OWNER'S MANUAL
INTELLIMIST
HUMIDIFIER
P/N P110-300
Replacement Components Division Carrier Corporation 3/01
INTELLIMIST MicroFine Spray
MICROPULSE Technology
Assures Maximum Efficiency
Scale Reducing Filter Included
Up to 24 Gallons Per Day of
Additional Humidity
For Use With 1 - 7 Ton HVAC
Systems
Designed For Use Only With:
P110-0009 Humidistat
P474-3000 Humidistat
P374-1600 INTELLISTAT
TOTALINE
USE ONLY WITH CENTRAL AIR CONDITIONING SYSTEMS.
THE HUMIDIFIER MUST BE MOUNTED OVER THE
EVAPORATOR COIL OR EVAPORATOR COIL DRAIN PAN.
IF THERE IS NOT A DRAIN PAN, ONE MUST BE INSTALLED.
PATENTS PENDING
TM
TOTALINE
Humidifier
IntelliMist
4Z95
MODEL P11 0-300
R
C
H1
H2
TM
24vac 7.5w
Intellimist
On
For
Residential
Use Only

INTELLIMIST HUMIDIFIER
TABLE OF CONTENTS
CONTENTS & ACCESSORIES.....................2
MOUNTING LOCATIONS..............................3
ASSEMBLY & INSTALLATION.......................4
WATER HARDNESS......................................6
WATER FILTER..............................................7
WIRING DIAGRAMS......................................8
TROUBLE SHOOTING GUIDE.....................11
OUTPUT CHECK..........................................16
Page 1

Page 2
CAUTION
Follow Installation Instructions for Humidifier carefully.
UNIT MUST NOT BE INSTALLED WHERE FREEZING TEMPERATURES
MAY OCCUR. DO NOT INSTALL ON FURNACE JACKET, OR WHERE
UNIT AND ITS COMPONENTS MAY COME INTO CONTACT WITH HOT SURFACES.
PACKAGE CONTENTS
P110-300 INTELLIMIST Humidifier Assy.
#0862 Tube Assy.
#0759 INTELLIMIST In-Line Water Filter
#0800 Water Filter Mounting Bracket
#0152 Mounting Kit
AVAILABLE INTELLIMIST ACCESSORIES
P110-0009 Humidistat
P474-3000 Humidistat
P374-1600 INTELLISTAT
(Combination Thermostat / Humidistat)
P110-0008 Replacement Filter / Nozzle
INTELLIMIST HUMIDIFIER
This Humidifier MUST be used with Totaline
P110-0009, P474-3000 Humidistats or P374-1600 INTELLISTAT.
USE ONLY WITH CENTRAL AIR CONDITIONING SYSTEMS.
THE HUMIDIFIER MUST BE MOUNTED OVER THE
EVAPORATOR COIL OR EVAPORATOR COIL DRAIN PAN.
IF THERE IS NOT A DRAIN PAN, ONE MUST BE INSTALLED.

Page 3
11SELECT MOUNTING LOCATION
1. The humidifier should be installed on the supply plenum,
preferably near the coil. Mounting near the evaporative
coil, if applicable, will allow any excess moisture to exit
the system via the condensation drain pan.
2. On vertical equipment allow clearance of the humidifier
and related components such as the water filter and
plastic water live, from the exhaust vent.
3. On vertical equipment, if the nozzle is spraying away
from the coil, there should be a minimum of three feet
from the nozzle to the top of the plenum. If this is not
available, then point the nozzle of the humidifier
directly into the evaporative coil.
4. Always install downstream of an electronic air cleaner.
Drill or ‘knock out’ a 1” hole & 4 mounting holes for the
#6 screws on the mounting template.
INTELLIMIST HUMIDIFIER
AIR FLOW
HUMIDIFIER
DRAIN
PAN
EVAPORATOR
COIL
PLENUM
FURNACE
HORIZONTAL
EQUIPMENT
HUMIDIFIER
ALTERNATE
LOCATION
ALTERNATE
LOCATION
FURNACE
EVAPORATOR
N-COIL
PLENUM PLENUM
EVAPORATOR
A-COIL
FURNACE
DRAIN PANS
HUMIDIFIER
VERTICAL VERTICAL

