SERVICE MANUAL
PRINTED IN UK. 2002 C
COLOURTELEVISION
53S23F2
TOSHIBA

SERVICING NOTICES ON CHECKING
6. AVOID AN X-RAY1. KEEP THE NOTICES
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep the
indications and notices in the operation manual.
3. USE THE DESIGNATED PARTS
5. TAKE CARE TO DEAL WITH THE
CATHODE-RAY TUBE
Safety is secured against an X-ray by consider-
ing about the cathode-ray tube and the high
voltage peripheral circuit, etc.
Therefore, when repairing the high voltage pe-
ripheral circuit, use the designated parts and
make sure not modify the circuit.
Repairing except indicates causes rising of high
voltage, and it emits an X-ray from the cathode-
ray tube.
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.
HOW TO ORDER PARTS
Inferior silicon grease can damage IC's and transistors.
When replacing an IC's or transistors, use only specified silicon grease (YG6260M).
Remove all old silicon before applying new silicon.
IMPORTANT
2. AVOID AN ELECTRIC SHOCK
There is a high voltage part inside. Avoid an
electric shock while the electric current is
flowing.
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
4. PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.
In the condition that an explosion-proof cathode-
ray tube is set in this equipment, safety is
secured against implosion. However, when
removing it or serving from backward, it is
dangerous to give a shock. Take enough care to
deal with it.
PERFORM A SAFETY CHECK AFTER
SERVICING
7.
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
(INSULATION CHECK PROCEDURE)
1.
2.
3.
4.
Unplug the plug from the AC outlet.
Remove the antenna terminal on TV and turn
on the TV.
Insulation resistance between the cord plug
terminals and the eternal exposure metal
[Note 2] should be more than 1M ohm by
using the 500V insulation resistance meter
[Note 1].
If the insulation resistance is less than 1M
ohm, the inspection repair should be
required.
[Note 1]
If you have not the 500V insulation
resistance meter, use a Tester.
[Note 2]
External exposure metal: Antenna terminal
Earphone jack
A1-1

CONTENTS
A2-1
SERVICING NOTICES ON CHECKING......................................................................................................
HOW TO ORDER PARTS ...........................................................................................................................
IMPORTANT................................................................................................................................................
CONTENTS .................................................................................................................................................
GENERAL SPECIFICATIONS ....................................................................................................................
DISASSEMBLY INSTRUCTIONS
1.REMOVAL OF ANODE CAP ..............................................................................................................
2.REMOVAL AND INSTALLATION OF FLAT PACKAGE IC ...............................................................
SERVICE MODE LIST.................................................................................................................................
CONFIRMATION OF HOURS USED ..........................................................................................................
WHEN REPLACING EEPROM( MEMORY) IC ...........................................................................................
ELECTRICAL ADJUSTMENTS ..................................................................................................................
BLOCK DIAGRAM ......................................................................................................................................
PRINTED CIRCUIT BOARDS
MAIN/CRT...............................................................................................................................................
SCHEMATIC DIAGRAMS
MICON/TUNER.......................................................................................................................................
IF/CHROMA............................................................................................................................................
21PIN/AV SW .........................................................................................................................................
STEREO .................................................................................................................................................
SOUND AMP ..........................................................................................................................................
DEFLECTION/CRT .................................................................................................................................
POWER ..................................................................................................................................................
WAVEFORMS .............................................................................................................................................
MECHANICAL EXPLODED VIEW ..............................................................................................................
MECHANICAL REPLACEMENT PARTS LIST ..........................................................................................
ELECTRICAL REPLACEMENT PARTS LIST ............................................................................................
A1-1
A1-1
A1-1
A2-1
A3-1~A3-5
B1-1
B2-1, B2-2
C-1
C-1
C-1
D-1~D-5
E-1, E-2
F-1~F-4
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
G-11, G-12
G-13, G-14
H-1~H-4
I-1
J1-1
J2-1~J2-9

GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 21 inch / 544.5mmV
System CRT Type NORMAL
Deflection 90 degree
Magnetic Field BV/BH +0.45G/0.18G
Color System PAL/SECAM
Speaker 2 Speaker
Position Front
Size 2.0 x4.7 Inch
Impedance 8 ohm
Sound Output MAX 5.0+5.0 W
10%(Typical) 4.0+4.0 W
DDR SECAM Yes
NTSC3.58(AV)+NTSC4.43 Yes
PAL60Hz Yes
G-2 Tuning Broadcasting System FRANCE+CCIR System B/G L D/K
System Tuner and System 1Tuner
Receive CH Destination Hyper
Tuning System F-Synth
Input Impedance VHF/UHF 75 ohm
E2 - E4, X - Z+2, S1 - S10, E5 - E12,
CH Coverage S11 - S41, E21 - E69
Intermediate PAL/SECAM(U&VH)/SECAM(VL)
Frequency Picture(FP) 38.9/38.9/34.4MHz
Sound(FS) 33.4/32.4/40.9MHz
FP-FS 5.5/6.5/6.5MHZ
PAL DK,SECAM DK
Picture(FP) 38.9 , 38.9 MHz
Sound(FS) 32.4 , 32.4 MHz
FP-FS 6.5 , 6.5MHz
Preset CH 100
Stereo/Dual TV Sound Nicam, G-ST
Tuner Sound Muting Yes
G-3 Power Power Source AC 230V-240V AC 50Hz
DC
Power Consumption at AC 60 W at AC 230 V 50 Hz
Stand by (at AC) 3 W at AC 230 V 50 Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
G-4 Regulation Safety CE(EN60065:98)
Radiation CE
X-Radiation -
G-5 Temperature Operation +5oC ~ +40oC
Storage -20oC ~ +60oC
G-6 Operating Humidity Less than 80% RH
A3-1

