TouchTunes Fusion Music System Assembly instructions

Fusion Music System
Installation and Setup Guide

Disclaimer
Document Part Number: 901095-001 Rev 01 November 2018
INSTALLATION AND SETUP GUIDE FOR TOUCHTUNES FUSION MUSIC SYSTEM
A. About this Guide
• This Installation and Setup Guide (the "Guide") is produced by TouchTunes Music Corporation
on behalf of itself and its subsidiaries (collectively, "TouchTunes").
• The information contained in this Guide, including any product specifications, is subject to change
without notice.
• TouchTunes assumes no responsibility or liability for any errors in this publication and makes no
warranty of any kind with respect to the content of this Guide.
• No part of this Guide may be reproduced, transmitted, transcribed, stored in a retrieval system,
adapted or translated into any language in any form, by any means, without TouchTunes' prior
written permission.
• TouchTunes reserves the right to change the specifications of the hardware and software
described in this Guide at any time and without prior notice.
• This Guide is furnished for informational purposes only, is subject to change without notice, and
should not be construed as a commitment by TouchTunes.
• Changes may be periodically made to the information set forth in this Guide, which changes will
be incorporated into new editions of this Guide.
• TouchTunes will not be held liable for any damages resulting from the use of this Guide or the
product(s) described in this Guide.
TOUCHTUNES PROVIDES NO WARRANTY WITH REGARD TO THIS GUIDE OR ANY OTHER
INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE WITH
REGARD TO ANY OF THE FOREGOING. TOUCHTUNES ASSUMES NO LIABILITY FOR ANY
DAMAGES INCURRED DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR TYPOGRAPHICAL
ERRORS OR OMISSIONS CONTAINED HEREIN OR FOR DISCREPANCIES BETWEEN THE
PRODUCT AND THIS GUIDE. IN NO EVENT SHALL TOUCHTUNES BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER BASED ON
TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS GUIDE OR
ANY OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
B. Trademarks
TouchTunes and the TouchTunes logo are some of the trademarks or registered trademarks of
TouchTunes in the United States, other countries, or both. Any third party company, product(s), brand and/
or service names may be registered or unregistered trademarks or service marks of their respective
owners and are hereby recognized.

Logos, trademarks, photography, illustrations, graphics, screenshots, videos, audios and text
incorporated into TouchTunes' hard copy and online documents and publications are copyright protected
by TouchTunes or its licensors. Downloading, web linking, screen capturing or copying these items in
any manner for any use--other than personally viewing the original document in its entirety--are prohibited
by copyright law, and written permission from TouchTunes must be obtained before any use of
TouchTunes' copyrighted material.
C. Intellectual Property
All Intellectual Property (as defined below) owned by or which is otherwise the property of TouchTunes
or its respective suppliers or licensors relating to Fusion Music System, including accessories, parts or
software relating thereto (the "Product"), is proprietary to TouchTunes and protected under Federal and
State laws and international treaty provisions. "Intellectual Property" includes trademarks, service marks,
logos, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer
programs and related documentation and other works of authorship. You may not infringe or otherwise
violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not
attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble or otherwise
attempt to create source code from the software. No title or ownership in the Intellectual Property is
transferred to you. All applicable rights of the Intellectual Property shall remain with TouchTunes.
D. Confidential Information
This Guide is copyrighted by TouchTunes and the contents are confidential information of TouchTunes.
You may not disclose the information described herein without written authorization of TouchTunes.
E. Contact Information
While every effort was made to ensure that the information in this Guide is accurate and complete, we
would appreciate it if you bring to our attention any errors or omissions or if you otherwise have any
comments on this Guide or the products it describes to:
TouchTunes Music Corporation
ATTN: Product Operations
850 Third Ave, 15th Floor
New York, NY 10022
USA
© The Octave Music Group, Inc. (formerly known as TouchTunes Interactive Networks, Inc.) 2018
All rights reserved, including those to reproduce this Guide or parts thereof in any form without permission
from TouchTunes.

