Crane EE-5200B,EE-520B User manual

Warm Mist Humidifiers
1 GALLON / 4 LITER
WARM MIST HUMIDIFIER
FOR THE FOLLOWING MODELS:
EE-5200W
EE-5200B
PLEASE READ AND SA E ALL INSTRUCTIONS TO ENSURE
THE SAFE AND EFFCTI E USE OF THIS APPLIANCE.
If you have any questions about the operation of
your ultrasonic humidifier, please contact Crane
Customer Care.
Toll Free: 888-599-0992
Email: [email protected]

1
TABLE OF CONTEN
TS
Table of Contents, Humidifier Models . 1
Safety Instructions . 2-3
List of Main arts, Technical Specifications . 4
Operation and Use . 5-7
Maintenance . 7
Trouble Shooting . 8
Customer Care . 9
Warranty . 10
HUMI
DIFIER MODELS
This instruction manual applies to the following models of the Warm Mist Humidifiers
product line:
Color Model #
White EE-5200W
Black EE-5200B
For information about all CRANE Humidifiers,
Please visit http://www.crane-usa.com.

2
IMPORTANT SAFETY INSTRUCTIONS
WARNING! READ AND SA E THESE INSTRUCTIONS. Failure to follow all the
instructions listed below may result in electric shock, fire and/or serious personal injury.
1. DO NOT carry Water Tank by handle when it is filled with water. It is advisable to
carry filled Water Tank with two hands.
2. DO NOT operate outdoors. This humidifier is intended for indoor use only.
3. DO NOT TOUCH STEAM MIST. Steam can cause burns.
4. DO NOT remove the water tank during operation, or within 15 minutes after the
humidifier is turned off and unplugged. Serious injury may result.
5. DO NOT operate without water. Always have water in the water tank when
operating the unit.
6. Use only clean, cool tap water to fill the tank. DO NOT use hot water.
7. DO NOT pour water into any openings other than the water tank.
8. Do not cover any openings on the unit, or insert objects into any openings.
9. Be sure that the water tank cap is firmly tightened. DO NOT aim mist directly at
children, walls, furniture or electrical appliances.
10. Use only a 110-120VAC outlet. ALWAYS plug and unplug unit with dry hands
to avoid electric shock.
11. Never operate the unit with a damaged cord or plug.
12. Always place the unit on a smooth, flat, lint-free, non-metallic, waterproof and
level surface and position unit away from direct sunlight. Keep the cord away from
heated surfaces and areas where it could be walked on or tripped over. Unplug the
unit when not in use and whenever you clean or move the unit.
13. Do NOT add medication of any type into the Water Basin or Water Tank. Do not
cover any openings on the unit or insert objects into any openings. ONLY add
liquid vapor medicine to the medicine cup include with this humidifier.
14. The unit should not be left unattended in a closed room, as the air could become
saturated and leave condensation on walls or furniture. Leave room door partly
open.
15. The humidifier requires daily and weekly cleaning to operate appropriately. Refer
to cleaning instructions.
16. NEVER use detergents, gasoline, glass cleaner, furniture polish, paint thinner or
other household solvents to clean any part of the humidifier.
17. Do not tilt, tip or attempt to empty or fill the unit while it is in operation.
SA E THESE INSTRUCTIONS!

