FILE NO. 023-2006169GR
SUPPLEMENT
SERVICE MANUAL
Colour Television
62HM85
The above models are classified as either green products (*1) or non-green products. Green product(s) are
indicated by an underlined serial number. This Service Manual describes replacement parts for green
product(s). When repairing any green product(s), use the parts described in this manual and lead-free solde
r
(*2).
For (*1) and (*2), see the next page.
Use this Service Manual in conjunction with the original Service Manual (File No. 020-200506) for 62HM85.
Pubished in Singapore Feb. 2005 Green
© TOSHIBA SINGAPORE PTE LTD

- 2 -
(＊2 ）
LEAD-FREE SOLDER
This product is manufactured using lead-free solder as a part of a movement within the
consumer products industry at large to be environmentally responsible. Lead-free solder
must be used in the servicing and repair of this product.
WARNING
This product is manufactured using lead free solder.
DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT!
The melting temperature of lead-free solder is higher than that of leaded solder by 86°F to
104°F (30°C to 40°C). Use of a soldering iron designed for lead-based solders to repair
product made with lead-free solder may result in damage to the component and or PCB
being soldered. Great care should be made to ensure high-quality soldering when servicing
this product especially when soldering large components, through-hole pins, and on PCBs
as the level of heat required to melt lead-free solder is high.
(＊１）
GREEN PRODUCT PROCUREMENT
The EC is actively promoting the WEEE & RoHS Directives that define standards fo
r
recycling and reuse of Waste Electrical and Electronic Equipment and for the Restriction
of the use of certain Hazardous Substances. From July 1, 2006, the RoHS Directive will
prohibit any marketing of new products containing restricted substances.
Increasing attention is given to issues related to the global environmental. Toshiba
Corporation recognizes environmental protection as a key management tasks, and is doing
its utmost to enhance and improve the quality and scope of its environmental activities. In
line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase
and use products, parts and materials that have low environmental impacts.
Green procurement of parts is not only confined to manufacture. The same green parts
used in manufacture must also be used as replacement parts.

Location
No.
Parts No. Description Location
N
o.
Parts No. Description
CAPACITOR C814 76092553 CAPACITOR, CERAMIC DISC, AC250V B 470PF K
C101 76797339 CAPACITOR, ELECTROLYTIO, 50V 3.3UF M C814 76092565 CAPACITOR, CERAMIC DISC, AC250V B 470PF K
C102 76665221 CAPACITOR, ELECTROLYTIC, 10V 220UF M 3A C816 76092555 CAPACITOR, CERAMIC DISC, AC250V E 1000PF M
C105 76100102 CAPACITOR, CERAMIC CHIP, 50V F 1000PF Z C816 76092567 CAPACITOR, CERAMIC DISC, AC250V E 1000PF M
C106 76669479 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M C8200 76073067 CAPACITOR, ELECTROLYTIC, 35V 47UF M 3A
C107 76666221 CAPACITOR, ELECTROLYTIC, 16V 220UF M C8201 76539334 CAPACITOR, PLASTIC FILM, 50V 0.33UF J
C108 76665221 CAPACITOR, ELECTROLYTIC, 10V 220UF M 3A C8201 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J
C109 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z C8202 76073169 CAPACITOR, ELECTROLYTIC, 25V 470UF M 3A
C110 76794101 CAPACITOR, ELECTROLYTIC, 16V 100UF M C8210 76073172 CAPACITOR, ELECTROLYTIC, 25V 1000UF M 3A
C601 76109122 CAPACITOR, CERAMIC CHIP, 50V B 1200PF K C8211 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J
C602 76109122 CAPACITOR, CERAMIC CHIP, 50V B 1200PF K C8211 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J
C603 76073084 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M C8211 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J
C604 76073084 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M C8212 76214221 CAPACITOR, CERAMIC DISC, 500V B 220PF K
C605 76073086 CAPACITOR, ELECTROLYTIC, 50V 10UF M 3A C8213 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J
C606 76073086 CAPACITOR, ELECTROLYTIC, 50V 10UF M 3A C8213 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J
C607 76073053 CAPACITOR, ELECTROLYTIC, 25V 100UF M 3A C8213 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J
C608 76073086 CAPACITOR, ELECTROLYTIC, 50V 10UF M 3A C8214 76617006 CAPACITOR, ELECTROLYTIC, 25V 820UF M
C612 76073054 CAPACITOR, ELECTROLYTIC, 25V 220UF M 3A C8215 76073138 CAPACITOR, ELECTROLYTIC, 10V 220UF M 3A
C621 76109822 CAPACITOR, CERAMIC CHIP, 50V B 8200PF K C8220 76073068 CAPACITOR, ELECTROLYTIC, 35V 100UF M 3A
C622 76109822 CAPACITOR, CERAMIC CHIP, 50V B 8200PF K C8221 76073169 CAPACITOR, ELECTROLYTIC, 25V 470UF M 3A
C661 76073084 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M C8224 76073087 CAPACITOR, ELECTROLYTIC, 50V 22UF M 3A
C662 76073086 CAPACITOR, ELECTROLYTIC, 50V 10UF M 3A C8225 76073141 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A
C663 76073086 CAPACITOR, ELECTROLYTIC, 50V 10UF M 3A C8240 76073038 CAPACITOR, ELECTROLYTIC, 16V 100UF M 3A
C665 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K C8241 76539334 CAPACITOR, PLASTIC FILM, 50V 0.33UF J
C666 76073084 CAPACITOR, ELECTROLYTIC, 50V 4.7UF M C8241 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J
C667 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M C8242 76073141 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A
C668 76105560 CAPACITOR, CERAMIC CHIP, 50V CH 56PF J C8250 76073141 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A
C669 76105560 CAPACITOR, CERAMIC CHIP, 50V CH 56PF J C8251 76567334 CAPACITOR, PLASTIC FILM, 50V 0.33UF J
C680 76073073 CAPACITOR, ELECTROLYTIC, 35V 2200UF M 3A C8252 76073141 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A
C681 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K C8253 76669339 CAPACITOR, ELECTROLYTIC, 50V 3.3UF M
C682 76073082 CAPACITOR, ELECTROLYTIC, 50V 2.2UF M 3A C840 76679220 CAPACITOR, ELECTROLYTIC, 250V 22UF M 3A
C683 76073053 CAPACITOR, ELECTROLYTIC, 25V 100UF M 3A C841 76073043 CAPACITOR, ELECTROLYTIC, 16V 2200UF M 3A
C684 76795470 CAPACITOR, ELECTROLYTIC, 25V 47UF M C842 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J
C801 76503004 CAPACITOR, PLASTIC FILM, AC275V 0.47UF M C842 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J
C803 76503002 CAPACITOR, PLASTIC FILM, AC275V 0.22UF M C843 76092333 CAPACITOR, CERAMIC DISC, 2KV 100PF K
C805 76092281 CAPACITOR, CERAMIC DISC, AC250V E 4700PF C843 76092469 CAPACITOR, CERAMIC DISC, 2KV B 100PF K
C809 76086067 CAPACITOR, CHEMICON 200V 102M C845 76073082 CAPACITOR, ELECTROLYTIC, 50V 2.2UF M 3A
C810 76086067 CAPACITOR, CHEMICON 200V 102M C848 76073039 CAPACITOR, ELECTROLYTIC, 16V 220UF M 3A
C811 76092557 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M C861 76092479 CAPACITOR, CERAMIC DISC, 2KV B 560PF K
C811 76092569 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M C861 76092342 CAPACITOR, CERAMIC DISC, 2KV R 560PF K
C812 76092557 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M C862 76539224 CAPACITOR, PLASTIC FILM, 50V 0.22UF J
C812 76092569 CAPACITOR, CERAMIC DISC, AC250V E 2200PF M C862 76503045 CAPACITOR, PLASTIC FILM, 63V 0.22UF J
- 3 -
CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 62HM85
Capacitors............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
MF : Oxide Metal Film VR : Variable Resistor FR : Fusible
Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND
"PRODUCT SAFETY NOTICE" ON PAGE 3 OF THE ORIGINAL SERVICE MANUAL (File No. 063-200467)
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical t
o
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade
the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with  mark is no longer available after the end of the production.
