47?F, ±20%, 1 V
CV8 24203470 EL, 47?F, ±20%, 1 V
CV87 24203470 EL, 47?F, ±20%, 1 V
CV90 24109103 Chip, 0.01?F, ±10%
CV91 247 3101 EL, 100?F, ±20%, 1 V
D201 23118041 Diode, MA111
D202 23118041 Diode, MA111
D203 23118041 Diode, MA111
D204 23118041 Diode, MA111
D205 2331 573 Diode, Zener, MA80 2-L
D20 2331 573 Diode, Zener, MA80 2-L
D820 23118041 Diode, MA111
D821 23118094 Diode, EU2A
DC01 23118041 Diode, MA111
DC02 23118041 Diode, MA111
DC03 23118041 Diode, MA111
DC04 23118041 Diode, MA111
DS90 2331 59 Diode, Zener Chip 11.40-11.9 V,
MA8120-L, TX
DV01 2331 587 Diode, Zener, MA8091-L
DV02 2331 587 Diode, Zener, MA8091-L
DV03 2331 587 Diode, Zener, MA8091-L
DV07 2331 587 Diode, Zener, MA8091-L
DV08 2331 587 Diode, Zener, MA8091-L
DV09 2331 587 Diode, Zener, MA8091-L
DV11 2331 587 Diode, Zener, MA8091-L
DV12 2331 587 Diode, Zener, MA8091-L
DV13 2331 587 Diode, Zener, MA8091-L
DV17 2331 587 Diode, Zener, MA8091-L
DV18 2331 587 Diode, Zener, MA8091-L
DV25 23118041 Diode, MA111
DV1 1 2331 587 Diode, Zener, MA8091-L
DV1 2 2331 587 Diode, Zener, MA8091-L
DV1 3 2331 587 Diode, Zener, MA8091-L
DV1 4 2331 587 Diode, Zener, MA8091-L
DV1 5 2331 587 Diode, Zener, MA8091-L
DV1 2331 587 Diode, Zener, MA8091-L
GJ13 24000445 Chip Jumper, 1 80 Type
GJ91 24000445 Chip Jumper, 1 80 Type
GJ92 24000445 Chip Jumper, 1 80 Type
GJ93 24000445 Chip Jumper, 1 80 Type
GJ97 24000445 Chip Jumper, 1 80 Type
GJ98 24000445 Chip Jumper, 1 80 Type
GJ201 24000445 Chip Jumper, 1 80 Type
GJ202 24000445 Chip Jumper, 1 80 Type
GJ203 24000445 Chip Jumper, 1 80 Type
GJ204 24011220 Chip, 22 ohm, 1/20W
GJ205 24000445 Chip Jumper, 1 80 Type
GJ208 24000445 Chip Jumper, 1 80 Type
GJ210 24000445 Chip Jumper, 1 80 Type
GJ21 24000445 Chip Jumper, 1 80 Type
GJ223 24000445 Chip Jumper, 1 80 Type
GJ224 24000445 Chip Jumper, 1 80 Type
GJ225 24000445 Chip Jumper, 1 80 Type
GJ22 24000445 Chip Jumper, 1 80 Type
GJ227 24000445 Chip Jumper, 1 80 Type
GJ228 24000445 Chip Jumper, 1 80 Type
GJ229 24000445 Chip Jumper, 1 80 Type
GJ230 24000445 Chip Jumper, 1 80 Type
K501 23311957 Screen, 50KM Lenticular Sheet,
SCREEN50KM-L
K502 23311958 Screen, 50KM Fresnel Sheet,
SCREEN50KM-F
L201 23103152 Chip (Ferrite Bead),
TEM2133AM
L202 23103152 Chip (Ferrite Bead),
TEM2133AM
L203 23103152 Chip (Ferrite Bead),
TEM2133AM
L204 23103152 Chip (Ferrite Bead),
TEM2133AM
L205 23103152 Chip (Ferrite Bead),
TEM2133AM
L20 23103152 Chip (Ferrite Bead),
TEM2133AM
L207 23103152 Chip (Ferrite Bead),
TEM2133AM
L208 23103152 Chip (Ferrite Bead),
TEM2133AM
L209 23103152 Chip (Ferrite Bead),
TEM2133AM
L210 23103152 Chip (Ferrite Bead),
TEM2133AM
L211 2324 191 Chip, Inductor, TRF4R47CG
L212 2324 191 Chip, Inductor, TRF4R47CG
L213 2324 190 Chip, Inductor, TRF4R39CG