3
GENERAL SAFETY INSTRUCTIONS
WARNING! Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire or serious personal injury. The warnings,
cautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the user that
common sense and caution are a factor which cannot be built into this product, but must
be supplied by the user.
THIS HUMIDIFIER IS NOT A TOY!
Do not let your child play with this humidifier. Serious injury and
electrocution might be possible. This humidifier has to be operated by an adult only.
Children should be supervised to ensure that they do not play with the humidifier.
SA E ALL INSTRUCTIONS!
CAUTION: A short ower Supply Cord is provided to reduce the risk of personal
injury resulting from becoming entangled in or tripping over a longer cord. Extension
cords are available from local hardware stores and may be used if care is exercised in
their use. If an extension cord is required, special care and caution is necessary. Also
the extension cord must be (1) marked with an electrical rating of 125 V and at least 13
A., 1625 W., and (2) the cord must be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or accidently tripped over.
ELECTRIC POWER
If the electric circuit is overloaded by other appliances, your humidifier and/or
appliances may not operate properly. The humidifier should be operated on a separate
electrical circuit from other operating appliances.
POLARIZED PLUG
This humidifier has a polarized plug (one blade is wider than the
other). As a safety feature to reduce the risk of electrical shock, this
plug is intended to fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety
feature.
SAFETY WARNING
Although your humidifier is easy to operate, for your safety, the below warnings must be
followed:
1. Do not place the humidifier near a heat source.
2. Never leave the humidifier unattended while connected to the electrical outlet.
3. To avoid any accidents, never cover the Mist Lid when the humidifier is in operation.
4. Use the humidifier on a smooth, flat, lint-free, non-metallic, waterproof, and level
surface away from water.
5. Do not unplug from the wall socket by pulling on the supply cord.
6. The humidifier must be unplugged:
A. Before either filling or emptying the Water Basin and/or Water Tank.
B. Before any cleaning or maintenance is performed.
C. After each use.
D. If it appears to be faulty.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.

4
LIST OF MAIN PARTS
1. Medicine Cup
2. Mist Channel
3. Water Basin
4. Heating
Element
5. Control Knob
6. Reset Button
7. Mist Chamber
Latch
8. Tip Over
Switch
9. Mist Chamber
10. Water Tank
Cap
11. Water Tank
12. Water Tank
Handle
Fig. 1
TECHNICAL SPECIFICATIONS:
Rating Voltage 120V
Frequency 60Hz
ower 400W
Water Tank Capacity Approx. 1.1 Gallon / 4.2 Liter
Output er 24 Hours Approx. 3.6 Gallon / 13.7 Liter
Run Time er Tank Min. 7 Hours
Humidifying Capacity Up to 250 sq.ft. / 23 m²

5
OPERATION AND USE
BEFORE EACH USE
CHECK HUMIDIFIER PLACEMENT
lace the Humidifier on an elevated, non-metallic, lint-free, waterproof, level surface at
least 2 feet above the floor.
•DO NOT place the humidifier on carpet or a towel. The fan vent is located on the
bottom of the humidifier base. The fan vent MUST NOT be obstructed.
•DO NOT place the humidifier on a wood surface or near furniture that can be
damaged by too much moisture.
CHECK WATER LE EL SENSOR
Make sure that the Water Level Sensor is secured properly and not obstructed.
CAUTION
DO NOT operate the humidifier without water in the Water Tank.
DO NOT plug or unplug the Power Cord with wet hands as electric
shock could occur.
ASSEMBLY
CAUTION: DO NOT TOUCH STEAM MIST WHEN HUMIDIFIER IS ON. STEAM
MAY CAUSE BURNS. ALWAYS USE CAUTION!
1. Turn Water Tank upside down and unscrew Water
Tank Cap.
2. Fill Water Tank with cool water. DO NOT fill water all
the way to the rim.
DO NOT CARRY FULL WATER TANK BY HANDLE.
ALWAYS HOLD WATER TANK WITH TWO HANDS.
DO NOT use hot water. Use cool tap water.
DO NOT add any medication, essential oils, or salt to
water. USE ONLY included medicine cup for liquid vapors.
DO NOT pour water into Mist Channel.
DO NOT overfill medicine cup and allow medication to spill
into mist chamber.