GENERAL SPECIFICATIONS
G-7 On Screen Menu Yes
Display Menu Type Character
Picture Yes
Contrast Yes
Brightness Yes
Colour Yes
Tint (NTSC Only) Yes
Sharpness Yes
Audio Yes
Bass Yes
Treble Yes
Balance Yes
BBE On/Off No
Stable Sound On/Off No
CH Tuning Yes
Manual Yes
ITS Yes
CH MAPPING Yes
CH Allocation No
Text Langage(East/West) Yes
Language Yes
Clock Set No
On/OffTimer Set Yes
On Timer Set No
Pin Code Registration No
Panel Lock Yes
Nicam Auto Off Yes
AV Colour System Yes
Sound System No
Auto 4:3 Default No
AV2 Output Yes
Output Source Yes
Source Yes
Control Level Yes
Volume Yes
Brightness Yes
Contrast Yes
Colour Yes
Tint (NTSC Only) Yes
Sharpness Yes
Tuning Yes
Bass Yes
Treble Yes
Balance Yes
Back Light No
Nicam ST Yes
G(A2)Stereo Yes
Tone 1/2 (A/B) Yes
Surround On/Off No
Pin Code No
AV Yes
Skip Yes
Channel Yes
Broadcasting Station Name Yes
Hotel Lock No
Sleep Timer No
Selectable Picture Yes
Wide Mode No
Sound Mute Yes
G-8 OSD Language English , French , Spanish
Germany , Italian
Polski , Turkey , Sweden
Netherland , Portgal
Norway , Finland , Denmark
Czech , Slovak , Hungarian
Russian , Greek
Yugoslavian , Bulgarian , Romanian
Slovenian , Croatian
G-9 Clock and Sleep Timer Max Time - Min
Timer Step - Min
Clock No
On Timer Program( On Timer) Yes
Off Timer Program( Off Timer) Yes
Wake Up Timer No
Timer Back-up (at Power Off Mode) more than -- Min Sec
A3-2

GENERAL SPECIFICATIONS
G-10 Remote Unit RC-GX
Control Glow in Dark Remocon No
Format NEC
Custom Code 40-BF h
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Total Keys 34 Keys
Keys Power Yes
1/Rename Yes
2/Move Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 Yes
Volume Up / + Yes
Volume Down / - Yes
Previous Yes
Select Picture Yes
Menu Yes
OK(Enter) Yes
EXIT Yes
Audio Select Yes
On/OffTimer No
Mute Yes
DSP/surround/Virtual Dolby No
Woofer/Bass No
Picture Size No
T'TEXT Keys TEXT / MIX / TV Yes
CH Up / Page Up Yes
CH Down / Page Down Yes
Red Yes
Green Yes
Yellow Yes
Cyan Yes
TEXT F/T/B Yes
Reveal Yes
TIMED PAGE(SUB PAGE) Yes
CALL / TEXT INDEX Yes
INPUT SELECT Yes
TEXT HOLD Yes
TIME / TXCL Yes
A3-3

GENERAL SPECIFICATIONS
G-11 Features Auto Degauss Yes
Auto Shut Off Yes
Canal+ No
CATV No
Anti-theft(Back Up 30 Min.) No
Memory(Last CH) Yes
Memory(Last Volume) Yes
BBE No
Auto Search No
ITS Yes
CH Allocation No
CH MAPPING Yes
Just Clock Function No
Game Position No
CH Label No
VM Circuit No
Full OSD No
Noise Blue Back Yes
T'Text Yes
Text type Fastext
Text Language English , French, Swedish, Hungarian
Finnish, Turkish, German, Dutch
Portuguese, Spanish, Italian, Greek
Polish, Russian, Bulgarian, Czech
Slovak, Romanian, Slovenian
Croatian, Yugoslavian
Premiere No
Comb Filter No
Lines
Auto CH Memory No
Stable Sound No
Auto Set Up No
FBT Leak Test Protect Yes
Previous (Quick View) Yes
Panel Lock Yes
Power ON Memory Yes
Double Focus & Dynamic Focus No
Wss Signal Wide Change No
Virtual Dolby Surround No
Hotel Lock No
G-12 Accessories Owner's Manual Language French
w/Guarantee Card No
Remote Control Unit Yes
Rod Antenna No
Poles -
Terminal -
Loop Antenna No
Terminal -
U/V Mixer No
DC Car Cord (Center+) No
Guarantee Card No
Warning Sheet No
Circuit Diagram No
Antenna Change Plug No
Service Facility List No
Important Safeguard Yes (Owner's Manual In)
Dew/AHC Caution Sheet No
AC Plug Adapter No
Quick Set-up Sheet Yes
Battery Yes
UM size x pcs UM-4 x 2 pcs
OEM Brand No
AC Cord No
AV Cord (2Pin-1Pin) No
Registration Card Yes
PTB Sheet No
300 ohm to 75 ohm Antenna Adapter No
A3-4

