Totem LAGOS User manual

LAGOS BED KING SINGLE
ASSEMBLY INSTRUCTIONS
PARTS LIST
1Head rail QTY 1 6LHS rail QTY 1
2Legs QTY 4
7Headboard QTY 1
3RHS rail QTY 1
4Foot rail QTY 1
5Slats QTY 11
1
2
3
4
5
6
7
A
QTYHARDWARE LIST
white bolt
M5x60mm 4
timber gauge
43x20x5 1
bolt M5x50mm 4
washer Ø15
6
5
dowel Ø10x40
8
bolt M5x30mm
4
felt pad Ø38
1
U washer
9
Allen key
B
C
D
E
F
G
H
I

STEP 1: BEGIN ASSEMBLING THE BED FRAME.
STEP 2: REPEAT FOR PART 4.
Screw bolts
(A) and install
dowels (G) onto
parts 3 and 6.
Use timber
gauge (B) to set
the bolt at the
correct length.
Connect part 6
to part 2, then
repeat for part 3.
Install U wash-
ers (F) over the
bolts (A).
Gently tighten
with the Allen
key provided (J).
1
3
6
4

STEP 3: INSTALL LEGS.
C
F
Use bolt (C) and washer (F) to fit legs to frame.
Gently tighten using Allen key provided (J).
Repeat for all legs.
For use on timber or hard floors, we recommend applying
felt pads (I) at the bottom of the legs.
2
2
2
2
STEP 4: FIT HEADBOARD.
Install 2x dowels (G) to the bed frame, then install the headboard (9) using 5x bolts (D)
and 5x washers (F).
Gently tighten using Allen key provided (J).
G
2x
D
5x
F
5x

Congratulations! Your Lagos bed is now assembled and ready for a good night’s sleep.
Paddington Gallery
Shop 3 / 188 Oxford Street, Paddington, 2021, NSW, Australia
On-site parking available please enquire.
Contact telephone no: 1300 430 818
Email: [email protected]
STEP 5: FIT SLATS.
Fit the slats (5) by simply placing them onto the slots on the bed frame.
5
