Toyota TUNDRA 2008 User manual

MN 00505-QRG08-TUN
Printed in the USA 9/07
Customer Experience Center
1-800-331-4331
2008
Quick Reference Guide

This iGuide is not intended as a substitute for the Owner’s Manual
located in the vehicle’s glove box. We strongly encourage you to
review the Owner’s Manual and supplementary manuals so you will
have a better understanding of the vehicle’s capabilities and
limitations. Important Cautions, to help you avoid injuries, and
Notices, to help you avoid equipment damage or malfunction, can
also be found in the Owner’s Manual.
www.ToyotaiGuide.com
Interactive Owner’s Guide
Have a question about the main features of your new Toyota? Find
the answers quickly and easily in this Quick Reference Guide, which
includes highlights from the Owner’s Manual. For more detailed
information, and helpful interactive demonstrations and tips, visit
www.Toyotaiguide.com. This user-friendly website makes learning
all about your new vehicle fun and easy.
29
Spare tire & tools
Tool location
Removing the spare tire
(1) Assemble the jack handle.
(2) Insert the jack handle end into the lowering screw.
(3) Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and jack positioning
procedures.
Regular cab models
-behind the right seatback
Double cab models
-under the right rear seats
with storage box
Tool bag
Jack
Tool bag
Jack
Tool bag
Jack
Moving the lever to “LOCK” will allow the door to be opened only from
the outside.
Rear door
Double cab models
-under the right rear seats
without storage box
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Doors-Child safety locks
(double cab and Crew Max models)
Crew Max models
-behind the right rear seatback
Tool bag
Jack
(1) (2)
(3)

1
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
2008 Tundra Quick Reference Guide
Engine maintenance 8
Fuel tank door release and cap 7
Hood release 7
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry16
Light control-Instrument panel 6
Accessory meter 25
Air Conditioning/Heating 20-21
Audio 22-23
Auto LSD (Auto Limited Slip Differential) 27
Automatic Transmission 9
Bottle holders 27
Cruise control 25
Cup holders 26
Door locks 10
Four-wheel drive 10
Garage door opener (HomeLink®)321
Lights1& turn signals 16
Mirrors-Power side view 10
Moonroof 12
Multi-information display218
Parking brake 26
Power outlets-12V DC 17
Power outlets-115V AC 17
Rear seat entertainment system 24
Seat adjustments-Front 12-13
Seat adjustments-Rear 13
Seat heaters 20
Seats-Folding 14-15
Seats-Head restraints 14
Telephone controls (Bluetooth®)24
Tilt and telescopic steering wheel 11
“TOW/HAUL” switch 11
Window-Rear 19
Windows-Power 19
Windshield wipers & washers 15
Doors-Child safety locks 29
Seat belts 28
Seat belts-Shoulder belt anchor 28
Spare tire & tools 29
Tire Pressure Warning System 28
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
1Visit your Toyota dealer for information on customizing this feature.
2 Programmable by customer. Refer to the Owner’s Manual for instructions and
more information.
3HomeLink®is a registered trademark of Johnson Controls, Inc.

2
OVERVIEW
Instrument panel
Steering wheel audio controls1
Telephone controls1
Voice command button1,2
Headlight and turn signal controls
Wiper and washer controls
Multi-information display/Accessory meter control buttons
Intuitive parking assist button1
Emergency flasher button
Audio system or navigation system-integrated audio system1,2
Outside rearview mirror/Back window defogger button1
Front passenger seat belt reminder
Front passenger occupant classification indicator or front passenger
airbag ON/OFF indicator1
Seat heater controls1
Air Conditioning controls
12V DC Power outlet
AUX audio jack
Cigarette lighter/12V DC Power outlet
Steering wheel
controls (if equipped)

3
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Bench seat
Separate seat with manual
Air Conditioning system
“TOW/HAUL” button1
Two-wheel/Four-wheel drive selector1
Tire Pressure Warning System reset
“VSC OFF” button
115V AC Power outlet ON/OFF switch1
Cruise control1
Engine switch
Accessory meter1
Theft deterrent system/Engine immobilizer indicator1
Intuitive parking assist indicator1
Front passenger airbag manual ON/OFF switch1 (in glove box)
Instrument panel light control
Interior light/Personal light main switch
“RSCA OFF” switch
Power back window switch1
Cargo lamp switch
Power rearview mirror control1
1If equipped
2For details, refer to the “Navigation System Owner’s Manual.”

