Touch Dynamic Pulse Ultra Touch Monitor 17 User manual
USER MANUAL
VERSION 1.0 October 2019
Pulse Ultra
Touch Monitor 17
ii
Copyright 2019
All Rights Reserved
Manual Version 1.0
The information contained in this document is subject to change without notice.
We make no warranty of any kind with regard to this material, including, but not limited
to, the implied warranties of merchantability and fitness for a particular purpose.
We shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright. All rights
are reserved. No part of this document may be photocopied, reproduced or translated
to another language without the prior written consent of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation.
Microsoft® and Windows® are registered trademarks of Microsoft Corporation.
Other trademarks mentioned herein are the property of their respective owners.
Safety
IMPORTANT SAFETY INSTRUCTIONS
1. To disconnect the machine from the electrical power supply, turn off the power switch
and remove the power cord plug from the wall socket. The wall socket must be easily
accessible and in close proximity to the machine.
2. Read these instructions carefully. Save these instructions for future reference.
3. Follow all warnings and instructions marked on the product.
4. Do not use this product near water.
5. Do not place this product on an unstable cart, stand, or table. The product may fall,
causing serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation
to ensure reliable operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should
never be placed near or over a radiator or heat register or in a built-in installation
unless proper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking label.
If you are not sure of the type of power available, consult your dealer or local power
company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
persons will walk on the cord.
9. Never push objects of any kind into this product through cabinet slots as they may
WRXFKGDQJHURXVYROWDJHSRLQWVRUVKRUWRXWSDUWVWKDWFRXOGUHVXOWLQDÀUHRUHOHFWULF
shock. Never spill liquid of any kind on the product.
iii
CE MARK
This device complies with the requirements of the EEC directive 2014/30/EU with
regard to “Electromagnetic compatibility” and 2014/35/EU “Low Voltage Directive”.
FCC
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
CAUTION ON LITHIUM BATTERIES
There is a danger of explosion if the battery is replaced incorrectly. Replace only
with the same or equivalent type recommended by the manufacturer. Discard used
batteries according to the manufacturer’s instructions.
Battery Caution
Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery
according to the local disposal instructions.
Safety Caution
Note: To comply with IEC60950-1 Clause 2.5 (limited power sources, L.P.S) related
OHJLVODWLRQSHULSKHUDOVVKDOOEH´0DWHULDOVIRUÀUHHQFORVXUHµFRPSOLDQW
0DWHULDOVIRUÀUHHQFORVXUHV
For MOVABLE EQUIPMENT having a total mass not exceeding 18kg.the material of a
),5((1&/2685(LQWKHWKLQQHVWVLJQLÀFDQWZDOOWKLFNQHVVXVHGVKDOOEHRI9&/$66
MATERIAL or shall pass the test of Clause A.2.
For MOVABLE EQUIPMENT having a total mass exceeding 18kg and for all STATIONARY
EQUIPMENT, the material of a FIRE ENCLOSURE, in the thinnest significant wall
thickness used, shall be of 5VB CLASS MATERIAL or shall pass the test of Clause A.1
iv
LEGISLATION AND WEEE SYMBOL
2012/19/EU Waste Electrical and Electronic Equipment Directive on the treatment,
collection, recycling and disposal of electric and electronic devices and their
components.
The crossed dust bin symbol on the device means that it should not be disposed of
with other household wastes at the end of its working life. Instead, the device should
be taken to the waste collection centers for activation of the treatment, collection,
recycling and disposal procedure.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product,
RUWKHLUORFDOJRYHUQPHQWRIÀFHIRUGHWDLOVRIZKHUHDQGKRZWKH\FDQWDNHWKLVLWHPIRU
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of
the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
v
Revision Description Date
1.0 • Initial release October 2019
Revision History
Changes to the original user manual are listed below:
vi
Table of Contents
1. Packing List..................................1
1-1. Standard Accessories.....................................................1
1-2. Optional Accessories.......................................................2
2. System View..................................3
2-1. Front & Side View............................................................3
2-2. Rear View.........................................................................3
2-3. IO Ports View....................................................................4
2-4. Dimensions......................................................................4
3. System Assembly & Disassembly5
3-1. Disassemble the Stand ..................................................5
3-2. Remove the Cable Cover ................................................5
3-3. Install the Power Adapter................................................6
4. Peripheral Installation.................7
4-1. Install the MSR Module..................................................7
4-2. Install the Fingerprint Module........................................8
4-3. Install the iButton Module..............................................9
4-4. Install the LCM Module..................................................10
vii
6SHFLÀFDWLRQ................................11
&RQÀJXUDWLRQ...............................12
6-1. D01 AD Board Layout.....................................................12
6-2. Connectors & Functions ................................................13
6-3. Jumper Setting...............................................................14
viii
The page is intentionally left blank.