GENERAL SPECIFICATIONS
G-13 Interface Switch Front Power (Tact Sw) No
System Select No
Main Power SW Yes
Sub Power No
Channel Up Yes
Channel Down Yes
Volume Up Yes
Volume Down Yes
Rear AC/DC No
TV/CATV Selector No
Degauss No
Main Power SW No
Indicator Power No
Stand-by No
Stand-by/ON Yes(Red)
On Timer Yes(Green)
Terminals Front Video Input RCA
Audio Input RCA x 2(Stereo)
Other Terminal HeadPhone (Stereo)
Rear Video Input(Rear1) No
Video Input(Rear2) No
Audio Input(Rear1) No
Audio Input(Rear2) No
Video Output No
Audio Output No
Euro Scart(21Pin) Yes ( x1 )
S-INPUT Yes ( x1 )
Euro Scart(21Pin) Yes ( x1 )
RGB-INPUT Yes ( x1 )
Component Input No
Diversity No
Ext Speaker No
DC Jack 12V(Center +) No
VHF/UHF Antenna Input D Type
AC Outlet No
G-14 Set Size Approx. W x D x H (mm) 590 x 492 x 446.5
G-15 Weight Net (Approx.) 21.0 kg ( --- lbs)
Gross (Approx.) 23.8kg ( ---lbs)
G-16 Carton Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Yes
Material Double/Brown
Dimensions W x D x H(mm) 658 x 575 x 529
Design As per Buyer's
Description of Origin No (Assembled in U.K.)
Drop Test Natural Dropping At 1
C
orner
/
3 Edges
/
6
Su
rf
aces
Height (cm) 46
Container Stuffing 288 Sets/40' container
G-17 Material Cabinet Front PS 94HB
Rear PS 94HB
Holder PS 94V0 NON-Decabrom
PCB Non-Halogen Demand Yes
Eyelet Demand Yes
G-18 Environment Pb Free Lead-free Solder No
Other No
Cd Free No
A3-5

1. REMOVAL OF ANODE CAP
Read the following NOTED items before starting work.
After turning the power off there might still be a potential
voltage that is very dangerous. When removing the
Anode Cap, make sure to discharge the Anode Cap's
potential voltage.
Do not use pliers to loosen or tighten the Anode Cap
terminal, this may cause the spring to be damaged.
*
*
REMOVAL
1. Follow the steps as follows to discharge the Anode Cap.
(Refer to Fig. 1-1.)
Connect one end of an Alligator Clip to the metal part of a
flat-blade screwdriver and the other end to ground.
While holding the plastic part of the insulated Screwdriver,
touch the support of the Anode with the tip of the
Screwdriver.
A cracking noise will be heard as the voltage is discharged.
Flip up the sides of the Rubber Cap in the direction of the
arrow and remove one side of the support.
(Refer to Fig. 1-2.)
2.
DISASSEMBLY INSTRUCTIONS
GND on the CRT
Screwdriver
Alligator Clip
Support CRT
GND on the CRT
Rubber Cap
CRT Support
Fig. 1-1
Fig. 1-2
3. After one side is removed, pull in the opposite direction to
remove the other.
NOTE
Take care not to damage the Rubber Cap.
INSTALLATION
1. Clean the spot where the cap was located with a small
amount of alcohol. (Refer to Fig. 1-3.)
B1-1
Location of Anode Cap
Fig. 1-3
NOTE
Confirm that there is no dirt, dust, etc. at the spot where
the cap was located.
2.
3.
Arrange the wire of the Anode Cap and make sure the
wire is not twisted.
Turn over the Rubber Cap. (Refer to Fig. 1-4.)
Fig. 1-4
4. Insert one end of the Anode Support into the anode button,
then the other as shown in Fig. 1-5.
5.
6. Confirm that the Support is securely connected. Put on the Rubber Cap without moving any parts.
CRT Support Fig. 1-5

B2-1
Masking Tape
(Cotton Tape)
DISASSEMBLY INSTRUCTIONS
2.
REMOVAL
IC
Put the Masking Tape (cotton tape) around the Flat
Package IC to protect other parts from any damage.
(Refer to Fig. 2-1.)
1.
Fig. 2-1
NOTE
REMOVAL AND INSTALLATION OF
FLAT PACKAGE IC
Some ICs on the PCB are affixed with glue, so be
careful not to break or damage the foil of each IC
leads or solder lands under the IC when removing it.
NOTE
Masking is carried out on all the parts located within
10 mm distance from IC leads.
Blower type IC
desoldering machine
IC
Heat the IC leads using a blower type IC desoldering
machine. (Refer to Fig. 2-2.)
2.
Fig. 2-2
NOTE
Do not add the rotating and the back and forth
directions force on the IC, until IC can move back and
forth easily after desoldering the IC leads completely.
When IC starts moving back and forth easily after
desoldering completely, pickup the corner of the IC using
a tweezers and remove the IC by moving with the IC
desoldering machine. (Refer to Fig. 2-3.)
3.
Blower type IC
desoldering
machine
IC Fig. 2-3
Tweezers
Peel off the Masking Tape.4.
Absorb the solder left on the pattern using the Braided
Shield Wire. (Refer to Fig. 2-4.)
5.
NOTE
Do not move the Braided Shield Wire in the vertical
direction towards the IC pattern.
Braided Shield Wire
Soldering Iron
Fig. 2-4
IC pattern

B2-2
DISASSEMBLY INSTRUCTIONS
Supply soldering
from upper position
to lower position
IC
Supply the solder from the upper position of IC leads
sliding to the lower position of the IC leads.
(Refer to Fig. 2-6.)
2.
Fig. 2-6
Soldering IronSolder
IC
Absorb the solder left on the lead using the Braided
Shield Wire. (Refer to Fig. 2-7.)
3.
Fig. 2-7
Soldering Iron
Braided Shield Wire
NOTE
Do not absorb the solder to excess.
IC
When bridge-soldering between terminals and/or the
soldering amount are not enough, resolder using a Thin-
tip Soldering Iron. (Refer to Fig. 2-8.)
4.
Fig. 2-8
Thin-tip Soldering Iron
NOTE
When the IC leads are bent during soldering and/or
repairing, do not repair the bending of leads. If the
bending of leads are repaired, the pattern may be
damaged. So, be always sure to replace the IC in this
case.
Finally, confirm the soldering status on four sides of the
IC using a magnifying glass.
Confirm that no abnormality is found on the soldering
position and installation position of the parts around the
IC. If some abnormality is found, correct by resoldering.
5.
Solder temporarily
Soldering Iron
INSTALLATION
Take care of the polarity of new IC and then install the
new IC fitting on the printed circuit pattern. Then solder
each lead on the diagonal positions of IC temporarily.
(Refer to Fig. 2-5.)
1.
Fig. 2-5
Solder temporarily

