Toyota Tundra 2020 User manual

QUICK
REFERENCE
GUIDE
2020

TUNDRA
2020
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in your vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and sup-
plementary manuals so you will have a better understanding of
your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor North
America, Inc. wish you many years of satised driving in your
new Tundra.
A word about safe vehicle operations
This Quick Reference Guide is not a full description of Tundra operations.
Every Tundra owner should review the Owner’s Manual that accompanies this
vehicle.
Pay special attention to the boxed information highlighted in color throughout
the Owner’s Manual. Each box contains safe operating instructions to help you
avoid injury or equipment malfunction.
All information in this Quick Reference Guide is current at the time of printing.
Toyota reserves the right to make changes at any time without notice.

1
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
INDEX
Engine maintenance 8
Fuel tank door release & cap 7
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Instrument panel light control 8
Keyless entry16
Smart Key system1,2 7
OVERVIEW
FEATURES & OPERATIONS
FEATURES & OPERATIONS (continued)
SAFETY & EMERGENCY FEATURES
Air conditioning/heating 18
Audio 20
Auto lock/unlock1 9
Automatic transmission 10
Bottle holders 28
Blind Spot Monitor with Rear
Cross Trafc Alert (BSM w/RCTA) 26
Cup holders 29
Door locks 11
Garage door opener (HomeLink®)3 28
Headlight leveling dial 13
Intuitive parking assist 27
Lights1& turn signals 12
Mirrors-Power outside rear view 9
Moonroof 14
Multi-Information Display (MID)221
Parking brake 14
Power outlets-12V DC 22
Rear view monitor system 19
Seat adjustments-Front 16-17
Seat folding-Rear 17
Seat heaters/ventilators 19
Seats-Head restraints 17
Steering lock release 14
Steering wheel switches &
telephone controls (Bluetooth®) 23
Tilt & telescopic steering wheel 11
TOW/HAUL switch 25
Trailer brake controller 24
Two & four-wheel drive selector 24
USB charge-ports 20
USB media port 21
Vehicle Stability Control (VSC)
OFF switch 26
Window-Power back 15
Windows-Power 15
Windshield wipers & washers 13
Floor mat installation 45
Rear door child safety locks 42
Safety Connect 42
Seat belts 41
Seat belts-Shoulder belt anchor 41
Spare tire & tools 43
Star Safety System 44-45
Trailer Sway Control 45
Tire Pressure Monitoring
(warning) System (TPMS) 41
BLUETOOTH®DEVICE
PAIRING SECTION 46-48
1Visit your Toyota dealer for information on customizing this feature.
2 Programmable by customer. Refer to the Owner’s Manual for instructions and more information.
3HomeLink®is a registered trademark of Gentex Corporation.
TOYOTA SAFETY SENSE™ P (TSS-P)
Automatic High Beams (AHB) 40
Dynamic Radar
Cruise Control (DRCC) 37-39
Lane Departure Alert (LDA) 33-36
Pre-Collision System with
Pedestrian Detection (PCS w/PD) 31-33
Quick overview-
Toyota Safety Sense™ P (TSS-P) 30
Sensors 30

2
Instrument panel
OVERVIEW
Power tilt and telescopic steering
control switch1
Automatic High Beam (AHB) switch
Power rearview mirror controls1
Personal/Interior lights main switch
Headlight leveling dial
Power back window switch1
Cargo lamp main switch
Tilt and telescopic steering lock release lever1
(below the steering wheel)
Hood lock release lever
Parking brake
Headlight/turn signal/
front fog light1control
Steering wheel controls
Audio control switches2
Telephone controls2
Voice command switch2Meter control switches
Dynamic Radar
Cruise Control (DRCC)
Vehicle-to-vehicle
distance switch
Lane Departure Alert (LDA)
switch
Dynamic Radar Cruise
Control (DRCC) switch
Multi-Information Display (MID)
Meters