1
a. System
b. Power adapter
c. Power cord
d. USB cable (x2)
Note: Power cord will be supplied differently according to various region or country.
1. Packing List
1-1. Standard Accessories
ab
cd
2
a. MSR module
b. Fingerprint module
c. iButton module
d. Customer display
1-2. Optional Accessories
ab
cd
3
2. System View
2-1. Front & Side View
No. Description
1 Fingerprint (option)
2 Touch screen
3 MSR (option)
4 Power button
5 Stand
2-2. Rear View
No. Description
1 VESA top cove
2 Cable cover
3 Stand cover
1
2
3
4
5
1
23
4
2-3. IO Ports View
2-4. Dimensions
391.59 mm
437.44mm
205.85 mm
360.42mm
abcd efghi
No. Description
a Display port (option)
b Auto adjust
c Power button
dUSBin
eVGA
f DC in 12V
g USB 2.0 x2 (one is option)
h COM (option)
i Line-out (option)
5
3. System Assembly & Disassembly
3-1. Disassemble the Stand
3-2. Remove the Cable Cover
1. Loosen the thumb screw (x1) and
slide the stand towards the IO panel
to release it from the system.
2. Reverse the steps above to attach
stand to the system.
1. Remove the screw (x1) of the cable
cover.
2. Pull the cable cover upwards to
release it from the system.
6
3-3. Install the Power Adapter
The system is equipped with a 36W power adapter. Please follow the steps to install
the power adapter.
1. )ROORZWKHVWHSVGHVFULEHGLQ&KDSWHUWRUHOHDVHWKHFDEOHFRYHUÀUVW
2. Connect the power adapter to the 19V DC in port and then route the cable
through the hole of the stand as shown in the picture.
3. Open the stand cover and arrange the cable.
7
4. Peripheral Installation
4-1. Install the MSR Module
5HPRYHWKHGXPP\FRYHUÀUVW
2. Insert the MSR module in place and
fasten the screws (x2) on the back to
secure the module.
8
4-2. Install the Fingerprint Module
5HPRYHWKHGXPP\FRYHUÀUVW
2. Insert the Fingerprint module in
place and fasten the screws (x2) on
the back to secure the module.
9
4-3. Install the iButton Module
5HPRYHWKHGXPP\FRYHUÀUVW
2. Insert the iButton module in place
and fasten the screws (x2) on the
back to secure the module.
10
4-4. Install the LCM Module
1. Follow the steps in Chapter 3-1 to diassemble the stand from the LCD panel.
2. Remove the thumb screw (x1) from the VESA top cover and then pull the cover
up.
3. Attach the VFD module to system by fastening the thumb screw (x1).
4. Route the RJ-45 cable through the hole of the stand as picture shown.
5. Attach the stand to the LCD panel
and fasten the thumb screw (x1).
6. Connect the RJ-45 cable to COM
port on the systems IO panel.
Make sure the system is powered
off.
* Please note the cable cover (refer
to Chapter 2-2) have to be removed
before routing the cable.
11
Model Name Pulse Ultra Touch Monitor 17
Mainboard D01
LCD Touch Panel
LCD size 17” TFT LED Panel
Brightness (cd/m²) 350 nits
Maximan resolution 1280 x 1024
Touch screen type 7UXHÁDW3&$3
Tilt angle 0~90o
I/O Ports
USB in 1 x USB 2.0 (Type B to PC)
USB out 1 x USB 2.0 (Type A to device)
VGA 1
DC jack 1
OSD button 2 (power, auto adjust)
Optional I/O Ports
Display port 1
COM 1
USB 1 x USB 2.0 (Type A)
Audio 1 x line out
Power
Power adapter 36W, 12V/3A
Peripherals (optional)
MSR 1 (USB)
Fingerprint 1 (USB)
iButton 1 (USB)
Customer display Flush mount LCM display 2 x 20 characters (USB)
Speaker 2 x 2W
&HUWLÀFDWH
EMC & Safety FCC, Class A, CE, LVD
Environment
Operating temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 20% ~ 80% RH non-condensing
Dimension (W x D x H) LCD 90 degree: 391.1 x 210.4 x 368 mm
Weight 5.8kgs
Mounting 100mm x100mm VESA Standard holes
7KLVVSHFLÀFDWLRQLVVXEMHFWWRFKDQJHZLWKRXWSULRUQRWLFH
5. 6SHFLÀFDWLRQ
12
6. &RQÀJXUDWLRQ
6-1. D01 AD Board Layout