C-1
SERVICE MODE LIST
This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.
To enter the Service Mode, press both set key and remote control key for more than 2 seconds.
Set Key Remocon Key Operations
VOL. (-) MIN 0 Reset the user setting items (PICTURE, VOLUME and LANGUAGE) to the initial state
for delivery.
VOL. (-) MIN 1
Initialization of the factory.
NOTE: Do not use this for the normal servicing.
If you set a factory initialization, the memories are reset such as the
channel setting, and the POWER ON total hours.
VOL. (-) MIN 6
POWER ON total hours is displayed on the screen.
Refer to the "CONFIRMATION OF HOURS USED".
Can be checked of the INITIAL DATA of MEMORY IC.
Refer to the "WHEN REPLACING EEPROM (MEMORY) IC".
VOL. (-) MIN 8Writing of EEPROM initial data.
NOTE: Do not use this for the normal servicing.
VOL. (-) MIN Display of the Adjustment MENU on the screen.
Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).
9
If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to
ensure correct data settings while making reference to TABLE 1.
WHEN REPLACING EEPROM (MEMORY) IC
Table 1
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
The unit will now have the correct DATA for the new MEMORY IC.
Enter DATA SET mode by setting VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 2 seconds.
ADDRESS and DATA should appear as FIG 1.
ADDRESS is now selected and should "blink". Using the VOL. +/- button on the remote, step through the ADDRESS until
required ADDRESS to be changed is reached.
Press OK to select DATA. When DATA is selected, it will "blink".
Again, step through the DATA using VOL. +/- button until required DATA value has been selected.
Pressing OK will take you back to ADDRESS for further selection if necessary.
Repeat steps 3 to 6 until all data has been checked.
When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.
After the data input, set to the initializing of shipping.
Turn POWER on.
Press both VOL. DOWN button on the set and Channel button (1) on the remote control for more than 2 seconds.
After the finishing of the initializing of shipping, the unit will turn off automatically.
NOTE: No need setting for after INI 16 due to the adjustment value.
CONFIRMATION OF HOURS USED
POWER ON total hours can be checked on the screen. Total hours are displayed in 16 system of notation.
NOTE: If you set a factory initialization, the total hours is reset to "0".
1.
2.
3.
Set the VOLUME to minimum.
Press both VOL. DOWN button on the set and Channel
button (6) on the remote control for more than 2 seconds.
After the confirmation of using hours, turn off the power.
ADDRESS DATA
INIT 01 00
CRT ON 0010
FIG. 1
Initial setting content of MEMORY IC.
POWER ON total hours.
= (16 x 16 x 16 x thousands digit value)
+ (16 x 16 x hundreds digit value)
+ (16 x tens digit value)
+ (ones digit value)
---
+0 +1 +2 +3 +4 +5 +6 +7 +8 +9 +A +B +C +D +E +F
INI
10
00 23 18 F1 90 62 6E 5E F3 07 03 00 06 7300 38
98 98 3C C098
10 00 --- --- --- --- --- --- --- --- ---