Page 4
INTELLIMIST HUMIDIFIER
MOUNTING NUT
TUBE ASSY
22ASSEMBLE THE HUMIDIFIER
Slide the mounting nut over the tube
(fig. 1)
assembly.
Insert the tube assembly into the humidifier
valve. Secure by turning the nut clockwise
until finger tight, then additional 1/4 turn.
(fig. 2)
Fig. 1
Fig. 2
33INSTALL THE HUMIDIFIER
Be sure to use a cold water
connection.
Mount the humidifier to the sheet
metal using the four #6 mounting
screws supplied. (Page 3)
The in-line water filter should be
mounted below or to one side of
the humidifier assembly in a vertical
position as shown. (Fig. 3)
Be sure the flow arrow on the filter is
pointing to the humidifier.
Fig. 3
RR
CC
H1H1
H2H2
INTELLIMIST
ON
INTELLIMIST
HUMIDIFIER
MODEL: P110-300
24 VAC 7.5 WATTS
UULL
CUS
LISTED
4Z95
TOTALINE

Page 5
44WATER CONNECTION
Run 1/4” tubing from the water supply to the
in-line filter. The saddle valve and tubing
is supplied for this purpose.
SADDLE VALVE INSTALL
The self piercing
is for copper pipe
of pipe, drill a 1/8” hole in the pipe. Turn the
handle clockwise to expose the piercing pin
beyond the seal approximately 3/16”. Place
the body of the valve over the hole in the
pipe so the pin fits in the hole. Tighten the
bottom clamp evenly. Turn handle clockwise
and close the valve.
feature of the saddle valve
only. All other materials
INTELLIMIST HUMIDIFIER
CAUTION
SAFETY NOTE
USE COPPER TUBING WHERE INSTALLATIONS
MAY CAUSE DAMAGE IF A WATER LEAK OCCURS.

Page 6
INTELLIMIST HUMIDIFIER
WATER HARDNESS
If water hardness is 15 grains/gal or under the filter & nozzle
(P/N P110-0008) should be replaced once a year.
If the water hardness is higher than 15, the filter & nozzle
should be replaced every 3 months during the heating season.
If the humidifier is run with the fan in the non-heating season,
then the filter/nozzle should be replaced every 6 months.
Water hardness test kits are available at local home
improvement centers.
Rotary PinOrifice
Nozzle
Water
Filter

INTELLIMIST HUMIDIFIER
WATER FILTER
Page 7
The water filter should be mounted using the supplied
bracket. (Figure 4)
Up to 3 gallons of water should be run through the filter
from the supply
before connection to the humidifier. This may be
done using a short piece of tubing on the output of the filter.
Connect to the humidifier and check for leaks.
until the water appears clear, not gray or
cloudy,
Fig. 4
SUPPLIED
BRACKET
The water filter supplied with the humdifier is specifically
formulated for optimal operation. The filter design inhibits
bacteria, odor, and calcium buildup. The filter should only be
replaced with Totaline part # P110-0008.
In the rare instance white powder is noticed on the interior of
the house, this is an indication the filter needs to be replaced.
Polyphosphate
Clear, Plastic Case
KDF Activated Charcoal
4) 5 Micron Filter Screens

55
Page 8
WIRING DIAGRAMS
When R & C are used from a nearby thermostat:
If only 1 wire is available from the furnace to the humidistat, W1
may be obtained from the thermostat.
R
R
R24vac
24vac
C
W1
W1
C
R
C
C
C
C
Humidistat
P110-0009
P110-0009
Humidistat
Thermostat
Furnace
Furnace
Humidifier
Humidifier
HUM
HUM
H1
H1
H1
H1
H2
H2
INTELLIMIST HUMIDIFIER

