Honeywell HCM-2051 Series User manual

OWNER’S MANUAL
4 GALLON OUTPUT PER DAY
COOL MOISTURE HUMIDIFIER
Model HCM-2051 Series
* Output dependent on room temperature and humidity.
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 1

READ AND SAVE THESE SAFETY INSTRUCTIONS
BEFORE USING THIS HUMIDIFIER
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons,
including the following:
1. Always place this humidifier on a firm, flat and level surface. This humidifier may not work
properly on an uneven surface.
2. Place this humidifier in an area where it is not accessible to children.
3. Do not place the humidifier near any heat sources such as stoves, radiators, and heaters.
4. Before using the humidifier, check the power cord for any signs of damage. If the cord is
found to be damaged, DO NOT USE and return the humidifier to the manufacturer under
the warranty agreement for repair.
5. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk
of shock, this plug is intended to fit only one way in a polarized outlet. If the plug does not
fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature.
6. To disconnect the humidifier, first turn controls to the OFF position, then grip the plug and
pull it from the wall outlet. Never pull by the cord.
7. A loose fit between the AC outlet (receptacle) and plug may cause overheating and a
distortion of the plug. Contact a qualified electrician to replace loose or worn outlet.
8. The humidifier should always be unplugged and emptied when not in operation or while
being serviced or cleaned.
9. Never tilt or attempt to move the humidifier while it is operating or filled with water.
UNPLUG the humidifier before moving.
10. This humidifier requires regular cleaning. Refer to the CLEANING instructions provided.
Never clean the humidifier in any manner other than as instructed in this manual.
11. Turn the humidifier OFF if the relative humidity exceeds 60%, or if you notice moisture on
the inside of your windows. For proper humidity reading use a hygrometer.
IMPORTANT SAFETY
INSTRUCTIONS
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 2

Thank you for purchasing a Honeywell Natural Cool Moisture®Humidifier. If you would like
more information on our full line of products please visit our website at:
www.honeywell.com/yourhome.
HOW DOES IT WORK?
NATURAL COOL MOISTURE®SYSTEM
Dry air is pulled through the Natural Cool Moisture®system and a quiet fan blows out
invisible, moisture-balanced air. Unwanted minerals and bacteria from the water are trapped
inside the Natural Cool Moisture®filter. When the unit is running you will not see or feel a
“mist”. You will know your humidifier is putting moisture into the air as you watch the water
level in your tank decrease throughout the day.
WHAT IS AgION ™ANTIMICROBIAL ?
Your Honeywell Natural Cool Moisture®filter has been designed using new AgION™
technology which prevents surface growth and migration of mold, fungus, algae and bacteria
in the filter for its life - approximately one season. Keep in mind, depending on your water
quality, mineral deposits can still clog or discolor the filter, affect its life and that of the
humidifier.
MODEL - HCM-2051
Your humidifier is made up of these parts:
Motor Housing
Water Tank
Fill Cap
Base
Natural Cool
Moisture®Filter
INTRODUCTION
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 3

•Remove the water tank by grasping handle and
pulling straight up (Fig. 1). Set aside.
•Lift up on the motor housing to remove and set aside
(Fig. 2). Remove the Natural Cool Moisture®filter
from the base before filling the unit with water. Soak
filter in a sink full of cool water to help reduce
mineral build up and place back in the humidifier
while wet. DO NOT SQUEEZE OR WRING OUT THE
NATURAL COOL MOISTURE®FILTER. To help extend
the life of your filter repeat this step each time you
fill your humidifier.
•Turn the Water Tank upside down so that the Fill Cap
is facing up; unscrew the Fill Cap by turning it
counter-clockwise and set aside.
•
Fill the Water Tank with COOL tap water (Fig. 3).
Distilled water is not necessary as the water is filtered
by the Natural Cool Moisture
®
filter. DO NOT USE HOT
WATER. Doing so may damage the humidifier.
•Replace the fill cap by turning it clockwise . DO
NOT OVER TIGHTEN. Turn the Water Tank right-side
up.
NOTE: WHEN CARRYING THE FILLED WATER TANK
PLEASE USE THE HANDLE AND PLACE YOUR OTHER
HAND UNDER THE TANK FOR ADDITIONAL SUPPORT.
NOTE: We recommend that the humidifier be disinfected prior to first use. Please
see CLEANING instructions.
•Select a firm, level, flat location - at least six inches from any wall for proper air flow (Fig.
1). Place the humidifier on a water-resistant surface, as water can damage furniture and
some flooring.
The manufacturer will not accept responsibility for property damage caused by water
spillage
Fig. 1
Fig. 2
Fig. 3
WALL
6"
SET UP
FILLING
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 4