• The green parts describes in "G" mark, listed to the left side of the Parts No. item.

Parts No. Description Parts No. Description
C863 76212221 CAPACITOR, CERAMIC DISC, 50V B 220PF K CS10 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C864 76590681 CAPACITOR, PLASTIC FILM, 50V 680PF J CS11 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C864 76591681 CAPACITOR, PLASTIC FILM, 50V 680PF J CS12 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C865 76073063 CAPACITOR, ELECTROLYTIC, 35V 4.7UF M 3A CS13 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C866 76820223 CAPACITOR, PLASTIC FILM, 630V 0.022UF J CS14 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C868 76073068 CAPACITOR, ELECTROLYTIC, 35V 100UF M 3A CS15 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C883 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J CS16 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K
C883 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J CS25 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
C884 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CS26 76794470 CAPACITOR, ELECTROLYTIC, 16V 47UF M
C885 76073191 CAPACITOR, ELECTROLYTIC, 35V 1500UF M 3A CS27 76794220 CAPACITOR, ELECTROLYTIC, 16V 22UF M
C886 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CS28 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M
C887 76676470 CAPACITOR, ELECTROLYTIC, 100V 47UF M CS29 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M
C888 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CS30 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M
C889 76073171 CAPACITOR, ELECTROLYTIC, 25V 820UF M 3A CV01 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C890 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CV02 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8905 76073002 CAPACITOR, ELECTROLYTIC, 6.3V 220UF M 3A CV03 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C891 76073161 CAPACITOR, ELECTROLYTIC, 16V 3900UF M 3A CV04 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
C8911 76539394 CAPACITOR, PLASTIC FILM, 50V 0.39UF J CV05 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8911 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J CV06 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8912 76539394 CAPACITOR, PLASTIC FILM, 50V 0.39UF J CV10 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
C8912 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J CV11 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C892 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CV13 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
C8921 76073141 CAPACITOR, ELECTROLYTIC, 10V 1000UF M 3A CV13 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M
C893 76073173 CAPACITOR, ELECTROLYTIC, 10V 3900UF M 3A CV14 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8930 76073067 CAPACITOR, ELECTROLYTIC, 35V 47UF M 3A CV14 76232103 CAPACITOR, CERAMIC DISC, 50V F 0.01UF Z
C8931 76539334 CAPACITOR, PLASTIC FILM, 50V 0.33UF J CV15 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
C8931 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J CV15 76232103 CAPACITOR, CERAMIC DISC, 50V F 0.01UF Z
C8932 76073152 CAPACITOR, ELECTROLYTIC, 16V 330UF M 3A CV245 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8933 76073069 CAPACITOR, ELECTROLYTIC, 35V 220UF M 3A CV246 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C894 76214331 CAPACITOR, CERAMIC DISC, 500V B 330PF K CV247 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8940 76073067 CAPACITOR, ELECTROLYTIC, 35V 47UF M 3A CV249 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8941 76539334 CAPACITOR, PLASTIC FILM, 50V 0.33UF J CV250 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8941 76503047 CAPACITOR, PLASTIC FILM, 63V 0.33UF J CV251 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8942 76073152 CAPACITOR, ELECTROLYTIC, 16V 330UF M 3A CV253 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C8943 76073069 CAPACITOR, ELECTROLYTIC, 35V 220UF M 3A CV254 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C895 76073075 CAPACITOR, ELECTROLYTIC, 35V 4700UF M 3A CV255 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
C898 76590104 CAPACITOR, CERAMIC DISC, 50V 0.1UF J CV27 76762471 CAPACITOR, ELECTROLYTIC, 10V 470UF M
C898 76503041 CAPACITOR, PLASTIC FILM , 63V 0.1UF J CV29 76763101 CAPACITOR, ELECTROLYTIC, 16V 100UF M
C898 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J CV30 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K
CA81 76109333 CAPACITOR, CERAMIC CHIP, 25V B 0.033UF K CV38 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K
CA82 76109123 CAPACITOR, CERAMIC CHIP, 50V B 0.012UF K CV39 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K
CA83 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K CV47 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
CA84 76109333 CAPACITOR, CERAMIC CHIP, 25V B 0.033UF K CV70 76794101 CAPACITOR, ELECTROLYTIC, 16V 100UF M
CA85 76109273 CAPACITOR, CERAMIC CHIP, 25V B 0.027UF K CV71 76092621 CAPACITOR, CERAMIC CHIP, 10V B 1UF K
CA86 76109123 CAPACITOR, CERAMIC CHIP, 50V B 0.012UF K CV72 76794220 CAPACITOR, ELECTROLYTIC, 16V 22UF M
CA87 76109123 CAPACITOR, CERAMIC CHIP, 50V B 0.012UF K CY101 76092441 CAPACITOR, CERAMIC CHIP, 16V F 1UF Z
CA88 76109333 CAPACITOR, CERAMIC CHIP, 25V B 0.033UF K CY102 76665221 CAPACITOR, ELECTROLYTIC, 10V 220UF M 3A
CA91 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY102 76794101 CAPACITOR, ELECTROLYTIC, 16V 100UF M
CA914 76619040 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M 3A CY103 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
CA915 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY104 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CA916 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY105 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CA92 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY105 76100102 CAPACITOR, CERAMIC CHIP, 50V F 1000PF Z
CA93 76619040 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M 3A CY106 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CA94 76619040 CAPACITOR, ELECTROLYTIC CHIP, 16V 10UF M 3A CY107 76794100 CAPACITOR, ELECTROLYTIC, 16V 10UF M
CA95 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY108 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z
CA96 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY109 76105101 CAPACITOR, CERAMIC CHIP, 50V CH 100PF J
CB01 76794470 CAPACITOR, ELECTROLYTIC, 16V 47UF M CY111 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CB81 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY112 76105181 CAPACITOR, CERAMIC CHIP, 50V CH 180PF J
CB82 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY113 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CB83 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY114 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CB99 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K CY115 76105390 CAPACITOR, CERAMIC CHIP, 50V CH 39PF J
CS01 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY116 76105470 CAPACITOR, CERAMIC CHIP, 50V CH 47PF J
CS02 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY117 76105180 CAPACITOR, CERAMIC CHIP, 50V CH 18PF J
CS03 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY160 76815393 CAPACITOR, CERAMIC CHIP, 50V B 0.039UF K
CS04 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY501 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CS05 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY502 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K
CS06 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY504 76109222 CAPACITOR, CERAMIC CHIP, 50V B 2200PF K
CS07 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY505 76105120 CAPACITOR, CERAMIC CHIP, 50V CH 12PF J
CS08 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY506 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K
CS09 76092795 CAPACITOR, CERAMIC CHIP, 6.3V B 2.2UF K CY508 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K
- 4 -
Location
No.
Location
N
o.

