Eizo CuratOR EX3242-3D User manual

Important
Please read this “Installation Manual”, and “Instructions for Use”
(separate volume) carefully to familiarize yourself with safe and
e󰀨ective usage.
•Refer to the “Instructions for Use” for information on the
installation / connection of the monitor.
Color LCD Monitor
Installation Manual

This product has been adjusted specically for use in the region to which it was originally shipped.
If operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
e󰀨ort has been made to ensure that this manual provides up-to-date information, please note that EIZO
product specications are subject to change without notice.
2

Contents
Contents ................................................................. 3
Chapter 1 Basic Adjustment / Setting .............. 4
1-1. Loading the Monitor Settings ...................... 4
●Saving current settings to "User1"
through "User5" ............................................... 5
1-2. Switching Input Signals ............................... 5
1-3. Using Custom Keys ...................................... 6
●Setting a function to custom keys ................... 6
1-4. 3D/2D Switching ............................................ 6
1-5. Locking Control Buttons.............................. 6
Chapter 2 Advanced Adjustment / Setting ...... 7
2-1. Basic Operation of the Setting Menu ......... 7
2-2. Setting Menu Functions ............................... 9
●3D .................................................................... 9
●Color Adjustment ............................................10
●Signal .............................................................11
●Preferences ....................................................12
●Information .....................................................14
●PbyP ...............................................................15
●PinP ................................................................16
Chapter 3 Troubleshooting .............................. 17
3-1. No Picture Displayed ...................................17
3-2. Imaging Problems ........................................18
3-3. Other Problems ............................................18
Chapter 4 Reference ........................................ 19
4-1. Main Default Settings ..................................19
4-2. Pin Specications ....................................... 20
Appendix .............................................................. 21
Trademark ................................................................21
License .....................................................................21
LIMITED WARRANTY ............................................. 22
3
Contents

4Chapter 1Chapter Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting
This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front
of the monitor.
1-1. Loading the Monitor Settings
Basic settings are made in advance at the factory.
It is possible to switch to the following preset settings that have been set in advance.
DisplayPort [LINE BY
LINE]
Basic settings for DisplayPort. The input signal is set to DisplayPort when this item is
selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
SDI [SIMUL] Basic settings for SDI. The input signal is set to SDI 1 | SDI 2 when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
HDMI [LINE BY LINE] Basic settings for HDMI. The input signal is set to HDMI when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
DVI [2D] Basic settings for DVI. The input signal is set to DVI when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
"User1" through
"User5"
You can save the current setting values and display status in the following items.
These items are not selectable unless they have been saved. For details, see “Saving
current settings to “User1” through “User5”” (page 5).
1. Press (PRESET).
The preset menu is displayed.
2.
Press to select the item to load, and then press (ENTER).
The pre-made settings are loaded and the settings are changed.
Note
• The preset menu will disappear after about 10 seconds have elapsed if no operation is performed.

5
Chapter 1Chapter Basic Adjustment / Setting
●Saving current settings to "User1" through "User5"
You can save the current setting values and display status to "User1" through "User5".
1. Press (MENU).
The Setting menu appears.
2.
Press (F3) or (F4) to select "Preferences", and then press (ENTER).
The "Preferences" menu appears.
3.
Press (F3) or (F4) to select "Preset Save", and then press (ENTER).
The "Preset Save" menu appears.
4.
Press (F3) or (F4) to select one from "User1" to "User5", and then press
(ENTER).
Current setting values and display status will be saved in the selected item.
1-2. Switching Input Signals
Select the signal input to the monitor and display it on the screen.
1. Press (INPUT).
The input port menu appears.
2.
Press to select an input signal.
This switches to the selected input signal.
3.
Press (INPUT).
This exits the menu screen.
Note
• When the "Signal Format" in 3D mode is "SIMUL" then "SD 1" or "SDI 2" are not displayed; rather, "SDI 1 | SDI 2"
is displayed.
• If you press (INPUT) while the input port menu is displayed in dual screen mode (PbyP or PinP), the "PbyP" /
"PinP" menu is displayed. For details, see “PbyP” (page 15) and “PinP” (page 16).
• After the input port menu is displayed, the input port menu will disappear after 10 seconds if no key operations
are performed.

