Toshiba S5ES Series User manual

SERVICE MANUAL
Color Television
S5ES series
FILE NO. 060-200564
Published in Singapore, September 2005 GREEN© TOSHIBA SINGAPORE PTE LTD
21CZ8DE
The above model is classified as green product(s) (*1), as indicated by the underlined serial number(s).
This Service Manual describes replacement parts for green product(s). When repairing any green product(s), use the
parts described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.

– 2 –
TABLE OF CONTENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS ............................................................................................................................................. 3
SET-UP ADJUSTMENT ................................................................................................................................................. 4
SERVICE MODE ........................................................................................................................................................... 6
DESIGN MODE ............................................................................................................................................................. 9
ELECTRICAL ADJUSTMENTS ................................................................................................................................... 10
CIRCUIT CHECK ......................................................................................................................................................... 11
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA ................................................................................................................................... 12
NAMES AND FUNCTIONS OF CONTROLS .............................................................................................................. 13
PROGRAMMING CHANNEL MEMORY ...................................................................................................................... 14
PROCEDURES TO SET HOTEL MODE ..................................................................................................................... 16
CHASSIS AND CABINET REPLACEMENT PARTS LIST ........................................................................................... 17
PC BOARDS BOTTOM VIEW...................................................................................................................................... 23
TERMINAL VIEW OF TRANSISTORS ........................................................................................................................ 26
CIRCUIT BLOCK DIAGRAM ....................................................................................................................................... 28
SPECIFICATIONS .................................................................................................................................................... END
APPENDIX:
CIRCUIT DIAGRAM
LEAD-FREE SOLDER
This product is manufactured using lead-free solder as a part of a movement within the CE industry at large to be environ-
mentally responsible. Lead-free solder must be used in the servicing and repair of this product.
WARNING
This product is manufactured using lead free solder.
DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT!
The melting temperature of lead-free solder is higher than that of leaded solder by 86˚F to 104˚F (30˚C to 40˚C). Use of a
soldering iron designed for lead-based solders to repair product made with lead-free solder may result in damage to the
component and or PCB being soldered. Great care should be made to ensure high-quality soldering when servicing this
product – especially when soldering large components, through-hole pins, and on PCBs – as the level of heat required to
melt lead-free solder is high.
GREEN PRODUCT PROCUREMENT
The EC is actively promoting the WEEE & RoHS Directives that define standards for recycling and reuse of Waste Electri-
cal and Electronic Equipment and for the Restriction of the use of certain Hazardous Substances. From July 1, 2006, the
RoHS Directive will prohibit any marketing of new products containing lead.
Increasing attention is given to issues related to the global environmental. Toshiba Corporation recognizes environmental
protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its
environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and
use products, parts and materials that have low environmental impacts.
Green procurement of parts is not only confined to manufacture. The same green parts used in manufacture must also be
used as replacement parts.
(*1)
(*2)

GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
–3 –
2. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION
protection, the replacement tube must be exactly the same
type tube as specified in the parts list.
3. Some part in this receiver have special safety-related
characteristics for X-RAY RADIATION protection. For
continued safety, parts replacement should be undertaken
only after referring to the PRODUCT SAFETY NOTICE
below.
SAFETY PRECAUTION
WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver.The following
are the necessary precautions to be observed before servicing this chassis.
1. An isolation transformer should be connected in the power line between the receiver and the AC line before any service is
performed on the receiver.
2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube
is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture
tube away from the unprotected body while handling.
3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as;
nonmetallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous
X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit.The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a (C) V AC
power source. The high voltage must not, under any
circumstances, exceed (B) kV.
Refer to table-1 for high voltage (A), (B) & AC voltage (C).
(See SETTING & ADJUSTING DATA on page 12)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the
reading of the high voltage be recorded as a part of the
service record. It is important to use an accurate and
reliable high voltage meter.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety char-
acteristics are identified in this manual and its supplements; electrical components having such features are identified by the
international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray radiation
or other hazards.

GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
–4 –
SET-UP ADJUSTMENT
RThe following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
Mounting position of the purity magnet assembly should fit to same position as old one because slightly difference to
the position depend on a kind of tube.
*There are no adjustment of purity and convergence in some picture tube (Unified with purity magnet)
5. Remove the Rubber Wedges.
6. Rotate and spread the tabs of the purity magnet (See fig-
ure 2.) around the neck of the picture tube until the green
belt is in the center of the screen. At the same time, enter
the raster vertically.
7. Slowly move the yoke forward or backward until a uniform
green screen is obtained. Tighten the clamp screw of the
yoke temporarily.
8. Check the purity of the red and blue raster.
GLASS CLOTH
TAPES
DEFLECTION
YOKE
TEMPORARY
MOUNTING
RUBBER WEDGE
ADHESIVE
DEFLECTION
YOKE
PURITY/
CONVERGENCE
MAGNET ASS'Y
29.1mm(28", 29")
25mm(25")
19mm(19", 20", 21")
14mm(13", 14")
Figure 1.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF THIS MANUAL.
COLOR PURITY ADJUSTMENT
NOTE : Before attempting any purity adjustments, the
receiver should be operated for at least fifteen min-
utes.
1. Demagnetize the picture tube and cabinet using a degauss-
ing coil.
2. Set the brightness and contrast to maximum.
3. Use a green raster from a signal generator.
4. Loosen the clamp screw holding the yoke and slide the
yoke backward or forward to provide vertical green belt
(zone) in the picture screen.

GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
–5 –
Figure 2.
BLU RED
BLU
RED
RED/BLU GRN
RED/BLU
GRN
B
G
R
R
G
B
BGR
RGB
BGR
RGB
R
G
B
B
G
R
4-POLE MAGNETS MOVEMENT
INCLINE THE YOKE UP (OR DOWN)
6-POLE MAGNETS MOVEMENT
Center Convergence by Convergence Magnets
Circumference Convergence by DEF Yoke
INCLINE THE YOKE RIGHT (OR LEFT)
Figure 3. Dot Movement Pattern
4-POLE
MAGNETS
PURITY
MAGNETS
6-POLE
MAGNETS
ADJUST THE ANGLE
(VERTICAL LINES) FIXED
ROTATE TWO TABS
AT THE SAME TIME
(HORIZONTAL LINES)
CONVERGENCE MAGNET ASSEMBLY ADJUSTMENT OF MAGNETS
R CIRCUMFERENCE CONVERGENCE ADJUSTMENT
1. Loosen the clamping screw of deflection yoke slightly to
allow the yoke to tilt.
2. Temporarily put a wedge as shown in figure 1. (Do not
remove cover paper on adhesive part of the wedge.)
3. Tilt front of the deflection yoke up or down to obtain better
convergence in circumference. (See figure 3.) Push the
mounted wedge into the space between picture tube and
the yoke to fix the yoke temporarily.
4. Put other wedge into bottom space and remove the cover
paper to stick.
5. Tilt front of the yoke right or left to obtain better convergence
in circumference. (See figure 3.)
6. Keep the yoke position and put another wedge in either
upper space. Remove cover paper and stick the wedge on
picture tube to fix the yoke.
7. Detach the temporarily mounted wedge and put it in an-
other upper space. Stick it on picture tube to fix the yoke.
8. After fixing three wedges, recheck overall convergence.
Tighten the screw firmly to fix the yoke and check the yoke
is firm.
9. Stick three adhesive tapes on wedges as shown in figure
1.
CONVERGENCE ADJUSTMENTS
NOTE: Before attempting any convergence adjustments, the
receiver should be operated for at least fifteen
minutes.
R CENTER CONVERGENCE ADJUSTMENT
1. Use the cross-dot pattern from a signal generator.
2. Set the brightness and contrast for well defined pattern.
3. Adjust two tabs of the 4-Pole Magnets to change the angle
between them (See figure 2.) and superimpose red
and blue vertical lines in the center area of the picture
screen.
4. Turn the both tabs at the same time keeping the angle
constant to superimpose red and blue horizontal lines at
the center of the screen.
5. Adjust two tabs of 6-Pole Magnets to superimpose red/
blue line and green one. Adjusting the angle affects the
vertical lines and rotating both magnets affects the
horizontal lines.
6. Repeat adjustments 3, 4, 5 keeping in mind red, green
and blue movement, because 4-Pole Magnets and 6-Pole
Magnets have mutual interaction and make dot movement
complex.

GENERAL ADJUSTMENTS
–6 –
SERVICE MODE
1. ENTERING TO SERVICE MODE
1) Press obutton once on
Remote Control.
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
A single horizontal line ON/OFF: - / - - button (on remote control)
Test signal ON/OFF : abutton (on TV or remote control)
Selection of the adjustment items : Channel s/t(on TV or remote control)
Change of the data value : Volume ;+/–(on TV or remote control)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory (QA10) : CALL + Channel button on TV (s)
Reset the count of operating protect
circuit to “00”: CALL + Channel button on TV (t)
“VG2”alignment : 0 button
“BCUT”selection : 1 button
“GCUT”selection : 2 button
“SCNT”selection : 4 button
“COLC”selection : 5 button
“TNTC”selection : 6 button
“SBY”selection : 7 button
Self diagnostic display ON/OFF : 9 button
CAUTION : Never try to perform initialization unless you have changed the memory IC.
2) Press obutton again to
keep pressing.
3) While pressing the obutton,
press MENU button on TV.
Color thickness correction
note: Displayed differently as shown below, depending
on the setting of the receiving color system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
S
(Service mode display)
Item
Data
Adjustment mode
Press
Press
Service mode
Item
Data
S

GENERAL ADJUSTMENTS
–7 –
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CH sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 12)
5. ADJUSTING THE DATA
1) Pressing of ;+/–button will change the value of data in the range from 00H to FFH. The variable range depends on
the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
RINITIALIZATION OF MEMORY DATA OF QA02
After replacing QA10, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the remote control, then press the CH sbutton on the TV. The initialization of QA10
has been completed.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “ASM function”on the owner’s manual.
CAUTION: Never attempt to initialize the data unless QA02 has been replaced.

GENERAL ADJUSTMENTS
–8 –
7. SELF DIAGNOSTIC FUNCTION
1) Press “9”button on the remote control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
Indicated color of mode now selected : Green and Red
Indicated color of other modes : White
Green : Normal
Red : The microprocessor operates to provide judgement
of no video signal.
OTHERS : (1) In case that power indicator is blinking with
interval of 0.5 seconds; it means protecting
circuit (Current limiter) is operating, and circuit
components may possibly be damaged.
Check related components.
(2) In case that power indicator is blinking with
interval of 1 second; Protecting circuit does
not operate, but a part of Bus line does not
operate normally. Check Bus line.
1Part number of microprocessor (QA51)
2Software type:
“ECMVT A01”--------- Software for Asian models.
“ERFAP R01”--------- Software for Russian models.
“ERFAP P01”--------- Software for Middle East models.
3Software version
4Memory IC data version
5Protection circuit operation count
6BLOCK
UV : TV reception mode
V1 : VIDEO 1 input mode (a1)
V2 : VIDEO 2 input mode (a2)
V3 : VIDEO 3 input mode (a3)
MICON : 23* * * * * *
S/W : E* * * * * 01
V 1.00
EEP : V00
POWER : 000
BLOCK : UV V1 V2 V3
<SELF CHECK>
1
2
3
4
5
6

GENERAL ADJUSTMENTS
–9 –
DESIGN MODE
2) While pressing CALL button
again and press MENU button
on the TV.
3) Press MENU button on TV.
ITEM
DATA
S D Press
(Design mode) (Adjustment mode)
Press
1. ENTERING TO DESIGN MODE
1) When in Service mode (see
page 6), press CALL button
on the remote control once.
When QA10 is initialized, items “OPT”,“OPT1”and “OPT2”of DESIGN MODE are set to the data of the representative model
of this chassis family.
Therefore, because ON-SCREEN specification remains in the state of the representative of model. This model is required to
reset the data of items “OPT”,“OPT1”and “OPT2”according to current on-serviced model .
2. SELECTING THE ADJUSTING ITEMS
Every pressing of CH tbutton in the design mode changes the adjustment items in the order of table-3.
(sbutton for reverse order)
Refer to table-3 for data of design mode.
(See SETTING & ADJUSTING DATA on page 12)
3. ADJUSTING THE DATA
Pressing of ;-/+ buttons will change the value of data.

GENERAL ADJUSTMENTS
–10 –
ELECTRICAL ADJUSTMENTS
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
HORIZONTAL POSITION
ADJUSTMENT (HPOS)
VERTICAL POSITION
ADJUSTMENT (VPOS)
VERTICAL AMPLITUDE
ADJUSTMENT (HIT)
1. Enter the service mode, then input AV1 black cross-bar pattern with signal generator.
2. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
1. Input AV1 “5 steps pattern”with video signal
generator.
2. Set CONTRAST to minimum and
BRIGHTNESS to center by adjusting user
controls.
3. Enter Service mode and press CH s/tto
select BRTC.
4. Press ;–/+ buttons to adjust BRTC until
step 0 and step 1 has the same blackness.
5. Exit service mode and press hbutton to
set picture mode to DYNAMIC.
1. Enter the service mode, input AV1 black
or white cross-bar signal with signal
generator.
2. Select either HPOS (Horizontal picture
phase) or VPOS (Vertical picture
phase) with CH s/tbuttons, and
adjust horizontal or vertical picture
position in the center of screen with
;–/+ buttons.
1. Enter the service mode, input AV1 black
or white cross-hatch signal with signal
generator.
2. Select HIT (Vertical amplitude) with
CH s/tbuttons, and adjust vertical
amplitude with ;–/+ buttons so that
vertical amplitude lacks a little.
3. Adjust vertical amplitude with ;–/+
buttons so that the first bar on cross-
hatch signal touches edge of screen.
The first
ITEM ADJUSTMENT PROCEDURE

GENERAL ADJUSTMENTS
–11 –
WHITE BALANCE
ADJUSTMENT
SCREEN VOLTAGE ADJUST-
MENT (SCREEN VR) of FBT
•DRIVE ADJUSTMENT
(GDRV)
(BDRV)
(RDRV)
•CUTOFF ADJUSTMENT
(GCUT)
(BCUT)
ITEM ADJUSTMENT PROCEDURE
1. Select AV1 (with no input).
2. Enter Service mode and press “0”button.
3. Adjust Screen VR until OSD “HBC”toggle
between 1 & 0.
4. Press “0”button again to exit.
5. Input AV1 “5 steps pattern”with video signal
generator.
6. Press hbutton to set picture mode to
DYNAMIC.
XTo correct white balance in high light area
(steps 3 and 4) select GDRV, BDRV and
RDRV with ;–/+buttons.
XTo correct white balance in low light area
(steps 1 and 2), select GCUT and BCUT.
CIRCUIT CHECK
HIGH VOLTAGE CHECK
CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps below.
1. Connect an accurate high voltage meter to the second anode of the picture tube.
2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current).
3. High voltage must be measured below (B) kV.
Refer to table-1 for high voltage (B).
(See SETTING & ADJUSTING DATA on page 12)
4. Vary the BRIGHTNESS control to both extremes to be sure the high voltage does not exceed the limit under any conditions.

SPECIFIC INFORMATIONS
–12 –
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA
SAFETY INSTRUCTIONS
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
Table-1
Table-2
21"
HIGH VOLTAGE AT MAX BEAM CURRENT: (A) 30.0 kV
MAX HIGH VOLTAGE: (B) 32.0 kV
AC VOLTAGE (C) 110-240 V
BCUT B CUTOFF (B/W) 20H ←
GCUT G CUTOFF (B/W) 20H ←
RDRV R DRIVE 20H ←
GDRV G DRIVE 20H ←
BDRV B DRIVE 20H ←
BRTC SUB BRIGHT CENTER 24H ←
COLC SUB COLOR CENTER NTSC 1EH ←
TNTC SUB TINT CENTER 1EH ←
COLP SUB COLOR CENTER PAL 1DH ←
COLS SUB COLOR CENTER SECAM 1DH ←
SCNT SUB CONTRAST TV 00H ←
SBY SECAM B-Y BLACK OFFSET 01H ←
VPOS 50Hz V-POSITION 1CH ←
HIT HEIGHT 25H ←
VLIN V-LINEARITY 24H ←
HPOS H-POSITION 2BH ←
WID EW WIDTH 31H ←
PARA EW PARABOLA 17H ←
TRAP EW TRAPEZIUM 26H ←
TCNR EW UPPER PARABOLA 15H ←
BCNR EW LOWER PARABOLA 15H ←
HPLL HORIZONTAL PARALLELOGRAM 22H ←
HBOW HORIZONTAL BOW 20H ←
XCAL CRYSTAL CALIBRATION 30H ←
RAGC AGC TAKE-OVER 12H ←
CTR1 CONTROL 1 07H ←
Item Adjustment Reference Data Adjust Data

SPECIFIC INFORMATIONS
–13 –
NAMES AND FUNCTIONS OF CONTROLS
TV Front and Remote control

SPECIFIC INFORMATIONS
–14 –
PROGRAMMING CHANNEL MEMORY
To use the SEARCH function
1Press MENU and then ; -/+ to highlight
the “TUNING”icon.
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P001
ON
MENU
SELECT / MENU –/+ BACK
2Press CH s/tto select “SEARCH”. Press ; -/+ to
start searching. Pressing “–” searches for channels at
lower frequencies while pressing “+”searches for
channels at higher frequencies. While searching,
pressing the opposite direction button, + and -
respectively, will cancel SEARCH function.
SEARCH VHF H P001
STOP
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P001
ON
MENU
SELECT / ADJUST –/+ BACK
Repeat this process until you can get the desired
channel.
3When the desired channel is shown, press CH tto
select “POSITION”. Press the ; -/+ buttons
repeatedly until the position number to be preset is
shown.
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P002
OFF
MENU
SELECT / ADJUST –/+ BACK
4Press CH s/tto select “MEMORY”, then press ; +
to memorize the channel at the current position.
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P002
OFF
MENU
SELECT / ADJUST –/+ BACK
TUNING
5When you program other channels, repeat steps 2 to
4.
Preset the channels automatically
(ASM function)
Use remote control for this operation. The buttons on the TV
with similar name may also be use.
1Select the starting position for channel to be preset.
Press the Number buttons (-/--, 0~9) or CH s/t.
1
2Set the correct broadcast system for your region.Press
MENU and then ; -/+ to highlight the “SET UP”
icon.
SETUP
LANGUAGE
COLOR MODE
SOUND MODE
SKIP
BLUE SCREEN
TEXT
ON
FAST
AUTO
OFF
B/G
ENGLISH
MENU
SELECT / ADJUST –/+ BACK
Confirm “COLOR MODE”is set to “AUTO”and
“SOUND MODE”is set to proper system. If not, press
CH s/tto select “COLOR MODE”or “SOUND MODE”
and press ; -/+ to set each proper system.
3Press MENU and then ;-/+ to highlight
the “TUNING”icon. Select “ASM”, then press ; +
to start the search. When the TV screen returns to the
start position, the procedure is complete.
CH
CH
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P001
OFF
MENU
SELECT / ADJUST –/+ BACK
Presetting channel
•First, use the ASM (Automatic Search Memory) function
to preset all active channels in your area automatically.
Then, arrange the preset channels with the SEARCH,
SKIP and MFT (Manual Fine Tuning) functions so that
you can tune into only desired channels.
•Use the SEARCH function if desired channels cannot be
preset with the ASM or if you would like to preset channels
to specific position numbers one by one.

SPECIFIC INFORMATIONS
–15 –
Auto fine tuning (AFT)
If the signal frequency is unstable due to environmental
conditions, use auto fine tuning.
1Select the position number where the channel you
want to fine-tune with CH s/tor the digit selection
and number buttons (-/--, 0~9).
Note
When the position is set to “AFT OFF”status, the “R”
mark appears to the left of the position number.
When the channel is set to “AFT ON”status,the
position number is displayed without the “R”mark.
2Press MENU then ; -/+ to highlight the “TUNING”
icon.
3Press CH s/tto select “AFT”. Press ; -/+ to select
the “ON”indication.
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P002
OFF
MENU
SELECT / ADJUST –/+ BACK
Notes
•When you operate MFT, AFT is switched “OFF”
automatically. If you switch on AFT after fine tuning with
MFT, MFT may be canceled.
•AFT may be set independently for each position.
Manual fine tuning (MFT)
The adjustments below are not necessary under normal
conditions. However, under some reception conditions, fine
tuning may be necessary to improve the picture quality. In
such cases, adjust the manual fine tuning (MFT).
1Select the position number where the channel you
want to fine-tune with CH s/tor digit selection and
number buttons (-/--,0~9).
2Press MENU and then ; -/+ to highlight the “
TUNING”icon.
3Press CH s/tto select “MFT”. Press ; -/+ to start
fine tuning. Press ; -/+ repeatedly until the best
possible picture and sound are obtained.
To skip a position number
After presetting the channels, you may skip unnecessary
position numbers so that only the channels you want to watch
are selected using CH s/t.
1First, select the position number to be skipped with
CH s/tor digit selection and number buttons (-/--,
0~9).
2Highlight the “SET UP”icon and press CH s/tto
select “SKIP”.
SETUP
LANGUAGE
COLOR MODE
SOUND MODE
SKIP
BLUE SCREEN
TEXT
ON
FAST
AUTO
ON
B/G
ENGLISH
MENU
SELECT / ADJUST –/+ BACK
3Press the ; -/+ to set “SKIP”to “ON”.This completes
the setting for skipping the selected position number.
Notes
•When “SKIP”is set to “ON”for the selected position number,
a “* ”mark appears to the left of the position number.
The position number will then be skipped when you select
the position with the CH s/tbuttons.
•If you want to restore a skipped position number, select it
using the -/-- and 0~9 buttons then switch the “SKIP”setting
to “OFF”.
TUNING
MFT
AFT
ASM
SEARCH
POSITION
MEMORY
P002
ON
MENU
SELECT / ADJUST –/+ BACK

SPECIFIC INFORMATIONS
–16 –
PROCEDURES TO SET HOTEL MODE
1. Set the Channel Programs which you want the Customer to watch.
1) Use ASM (see page 14) or SEARCH (see page 14) to select the programs.
2) Choose the position you want the programs to be stored in TUNING menu.
3) Save the programs by MEMORY operation in TUNING menu (see page 14).
2. Set the Channels which you don’t want the Customer to access
1) Select the channel by pressing the number buttons or CH s/tbuttons.
2) Set the SKIP from OFF to ON (see page 15).
3) Repeat above 1) & 2) for all the channels which need to be blocked.
3. Activate the HOTEL Mode:
1) Select startup channel (TV, video input 1, 2, or 3) first, then enter into design mode (see page 9).
2) In Design Mode (see page 9), press CH tbutton on the remote controller to show the Design Item “OPT1”.
3) Add “0x80”to the data of “OPT1”to activate the HOTEL Mode with panel buttons unlocked, or add “0xC0”to the
data of “OPT1”to activate the HOTEL Mode with panel buttons locked.
4) AC Power OFF the TV, then next time AC Power ON the TV will in HOTEL Mode with all the customer settings
taking effect.
4. Set the maximum volume:
1) Enter Service Mode (see page 6).
2) Enter Design Mode (see page 9).
3) Use the CH tbutton on the remote controller to show the Design Item “VOLX”.
4) Adjust the “VOLX”data by pressing ;+/- buttons (Default 0x1E is equal to Volume 30 in Decimal).
5. Set the following items in HOTEL Mode:
1) Picture mode
Press hbutton to select the desired picture quality. “DYNAMIC”, “STANDARD”, “MILD”and “MEMORY”will appear
cyclically.
2) Sound mode
Press 8button to select the desired sound quality. “THEATER”, “NEWS”and “MEMORY”will appear cyclically.
(Every time AC Power ON the TV will call back the above customer setting.)

– 17 –
SPECIFIC INFORMATIONS
CHASSIS AND CABINET REPLACEMENT PARTS LIST
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRE-
CAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
•The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
•The PC board assembly with *mark is no longer available after the end of the production.
Model: 21CZ8DE
Capacitors .......... CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............ CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Location Parts No. Description
No.
Location Parts No. Description
No.
CAPACITORS
C101 76797479 ELECTROLYTIC 50V 4.7UF M
C102 76109103 CERAMIC CHIP 50V B 0.01UF K
C103 76109103 CERAMIC CHIP 50V B 0.01UF K
C104 76109103 CERAMIC CHIP 50V B 0.01UF K
C105 76109103 CERAMIC CHIP 50V B 0.01UF K
C106 76109103 CERAMIC CHIP 50V B 0.01UF K
C107 76109102 CERAMIC CHIP 50V B 1000PF K
C108 76797100 ELECTROLYTIC 50V 10UF M
C109 76797221 ELECTROLYTIC 50V 220UF M
C110 76797221 ELECTROLYTIC 50V 220UF M
C114 76109103 CERAMIC CHIP 50V B 0.01UF K
C116 76109103 CERAMIC CHIP 50V B 0.01UF K
C121 76797100 ELECTROLYTIC 50V 10UF M
C122 76100104 CERAMIC CHIP 25V F 0.1UF Z
C123 76109332 CERAMIC CHIP 50V B 3300PF K
C124 76100104 CERAMIC CHIP 25V F 0.1UF Z
C125 76797229 ELECTROLYTIC 50V 2.2UF M
C127 76797229 ELECTROLYTIC 50V 2.2UF M
C128 76100104 CERAMIC CHIP 25V F 0.1UF Z
C129 76793471 ELECTROLYTIC 10V 470UF M
C131 76109103 CERAMIC CHIP 50V B 0.01UF K
C156 76105120 CERAMIC CHIP 50V CH 12PF J
C157 76105510 CERAMIC CHIP 50V CH 51PF J
C158 76797100 ELECTROLYTIC 50V 10UF M
C159 76100104 CERAMIC CHIP 25V F 0.1UF Z
C201 76109682 CERAMIC CHIP 50V B 6800PF K
C202 76125006 E. CAP 25V 1.5UF REA1R5K1EFC-0511
C203 76503045 PLASTIC FILM 63V 0.22UF J
C204 76795100 ELECTROLYTIC 25V 10UF M
C205 76109223 CERAMIC CHIP 25V B 0.022UF K
C206 76100104 CERAMIC CHIP 25V F 0.1UF Z
C211 76100104 CERAMIC CHIP 25V F 0.1UF Z
C212 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C219 76109102 CERAMIC CHIP 50V B 1000PF K
C220 76503045 PLASTIC FILM 63V 0.22UF J
C303 76214471 CERAMIC DISC 500V B 470PF K
C308 76669221 ELECTROLYTIC 50V 220UF M
C309 76667102 ELECTROLYTIC 25V 1000UF M
C310 76667222 ELECTROLYTIC 25V 2200UF M 3A
C313 76082061 PLASTIC FILM 100V 0.47UF J
C315 76109102 CERAMIC CHIP 50V B 1000PF K
C321 76109272 CERAMIC CHIP 50V B 2700PF K
C322 76214471 CERAMIC DISC 500V B 470PF K
C327 76100102 CERAMIC CHIP 50V F 1000PF Z
C328 76693104 PLASTIC FILM 100V 0.1UF J
C329 76100102 CERAMIC CHIP 50V F 1000PF Z
C331 76109472 CERAMIC CHIP 50V B 4700PF K
C333 76667222 ELECTROLYTIC 25V 2200UF M 3A
C335 76667221 ELECTROLYTIC 25V 220UF M
C336 76109272 CERAMIC CHIP 50V B 2700PF K
C350 76503043 PLA CAP PCMT36676154
C363 76693104 PLASTIC FILM 100V 0.1UF J
C402 76693472 PLASTIC FILM 100V 4700PF J
C417 76214391 CERAMIC DISC 500V B 390PF K
C430 76092731 CERAMIC CHIP 16V B 1UF K
C432 76100102 CERAMIC CHIP 50V F 1000PF Z
C435 76794220 ELECTROLYTIC 16V 22UF M
C440 76503193 PLASTIC FILM 1500VH 1000PF H
C442 76168022 PLASTIC FILM 540)250V 334J 4-15
C444 76503278 PLASTIC FILM 1500VH 8700PF H
C447 76679100 ELECTROLYTIC 250V 10UF M 3A
C448 76640908 ELECTROLYTIC 160V 33UF M 3A LI
C449 76667102 ELECTROLYTIC 25V 1000UF M
C463 76212222 CERAMIC DISC 50V B 2200PF K
C464 76073124 ELECTROLYTIC 100V 10UF M
C467 76829433 PLASTIC FILM 400V 0.043UF J
C470 76766470 ELECTROLYTIC 50V 47UF M
C4712 76109332 CERAMIC CHIP 50V B 3300PF K
C472 76503049 PLASTIC FILM 63V 0.47UF J
C475 76100103 CERAMIC CHIP 50V F 0.01UF Z
C501 76793470 ELECTROLYTIC 10V 47UF M
C502 76092730 CERAMIC CHIP 16V B 0.1UF K
C503 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C504 76100104 CERAMIC CHIP 25V F 0.1UF Z
C505 76793471 ELECTROLYTIC 10V 470UF M
C506 76100104 CERAMIC CHIP 25V F 0.1UF Z
C507 76793471 ELECTROLYTIC 10V 470UF M
C508 76100104 CERAMIC CHIP 25V F 0.1UF Z
C509 76109561 CERAMIC CHIP 50V B 560PF K
C510 76105220 CERAMIC CHIP 50V CH 22PF J
C511 76105220 CERAMIC CHIP 50V CH 22PF J
C512 76105220 CERAMIC CHIP 50V CH 22PF J
C660 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C662 76109102 CERAMIC CHIP 50V B 1000PF K
C663 76797229 ELECTROLYTIC 50V 2.2UF M
C664 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C666 76109102 CERAMIC CHIP 50V B 1000PF K
C667 76797229 ELECTROLYTIC 50V 2.2UF M
C671 76763471 ELECTROLYTIC 16V 470UF M
C672 76203470 ELECTROLYTIC 16V 47UF M 7L 3A
C681 76765102 ELECTROLYTIC 35V 1000UF M
C682 76765102 ELECTROLYTIC 35V 1000UF M
C683 76765102 ELECTROLYTIC 35V 1000UF M
C684 76794470 ELECTROLYTIC 16V 47UF M
C686 76092883 CERAMIC CHIP 50V B 0.1UF K

–18 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
C687 76092883 CERAMIC CHIP 50V B 0.1UF K
C690 76766101 ELECTROLYTIC 50V 100UF M
zC801 76503507 PLASTIC FILM AC275V 0.22UF K
zC802 76503507 PLASTIC FILM AC275V 0.22UF K
C805 76092281 CERAMIC DISC AC250V E 4700PF
C806 76092281 CERAMIC DISC AC250V E 4700PF
C808 76794222 ELECTROLYTIC 16V 2200UF M
C809 76797479 ELECTROLYTIC 50V 4.7UF M
C810 76086857 ELECTROLYTIC 400V 560UF
zC811 76166021
CERA CAP E 250V 102 DE1E3KX102MB4BL01
zC813 76166021 CERA CAP E 250V 102 DE1E3KX102MB4BL01
zC814 76166021 CERA CAP E 250V 102 DE1E3KX102MB4BL01
zC815 76166021 CERA CAP E 250V 102 DE1E3KX102MB4BL01
C817 76092347 CERAMIC DISC 2KV R 1500PF K
C818 76105471 CERAMIC CHIP 50V CH 470PF J
C820 76591473 PLASTIC FILM 50V 0.047UF J
C821 76797470 ELECTROLYTIC 50V 47UF M
C823 76105221 CERAMIC CHIP 50V CH 220PF J
C824 76109182 CERAMIC CHIP 50V B 1800PF K
C830 76212103 CERAMIC DISC 50V B 0.01UF K
C831 76794101 ELECTROLYTIC 16V 100UF M
C832 76794101 ELECTROLYTIC 16V 100UF M
C833 76212103 CERAMIC DISC 50V B 0.01UF K
C834 76794101 ELECTROLYTIC 16V 100UF M
C836 76794102 ELECTROLYTIC 16V 1000UF M
C837 76794101 ELECTROLYTIC 16V 100UF M
C838 76503047 PLASTIC FILM 63V 0.33UF J
C839 76503047 PLASTIC FILM 63V 0.33UF J
C841 76503047 PLASTIC FILM 63V 0.33UF J
C842 76503047 PLASTIC FILM 63V 0.33UF J
C843 76794101 ELECTROLYTIC 16V 100UF M
C848 76212103 CERAMIC DISC 50V B 0.01UF K
C849 76794101 ELECTROLYTIC 16V 100UF M
C884 76086052 ELECTROLYTIC 200V 220UF M 22A
C885 76214471 CERAMIC DISC 500V B 470PF K
C888 76105471 CERAMIC CHIP 50V CH 470PF J
C889 76796222 ELECTROLYTIC 35V 2200UF M
C890 76796222 ELECTROLYTIC 35V 2200UF M
C891 76794471 ELECTROLYTIC 16V 470UF M
C892 76214471 CERAMIC DISC 500V B 470PF K
C893 76092337 CERAMIC DISC 2KV 220PF K
C894 76214471 CERAMIC DISC 500V B 470PF K
C895 76796332 ELECTROLYTIC 35V 3300UF M
C896 76668331 ELECTROLYTIC 35V 330UF M 3A
C897 76214471 CERAMIC DISC 500V B 470PF K
C898 76503045 PLASTIC FILM 63V 0.22UF J
C899 76214471 CERAMIC DISC 500V B 470PF K
C901 76214103 CERAMIC DISC 500V B 0.01UF K
C902 76092349 CERAMIC DISC 2KV R 2200PF K
C902 76092353 CERAMIC DISC 2KV 4700PF K
C903 76082637 PLASTIC FILM 400V 0.1UF J
C904 76679100 ELECTROLYTIC 250V 10UF M 3A
C909 76679100 ELECTROLYTIC 250V 10UF M 3A
C910 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
C911 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
C912 76763471 ELECTROLYTIC 16V 470UF M
C931 76214101 CERAMIC DISC 500V B 100PF K
CA01 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
CA03 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA04 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA05 76092730 CERAMIC CHIP 16V B 0.1UF K
CA06 76793101 ELECTROLYTIC 10V 100UF M
CA101 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA108 76105680 CERAMIC CHIP 50V CH 68PF J
CA109 76105680 CERAMIC CHIP 50V CH 68PF J
CA110 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA112 76795100 ELECTROLYTIC 25V 10UF M
CA116 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA117 76797221 ELECTROLYTIC 50V 220UF M
CA118 76092730 CERAMIC CHIP 16V B 0.1UF K
CA119 76797229 ELECTROLYTIC 50V 2.2UF M
CA120 76100103 CERAMIC CHIP 50V F 0.01UF Z
CA124 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA14 76795100 ELECTROLYTIC 25V 10UF M
CA30 76100104 CERAMIC CHIP 25V F 0.1UF Z
CA31 76100104 CERAMIC CHIP 25V F 0.1UF Z
CA88 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA89 76793101 ELECTROLYTIC 10V 100UF M
CA90 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA91 76092730 CERAMIC CHIP 16V B 0.1UF K
CA92 76793101 ELECTROLYTIC 10V 100UF M
CA93 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA94 76793101 ELECTROLYTIC 10V 100UF M
CA95 76092730 CERAMIC CHIP 16V B 0.1UF K
CA96 76092734 CERAMIC CHIP 16V F 0.22UF Z
CA97 76100103 CERAMIC CHIP 50V F 0.01UF Z
CA98 76105680 CERAMIC CHIP 50V CH 68PF J
CA99 76105680 CERAMIC CHIP 50V CH 68PF J
CB01 76794470 ELECTROLYTIC 16V 47UF M
CB07 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
CC01 76109103 CERAMIC CHIP 50V B 0.01UF K
CC02 76109102 CERAMIC CHIP 50V B 1000PF K
CC03 76109102 CERAMIC CHIP 50V B 1000PF K
CC04 76109102 CERAMIC CHIP 50V B 1000PF K
CC05 76109102 CERAMIC CHIP 50V B 1000PF K
CC06 76109102 CERAMIC CHIP 50V B 1000PF K
CC07 76109102 CERAMIC CHIP 50V B 1000PF K
CC08 76109102 CERAMIC CHIP 50V B 1000PF K
CC09 76109102 CERAMIC CHIP 50V B 1000PF K
CC14 76109103 CERAMIC CHIP 50V B 0.01UF K
CS01 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
CS02 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
CS03 76794220 ELECTROLYTIC 16V 22UF M
CS04 76100103 CERAMIC CHIP 50V F 0.01UF Z
CS05 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS06 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS07 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS08 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS09 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS10 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS11 76206478 ELECTROLYTIC 50V 0.47UF M 7L 3A
CS12 76105470 CERAMIC CHIP 50V CH 47PF J
CS13 76105470 CERAMIC CHIP 50V CH 47PF J
CS14 76105470 CERAMIC CHIP 50V CH 47PF J
CS15 76105470 CERAMIC CHIP 50V CH 47PF J
CS16 76105470 CERAMIC CHIP 50V CH 47PF J
CS17 76105470 CERAMIC CHIP 50V CH 47PF J
CS18 76105470 CERAMIC CHIP 50V CH 47PF J
CS19 76105470 CERAMIC CHIP 50V CH 47PF J
CS20 76105470 CERAMIC CHIP 50V CH 47PF J
CS21 76105470 CERAMIC CHIP 50V CH 47PF J
CS22 76105470 CERAMIC CHIP 50V CH 47PF J
CS23 76105470 CERAMIC CHIP 50V CH 47PF J
CV06 76762471 ELECTROLYTIC 10V 470UF M
CV08 76795470 ELECTROLYTIC 25V 47UF M
CV09 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV10 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV11 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV13 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV14 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV15 76100104 CERAMIC CHIP 25V F 0.1UF Z
CV16 76105101 CERAMIC CHIP 50V CH 100PF J
CV17 76105101 CERAMIC CHIP 50V CH 100PF J
CV18 76105101 CERAMIC CHIP 50V CH 100PF J
CV19 76105101 CERAMIC CHIP 50V CH 100PF J
CV20 76105101 CERAMIC CHIP 50V CH 100PF J
CV22 76109102 CERAMIC CHIP 50V B 1000PF K
Z154 23303166 CERAMIC TRAP 39.5MHZ TCF1107
Z155 23303224 CERAMIC TRAP TCF1120AM
RESISTORS
C4717 76000445 CHIP JUMPER 1608TYPE
D4703 76000445 CHIP JUMPER 1608TYPE
GJ01 76011472 CHIP 1/20W 4.7K OHM J
GJ02 76011472 CHIP 1/20W 4.7K OHM J
GJ03 76000445 CHIP JUMPER 1608TYPE
GJ05 76000445 CHIP JUMPER 1608TYPE
GJ808 76000445 CHIP JUMPER 1608TYPE
GJ811 76000445 CHIP JUMPER 1608TYPE
GR828 76366221 CARBON FILM 1/6W 220 OHM J
JR001 76000445 CHIP JUMPER 1608TYPE
JR002 76000445 CHIP JUMPER 1608TYPE
JR003 76000445 CHIP JUMPER 1608TYPE
JR004 76000445 CHIP JUMPER 1608TYPE
JR005 76000445 CHIP JUMPER 1608TYPE
JR006 76000445 CHIP JUMPER 1608TYPE
JR007 76000445 CHIP JUMPER 1608TYPE
JR008 76000445 CHIP JUMPER 1608TYPE

–19 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
JR009 76000445 CHIP JUMPER 1608TYPE
JR010 76000445 CHIP JUMPER 1608TYPE
JR011 76000445 CHIP JUMPER 1608TYPE
JR012 76000445 CHIP JUMPER 1608TYPE
JR013 76000445 CHIP JUMPER 1608TYPE
JR014 76000445 CHIP JUMPER 1608TYPE
JR015 76000445 CHIP JUMPER 1608TYPE
JR016 76000445 CHIP JUMPER 1608TYPE
JR017 76000445 CHIP JUMPER 1608TYPE
JR018 76000445 CHIP JUMPER 1608TYPE
JR019 76000445 CHIP JUMPER 1608TYPE
LC04 76366101 CARBON FILM 1/6W 100 OHM J
LC05 76366101 CARBON FILM 1/6W 100 OHM J
LC06 76000445 CHIP JUMPER 1608TYPE
LC07 76000445 CHIP JUMPER 1608TYPE
LC08 76000445 CHIP JUMPER 1608TYPE
LC09 76000445 CHIP JUMPER 1608TYPE
LC10 76000445 CHIP JUMPER 1608TYPE
LC11 76000445 CHIP JUMPER 1608TYPE
LC12 76000445 CHIP JUMPER 1608TYPE
LC13 76000445 CHIP JUMPER 1608TYPE
LC14 76000445 CHIP JUMPER 1608TYPE
LC15 76000445 CHIP JUMPER 1608TYPE
LC16 76000445 CHIP JUMPER 1608TYPE
LC17 76000445 CHIP JUMPER 1608TYPE
LC18 76000445 CHIP JUMPER 1608TYPE
LC19 76000445 CHIP JUMPER 1608TYPE
LC20 76000445 CHIP JUMPER 1608TYPE
R101 76011330 CHIP 1/20W 33 OHM J
R102 76011682 CHIP 1/20W 6.8K OHM J
R103 76011272 CHIP 1/20W 2.7K OHM J
R104 76011330 CHIP 1/20W 33 OHM J
R105 76011751 CHIP 1/20W 750 OHM J
R106 76011330 CHIP 1/20W 33 OHM J
R107 76366390 CARBON FILM 1/6W 39 OHM J
R108 76011821 CHIP 1/20W 820 OHM J
R109 76011102 CHIP 1/20W 1K OHM J
R110 76366103 CARBON FILM 1/6W 10K OHM J
R111 76011302 CHIP 1/20W 3K OHM J
R112 76011103 CHIP 1/20W 10K OHM J
R113 76011332 CHIP 1/20W 3.3K OHM J
R115 76011102 CHIP 1/20W 1K OHM J
R116 76011101 CHIP 1/20W 100 OHM J
R117 76366153 CARBON FILM 1/6W 15K OHM J
R118 76011101 CHIP 1/20W 100 OHM J
R119 76000445 CHIP JUMPER 1608TYPE
R121 76011471 CHIP 1/20W 470 OHM J
R122 76011391 CHIP 1/20W 390 OHM J
R124 76011123 CHIP 1/20W 12K OHM J
R125 76011563 CHIP 1/20W 56K OHM J
R126 76011681 CHIP 1/20W 680 OHM J
R152 76011331 CHIP 1/20W 330 OHM J
R156 76553153 OXIDE METAL FILM 1W 15K OHM J
R201 76011123 CHIP 1/20W 12K OHM J
R215 76366203 CARBON FILM 1/6W 20K OHM J
R216 76366103 CARBON FILM 1/6W 10K OHM J
R216 76366243 CARBON FILM 1/6W 24K OHM J
R217 76366203 CARBON FILM 1/6W 20K OHM J
R218 76366183 CARBON FILM 1/6W 18K OHM J
R219 76011224 CHIP 1/20W 220K OHM J
R228 76011103 CHIP 1/20W 10K OHM J
R303 76170001 0XIDE R 109J RS1BSJHD109
R305 76322159 OXIDE METAL FILM 1W 1.5 OHM J
R314 76011473 CHIP 1/20W 47K OHM J
R318 76011102 CHIP 1/20W 1K OHM J
R320 76011101 CHIP 1/20W 100 OHM J
R321 76011103 CHIP 1/20W 10K OHM J
R322 76182011 METAL ERX1SJS4R7P
R324 76011472 CHIP 1/20W 4.7K OHM J
R325 76011101 CHIP 1/20W 100 OHM J
R327 76182011 METAL ERX1SJS4R7P
R328 76011682 CHIP 1/20W 6.8K OHM J
R329 76011682 CHIP 1/20W 6.8K OHM J
R331 76366562 CARBON FILM 1/6W 5.6K OHM J
R336 76383221 OXIDE METAL FILM 2W 220 OHM J
R346 76000445 CHIP JUMPER 1608TYPE
R347 76011103 CHIP 1/20W 10K OHM J
R348 76011562 CHIP 1/20W 5.6K OHM J
R350 76367393 CARBON FILM 1/6W 39K OHM J
R354 76011223 CHIP 1/20W 22K OHM J
R363 76552181 OXIDE METAL FILM 1/2W 180 OHM J
R403 76382472 OXIDE METAL FILM 1W 4.7K OHM J
R409 76011123 CHIP 1/20W 12K OHM J
R412 76011472 CHIP 1/20W 4.7K OHM J
R413 76011102 CHIP 1/20W 1K OHM J
R416 76019323 OXIDE METAL FILM 5W 1.8K OHM J
R419 76011183 CHIP 1/20W 18K OHM J
R420 76011102 CHIP 1/20W 1K OHM J
R424 76011104 CHIP 1/20W 100K OHM J
R425 76011103 CHIP 1/20W 10K OHM J
R426 76011101 CHIP 1/20W 100 OHM J
R429 76552560 OXIDE METAL FILM 1/2W 56 OHM J
R431 76011101 CHIP 1/20W 100 OHM J
R435 76011562 CHIP 1/20W 5.6K OHM J
R437 76000445 CHIP JUMPER 1608TYPE
R439 76366222 CARBON FILM 1/6W 2.2K OHM J
R440 76011471 CHIP 1/20W 470 OHM J
R441 76532102 FUSIBLE 1W 1K OHM J
R448 76182049 METAL OXIDE 9.1 OHM ERX1FJ9R1H
R470 76182021 METAL R ERX1FJR75H
R471 76382121 OXIDE METAL FILM 1W 120 OHM J
R4716 76011473 CHIP 1/20W 47K OHM J
R4717 76011225 CHIP 1/20W 2.2M OHM K
R4717 76011564 CHIP 1/20W 560K OHM J
R4718 76011273 CHIP 1/20W 27K OHM J
R473 76366183 CARBON FILM 1/6W 18K OHM J
R474 76383271 OXIDE METAL FILM 2W 270 OHM J
R4760 76366183 CARBON FILM 1/6W 18K OHM J
R4770 76011102 CHIP 1/20W 1K OHM J
R479 76381301 OXIDE FILM 1/2W 300 J
R501 76011103 CHIP 1/20W 10K OHM J
R502 76011102 CHIP 1/20W 1K OHM J
R503 76011101 CHIP 1/20W 100 OHM J
R504 76011101 CHIP 1/20W 100 OHM J
R505 76011101 CHIP 1/20W 100 OHM J
R620 76011103 CHIP 1/20W 10K OHM J
R621 76366103 CARBON FILM 1/6W 10K OHM J
R660 76011223 CHIP 1/20W 22K OHM J
R662 76011222 CHIP 1/20W 2.2K OHM J
R664 76011223 CHIP 1/20W 22K OHM J
R666 76011222 CHIP 1/20W 2.2K OHM J
R671 76011103 CHIP 1/20W 10K OHM J
R672 76011103 CHIP 1/20W 10K OHM J
R673 76011103 CHIP 1/20W 10K OHM J
R674 76011103 CHIP 1/20W 10K OHM J
R675 76011104 CHIP 1/20W 100K OHM J
R686 76011229 CHIP 1/16W 2.2 OHM J
R687 76011229 CHIP 1/16W 2.2 OHM J
zR801 76017010 METAL GLAZE 1/2W PRC92M02M20J
R805 76366221 CARBON FILM 1/6W 220 OHM J
zR808 76079013
THERMISTOR PTC AC290V 18 DGC3D180M27
R810 76007737 CERAMIC COVERED 15W 2.2 OHM J
R814 76568271 CERAMIC COVERED 7W 270 OHM J
R817 76366124 CARBON FILM 1/6W 120K OHM J
R818 76366229 CARBON FILM 1/6W 2.2 OHM J
R820 76366224 CARBON FILM 1/6W 220K OHM J
R825 76366474 CARBON FILM 1/6W 470K OHM J
R826 76366564 CARBON FILM 1/6W 560K OHM J
R829 76182014 METAL R ERX1FJR22H
R830 76019459 METAL PLATE 2W 0.12 OHM J
R830Z 76019459 METAL PLATE 2W 0.12 OHM J
R831 76366152 CARBON FILM 1/6W 1.5K OHM J
R832 76366183 CARBON FILM 1/6W 18K OHM J
R833 76011223 CHIP 1/20W 22K OHM J
R834 76366222 CARBON FILM 1/6W 2.2K OHM J
R837 76011102 CHIP 1/20W 1K OHM J
R838 76366392 CARBON FILM 1/6W 3.9K OHM J
R839 76366222 CARBON FILM 1/6W 2.2K OHM J
R840 76011472 CHIP 1/20W 4.7K OHM J
R841 76011152 CHIP 1/20W 1.5K OHM J
R842 76011472 CHIP 1/20W 4.7K OHM J
R843 76000445 CHIP JUMPER 1608TYPE
R846 76011154 CHIP 1/20W 150K OHM J
R847 76000445 CHIP JUMPER 1608TYPE
R848 76011101 CHIP 1/20W 100 OHM J
R898 76321228 OXIDE METAL FILM 1/2W 0.22 OHM J
zR899 76017012 METAL GLAZE 1/2W PRC92M08M20J
R901 76376222 CARBON RES 1/2W 2R2K J

–20 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
R902 76376222 CARBON RES 1/2W 2R2K J
R903 76376222 CARBON RES 1/2W 2R2K J
R904 76376101 CARBON FILM RD50JJHBA101
R905 76376101 CARBON FILM RD50JJHBA101
R906 76376101 CARBON FILM RD50JJHBA101
R907 76383101 OXIDE METAL FILM 2W 100 OHM J
R911 76366101 CARBON FILM 1/6W 100 OHM J
R912 76366101 CARBON FILM 1/6W 100 OHM J
R913 76366101 CARBON FILM 1/6W 100 OHM J
R920 76000880 FUSIBLE 1W 5.1 OHM J
R936 76545150 FUSIBLE 1/4W 15 OHM J
R937 76366181 CARBON FILM 1/6W 180 OHM J
R938 76366563 CARBON FILM 1/6W 56K OHM J
R939 76366561 CARBON FILM 1/6W 560 OHM J
R992 76366150 CARBON FILM 1/6W 15 OHM J
RA105 76011101 CHIP 1/20W 100 OHM J
RA106 76011101 CHIP 1/20W 100 OHM J
RA108 76011332 CHIP 1/20W 3.3K OHM J
RA109 76011332 CHIP 1/20W 3.3K OHM J
RA14 76366100 CARBON FILM 1/6W 10 OHM J
RA15 76366100 CARBON FILM 1/6W 10 OHM J
RA16 76366473 CARBON FILM 1/6W 47K OHM J
RA17 76366472 CARBON FILM 1/6W 4.7K OHM J
RA18 76366473 CARBON FILM 1/6W 47K OHM J
RA19 76366100 CARBON FILM 1/6W 10 OHM J
RA20 76366100 CARBON FILM 1/6W 10 OHM J
RA21 76366472 CARBON FILM 1/6W 4.7K OHM J
RA30 76011153 CHIP 1/2OW 15K OHM J
RA31 76011101 CHIP 1/20W 100 OHM J
RA32 76366153 CARBON FILM 1/6W 15K OHM J
RA33 76011153 CHIP 1/2OW 15K OHM J
RA34 76011153 CHIP 1/2OW 15K OHM J
RA35 76011101 CHIP 1/20W 100 OHM J
RA36 76011101 CHIP 1/20W 100 OHM J
RA98 76011472 CHIP 1/20W 4.7K OHM J
RA99 76011472 CHIP 1/20W 4.7K OHM J
RB01 76366122 CARBON FILM 1/6W 1.2K OHM J
RB02 76366151 CARBON FILM 1/6W 150 OHM J
RB03 76366181 CARBON FILM 1/6W 180 OHM J
RB04 76366241 CARBON FILM 1/6W 240 OHM J
RB05 76366331 CARBON FILM 1/6W 330 OHM J
RB06 76366471 CARBON FILM 1/6W 470 OHM J
RB08 76011102 CHIP 1/20W 1K OHM J
RB09 76011332 CHIP 1/20W 3.3K OHM J
RB10 76011470 CHIP 1/20W 47 OHM J
RB11 76011103 CHIP 1/20W 10K OHM J
RB12 76011271 CHIP 1/20W 270 OHM J
RB13 76011221 CHIP 1/20W 220 OHM J
RB14 76011223 CHIP 1/20W 22K OHM J
RB15 76011102 CHIP 1/20W 1K OHM J
RB49 76366102 CARBON FILM 1/6W 1K OHM J
RC01 76000445 CHIP JUMPER 1608TYPE
RC02 76000445 CHIP JUMPER 1608TYPE
RC03 76000445 CHIP JUMPER 1608TYPE
RC04 76000445 CHIP JUMPER 1608TYPE
RC05 76000445 CHIP JUMPER 1608TYPE
RC06 76000445 CHIP JUMPER 1608TYPE
RC07 76000445 CHIP JUMPER 1608TYPE
RC08 76000445 CHIP JUMPER 1608TYPE
RS01 76011473 CHIP 1/20W 47K OHM J
RS02 76011473 CHIP 1/20W 47K OHM J
RS03 76011473 CHIP 1/20W 47K OHM J
RS04 76011473 CHIP 1/20W 47K OHM J
RS05 76011102 CHIP 1/20W 1K OHM J
RS06 76011102 CHIP 1/20W 1K OHM J
RS07 76011473 CHIP 1/20W 47K OHM J
RS08 76011473 CHIP 1/20W 47K OHM J
RS09 76011561 CHIP 1/20W 560 OHM J
RS10 76011101 CHIP 1/20W 100 OHM J
RS11 76011101 CHIP 1/20W 100 OHM J
RS12 76011222 CHIP 1/20W 2.2K OHM J
RS13 76011222 CHIP 1/20W 2.2K OHM J
RS14 76011104 CHIP 1/20W 100K OHM J
RS15 76011104 CHIP 1/20W 100K OHM J
RS16 76011103 CHIP 1/20W 10K OHM J
RS17 76011103 CHIP 1/20W 10K OHM J
RS18 76011104 CHIP 1/20W 100K OHM J
RS19 76011103 CHIP 1/20W 10K OHM J
RS20 76011103 CHIP 1/20W 10K OHM J
RS21 76011103 CHIP 1/20W 10K OHM J
RS23 76011103 CHIP 1/20W 10K OHM J
RS24 76011103 CHIP 1/20W 10K OHM J
RS25 76011103 CHIP 1/20W 10K OHM J
RS26 76011103 CHIP 1/20W 10K OHM J
RS27 76011103 CHIP 1/20W 10K OHM J
RS28 76011103 CHIP 1/20W 10K OHM J
RS29 76011103 CHIP 1/20W 10K OHM J
RS30 76011103 CHIP 1/20W 10K OHM J
RS31 76011103 CHIP 1/20W 10K OHM J
RS32 76011103 CHIP 1/20W 10K OHM J
RS33 76011101 CHIP 1/20W 100 OHM J
RS34 76011101 CHIP 1/20W 100 OHM J
RS35 76011101 CHIP 1/20W 100 OHM J
RS36 76011101 CHIP 1/20W 100 OHM J
RS61 76552271 OXIDE METAL FILM 1/2W 270 OHM J
RS62 76552271 OXIDE METAL FILM 1/2W 270 OHM J
RV03 76011750 CHIP 1/20W 75 OHM J
RV04 76000445 CHIP JUMPER 1608TYPE
RV05 76011750 CHIP 1/20W 75 OHM J
RV06 76000445 CHIP JUMPER 1608TYPE
RV07 76011750 CHIP 1/20W 75 OHM J
RV08 76000445 CHIP JUMPER 1608TYPE
RV09 76011750 CHIP 1/20W 75 OHM J
RV10 76000445 CHIP JUMPER 1608TYPE
RV11 76011750 CHIP 1/20W 75 OHM J
RV15 76366101 CARBON FILM 1/6W 100 OHM J
RV16 76011101 CHIP 1/20W 100 OHM J
RV17 76011750 CHIP 1/20W 75 OHM J
RV18 76000445 CHIP JUMPER 1608TYPE
RV19 76011101 CHIP 1/20W 100 OHM J
RV22 76011102 CHIP 1/20W 1K OHM J
COILS & TRANSFORMERS
G404 23103308 FERRITE CORE TEM2011AO 3.5X4.5
G405 23103308 FERRITE CORE TEM2011AO 3.5X4.5
G461 23103308 FERRITE CORE TEM2011AO 3.5X4.5
GL601 23103308 FERRITE CORE TEM2011AO 3.5X4.5
GL808 23289174
COIL PEAKING 10MMHK TWE5NP-100K-5
L101 23289187 COIL PEAKING 0.22MMHK COLTRF4R22AV
L102 23289043 COIL PEAKING TRF4100AU
L103 23289197
COIL PEAKING 1.2MMHK CNSS (NP)-1R2J
L104 23248461 COIL CHOKE TLN3278AC
L156 23289196
COIL PEAKING 1.0MMHK COLTRF41R0AV
L157 23289196 COIL PEAKING 1.0MMHK COLTRF41R0AV
L301 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L441 23233113 COIL HORIZ LINEARITY TLN2210AA
L461 23248410 COIL CHOKE TLN3337AD
L462 23231497
DEFLECTION YOKE 21LPD AK DY TDY-821EG
L462A 23993696 BOARD CORRECTION
L462B 23949616 CONVER COMPENSATOR TC-R (YV)
L462C 23993081
METAL SHEET CONV. CORRECTION TCRMXH01H
L462D 23948535 SHEET MAGNETIC FERRITE
L462E 23948536 SHEET MAGNETIC FERRITE
L501 23289022 COIL PEAKING TRF4100AT
L502 23289022 COIL PEAKING TRF4100AT
L503 23289022 COIL PEAKING TRF4100AT
L504 23289022 COIL PEAKING TRF4100AT
L805 23248423 COIL CHOKE TLN3481AC
L806 23248423 COIL CHOKE TLN3481AC
L811 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L815 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L882 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L883 23221142 COIL CHOKE TRF9253D
L885 23248400 COIL CHOKE TLN3299D
L886 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L888 23289174
COIL PEAKING 10MMHK TWE5NP-100K-5
L889 23289174 COIL PEAKING 10MMHK TWE5NP-100K-5
L891 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L892 23103308 FERRITE CORE TEM2011AO 3.5X4.5
L894 23103308 FERRITE CORE TEM2011AO 3.5X4.5
zL901 23200035 COIL DEGAUSSING TSB2301AH
LA01 23289049 COIL PEAKING TRF4330AU
LA03 23289022 COIL PEAKING TRF4100AT
LA04 23289022 COIL PEAKING TRF4100AT
LA05 23289022 COIL PEAKING TRF4100AT
LA101 23289022 COIL PEAKING TRF4100AT
LA110 23289022 COIL PEAKING TRF4100AT
LA117 23289022 COIL PEAKING TRF4100AT
