FILE NO. 023-200315
SERVICE MANUAL
– SUMMARY –
N3PSP Chassis
COLOR TELEVISION
51HX83
(TAC0355)
51HX83 is the same as 57H83 except for the parts tabled on back of this sheet.
Use this service manual together with the service manual of 51H83, 57H83, 65H83 (File No.
020-200307).

REPLACEMENT PARTS LIST DIFFERENCES
Location
No. Part No. Description
Location
No. Part No. Description
A001 23411874 Cabinet, Wood Cabinet Ship
A102 23527268 G ille, Speake G ille Assembly
A201 23532007 Cove , Bezel
A202 23450694 Panel, Cont ol Panel Assembly
A213 23428227 Doo
A223 23445719 Button, Powe Button
A268 23530772 Cove , F ont Cove
A331 23929942 Piece, Bottom Pole L
A332 23929943 Piece, Bottom Pole R
A401 23530781 Cove , Back Cove
A701 23067147 Ca ton
A703 23946479 Packing, Top Packing
A708 23946478 Packing, Bottom Packing
A709 23946483 Packing, Bottom T ay
C412 24828104 PF, 0.1?F, 200V
C707 24797101 EL, 100?F, ±20%, 50V
C760 24797101 EL, 100?F, ±20%, 50V
C780 24797101 EL, 100?F, ±20%, 50V
C904 24436561 CD, 560pF
C914 24436681 CD, 680pF
C915 24679330 EL, 33?F, ±20%, 250V
C923 24436681 CD, 680pF
C967 24436331 CD, 330pF
C9100 24436331 CD, 330pF
C9200 24436331 CD, 330pF
CB51 24590103 PF, 0.01?F
CB52 24794470 EL, 47?F, ±20%, 16V
CB53 24503041 PF, 0.1?F, 63V
CB54 24436221 CD, 220pF
CB55 24797010 EL, 1?F, ±20%, 50V
CB56 24794470 EL, 47?F, ±20%, 16V
CB58 24794470 EL, 47?F, ±20%, 16V
CB59 24590103 PF, 0.01?F
CB60 24794100 EL, 10?F, ±20%, 16V
CB61 24503041 PF, 0.1?F, 63V
CB501 24092730 Chip, 0.1?F, ±10%, 16V
CB502 24666100 EL, 10?F, ±20%, 16V
CB503 24092730 Chip, 0.1?F, ±10%, 16V
CB504 24666100 EL, 10?F, ±20%, 16V
D902 23118859 Diode, 1SS133
D911 23118859 Diode, 1SS133
D916 23115337 Diode, 1S1834
D917 23118859 Diode, 1SS133
D918 23118859 Diode, 1SS133
D922 23118859 Diode, 1SS133
D924 23118859 Diode, 1SS133
D925 23118859 Diode, 1SS133
D931 23118859 Diode, 1SS133
D932 23118859 Diode, 1SS133
D933 23118859 Diode, 1SS133
D934 23118859 Diode, 1SS133
D939 23118859 Diode, 1SS133
D946 23118859 Diode, 1SS133
D961 23118859 Diode, 1SS133
D962 23118859 Diode, 1SS133
D963 23118859 Diode, 1SS133
D964 23118859 Diode, 1SS133
D965 23118859 Diode, 1SS133
D966 23118859 Diode, 1SS133
– 2 –
DB51 23358573 Photo Diode, PIN 940NM,
HPI-2FER4
DB52 23118859 Diode, 1SS133
DB54 23118859 Diode, 1SS133
DB55 23118859 Diode, 1SS133
DB56 23118859 Diode, 1SS133
DB501 23118041 Diode, MA111
DB504 23118041 Diode, MA111
K501 23311015 Sc een, 51KNH Lenticula Sheet,
SCREEN51KNHL
K502 23311016 Sc een, 51KN F esnel Sheet,
SCREEN51KN-F
K601 23405249 Mi o , 51WL
K912 23306504 Remote Hand Unit,IR CTVUSA,
CT-90164
K913 23306465 Remote Hand Unit, IR BLAST
VTR CONT