6Chapter 1Chapter Basic Adjustment / Setting
1-3. Using Custom Keys
Execute the functions assigned to the custom keys (F1 ( ), F2 ( ), F3 ( ) and F4 ( )). For
information on how to set a function to each custom key, see
“Setting a function to custom keys” (page 6) .
1. Press F1 ( ), F2 ( ), F3 ( ) and F4 ( ).
The function associated with the custom key that is pressed will run.
Note
• For dual screen display (PbyP or PinP), adjust the "Active Window" side.
●Setting a function to custom keys
1. Press (MENU).
The Setting menu appears.
2.
Press (F3) or (F4) to select "Preferences", and then press (ENTER).
The "Preferences" menu appears.
3.
Press (F3) or (F4) to select "Custom Key", and then press (ENTER).
The "Custom Key" menu appears.
4.
Press (F3) or (F4) to select which custom key to set the function to, and
then press (ENTER).
5.
Press (F3) or (F4) to select the function, and then press (ENTER).
The selected function is assigned to the corresponding custom key.
1-4. 3D/2D Switching
Switch between 3D and 2D.
1. Press the 3D/2D ( (ENTER) ) button.
3D and 2D are toggled each time this button is pressed.
Note
• The 3D mode indicator is displayed on the upper left of the screen in 3D mode.
1-5. Locking Control Buttons
Adjusted or set states can be made unchangeable.
Procedure
1. Press the (MENU) and (ENTER) keys for at least 4 seconds.
Note
• Press the (MENU) and (ENTER) keys for at least 4 seconds to exit Key Lock.

7
Chapter 2Chapter Advanced Adjustment / Setting
Chapter 2 Advanced Adjustment / Setting
This chapter describes advanced monitor adjustment and setting procedures using the main menu.
2-1. Basic Operation of the Setting Menu
1. Menu display
1. Press (MENU).
The Setting menu appears.

8Chapter 2Chapter Advanced Adjustment / Setting
2.
Adjustment / Setting
Pressing (MENU) during adjustment/setting will cancel the adjustment/setting and restore the
state prior to making changes.
1. Press (F3) or (F4) to select a menu to adjust/set, and then press (ENTER).
The submenu appears.
2. Press (F3) or (F4) to select an item to adjust/set, and then press (ENTER).
The Adjustment/Setting menu appears.
3. Press (F1) or (F2) to adjust/set the selected item, and then press (ENTER) to conrm
the settings.
The submenu appears.
3.
Exiting
1. Press (MENU).
The Setting menu appears.
2. Press (MENU).
Exits the Setting menu.

9
Chapter 2Chapter Advanced Adjustment / Setting
2-2. Setting Menu Functions
●3D
Adjustments / settings for 3D display.
Function Setting Description
3D/2D Selection 3D
2D
Switches 3D/2D display.
Note
• Selecting "3D" will enable "Signal Format", "Left/
Right Swap", and "H Parallax".
• Fixed at "2D" during PbyP display.
Signal Format SIMUL
TOP AND BOTTOM
SIDE BY SIDE
LINE BY LINE
LEVEL B
Sets the signal format in 3D mode.
• "SIMUL"
Inputs left-eye signals from SDI 1 and right-
eye signals from SDI 2.
When using one screen:
This can only be set when "SDI 1" has been
selected in the input port menu.
During PinP:
This can only be set when "SDI 1" has been
selected in the "Large Window" for PinP
settings and when something other than "SDI
1" has been selected in the "Small Window".
• "TOP AND BOTTOM"
Inputs TOP AND BOTTOM signals.
• "SIDE BY SIDE"
Inputs SIDE BY SIDE signals.
• "LINE BY LINE"
Inputs LINE BY LINE signals. During PinP, if
the input signal is DisplayPort, HDMI, or DVI,
then it is xed at "LINE BY LINE".
• "LEVEL B"
This can only be set when "SDI 1" or "SDI 2"
has been selected in the input port menu. The
SIMUL method signal is input to SDI 1 or SDI
2 using dual stream.
Left/Right Swap O󰀨
On
Switches the displays of the left-eye signal and
the right-eye signal.
H Parallax -62 to 62
Adjusts horizontal o󰀨set of the left-eye signal and the
right-eye signal. If you do not experience a 3D e󰀨ect,
this may be improved by adjusting the parallax.
Note
• The 3D mode indicator is displayed on the upper left of the screen in 3D mode.
• When displaying 3D in PinP, be sure to observe the following:
- Only the large window will display the 3D image. The small window cannot display in 3D.
- The signal formats that can be selected may be di󰀨erent, depending on the input signal (PinP setting “Large
Window*1” (page 16) setting).

