Tower Hobbies T14045 Operator's manual

T14045
FAMILY 42 LITRE
MINI OVEN
WITH HOT PLATES
& ROTISSERIE
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.

2
4
5
6
7
9
8
10
11 1312 14 15
Description: Family 42 Litre Mini Oven With Hot Plates & Rotisserie
Model: T14045
Rated Voltage: 220-240V ~
Frequency: 50/60Hz
Power consumption: 3100W
Documentation
We declare that this product conforms to the following product legislation in accordance with
the following directive(s):
2014/30/EU Electromagnetic Compatibility (EMC)
2014/35/EU Low Voltage Directive (LVD)
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31)
2015/863/EU Restriction of Hazardous Substances Directive.
(including amendment (EU) 2015/863).
2009/125/EC Eco-design of Energy related Products (ErP)
RK Wholesale LTD Quality Assurance, United Kingdom.
Technical Data:
Specifications:
This box contains:
Instruction Manual
Mini Oven
Wire Rack
Baking Tray
Rotisserie Handle
Rotisserie Fork
Tray Handle
1. Door handle
2. Small hotplate
3. Large hotplate
4. Temperature control
oven
5. Function control
(hotplates)
6. Power indicator
(hotplates)
7. Function control (oven)
8. Power indicator (oven)
9. Timer control
10. Oven Door
11. Wire Rack
12. Rotisserie fork
13. Rotisserie handle
14. Baking tray handle
15. Baking tray
1 2 3

3
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must
be connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!

4
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the
appliance unattended
while it is operating.
• Close supervision is
necessary when any
appliance is used by or
near children or pets.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
• Children should not play
with the appliance.
• Cleaning and user
maintenance should not
be made by children
without supervision.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or before
cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer or its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords or
timers with the appliance
as these could increase
the risk of fire.
• DO NOT pull the plug out
by the cord as this may
damage the plug and/or
the cable.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:

5
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use the
appliance outdoors.
• DO NOT touch hot
surfaces, Use handles or
knobs.
• DO NOT place on or near
gas or electric cookers.
• When operating the oven
keep at least four inches
of space on all sides of
the oven to allow for
adequate air circulation
and ventilation.
• Moving this appliance
whilst it is hot or cooling is
not recommended.
• DO NOT cover any part of
the oven with metal foil.
• DO NOT clean with metal
scouring pads or abrasive
materials as this may
cause damage to the
appliance and may touch
electrical parts, creating a
risk of electric shock to the
user.
• Oversized foods or metal
utensils must not be
inserted in an electric oven
as they may create a fire or
risk of electric shock.
• Ensure that the appliance
is not placed near
combustible materials
such as curtains, blinds
or towels and ensure
that nothing covers this
appliance.
• DO NOT use containers
constructed of anything
other than metal or glass.
• DO NOT place any of the
following materials in the
oven: cardboard, plastic,
paper, or anything similar.
• DO NOT store any
materials, other
than recommended
accessories, in this oven
when hot.
• Always wear protective,
insulated oven gloves
when inserting or
removing items from the
hot oven and remember
that the top of this
appliance may become
very hot.
• Always wear protective,
insulated oven mitts when
handling, inserting or
removing items from the
appliance.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

6
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this information
for future reference.
1. Remove the parts from the packaging.
2. Place the oven on a flat, dry surface.
3. Remove any promotional labels or stickers.
4. Plug in and heat the oven empty for around 10 minutes at 230°C with the upper and lower
heating elements on.
5. Dispose of the packaging in a responsible manner.
6. Your appliance is now ready for normal use.
Note: There may be some smoke and a slight burning smell emitted during first use. This is normal
and just a product of any leftover manufacturing residue. This is not a malfunction and will stop after
the first few uses.
Using Your Appliance:
1. Insert the wire rack or baking tray into the oven, onto the required shelf.
2. Plug the oven in and preheat as required by your recipe.
3. Set the temperature dial and the oven function dial. The front indicator light will show when
the heating elements are on.
4. Using oven gloves, place the food to be cooked into the oven.
5. Set the timer by turning it clockwise.
6. Once the time is up, the timer will ring, reminding you to remove your food from the oven.
Note: Some food may require turning halfway through cooking time. Always follow the instructions
on the food packaging.
Note: You can only use 2 of the functions at any one time, ie: 2 x Hotplate, 1 X Hotplate & Oven &
1 x Hotplate and 1 x Rotisserie.
Using the hotplates:
1. Place a pot or pan onto the desired hotplate.
2. Turn on the hotplate dial, select your required temperature, and then set the required time.
3. When the timer has finished, the hotplates will shut off automatically.
Using the rotisserie:
1. Slide the spit in to the centre of the chicken, beef or any meats, slide the rotisserie forks on to
the spit (forks inwards) securing the forks with the thumb screws so that the meat is tight on
the spit.
2. Set the temperature dial and the oven function dial.
3. Insert the pointed end of the spit into the drive socket, inside the oven. Rest the square end of
the spit on to the spit support, on the opposite inner wall of the oven.
4. Set the timer dial to the desired cooking time.
5. When complete, the timer bell will ring and the timer will turn off.
6. Remove the spit by placing the hooks of the rotisserie handle under the grooves on either side
of the spit.
7. Lift the left side of the spit up and out first, and then pull the spit out of the drive socket and
carefully remove from the oven.
8. Take the food off the spit and place it on a cutting board or platter.
Note: When cooking poultry, it may be necessary to secure both the legs and wings to the body with
butchers twine to make the roast as compact as possible for smooth movement of the rotisserie
spit.

7
Settings:
Turn each dial clockwise to select the setting you require.
Temperature Dial: Set the temperature by turning the temperature dial clockwise to select the
required temperature for your recipe. The temperature control varies between 90°C and 230°C.
Timer Dial: Set the timer by turning the timer dial clockwise to select the required time for your
recipe. The timer can be set from 0 to 90 minutes. The oven will turn off automatically once the
selected time has been reached, and a bell will sound to let you know your food is done.
Alternatively turn the dial anti clockwise to “Stay On”, the oven will be on constantly.
Oven Function Dial: There are seven settings to choose from, depending on what you are going to
cook
Function Control Panel Icon Uses
Heaters off
OFF
Upper heaters Use as a grill when toasting bread and grilling chick-
en, bacon, sausage etc.
Lower heaters This setting can be used for most of the same food
that can be cooked in the conventional oven, but
will take longer to cook the food.
Upper and lower
heaters
Use when roasting meat and vegetables, for ready
meals, casseroles, bread, cakes and more.
Upper and lower
heaters with
rotisserie
Use for rotisserie chicken, kebabs or without rotis-
serie spit as a grill when toasting bread and grilling
chicken, bacon, sausage etc.
Left hotplate
Right hotplate
Both hotplates
Accessories:
The baking tray and rack can be slotted into any of the four slats inside the oven, depending on the
food you want to cook. For example, if you are cooking a roast chicken, you would place the tray on
the lowest slots of oven. If you are cooking a dish and would like the top part browned and cooked
the most, you would place the tray on either the top or second slot.
Note: You can use the accessories in conjunction with one another to cook a full meal.

8
Troubleshooting
Questions Answers
Food is cooking too
slowly, too quickly, or
burning.
The oven temperature may be too low or high.
If food is cooking too quickly, try lowering the shelf. If food is cooking too
slowly, move the shelf up.
Steam is coming
from the oven.
This is a normal occurrence when cooking foods with high water
content.
Take care when opening the oven as steam may escape when you open
the door.
The oven is not
cooking evenly.
Check you are using the correct temperature for the recipe as the
temperature may be too high.
The food/dish may not be placed centrally on the tray.
There is a smell of
burning in the oven.
There may be a build-up of grease in the oven or on the wire rack.
Always wipe down the oven inside after use, once it has cooled
completely. Always wash the wire rack after each use to remove any
grease build-up.
My roast chicken will
not fit neatly on the
rotisserie.
It’s important to truss your chicken so it is compact and fits nicely onto
the spit.
Cleaning & Care
It is important that you clean the appliance after each use to prevent an accumulation of grease and
avoid unpleasant odours.
• Excess grime may also increase the cooking times.
• Allow the appliance to cool and unplug from outlet before cleaning.
• Do not use abrasive cleaners or sharp utensils to clean the oven, as scratching may weaken it
and cause shattering.
Inner:
Wipe the inside of the oven with a hot, damp sponge cloth. Dry before next use. A mild spray or
oven cleaner can be used. Apply to the sponge, not the oven.
Outer Casing and Hobs:
Clean outside of appliance and the hobs with a damp sponge and dry with a clean towel.
Door:
Wipe the glass with a hot damp sponge. Clean the glass with a glass cleaner spray if desired. Dry
with a clean towel.
Accessories:
The wire rack, rotisserie fork, rotisserie handle, baking tray and tray handle can all be washed as
normal kitchenware. Let all parts and surfaces dry thoroughly prior to plugging oven in and using.
IMPORTANT:
Do not use the appliance if damp. Ensure the appliance is completely clean and dry before storing.
To store your appliance:
• Unplug power cord from the power outlet and clean as instructed.
• Store on a flat, dry level surface out of reach of children.

9
NOTES

10
NOTES

11
NOTES

0321.V2
thank you!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to
the place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the
product with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each
qualifying product needs to be registered individually in order to extend its warranty past the
standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
[phone]