Parts No. Description Parts No. Description
CY512 76092463 CAPACITOR, CERAMIC CHIP, 16V B 0.22UF K R662 76011333 RESISTOR, CHIP, 1/20W 33K OHM J
CY513 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R663 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J
CY514 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R665 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
CY515 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R666 76011473 RESISTOR, CHIP, 1/20W 47K OHM J
CY516 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K R667 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
CY517 76092731 CAPACITOR, CERAMIC CHIP, 16V B 1UF K R668 76011473 RESISTOR, CHIP, 1/20W 47K OHM J
CY524 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R671 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
CY525 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R672 76011333 RESISTOR, CHIP, 1/20W 33K OHM J
CY526 76092730 CAPACITOR, CERAMIC CHIP, 16V B 0.1UF K R673 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J
CY538 76761102 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M R674 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J
CY539 76794471 CAPACITOR, ELECTROLYTIC, 16V 470UF M R676 76011104 RESISTOR, CHIP, 1/20W 100K OHM J
CY540 76794471 CAPACITOR, ELECTROLYTIC, 16V 470UF M R677 76011104 RESISTOR, CHIP, 1/20W 100K OHM J
CY541 76761102 CAPACITOR, ELECTROLYTIC, 6.3V 1000UF M R681 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J
CY582 76105101 CAPACITOR, CERAMIC CHIP, 50V CH 100PF J R682 76011473 RESISTOR, CHIP, 1/20W 47K OHM J
R683 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
RESISTOR R684 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
G101 76011151 RESISTOR, CHIP, 1/20W 150 OHM J R687 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
G102 76011151 RESISTOR, CHIP, 1/20W 150 OHM J R688 76011224 RESISTOR, CHIP, 1/20W 220K OHM J
GA89 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R693 76000445 RESISTOR, CHIP JUMPER, 1608TYPE
GA90 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R697 76553561 RESISTOR, OXIDE METAL FILM, 1W 560 OHM J
GJ105 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R698 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
GR103 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R699 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
JR003 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R810 76568479 RESISTOR, CERAMIC COVERED, 7W 4.7 OHM J
JR004 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R811 76120001 RESISTOR, CEMENT RES 141C 2.1W 1R8 K
JR005 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R811 76007061 RESISTOR, CERAMIC COVERED, 2W 1.8 OHM K
JR006 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8200 76367390 RESISTOR, CARBON FILM, 1/6W 390 OHM G
JR007 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8210 76000147 RESISTOR, METAL FILM, 1/4W 470 OHM F
JR008 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8211 76000219 RESISTOR, METAL FILM, 1/4W 10 OHM F
JR009 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8220 76367390 RESISTOR, CARBON FILM, 1/6W 390 OHM G
JR010 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8240 76000635 RESISTOR, METAL FILM, 1/4W 12K OHM F
JR011 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8241 76000529 RESIST0R, METAL FILM, 1/4W 6.8K OHM F
JR012 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8242 76367471 RESISTOR, CARBON FILM, 1/6W 470 OHM G
JR013 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8250 76000145 RESISTOR, METAL FILM, 1/4W 330 OHM F
JR014 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8251 76000145 RESISTOR, METAL FILM, 1/4W 330 OHM F
JR015 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R8252 76367392 RESISTOR, CARBON FILM, 1/6W 3.9K OHM G
JR016 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R840 76552562 RESISTOR, OXIDE METAL FILM, 1/2W 5.6K OHM J
JR017 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R841 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J
JR018 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R842 76376563 RESISTOR, CARB0N FILM, 1/2W 56K OHM J
JR019 76000445 RESISTOR, CHIP JUMPER, 1608TYPE R843 76376563 RESISTOR, CARB0N FILM, 1/2W 56K OHM J
R010 76011102 RESISTOR, CHIP, 1/20W 1K OHM J R844 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J
R150 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J R845 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J
R151 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J R846 76366471 RESISTOR, CARBON FILM, 1/6W 470 OHM J
R152 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R847 76366473 RESISTOR, CARBON FILM, 1/6W 47K OHM J
R173 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R848 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J
R174 76011273 RESISTOR, CHIP, 1/20W 27K OHM J R849 76552470 RESISTOR, OXIDE METAL FILM, 1/2W 47 OHM J
R264 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R850 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J
R265 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R860 76382101 RESISTOR, OXIDE METAL FILM, 1W 100 OHM J
R266 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R861 76383333 RESISTOR, OXIDE METAL FILM, 2W 33K OHM J
R286 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R862 76019463 RESISTOR, METAL PLATE, 2W 0.22 OHM J
R287 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R863 76019461 RESISTOR, METAL PLATE, 2W 0.15 OHM J
R288 76011750 RESISTOR, CHIP, 1/20W 75 OHM J R864 76321828 RESISTOR, METAL FILM, 1/2W 0.82 OHM J
R347 76011101 RESISTOR, CHIP, 1/20W 100 OHM J R865 76381221 RESISTOR, OXIDE METAL FILM, 1/2W 220 OHM J
R348 76011101 RESISTOR, CHIP, 1/20W 100 OHM J R866 76366681 RESISTOR, CARBON FILM, 1/6W 680 OHM J
R601 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J R867 76366152 RESISTOR, CARBON FILM, 1/6W 1.5K OHM J
R602 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J R868 76555473 RESISTOR, OXIDE METAL FILM, 3W 47K OHM J
R603 76011122 RESISTOR, CHIP, 1/20W 1.2K OHM J R869 76366152 RESISTOR, CARBON FILM, 1/6W 1.5K OHM J
R604 76011122 RESISTOR, CHIP, 1/20W 1.2K OHM J R870 76366154 RESISTOR, CARBON FILM, 1/6W 150K OHM J
R609 76011563 RESISTOR, CHIP, 1/20W 56K OHM J R881 76366222 RESISTOR, CARBON FILM, 1/6W 2.2K OHM J
R610 76011223 RESISTOR, CHIP, 1/20W 22K OHM J R882 76366471 RESISTOR, CARBON FILM, 1/6W 470 OHM J
R611 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R885 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J
R612 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J R886 76000525 RESISTOR, METAL FILM, 1/4W 4.7K OHM F
R613 76011223 RESISTOR, CHIP, 1/20W 22K OHM J R887 76367683 RESISTOR, CARBON FILM, 1/6W 68K OHM G
R614 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R888 76000525 RESISTOR, METAL FILM, 1/4W 4.7K OHM F
R615 76011104 RESISTOR, CHIP, 1/20W 100K OHM J R889 76383222 RESISTOR, OXIDE METAL FILM, 2W 2.2K OHM J
R616 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J R8902 76366333 RESISTOR, CARBON FILM, 1/6W 33K OHM J
R621 76011391 RESISTOR, CHIP, 1/20W 390 OHM J R8903 76366333 RESISTOR, CARBON FILM, 1/6W 33K OHM J
R622 76011391 RESISTOR, CHIP, 1/20W 390 OHM J R8904 76366472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM J
R626 76011223 RESISTOR, CHIP, 1/20W 22K OHM J R8905 76366681 RESISTOR, CARBON FILM, 1/6W 680 OHM J
R627 76011223 RESISTOR, CHIP, 1/20W 22K OHM J R8908 76366104 RESISTOR, CARBON FILM, 1/6W 100K OHM J
R661 76011102 RESISTOR, CHIP, 1/20W 1K OHM J R891 76555331 RESISTOR, OXIDE METAL FILM, 3W 330 OHM J
- 5 -
Location
No.
Location
No.