6
3. Screw Water Tank Cap back onto Water Tank. Turn
the Water Tank over and place on Water Basin,
making sure it fits perfectly.
4. lug the power cord into a wall socket and turn on
the unit by using the Control Knob. The power light
will turn BLUE.
5. Use the Control Knob to adjust the intensity of the mist
output.
6. When the humidifier runs out of water, the BLUE power
light will turn off, and the mist ouput will stop. This
safety feature uses a water level sensor to stop the
heating element once the water level sinks below the
required level in the water basin. A small ORANGE light
will turn on (light will appear near the “2” on Control
Knob) to indicate that the humidifier has automatically turned off. Turn the
humidifier off and unplug before removing and refilling the Water Tank.
IMPORTANT: O ERHEAT RED LIGHT
When the humidifier runs out of water, the BLUE light will turn off and mist will stop. If
the unit has overheated, a small RED light will turn on (light will appear near the “2” on
Control Knob). The RED light indicates that the unit has overheated. Turn humidifier off,
unplug the unit, allow basin and water to cool then empty water in basin. Turn
humidifier basin over and press the Reset Button, with a pen or pencil tip, on the bottom
of the Water Basin. This will reset the humidifier.
USING THE MIST CHAMBER AND MEDICINE CUP
MIST CHAMBER
1. To remove Mist Chamber, slide Mist Chamber Latch to left. Carefully lift Mist
Chamber off of Water Basin.
2. To attach the Mist Chamber, slide Mist Chamber Latch to left and place the Mist
Chamber onto Water Basin. Release the latch to secure the Mist Chamber to
Water Basin.
MEDICINE CUP
The Medicine Cup allows the addition of medications recommended for use with warm
mist humidifiers only.
1. Remove the Medicine Cup from the top of the Mist
Channel for easier filling.
2. BE CAREFUL not to overfill the Medicine Cup.
Overfilling may cause medicine to spill into Mist
Channel. Medicine in the Mist Channel may affect
the operation of the humidifier.
3. lace Medicine Cup on top of the Mist Channel.
4. DO NOT add any medication or other additives
directly to the water.

7
A NOTE ABOUT HUMIDITY
It is best to keep the humidity level at about 40%-50% of relative humidity.
In cold weather, windows and even some walls may fog or develop frost from
excessive indoor humidity. If this occurs, reduce the mist output setting to avoid
damage from condensed water dripping onto windowsills.
Too much humidity in the room may allow moisture to accumulate on surfaces where
bacteria and fungi can grow. Moisture that gathers may also damage furniture and
walls, especially wallpaper.
To reduce excessive humidity, especially in small rooms, leave the room door open
and adjust the mist intensity control setting.
MAINTENANCE
IMPORTANT: Failure to keep this humidifier clean from mineral deposits normally
contained in any water supply will affect the efficiency of the operation. Customer
failure to follow these instructions may void warranty
DO NOT leave water in Water Tank or Water Basin when unit is not in use as it may
result in the buildup of mineral deposits and bacteria that can inhibit the output
efficiency of the humidifier. If water remains in the Water Tank for more than a day or
two, bacterial growth is possible.
DAILY MAINTENANCE
1. Always turn off and unplug from outlet before cleaning.
2. Empty water from the water tank and water basin daily.
3. Wipe and dry water basin with a clean, dry cloth or paper towel.
4. Replace the water tank.
WEEKLY MAINTENANCE
1. Always turn off and unplug from outlet before cleaning.
2. Empty water from the water tank and water basin.
3. Fill the water tank with about a half-gallon of warm water. Add 2 Tablespoons of
white vinegar. Shake vigorously and let sit for 20-30 minutes. Shake vigorously
again and empty the water. Rinse water tank.
4. Make similar white vinegar/water solution. our into water basin. Let sit for 20-
30 minutes, and then empty. Rinse water tank. Wipe dry with a clean, soft
cloth.
5. Wipe the exterior surface water tank and water basin with a soft, dry cloth.
NEVER IMMERSE WATER BASIN IN WATER.
END-OF-SEASON MAINTENANCE & STORING YOUR HUMIDIFIER
1. Always turn off and unplug from outlet before cleaning.
2. Empty water from the water tank and water basin.
3. Disinfect water tank and water basin with the white vinegar and water solution.
4. Make sure that water tank has air dried without the water cap secured.
5. Make sure the water basin and water tank are completely dry before end of
season storage. Store the humidifier in a cool dry place.
6. DO NOT place any heavy items on top of humidifier during storage as this may
result in possible damage of the humidifier.
7. Store the cord in a clean, dry location away from metal objects. Always check
the plug before use to ensure metal items have not become attached.