55
Page 9
WIRING DIAGRAMS
When connected to the IntelliStat (P374-1600):
R
W1
R
R
C
C
C
Humidistat
Furnace
Humidifier
HUM
H1
H1
H2
The C & R terminals on the
IntelliMist Humidifier are
not connected internally.
They are provided for an
easy ‘tie-off point’ when
using 1 multi-conductor
cable from the Humidifier
to the humidistat. In this
case H2 would need a
jumper to C.
Y2 HUM Y1
W2
W1/O/B
G C R
Furnace
Humidifier
R
W1/O/B
Y1
Y2
W2
C
G
Intellistat
W3
H1 H2 CR
P110-0009
P374-1600
INTELLIMIST HUMIDIFIER
24vac
24vac

66
Page 10
START UP
Open all supply water valves to permit water flow
to the humidifier.
Check for leaks.
Set humidistat to highest demand, 99%.
When the humidifier mist is on, the Red LED indicator,
on the top of the housing, will be on.
When connected to the INTELLIMIST control, the Red
LED will be observed to go on and off with the
MICROPULSE technology control.
Reset the humidistat to the recommended setting,
~35%.
INTELLIMIST HUMIDIFIER
55WIRING DIAGRAMS
R
Y1
G
R
G
Y1
W1
C
C
W1
Humidistat
P110-0009
Thermostat
Furnace
Humidifier
R
C
HUM
H1
H1
H2
ADD
A
Wire
ADD
A
Wire
Part A
Part B
When only 5 wires are available to the thermostat and
a P474-0410 Add-A-Wire may be used as shown.humidistat,
24vac

INTELLIMIST HUMIDIFIER
IntelliMist Humidifier
Troubleshooting Guide
1. Humidity Reading Will Not Increase
When humidity levels are in the teens it may take several
weeks to notice an increase in humidity in your home.
This is due to the fact that virtually all of the moisture has
evaporated from the wood, drywall, carpets, draperies, and
furniture. Until this moisture is replaced, materials will
absorb moisture from the air, causing very little humidity
rise in the rooms.
2. In-line Fitler Installation
When installing the in-line water filter, it is important that
enough water be flushed through the filter. Up to three
gallons of water (or until the water flow is clear) should be
run through the filter to prevent micro fine particles form
clogging the sprayer nozzle.
3. Humidifier Water Connections
The plastic fittings supplied with the humidifier should be
finger tightened, plus 1/4 turn with pliers. Over tightening
with pliers or a wrench will cause the fittings to crack and
split, thus leaking water. The plastic fittings are OK to use
on copper pipe. The brass compression fittings should be
tightened with a wrench, and then re-checked for leaks.
The brass nut should slide on the tube first, followed by the
compression sleeve, and the brass tube end inserted last.
Then the tube should be inserted into the humdifier
valve base and tightened with pliers or a wrench.
Page 11

INTELLIMIST HUMIDIFIER
Page 12
4. Too much moisture in the duct
The IntelliMist Humidifier must be used with either the
Totaline Humidistat (P110-0009) or Intellistat (P374-1600).
Any other controller will cause a continuous (non-pulsed)
spray. Check setup step 1 (Humidistat) or step 9 (Intellistat)
to make sure pulse is turned on - if pulse is set to off,
the humidifier sprays constantly, producing too much water.
Maker sure the controller is set to the correct tonnage to
match the air handler, setup step 3 (Humidistat) or step 10
(Intellistat). Humidistat: make sure HUM wire from
humidistat is connected to the W or W1 terminal on the
furnace, but NOT to the G or fan terminal. Interlocking the
humidistat with the fan will cause the humidifier to run
during fan-only or cooling, which will result in excess
water in the duct. To run the humidifier in fan-only, use the
Intellistat. For more information, see Factors that Affect
Humidity Control.
5. Can’t raise humidity enough
Make sure the controller is set to the correct tonnage to
match the air handler, setup step 3 (humidistat) or step 10
(Intellistat). With the Intellistat it is possible to bring on the
fan and humidifier any time the humidity is below the
setpoint. To enable this feature turn on setup step 11, which
will help to increase humidity in the space. Humidity can
also be increased by running the fan continuously (Fan On
button) or by using the programmable fan feature of the
Intellistat to bring the fan on at selected intervals. Check
the position of humidifier spray nozzle to make sure good
evaporation is occurring - on short plenums if the spray is
hitting the end of the plenum, it is better to turn the spray
toward the coil.