ELECTRICAL ADJUSTMENTS
D-1
2. BASIC ADJUSTMENTS
2-1: CONSTANT VOLTAGE
1.
2.
3.
4.
Place the set with Aging Test for more than 15 minutes.
Connect the digital voltmeter to TP501.
Set condition is AV MODE without signal.
Adjust the VR501 until the DC voltage is 117 ±1V.
1. ADJUSTMENT PROCEDURE
Read and perform these adjustments when repairing the
circuits or replacing electrical parts or PCB assemblies.
CAUTION
•
•
•
•
Use an isolation transformer when performing any
service on this chassis.
Before removing the anode cap, discharge electricity
because it contains high voltage.
When removing a PCB or related component, after
unfastening or changing a wire, be sure to put the wire
back in its original position.
When you exchange IC and Transistor for a heat sink,
apply the silicon grease on the contact section of the
heat sink. Before applying new silicon grease, remove all
the old silicon grease. (Old grease may cause damages
to the IC and Transistor).
1. Oscilloscope
2. Digital Voltmeter
3. Pattern Generator
Prepare the following measurement tools for electrical
adjustments.
2-2: VCO
1.
2.
3.
4.
5.
6.
Place the set with Aging Test for more than 10 minutes.
Connect the oscillator (38.9MHz) to TP001.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (13) on the remote control to
select "VCO COARSE".
Press the VOL. +/- button on the remote control until
the "OK" appear on the screen. If the "OK" is not
displayed, select the "+" side on the changed from "+"
to "-".
Press the Page UP button once to set to "VCO FINE"
mode.
Press the VOL. +/- button on the remote control to
select the 4 step down point from the upper limit on the
"OK".
(Example: In case of the "OK" range 30~41, select 37.)
On-Screen Display Adjustment
1. In the condition of NO indication on the screen.
Press the VOL. DOWN button on the set and the
Channel button (9) on the remote control for more than
2 seconds to appear the adjustment mode on the
screen as shown in Fig. 1-1.
2.
3.
Use the Channel button (0-9) or Channel UP/DOWN
button on the remote control to select the options
shown in Fig. 1-2.
Press the MENU button on the remote control to end
the adjustments.
NO.
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
FUNCTION
CUT OFF
RF AGC
AGC GAIN
R DRIVE
R CUTOFF
G DRIVE
G CUTOFF
B DRIVE
H POSI (50)
V POSI (50)
V POSI (60)
V SIZE (50)
V SIZE (60)
VCO COARSE
VCO FINE
VCO COARSE L1
VCO FINE L1
BRIGHT CENT
BRIGHT MAX
BRIGHT MIN
NO.
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
FUNCTION
TINT
SHARP
CONTRAST CENT
CONTRAST MAX
CONTRAST MIN
COLOR CENT
COLOR MAX
COLOR MIN
M R CUT OFF
M G CUT OFF
M B CUT OFF
CVBS OUT
APR THRESHOLD
BELL FILTER
BANDPASS
H POSI OSD
V POSI OSD
H POSI TEXT
V POSI TEXT
H POSI (60) Fig. 1-2
Fig. 1-1
9- EXT VCO Status -
MMM
35 H POSI OSD
36 V POSI OSD
37 H POSI TEXT
38 V POSI TEXT
39 H POSI 60
00 CUT OFF
120
57
119
57
34
1.
2.
3.
4.
5.
Place the set with Aging Test for more than 15 minutes.
Receive the UHF (63 ±1dB).
Connect the digital voltmeter to pin 5 of CP101.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (01) on the remote control to
select "RF AGC".
Press the VOL. +/- button on the remote control until the
digital voltmeter is 2.4 ±0.05V.
2-4: AGC VOLTAGE
2-5: CUT OFF
1.
2.
3.
4.
5.
Set condition is AV MODE without signal.
Using the remote control, set the brightness and
contrast to normal position.
Place the set with Aging Test for more than 15 minutes.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (00) on the remote control to
select "CUT OFF".
Adjust the Screen Volume until a dim raster is obtained.
2-3: VCO COASE L1, VCO FINE L1
1.
2.
3.
4.
5.
6.
Place the set with Aging Test for more than 10 minutes.
Connect the oscillator (33.95MHz) to TP001.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (15) on the remote control to
select "VCO COARSE L1".
Press the VOL. +/- button on the remote control until the
"OK" appear on the screen. If the "OK" is not displayed,
select the "+" side on the changed from "-" to "+".
Press the Page UP button once to set to "VCO FINE
L1" mode.
Press the VOL. +/- button on the remote control to select
the 5 step down point from the upper limit on the "OK".
(Example: In case of the "OK" point 30~41, select 36.)

ELECTRICAL ADJUSTMENTS
D-2
Receive a 70dB monoscope pattern.
Turn the Focus Volume fully counterclockwise once.
Adjust the Focus Volume until picture is distinct.
2-7: FOCUS
1.
2.
3.
2-8: HORIZONTAL POSITION
1.
2.
3.
4.
5.
6.
7.
8.
Receive the monoscope pattern from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (08) on the remote control to
select "H POSI (50)".
Press the VOL. +/- button on the remote control until
the SHIFT quantity of the OVER SCAN on right and left
becomes minimum.
Receive the monoscope pattern of NTSC. (Audio Video
Input)
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (39) on the remote control to
select "H POSI (60)".
Press the VOL. +/- button on the remote control until
the SHIFT quantity of the OVER SCAN on right and left
becomes minimum.
2-6: WHITE BALANCE
NOTE: Adjust after performing CUT OFF adjustment.
1.
2.
3.
4.
5.
6.
7.
Place the set with Aging Test for more than 10 minutes.
Receive the gray scale pattern from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (03) on the remote control to
select "R DRIVE".
Press the Page UP/DOWN button on the remote control
to select the "R DRIVE", "G DRIVE", "M R CUTOFF" or
"M G CUTOFF".
Adjust the VOL. +/- button on the remote control to
whiten the R DRIVE, G DRIVE, M R CUT OFF, and M G
CUT OFF at each step tone sections equally.
Perform the above adjustments 5 and 6 until the white
color is looked like a white.
Receive the monoscope pattern from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (11) on the remote control to
select "V SIZE (50)".
Adjust by using the VOL. +/- button on the remote
control so that the Up/Down OVER SCAN Quantity
becomes equal to the Right/Left OVER SCAN Quantity.
Receive a broadcast and check if the picture is normal.
Receive the monoscope pattern of NTSC. (Audio Video
Input)
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (12) on the remote control to
select "V SIZE (60)".
Adjust by using the VOL. +/- button on the remote
control so that the Up/Down OVER SCAN Quantity
becomes equal to the Right/Left OVER SCAN Quantity.
2-9: VERTICAL SIZE
1.
2.
3.
4.
5.
6.
7.
8.
9.
Receive the monoscope pattern from the Pattern
Generator.
Using the remote control, set the brightness and
contrast to normal position.
Adjust the VR401 until the horizontal line becomes fit to
the notch of the shadow mask.
Adjust the VR420 until the SHIFT quantity of the OVER
SCAN on upside and downside becomes minimum.
2-10: VERTICAL POSITION/VERTICAL LINEARITY
1.
2.
3.
4.
2-11: BRIGHT CENT
1.
2.
3.
4.
5.
6
7.
Receive the PAL black pattern*. (RF Input)
Using the remote control, set the brightness and
contrast to normal position.
Place the set with Aging Test for more than 15 minutes.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (17) on the remote control to
select "BRIGHT CENT".
Press the VOL. +/- button on the remote control until
the screen begin to shine.
Receive the PAL black pattern*. (Audio Video Input)
Set to the AV mode. Then perform the above
adjustments 2~5.
*The Black Pattern means the whole black raster signal.
Select the "RASTER" of the pattern generator, set to
the OFF position for each R, G and B.
2-12: CONTRAST CENT
1.
2.
3.
4.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (22) on the remote control to
select "CONTRAST CENT".
Press the VOL. +/- button on the remote control until
the contrast step No. becomes "40".
Receive a broadcast and check if the picture is normal.
Set to the AV mode. Then perform the above
adjustments 1~3.