Parts No. Description Parts No. Description
R8910 76366472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM J RS09 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8911 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J RS10 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8912 76366223 RESISTOR, CARBON FILM, 1/6W 22K OHM J RS11 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8913 76366334 RESISTOR, CARBON FILM, 1/6W 330K OHM J RS12 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8914 76366223 RESISTOR, CARBON FILM, 1/6W 22K OHM J RS13 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8915 76366102 RESISTOR, CARBON FILM, 1/6W 1K OHM J RS14 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R892 76555331 RESISTOR, OXIDE METAL FILM, 3W 330 OHM J RS15 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8922 76366122 RESISTOR, CARBON FILM, 1/6W 1.2K OHM J RS16 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
R8931 76367123 RESISTOR, CARBON FILM, 1/6W 12K OHM G RS21 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8932 76367182 RESISTOR, CARBON FILM, 1/6W 1.8K OHM G RS22 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8934 76367472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM G RS23 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8941 76367123 RESISTOR, CARBON FILM, 1/6W 12K OHM G RS24 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8942 76367182 RESISTOR, CARBON FILM, 1/6W 1.8K OHM G RS27 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8944 76367472 RESISTOR, CARBON FILM, 1/6W 4.7K OHM G RS28 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
R8950 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J RS29 76011682 RESISTOR, CHIP, 1/20W 6.8K OHM J
R8951 76366103 RESISTOR, CARBON FILM, 1/6W 10K OHM J RS30 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J
R899 76005014 RESISTOR, METAL FILM, 1W 8.2M OHM J RS31 76011100 RESISTOR, CHIP, 1/20W 10 OHM J
R899 76005015 RESISTOR, METAL GLAZE, 1W 8.2M OHM J RS32 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J
RA44 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS33 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J
RA48 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS34 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J
RA51 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS35 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA53 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS36 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA55 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS37 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
RA57 76011105 RESISTOR, CHIP, 1/20W 1M OHM J RS38 76011223 RESISTOR, CHIP, 1/20W 22K OHM J
RA61 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV001 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA62 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV002 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA63 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV003 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA64 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV004 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA65 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV005 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA66 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV006 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA67 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV007 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RA68 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV008 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA71 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J RV009 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA72 76011153 RESISTOR, CHIP, 1/2OW 15K OHM J RV01 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA73 76011273 RESISTOR, CHIP, 1/20W 27K OHM J RV03 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA75 76011822 RESISTOR, CHIP, 1/20W 8.2K OHM J RV06 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA76 76011153 RESISTOR, CHIP, 1/2OW 15K OHM J RV07 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
RA77 76011114 RESISTOR, CHIP, 1/20W 110K OHM J RV08 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA81 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV09 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA82 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV10 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA83 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV11 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA84 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV12 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA85 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV14 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
RA86 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV147 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA87 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV148 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA88 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RV15 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA91 76011623 RESISTOR, CHIP, 1/20W 62K OHM J RV17 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA94 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RV19 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RA95 76011623 RESISTOR, CHIP, 1/20W 62K OHM J RV20 76366750 RESISTOR, CARBON FILM, 1/6W 75 OHM J
RA98 76000445 RESISTOR, CHIP JUMPER, 1608TYPE RV21 76366750 RESISTOR, CARBON FILM, 1/6W 75 OHM J
RB15 76366471 RESISTOR, CARBON FILM, 1/6W 470 OHM J RV21 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J
RB19 76366470 RESISTOR, CARBON FILM, 1/6W 47 OHM J RV22 76366750 RESISTOR, CARBON FILM, 1/6W 75 OHM J
RB81 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J RV22 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RB82 76011471 RESISTOR, CHIP, 1/20W 470 OHM J RV23 76366101 RESISTOR, CARBON FILM, 1/6W 100 OHM J
RB83 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RV23 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J
RB84 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RV24 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J
RB87 76011394 RESISTOR, CHIP, 1/20W 390K OHM J RV32 76011104 RESISTOR, CHIP, 1/20W 100K OHM J
RB88 76011394 RESISTOR, CHIP, 1/20W 390K OHM J RV323 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RB89 76011103 RESISTOR, CHIP, 1/20W 10K OHM J RV324 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RB90 76011302 RESISTOR, CHIP, 1/20W 3K OHM J RV325 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RB92 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RV33 76011104 RESISTOR, CHIP, 1/20W 100K OHM J
RB93 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RV330 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RS01 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV331 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RS02 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV332 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RS03 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RV333 76011181 RESISTOR, CHIP, 1/20W 180 OHM J
RS04 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RV334 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
RS05 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV335 76011123 RESISTOR, CHIP, 1/20W 12K OHM J
RS06 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV34 76011104 RESISTOR, CHIP, 1/20W 100K OHM J
RS07 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV346 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RS08 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RV35 76011750 RESISTOR, CHIP, 1/20W 75 OHM J
- 6 -
Location
No.
Location
No.

Parts No. Description Parts No. Description
RV36 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RY583 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RV37 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY584 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RV38 76011562 RESISTOR, CHIP, 1/20W 5.6K OHM J RY585 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
RV40 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RY586 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RV41 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RY587 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RV42 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RY588 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RV43 76011750 RESISTOR, CHIP, 1/20W 75 OHM J RY589 76000445 RESISTOR, CHIP JUMPER, 1608TYPE
RV61 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY590 76011103 RESISTOR, CHIP, 1/20W 10K OHM J
RV85 76366471 RESISTOR, CARBON FILM, 1/6W 470 OHM J RY591 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RV86 76366471 RESISTOR, CARBON FILM, 1/6W 470 OHM J RY592 76011101 RESISTOR, CHIP, 1/20W 100 OHM J
RV89 76011680 RESISTOR, CHIP, 1/20W 68 OHM J RY593 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RY101 76011101 RESISTOR, CHIP, 1/20W 100 OHM J RY594 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RY102 76011221 RESISTOR, CHIP, 1/20W 220 OHM J RY595 76011330 RESISTOR, CHIP, 1/20W 33 OHM J
RY103 76011102 RESISTOR, CHIP, 1/20W 1K OHM J RY596 76000445 RESISTOR, CHIP JUMPER, 1608TYPE
RY104 76011102 RESISTOR, CHIP, 1/20W 1K OHM J
RY105 76011821 RESISTOR, CHIP, 1/20W 820 OHM J COILS & TRANSFORMERS
RY106 76000445 RESISTOR, CHIP JUMPER, 1608TYPE LV13 23246662 COIL, CHIP, TRF4100CN
RY107 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J LY012 23246662 COIL, CHIP, TRF4100CN