3
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
1If equipped.
2 For details, refer to the “Navigation and Multimedia System Owner’s Manual” or
visit www.toyota.com/audio-multimedia for additional resources.
NOTE: Instrument panel features depend on the seat option, split seats or bench.
Refer to the Owner’s Manual for more details.
Automatic transmission shift lever1
Windshield wiper and washer control
Two and four-wheel drive selector1
Audio/Navigation system2
USB port2
USB charging ports
VSC OFF switch Intuitive parking assist switch1
Power outlte-12V DC
Emergency flasher switch
Air conditioning/heating controls1
Tire Pressure Monitoring (warning)
System (TPMS) reset switch
Trailer brake controller1
Automatic shift lever1
TOW/HAUL switch1
Ignition
switch1
“ENGINE
START
STOP”
switch1

4
Instrument cluster
For details, refer to “Indicators and warning lights,” Section 2, 2020 Owner’s
Manual.
Multi-Information Display
Speedometer
Outside temperature display
Fuel gauge
ODO/TRIP display switch
Shift position and range display
Odometer and trip meter display
Instrument panel light control button
Oil pressure gauge
Engine coolant temperature gauge
Voltmeter
Tachometer
Air bag SRS warning1
AIR BAG ON and
AIR BAG OFF indicators1
BSM outside rearview mirror
indicators4
Indicator symbols
Automatic High Beam (AHB)
indicator
Blind Spot Monitor (BSM)
indicator4
Arrow direction indicates fuel
tank door position
AUTO Limited Slip Differential
(LSD) indicator1
Anti-lock Brake System (ABS)
warning1
OVERVIEW
Service indicators and reminders

5
Security indicator
Slip indicator1,3
Charging system warning1
Brake system warning1
Malfunction/Check Engine indicator1
Low fuel level warning
Master warning1,2
Trailer connection indicator4 (green)
Turn signal indicator
Vehicle Stability Control (VSC)
OFF indicator1
TOW/HAUL mode indicator
Low Tire Pressure Warning1
Fog light indicator
Brake Override System/
Drive-Start Control warning
BSM w/Rear Cross Traffic Alert
(RCTA)4
High engine coolant
temperature warning
TRAC OFF indicator1
Lane Departure Alert (LDA)
indicator [Green/Yellow3]
Pre-Collision System (PCS)
warning1,2
Low windshield washer fluid
warning
Low outside temperature
indicator
Parking brake indicator1,2
High/Low speed four-wheel
drive indicator4
1If the indicator does not turn off within a few seconds of starting the engine, there may be a
malfunction. Have the vehicle inspected by your Toyota dealer.
2If the indicator flashes, there may be a malfunction. Refer to the Owner’s Manual.
3If the indicator flashes, it indicates that the system is operating.
4If equipped.
Driver/Front passenger’s seat belt
reminder (alarm will sound if speed is
over 12 mph)
Constant speed cruise control
indicator/Constant speed
cruise control SET indicator
Dynamic Radar Cruise Control
(DRCC) indicator/DRCC SET
indicator
Headlight low/high beam
indicators
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES

6
Keyless entry
OVERVIEW
Push
UNLOCKING OPERATION
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for
safety.
Push
LOCKING OPERATION
Push and hold
PANIC BUTTON
Smart Key
Smart Key
Smart Key
Push ONCE: Driver door
TWICE: All doors
Carry Smart
Key remote
Grasp
Front door unlock*
All-door lock
Touch
Carry Smart
Key remote
* Driver door unlocking function can be programmed to unlock driver door only,
or all doors. In some models, grasping front passenger door handle will unlock all
doors.
Please refer to the Owner’s Manual for more details on how to program the doors.
NOTE: Doors may also be locked/unlocked using remote.