ELECTRICAL ADJUSTMENTS
D-3
2-14: TINT
1.
2.
3.
4.
5.
Receive the NTSC color bar pattern. (Audio Video Input)
Using the remote control, set the brightness and contrast
to normal position.
Connect the oscilloscope to TP024.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (20) on the remote control to
select "TINT".
Press the VOL. +/- button on the remote control until the
section "A" becomes a straight line. (Refer to Fig. 2-2)
Fig. 2-2
"A"
2-13: COLOR CENT
1.
2.
3.
4.
5.
6.
7.
8.
Receive the PAL color bar pattern. (RF Input)
Using the remote control, set the brightness, contrast
and color to normal position.
Connect the oscilloscope to TP022.
Activate the adjustment mode display of Fig. 1-1 and
press the channel button (25) on the remote control to
select "COLOR CENT".
Adjust the VOLTS RANGE VARIABLE knob of the
oscilloscope until the range between white 100% and
0% is set to 5 scales on the screen of the oscilloscope.
Press the VOL. +/- button on the remote control until
the red color level is adjusted to 85 ±10% of the white
level. (Refer to Fig. 2-1)
Receive the PAL color bar pattern. (Audio Video Input)
Set to the AV mode. Then perform the above
adjustments 2~6.
Fig. 2-1
85% 2-16: Confirmation of Fixed Value (Step No.)
Please check if the fixed values of the each adjustment
items are set correctly referring below.
NO.
02
04
06
07
09
10
18
19
20
21
23
24
26
27
30
31
32
33
34
36
37
38
FUNCTION
AGC GAIN
R CUTOFF
G CUTOFF
B DRIVE
V POSI (50)
V POSI (60)
BRIGHT MAX
BRIGHT MIN
TINT
SHARP
CONTRAST MAX
CONTRAST MIN
COLOR MAX
COLOR MIN
M B CUT OFF
CVBS OUT
APR THRESHOLD
BELL FILTER
BANDPASS
V POSI OSD
H POSI TEXT
V POSI TEXT
RF
00
00
00
45
08
00
35
09
30
03
50
10
50
10
127
31
00
00
00
57
115
57
AV
---
---
---
---
---
---
35
09
ADJ.
03
50
10
50
10
---
---
---
---
---
---
---
---
---
*To check for the fixed values of the RF (60Hz), indicate
the adjustment mode screen while input the 60Hz video
signal.
9- EXT VCO Status -
MMM
35 H POSI OSD
36 V POSI OSD
37 H POSI TEXT
38 V POSI TEXT
39 H POSI 60
00 CUT OFF
120
57
119
57
34
2-15: OSD HORIZONTAL
1.
2.
3.
Using the remote control, set the brightness and
contrast to normal position.
Activate the adjustment mode display of Fig. 1-1.
Press the VOL. +/- button on the remote control until
the difference of A and B becomes minimum.
(Refer to Fig. 2-3)
AB
Fig. 2-3

ELECTRICAL ADJUSTMENTS
D-4
3.
1.
2.
3.
1.
2.
3.
4.
5.
6.
7.
8.
3-2: PURITY
NOTE
Adjust after performing adjustments in section 3-1.
1.
2.
3.
4.
5.
Receive the green raster pattern from color bar
generator.
Adjust the pair of purity magnets to center the
color on the screen.
Adjust the pair of purity magnets so the color at the
ends are equally wide.
Move the deflection yoke backward (to neck side)
slowly, and stop it at the position when the whole
screen is green.
Confirm red and blue colors.
Adjust the slant of the deflection yoke while watching the
screen, then tighten the fixing screw.
DEFLECTION YOKE
DEFLECTION YOKE SCREW
MAGNET SCREW
PURITY MAGNETS
6 POLE MAGNETS
4 POLE MAGNETS
Fig. 3-1
PURITY AND CONVERGENCE
ADJUSTMENTS
NOTE
NOTE
3-1: STATIC CONVERGENCE (ROUGH ADJUSTMENT)
Tighten the screw for the magnet. Refer to the adjusted
CRT for the position. (Refer to Fig. 3-1)
If the deflection yoke and magnet are in one body,
untighten the screw for the body.
Receive the green raster pattern from the color bar
generator.
Slide the deflection yoke until it touches the funnel
side of the CRT.
Adjust center of screen to green, with red and blue on the
sides, using the pair of purity magnets.
Switch the color bar generator from the green raster
pattern to the crosshatch pattern.
Combine red and blue of the 3 color crosshatch pattern
on the center of the screen by adjusting the pair of
4 pole magnets.
Combine red/blue (magenta) and green by adjusting the
pair of 6 pole magnets.
Adjust the crosshatch pattern to change to white
by repeating steps 6 and 7.
Turn the unit on and let it warm up for at least 30
minutes before performing the following adjustments.
Place the CRT surface facing east or west to reduce the
terrestrial magnetism.
Turn ON the unit and demagnetize with a Degauss Coil.
Adjust after performing adjustments in section 3-2.
3-3: STATIC CONVERGENCE
1.
2.
3.
3-4: DYNAMIC CONVERGENCE
NOTE
Adjust after performing adjustments in section 3-3.
1.
2.
Adjust the differences around the screen by moving
the deflection yoke upward/downward and right/left.
(Refer to Fig. 3-2-a)
Insert three wedges between the deflection yoke and
CRT funnel to fix the deflection yoke.
(Refer to Fig. 3-2-b)
R G B
R
G
B
Fig. 3-2-a
WEDGE WEDGE
WEDGE
WEDGE POSITION
Fig. 3-2-b
R G B
R
G
B
UPWARD/DOWNWARD SLANT RIGHT/LEFT SLANT
Receive the crosshatch pattern from the color bar
generator.
Combine red and blue of the 3 color crosshatch pattern
on the center of the screen by adjusting the pair of
4 pole magnets.
Combine red/blue (magenta) and green by adjusting the
pair of 6 pole magnets.