RY109 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J LY501 23246662 COIL, CHIP, TRF4100CN
RY110 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J LY503 23246662 COIL, CHIP, TRF4100CN
RY160 76011471 RESISTOR, CHIP, 1/20W 470 OHM J LY104 23246653 COIL, CHIP, TRF4150CG
RY161 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LY105 23246655 COIL, CHIP, TRF4270CG
RY501 76011303 RESISTOR, CHIP, 1/20W 30K OHM J LY100 23246656 COIL, CHIP, TRF4330CG
RY502 76011103 RESISTOR, CHIP, 1/20W 10K OHM J LY101 23248398 COIL, CHOKE, TLN3278D
RY504 76011103 RESISTOR, CHIP, 1/20W 10K OHM J L888 23248424 COIL, CHOKE, TLN3462AF
RY505 76011123 RESISTOR, CHIP, 1/20W 12K OHM J L888 23248446 COIL, CHOKE, TLN3462AH
RY507 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L8213 23248417 COIL, CHOKE, TLN3481AH
RY508 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L893 23248417 COIL, CHOKE, TLN3481AH
RY509 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J L890 23248432 COIL, CHOKE, TLN3499AH
RY510 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J L891 23248432 COIL, CHOKE, TLN3499AH
RY511 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L892 23248432 COIL, CHOKE, TLN3499AH
RY512 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L8930 23248432 COIL, CHOKE, TLN3499AH
RY513 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J L8931 23248432 COIL, CHOKE, TLN3499AH
RY516 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J L8940 23248432 COIL, CHOKE, TLN3499AH
RY517 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J L8941 23248432 COIL, CHOKE, TLN3499AH
RY518 76011472 RESISTOR, CHIP, 1/20W 4.7K OHM J L895 23248432 COIL, CHOKE, TLN3499AH
RY519 76000445 RESISTOR, CHIP JUMPER, 1608TYPE L8211 23248457 COIL, CHOKE, TLN3540AF
RY520 76011101 RESISTOR, CHIP, 1/20W 100 OHM J L8211 23248456 COIL, CHOKE, TLN3540AH
RY521 76011101 RESISTOR, CHIP, 1/20W 100 OHM J T802 23211836 COIL, LINE FILTER, TRF3197AH
RY523 76011102 RESISTOR, CHIP, 1/20W 1K OHM J T802 23211800 COIL, LINE FILTER, TRF3197AQ
RY524 76011102 RESISTOR, CHIP, 1/20W 1K OHM J T801 23211824 COIL, LINE FILTER, TRF3239AF
RY525 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J T801 23211827 COIL, LINE FILTER, TRF3239AH
RY526 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J LY102 23221144 COIL, PEAKING, TRF4229AJ
RY527 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J LY103 23221144 COIL, PEAKING, TRF4229AJ
RY528 76011222 RESISTOR, CHIP, 1/20W 2.2K OHM J L8210 23289981 COIL, PEAKING, TRF4330AZ
RY529 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L840 23289981 COIL, PEAKING, TRF4330AZ
RY530 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L896 23289981 COIL, PEAKING, TRF4330AZ
RY531 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L103 23289026 COIL, PEAKING, TRF4470AT
RY532 76011101 RESISTOR, CHIP, 1/20W 100 OHM J LV20 23221156 COIL, PEAKING, TRF4560AJ
RY533 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L101 23289027 COIL, PEAKING, TRF4680AT
RY534 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L841 23103304 FERRITE CHOKE, TEM2011AA
RY535 76011330 RESISTOR, CHIP, 1/20W 33 OHM J L861 23103304 FERRITE CHOKE, TEM2011AA
RY536 76011330 RESISTOR, CHIP, 1/20W 33 OHM J L881 23103304 FERRITE CHOKE, TEM2011AA
RY541 76011392 RESISTOR, CHIP, 1/20W 3.9K OHM J L882 23103304 FERRITE CHOKE, TEM2011AA
RY542 76011392 RESISTOR, CHIP, 1/20W 3.9K OHM J L883 23103304 FERRITE CHOKE, TEM2011AA
RY543 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J L884 23103304 FERRITE CHOKE, TEM2011AA
RY545 76011101 RESISTOR, CHIP, 1/20W 100 OHM J L885 23103304 FERRITE CHOKE, TEM2011AA
RY548 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L886 23103304 FERRITE CHOKE, TEM2011AA
RY550 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J L841 23103302 FERRITE CHOKE, TEM2011AH
RY551 76011182 RESISTOR, CHIP, 1/20W 1.8K OHM J L861 23103302 FERRITE CHOKE, TEM2011AH
RY552 76011152 RESISTOR, CHIP, 1/20W 1.5K OHM J L881 23103302 FERRITE CHOKE, TEM2011AH
RY560 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J L882 23103302 FERRITE CHOKE, TEM2011AH
RY561 76011471 RESISTOR, CHIP, 1/20W 470 OHM J L883 23103302 FERRITE CHOKE, TEM2011AH
RY573 76011102 RESISTOR, CHIP, 1/20W 1K OHM J L884 23103302 FERRITE CHOKE, TEM2011AH
RY575 76011103 RESISTOR, CHIP, 1/20W 10K OHM J L885 23103302 FERRITE CHOKE, TEM2011AH
RY576 76011123 RESISTOR, CHIP, 1/20W 12K OHM J L886 23103302 FERRITE CHOKE, TEM2011AH
RY578 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J M811A 23103778 FERRITE CORE, TFE1008
RY579 76011102 RESISTOR, CHIP, 1/20W 1K OHM J M811D 23103778 FERRITE CORE, TFE1008
RY580 76011101 RESISTOR, CHIP, 1/20W 100 OHM J M905A 23103778 FERRITE CORE, TFE1008
RY582 76011332 RESISTOR, CHIP, 1/20W 3.3K OHM J MV60A 23103778 FERRITE CORE, TFE1008
- 7 -
Location
No.
Location
No.

Parts No. Description Parts No. Description
M802A 23103839 FERRITE CORE, TFE1012 D887 23357911 DIODE, FMB-26L
M811E 23103840 FERRITE CORE, TFE1013 D883 23357702 DIODE, FML-G12S
MB91A 23103840 FERRITE CORE, TFE1013 D888 23362113 DIODE, FML-G22S
MV01A 23103840 FERRITE CORE, TFE1013 D886 23357408 DIODE, FMX-12S(023-108)
P800A 23103840 FERRITE CORE, TFE1013 D843 23357366 DIODE, FR105-B5
ZB22B 23103840 FERRITE CORE, TFE1013 D864 23357366 DIODE, FR105-B5
L862 23103307 FERRITR CHOKE, TEM2014AA D884 23357366 DIODE, FR105-B5
SR82 23146587 RELAY, DC12V 0.53W, G5PA-1-M D601 23362140 DIODE, KDS160-RTK
SR82 23146584 RELAY, DC12V, TV5, DG-3 D602 23362140 DIODE, KDS160-RTK
SR81 23146588 RELAY, DLS5D1-O(M) 0.15W D603 23362140 DIODE, KDS160-RTK
T840 23217790 TRANSFORMER, CONVERTER TPW3425BH D604 23362140 DIODE, KDS160-RTK
T840 23217704 TRANSFORMER, CONVERTER, TPW3425AH D605 23362140 DIODE, KDS160-RTK
T862 23217682 TRANSFORMER, CONVERTER, TPW3553AS D606 23362140 DIODE, KDS160-RTK
LY101 23103827 INDUCTOR, BEAD, TEM2120M D607 23362140 DIODE, KDS160-RTK
LY102 23103827 INDUCTOR, BEAD, TEM2120M D608 23362140 DIODE, KDS160-RTK
LY103 23103230 INDUCTOR, BEAD, TEM2134AD D609 23362140 DIODE, KDS160-RTK
LY112 23103230 INDUCTOR, BEAD, TEM2134AD D611 23362140 DIODE, KDS160-RTK
JR001 23103239 INDUCTOR, BEAD, TEM2143AD D612 23362140 DIODE, KDS160-RTK
JR002 23103239 INDUCTOR, BEAD, TEM2143AD D613 23362140 DIODE, KDS160-RTK
D614 23362140 DIODE, KDS160-RTK
SEMICONDUCTORS D615 23362140 DIODE, KDS160-RTK
D850 23357622 DI0DE, ZENER, RD11ESA B3 D616 23362140 DIODE, KDS160-RTK
D8200 23357922 DIODE, 1SS120-7-E D617 23362140 DIODE, KDS160-RTK
D845 23357922 DIODE, 1SS120-7-E DB03 23358615 DIODE, LED INFRARED, SIR-56SB3F
D848 23357922 DIODE, 1SS120-7-E DB81 23358584 DIODE, LED, SML-811UTT86
D849 23357922 DIODE, 1SS120-7-E D840 23362046 DIODE, LN1WBA60 4101
D863 23357922 DIODE, 1SS120-7-E D801 23357407 DIODE, LN6SB60-F05
D865 23357922 DIODE, 1SS120-7-E D801 23357707 DIODE, RBV606, LF-A
D8902 23357922 DIODE, 1SS120-7-E D8210 23357519 DIODE, RK44,
D8903 23357922 DIODE, 1SS120-7-E D885 23357860 DIODE, RL2Z
D8914 23357922 DIODE, 1SS120-7-E D866 23357709 DIODE, RU1P
D8915 23357922 DIODE, 1SS120-7-E D846 23362005 DIODE, ZENER, HZS3.0N B2-E
D8930 23357922 DIODE, 1SS120-7-E D847 23362005 DIODE, ZENER, HZS3.0N B2-E
D8931 23357922 DIODE, 1SS120-7-E DV07 23357751 DIODE, ZENER, MA8068-M
D8940 23357922 DIODE, 1SS120-7-E DV14 23357751 DIODE, ZENER, MA8068-M
D8941 23357922 DIODE, 1SS120-7-E D628 23357772 DIODE, ZENER, MA8120-H
D8200 23357697 DIODE, 1SS133 D628 23357770 DIODE, ZENER, MA8120-L
D845 23357697 DIODE, 1SS133 D628 23357771 DIODE, ZENER, MA8120-M
D848 23357697 DIODE, 1SS133 D850 23357863 DIODE, ZENER, MTZJ11C
D849 23357697 DIODE, 1SS133 D867 23357900 DIODE, ZENER, MTZJ33B
D863 23357697 DIODE, 1SS133 D842 23357830 DIODE, ZENER, MTZJ4.7A
D865 23357697 DIODE, 1SS133 D8211 23357831 DIODE, ZENER, MTZJ4.7B
D8902 23357697 DIODE, 1SS133 D8922 23357836 DIODE, ZENER, MTZJ5.6A
D8903 23357697 DIODE, 1SS133 D861 23357837 DIODE, ZENER, MTZJ5.6B
D8914 23357697 DIODE, 1SS133 D841 23357838 DIODE, ZENER, MTZJ5.6C
D8915 23357697 DIODE, 1SS133 D844 23357838 DIODE, ZENER, MTZJ5.6C
D8930 23357697 DIODE, 1SS133 D8904 23357838 DIODE, ZENER, MTZJ5.6C
D8931 23357697 DIODE, 1SS133 D8905 23357838 DIODE, ZENER, MTZJ5.6C
D8940 23357697 DIODE, 1SS133 D8911 23357838 DIODE, ZENER, MTZJ5.6C
D8941 23357697 DIODE, 1SS133 D8912 23357838 DIODE, ZENER, MTZJ5.6C
D601 23357703 DIODE, 1SS355 D8913 23357838 DIODE, ZENER, MTZJ5.6C
D602 23357703 DIODE, 1SS355 D8950 23357838 DIODE, ZENER, MTZJ5.6C
D603 23357703 DIODE, 1SS355 D8951 23357838 DIODE, ZENER, MTZJ5.6C
D604 23357703 DIODE, 1SS355 D894 23357841 DIODE, ZENER, MTZJ6.8A
D605 23357703 DIODE, 1SS355 D895 23357841 DIODE, ZENER, MTZJ6.8A
D606 23357703 DIODE, 1SS355 D896 23357841 DIODE, ZENER, MTZJ6.8A
D607 23357703 DIODE, 1SS355 D897 23357841 DIODE, ZENER, MTZJ6.8A
D608 23357703 DIODE, 1SS355 D898 23357841 DIODE, ZENER, MTZJ6.8A
D609 23357703 DIODE, 1SS355 D846 23357684 DIODE, ZENER, RD3.0ESA B2
D611 23357703 DIODE, 1SS355 D847 23357684 DIODE, ZENER, RD3.0ESA B2
D612 23357703 DIODE, 1SS355 D867 23357659 DIODE, ZENER, RD33ESA B2
D613 23357703 DIODE, 1SS355 D842 23357645 DIODE, ZENER, RD4.7ESA B1
D614 23357703 DIODE, 1SS355 D8211 23357644 DIODE, ZENER, RD4.7ESA B2
D615 23357703 DIODE, 1SS355 D8922 23357639 DIODE, ZENER, RD5.6ESA B1
D616 23357703 DIODE, 1SS355 D861 23357638 DIODE, ZENER, RD5.6ESA B2
D617 23357703 DIODE, 1SS355 D841 23357637 DIODE, ZENER, RD5.6ESA B3
D801 23357712 DIODE, D5SB60, 4009 F05 D844 23357637 DIODE, ZENER, RD5.6ESA B3
D843 23357513 DIODE, EU2A D8904 23357637 DIODE, ZENER, RD5.6ESA B3
D864 23357513 DIODE, EU2A D8905 23357637 DIODE, ZENER, RD5.6ESA B3
D884 23357513 DIODE, EU2A D8911 23357637 DIODE, ZENER, RD5.6ESA B3
- 8 -
Location
No.
Location
No.

Parts No. Description Parts No. Description
D8912 23357637 DIODE, ZENER, RD5.6ESA B3 QY512 23205276 TRANSISTOR, 2SA1586Y(TE85L,F)
D8913 23357637 DIODE, ZENER, RD5.6ESA B3 QY513 23205276 TRANSISTOR, 2SA1586Y(TE85L,F)
D8950 23357637 DIODE, ZENER, RD5.6ESA B3 QY514 23205276 TRANSISTOR, 2SA1586Y(TE85L,F)
D8951 23357637 DIODE, ZENER, RD5.6ESA B3 QY515 23205276 TRANSISTOR, 2SA1586Y(TE85L,F)
D894 23357636 DIODE, ZENER, RD6.8ESA B1 QY516 23205276 TRANSISTOR, 2SA1586Y(TE85L,F)
D895 23357636 DIODE, ZENER, RD6.8ESA B1 Q845 23205313 TRANSISTOR, 2SC1815-Y(F)
D896 23357636 DIODE, ZENER, RD6.8ESA B1 Q846 23205313 TRANSISTOR, 2SC1815-Y(F)
D897 23357636 DIODE, ZENER, RD6.8ESA B1 Q847 23205313 TRANSISTOR, 2SC1815-Y(F)
D898 23357636 DIODE, ZENER, RD6.8ESA B1 Q8901 23205313 TRANSISTOR, 2SC1815-Y(F)
DA91 23357406 DIODE, ZENER, UDZS5.6B Q8902 23205313 TRANSISTOR, 2SC1815-Y(F)
DA92 23357406 DIODE, ZENER, UDZS5.6B Q8911 23205313 TRANSISTOR, 2SC1815-Y(F)
Q8240 23085821 IC, ADJ REG. VO=1.5V-16.0V BA7810T-V5 Q8912 23205313 TRANSISTOR, 2SC1815-Y(F)
Q601 23009603 IC, AN7580 QB81 23205446 TRANSISTOR, 2SC2412K, Q T146
Q8930 23009998 IC, BA00JC5WT-V5 QB84 23205446 TRANSISTOR, 2SC2412K, Q T146
Q8940 23009998 IC, BA00JC5WT-V5 Q661 23205302 TRANSISTOR, 2SC3326-B(F)
QB83 23085867 IC, BA10393F-E2 Q662 23205302 TRANSISTOR, 2SC3326-B(F)
Q840 23085559 IC, MIP280 Q681 23205302 TRANSISTOR, 2SC3326-B(F)
QV01 23009940 IC, MM1630AQ Q682 23205302 TRANSISTOR, 2SC3326-B(F)
QS01 23009916 IC, MM1631AJBE QS06 23205302 TRANSISTOR, 2SC3326-B(F)
Q881 23085389 IC, NJM431L QS07 23205302 TRANSISTOR, 2SC3326-B(F)
Q663 23085575 IC, OP AMP, BA4558 Q152 23205506 TRANSISTOR, 2SC4081 Q
Q8950 23085499 IC, OP AMP, TA75358CP, Q172 23205506 TRANSISTOR, 2SC4081 Q
Q8950 23085503 IC, OPE AMP, TA75358P Q613 23205506 TRANSISTOR, 2SC4081 Q
Q8950 23085869 IC, OPE AMP, TA75358PG(5) QY160 23205506 TRANSISTOR, 2SC4081 Q
Q841 23085585 IC, PHOTO COUPLER, ON3171-R QS02 23205506 TRANSISTOR, 2SC4081 Q
Q842 23085585 IC, PHOTO COUPLER, ON3171-R QS03 23205506 TRANSISTOR, 2SC4081 Q
Q862 23085585 IC, PHOTO COUPLER, ON3171-R QS04 23205506 TRANSISTOR, 2SC4081 Q
Q841 23085431 IC, PHOTO COUPLER, PS2581L1(D) QV004 23205506 TRANSISTOR, 2SC4081 Q
Q842 23085431 IC, PHOTO COUPLER, PS2581L1(D) QV005 23205506 TRANSISTOR, 2SC4081 Q
Q862 23085431 IC, PHOTO COUPLER, PS2581L1(D) QV006 23205506 TRANSISTOR, 2SC4081 Q
Q841 23000823 IC, PHOTO COUPLER, TLP421F(GR) QV007 23205506 TRANSISTOR, 2SC4081 Q
Q842 23000823 IC, PHOTO COUPLER, TLP421F(GR) QV008 23205506 TRANSISTOR, 2SC4081 Q
Q862 23000823 IC, PHOTO COUPLER, TLP421F(GR) QY101 23205506 TRANSISTOR, 2SC4081 Q
Q841 23085542 IC, PHOTO COUPLER, TLP621(GRL-LF2,F) QY102 23205506 TRANSISTOR, 2SC4081 Q
Q842 23085542 IC, PHOTO COUPLER, TLP621(GRL-LF2,F) QY506 23205506 TRANSISTOR, 2SC4081 Q
Q862 23085542 IC, PHOTO COUPLER, TLP621(GRL-LF2,F) QY507 23205506 TRANSISTOR, 2SC4081 Q
Q8250 23085377 IC, PQ5EV3J0000H QY508 23205506 TRANSISTOR, 2SC4081 Q
Q8251 23085600 IC, PST9129 QY509 23205506 TRANSISTOR, 2SC4081 Q
QA91 23085674 IC, QT240-ISS-G-CA QY518 23205506 TRANSISTOR, 2SC4081 Q
QA92 23085674 IC, QT240-ISS-G-CA QY522 23205506 TRANSISTOR, 2SC4081 Q
QA94 23085067 IC, R1121N331B-TR-FA Q152 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QA93 23085731 IC, R1121N421B-TR-FA Q172 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q8220 23135077 IC, SI-3090CA Q613 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q8200 23085050 IC, SI-3120J(LF1101) QY160 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q8210 23085397 IC, SI-8033SS QS02 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q801 23135069 IC, STRF6268S QS03 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY501 23009929 IC, TA1383FG(DRY,EL) QS04 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q881 23085587 IC, TA76431S QV004 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY100 23085570 IC, TC90A45F QV005 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q881 23085508 IC, UPC1093J QV006 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q8904 23205309 TRANSISTOR, 2SA1015-Y(F) QV007 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q151 23205507 TRANSISTOR, 2SA1576A Q QV008 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
Q612 23205507 TRANSISTOR, 2SA1576A Q QY101 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QV91 23205507 TRANSISTOR, 2SA1576A Q QY506 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY103 23205507 TRANSISTOR, 2SA1576A Q QY507 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY503 23205507 TRANSISTOR, 2SA1576A Q QY508 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY504 23205507 TRANSISTOR, 2SA1576A Q QY509 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY511 23205507 TRANSISTOR, 2SA1576A Q QY518 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY512 23205507 TRANSISTOR, 2SA1576A Q QY522 23205277 TRANSISTOR, 2SC4116-Y(TE85L,F)
QY513 23205507 TRANSISTOR, 2SA1576A Q QV009 23205305 TRANSISTOR, 2SC4667-O(F)
QY514 23205507 TRANSISTOR, 2SA1576A Q QY502 23205305 TRANSISTOR, 2SC4667-O(F)
QY515 23205507 TRANSISTOR, 2SA1576A Q Q664 23205428 TRANSISTOR, KRA104S/P
QY516 23205507 TRANSISTOR, 2SA1576A Q QS05 23205428 TRANSISTOR, KRA104S/P
Q151 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q614 23205426 TRANSISTOR, KRC106S/P
Q612 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q8904 23205497 TRANSISTOR, KTA1266 Y/P
QV91 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q151 23205346 TRANSISTOR, KTA2014Y/P
QY103 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q612 23205346 TRANSISTOR, KTA2014Y/P
QY503 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q661 23205424 TRANSISTOR, KTC2875B/P
QY504 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q662 23205424 TRANSISTOR, KTC2875B/P
QY511 23205276 TRANSISTOR, 2SA1586Y(TE85L,F) Q681 23205424 TRANSISTOR, KTC2875B/P
- 9 -
Location
No.