7
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
Fuel tank door release & cap
NOTE: Tighten until one click is heard.
If the cap is not tightened enough,
Check Engine “ ” indicator may
illuminate.
Pull
Turn to open
Store
Smart Key system
NOTE: The Smart Key must be carried to enable the start function. With the
gear shift lever in Park and the brake pedal depressed, push the “ENGINE
START STOP” switch.
Without depressing the brake pedal, pressing the “ENGINE START STOP” switch
will change the operation mode in succession from:
Off - All systems OFF. Emergency flashers can be used.
Accessory – Some electrical components can be used.
On - All electrical components can be used.
START FUNCTION
POWER (WITHOUT STARTING ENGINE)

8
OVERVIEW
Hood release
Pull up latch and
raise hood
Pull
Windshield washer fluid tank Engine coolant reservoir Engine oil filler capEngine oil level dipstick
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer
to the “Warranty & Maintenance Guide.”
Engine maintenance
Brightness control
Instrument panel light control

9
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
FEATURES & OPERATIONS
Mirrors-Power outside rear view (if equipped)
Mirrors can be manually slid outward to improve visibility while towing.
Adjust up,
down, left
and right
Select left
or right
Key must be in the “ACC” or “ON” position.
Refer to the Owner’s Manual for more details.
Type A Type B
Type A Folding from inside (if equipped) Adjusting mirrors
Type B
Automatic door locks can be programmed to operate in different modes, or turned
OFF.
Shift position linked door locking/unlocking function
Doors lock when shifting from Park.
Doors unlock when shifting into Park.
Speed linked door locking function
Doors lock when the vehicle speed goes above approximately 12 mph (20 km/h).
Driver’s door linked door unlocking function
Doors unlock within 10 seconds after the engine switch is turned to “OFF” and
driver’s door is opened.
Refer to the Owner’s Manual for more details.
ADJUST AND FOLD
EXTEND (IF EQUIPPED)
Auto lock/unlock

10
FEATURES & OPERATIONS
Shift the shift lever to “S” position from “D” position.
Floor shift type:
+ : Upshift (push and release)
- : Downshift (pull and release)
Column shift type:
+ : Upshift (push and release)
- : Downshift (push and release)
Downshifting increases power going uphill, or provides engine braking downhill. For
best fuel economy during normal driving conditions, always drive with the shift lever
in the “D” position.
* The engine switch must be in the “ON” position (without Smart Key)/“IGNITION
ON” mode (with Smart Key) and the brake pedal depressed to shift from Park.
Park*
Reverse
Neutral
Drive
N
“S” mode
Park*
Reverse
Neutral
Drive
“S” mode
N
+ (“S” mode)
- (“S” mode)
+ (“S” mode)
-(“S” mode)
FLOOR SHIFT TYPE
COLUMN SHIFT TYPE
“S” (SEQUENTIAL) MODE
Automatic transmission

11
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
Tilt & telescopic steering wheel
Door locks
Lock
Lock
Unlock
Unlock
Hold wheel, push lever down, set angle and length, and return lever.
Tilt steering wheel
Driver side
Tilt and telescopic steering wheel
Front passenger side
Length
Lock release lever
Lock release lever
Angle
Push the control switch, set angle and length.
NOTE: Do not attempt to adjust while the vehicle is in motion.
When ignition key removed, the steering wheel moves up and away
from driver and stows, but returns to it’s position when key is inserted
(power-adjustable type).
Angle
Control switch
Length
Up
Toward the
driver
Away from
the driver
Down
Angle
MANUAL (IF EQUIPPED)
POWER (IF EQUIPPED)

12
Lights & turn signals
HEADLIGHTS
FOG LIGHTS (IF EQUIPPED)
TURN SIGNALS
Daytime Running Light system (DRL) Automatically turns on under certain
conditions to make vehicle more visible to other drivers. Not for use at night.
Automatic light cut off system (AUTO) Automatically turns lights off after 30
second delay, or lock switch on remote is pushed after locking.
Automatic High Beam system (AHB) Automatically switches between high
and low beams as appropriate to enhance vision at night.
Refer to Toyota Safety Sense™ P (TSS-P) in this guide or the Owner’s Manual for
more details on the Automatic High Beam feature.
* Operating conditions must be met. Refer to the Owner’s Manual for details.
Front fog lights come on only when the headlights are on low beam.
Right turn
Lane change
Lane change
Left turn
High beam
flasher
Parking lights
DRL OFF
Auto
Headlights
Turn
OFF
ON
FEATURES & OPERATIONS
High beam
or
Automatic High Beam*
Low beam