D-5
ELECTRICAL ADJUSTMENTS
4. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION)
MAIN PCB
TU001
VR420
CP401
OS101
CP1001
VR401
CP802A
FB401
CP502
J701
CD802
CP803A
CP803B
TP024
TP022
J801
CP806
CP802B
R805
R803
SPEAKER
CRT
CD803
CP501
AC IN
CD501
TP501 R521
CRT PCB
DEGAUSS COIL
L302
TP001
CP101
CP801
VR501
CD801
CRT

MICON W/T.TEXT IC
IC101 OECF013B TU001
CHROMA IC
IC201 STV2248E
A2/NICAM/DOLBY IC
IC902 MSP3410G-QA-B8
SOUND AMP IC
IC1002 AN5276
V-DRIVE
IC401 TDA8174A
FB401
SW TRANS
T501
CVBSOUT1
XTAL2
29
39
VCC_IF
VCC_D
53
12
OSD-R
36
XTAL1
40
VCC1
VCC2
17
45
OSD-G
35 OSD-B
34
FM_OUT
11
7 154 11
SCL SDA BPL AGC IF
768
I2C
P.CON+5V
SDA 19
OSD-B
OSD-G 16
15
SCL 20
OSD-R
CVBS2 33
17
CVBS1 34
SDA
5
SCL
6
MEMORY IC
IC199
S-24C16AFJA-TB-01
31
39
1
25
50
STANDBY LED
AVDD1
AVDD2
ON_TIMER
AVDD3
REMORT
OSC_OUT
X101
4MHz
STAND BY/P.ON
D101
ON TIMER
D103
Q103
LED DRIVE
Q102
LED DRIVE
AT+5V
X602
3.579545MHz X601
4.433619MHz
1
OS101
RF_AGC_OUT
PIFIN1
PIFIN2
VERT 47
SDA
H_OUT 48
52
SCL 51
B.OUT
G.OUT 31
30
R.OUT 32
P.CON+5V
P.CON+8V
3TRIGGER INPUT
10
1
Vs
POWER OUTPUT
P.CON+25V
Q802, Q806
BLUE AMP
Q803, Q805
GREEN AMP
Q801, Q804
RED AMP
J801
6
11
8
F
7
Q402
H.DRIVE
Q401
H.OUTPUT
I2C
DY
1
F
S
2
3
HV
+B
P.CON+25V
CRT
V801
71
XTAL_OUT
72
XTAL_IN
X901
18.432MHz
DVSUP
AVSUP
66
11
P.CON+5V
312C_CL
2I2C
ANA_IN1+ 67
AHVSUP
39
P.CON+8V
DACM_L
27
DACM_R
28
25712
+ +
+
-
+
-
2
7
5
1
HEADPHONE JACK
J702
SPEAKER
SP351
5
12
9SOUND+B
15
+B
P.CON+8V
D
Q501
POWER
56
KEY_IN CH UP
VIDEO_SW IC
IC702 MM1501XNRE
OUT
IN2
4
2
CVBSIN2 20
AV1 42
J701
3
1
22
IN1
6
2
24
6
27
23
19
20
INT_CVBS_OUT 13
VIDEO OUT
VIDEO IN
37
SC1_OUT_R 36
34
33
SC1_OUT_L
SC2_OUT_R
SC2_OUT_L
R OUT
L OUT
R OUT
L OUT
56
SC1_IN_R 57
53
54
SC1_IN_L
SC2_IN_R
SC2_IN_L
R IN
L IN
R IN
L IN
41
40
26
27
25
44
22
VIDEO OUT
VIDEO IN
11
7
15
21-B IN
21-G IN
21-R IN
CVBSOUT2
Y/CVBS_IN3
G_EXT/Y_EXT
R_EXT/V_EXT
B_EXT/U_EXT
51
50
SC3_IN_L
SC3_IN_R
SW
1
1
3
2
1
3
2
1
3
2
FRONT VIDEO
J703
FRONT AUDIO L
J704
FRONT AUDIO R
J705
BLOCK DIAGRAM
9
VOL DOWN
49
LR
10
VCC
SOUND+B
16 AT+5V
P.CON+5V
R
L
12C_DA
VOL UP
CH DOWN
3
51 OSC_IN
2RESET
1
RESET IC
IC102 PST3231NR
E-1 E-2