10 Chapter 2Chapter Advanced Adjustment / Setting
●Color Adjustment
Function Setting Description
Active Window PbyP Left Window /
Right Window
Select which window to adjust settings when using dual screen
display (PbyP or PinP). Disabled during single screen display.
Note
• For dual screen display (PbyP or PinP), color adjustment can be
performed for each screen selected in "Active Window".
PinP Large Window /
Small Window
Single All
Backlight 0 to 100 Adjust screen brightness by changing the brightness of the backlight
(light source from the LCD back panel).
Note
• For dual screen display (PbyP or PinP), settings are applied to
"Left Window" / "Large Window".
• The backlight is disabled when the right window or small window
is selected during PbyP or PinP.
Brightness 0 to 100 Adjust the brightness of black.
Contrast 0 to 100 Contrast can be adjusted.
Adjust the brightness of the screen by changing the video signal
level.
Temperature Native / 6500K / 9300K /
User
Adjust the color temperature. The color temperature is normally
used to express the hue of "White" and / or "Black" with a numerical
value. The value is expressed in degrees "K" (Kelvin). The screen
becomes reddish at low color temperatures and bluish at high color
temperatures, similar to the temperatures of a ame.
Note
• Select "Native" to display the original colors of the LCD panel.
• "Gain" allows you to perform more advanced adjustment. When
gain is changed, "Temperature" is changed to "User".
• The gain preset values are set for each color temperature setting
value.
Gamma 1.8 / 2.0 / 2.2 / 2.4 / 2.6 /
DICOM / HLG / PQ
Adjust the gamma. While the brightness of the monitor varies
depending on the video level of the input signal, the variation rate
is not proportional to the input signal. Maintaining the balance
between the input signal and brightness of the monitor is referred to
as "Gamma correction".
Color Gamut Native / sRGB / BT.2020 Set the color reproduction area (color gamut). The color gamut is
the range of colors that can be represented. Multiple standards are
dened.
Note
• Select "Native" to display the original color gamut of the LCD panel.
Hue -100 to 100 Adjust the hue.
Saturation -100 to 100 Adjust the color saturation.
Gain 0 to 255 The brightness of each color component (red, green, and blue) is
called "gain". The hue of "white" can be changed by adjusting the
gain.

11
Chapter 2Chapter Advanced Adjustment / Setting
●Signal
Function Setting Description
Active Window (In single screen display mode.)
All
(When "Multi Window" is set to
"PbyP")
Left Window / Right Window
(When "Multi Window" is set to
"PinP")
Large Window / Small Window
Select which window to adjust settings in during dual
screen display (PbyP or PinP). Disabled during single
screen display.
Input Color
Format*1
(When input signal is DisplayPort.)
Auto / YUV / RGB
(When input signal is HDMI.)
Auto / YUV 4:2:2 / YUV 4:4:4 / RGB
(When input signal is SDI.)
Auto / YCC4:2:2 10bit / YCC4:2:2
12bit / YCC4:4:4 10bit / YCC4:4:4
12bit / RGB4:4:4 10bit / RGB4:4:4
12bit
The color space of the input signal can be specied.
Try changing this setting if colors are not displayed
correctly. Normally, select "Auto". When an SDI signal
is input, the bit depth is specied using the "Input Color
Format". If the specied bit depth is invalid, a signal
error is displayed.
YUV Color
Matrix*1
Auto / BT.601 / BT.709 / BT.2020 Select the YUV format of the input signal. Use this
setting for gradation collapse or other occurrences
where the screen is displayed incorrectly because of a
problem with the input signal.
Input Range (When input signal is DisplayPort or
HDMI.)
Auto / Full / Limited
(When input signal is SDI or DVI.)
Full / Limited
Depending on the video reproduction device, there
may be a restriction on black and white video signal
levels output to the monitor. This kind of signal is called
"Limited range". On the other hand, unlimited signals
are called "Full range".
• "Auto"
Input signal brightness range is automatically
judged and is displayed appropriately
(recommended setting). Depending on the video
reproduction device, Limited range and Full range
may not be able to be judged by the monitor. In
such a case, selecting "Full" or "Limited" will allow
it to be displayed appropriately.
• "Full"
To be selected in case of Full range signals.
Appropriate display can be obtained when this
is selected, in case both blacks and whites are
corrupted.
• "Limited"
To be selected in case of Limited range signals.
When this is selected, the output signal range is
expanded from 0 to 255 to obtain an appropriate
display when black is pale and white is dull.
*1 Disabled when input signal is DVI.