Contents
1 Welcome 9
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Disclaimer and Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contacting TouchTunes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Introducing Fusion Music System 13
Introducing Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Fusion Music System Features Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Touchscreen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Designed for Easy Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Amplification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Fan-less Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Powerful CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
High Capacity Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Wall Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Wireless Broadband . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Custom Facade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Fusion Music System Interior Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Modular Hardware Platform (MHP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Payment Means . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cable Management Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Custom Music Programming (CMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Multi-Language Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6
3 Preparing for Installation 25
Checking Fusion Music System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting Up a Broadband Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Preparing Tools and Materials for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4 Installing Fusion Music System 31
Moving the Fusion Music System to its Mounting Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Unpacking the Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Wall-Mounting the Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Installing the Modular Hardware Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Installing the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Applying the Custom Facade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Connecting the Fusion Music System to the Wired Broadband Network . . . . . . . . . . . . . . . . . 50
Setting up TouchTunes Wireless Broadband (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Connecting Speakers to the Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Connecting the Wired Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Powering on the Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Activating the Fusion Music System Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5 Activating Fusion Music System 57
Powering on Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Configuring Fusion Music System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Calibrating the Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Selecting Configuration Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Selecting Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Choosing Fusion Music System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Choosing Calling Window and Connection Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Verifying the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Updating Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Installation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Corruption in the ID Chip or Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Major System Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6 Setting up Fusion Music System 71
Opening the Operator Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Setting the Remote Control ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Learning the Remote ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Remote Key Assignments and Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Configuring the Bill Acceptors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Testing the Bill Acceptors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Enabling Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Connecting an External Audio Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Requirements for Connecting to an External Audio Source . . . . . . . . . . . . . . . . . . . . . . . .80

7
Connecting a Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Applying Filters and Credit Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Setting Local Favorites Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Setting Custom Music Programming (CMP) Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Changing Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Note About Applying Stickers to the Fusion Music System Touchscreen . . . . . . . . . . . . . . . . . 88
7 Service and Maintenance 89
Important Safety Instructions and Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
About Fusion Music System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Offline Diagnostic Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Starting the ODT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
RAM Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Hard Drive Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
8 Bridging the Internal Amplifiers 93
Bridged Amplifiers Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Bridging the Amplifiers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Bridging Safety Considerations and Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Troubleshooting Amplifier Bridging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
9 Connection Diagram 99
10 Acronyms 103

8

Fusion Music System Installation and Setup Guide 901095-001 Rev 01
1
Welcome
This section introduces the Fusion Music System, provides important safety information, and describes how to get
technical support.
Topics
Welcome
About This Guide
Disclaimer and Important Safety Information
Contacting TouchTunes

Fusion Installation and Setup Guide
Welcome
10
Welcome
Congratulations on your receipt of the Fusion Music System. Fusion Music System’s concept and appearance are
designed to impress as well as attract patrons.
About This Guide
This guide is intended for Operators of the Fusion Music System and their technicians, as well as TouchTunes
technical support and field service personnel. It provides important information about the installation and setup of the
Fusion Music System.
Disclaimer and Important Safety Information
The Octave Music Group, Inc. (formerly known as TouchTunes Interactive Networks, Inc.) is not responsible for any
damage resulting from the improper installation or connection of components of the Fusion Music System or any
other external equipment to your system. TouchTunes is not responsible for any damage caused during shipment
(except the shipment to the original purchaser) or any damage caused by:
• impacts, fluids, fire, flood, wind, earthquake, lightning or similar disaster
• unauthorized modifications, non-TouchTunes attachments or peripherals, improper use, environment,
installation or electrical supply
• improper maintenance
• any other misuse, abuse, or mishandling
Important Safety Instructions
Familiarize yourself with this important safety information before proceeding with product installation.
• READ THESE INSTRUCTIONS.
• KEEP THESE INSTRUCTIONS.
• HEED ALL WARNINGS.
• FOLLOW ALL INSTRUCTIONS.
The Lightning Flash with arrow head symbol within an equilateral triangle is intended to alert the user
to the presence of uninsulated “dangerous voltage” within the product enclosure that may be of
sufficient magnitude to constitute a risk of shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.
WARNING: Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE
FUSION MUSIC SYSTEM TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHOULD NOT BE PLACED ON THE FUSION MUSIC SYSTEM.
DO NOT USE THE FUSION MUSIC SYSTEM NEAR WATER.

Welcome
Fusion Installation and Setup Guide
11
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, THE FUSION MUSIC
SYSTEM SHALL BE CONNECTED TO A MAINS SOCKET OUTLET WITH A PROTECTIVE
EARTHING CONNECTION.
WARNING: The speaker output of the Fusion Music System can exceed 10 Watts and could cause a
shock injury. Connection to speakers should be performed by a skilled person in compliance with local
building codes. Class 2 wiring is required for speaker cables. Use of external speakers outside the
ratings stated at the speaker jack may result in a shock injury or damage to the Fusion Music System,
or equivalent.
CAUTION: Do not use the Fusion Music System immediately after transferring the Fusion Music
System from a cold place to a warm place as condensation may have occurred on internal
components. Wait for the Fusion Music System to reach room temperature before using it.
IMPORTANT: See the product enclosure for safety-related markings.
TO COMPLETELY DISCONNECT THE FUSION MUSIC SYSTEM FROM THE AC MAINS,
DISCONNECT THE POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE.
THE MAINS PLUG OF THE POWER SUPPLY CORD OR APPLIANCE COUPLER SHALL REMAIN
READILY ACCESSIBLE.
The Power Supply has no serviceable parts inside, please contact TouchTunes Customer Support
for service.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturers instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the Fusion Music System.
Only use attachments/accessories specified by the manufacturer.
Unplug the Fusion Music System during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the Fusion Music System
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the Fusion Music System, the Fusion Music System has been exposed to
rain or moisture, does not operate normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose the Fusion Music System to rain
or moisture.
To disconnect the Fusion Music System unplug from the mains plug, access to the mains plug should
be readily accessible after the installation.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.

Fusion Installation and Setup Guide
Welcome
12
Contacting TouchTunes
If you need help or have questions about this guide, call the TouchTunes 24/7 Service Hotline at 888-338-5853.
To help us assist you more effectively with problem reports, the following information may be required when
contacting TouchTunes Technical Support:
• Fusion Music System model and ID
• Operator ID
• Serial number of any component you believe to be problematic
• The date/time of the problem
• Actions performed immediately before the problem occurred
• Any additional comments relevant to the problem
Care should be taken when disposing of batteries to ensure there is no environmental impact. Refer
to your federal guidelines for the proper disposal methods.
WARNING: Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such
as sunshine, fire, or the like.
Use only with the bracket specified by the manufacturer or sold with the Fusion Music System.
IMPORTANT: Additional electrical and safety requirements appear on the Fusion Music System
product labels located inside the door near the locking mechanism and on the back of the Fusion
Music System.
WARNING: The Fusion Music System is not secured to the wall until the pivot latches are in the
vertical (locked) position.
WARNING
To prevent injury, the Fusion Music System must be securely attached to the
wall in accordance with the installation instructions.

Fusion Music System Installation and Setup Guide 901095-001 Rev 01
2
Introducing Fusion Music System
This section introduces the hardware and software features of the Fusion Music System.
Topics
Introducing Fusion Music System
Fusion Music System Features Overview
Fusion Music System Interior Components
•Modular Hardware Platform (MHP)
•Computer
•I/O Board
•Power Supply Unit
•Amplifiers
Payment Means
Cable Management Hardware
User Interface
•Custom Music Programming (CMP)
•Multi-Language Support

Fusion Music System Installation and Setup Guide
Introducing Fusion Music System
Introducing Fusion Music System
14
Introducing Fusion Music System
TouchTunes introduces the Fusion Music System, a revolutionary next-generation entertainment platform, with
features designed to enhance the customer experience and attract patrons.
Fusion Music System Features Overview
Touchscreen Display
19-inch high definition touchscreen with over 2 million pixels provides ample area to present rich content as well as
enhance the music search and selection experience for patrons.
Designed for Easy Maintenance
The design of Fusion Music System’s Modular Hardware Platform provides for quick and easy maintenance of its
core components.
Amplification
Dual amplifiers with integrated power supply provide world class audio for two independently controllable zones.
A third independently controllable zone can be used with external amplification. The amplifiers can be swapped out
individually, when needed.
Fan-less Design
Fusion Music System’s cooling system is an industrial design that uses passive cooling, which greatly reduces noise
and makes it a “green” out-of-home entertainment platform. However, a General Purpose Input/Output (GPIO)
module is available to add up to two optional fans.
Powerful CPU
The Fusion Music System’s advanced 64-bit CPU provides great performance and superior graphics quality.
High Capacity Storage
With a high-resilience 500-gigabyte hard drive, the Fusion Music System allows for the local storage of music and
multimedia content.
Wall Mounting Bracket
Fusion Music System’s mounting bracket has an auto-locking design and its dimensions are specific for supporting
the Fusion Music System.
Wireless Broadband
Wireless broadband enables operators to connect their Fusion Music System to the Internet with a wireless high
speed connection. This gives you:
• Real-time customer access to the entire TouchTunes catalog
NOTE For patrons’ optimal viewing angle and relaxed sight range, ensure that you adhere to the
installation guidelines for wall-mounting the Fusion Music System. See Wall-Mounting the Fusion
Music System.

Introducing Fusion Music System
Fusion Music System Interior Components
Fusion Music System Installation and Setup Guide
15
• Access to custom playlists created by venue staff
• Fast data transfers and communications with the TouchTunes Tempo site (https://tempo.touchtunes.com),
including music downloads, settings modifications and Network Diagnostic System (NDS)
• Improved song recommendation quality
• Expanded advertisement capabilities
• Support for the TouchTunes mobile app, which allows patrons to play songs from their mobile devices, without
needing to walk up to the Fusion Music System
Custom Facade
The beta release of the Fusion Music System is delivered with a new custom facade, which must be installed as a
cover to the chassis. There is a separate installation guide for the facade, Fusion Music System Barrel Facade
Installation Guide (P/N 901096-001). This guide is included in the Accessory Kit.
Fusion Music System Interior Components
The following figure shows the interior of the Fusion Music System.

Fusion Music System Installation and Setup Guide
Introducing Fusion Music System
Fusion Music System Interior Components
16
Modular Hardware Platform (MHP)
The following figure shows the components on Fusion Music System’s Modular Hardware Platform.
1Computer
2I/O Board
3Power Supply Unit
4Zone 2 amplifier
5Zone 1 amplifier

Introducing Fusion Music System
Fusion Music System Interior Components
Fusion Music System Installation and Setup Guide
17
Computer
The central computer in the Fusion Music System is a specially designed computer mounted inside the Fusion Music
System. The computer contains a 500 gigabyte SATA hard drive and connectors for attaching peripherals.
Computer top panel
1Status LEDs (Green = power, Yellow = hard drive activity)
2DVI out
3HDMI out
4Ethernet (LAN port)
5USB 3.0 ports (5)

Fusion Music System Installation and Setup Guide
Introducing Fusion Music System
Fusion Music System Interior Components
18
I/O Board
The I/O Board is an interface between the computer and Fusion Music System’s other components, providing
controls and status indicators.
1Wired remote (top of panel)
2Squid (main)
3Zones 1 through 3 audio
4Aux input
5Microphone input
6Status LEDs
7Manager button
8Handle for easy removal of component

Introducing Fusion Music System
Fusion Music System Interior Components
Fusion Music System Installation and Setup Guide
19
Power Supply Unit

Fusion Music System Installation and Setup Guide
Introducing Fusion Music System
Fusion Music System Interior Components
20
Amplifiers
Fusion Music System’s two amplifiers are specially-designed with integrated power supply and each provides an
independently controllable audio zone. Each amplifier has a handle that provides an easy way to remove the
component when needed. The following shows the Zone 2 amplifier.
Key Features
• Fully integrated audio power solution
• Rugged construction
• Thermal protection
• Over current protection
• Sound optimized soft clipping
