FILE NO. 023-200308
SERVICE MANUAL
– SUMMARY –
N3PSP Chassis
COLOR TELEVISION
57HX83
(TAC0355)
57HX83 is the same as 57H83 except for the parts tabled on back of this sheet.
Use this service manual together with the service manual of 51H83, 57H83, 65H83 (File No.
020-200307).

REPLACEMENT PARTS LIST DIFFERENCES
Location
No. Part No. Description
Location
No. Part No. Description
A001 23411875 Cabinet, Wood Cabinet Ship
A102 23527284 Grille, Speaker Grille
A201 23530860 Cover, Be el Proper
A202 23450694 Panel, Control Panel Assembly
A213 23428227 Door
A223 23445719 Button, Power
A331 23929940 Piece, Bottom Pole L
A332 23929941 Piece, Bottom Pole R
A701 23067146 Carton
C412 24828104 PF, 0.1?F, 200V
CB51 24590103 PF, 0.01?F
CB52 24794470 EL, 47?F, ±20%, 16V
CB53 24503041 PF, 0.1?F, 63V
CB54 24436221 CD, 220pF
CB55 24797010 EL, 1?F, ±20%, 50V
CB56 24794470 EL, 47?F, ±20%, 16V
CB58 24794470 EL, 47?F, ±20%, 16V
CB59 24590103 PF, 0.01?F
CB60 24794100 EL, 10?F, ±20%, 16V
CB61 24503041 PF, 0.1?F, 63V
CB501 24092730 Chip, 0.1?F, ±10%, 16V
CB502 24666100 EL, 10?F, ±20%, 16V
CB503 24092730 Chip, 0.1?F, ±10%, 16V
CB504 24666100 EL, 10?F, ±20%, 16V
DB51 23358573 Photo Diode, PIN 940NM,
HPI-2FER4
DB52 23118859 Diode, 1SS133
DB54 23118859 Diode, 1SS133
DB55 23118859 Diode, 1SS133
DB56 23118859 Diode, 1SS133
DB501 23118041 Diode, MA111-(TX)
DB504 23118041 Diode, MA111-(TX)
K501 23311955 Screen, Lenticular Sheet,
SCREEN57DM-L
K502 23311956 Screen, Fresnel Sheet,
SCREEN57DM-F
K503 23464992 Shielding, Protective Shield
* K912 23306504 Remote Hand Unit, CT-90164
L472 23102499 Magnet, CPM29.1VM, MAG-1119
L473 23102499 Magnet, CPM29.1VM, MAG-1119
L474 23102499 Magnet, CPM29.1VM, MAG-1119
LB51 23237987 Coil, Peaking, TRF4100AC
QB51 23319808 IC, M5218AP
QB52 23314965 Transistor, KTC3198 Y
QB53 23314962 Transistor, KTA1266 Y
QB501 23009558 IC, BLASTER IC, S3C80F9XKZ
QB502 23114422 Transistor, 2SA562TM-Y
QB504 23314993 Transistor, 2SC4081 Q
QB505 23314993 Transistor, 2SC4081 Q
QB506 23904123 IC, TC4W53F
QB507 23314993 Transistor, 2SC4081 Q
QB508 23114422 Transistor, 2SA562TM-Y
R900 24000907 FR, 3.9 ohm, 1W
R909 24366150 CF, 15 ohm
R919 24366150 CF, 15 ohm
R925 24366150 CF, 15 ohm
RA22 24011102 Chip, 1k ohm, 1/20W
RA23 24011102 Chip, 1k ohm, 1/20W
RB51 24366224 CF, 220k ohm
RB52 24366123 CF, 12k ohm
RB53 24366123 CF, 12k ohm
RB54 24366123 CF, 12k ohm
RB55 24366224 CF, 220k ohm
RB56 24366151 CF, 150 ohm
RB57 24366103 CF, 10k ohm
RB58 24366103 CF, 10k ohm
RB59 24366122 CF, 1200 ohm