13
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
WITH INTERMITTENT WIPER
WITHOUT INTERMITTENT WIPER
Interval wipe
Mist
Slow
OFF
Fast
Pull to wash
and wipe
2
Mist
Slow
Fast
Pull to wash
and wipe
Adjust frequency*
* Intermittent windshield wiper frequency adjustment Rotate to increase/
decrease wipe frequency.
Windshield wipers & washers
Headlight leveling dial
Raise
Lower
OFF

14
FEATURES & OPERATIONS
Moonroof (if equipped)
Open Tilt
Close Close
Push once to open/close completely.
Lightly press either side of the moonroof switch while opening/tilting is in progress,
the moonroof stops partway.
SLIDING OPERATION TILTING OPERATION
Set: Depress
Release: Depress again
Parking brake
Steering lock release
When starting the engine, the engine
switch may seem stuck in the OFF. To
free it, turn the key while turning the
steering wheel slightly left and right.
A message will be displayed on the
multi-information display.
Check that the shift lever is in P. Press
the engine switch while turning the
steering wheel left and right.
With Smart Key systemWithout Smart Key system
Push
Turn
Turn
Turn

15
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
All window up/down (passenger side for some models and driver side) Push
the switch completely down or pull it completely up and release to fully open or
close.* To stop window part way, lightly push the switch in the opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window remains
operable.
* Not all models are equipped with one-touch close function.
Up Up
Down Down
Driver side (Type A)
Window lock switch
Driver side (Type B)
Windows-Power
Window-Power back (if equipped)
Double cab model
Close
Close Open
CrewMax model
Open
CrewMax model
Double cab model

16
FEATURES & OPERATIONS
Seat adjustments-Front (if equipped)
Split seat (passenger side)
Bench seat
MANUAL SEAT
POWER - DRIVER’S SEAT
Seat position (forward/backward)
Seat cushion length (if equipped) Seat height Lumbar support Seat cushion (front) angle
Seatback angle (center)
Seat position (forward/backward)
Seatback angle
Seatback angle
Seatback angleSeat position (forward/backward)

17
POWER - PASSENGER’S SEAT
Seat position (forward/backward)
Seatback angle
Seats-Head restraints
Seat folding-Rear
Front
(1)
(1)
(1)
(2)
(2)
(2)
To use To fold
Rear-Center seat (CrewMax models)
Rear-Center seat (Double Cab models)
Rear-Outer seat
OVERVIEWFEATURES & OPERATIONSTOYOTA SAFETY SENSESAFETY & EMERGENCY FEATURES
Lumbar support
Lock release button
Lock release button
(1)
(2)
(3) Lift up
Pull
Lock release button
Lock release button

18
FEATURES & OPERATIONS
Air conditioning/heating
MANUAL AIR CONDITIONING (IF EQUIPPED)
AUTOMATIC AIR CONDITIONING (IF EQUIPPED)
Windshield defogger
(outside air only)
Outside rear view mirrors defogger*,
wiper de-icer* or back window defogger**
Air conditioning ON/OFF
Climate control OFF
Temperature selector
(driver’s side)
Recirculate cabin air
(outside air when OFF) Airflow vent mode
Fan speed
Temperature selector
(front passenger’s side)
Synchronize temperature
settings for driver and passenger.
Automatic climate control ON
Adjusting the temperature setting will
cause the airflow vents, air intake and
fan to adjust automatically
to set temperature.
Air Conditioning ON/OFF
*If equipped
**CrewMax models only
*If equipped
**CrewMax models only
Airflow vent selector
Fan speed
Temperature selector
Recirculate cabin air
(outside air when OFF)
Select for maximum cooling. Air intake
will automatically be set to recirculate.
Outside rear view mirrors defogger*,
wiper de-icer* or back window
defogger**