L214 2324 191 Chip, Inductor, TRF4R47CG
L215 2324 191 Chip, Inductor, TRF4R47CG
L21 2324 190 Chip, Inductor, TRF4R39CG
L217 2324 191 Chip, Inductor, TRF4R47CG
L218 2324 191 Chip, Inductor, TRF4R47CG
L219 2324 190 Chip, Inductor, TRF4R39CG
L220 2324 191 Chip, Inductor, TRF4R47CG
L221 2324 191 Chip, Inductor, TRF4R47CG
L222 2324 191 Chip, Inductor, TRF4R47CG
L801 23103152 Chip (Ferrite Bead),
TEM2133AM
L802 23103152 Chip (Ferrite Bead),
TEM2133AM
L821 23103152 Chip (Ferrite Bead),
TEM2133AM
L822 23103152 Chip (Ferrite Bead),
TEM2133AM
L823 23103152 Chip (Ferrite Bead),
TEM2133AM
LC01 23103152 Chip (Ferrite Bead),
TEM2133AM
LS90 23289100 Coil, Peaking, TRF4100A
LV81 23289100 Coil, Peaking, TRF4100A
* P801 23372191 Power Cord
Q152 23314204 Transistor, 2SC2412K,Q
Q201 23009234 IC, TFP501
Q202 23009233 IC, THS8200
Q203 23009 21 IC, TMP87C809M
Q204 23009371 IC, EPM3032A
Q205 23205151 Transistor, FET, BSN20
Q20 23205151 Transistor, FET, BSN20
Q207 233141 3 Transistor, 2SA11 2-Y
Q208 233141 3 Transistor, 2SA11 2-Y
Q209 233141 3 Transistor, 2SA11 2-Y
Q210 23314204 Transistor, 2SC2412K,Q
Q211 23205151 Transistor, FET, BSN20
Q212 70114402 Transistor, 2SC3437-Y

Q213 23314204 Transistor, 2SC2412K,Q
Q801 2300923 IC, TPS7 918
Q820 2390 484 IC, BA033T
Q822 70129444 IC, PST994D
QC01 230093 0 IC, AT24C04N-10SI-1.8TEL
QC02 23205151 Transistor, FET, BSN20
QC03 23205151 Transistor, FET, BSN20
QC04 230093 0 IC, AT24C04N-10SI-1.8TEL
QC05 23314204 Transistor, 2SC2412K,Q
QS01 7011439 Transistor, 2SC332 B
QS11 7011439 Transistor, 2SC332 B
QS12 23114493 Transistor, RN2404
QS13 23314204 Transistor, 2SC2412K,Q
QS14 23314204 Transistor, 2SC2412K,Q
QS90 23000529 IC, MM1231XD
QV10 23314204 Transistor, 2SC2412K,Q
QV20 23114499 Transistor, RN1404
QV21 23314204 Transistor, 2SC2412K,Q
QV22 23205045 Transistor, 2SA1037AKQ
QV23 23205045 Transistor, 2SA1037AKQ
QV28 23114500 Transistor, RN1403
QV48 23114433 Transistor, 2SC1815-Y
QV49 23114433 Transistor, 2SC1815-Y
QV81 23318438 IC, M52055P
QV83 23205057 Transistor, KTC3875Y
QV91 23205057 Transistor, KTC3875Y
QW17 23114502 Transistor, RN1401
QY2 0 23314204 Transistor, 2SC2412K,Q
R150 24011101 Chip, 100 ohm, 1/20W
R151 240115 2 Chip, 5 00 ohm, 1/20W
R152 24011103 Chip, 10k ohm, 1/20W
R201 24011102 Chip, 1k ohm, 1/20W
R202 24872102 Chip, 1k ohm, 1/1 W
R203 24872102 Chip, 1k ohm, 1/1 W
R204 24011102 Chip, 1k ohm, 1/20W
R205 24011152 Chip, 1500 ohm, 1/20W
R207 24011102 Chip, 1k ohm, 1/20W
R208 24011332 Chip, 3300 ohm, 1/20W
R209 24011332 Chip, 3300 ohm, 1/20W
R210 24011101 Chip, 100 ohm, 1/20W
R211 24011101 Chip, 100 ohm, 1/20W
R212 24011101 Chip, 100 ohm, 1/20W
R213 24011101 Chip, 100 ohm, 1/20W
R214 24011101 Chip, 100 ohm, 1/20W
R215 24011101 Chip, 100 ohm, 1/20W