8
TROUBLE SHOOTING
DO NOT attempt to repair the motor or nebulizer yourself. If the humidifier
continues to not operate please contact Crane Customer Care: 888-599-0992 or
[e-mail].
Problem
Solution
If humidifier does not
have any power:
Ensure unit is properly plugged into a power outlet.
Check that the Control Knob is turned to the ON position.
If ower On indicator light does not come on, contact
Crane Customer Care.
Condensation forms
around humidifier and
windows:
Adjust Control Knob to decrease mist output to low.
Leave room door cracked open during humidifier
operation.
If humidifier has
stopped, LUE light is off
and small RED light is
on:
Adjust Control Knob to turn humidifier off and unplug.
Empty water basin, turn over and press Reset Button on
bottom of humidifier.
If there is a strange
odor:
Clean the Water Tank with the water and vinegar solution
and rinse with clean water.
Leave the empty Water Tank open for some time
(without the Water Tank Cap attached) in a cool place.
The power indicator light
is blue, but there is no
mist being emitted:
Check that there is water in the Water Tank.
Make sure that nothing is blocking the mist output.
Check that the Fan Vent on the bottom of the humidifier
is not blocked.
Empty and rinse the Water Basin with cool tap water.
Check for possible mineral deposits on the Water Level
Sensor and Heating Element.

9
CUSTOMER CARE
If you have any questions with regard to the operation of this humidifier
or are in need of a spare part, please contact Crane Customer Care.
Crane USA, Inc.
621 IL Route 83, Suite 202
Bensenville, Illinois 60106
Toll Free: 1-888-599-0992 (Monday - Friday 9:00am - 4:00pm CST)
Email: customer-ser[email protected]
Website: http://www.crane-usa.com
NOTE: Spare arts can also be purchased online at http://www.crane-
usa.com.
EN IRONMENTAL PROTECTION
If the humidifier should no longer operate, please be sure to dispose of the unit in an
environmentally friendly way by taking it into a public collection point. lease do not
place broken humidifiers with your regular household waste.

10
LIMITED WARRANTY
Thank you for purchasing a Crane product. This Warm Mist Humidifier was tested
and meets our stringent quality standards. This product is warrantied to be free
from manufacturing defects under normal use and conditions for 1 year.
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE. CALL US FOR
PROBLEMS AND QUESTIONS. WE CAN HELP.
If you experience unsatisfactory operation, first refer to the troubleshooting
section in the manual to ensure that it is not due to care or cleaning. Follow Care
and Cleaning Instructions from manual. You can also visit www.crane-usa.com
Customer Care for information.
If you have any questions or comments, please call Crane Customer Care, Toll
Free: 888-599-0992 or Email [e-mail]. lease specify
the style and model number so our Customer Care Department can assist you.
WARRANTY REQUIRES A DATED PROOF OF PURCHASE.
This warranty is void if the defect is due to accidental damage, misuse, abuse,
neglect, improper repair or alteration by unauthorized persons, or a failure to
follow operating instructions provided with the product. This warranty does not
apply to normal wear and tear or commercial use.
The warranty is non-transferable and applies only to the original purchaser and
does not extend to subsequent owners of the product. Liability under this
warranty is limited to repair or replacement. In no event shall liability exceed the
purchase price paid by the purchaser of the product. Under no circumstances
shall there be liability for any loss - direct, indirect or incidental – or consequential
damage arising out of, or in connection with the use of this product.
This warranty is valid only in the 48 contiguous states plus the District of
Columbia and excludes uerto Rico and the Virgin Islands. This warranty is
effective only if the product is purchased and operated in the United States of
America.
This warranty gives you specific legal rights; however you may have other rights
that vary from state to state. Some states do not allow limitation on implied
warranties or exclusion of consequential damages; therefore these restrictions
may not apply to you.
Any instructions or warranty included in this manual may be subject to change
without notice. For the most up-to-date instructions and warranty information,
please contact us or visit our website.
To receive warranty instructions and return authorization, please call or email
Crane Customer Care.
Crane USA, Inc.
621 Route 83, Ste 202, Bensenville, Illinois 60106
Toll Free: 1-888-599-0992 (Monday - Friday 9:00am - 4:00pm CST)
Email: [e-mail]
Website: http://www.crane-usa.com
CRANE WARRANTY