Location
N
o.

Parts No. Description Parts No. Description
Q682 23205424 TRANSISTOR, KTC2875B/P PX19 23713110 CONNECTOR, FE-ST-VK-N 17P JST FE-ST-VK-N 17PR
QS06 23205424 TRANSISTOR, KTC2875B/P H003A 23747055 NUT, F-CONNECTOR 2H BS
QS07 23205424 TRANSISTOR, KTC2875B/P
Q845 23205499 TRANSISTOR, KTC3198 Y/P
T
UNER
Q846 23205499 TRANSISTOR, KTC3198 Y/P HY01 23321480 TUNER, TIF US IIC PH 181CH 5V ENG36A18GF
Q847 23205499 TRANSISTOR, KTC3198 Y/P H001 23321482 TUNER, US181CH IIC PH 5V PANA ELA52LX5
Q8901 23205499 TRANSISTOR, KTC3198 Y/P
Q8902 23205499 TRANSISTOR, KTC3198 Y/P PC BOARD ASSEMBLIES
Q8911 23205499 TRANSISTOR, KTC3198 Y/P UD02 23148439 PC BOARD ASSY SCALER, 62HM85 B910PD2208B1
Q8912 23205499 TRANSISTOR, KTC3198 Y/P U103 23764144 PC BOARD ASSY, BACK AV PU PD1774C
QV48 23205499 TRANSISTOR, KTC3198 Y/P UA03 23764203 PC BOARD ASSY, DOOR SW PU PD2128A-4
Q152 23205347 TRANSISTOR, KTC4075Y/P UV03 23764204 PC BOARD ASSY, FRONT AV PU PD2128A-2
Q172 23205347 TRANSISTOR, KTC4075Y/P U101 23764145 PC BOARD ASSY, IF AUDIO ACIN PU PD1775D
Q613 23205347 TRANSISTOR, KTC4075Y/P U802 23764201 PC BOARD ASSY, MAIN POWER PU PD2128A-1
QY160 23205347 TRANSISTOR, KTC4075Y/P UA02 23764202 PC BOARD ASSY, REMORT SENS PU PD2128A-3
QA81 23205329 TRANSISTOR, RN1404(F) UA66 23590180 PC BOARD, FRONT 46WM48P PB PD2072
QA82 23205329 TRANSISTOR, RN1404(F) SK10 23122497 P0WER UNIT, RPB-4456BA RPB-4456BA
QA83 23205329 TRANSISTOR, RN1404(F) UV02 23148418 HDMI MODULE, MHDM01A, 05HDMI-01A-G
QA84 23205329 TRANSISTOR, RN1404(F) H002 23148378 IF MODULE, US BUFFER 6M TRAP, MVUS51A
QA85 23205329 TRANSISTOR, RN1404(F) UV02 23148408 MODULE, 03DVI, MHDM01
QA86 23205329 TRANSISTOR, RN1404(F)
QA87 23205329 TRANSISTOR, RN1404(F)
A
CCESSORIES
QA88 23205329 TRANSISTOR, RN1404(F) Y101E 23566609 OWNERS MANUAL, ENGLISH 52HM85 ENG
Q614 23205327 TRANSISTOR, RN1406(F) Y101F 23566610 OWNERS MANUAL, FRENCH 52HM85 FRE
Q664 23205325 TRANSISTOR, RN2404(F) Y102 23589650 IMPORTANT NOTES SHEET, 52HM84
QS05 23205325 TRANSISTOR, RN2404(F) BB70 23713810 PLUG , TAC-A46P-B1
DB82 23358585 LED, LAMP, SML-810MTT86 P892 23713764 PLUG, 13P
XY502 23153721 CERAMIC RESONATOR, 503KHZ P800 23713702 PLUG, 2P 11.88MM W VT
D899 76019486 VARISTOR, ENE431D-10A P811A 23713713 PLUG, 2P 3.96MM VH
D899 76019485 VARISTOR, TNR10V431K P902A 23164563 PLUG, 3P
P901 23713754 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4
MISCELLANEOUS P105 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4
F801A 23165433 FUSE HOLDER, 5.2 P903 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4
F899A 23165433 FUSE HOLDER, 5.2 PB22 23713755 PLUG, 4P 2.5MM G, B4B-EH-F1-TV4
F8210 23144709 FUSE, AXIAL 125V 1.5A P805 23164965 PLUG, 4P, W-P3504-#02
F840 23144704 FUSE, AXIAL 125V 200MA PJ60 23713756 PLUG, 5P 2.5MM G, B5B-EH-F1-TV4
F881 23144706 FUSE, AXIAL 125V 500MA PJ63 23713756 PLUG, 5P 2.5MM G, B5B-EH-F1-TV4
F840 23144279 FUSE, AXIAL, 125V 0.2A PJ64 23713757 PLUG, 6P 2.5MM G, B6B-EH-F1-TV4
F881 23144266 FUSE, AXIAL, 125V 0.5A P891 23713759 PLUG, 8P 2.5MM G, B8B-EH-F1-TV4
F8210 23144252 FUSE, AXIAL, 125V 1.5A PV14 23713781 PLUG, 8P 2.5MM W, S8B-EH
F860 23144250 FUSE, AXIAL, 125V 4A BB10 23713014 PLUG, B-B 16P 1.5
F860 23144714 FUSE, AXIAL, 125V 4A BB20 23713014 PLUG, B-B 16P 1.5
F880 23144250 FUSE, AXIAL, 125V 4A P906 23713761 PLUG, NP 2.5MM G, B10B-EH-F1A
F880 23144714 FUSE, AXIAL, 125V 4A PJ61 23713762 PLUG, NP 2.5MM G, B11B-EH-F1A
F882 23144250 FUSE, AXIAL, 125V 4A P907 23713763 PLUG, NP 2.5MM G, B12B-EH-F1A
F882 23144714 FUSE, AXIAL, 125V 4A PV13 23713760 PLUG, NP 2.5MM G, B9B-EH-F1A
F801 23144278 FUSE, CARTRIDGE 125V 8.0A P801 23372117 POWER CORD, U/C 125V10A HSV 5 CMC-02P 5
F883 23144227 FUSE, CARTRIDGE 5.2X20, 125V 5A K912 23306617 REMOCON HAND UNIT IR, CTVUSA CT-90159
F883 23144715 FUSE, CARTRIDGE 5.2X20, 125V 5A K912 23306596 REMOCON HAND UNIT, CT-90159
F884 23144227 FUSE, CARTRIDGE 5.2X20, 125V 5A KB01 23000852 REMOCON RECEIVER, PIC-37043TE2
F884 23144715 FUSE, CARTRIDGE 5.2X20, 125V 5A
F801 23144319 FUSE, CARTRIDGE 5.2X20, 125V 8A CABINATE PARTS
F899 23144326 FUSE, CARTRIDGE, 250V 2A, 5.2X20 H003 23124099 ANTENNA SWITCH, RSU135X1, 2I3O BUNPAI US