TU001
CP101
J701
C002
L001
CP001
HS1002
C1008
IC1002
R112
SW104
SW102
SW107
SW106
R136
J704 J703
J705
J702
R725
R706
W001
D723
D712
R715
R714 R716
R713
L701
L703
L706
L707
L709
L708
L711
L710
C711
R543
W829
VR420
D520
D516
D513
C442
C437_2
CP401
IC401
C403
D410
T401_1
Q402 R446
C414_1
C448
R416
C418
R407
C417
D403
R426
R418
C412
HS401
HS503
C517_1
IC502
HS502
L401
Q509
R544 R545
Q513
R546
Q514
R547
C511
C523
D517
W002
L716
L715
B702
B701
C754
D101D103
C408_1
B504
C757
W003
OS101
C446
D526
R521
W004
R707
D405
IC503
C531
CP1001
L403
C518_1
R402
ICP501
CP803A
ICP502
D604
D407
R408
R406
R417
R401
R412
VR401_1
R425
R411
R121
R003 C723
L713
R712
W005
R004
C942
C936
C937
L904
L905
C911
C939
X901
W006
W007
W008
W009
R910
R909
W010
W011
D527
W012 L702
L705
W014 W015
W016
W018
C924_1
C923
W025
W026
W028
C613
CP802A
W019
W020
R646
X602
L202
L203
IC201
C209
L206
C610
L601
C217
C220
CF201
L204
C611
L208
X601
W021
CF204
R305
R213
L302
L207
W023 W024
R626
R602
W029
R604
R606
W030
R424
D406
W032
W033
W817
D402
W035
W036
R518
R530
R524
W037
R532
R410
D404
R403 D408
R550
D505
Q511
C522
W038
D519
D001
R717
W039
R1014
W040
W041
W042
W044
W045
W046
W047
W048
W049
C1002_1
C1001_1
W050
R422
W051
D603
W052
W053
W054
W055
W844
W842
W056
R150
W057
W058
W059
W060
W061
C115
C131
W062
D102
L101
L102
W063
IC101
X101
C121
D512
D515
W064
W065
W066
D1001
R109
W067
W068
W069
W070
W071
W072
W073
W074
W075
W076
W077
W078
W079
Q401 HS402
W080
R421
W081
W082
C618
W083
C620
R152
W084
R1004
C638
R428
R423
C930
C931
C932
W087
C933
W825
R528
W088
D108
C533
C743
W876
W875
W874
CP803B
TP023
TP024
C802
TP022
R807
R803
R805
R804
R802
Q805 J801
CP806_1
R806
CP801_1
CP802B
R819
D805
D804
C809
R813
C811
R815
D806
D521
W089
W090
W091
W092
W094
W803
W095
W096
D401
W097
W098
R147 R144
R145
R146
W099
W100
W101
W102
W103
C608
C622
C606
W104
W105
W106
W107
W109
W110
W111
W112
W113
C503_1
C404
C1014_1
C1004
C1009
C1015
C1013
C728
C634
W114
W115
W116
W118
W119
W120
W121
W122
W123
W124
W125
D508
D509
R430
W126
W127
W128
W129
W130
R517
D507
D533
R519
D525
Q507
R508
VR501
Q505
D506
W131
W132
W133
Q804
Q806
W134
W135
W136
C515
W137
C920
C541
C901
C422
C444
C407
C440_1
D514
D511
D609
SW501
RY501
CP502
C525
C540
T501_1
R536
IC506
D531
R511
W138
R531
Q502
C539
D532
R535
R510
R534
D530
C536_1
R529
W139
R552
C532
Q501
B501
HS501
R516
W814
R503
TH501
L501
C501_1
FH502
C526_1
D504
D501
D503
D502
C507
C505_2
R501
R509
D528
W140
C506
CP501
FH501
F501
W141
C635
D605
W832
W828
W845
W826
W839
W823
W816
W809
Q801
D801 Q803
Q802
D803
D802
R634
R719
R720
R308
S808Y
S808X
C122
C003
R307
R304
CF301
CF304
CF202_1
FB401
W085
W022
C537_3
W846
R721
CD802A
CD802B
CD803B
CD803A
D611
D602
PRINTED CIRCUIT BOARDS
MAIN/CRT (INSERTED PARTS)
SOLDER SIDE
F-1 F-2

1
25
41
64
R006 C001
C006
R104
Q103
R103
R101
R102
Q102
R132
R704
R739
R738
Q703
Q704
R731
R728
R730
R727
R729 R726
C730
C729
C722
C720
R736
R732
R737
C716
C721
C719
R702
R709
R005
R137
R420
C502_2
C753
C007
R541
R744
R747
R748
R743
C762
C759
R419
R710
R705
R746 C726 R745 C727
C731
C732
R733
IC702
Q701
R751
IC902
C921
C941
C938
C909 C910
C929
C906
C905
C902
C903
C904
C914
C944
C913
C945 C946
C919
C918
C917
R750
R749
C916
C912
C915
Q609
C633
C605_2
C612
C607_2
C603_2
R217
R630
R629
R628
C218
C303_1
R311
Q201
C204
C212
C203
R202
R215
C609
R312
R214 R201
C202
C207_1
R218
R622
C616
C615_2
R608
C221
C215
Q204
C614_2
R204
R607
R638
R645
R636
R639
C205
C201
R643
R641
R206
R219
C626
C213_2
C206_2
R303
C304_1 R302
Q301
C604
C210_2
Q403
R427
R538 R537 Q510
C1010
C1012
R1010
R1003
R1011
C143
C105
C141
R107
R108
R151
C140
C129
R125
C139_1
R128 R129
R502
Q503
R143
R141
R140
R142
IC199
R148
C101
R116
R114
R131
C108C109
C120_2
R120
R134
R124 R123
IC102
R106
R105
C125 C126 C127 C128 C114
C116 C118
C102
C103
R110
C111_1
C112
C106_1
R111
C113 R113
C104
R115 C119
Q1002
C736 C737
C530
Q508
C504
Q512
C602_1
C623
R618
R906
R907
R904R905
R133
R507
R542
R631
R811
R814
R809
R818
R812
R816
R817 C810
C619
R647
R548
R603
R605
Q601
R601
R540
C543
C509
R512
C524
C508
C132
W142
W143
R1005
R801
R810
R808
Q702
R126
Q304
Q302
Q303
R310
R301
R309
R306
C305
C306
C302
C301
D301
W859
W860
C629
R718
PRINTED CIRCUIT BOARDS
MAIN/CRT (CHIP MOUNTED PARTS)
SOLDER SIDE
F-3 F-4
B_SHORT