R21 24011102 Chip, 1k ohm, 1/20W
R217 24011330 Chip, 33 ohm, 1/20W
R218 24011330 Chip, 33 ohm, 1/20W
R219 24011330 Chip, 33 ohm, 1/20W
R220 24011330 Chip, 33 ohm, 1/20W
R221 24011330 Chip, 33 ohm, 1/20W
R222 24011330 Chip, 33 ohm, 1/20W
R223 24011302 Chip, 3k ohm, 1/20W
R224 24872750 Chip, 75 ohm, 1/1 W
R225 24872750 Chip, 75 ohm, 1/1 W
R22 24872750 Chip, 75 ohm, 1/1 W
R227 24872750 Chip, 75 ohm, 1/1 W
R228 24872750 Chip, 75 ohm, 1/1 W
R229 24872750 Chip, 75 ohm, 1/1 W
R230 24011103 Chip, 10k ohm, 1/20W
R231 24011153 Chip, 15k ohm, 1/20W
R233 24011472 Chip, 4700 ohm, 1/20W
R234 2401943 Chip, 22 ohm, 1/1 W
R235 2401943 Chip, 22 ohm, 1/1 W
R23 2401943 Chip, 22 ohm, 1/1 W
R237 2401943 Chip, 22 ohm, 1/1 W
R238 2401943 Chip, 22 ohm, 1/1 W
R239 2401943 Chip, 22 ohm, 1/1 W
R240 24011101 Chip, 100 ohm, 1/20W
R241 24011102 Chip, 1k ohm, 1/20W
R242 24011101 Chip, 100 ohm, 1/20W
R243 24011102 Chip, 1k ohm, 1/20W
R244 24011101 Chip, 100 ohm, 1/20W
R245 24011102 Chip, 1k ohm, 1/20W
R24 24011101 Chip, 100 ohm, 1/20W
R247 24011101 Chip, 100 ohm, 1/20W
R248 24011101 Chip, 100 ohm, 1/20W
R249 24011101 Chip, 100 ohm, 1/20W
R250 24011101 Chip, 100 ohm, 1/20W
R251 24011101 Chip, 100 ohm, 1/20W
R252 24011101 Chip, 100 ohm, 1/20W
R253 24011473 Chip, 47k ohm, 1/20W
R254 24011472 Chip, 4700 ohm, 1/20W
R255 24011101 Chip, 100 ohm, 1/20W
R25 24011103 Chip, 10k ohm, 1/20W
R257 24011103 Chip, 10k ohm, 1/20W
R258 24011101 Chip, 100 ohm, 1/20W
R259 24011101 Chip, 100 ohm, 1/20W
R829 24011102 Chip, 1k ohm, 1/20W
RB41 24011151 Chip, 150 ohm, 1/20W
RC01 24011101 Chip, 100 ohm, 1/20W
RC02 24011101 Chip, 100 ohm, 1/20W
RC03 24011473 Chip, 47k ohm, 1/20W
RC05 24011103 Chip, 10k ohm, 1/20W
RC0 24011103 Chip, 10k ohm, 1/20W
RC07 24011103 Chip, 10k ohm, 1/20W
RC08 24011103 Chip, 10k ohm, 1/20W
RC09 24011102 Chip, 1k ohm, 1/20W
RC10 24872101 Chip, 100 ohm, 1/1 W
RC11 24011222 Chip, 2200 ohm, 1/20W
RC12 24011102 Chip, 1k ohm, 1/20W
RS02 24011472 Chip, 4700 ohm, 1/20W
RS04 24011102 Chip, 1k ohm, 1/20W
RS0 24011102 Chip, 1k ohm, 1/20W
RS07 24011103 Chip, 10k ohm, 1/20W
RS08 24011103 Chip, 10k ohm, 1/20W
RS09 24011102 Chip, 1k ohm, 1/20W
RS10 24011102 Chip, 1k ohm, 1/20W
RS12 24011103 Chip, 10k ohm, 1/20W
RS21 24011104 Chip, 100k ohm, 1/20W
RS22 24011104 Chip, 100k ohm, 1/20W
RS25 24011223 Chip, 22k ohm, 1/20W
RS2 24011223 Chip, 22k ohm, 1/20W
RS27 24011471 Chip, 470 ohm, 1/20W
RS28 24011471 Chip, 470 ohm, 1/20W
RS29 24011104 Chip, 100k ohm, 1/20W
RS30 24011104 Chip, 100k ohm, 1/20W
RS31 24011103 Chip, 10k ohm, 1/20W
RS32 24011104 Chip, 100k ohm, 1/20W
RS33 24011222 Chip, 2200 ohm, 1/20W
RS34 24011222 Chip, 2200 ohm, 1/20W
RS35 24011103 Chip, 10k ohm, 1/20W
RS3 24011103 Chip, 10k ohm, 1/20W
RS37 24011101 Chip, 100 ohm, 1/20W