PV02 23023184 JACK, 1S3P, LAP5100-1502F A422 23084862 BRACKET, REAR VENT 52HMX85;B055047E
PV02 23023205 JACK, PIN 10P SMK KARI2 A278 23084267 BRACKET, SPEED CLIP
PV01 23023311 JACK, PIN 2S6P, LAP5030-0111GC A709 23067695 CARTON, BASE TRAY 62HM84 62HM84;C045012E
PV03 23023211 JACK, PIN 7P SMK KARI04 A701 23067698 CARTON, CARTON 62HM84;S1304D012
MX18 23389272 CABLE, FFC P1.25-11-365 B235 23845856 CLAMP, WIRE, POF COAT) L=70MM
MA01 23389271 CABLE, FFC P1.25-15-98 B236 23845856 CLAMP, WIRE, POF COAT) L=70MM
MX19 23389273 CABLE, FFC P1.25-17-410 A204 23532763 COVER, BACK COVER 62HM84 62HM84;S1304F048
MV04 23389270 CABLE, FFC P1.25-26-140 A205 23532784 COVER, BACKCOVER PURCHASE ASSY 62HM84;S1304F077
MV01 23368931 CABLE, MDR 26P 300MM 3M 79162-26M-030-011F A101 23533280 COVER, BASE PURCHASE ASSEY 52HM85;S1304E713
XY501 23153607 CRYSTAL, 3.58MHZ A201 23533345 COVER, BEZEL PURCHASE ASM 62HM85;S1304E791
S810 23344522 SWITCH, SPVF11 A025 23532769 COVER, LAMP TUNNEL PURCHASE ASY 52HM84
B214 23965241 TAPE, CC #12 10MM L30M A222 23532885 COVER, PEDESTAL ASSY 62HM84 62HM84;A045053E
B215 23965241 TAPE, CC #12 10MM L30M A401 23533281 COVER, REAR COVER PURCHASE 52HM85;S1304E714
J601A 23171400 WIRE, PVC, SOLDER-PLATED 300V 7/16 BRN UL CSA A421 23532738 COVER, REAR COVER,DLE 52HM84;S1304F012
PX18 23713270 CONNECTOR, 11FE-ST-VK-N 11FE-ST-VK-N A227 23433348 DECORATIVE, CTRL PANEL TRIM 62HM85;S1304E790
PA01 23713240 CONNECTOR, 15FE-BT-VK-N JST 15FE-BT-VK-N A026 23428292 DOOR, DOOR LAMP PURCHASE ASSY 52HM84
PV04 23713282 CONNECTOR, 26FE-ST-VK-N 26FE-ST-VK-N SK05 23311153 EXCHANGE LAMP, PJ-D95-LMP PJ-D95-LMP
- 10 -
Location
No.
Location
No.

Parts No. Description Parts No. Description
E998Z 23311153 EXCHANGE LAMP, PJ-D95-LMP PJ-D95-LMP
A184 23469392 INSULATOR, 05_LENS_GASKET 62HM195;C055045E
K601 23405383 MIRROR, 62C4M3 1426/695*725*3 MIRROR62C4M3
K601 23405562 MIRROR, 62E5M3 MIRROR62E5M3
K601 23405455 MIRROR, 62G4M3 MIRROR62G4M3
A271 23405476 OPTICAL ENGINE, LV-672 TB 0D LV-672 TB 0D
A708 23946769 PACKING, BOTTOM PACKING 62HM84 62HM84;A045027E
A710 23946775 PACKING, SUPPORT POST 62HM84;S1304D009
A703 23946772 PACKING, TOP PACKING 62HM84;A045030E
B112 23059129 PIECE COVER, 52HM84 52HM84
A333 23940463 PIECE, AV MOUNT PURCHASE ASY 52HM85;B045044E
A215 23940083 PIECE, PIECE ENCLOSURE,DLE 52HM84;S1304F019
A232 23940099 PIECE, PIECE SIDE LEFT 62HM84 62HM84;S1304F059
A231 23940100 PIECE, PIECE SIDE RIGHT 62HM84 62HM84;S1304F060
A225 23940084 PIECE, STRIKER 52HM84;S1304F028
A220 23451976 PUSH CATCH, CLICK
K501 23311080 SCREEN, 62K4M LENTICULAR SHEET SCREEN62K4ML
K502 23311081 SCREEN, 62K4MF FRESNEL SHEET SCREEN62K4MF
K501 23311137 SCREEN, 62K5M LENTICULAR SHEET SCREEN62K5ML
K501 23311149 SCREEN, 62K5N LENTICULAR SHEET SCREEN62K5NL
K502 23311158 SCREEN, 62K5NF SCREEN62K5NF
Q601B 23717240 SCREW
D883B 23717240 SCREW
D886B 23717240 SCREW
D887B 23717240 SCREW
D888B 23717240 SCREW
Q893B 23717241 SCREW, BITTB3X8ECO
Q894B 23717241 SCREW, BITTB3X8ECO
B209 23738088 SCREW, BTBW3X12ECO
B231 23738088 SCREW, BTBW3X12ECO
Q825B 23738088 SCREW, BTBW3X12ECO
A516 23717192 SCREW, SCREW, AV BOARD 62HM84;S1304F038
A516 23717443 SCREW, SCREW, AV BOARD ECO 62HM84;S1304F038
A305 23717197 SCREW, THUMB SCREW 52HM84
A305 23717197 SCREW, THUMB SCREW 52HM84
A306 23717198 SCREW, THUMB SCREW RETAINER 52HM84
A306 23717198 SCREW, THUMB SCREW RETAINER 52HM84
SK06 23587536 SERVICE KIT, B TO F CABLE B TO F CABLE
SK03 23587527 SERVICE KIT, BALLAST FAN BALLAST FAN
SK02 23587526 SERVICE KIT, DMD FAN DMD FAN
SK09 23587539 SERVICE KIT, FAN TRANSFER FAN TRANSFER
SK01 23587525 SERVICE KIT, LAMP FAN LAMP FAN
SK08 23587538 SERVICE KIT, S TO F CABLE S TO F CABLE
SK04 23587528 SERVICE KIT, THERMO STAT THERMO STAT
BB11 23713013 SOCKET, B-B 16P 1.5
BB21 23713013 SOCKET, B-B 16P 1.5
BB71 23903245 SOCKET, B-B 46P, TAC-A46X-B1
W661 23351244 SPEAKER, SPBOX(L) 8-OHM 20W SPK-1455AM
W662 23351245 SPEAKER, SPBOX(R) 8-OHM 20W SPK-1456AM
UA06 23764199 TOUCH PANEL FRONT KEY, PD2072H
A422 23084729 VENT, REAR DLE 52HMX85;S1304E778
- 11 -
Location
No.
Location
No.

TOSHIBA SINGAPORE PTE. LTD.
Blk438B ALEXANDRA ROAD #06-05 ALEXANDRA TECHNOPARK