RB60 24366224 CF, 220k ohm
RB61 24366100 CF, 10 ohm
RB62 24366272 CF, 2700 ohm
RB63 24366271 CF, 270 ohm
RB67 24366221 CF, 220 ohm
RB69 24366272 CF, 2700 ohm
RB70 24366331 CF, 330 ohm
RB501 24998100 Chip, 10 ohm, 1/16W
RB502 24011332 Chip, 3300 ohm, 1/20W
RB503 24011332 Chip, 3300 ohm, 1/20W
RB504 24011104 Chip, 100k ohm, 1/20W
RB505 24011101 Chip, 100 ohm, 1/20W
RB506 24998101 Chip, 100 ohm, 1/16W
RB507 24998101 Chip, 100 ohm, 1/16W
RB508 24998101 Chip, 100 ohm, 1/16W
RB509 24998101 Chip, 100 ohm, 1/16W
RB516 24011472 Chip, 4700 ohm, 1/20W
RB517 24011472 Chip, 4700 ohm, 1/20W
RB518 24011101 Chip, 100 ohm, 1/20W
RB519 24011472 Chip, 4700 ohm, 1/20W
RB520 24011472 Chip, 4700 ohm, 1/20W
RB521 24011472 Chip, 4700 ohm, 1/20W
RB522 24011472 Chip, 4700 ohm, 1/20W
RB523 24011103 Chip, 10k ohm, 1/20W
RB524 24011103 Chip, 10k ohm, 1/20W
RB525 24011101 Chip, 100 ohm, 1/20W
RB526 24011103 Chip, 10k ohm, 1/20W
RB528 24011472 Chip, 4700 ohm, 1/20W
RB529 24011472 Chip, 4700 ohm, 1/20W
RB554 24011101 Chip, 100 ohm, 1/20W
RB555 24011103 Chip, 10k ohm, 1/20W
RB556 24011101 Chip, 100 ohm, 1/20W
RB557 24011103 Chip, 10k ohm, 1/20W
RB558 24011104 Chip, 100k ohm, 1/20W
RB559 24011103 Chip, 10k ohm, 1/20W
RB560 24011103 Chip, 10k ohm, 1/20W
RB561 24011101 Chip, 100 ohm, 1/20W
RB562 24011104 Chip, 100k ohm, 1/20W
RB563 24998101 Chip, 100 ohm, 1/16W
RB564 24998101 Chip, 100 ohm, 1/16W
RB565 24998101 Chip, 100 ohm, 1/16W
RB566 24998101 Chip, 100 ohm, 1/16W
* T461 23236756 Transformer, Flyback,
TFB3092BH
*E031Z 23788622 CRT-D/R Board, PD1153B-1
*E032Z 23788623 CRT-D/G Board, PD1153B-2
*E033Z 23788624 CRT-D/B Board, PD1153B-3
*E034Z 23788625 SVM/R Board, PD1153B-4
*E035Z 23788626 SVM/G Board, PD1153B-5
*E036Z 23788627 SVM/B Board, PD1153B-6
*E041Z 23788825 FRONT-CON Board, PD1154B-1
*E042Z 23788826 FRONT-IN Board, PD1154B-2
*E043Z 23788827 REM Board, PD1154B-3
– 2 –

Location
No. Part No. Description Location No. Part No. Description
–3 –
*E044Z 23788828 FRONT-SEN Board, PD1154B-4
*E045Z 23788823 IR BLASTER Board, PD1289
*U401 23788630 DEFCONVER Board, PD1147B
*U801 23788629 POWER Board, PD1151B
*U901 23788628 SIGNAL Board, PD1146B
* V901R 23071470 OTHER BLOCK, COUPLING R
* V902G 23071471 OTHER BLOCK, COUPLING G
* V903B 23071472 OTHER BLOCK, COUPLING B
W663 23351220 Speaker, TWC 50X50 16-OHM
20W, SPK-1417BM
W664 23351220 Speaker, TWC 50X50 16-OHM
20W, SPK-1417BM
XB501 23153504 Ceramic Resonator, 8.00MH ,
TCR1056BM
* Y101 23565935 Owner’s Manual, English/
French, 57HX83