•Place the Motor Housing back into the base.
•Position the Water Tank in the humidifier and push into place. Some water will empty into
the base.
•Once the filled tank has been positioned, do not attempt to move the humidifier. If it has to
be moved, unplug the humidifier and remove the water tank first.
CAUTION: DO NOT POUR WATER INTO THE GRILLE ON TOP OF THE HUMIDIFIER.
DOING SO MAY DAMAGE THE HUMIDIFIER OR CAUSE PERSONAL INJURY.
POWER
CAUTION: DO NOT PLUG IN THE HUMIDIFIER WITH WET HANDS AS AN
ELECTRICAL SHOCK COULD OCCUR.
•With the power switch in the OFF position, plug the filled humidifier into a
polarized 120V outlet. DO NOT FORCE THE POLARIZED PLUG INTO THE OUTLET; it
will only fit one way.
HUMIDITY CONTROL
1. Set the fan speed to the desired position (Fig. 4).
HIGH: For fast humidifying
MED: For everyday moisture control
LOW: For quieter nighttime operation
2. Set the Moisture Control knob (Humidistat) to the
highest setting by turning the dial clockwise to
No. 9 (Fig. 4).
NOTE: If the humidifier fan will not start or restart
when you select a fan speed, the Moisture Control
may be set too low. Turn the dial clockwise
to No.9. This is the highest setting. The Desired
Humidity light will be Off when the unit is
producing moisture (Fig. 4).
Turn the humidifier OFF if the humidity level feels too moist or you notice
condensation forming on the walls and/or windows.
Fig. 4
FILLING CONTINUED
OPERATION
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 5

MOISTURE CONTROL KNOB/HUMIDISTAT
The Moisture Control Knob allows you to adjust and select the humidity level to your personal
preference. Your humidifier will turn on and off throughout the day and night to maintain the
desired humidity level you have selected.
HOW TO SET THE MOISTURE CONTROL KNOB/HUMIDISTAT
First run the humidifier per the operation instruction with the Moisture Control knob set to No.
9–the highest setting.
•Let the humidifier run on high for a least one hour or until your room has reached a
comfortable humidity level.
•At this point, slowly turn your Moisture Control knob
counter-clockwise until the humidifier shuts off
and the Desired Humidity light comes on (Fig. 5).
•Now that your Moisture Control knob is set, the
humidifier will automatically turn back on when your
room drops below your comfort setting and will
automatically turn off again when the setting is
reached.
AUTOMATIC SHUT OFF FEATURE - REFILL LIGHT
1. AUTO-OFF
•The humidifier will turn off when both the Base and Water Tank are empty. The Refill light
will glow to let you know your humidifier is empty.
2. AUTO-ON
•Refill the tank per the FILLING instructions. Once the base begins to fill with water the Refill
light will go off and the unit will automatically turn back on.
Fig.5
FEATURES
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 6

STEP ONE:
SCALE REMOVAL
BASE
1. Fill the Base with either:
•1 cup (8 oz) of undiluted white
vinegar
or
•Use DuraRinse®Humidifier
Cleaner, part no. AC-816, following
the instructions on the bottle.
2. Let solution stand for 20 minutes.
3. With the vinegar or DuraRinse®in the
Base clean all interior surfaces with a
soft cloth or brush to help remove scale.
4. Rinse the Base thoroughly with water
to remove scale and cleaning solution.
STEP TWO:
DISINFECTING
WATER TANK/BASE
1. Fill the Water Tank with:
•1 teaspoon of household bleach
and
•1 gallon of water
Pour some of this solution into the
Base.
2. Let solution stand for 20 minutes.
3. Rinse with water until the odor of
bleach is gone.
NOTE: THE USE OF OTHER WATER TREATMENT PRODUCTS AND CHEMICALS MAY
CAUSE DETERIORATION OF THE FILTER OR DAMAGE THE HUMIDIFIER, THEREBY
HINDERING THE HUMIDIFIER’S EFFECTIVENESS.
We recommend cleaning the humidifier once a week, more often if you have hard water,
notice a build up of impurities or detect unpleasant odors.
Cleaning involves two steps SCALE REMOVAL and DISINFECTING. Be sure to perform these
in the proper order to avoid harmful chemical interactions.
•First, turn off and unplug the humidifier.
•Remove the Water Tank and Motor Housing.
•Remove the Natural Cool Moisture®filter from the Base.
•Empty any water from the Base.
NOTE: REMOVE FILTER BEFORE CLEANING.
Failure to remove filter during cleaning will destroy the filter.
WEEKLY CLEANING
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 7

