TP-Link td-w8970 User manual

1
Installation
Insert the provided Resource
CD into your CD-ROM drive.
Please select you
r
product model and
click Start Setup.
1
CD Setup Wizard
Note The product model shown in this QIG is TD-W8970, as an example.
IMPORTANT INFORMATION
zFor Windows users, please refer to 1. CD Setup Wizard on
page 1 for step-by-step guidance.
zFor Mac OS/Linux users or Windows users who cannot run
the mini CD, please refer to 2. Web-based Quick Setup
Wizard on page 2 for step-by-step guidance.

2
Step 1: Connect your devices step by step following the figure below.
Then a flash video will pop
up and show you how to
connect your devices.
Please connect the devices
step by step following the
flash. When you finish the
hardware connection, click
the to continue.
Note The basic settings for your modem router are completed. Please open the
web browser and try to log on to some popular websites to test you
r
Internet connection. If you cannot access the Internet, please refer to T4
in Troubleshooting.
The Easy Setup Assistant
will start. Please check to
see if the LEDs of you
r
modem router display
normally as the chart
describes. Then click NEXT,
and follow the step-by-step
instruction until you
complete the configuration.
Hardware connection.
Note For the advance configurations, please refer to the User Guide on the
Resource CD provided. You can also log on to www.tp-link.com →select
your region →search for the product →User Guide can be found unde
r
the “Download” tab on the product page.
2
Web-based Quick Setu
p
Wizard

3
Step 2: Power on all your network devices and then check the LEDs.
Open your web browser and
type 192.168.1.1 in the
address bar and
p
ress Enter.
Note If you cannot access 192.168.1.1, please refer to T3 in Troubleshooting.
ADSL: Solid light or flashing
POWER: Solid light
WLAN: Solid light or flashing
LAN: Solid light if the corresponding
port is connected

4
Enter the modem router’s
default username and
password: admin/admin,
then click OK.
Note If you forget the password, please refer to T2 in Troubleshooting.
Click Quick Setup and
then enter VPI/VCI values
provided by your ISP. Click
Next to continue.
Select ADSL Connection
Type and then click Next to
continue. Here we use
PPPoE as an example.
Enter the PPPoE Username
and Password provided by
your ISP. After confirming
the password, click Next to
continue.
Note If you don’t have the VPI, VCI and Connection Type information, please
contact your ISP for this information.
Bridge mode is not recommended because it doesn’t allow Internet
access sharin
g
for multi
p
le com
p
uters.
Note
Record your PPPoE information here:
Username:
Password:

5
The Wireless function is
enabled by default. Create an
easy-to-remember Wireless
Network Name (SSID). It is
also strongly recommended to
set a password for the
wireless network to prevent
outside intrusion. Click Next to
continue.
Note Disable Wireless Security is not recommended.
Please confirm all parameters.
Click Back to modify them or
click Save to save your
settings. Then the following
page will display, click Finish
to make your settings take
effect.
Note The basic settings for your modem router are completed. Please open the
web browser and try to log on to some popular websites to test you
r
Internet connection. If you cannot access the Internet, please refer to T4
in Troubleshooting.
Record your wireless information here:
WirelessNetworkName(SSID):
Password:
For the advanced configurations, please log on to www.tp-link.com →
select your region→search for the product →User Guide can be
found under the “Download” tab on the product page.
Note

6
Note
T1. How can I restore my modem router’s configuration to its factory default
settings?
T2. What can I do if I forget the modem router’s password?
1) Restore the modem router’s configuration to its factory default settings. If you
don’t know how to do that, please refer to T1.
2) Try the default user name and password: admin, admin.
3) Try to configure your modem router once again following the instructions in
the previous steps of the QIG.
T3. What can I do if I cannot access 192.168.1.1?
For Windows 7/Vista
Go to ‘Start > Settings > Control Panel’. Click ‘View network status and tasks
> View status > Properties’ and double-click ‘Internet Protocol Version 4
(TCP/IPv4)’. Select ‘Obtain an IP address automatically’, choose ‘Obtain DNS
server address automatically’ and then click ‘OK’.
For Windows XP/2000
Go to ‘Start > Control Panel’. Click ‘Network and Internet Connections >
Network Connections’. Right-click ‘Local Area Connection’, select
‘Properties’ and then double-click ‘Internet Protocol (TCP/IP)’. Select ‘Obtain
an IP address automatically’, choose ‘Obtain DNS server address
automatically’ and then click ‘OK’.
For Mac OS
Click the icon at the right top of your desktop. Then click ‘Open Network
Preferences…’. Choose ‘AirPort’ and click ‘Advanced…’. Choose ’TCP/IP’. Set
the ‘Configure IPv4’ as ‘Using DHCP’ and then click ‘OK’.
Once the modem router is reset, the current settings will be lost and you
will need to reconfigure the modem router. We strongly suggest you back
up current settings before resetting the modem router.
With the modem router powered
on, use a pin to press and hold the
RESET button on the rear panel fo
r
8 to 10 seconds before releasing it.
Troubleshooting

7
Note
T4. What can I do if I cannot access the Internet?
1) Check to see if all the connectors are connected well, including the telephone
line, Ethernet cables and power adapter.
2) Check to see if you can log on to the web management page of the modem
router. The default IP address of the web management page is 192.168.1.1.
If you can, try the following steps. If you cannot, please set your computer
referring to T3 then try to see if you can access the Internet. If the problem
still exists, please go to the next step.
3) Consult your ISP and make sure all the VPI/VCI, Connection Type, account
username and password are correct. If there are any mistakes, please correct
the settings and try again.
4) If you still cannot access the Internet, please restore your modem router to its
factory default settings and reconfigure your modem router following the
instructions of this QIG.
5) Please feel free to contact our Technical Support if the problem still exists.
T5. How can I configure the USB features?
Please refer to our Application Guides. There are two ways to get them:
1) Open the Resource CD, and then find the folder named “Application Guide”.
The Application Guides will be found there.
2) Log on to the website: http://www.tp-link.com/app/usb/?siteid=1
For more details about Troubleshooting and Technical Support contact
information, please log on to our Technical Support Website:
http://www.tp-link.com/en/support