RS40 24011101 Chip, 100 ohm, 1/20W
RS42 24011101 Chip, 100 ohm, 1/20W
RS48 24011101 Chip, 100 ohm, 1/20W
RS49 24011103 Chip, 10k ohm, 1/20W
RS51 24011103 Chip, 10k ohm, 1/20W
RS52 24011103 Chip, 10k ohm, 1/20W
Location
No. Part No. Description Location No. Part No. Description
–4 –

RS53 24011103 Chip, 10k ohm, 1/20W
RS54 24011103 Chip, 10k ohm, 1/20W
RS91 24011101 Chip, 100 ohm, 1/20W
RS92 24011101 Chip, 100 ohm, 1/20W
RS93 24011101 Chip, 100 ohm, 1/20W
RS94 24011101 Chip, 100 ohm, 1/20W
RV01 24011472 Chip, 4700 ohm, 1/20W
RV03 24011101 Chip, 100 ohm, 1/20W
RV04 24011101 Chip, 100 ohm, 1/20W
RV11 24011100 Chip, 10 ohm, 1/20W
RV12 24011100 Chip, 10 ohm, 1/20W
RV13 24011100 Chip, 10 ohm, 1/20W
RV15 24011222 Chip, 2200 ohm, 1/20W
RV24 24011750 Chip, 75 ohm, 1/20W
RV25 24011750 Chip, 75 ohm, 1/20W
RV2 24011750 Chip, 75 ohm, 1/20W
RV31 24011332 Chip, 3300 ohm, 1/20W
RV32 24011750 Chip, 75 ohm, 1/20W
RV 3 24011102 Chip, 1k ohm, 1/20W
RV 4 24011750 Chip, 75 ohm, 1/20W
RV 5 24011750 Chip, 75 ohm, 1/20W
RV 7 24011750 Chip, 75 ohm, 1/20W
RV70 24011472 Chip, 4700 ohm, 1/20W
RV74 24011750 Chip, 75 ohm, 1/20W
RV81 24011472 Chip, 4700 ohm, 1/20W
RV83 24011332 Chip, 3300 ohm, 1/20W
RV84 24011750 Chip, 75 ohm, 1/20W
RV85 24552101 OMF, 100 ohm, 1/2W
RV8 24011101 Chip, 100 ohm, 1/20W
RV87 24011182 Chip, 1800 ohm, 1/20W
RV89 24011 80 Chip, 8 ohm, 1/20W
RV91 24011102 Chip, 1k ohm, 1/20W
RV92 24011103 Chip, 10k ohm, 1/20W
RV93 24011101 Chip, 100 ohm, 1/20W
RV94 24011472 Chip, 4700 ohm, 1/20W
RV95 24011273 Chip, 27k ohm, 1/20W
RV97 24011221 Chip, 220 ohm, 1/20W
RV117 24011750 Chip, 75 ohm, 1/20W
RV118 24011750 Chip, 75 ohm, 1/20W
RV119 24011750 Chip, 75 ohm, 1/20W
RV124 24011392 Chip, 3900 ohm, 1/20W
RV125 24011123 Chip, 12k ohm, 1/20W
RV12 24011274 Chip, 270k ohm, 1/20W
RV127 24011331 Chip, 330 ohm, 1/20W
RV128 24011472 Chip, 4700 ohm, 1/20W
RV140 24011103 Chip, 10k ohm, 1/20W
RV141 24011302 Chip, 3k ohm, 1/20W
RV142 24011103 Chip, 10k ohm, 1/20W
RV143 24011103 Chip, 10k ohm, 1/20W
RV144 24011472 Chip, 4700 ohm, 1/20W
RW40 24011182 Chip, 1800 ohm, 1/20W
RW45 24011103 Chip, 10k ohm, 1/20W
RY80 243 331 CF, 330 ohm
RY81 24011101 Chip, 100 ohm, 1/20W
RY82 24011182 Chip, 1800 ohm, 1/20W
S 02 23145412 Switch, Slide
*U901 2378881 SIGNAL/CONV Board, PD0 39Q
*UV02 237874 8 DVI Board, PD0 47A, 5HDX82
* V901R 23071799 OTHER BLOCK, COUPLING R
50H13
* V902G 23071800 OTHER BLOCK, COUPLING G
50H13
* V903B 23071801 OTHER BLOCK, COUPLING B
50H13
Location
No. Part No. Description Location No. Part No. Description
–5 –
XV01 23153533 Ceramic Resonator, 8.00MHz,
TCR1082AM
Y101 235 5981 Owner’s Manual, English/
French, 50H13

TOSHIBA CORPORATION
1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN
