Total TABLI2002 User manual

1
v
BATTERY BLOWER

2
Security instructions
Warning
Read all safety warnings and all instructions. Failure to follow warnings and instructions
may result in battery discharge, fire, and/or serious injury.
Save all warnings and instructions for future reference.
Note: The term “battery tool” in the warnings refers to your battery-operated (cordless) battery
tool. Due to our ongoing R&D&I program, the specifications in this document are subject to
change without notice.
1) Work area safety
a. Keep the work area clean and well lit to prevent accidents.
b. Do not use battery tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust that can cause fires.
c. Keep children and other unauthorized persons away while using a battery
tool. Distractions can cause you to lose control of the tool.
2) Electrical safety
a. The plugs for charging the battery of the P20S tools must match the outlet.
Never modify the plug in any way. Using a suitable plug reduces the risk
of electric shock.
b. Avoid bodily contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if
your body is grounded.
c. Do not expose battery tools to rain or wet conditions. Water entering a
battery tool will increase the risk of electric shock.
d. Never use the cable to carry, pull or unplug the battery charger. Keep the
cable away from heat or oil.
e. If using the tool in a wet location is unavoidable, use a Residual Current
Device (RCD) protected supply to reduce the risk of electric shock when
charging the battery.
3) Personal security
a. Always stay alert, watch what you are doing and use common sense
when using the tool.
b. Do not use a battery tool if you are tired or under the influence of
medication or other substances.
c. Wear personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-slip safety shoes, hard
hat, or hearing protection used in the proper conditions will reduce
personal injury. Also don't wear loose clothing or jewelry.
d. Prevent the tool from turning on unintentionally. Make sure the switch is
in the off position before connecting to battery or moving.
e. If devices are used for dust extraction and collection, make sure they are
properly connected. Properly use these devices and you will reduce dust-
related hazards.
f. Don't overdo it. Maintain posture and balance at all times. This allows for
better control of the power tool in unexpected situations.

3
4) Use and care of battery tools
a. Do not force the tool. Use the right battery tool for each use.
b. Do not use the battery tool if its power switch does not work. Any battery
tool that cannot be controlled with the switch is dangerous and must be
repaired.
c. Disconnect the battery before making any adjustments, changing
accessories, or storing the tool to avoid accidental starting.
d. Use the battery tool, accessories and bits etc. in accordance with these
instructions, taking into account the working conditions and the work to
be carried out. Using the battery tool for operations other than its intended
purpose could result in a dangerous situation.
e. Store battery tools out of the reach of children and do not allow people
unfamiliar with the tool to use it.
f. Carry out regular maintenance on battery tools. Check for misalignment
or binding of moving parts, breakage of parts, and any other condition that
may affect the operation of battery tools. If it is damaged, have the battery
tool repaired before using it. Many accidents are caused by poorly
maintained battery tools.
g. Keep accessories clean and sharp, as with proper maintenance they are
less likely to bind and are easier to control.
5) Service
a. Have your battery tool serviced by a qualified person and use
replacement parts recommended by the manufacturer. This will ensure
the safety of the battery tool is maintained.

4
Safety rules for correct use
Read the instruction manual.
Wear eye protection
Wear ear protection
Keep bystanders away
The distance between the machine and bystanders must be at
least 5m.
Power off and remove battery before adjusting and
cleaning
Waste electrical products must not be disposed of with household waste.
Please recycle at the appropriate facilities. Check with your local authority or
retailer for recycling advice.
This product should be disposed of at an appropriate recycling facility.
failsafe transformer
Use and store the battery charger indoors only.
Do not use it in the rain or leave it outdoors while it is raining.

5
Additional security warnings
Do not allow people with a lack of experience and knowledge to use tools, unless they
have been supervised or instructed on the use of the appliance by a person responsible
for their safety. Children must not use the tool.
Before using
•Please read the instructions carefully. Become familiar with the controls and the
proper use of the blower.
•Never allow people unfamiliar with these instructions to use the appliance.
•Never use the tool if there are people in the work area, especially children or pets.
•The user is responsible for accidents or dangers that other people or their
property may suffer while using the tool.
Preparation
•Get hearing protection and safety glasses. Wear them at all times while using the
machine.
•While using the blower, always wear sturdy shoes and long pants. Do not use the
equipment barefoot or with open sandals.
•Do not wear loose clothing or jewelry that may enter the air intake. Keep long hair
away from air intakes.
•To avoid irritation from inhalation of dust, the use of a mask is recommended.
•Never use the tool without guards or with defective guards.
•Before using the tool, always visually inspect to see that grinding media, bolts,
and other items are secure, housing is not damaged, and guards and screens
are in place. Replace worn or damaged components in sets to preserve balance.
Replace damaged or unreadable labels.
Start up
•Keep your face and body away from the blower inlet opening.
•Do not allow hands or any other body part, including clothing, to enter the feed
chamber, discharge chute, or near any moving parts.
•Keep your balance and your feet in a firm position at all times. Never stand higher
than the base of the machine when feeding material into the machine.
•Always stay clear of the discharge area when operating this machine.
•When feeding material into the machine, be very careful that no metal pieces,
stones, bottles, cans, or other similar objects are included.
•If the cutting mechanism hits any foreign object or if the machine starts to make
unusual noises or vibrations, turn off the power immediately and allow the
machine to stop. Disconnect the machine from the supply and follow the steps
below before restarting and operating the machine:
oInspect damage.
oReplace or repair any damaged part.
oCheck and tighten loose parts.
•Do not allow processed material to accumulate in the discharge area; this may
prevent proper discharge and may cause material to back up through the inlet
opening.
•If the machine becomes clogged, turn off the power supply and disconnect the
machine from the supply before cleaning the debris.

6
Other warnings and risks
•Keep the power supply clear of debris and other buildup to prevent damage to
the power supply or possible fire.
•Do not carry this machine while the power supply is on.
•Stop the machine and remove the plug from the socket. Make sure all moving
parts have come to a complete stop:
oAs long as it comes out of the machine.
oBefore clearing obstructions or unclogging the duct.
oBefore checking, cleaning or working on the machine
•Do not leave the machine while the power supply is working.
•Recharge only with the charger specified by Total. Do not use any charger other
than the one provided specifically for use with the equipment. Otherwise, you
may create a fire hazard.
•Keep the battery pack out of the reach of children.
•Please retain the original product documentation for future reference.
•Remove the battery from the equipment when not in use.
Maintenance and storage
•When the machine is stopped for maintenance, inspection, or storage, or to
change an accessory, turn off the power supply, disconnect the machine from the
supply, and make sure all moving parts come to a complete stop.
•Let the machine cool down before making any inspections, adjustments, or even
putting it away.
•Please use the machine carefully and keep it clean.
•Store the machine in a dry place out of reach of children.
•When servicing the shredding media, be aware that even if the power supply is
off due to the guard lock function, the shredding media may move.
•Replace worn or damaged parts for safety. Use only original spare parts and
accessories.
•Never attempt to defeat the protector's interlock function.
Attention
Safe operation of this machine is only possible when the operating or safety
information is fully read and the instructions contained therein are strictly
followed.

7
Technical data
Technical sheet of the battery-powered blower
Voltage
20V
No load speed
15000rpm
Blow speed
38m/s
Air capacity
8.5m³/min
Note: Voltage measured without work load. The initial battery voltage reaches a maximum of 20
volts. The nominal voltage is 18 volts.
Accessories
Battery
2Ah (ref. TFBLI2001E) or 4Ah (ref. TFBLI2002)
Charger
Fast charge (ref. TFCLI2001E)
Note: Accessories are not included with the P20S battery blower. We recommend that you
purchase your accessories from the same store that sold you the tool. See accessory packaging
for details. The store staff can help you and offer advice.
Noise and vibration information
Sound power level, measured according to ISO22868, dB (A):
84.3
Sound pressure level, measured according to EN50636-2-100, dB
(A):
76.6
Vibration levels at the handles, measured according to ISO 22867:
1.0m/s2
Caution
The vibration emission value during actual use of the power tool may differ from the
declared value depending on the ways the tool is used, according to the following
examples and other variations:
•How the tool is used.
•The tool is in good condition and well maintained.
•Use the correct accessory for the tool and make sure it is in good condition.
•The strength of the grip on the handles and any vibration on the accessories are
used.
•The tool is being used as intended by its design and these instructions.
•This tool can cause hand-arm vibration syndrome if its use is not managed
properly.

8
Product description
1. Blower tube
2. Trigger switch
3. Control handle
4. Battery (not included)
Note: Safe use of this product requires an understanding of the product information in this user
manual, as well as knowledge of the project you are performing. Before using this product,
familiarize yourself with all operating features and safety regulations.
Note 2: Not all accessories illustrated or described in this manual need to be included in the
standard delivery.
Start up
Blower Tube Assembly
Always remove the battery pack before assembling the fan tube.
•Align the grip and the groove.
•Push the blower tube into the housing.
•Rotate the blower tube counterclockwise.
Case
grip
Groove

9
Start up
Remove and install the battery
•Press the battery release button to release the battery from your tool.
•After recharging, insert the battery into the battery port of the tool. A simple push
and light pressure will suffice.
Turning the blower on and off
Switched on
•Hold the blower with one hand on the control handle.
•Wrap your thumb around the handle/handle.
•Squeeze the trigger with your index finger and hold it there. You will notice the
blower speed up and air coming out of the nozzle.
Off
•Variable speed trigger release
•Check that no air flows from the nozzle.
Using the blower
Hold and control the blower
•Hold and control the blower with one hand on the control handle or handle.
•Wrap your thumb around the handle.
•Point the nozzle at the ground, walk slowly and steadily forward.
execute
button
Battery

10
Maintenance and cleaning
Maintenance
To avoid the risk of fire, electric shock, or electrocution:
•Do not use a damp cloth or detergent on the battery or battery charger.
•Always remove the battery pack before cleaning, inspecting or performing any
maintenance.
Cleaning
•Clean the outside of the blower with a soft, dry cloth. Do not wash with water.
•Brush or blow dust, debris, and grass clippings out of vents. Keep them free from
obstructions
Batteries
•Keep the battery fully charged.
•Do not store battery in tool or charger.
•After charging, the battery can be stored in the charger, as long as the charger is
not plugged in.
Charger maintenance
•Keep the charger clean and free of debris.
•Do not allow foreign material to enter the cavity or the contacts.
•Clean the charger with a dry cloth. Do not use solvents or water, and do not place
the charger in wet conditions.
•Please unplug the charger when you have no battery.
•Fully charge the batteries before storing them.
•Store the charger at normal room temperature. Do not store in excessive heat.
•Do not use the charger in direct sunlight. Recharge at room temperature between
41˚F and 104˚F (5˚C and 40˚C). If the battery is hot, let it cool down before
recharging.
Problem solving
From battery charger during charging
LED indicator
possible
mistake
Possible solution
flashing red LED temperature
drift
Use the battery charger only when the
ambient temperature is between 5°C and
44°C
red LED on
Contact your service agent
From the blower during operation
Problem
possible mistake
Possible solution
Blower run time is too short
The battery is not fully
charged
Fully charge the battery
Note: If you still cannot get your tool to work, please contact your service agent.

11
Environment
•Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
•Contact your local authority for information on available collection systems.
•If electrical appliances are disposed of in landfills, hazardous substances can
seep into the groundwater and enter the food chain, harming your health and
well-being.
•Recycle raw materials instead of disposing of them as waste.
•The machine, accessories and packaging must be sorted for environmentally
friendly recycling.
•Plastic components are labeled for categorized recycling.
Exploded view

12
BATTERY BLOWER