4
OVERVIEW
Indicator symbols
Instrument cluster
Tachometer
Service indicator and reminder
Speedometer
Fuel gauge
Voltmeter
Oil pressure gauge
Engine coolant temperature
Trip meter reset knob
Odometer and two trip meters
Multi-information display
Automatic Transmission shift position indicator
Automatic Transmission shift range display
Automatic Transmission fluid temperature gauge
Without multi-information display
With multi-information display
Driver/Front passenger seat belt reminder1
(alarm will sound if speed is over 12 mph)
Charging system warning1
Brake system warning1
Front passenger occupant classification or front passenger airbag
ON/OFF indicator
1For details, refer to “Service reminder indicators and warning buzzers,” Section 1-6, 2008
Owner’s Manual.
2If this light flashes, refer to “Four-wheel drive system,” Section 1-7, 2008 Owner’s Manual.

5
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Low engine oil pressure warning1
Malfunction/Check Engine indicator1
Engine oil replacement reminder1
3If this light flashes, refer to “Cruise control,” Section 1-7, 2008 Owner’s Manual.
4If this light flashes, refer to “Roll sensing of curtain shield airbags off switch,” Section 1-3,
2008 Owner’s Manual.
Anti-lock Brake System warning1
Headlight low/high beam indicator
Turn signal indicator
High/Low speed four-wheel drive indicator2
Slip indicator
Vehicle Stability Control “OFF” indicator/warning1
TOW/HAUL mode indicator
“AUTO LSD” indicator
Cruise control indicator3
Automatic Transmission fluid temperature warning1
Low Tire Pressure Warning1
Theft deterrent/Engine immobilizer system indicator
Low fuel level warning1
Open door warning1
Roll Sensing Curtain Airbags OFF indicator4
Airbag SRS warning1
Master warning1
Low windshield washer fluid level warning1

6
OVERVIEW
Keyless entry
Panic button
NOTE: If a door is not opened within
30 seconds of unlocking, all doors
will relock for safety.
Push
Push and hold
Push ONCE: Driver door
TWICE: All doors
Locking operation Unlocking operation
Light control-Instrument panel
Brightness
control
-
+

7
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Fuel tank door release and cap
Hood release
Pull up latch and
raise hood
Pull
NOTE: Tighten until one click is
heard. If the cap is not sealed
properly, Check Engine “ ”
indicator may illuminate.
Pull
Tu r n
Store

8
OVERVIEW
Windshield washer fluid tank
Power steering fluid reservoir
Engine oil level dipstick
Engine coolant reservoir
Engine oil filler cap
Note: Regularly scheduled maintenance, including oil changes, will
help extend the life of your vehicle and maintain performance.
Please refer to the “Owner’s Warranty Information Booklet,”
“Scheduled Maintenance Guide” or “Owner’s Manual
Supplement.”
Engine maintenance
6 cylinder (1GR-FE) engine
4.7L 8 cylinder (2UZ-FE) engine
5.7L 8 cylinder (3UR-FE) engine

9
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS
Automatic Transmission
* The engine switch must be set at ON and the brake pedal depressed to
shift from “Park.”
Downshifting increases power going uphill, or provides engine braking
downhill. For best fuel economy during normal driving conditions, always
drive with the shift lever in the “D” position.
Floor shift type:
+: Upshift (push and release)
-: Downshift (pull and release)
Column shift type:
+: Upshift (turn up and release)
-: Downshift (turn down and release)
“S” (Sequential) mode
Shift the shift lever to “S” position from “D” position.
Floor shift type
Column shift type
Park*
Reverse
Neutral
Drive
“S” mode
“S”
“D”
Park*
Reverse
Neutral
Drive
“S” mode
+ (“S” mode)
- (“S” mode)

10
FEATURES/OPERATIONS
Four-wheel drive (if equipped)
High speed (2WD)
High speed (4WD)
Turn to “4H” with speed below 62 mph.
Low speed (4WD)
Shift to “N” position when stopped, then push and turn to “4L.”
WD
For best fuel economy and performance under normal driving conditions,
keep in “2WD” position.
Push
and turn
Tu r n
Tu r n
Mirrors-Power side view (if equipped)
Fold mirrors in
Return mirrors to
original position
Adjust
Select left or right
Key must be in the “ACC” or “ON” position.
Door locks (if equipped)
Lock
Unlock

11
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Hold wheel, push lever down, set angle and length, and return lever.
Manual
Tilt steering wheel Tilt and telescopic steering wheel
Tilt and telescopic (if equipped)
steering wheel
Angle
Length
Lock release lever
Lock release lever
Angle
Push the control switch, set angle and length.
Note: Do not attempt to adjust while the vehicle is in motion.
Power
Angle
Control switch
Length
Control switch
“TOW/HAUL” switch (if equipped)
Tow/Haul mode can be used when carrying heavy loads. As fuel economy
is reduced while in Tow/Haul mode, deactivating when driving without a
load is recommended.
Refer to the Owner‘s Manual for more details on this system before
attempting to use it.
Floor shift type
System ON/OFF
Column shift type
System
ON/OFF

12
FEATURES/OPERATIONS
Seat adjustments-Front
Manual seat
Separate seat
-Regular cab model
Separate seat
-Double cab and Crew Max models
Bench seat
-Regular cab model
Bench seat
-Double cab and Crew Max models
Moonroof (if equipped)
Sliding operation Tilting operation
Open Tilt
Close Close

13
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Seat adjustments-Rear
Position
Seatback angle and fold
Position
Seatback angle
Seat cushion angle
Seat height
Lumbar support*
Seatback angle (side)
Seatback angle (center)
Leg support
Position, cushion angle and height
* If equipped
Power seat

14
FEATURES/OPERATIONS
Seats-Folding
Front (regular cab model)
(1) Pull
(2) Pull
Seats-Head restraints
Front-Separate seat (type B)
Front-Separate seat (type A)
Lock release button Lock release button
(1)
(2)
Rear (double cab model)
Front-Bench seat
Lock release button
Lock release button
Rear (Crew Max model)
Lock release button

15
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Rear (double cab model)
(2)
(3) Lift up
Pull
(2)
(1) Stow
(3) Pull and
fold down
Rear (Crew Max model)
Windshield wipers & washers
With intermittent wiper Without intermittent wiper
Interval wipe
Single wipe
Slow
Fast
Pull to wash
and wipe
Adjust interval
Pull to wash
and wipe
Single wipe
Slow
Fast
(1) Stow

16
FEATURES/OPERATIONS
Lights & turn signals
Turn signals
Headlights
High beam flasher
Low beam
Front fog lights (if equipped)
Headlights
* If equipped
-Daytime Running Light system (DRL)(if equipped) Automatically turns
on the turn signal lights at a reduced intensity.
-Automatic light cut off system Automatically turns lights off after a
delay of 30 seconds, or the lock switch on remote may be pushed.
Front fog lights come on only when the headlights are on low beam.
Parking lights
Right turn
Tu r n
Lane change
Lane change
Left turn
High beam
Auto*
Headlights
Parking lights

17
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Power outlets-12V DC (if equipped)
Separate seats
Bench seat
Instrument panel Under the seat cushion
of the front center seat
Back of the center console box
(Crew Max model)
Instrument panel Inside of the center console box
Back of the front center seat
(Crew Max model)
Key must be in the “ACC” or “ON” position to be used.
Power outlets-115V AC (if equipped)
ON/OFF switch
Back of the center
console box Back of the front
center seat
Push
Back of the center
console box
Back of the front center seat

18
FEATURES/OPERATIONS
Multi-information display (if equipped)
Push “INFO” to change information in the following:
(1) Zoom display of odometer and trip meter
(2) Average gas mileage
(3) Current gas mileage
(4) Miles left on remaining fuel
(5) Running time from engine start
(6) Average vehicle speed
Push “SETUP US/M” to customize to the following settings:
(1) KEYLESS ENTRY FEEDBACK
(2) KEYLESS ENTRY RELOCK TIMER
(3) KEYLESS ENTRY ALL DOORS UNLOCK
(4) DOOR AUTO LOCKING
(5) DOOR AUTO UNLOCKING
(6) HEADLAMPS AUTO OFF TIMER
(7) COURTESY LAMPS OFF TIMER
(8) DEFAULT SETTING