12 Chapter 2Chapter Advanced Adjustment / Setting
●Preferences
Function Setting Description
Multi Window Single / PbyP / PinP Select single screen display or dual screen
display (PbyP or PinP). Disabled when
"Display Direction" is "180°" or "Mirror" or
"Signal format" is "TOP AND BOTTOM" or
"SIDE BY SIDE" in 3D mode.
• "Single"
Displays the selected input signal on the
screen.
• "PbyP"
Displays two di󰀨erent signals side-by-
side on one screen simultaneously.
Disabled in 3D mode.
• "PinP"
Displays two di󰀨erent signals on one
screen by overlapping a subscreen on a
main screen.
Note
• In PbyP and PinP, the same input signal
can be displayed on two screens. Example:
During PbyP display, select "DisplayPort"
for both "Left Window" and "Right Window"
in the "PbyP" screen.
• "SDI 1" and "SDI 2" cannot be displayed
simultaneously.
Display Direction*1 Normal / 180° / Mirror Select the rotation angle or horizontally ip
the main screen.
Note
• Displays on the screen when "180°"
selected.
• Displays on the screen when "Mirror"
selected.
Languages English / German / French / Spanish
/ Italian / Swedish / Japanese /
Simplied Chinese / Traditional
Chinese / Russian / Portuguese
Select the language to be used for display in
settings and all menus.
PRESET Save User1 OK / Cancel Save current setting values and display
status for each user.
Note
• The saved items are the same as the
presets (DisplayPort [LINE BY LINE] / SDI
[SIMUL] / HDMI [LINE BY LINE] / DVI [2D]).
For the setting items of preset settings, see
“4-1. Main Default Settings” (page 19).
User2
User3
User4
User5

13
Chapter 2Chapter Advanced Adjustment / Setting
Function Setting Description
Custom Key [F1] O󰀨 / Backlight / Gamma
/ Color Gamut / Multi
Window / Display
Direction / Swap
Select the function that is assigned to each
custom key. For details, see “Setting a
function to custom keys” (page 6).
[F2]
[F3]
[F4]
Advanced
Setting
Auto Input
Detection*1
On / O󰀨 This function automatically recognizes the
connector through which computer signals
are input, and displays images on the screen
accordingly.
• "On"
When the monitor is connected to
multiple computers, if a specic computer
enters power saving mode or no signals
are input to the monitor, the connector is
automatically changed to another one to
which signals are input.
• "O󰀨"
Set to this when manually selecting input
signals. In this case, you can select
the input signal to display using the
control button on the front of the monitor.
For details, see “1-2. Switching Input
Signals” (page 5).
Note
• When this function is set to "On", the
monitor only enters the power saving
mode when signals are not input from any
computer.
Input
Skip*1
DisplayPort - / Skip When "Auto Input Detection" is "On", select
the port to skip signal detection.
Note
• If all of the ports are set to "Skip", then input
signal will not be detected, in the same way
as when "Auto Input Detection" is set to
"O󰀨".
• When the "Signal Format" in 3D mode
is "SIMUL" then "SD 1" or "SDI 2" are
not displayed; rather, "SDI 1 | SDI 2" is
displayed.
HDMI
SDI 1
SDI 2
DVI
On-Screen
Logo
On / O󰀨 Select whether to display or hide the logo
when the monitor starts.
SDI Input
equalizer
On / O󰀨 Emphasizes the SDI input signal
Note
• If noise is apparent when using the short
SDI cable, set this to "O󰀨".
RS-232C 19200 bps / 115200 bps Sets the communication speed when
controlling this product from an external
device connected using the RS-232C
terminal.
Monitor Reset OK / Cancel Restores all settings to their default values.
*1 Disabled during dual screen display (PbyP or PinP).

14 Chapter 2Chapter Advanced Adjustment / Setting
●Information
Display the monitor information (model name, serial number (S/N), usage time) and the input signal
information.
Example:

15
Chapter 2Chapter Advanced Adjustment / Setting
●PbyP
If you press (INPUT) while in PbyP dual screen mode, the "PbyP" menu is displayed.
Function Setting Description
Left Window DisplayPort / HDMI / SDI 1 /
SDI 2 / DVI
Select the signal input to the left window when PbyP dual screen
display.
Note
• "SDI 1" and "SDI 2" cannot be displayed simultaneously.
• The 3D signal cannot be selected.
Right Window DisplayPort / HDMI / SDI 1 /
SDI 2 / DVI
Select the signal input to the right window when PbyP dual
screen display.
Note
• "SDI 1" and "SDI 2" cannot be displayed simultaneously.
• 3D signals will be shown as 2D.
Swap Swap the input ports of left window and right window.
Note
• Swapping may not be possible for some input signals.

16 Chapter 2Chapter Advanced Adjustment / Setting
●PinP
If you press (INPUT) while in PinP dual screen mode, the "PinP" menu is displayed.
Function Setting Description
Large Window*1 DisplayPort / HDMI / SDI 1 /
SDI 2 / DVI
Select the signal input to the large window when PinP dual
screen display.
Note
• This function can be set when the "Signal format" in either
2D or 3D mode is set to "SIMUL", "LINE BY LINE", or
"LEVEL B".
• "SDI 1" and "SDI 2" cannot be displayed simultaneously.
Small Window*1 DisplayPort / HDMI / SDI 1 /
SDI 2 / DVI
Select the signal input to the small window when PinP dual
screen display.
Note
• "SDI 1" and "SDI 2" cannot be displayed simultaneously.
• 3D signals will be shown as 2D.
PinP Size Small / Large Select size of the small window.
PinP Position Upper Right / Lower Right /
Lower Left / Upper Left
Select position of the small window.
Swap Swaps the input ports of the large window and small window.
Note
• Swapping may not be possible for some input signals.
*1 In 3D mode, the same signal cannot be selected for both the "Large Window" and "Small Window".

17
Chapter 3Chapter Troubleshooting
Chapter 3 Troubleshooting
3-1. No Picture Displayed
Problem Possible cause and remedy
1. No picture. • Check whether the power cord is connected properly.
• Check whether the DC OUT terminal and the DC IN terminal
are connected properly.
• Turn on the power switch.
• Check whether the main power indicator of the AC adapter is on.
• Turn o󰀨 the power and then turn it on again.
2. The message below appears. These messages appear when the signal is not input correctly
even though the monitor is functioning properly.
• This message appears when no signal is
input.
Example:
• The message shown on the left may appear, because some
devices to be connected do not output the signal immediately
after power-on.
• Check whether the device to be connected is turned on.
• Check whether the signal cable is connected properly.
• Turn o󰀨 the power and then turn it on again.
• Change the setting for "Auto Input Detection" under
"Advanced Setting" in the "Preferences" menu to "O󰀨" and
then manually switch the input signals (see “Auto Input
Detection*1” (page 13)).
• This message indicates that the input signal
is outside the specied frequency range.
Example:
• Check whether the device to be connected is congured to
meet the resolution and vertical scan frequency requirements
of the monitor.
• Reboot the device to be connected.

18 Chapter 3Chapter Troubleshooting
3-2. Imaging Problems
Problem Possible cause and remedy
1. The screen is too bright or too dark. • Use "Brightness" or "Backlight" in the Setting menu to adjust it.
2. Text is blurred • Check whether the computer is congured to meet the
resolution and vertical scan frequency requirements of
the monitor (see "Displayable Input Signals" in the User's
Manual).
3. Afterimages appear • Afterimages are particular to LCD monitors. Avoid displaying
the same image for a long time.
• Use the screen saver or power saving function to avoid
displaying the same image for extended periods of time.
• An afterimage may appear even after a short time period has
elapsed depending on the displayed image. If this occurs,
changing the image or leaving the power o󰀨 for a few hours
may solve the problem.
4. Green, red, blue, white dots or dark dots
remain on the screen
• This is due to LCD panel characteristics and not a
malfunction.
5. The screen suddenly went black. / The
screen does not become brighter after
increasing the "Backlight" value in the
Settings menu.
• This product is equipped with a heat dissipation fan. If the fan
is not operating properly, screen brightness can be limited in
order to lower the internal temperature. In this case, please
make sure that the fan is operating properly.
6. 3D images are not shown • Switch to 3D mode.
• Change the signal format.
• Switch the displays of the left-eye signal and the right-eye
signal.
• In SIMUL mode, make sure that the left-eye image signal and
the right-eye image signal are input correctly.
7. The 3D image has insu󰀩cient three-
dimensionality
• Use "H Parallax" in the Setting menu to adjust it.
3-3. Other Problems
Problem Possible cause and remedy
1. The Setting menu does not appear. • Make sure the lock function is not set to "On."
(See “1-5. Locking Control Buttons” (page 6).)
2. The message below appears. This will be displayed when the signal is not displaying properly.
• This will be displayed when a 6-bit (64
gradient) signal is being input.
Example:
• Turn o󰀨 the power to the connected device and this product
and then turn on the power again.
• Check the settings on the connected device.

19
Chapter 4Chapter Reference
Chapter 4 Reference
4-1. Main Default Settings
Preset
Item
Default
DisplayPort
[LINE BY
LINE]
SDI
[SIMUL]
HDMI [LINE
BY LINE] DVI [2D]
Input Port
MAIN
(Left Window / Large Window) DisplayPort SDI1 | SDI2 HDMI DVI
SUB
(Right Window/Small Window) DVI DVI DVI DisplayPort
3D
3D/2D Selection 3D 3D 3D 2D
Signal Format LINE BY LINE SIMUL LINE BY LINE LINE BY LINE
Left/Right Swap O󰀨 O󰀨 O󰀨 O󰀨
H Parallax 0 0 0 0
Preferences Multi Window Single Single Single Single
Display Direction Normal Normal Normal Normal
Color
Backlight 100 100 100 100
Brightness 0 0 0 0
Contrast 100 100 100 100
Temperature 6500 K 6500 K 6500 K 6500 K
Gamma 2.2 2.2 2.2 2.2
Color Gamut sRGB sRGB sRGB sRGB
Saturation 0 0 0 0
Hue 0 0 0 0
Signal
Input Color Format Auto Auto Auto -
(RGB)
YUV Color Matrix Auto Auto Auto -
(BT.709)
Input Range Auto Limited Auto Full
Others
Preferences Language English
Advanced Setting On-Screen Logo On
Custom Key F1 O󰀨
F2 O󰀨
F3 O󰀨
F4 O󰀨
Key Lock Unlock

20 Chapter 4Chapter Reference
4-2. Pin Specications
●DC IN terminal
1
2
3
4
5
Pin No. Signal name
1GND
2GND
3F.E
4 DC 48V
5 DC 48V
●DC OUT terminal on the main unit
1
23
4
Pin No. Signal name
1GND
2GND
3DC 5 V
4 DC 5 V
HIROSE P/N: HR10A-7R-4S(74)
Recommended plug
HIROSE P/N: HR10A-7P-4P(74)
●DC OUT terminal of AC adapter
3
2 1
54
Pin No. Signal name
1GND
2GND
3F.E
4 DC 48V
5 DC 48V