•Follow weekly CLEANING instructions when the humidifier will not be used for at least one
week or more, or at the end of the season.
•At the end of the season, remove and throw away the filter; do not store with a used filter.
•Dry the humidifier completely before storing. DO NOT store with water inside the Base or
Water Tank.
•Pack the unit in its original carton and store in a cool, dry location.
•Before next use, remember to install a new filter and clean the humidifier.
NOTE: DO NOT ATTEMPT TO CLEAN THE NATURAL COOL MOISTURE®FILTER WITH ANY
CHEMICAL SOLUTIONS, DOING SO WILL DAMAGE THE FILTER.
•AgION™prevents the surface growth and migration of mold, fungus, algae, and bacteria.
It is normal for a filter to discolor from mineral build-up. This will vary depending on water
quality.
•DO NOT clean the filter using any chemical solution.
•If a Natural Cool Moisture®filter appears to be clogged by hard water or mineral deposits,
soak it in a sink full of cool water for 10 minutes. DO NOT SQUEEZE OR WRING OUT THE
NATURAL COOL MOISTURE®FILTER. Always place filter back in the humidifier wet.
•To prevent mineral deposits use DuraFree®Humidifier Water Softener, part no. AC-817,
each time the Water Tank is refilled.
•Always purchase Honeywell Brand Natural Cool Moisture®filters as the fan motor of this
humidifier and the Natural Cool Moisture®filter are designed to function efficiently as a
set. Using any other filter could damage the motor or reduce the humidifier’s
performance.
•Be sure to empty water from the Water Tank and Base when not in use.
PROLONGING THE LIFE OF THE FILTER AND
MAINTAINING A CLEAN HUMIDIFER
END-OF-THE-SEASON CARE AND STORAGE
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 8

Q: I hear the fan turning, but I don’t see any mist. Is my humidifier operating
properly?
A: Dry air is pulled through the Natural Cool Moisture®system and a fan disperses invisible,
moisture balanced air. There is no “mist”emitted. When operating normally you will feel
only cool air coming from the unit. Monitor the water level in your Tank/ Base. If you
notice a decrease in the Water Tank over 24 hours then the unit is operating normally.
Q: My unit has been running for several hours. I hear the fan spinning, but I do not notice
the water level in the tank decreasing.
A: First, check the Natural Cool Moisture®filter to ensure it is wet. If the pad appears dry,
remove it from the Base and gently rinse under cool water. Reposition wet filter in the
Base. You may also want to note the current moisture level in your home. If the humidity
level is over 60% the unit will not put out much moisture as your air is already saturated.
Q: The humidifier is not running (the fan is not even spinning), but all (or some) of the lights
are on.
A: If the Desired Humidity light is ON: The Moisture Control knob may be set too low. Moving
the Moisture Control knob to No. 9 should restart the unit.
If the Refill light is ON: The humidifier is out of water. Refill the Water Tank and the
humidifier should restart.
Q: The Moisture Control knob was set according to the manual, but the humidifier never
seems to turn back on. Is something wrong?
A: The Moisture Control knob may be set too low. Moving the Moisture Control knob to No. 9
should restart the unit. Reset the Moisture Control knob following the instructions under
FEATURES.
Q: The Moisture Control knob was set according to the manual, but the humidifier never
seems to turn off. Is something wrong?
A: The Moisture Control knob may be set too high. Reset the Moisture Control knob following
the instructions under FEATURES.
Q: My filter has changed color. Do I need a new filter?
A: Probably not. Since your filter has been made with AgION™technology the change in
color indicates only a mineral deposit. Soak filter in a sink full of cool water to help break
up deposits. The discoloration may remain but will not affect the humidifier’s
performance.
TROUBLE SHOOTING
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 9