INTELLIMIST HUMIDIFIER
Page 13
6. Humidifer won’t spray
Check the red LED on humidifier, which must be viewed
straight on. When the light is on the humidifier is attempting to
to spray. If there is no spray, check the nozzle for blockage
- if blocked remove and rinse or replace the nozzle. If the
light never comes on, the humidifier is not receiving a signal
to spray, or has no power. Check the controller to make
sure there is a humidity demand - on the humdistat three
raindrops will appear when it is calling for the humidifier to
spray, on the intellistat a small vertical bar will appear in the
lower left corner of the screen. If the symbol appears, check
the wiring or, if using the humidistat, see below.
7. Raindrops appear on the humidistat but the
humidifier won’t spray.
There may a compatibility problem with the furnace.
Add a pilot relay with the coil connected to W and C
on the furnace and the contacts to HUM and R on the
humidistat. This will isolate the humidistat from the 24
VAC and solve the problem. Humidistats manufactured
after 5/00 have built in isolation.
8. What are the R and C terminals for on the Humidifier?
These terminals are merely tie-off points provided for
convenience. It is not necessary to connect them to
anything.

INTELLIMIST HUMIDIFIER
Page 14
9. Increasing Humidity in the Home: Factors that
Affect Humidity
For homes that are in very dry climates with humidity
levels in the teens, it may take several days or up to a week
to notice increases in humidity in the spaces. This is due to
the fact that virtually all the moisture has evaporated from
the wood, drywall, carpets, draperies, and furniture. Until
this moisture is replaced materials will absorb moisture
from the air, causing little or very little relative humidity
rise in the rooms. As with any whole-house humidifier, the
Humidifier can only increase the moisture in the house
when the fan is running Therefore, in climates where little
heating is required and the heating/fan system is therefore
run very few hours per day, the fan must be run in the non-
heating modes to increase the humidity in the rooms.
This can be accomplished in one of three ways.
1. The Intellistat in setup step 11 can be set to ON, then the
Intellistat will run the fan and humidifier any time the
humidity is below the setpoint.
2. The fan in setup step 13 through 15 of the Intellistat can
be programmed to run so many minutes per hour during
certain hours of the day. The Humidifier will run any time
the fan runs and the humidity is below the setpoint.
3. The fan can be run continuously with the fan ON button.
The Humidifier will then run constantly on a call for
humidity with the Intellistat.

INTELLIMIST HUMIDIFIER
Page 15
10. Factors That Affect Humidity: Additional Notes
Even though the IntelliMist Humidifier puts out more
humidity than any other whole-house humidifier, up to 24
gallons per day, it may not be possible to increase the
humidity to a high level especially if the outside humidity
is fairly low. For instance, with an outdoor air temperature
of 40 degrees and 20% relative humidity, when the air is
heated up to 72 degrees, the resulting humidity in the house
is 8%. The amount of humidity that can be added to the air
is limited by the airflow in the ductwork and the temperature
of the air. Hot air, which you have when the furnace is
running, can hold 6 time as much moisture as the air can
hold when only the fan is running. It is much easier to
increase the humidity in the house with the furnace running
versus when only the fan is running. Both applications are
limited by the amount of moisture that can be put into the air
going through the ductwork without the moisture actually
condensing in the ductwork.

INTELLIMIST HUMIDIFIER
OUTPUT CHECK
To check that all the terminals are in proper working
order at the factory Carrier has created a test screen
located in the calibration mode of the Humidistat.
1. Push the 'on/off' button and the 'down' arrow until
all icons on the LCD screen are visible.
2. Now push the 'on/off' button once more.
3. The screen you are currently seeing is our test mode to
ensure proper wiring between the Humidistat and the
Humidifier. Push the 'flow' button to energize the
Intellimist Humidifier. Water droplets on the bottom left
hand corner of the screen will appear and the red LED
will energize. Push the 'flow' button once more to
deenergize the Intellimist Humidifier.
4. The screen you are now seeing is our test mode to ensure
proper wiring between the Humidistat and the Furnace
board, if your furnace is currently energized the
Humidistat will display an H in the upper right hand
corner of your screen. If the furnace is not energized a
dash will appear in the upper right hand corner of your
screen.
5. Push the 'on/off' button to exit the test screen and enter
into the normal operating screen.
Page 16

Page 17 P/N 88-231
Warranty
One-Year Warranty - This CARRIER CORPORATION (herein referred to as “COMPANY”)
product is warranted to be free from defects in material and workmanship. If it appears within
one year from the date of original installation, whether or not actual use begins on that date,
that the product does not meet this warranty a new or remanufactured part at the
COMPANY’S sole option, to replace any defective part will be provided without charge for the
part itself; PROVIDED the defective part is returned to our distribution through a qualified
servicing dealer.
THIS WARRANTY DOES NOT INCLUDE LABOR OR OTHER COSTS incurred for
diagnosing, repairing, removing, installing, shipping, servicing or handling of either defective
parts or replacement parts. Such costs may be covered by a separate warranty provided by
the installer.
THIS WARRANTY APPLIES ONLY TO PRODUCTS IN THEIR ORIGINAL INSTALLATION
LOCATION AND BECOMES VOID UPON REINSTALLATION.
LIMITATIONS OF WARRANTIES – ALL IMPLIED WARRANTIES INCLUDING IMPLIED
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY)
ARE HEREBY LIMITED IN DURATION TO THE PERIOD FOR WHICH THE LIMITED
WARRANTY IS GIVEN. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, SO THE ABOVE MAY NOT APPLY TO YOU. THE
EXPRESSED WARRANTIES MADE IN THIS WARRANTY ARE EXCLUSIVE AND MAY NOT
BE ALTERED, ENLARGED, OR CHANGED BY ANY DISTRIBUTOR, DEALER, OR OTHER
PERSON WHATSOEVER.
ALL WORK UNDER THE TERMS OF THIS WARRANTY SHALL BE PERFORMED DURING
NORMAL WORKING HOURS. ALL REPLACEMENT PARTS, WHETHER NEW OR
REMANUFACTURED, ASSUME AS THEIR WARRANTY PERIOD ONLY THE REMAINING
TIME PERIOD OF THIS WARRANTY.
THE COMPANY WILL NOT BE RESPONSIBLE FOR:
1. Normal maintenance as outlined in the installation and servicing instructions or owners
manual including filter cleaning and/or replacement and lubrication.
2. Damage or repairs required as a consequence of faulty installation, misapplication, abuse,
improper servicing, unauthorized alteration or improper operation.
3. Failure to start due to voltage conditions, blown fuses, open circuit breakers or other
damages due to the inadequacy or interruption of electrical service.
4. Damage as a result of floods, winds, fires, lighting, accidents, corrosive environments or
other condition beyond the control of the Manufacturer.
5. Parts not supplied or designated by the Manufacturer, or damages resulting form their use.
6. Manufacturer products installed outside the continental U. S. A., Alaska, Hawaii, and
Canada.
7. Electricity or fuel costs or increases in electricity or fuel costs from any reason whatsoever
including additional or unusual use of supplemental electric heat.
8. ANY SPECIAL INDIRECT OR CONSEQUENTIAL PROPERTY OR COMMERCIAL
DAMAGE OF ANY NATURE WHATSOEVER. Some states do not allow the exclusion of
incidental or consequential damages, so the above limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which may
vary from state to state.