L472 23102499 Magnet, CPM29.1VM, MAG-1119
L473 23102499 Magnet, CPM29.1VM, MAG-1119
L474 23102499 Magnet, CPM29.1VM, MAG-1119
L902 23289100 Coil, Peaking, TRF4100AF
L903 23289101 Coil, Peaking, TRF4101AF
L911 23237987 Coil, Peaking, TRF4100AC
L912 23289101 Coil, Peaking, TRF4101AF
L913 23289100 Coil, Peaking, TRF4100AF
L922 23289101 Coil, Peaking, TRF4101AF
L923 23289150 Coil, Peaking, TRF4150AF
L961 23238714 Coil, Peaking, TRF4100AJ
LB51 23237987 Coil, Peaking, TRF4100AC
Q901 23314971 T ansisto , 2SC5360(FA)
Q902 23114433 T ansisto , 2SC1815-Y
Q911 23314971 T ansisto , 2SC5360(FA)
Q912 23114433 T ansisto , 2SC1815-Y
Q913 23114735 T ansisto , 2SA102-Y(C)
Q921 23314971 T ansisto , 2SC5360(FA)
Q922 23114433 T ansisto , 2SC1815-Y
Q961 23114433 T ansisto , 2SC1815-Y
Q962 23114735 T ansisto , 2SA102-Y(C)
Q973 23114735 T ansisto , 2SA102-Y(C)
QB51 23319808 IC, M5218AP
QB52 23314965 T ansisto , KTC3198 Y
QB53 23314962 T ansisto , KTA1266 Y
QB501 23009558 IC, BLASTER, S3C80F9XKZ
QB502 23114422 T ansisto , 2SA562TM-Y
QB504 23314993 T ansisto , 2SC4081 Q
QB505 23314993 T ansisto , 2SC4081 Q
QB506 23904123 IC, TC4W53F
QB507 23314993 T ansisto , 2SC4081 Q
QB508 23114422 T ansisto , 2SA562TM-Y
R715 24366273 CF, 27k ohm
R725 24366222 CF, 2200 ohm
R742 24322229 MF, 2.2 ohm, 1W
R746 24366101 CF, 100 ohm
R748 24366101 CF, 100 ohm
R900 24000907 FR, 3.9 ohm, 1W
R901 24366101 CF, 100 ohm
R903 24942102 CC, 1k ohm, 1/2W
R904 24366222 CF, 2200 ohm
R905 24366330 CF, 33 ohm
R906 24366331 CF, 330 ohm

Location
No. Part No. Description Location No. Part No. Description
–3 –
R908 24366150 CF, 15 ohm
R909 24366330 CF, 33 ohm
R911 24366101 CF, 100 ohm
R913 24942102 CC, 1k ohm, 1/2W
R914 24366222 CF, 2200 ohm
R916 24366331 CF, 330 ohm
R918 24366100 CF, 10 ohm
R919 24366270 CF, 27 ohm
R920 24366562 CF, 5600 ohm
R921 24366101 CF, 100 ohm
R923 24942102 CC, 1k ohm, 1/2W
R924 24366222 CF, 2200 ohm
R925 24366390 CF, 39 ohm
R926 24366331 CF, 330 ohm
R928 24366100 CF, 10 ohm
R929 24366330 CF, 33 ohm
R930 24366153 CF, 15k ohm
R943 24383153 OMF, 15k ohm, 2W
R948 24366562 CF, 5600 ohm
R949 24366153 CF, 15k ohm
R953 24383153 OMF, 15k ohm, 2W
R959 24366150 CF, 15 ohm
R961 24366152 CF, 1500 ohm
R962 24366102 CF, 1k ohm
R965 24366471 CF, 470 ohm
R987 24366470 CF, 47 ohm
R991 24366562 CF, 5600 ohm
R992 24366153 CF, 15k ohm
R995 24366100 CF, 10 ohm
R9501 24366470 CF, 47 ohm
R9507 24366220 CF, 22 ohm
R9607 24366470 CF, 47 ohm
R9620 24366100 CF, 10 ohm
RA22 24011102 Chip, 1k ohm, 1/20W
RA23 24011102 Chip, 1k ohm, 1/20W
RB51 24366224 CF, 220k ohm
RB52 24366123 CF, 12k ohm
RB53 24366123 CF, 12k ohm
RB54 24366123 CF, 12k ohm
RB55 24366224 CF, 220k ohm
RB56 24366151 CF, 150 ohm
RB57 24366103 CF, 10k ohm
RB58 24366103 CF, 10k ohm
RB59 24366122 CF, 1200 ohm
RB60 24366224 CF, 220k ohm
RB61 24366100 CF, 10 ohm
RB62 24366272 CF, 2700 ohm
RB63 24366271 CF, 270 ohm
RB67 24366221 CF, 220 ohm
RB69 24366272 CF, 2700 ohm
RB70 24366331 CF, 330 ohm
RB501 24998100 Chip, 10 ohm, 1/160W
RB502 24011332 Chip, 3300 ohm, 1/20W
RB503 24011332 Chip, 3300 ohm, 1/20W
RB504 24011104 Chip, 100k ohm, 1/20W
RB505 24011101 Chip, 100 ohm, 1/20W
RB506 24998101 Chip, 100 ohm, 1/16W
RB507 24998101 Chip, 100 ohm, 1/16W
RB508 24998101 Chip, 100 ohm, 1/16W
RB509 24998101 Chip, 100 ohm, 1/16W
RB516 24011472 Chip, 4700 ohm, 1/20W
RB517 24011472 Chip, 4700 ohm, 1/20W
RB518 24011101 Chip, 100 ohm, 1/20W
RB519 24011472 Chip, 4700 ohm, 1/20W
RB520 24011472 Chip, 4700 ohm, 1/20W
RB521 24011472 Chip, 4700 ohm, 1/20W
RB522 24011472 Chip, 4700 ohm, 1/20W
RB523 24011103 Chip, 10k ohm, 1/20W
RB524 24011103 Chip, 10k ohm, 1/20W
RB525 24011101 Chip, 100 ohm, 1/20W
RB526 24011103 Chip, 10k ohm, 1/20W
RB528 24011472 Chip, 4700 ohm, 1/20W
RB529 24011472 Chip, 4700 ohm, 1/20W
RB554 24011101 Chip, 100 ohm, 1/20W
RB555 24011103 Chip, 10k ohm, 1/20W
RB556 24011101 Chip, 100 ohm, 1/20W
RB557 24011103 Chip, 10k ohm, 1/20W
RB558 24011104 Chip, 100k ohm, 1/20W
RB559 24011103 Chip, 10k ohm, 1/20W
RB560 24011103 Chip, 10k ohm, 1/20W
RB561 24011101 Chip, 100 ohm, 1/20W
RB562 24011104 Chip, 100k ohm, 1/20W
RB563 24998101 Chip, 100 ohm, 1/16W
RB564 24998101 Chip, 100 ohm, 1/16W
RB565 24998101 Chip, 100 ohm, 1/16W
RB566 24998101 Chip, 100 ohm, 1/16W
* T461 23236756 T ansfo me , Flyback,
TFB3092BH
* T862 23217598 T ansfo me , Conve te ,
TPW3516AS
*E031Z 23788810 CRT-D/R Boa d, PD1200B-1
*E032Z 23788811 CRT-D/G Boa d, PD1200B-2
*E033Z 23788812 CRT-D/B Boa d, PD1200B-3
*E034Z 23788813 SVM/R Boa d, PD1200B-4
*E035Z 23788814 SVM/G Boa d, PD1200B-5
*E036Z 23788815 SVM/B Boa d, PD1200B-6
*E041Z 23788825 FRONT-CON Boa d, PD1154B-1
*E042Z 23788826 FRONT-IN Boa d, PD1154B-2
*E043Z 23788827 REM Boa d, PD1154B-3
*E044Z 23788828 FRONT-SEN Boa d, PD1154B-4
*E045Z 23788823 IR BLASTER Boa d, PD1289
*U401 23788630 DEFCONVER Boa d, PD1147B
*U801 23788629 POWER Boa d, PD1151B
*U901 23788628 SIGNAL Boa d, PD1146B
* V901R 23071861 Othe Block, CRT COUPLING R
* V902G 23071862 Othe Block, CRT COUPLING G
* V903B 23071863 Othe Block, CRT COUPLING B
W663 23351220 Speake , TWC 50X50 16-ohm
20W, SPK-1417BM
W664 23351220 Speake , TWC 50X50 16-ohm
20W, SPK-1417BM
XB501 23153504 Ce amic Resonato , 8.00MHz,
TCR1056BM
Y101 23565935 Owne ’s Manual English/
F ench, 57HX83

TOSHIBA CORPORATION
1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN
