Cookology FOD60SS User manual

Instruction Manual
BUILT-IN OVEN
MODEL:
FOD60SS
FOD60BK

1）The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction. children being supervised not to
play with the appliance.
2）During use the appliances becomes hot. Care should be taken to avoid touching
heating elements inside the oven, for cooking ranges and ovens.
3）WARNING: Accessible parts may become hot during use. Young children should
be kept away.
4）Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass since they can scratch the surface, which may result in shattering of the
glass.
5）If during the test of Clause 11, the temperature rise at the centre of the internal
bottom surface of a storage drawer exceeds that specified for handles held for short
periods in normal use, the instruction shall state that these surfaces can get hot.
6）The oven must be switched off before removing the guard and that, after
cleaning, the guard must be replaced in accordance with the instructions.
7）Details indicating the correct installation of the shelves.
8）A steam cleaner is not be used.
9）Ensure that the appliance is switched off before replacing the lamp to avoid the
possibility of electric shock.
10）The appliance must not be installed behind a decorative door in order to avoid
overheating.
11）Disconnection of the appliance after installation, by accessible plug or a switch
in the fixed wiring.
12）If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
13）This appliance should be connected to a circuit which incorporates an isolating
switch which can accessible by the user after installation providing full disconnection
from the power supply. The disconnection may be achieved by incorporating a
Warning

switch in the fixed wiring in accordance with the wiring rules.
14）This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. children shall not
play with the appliance. cleaning and user maintenance shall not be made by
children without supervision.
15）WARNING: The appliance and its accessible parts become hot during use.
16）Care should be taken to avoid touching heating elements.
17）Children less than 8 years of age shall be kept away unless continuously
supervised.
18) This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Warning
19）If using alcohol in your recipes, please be aware that high temperatures can
cause the alcohol to vaporize and even to ignite on the hot heating elements.
20）When residual heat is used to keep food warm, the high level of humidity and
condensation can cause corrosion in the oven. The control panel, worktop or
furniture unit may also be damaged. Do not switch the oven off completely while
food is inside it , but select the lowest possible temperature for the oven function
you are using. This will ensure the fan will automatically continue to run.
21）Cover any food which is left in the oven to be kept hot, as moisture in the food
could lead to corrosion damage in the oven. This also prevents the food from drying
out.
22）Never cover the floor of the oven with aluminium foil, or place oven dishes, pans,
saucepans or trays directly onto the floor of the oven.
This would cause concentrations of heat which could cause damage to the floor of
the oven.

1
DEAR CUSTOMER,
The oven is exceptionally easy to use and extremely efficient.After reading the instruction
manual,operating the oven will be easy.
Before being packaged and leaving the manufacturer,the oven was thoroughly checked with
regard to safety and functionality.
Before using the appliance,please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for household use only.
The manufacturer reserves the right to introduce changes which do not affect
the operation of the appliance.

2
TABLE OF CONTENTS
Safety instructions.......................................................................................3
Specifications of the appliance........................................................................7
Installation.................................................................................................8
Operation....................................................................................................1 0
Cleaning and maintenance.........................................................................
Openration in case of emergency..................................................................
Technical data...............................................................................................
20
24
23

3
SAFETY INSTRUCTIONS
NOTE;
Ensure there is a grounded socket nearby(behind the unit)
A dedicated power circuit is recommended for the unit but not required.Additional electrical
appliances on the same circuit may exceed the current(amperage)rating for that circuit.If after
the installation of your unit.the circuit breaker trips or the fuse fails on a repeated basis,then
a dedicated circuit will likely be required.
!The appliance must be installed only by a qualified person in compliance with the
instructions provided.Incorrect installation may cause harm to persons,animals or may
damage property.
The manufacturer declines all responsibility for improper
installation which may harm persons and animals and damage property.
Important:The power supply to the appliance must be cut off before any adjustments or
maintenance work is done on it.
WARNING:
When using this product,basic precautions should always be taken,including the following:
Your built-in oven is a classified electrical appliance.As with any electrical appliance and
particularly with electric heaters,basic precautions must be followed in order to reduce the risk
of fire,burns,electrical shocks and/or other serious injuries or death.
! The appliance becomes hot during operation.Take care not to touch the hot parts inside
the oven.
! This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
While in operation direct contact with the cooker may cause burns!
! Ensure that small items of household equipment,including connection leads,do not touch
the hot oven or the hob as the insulation material of this equipment is usually not resistant
to high temperatures.
! Do not leave the cooker unattended when frying.Oils and fats may catch fire due to
overheating or boiling over.
Do not put pans weighing over 15 Kg on the opened door of the oven and pans over 25
kg on the hob.
! Do not use harsh cleaning agents or sharp metal objects to clean the door as they can
scratch the surface,which could then result in the glass cracking.
! Do not use the cooker in the event of a technical fault.Any faults must be fixed by an
appropriately qualified and authorised person.
! In the event of any incident caused by a technical fault,disconnect the power and report
the fault to the service centre to be repaired.
! The rules and provisions contained in this instruction manual should be strictly observed.
Do not allow anybody who is not familiar with the contents of this instruction manual to
operate the cooker.
! The cooker should not be cleaned using steam cleaning equipment.

4
SAFETY INSTRUCTIONS
! The panels adjacent to the oven must be made of heat-resistant material.
! Cabinets with a veneer exterior must be assembled with glues which can withstand temp-
erature of up to 100℃.
! Keep combustible materials,such as:curtains,drapes,furniture,pillows,clothing,linens,bedding,
paper,etc.,at least 3 feet(0.9 meters)from the front sides and rear of the heater.Do not use
this unit in areas where gasoline,paint or other flammable liquids or their associated vapors
may be present.
! To reduce the risk of fire,do not place or install this unit in areas where the ventilation or
circulation ducts may become blocked.
! The unit's power cord must be connected to a properly grounded and protected,220-240V
electrical outlet.Always use ground fault protection where required by the electrical code.To
reduce the risk of fire,avoid running the power cord under rugs,carpets,etc.Keep the power
cord away from high traffic areas where it may pose as a tripping hazard.
! Avoid the use of an extension cord,which may overheat and cause a fire.
! When transporting or storing the unit,keep it in a dry location,free from dust,excessive
vibration or other factors,which may damage the unit.
! Do not operate any oven with a damaged cord or plug or after the heater malfunctions,has
been dropped or damaged in any manner.Return the oven to an authorised service centre to be
checked.
! If the supply cord is damaged, it must be replaced by a special cord or assembly available from
the manufacturer or its service agent.
! Use this oven only as described in this manual.Any other use not recommended by the
manufacturer may cause fire,electric shock,or injury to persons.
!This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
! Never add cold water to food on a hot universal tray or baking tray or directly onto food in a hot
oven.The steam created could cause serious burns or scalding and the sudden change in
temperature can damage the enamel.
! Do not lift the oven by the handle.

5
HOW TO SAVE ENERGY
Using energy in a respon-
sible way not only saves
money but also helps the
environment.So let's save
energy!And this is how you
can do it:
! Do not uncover the pan too often
(a watched pot never boils!)
Do not open the oven door unnecessarily
often.
! Switch off the oven in good time and
make use of residual heat.
For long cooking times,switch off heating
zones 5 to 10 minutes before finishing
cooking,This saves up to 20% on energy.
Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
! Make use of residual heat from the
oven.
If the cooking time is greater than 40
minutes switch off the oven 10 minutes
before the end time.
Important!When using the timer,set
appropriately shorter cooking times
according to the dish being
prepared.
! Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals.Clean up any spillages immediately.
! Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.

6
UNPACKING DISPOSAL OF THE APPLIANCE
During transportation,protec-
tive packaging was used to
protect the appliance against
any damage.After unpack-
ing,please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly;they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking,the packag-
ing materials(polythene bags,polystyrene
pieces,etc.)should be kept out of reach of
children.
Old appliances should not sim-
ply be disposed of with normal
household waste,but should
be delivered to a collection and
recycling centre for electric and
electronic equipment.A symbol
shown on the product,the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this.By recycling materials or
other parts from used devices you are making
a significant contribution to the protection of
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.
▲
▲

7
SPECIFICATIONS OF THE APPLIANCE

8
600
530
Product Dimensions
Height: 595mm
Width: 595mm
Depth: 530mm
Aperture Dimensions
600mm
560mm
560mm(min)

9
The oven is manufactured to work with single-
Fitting guidelines
phase alternating current(220V-240V/
50Hz).The connection diagram is also found on
the cover of the connection box. Remem-ber
that the connection wire should match the
connection type and the power rating of the
oven.

10
OPERATION
Before first use
! Remove packaging,clean the interior
of the oven.
! Take out and wash the oven fittings
with warm water and a little washing-
up liquid.
! Switch on the ventilation in the room
or open a window.
! Heat the oven (to a temperature of
250℃, for approx,30 min.),remove any
stains and wash carefully.
Important!
The inside of the oven should only be
washed with warm water and a small
amount of wash-ing-up liquid.

11
OPERATION
Main Body

12
3
1 Oven function selection knob
2 Temperature control knob
3 Oven door handle
4 Yellow function operation signal light
5 Red temperature regulator signal light
6 Keep-press
7 Display
45
6
7

12
OPERATION
Control Panle
1) Oven function selector knob
2) Thermostat control knob
3) Minute minder button
4) Duration button
5) End cook button
6) Manual operation button
7) Minus button
8) Plus button
9) LED display
A) Power indicator light
B) Oven operating light
10 Auto funciton symbol
11 Minute minder symbol
12 Manual operation symbol
1 2
3 4 5 6 7 8
9
A B
A
U
T
O
12
11
10

13
OPERATION
Selecting manual operation mode
After your appliance is connected to your mains supply for the first time, the numbers on the timer
display will flash. Before you can select a cooking function or set a temperature, you must set the
appliance into “manual operation” mode.
·To select manual operation mode, press the manual operation button (6) on the control
panel.
Setting clock ( the time of day )
After setting your oven for manual operation, you should also set the time of day.
·After pressing the manual operation button (6), use the minus button (7) and plus button
(8) to adjust the time that appears in the display. After getting the display to the correct
time, release the minus and plus buttons. After a few seconds the time will fix in the display
and you will be able to use your oven.
The oven timer
·Only the minute minder can be used with the defrost oven function. None of the other
timer modes will work with the defrost function.
Before first use
·To remove any residue from the oven that may have been left from the manufacturing process, you
should select the fan oven function and set the thermostat to its maximum temperature setting.
·It is perfectly normal for a smell to be produced during this process.
·You should make sure that any windows in the room are left open during this process.
·It is advisable for you not to remain in the room whilst the burning off process is taking place.
·You should leave the oven on maximum setting for 30 – 40 minutes.
·After the oven cavity has cooled, it should then be cleaned with warm soapy water, using either a
sponge or soft cloth. No abrasive cleaners should be used.
·Outer parts of the oven should be cleaned with warm soapy water, using either a sponge or soft
cloth. No abrasive cleaners should be used.
·We would recommend that an appropriate stainless steel cleaner and polish is regularly used on the
stainless steel surfaces of this appliance.
Setting the minute minder function
You are able to set the minute minder at any time, regardless of whether an oven function
has been selected. You can set a period of time using the minute minder function and an
alarm will sound when that period of time has elapsed.
·Press the minute minder button (3), the display will show a value of 00:00. Set the period
of time that you wish the minute minder to countdown for, by using the minus (7) and plus
(8) buttons.

OPERATION
14
·Use the thermostat control knob (2) to set the temperature that you require. The duration
symbol (12) will appear on the display.
·Use the oven function selector knob (1) to select the mode of cooking that you require.
·It is then possible to set the duration of the cooking time that you require.
·Press the duration button (4) and the display will show a value of 00:00. Set the period of
time that you wish the duration function to countdown for, by using the minus (7) and plus
(8) buttons.
·Once the display has got to your desired countdown time, let go of the minus and plus
buttons. The countdown will start immediately and the word AUTO will appear on the timer
display.
·Once a countdown time has been set, it is possible to shorten or lengthen the time by
using the minus or plus buttons.
·An alarm will sound when the countdown time has elapsed and the oven will switch off.
The word AUTO will flash and the heating symbol will disappear. The alarm can be silenced
by pressing the duration button.
·You will need to return the oven to manual operation mode, once the duration function
has been used. To do this you should press the “manual operation” button, the word AUTO
will disappear from the display and the manual operation symbol will appear instead.
·Important: If you do not turn the thermostat control knob and oven function selector knob
to 0, then the appliance will continue to operate as soon as you press the manual operation
button.
·Once the display has got to your desired countdown time, let go of the minus and plus buttons.
The minute minder symbol (11) will appear on the timer display.
·Once a countdown time has been set, it is possible to shorten or lengthen the time by using the
minus or plus buttons.
·An alarm will sound when the countdown time has elapsed. The alarm can be silenced by
pressing the minute minder button.
·Important: The oven will continue to heat once the alarm has been silenced. If you have
finished cooking, then you should turn the oven function selector and thermostat control knob to 0.
Setting the duration function
This function will allow you to set a countdown time similar to the minute minder function.
However the oven will no longer continue to heat, once the countdown period has elapsed.

OPERATION
15
·When the time of day reaches the end of cooking time that you set, the oven will switch
off and an alarm will sound. The word AUTO will flash and the heating symbol will
disappear. The alarm can be silenced by pressing the “end cook” button.
·You will need to return the oven to manual operation mode, once the end cook function
has been used. To do this you should press the manual operation button, the word AUTO
will disappear from the display and the manual operation symbol will appear instead.
·Important: If you do not turn the thermostat control knob and oven function selector
knob to 0, then the appliance will continue to operate as soon as you press the “manual
operation” button.
Setting the start and end time function
This function will allow you to set a time in the future that the oven switches on at and
a time that the oven will switch off at.
·Use the thermostat control knob (2) to set the temperature that you require. The duration symbol
(12) will appear on the display.
·Use the oven function selector knob (1) to select the mode of cooking that you require.
·Press the duration button (4) and the display will show a value of 00:00. Set the period of time
that you wish to cook for, by using the minus (7) and plus (8) buttons. The word AUTO will appear
on the timer display.
·Immediately press the end cook button (5) and the timer display will show a calculated end of
cooking time. Set the time of day that you want the oven to switch off at, using the minus and plus
buttons.
Setting the end cook function
This function is similar to the duration function, however instead of selecting a period of time
that you wish the oven to switch off after. You select the time of day that you wish the oven to
switch off at.
·Use the thermostat control knob (2) to set the temperature that you require. The duration
symbol (12) will appear on the display.
·Use the oven function selector knob (1) to select the mode of cooking that you require.
·Press the end cook button (5) and the display will show the current time of day. Set the
time of day that you wish the oven to stop cooking at by using the minus (7) and plus (8)
buttons. The timer will calculate how long the cooking time will be, based on the time of day
that you have selected and show it on the display.
·Once the display has got to the time of day that you want the oven to stop cooking at, let
go of the minus and plus buttons. The countdown will start immediately and the word AUTO
will appear on the timer display.
·When the time is set, it can be modified by pressing the minus and plus buttons.

OPERATION
16
·The oven will calculate what time it needs to switch on at, so that your food will cook for
the length of time that you selected. It will automatically switch itself on, once it reaches the
time of day that it has calculated.
·When the time of day reaches the end of cooking time that you set, the oven will switch
off and an alarm will sound. The word AUTO will flash and the heating symbol will
disappear. The alarm can be silenced by pressing the end cook or duration button.
·You will need to return the oven to manual operation mode, once the start and end time
function has been used. To do this you should press the manual operation button, the word
AUTO will disappear from the display and the manual operation symbol will appear instead.
·Important: If you do not turn the thermostat control knob and oven function selector
knob to 0, then the appliance will continue to operate as soon as you press the manual
operation button.

OPERATION
17
50
100
150
200
250
