TP-Link Archer TX20U Plus User manual

REV1.0.0 1910012840
User Guide
AX1800 Dual Antennas High Gain Wireless USB Adapter
Archer TX20U Plus

Contents
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Chapter 1. Get to Know About Your Adapter . . . . . . . . . . . . . . . . . . . . .2
1. 1. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1. 2. LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2. Connect to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Chapter 3. Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3. 1. Install Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. 2. Join a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. 3. Uninstall Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 4. Appendix: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .9

1
About This Guide
This guide is a complement to Quick Installation Guide. The Quick Installation
Guide instructs you on quick installation, and this guide provides the product
overview and detailed instructions for each steps.
When using this guide, please notice that features available of the adapter may
vary by model and software version. It may also vary by region or ISP. All images,
steps, and descriptions in this guide are only examples and may not reflect your
actual experience.
Conventions
In this guide, the following conventions are used:
Convention Description
Underlined Underlined words or phrases are hyperlinks. You can click to redirect to a
website or a specific section.
Teal Contents to be emphasized and texts on the web page are in teal, including
the menus, items, buttons, etc.
Note: Ignoring this type of note might result in a malfunction or damage to the
device.
Tips: Indicates important information that helps you make better use of your
device.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications.
Actual wireless data throughput , wireless coverage, and number of connected devices are not guaranteed
and will vary as a result of network conditions, AP limitations, and environmental factors, including building
materials, obstacles, volume and density of traffic, and AP location.
‡Use of Wi-Fi 6 (802.11ax), and features including OFDMA, MU-MIMO, and 1024-QAM require APs to also
support the corresponding features.
§Functionality of Archer TX20U Plus may be restricted on some operating systems and platforms. Please
try to update the device’s driver for feature compatibility.
△Use of WPA3 requires APs to also support the corresponding feature.
More Info
•The latest driver can be found at Download Center
at https://www.tp-link.com/support.
•The Quick Installation Guide can be found where you find this guide or inside
the package of the router.
•Specifications can be found on the product page at https://www.tp-link.com.
•A TP-Link Community is provided for you to discuss our products at
https://community.tp-link.com.
•Our Technical Support contact information can be found at the Contact
Technical Support page at https://www.tp-link.com/support.

Chapter 1
Get to Know About Your
Adapter
This chapter introduces what the adapter can do and shows its appearance.
This chapter contains the following sections:
• Product Overview
• LED Status

3
Chapter 1 Get to Know about Your Adapter
1. 1. Product Overview
The latest Wi-Fi 6 standard guarantees extreme speeds, ultra-low latency, and
uninterrupted connections. Archer TX20U Plus arms your PC with Wi-Fi 6 to
ensure powerful, continuous signal reception, unlocking your Wi-Fi 6 router’s
full potential.
1. 2. LED Status
You can check the adapter’s working status by following the LED explanation
table.
Status Indication
On The driver has been installed successfully.
Off The driver is not installed.
The adapter is not detected.
Tips:
If the LED is off, try these troubleshooting tips:
1. Check if the adapter is recognized and enabled or not. Refer to Troubleshooting-T2 for detailed
instructions.
2. Remove and reinsert the adapter.
3. Reinstall the software, if necessary.