If your local retailer is out of stock, Honeywell replacement parts and care products may be
ordered directly from the manufacturer. You can call 1-800-332-1110 to order with a MasterCard,
Visa or Discover or fill out the form below and mail it along with a check or money order (sorry no
COD’s accepted) to:
Honeywell
Consumer Service Center
250 Turnpike Road
Southborough, MA 01772
Please allow four to six weeks for delivery.
Massachusetts residents please add 5% Sales Tax.
Item Item No. Qty. U.S. Price Total
Natural Cool Moisture®Filter, one per pack HAC-504 $ 14.00
DuraFree®Humidifier Water Softener (32 oz.) AC-817 5.00
DuraRinse®Humidifier Cleaner (32 oz.) AC-816 5.00
Water Tank and Fill Cap HCM-2051-1 19.99
Fill Cap HCM-2051-2 9.99
SUBTOTAL
MA Residents add 5% Sales Tax
Shipping and Handling $4.95
TOTAL ENCLOSED
Name Check or Money Order Enclosed
Address Credit Card No.
Exp. Date
Day Time Phone Signature
CARE PRODUCTS
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 10

Model HCM-2051 is rated 0.6 Amps at 120V, 60 Hz.
NOTE: IF YOU EXPERIENCE A PROBLEM WITH YOUR HUMIDIFIER’S POWER UNIT, PLEASE
SEE THE WARRANTY FOR INSTRUCTIONS. PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR
THE HUMIDIFIER YOURSELF. DOING SO WILL VOID THE WARRANTY AND COULD CAUSE
DAMAGE OR PERSONAL INJURY. IF THE PROBLEM PERSISTS, PLEASE CONTACT THE
CONSUMER SERVICE CENTER.
Mail questions or comments to:
Honeywell
Consumer Service Center
250 Turnpike Road
Southborough, MA 01772
e-mail: [email protected]
Please be sure to specify model number.
Call us toll-free at:
1-800-332-1110
Or visit our website at:
www.honeywell.com/yourhome
CUSTOMER ASSISTANCE
ELECTRICAL RATINGS
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 11

©2001 All rights reserved. Honeywell P/N: 035-02383-000
69-3006
You should first read all instructions before
attempting to use this product.
The enclosed Customer Response card should
be filled out and returned within 7 days of
purchase.
A. This 5 year limited warranty applies to repair
or replacement of product found to be
defective in material or workmanship. This
warranty does not apply to damage resulting
from commercial, abusive, unreasonable use
or supplemental damage. Defects that are the
result of normal wear and tear will not be
considered manufacturing defects under this
warranty.
HONEYWELL IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY
NATURE. ANY IMPLIED WARRANTY OF
MERCHANTABILITY FOR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS
LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY.
Some jurisdictions do not allow the exclusion
or limitation of incidental or consequential
damages or limitations on how long an implied
warranty lasts, so the above limitations or
exclusions may not apply to you. This
warranty gives you specific legal rights, and
you also may have other rights which vary
from jurisdiction to jurisdiction. This warranty
applies only to the original purchaser of this
product from the original date of purchase.
B. At its option, Honeywell will repair or replace
this product if it is found to be defective in
material or workmanship. Defective product
should be returned to the place of purchase in
accordance with store policy. Thereafter,
while within the warranty period defective
product may be returned to Honeywell.
C. This warranty does not cover damage
resulting from any unauthorized attempts to
repair or from any use not in accordance with
the instruction manual.
NOTE: THIS WARRANTY DOES NOT COVER THE
NATURAL COOL MOISTURE®FILTER, WHOSE
PERFORMANCE WILL DEPEND UPON THE
CONDITION OF THE WATER USED IN THE
HUMIDIFIER.
D. Return defective product to Honeywell
Consumer Products with a brief description of
the problem. Include proof of purchase and a
$10 US check or money order for handling,
return packing and shipping charges. Please
include your name, address and a daytime
phone number.
You must prepay shipping charges.
Send to:
Honeywell
Consumer Products,
Attn: Returns Department,
4755 South Point Drive, Memphis, TN 38118
1-800-332-1110
5 YEAR LIMITED WARRANTY
HCM-2051 OM (eng only) 6/25/01 1:40 PM Page 12
